Serve DEWS100GBBK06 - Electric bottle opener Dash - Free user manual and instructions

Product type	Electric wine opener with wine preservation system
Brand	Dash
Model	Serve DEWS100GBBK06
Dimensions (approx.)	25 cm (height) x 10 cm (width) x 10 cm (depth)
Weight (approx.)	0.5 kg
Power source	Built-in rechargeable battery, AC/DC adapter and charging base included
Main functions	Automatic cork extraction, vacuum wine preservation
Intended use	Domestic, for standard wine bottles
Housing material	Plastic
Compatible cork type	Natural and synthetic cork
Battery life	Approximately 30 openings per charge (estimated)
Charging time	Approximately 4 hours (estimated)
Care and cleaning	Do not immerse, clean with a damp cloth
Safety	Do not use near water, keep out of reach of children, do not open the housing
Spare parts	AC/DC adapter, charging base, corkscrew spiral
Repairability	No user-serviceable parts, battery replaceable by a professional
Operating conditions	Indoor only, room temperature, avoid moisture
Warranty	Refer to user manual for conditions

Frequently Asked Questions - Serve DEWS100GBBK06 Dash

How to charge the Dash Serve DEWS100GBBK06 wine opener?

Place the device on the provided charging base and plug in the AC/DC adapter. The indicator light turns on during charging. A full charge takes approximately 4 hours.

How to use the electric wine opener?

Ensure the device is charged. Place it vertically on the wine bottle, centering the spiral on the cork. Press the start button. The device automatically extracts the cork. Once removed, press the eject button to release the cork.

What to do if the battery does not hold a charge?

Check that the charging base and adapter are properly connected. If the problem persists, the battery may be defective. Contact customer service for a replacement. Do not attempt to replace the battery yourself.

How to clean the wine opener?

Unplug the device. Wipe the housing with a slightly damp soft cloth. Do not use abrasive products. Never immerse the device in water. The spiral can be cleaned with a dry cloth.

Can this wine opener be used on all types of corks?

It is designed for natural and synthetic corks on standard wine bottles. Do not use on plastic corks or capsules.

Is the device safe for children?

This device is not intended for children. Keep it out of their reach. The spiral is sharp and can cause injury. Supervise children nearby.

What to do if the device does not turn on?

Check the charge: place it on the base, the light should turn on. If no light, check the adapter and outlet. If still no power, contact after-sales service.

Can the wine opener be used without the charging base?

No, the charging base is necessary to recharge the battery. The device does not operate plugged directly into the mains. Use only the provided adapter and base.

How to preserve wine after opening?

This set includes a wine preservation system. After opening, use the vacuum pump (if provided) to remove air and seal with the preservation stopper. Store the bottle in the refrigerator.

Where can I find spare parts?

Spare parts such as the adapter or charging base are available from the manufacturer or authorized retailers. Contact Dash customer service for more information.

USER MANUAL Serve DEWS100GBBK06 Dash

Exterior view of a modern electric water purifier with black and gray casing (no text or symbols visible)

DEWS100

SERVE & PRESERVE

ELECTRIC WINE SET

Instruction Manual

Simple line drawing of a wine bottle and a glass (no text or symbols)

SERVE & PRESERVE ELECTRIC WINE SET

Important Safeguards....4-7

Parts & Features....8-9

Using Your Electric Wine Set....10-18

Cleaning & Maintenance....19

Notes....20-21

Customer Support....22

Warranty....23

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

When using electrical appliances, basic safety precautions should be followed, including:

• Read all instructions.
• Remove all bags and packaging from appliance before use.
• Never leave appliance unattended when in use
  • Make sure the appliance is cleaned thoroughly before using.
  • This Wine Opener and Wine Preserver Set is intended for household use only.
• This Wine Opener and Wine Preserver Set is intended to extract the corks from standard wine bottles.
• Do not operate the Wine Opener and Wine Preserver Set with a damaged AC/DC Adapter or Charging Base. If the AC/DC Adapter is damaged it must be replaced by the manufacturer or a suitably qualified person.
• Do not place the appliance near an open flame, cooking or heating appliance, or hot surface.
• This appliance is not intended for use in wet or damp conditions.
• Ensure that the power cord is positioned so that it will not get damaged or cause a trip hazard.
• Use only the AC/DC Adapter and Charging Base supplied with the appliance.

• Do not immerse the appliance in water or any other liquid.

• For indoor use only. Do not expose the Wine Opener and Wine Preserver Set or Charging Base to rain or other extreme conditions.

• Never force the Wine Opener and Wine Preserver Set onto a bottle or attempt to speed up the mechanism. The Cork Remover will work best when it is operated at its intended speed.
• Do not touch or adjust the Wine Opener and Wine Preserver Set mechanism or the corkscrew spiral. Only hold the Cork Remover by its plastic housing.
• This appliance contains a re-chargeable battery. Do not dispose of the product on a fire as this may cause an explosion.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
  • To avoid electric shock do not open the casing. There are no user serviceable parts inside.

• CAUTION: The corkscrew is sharp. Keep body parts (e.g. fingers) and utensils away from the operating end of the Wine Opener.

• This Wine Set contains rechargeable batteries. Before you dispose of your Wine Opener and Wine Preserver, you should remove the batteries and dispose of them responsibly. To take out the battery pack remove the screws from the rear cover. Dispose of the rechargeable batteries and product responsibly.

• The WEEE directive (Waste Electrical and Electronic Equipment; 2002/96/EC) has been put in place to ensure that products are recycled using best available treatment, recovery and recycling techniques to ensure human health and high level environment protection. Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
• Do not mix products bearing the crossed out bin symbol with your general household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

GARANTIES IMPORTANTES GARANTIES IMPORTANTES

GARANTIES IMPORTANTES: VEUILLEZ LIRE ATTEN- TIVEMENT CE MANUEL AVANT D'UTILISER L'APPAREIL.

Vacuum Wine Presserver ▲ Button ▼ Button Wine Opener LED Indicator Light Non-Slip Mouth Charging Base Wine Stoppers Stainless Foil Cutter

Power Adapter Power PlugPower Socket

USING YOUR ELECTRIC WINE SET USING YOUR ELECTRIC WINE SET

CHARGING THE WINE OPENER AND WINE PRESERVER UNIT

NOTE: It is recommended that the Wine Opener and Vacuum Wine Preserver Unit is charged for at least 12 hours before using it for the first time.

Please follow the instructions for charging the unit below:

1 Connect the Power Plug into the Power Socket at the back of the Charging Base.
2 Place the Wine Opener and Vacuum Wine Preserver onto the Charging Base. Ensure that the arrows on the Unit and Base align with each other so that the electrical connections are made correctly.
3 Plug in the Charging Base. The LED Indicator Light will illuminate blue, indicating that the battery is charging. It will take 10-12 hours to fully charge the battery.
4 To stop charging, remove the plug from the outlet. Remove the Power Plug from the Charging Base.
5 The Wine Opener can be used to open up to 30 bottles when fully charged.

NOTE: This Wine Opener has intelligent light features;

• When battery power is low, the LED Indicator Light will flash blue when connected to a power source.
• When the unit is completely charged, the LED Indicator Light will be solid blue.

OPENING WINE BOTTLES

Close-up of hands holding a black and white object with a black handle, no visible text or symbols

1 Before extracting the cork, please remove any seal from the bottle using the Foil Cutter provided (photo A).

Hand holding a silver and black electric water heater with a spiral glass, next to a small black object (no text or symbols visible)

2 Place the Wine Opener on top of the wine bottle making sure that it remains as upright as possible at all times. If you hold the Wine Opener at an angle to the bottle it will not remove the cork properly (photo B).

USING YOUR ELECTRIC WINE SET USING YOUR ELECTRIC WINE SET

Close-up of a hand holding a metallic wine stopper with a glass and black barrel (no visible text or symbols)

3 Hold the Wine Opener and bottle firmly. Press and hold the ▼ Button (photo C). The corkscrew spiral will turn in a clockwise direction and enter the cork, then gradually remove it from the bottle.

When the Cork Remover mechanism stops, the cork will be visible through the transparent window and the blue LED Indicator Light will go off.

Close-up of a hand holding a small object with a lit water stopper (no visible text or symbols)

4 Lift the Wine Opener away from the bottle. To remove the cork simply press and hold the ▲Button and the spiral will turn in a counterclockwise direction and release the cork (photo D).

Hand holding a silver cylindrical device with a small knob, next to a base (no visible text or symbols)

5 Return the Wine Opener to the Charging Base when not in use, so as to protect the mechanism (photo E).

NOTE: This Wine Opener is designed for use with traditional corks, but it may be used with synthetic corks as well.

Synthetic corks are smaller and do not expand like normal cork so sometimes they may stick on the spiral. If this happens, hold the cork firmly with a small pair of pliers. Press and hold the ▲ Button and allow the cork to be slowly released.

USING YOUR ELECTRIC WINE SET USING YOUR ELECTRIC WINE SET

SEALING WINE BOTTLES

Hand pouring liquid from a bottle into a stopper (no text or symbols visible)

1 Place the wine bottle on a flat surface. Insert a Wine Stopper into the wine bottle (photo A).

Hand holding a silver handheld device with a black connector, against a plain background (no text or symbols visible)

2 Hold the Wine Stopper and wine bottle neck securely in one hand and place the Non-Slip Mouth of the Vacuum Wine Preserver on the Wine Stopper (photo B).
Please use light, steady pressure on the stopper when using the Vacuum Wine Preserver.

Hand holding a silver and black electric shaver device (no visible text or symbols)

3 Keep the Vacuum Wine Preserver as straight as possible and in line with the wine bottle (photo C).

Hand holding a silver cylindrical device with black handle, no visible text or symbols

4 Push down on the Wine Stopper using light, steady pressure (photo D).

USING YOUR ELECTRIC WINE SET

Close-up of a hand holding a silver handheld device with a black handle (no visible text or symbols)

5 The Wine Preserver removes the air from the bottle while making a light vacuum sound, and the blue LED Indicator Light on the top will light up. The motor will stop working after 15 seconds. The blue LED Indicator Light on top will turn off and a beep will sound when the motor stops (photo E).

Hand holding a silver cylindrical device with a small base, against a plain white background (no text or symbols visible)

6 Do not release the Wine Preserver until the unit stops. Remove the Wine Preserver and replace on its charging base until it is needed again (photo F).

NOTE: The Non-Slip Mouth may attach itself to the wine stopper. In this case, hold the wine stopper and the neck of the bottle securely in one hand and tilt the Wine Preserver away from the Wine Stopper to break the suction. This should prevent air from re-entering the bottle. If in doubt, repeat the above operating process.

SUGGESTION: For more than half a bottle of wine remaining, one session should suffice. For less than half a bottle we suggest you repeat the above process a 2nd time.

Close-up of wine being poured into a glass with red liquid, no visible text or symbols

USING YOUR ELECTRIC WINE SET CLEANING & MAINTENANCE

SETTING DATE INDICATORS

Close-up of hands adjusting a black mechanical component with a metallic clip (no visible text or symbols)

1 Use the ▼ symbol to indicate the date when the bottle was sealed with your Wine Preserver (photo A).

Close-up of a hand holding a black cylindrical object with a white lid, labeled 'B' in red (no text or symbols on the object itself)

2 Gently swivel the silver ring to left or right until the correct date is in line with the ▼ symbol (photo B).

REMOVING WINE STOPPERS

1 Firmly hold the bottle in one hand and gently ease the Wine Stopper away from the bottle with the other hand.
2 Store the Wine Stoppers in a clean, safe place until next required.

· 18 ·

• We recommend that you return your Wine Opener and Wine Preserver to the Charging Base so that it is fully charged and available to use at any time.
- Wipe the Wine Opener and Vacuum Wine Preserver Set and Charging Base with a soft, dry cloth.
- Wine Stoppers can be handwashed with warm soapy water and air-dried. Wine Stoppers are NOT dishwasher safe.

Still life arrangement of wine bottles, grapes, cheese, and a wine bottle on a white background (no text or symbols)

19

NOTES NOTES

CUSTOMER SUPPORT

WARRANTYWAR

FEEL GOOD GUARANTEE ^TM

Dash values quality and workmanship and stands behind this product with our Feel Good Guarantee™. To learn more about our commitment to quality, visit bydash.com/feelgood.

Our customer support teams in the US and Canada are at your service Monday - Friday during the times below. Contact us at 1 [phone] or [e-mail]

7am 7pm 8am 8pm 9am 9pm 10am 10pm

Hey Hawaii! You can reach our customer service team from 5AM to 5PM. And also, Alaska, feel free to reach out from 6AM to 6PM.

STOREBOUND, LLC - 1 YEAR LIMITED WARRANTY

Your StoreBound product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase when utilized for normal and intended household use. Should any defect covered by the terms of the limited warranty be discovered within one (1) year, StoreBound, LLC will repair or replace the defective part. To process a warranty claim, contact Customer Support at 1-800-898-6970 for further assistance and instruction. A Customer Support agent will assist you by troubleshooting minor problems. If troubleshooting fails to fix the problem, a return authorization will be issued. Proof of purchase indicating the date and place of purchase is required and should accompany the return. You must also include your full name, shipping address, and telephone number. We are unable to ship returns to a PO box. StoreBound will not be responsible for delays or unprocessed claims resulting from a purchaser's failure to provide any or all of the necessary information. Freight costs must be prepaid by the purchaser.

Send all inquiries to [e-mail].

There are no express warranties except as listed above.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CUSTOMER. STOREBOUND SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE LAW. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts. Therefore, the above exclusions or limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.

REPAIRS

DANGER! Risk of electric shock! The Dash Serve & Preserve Electric Wine Set is an electrical appliance. Do not attempt to repair the appliance yourself under any circumstances. Contact Customer Support regarding repairs to the appliance.

TECHNICAL SPECIFICATIONS

Voltage 6V DC 80mA

Power Rating 0.48W

Stock#: DEWS100 IM 200626 v3

Made in China

DASH®
