| Product Type | VGA + Audio to HDMI Video Adapter |
| Brand | Tripp Lite |
| Model | P116-006-HDMI-A |
| Connectors | 1 x HDMI Male, 1 x VGA HD15 Male, 1 x 3.5mm Audio Male, 1 x USB-A Male (power) |
| Cable Length | 1.8 m (6 ft) |
| Maximum Resolution | 1920 x 1080 @ 60 Hz |
| Supported Video Standards | HDMI 1.2, HDCP 1.3 |
| Power | Bus-powered via USB-A connector (5V, 500mA typical) |
| Audio Compatibility | Stereo audio via 3.5mm input, embedded into HDMI signal |
| Installation | Plug-and-play, no software or driver required |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Storage Temperature | -20 to 60°C (-4 to 140°F) |
| Storage Humidity | 10 to 90% RH, non-condensing |
| Warranty | 2 years (limited) |
| Weight | Approximately 100 g (estimated) |
Frequently Asked Questions - P116006HDMIA Tripp Lite
User questions about P116006HDMIA Tripp Lite
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Video adapter in PDF format for free! Find your manual P116006HDMIA - Tripp Lite and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. P116006HDMIA by Tripp Lite.
USER MANUAL P116006HDMIA Tripp Lite
VGA + Audio to HDMI Adapter Cable (M/M), 6 ft.
Model: P116-006-HDMI-A
Español 5 • Français 9 • Русский 13
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value! www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Product Features
- All-in-one solution to connect a VGA + audio source to an HDMI display
• Supports resolutions up to 1920 x 1080 @ 60 Hz
• HDCP 1.2 and HDMI 1.3 compliant - Bus-powered via USB-A connector
- Plug-and-play—no software or drivers to install
Package Contents
• P116-006-HDMI-A
- Quick Start Guide
Installation
Note: Make sure all devices you are connecting are powered off prior to installation.
1 Connect the VGA connector to the source's VGA port.
2 Connect the 3.5 mm plug to the source's audio jack.
3 Connect the built-in USB connector to a USB port on a USB charger or VGA source.
4 Connect the HDMI connector to an HDMI display.
Specifications
| Connectors | |
| HDMI HDMI (Male) | |
| VGA HD15 (Male) | |
| Audio 3.5 mm (Male) | |
| USB USB-A (Male) | |
| Environmental | |
| Operating Temperature 32 to | 104°F (0 to 40°C) |
| Storage Temperature -4 to 1 | 40°F (-20 to 60°C) |
| Storage Humidity 10% to 9 | 0% RH, Non-Condensing |
Warranty and Product Registration
2-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of two (2) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
Warranty and Product Registration
Product Registration
Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:
- Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
- Send the new equipment back for recycling when this ultimately becomes waste
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Product specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
17-09-026 93-3700_RevC
