U44406NDVIAM - Video adapter Tripp Lite - Free user manual and instructions

Product Type	USB-C to DVI Video Adapter
Brand	Tripp Lite
Model	U44406NDVIAM (White) / U44406N-DVIBAM (Black)
Input Connector	USB Type-C (Male)
Output Connector	DVI-D (Female)
Maximum Resolution	1920 x 1080 (1080p) @ 60 Hz
Color Depth	36-bit Deep Color (12 bits per channel)
USB Data Rate	Up to 5 Gbps (USB 3.1 Gen 1)
DVI Transfer Rate	6.75 Gbps (2.25 Gbps per channel)
Alternate Mode Support	USB DisplayPort (Alternate Mode)
External Power Required	No
Installation	Plug-and-play, no driver required
Operating Temperature	0° to 45 °C
Operating Humidity	10 to 85% RH (non-condensing)
Storage Temperature	-10° to 70 °C
Storage Humidity	5 to 90% RH (non-condensing)
Warranty	3-year limited
Package Contents	Adapter and quick start guide
Compatibility	USB-C devices supporting USB DisplayPort Alternate Mode (tablets, laptops, MacBook, Chromebook, smartphones)
Care and Cleaning	Clean with a dry, lint-free cloth. Do not use abrasive liquids.
Safety	Use within specified temperature and humidity ranges. Do not expose to shock or excessive moisture.
Spare Parts and Repairability	No user-serviceable parts. Contact technical support for any repairs.

Frequently Asked Questions - U44406NDVIAM Tripp Lite

Which devices are compatible with this adapter?

This adapter is compatible with any device featuring a USB Type-C port that supports USB DisplayPort Alternate Mode, such as laptops, tablets, MacBook, Chromebook, and some smartphones.

What maximum video resolution does it support?

It supports a maximum resolution of 1920 x 1080 (1080p) at 60 Hz with 36-bit Deep Color.

Do I need external power for the adapter?

No, the adapter is powered by your device's USB-C port. No external power supply is required.

What DVI cable should I use?

You must use a standard DVI cable (not included). Tripp Lite recommends its P561 series cables.

Can I use this adapter with a DVI projector?

Yes, the adapter works with any monitor or projector equipped with a DVI input.

Does the adapter require driver installation?

No, it is plug-and-play. No additional drivers or software are needed.

What is the difference between the white and black models?

The only difference is color. The white model is U444-06N-DVI-AM and the black model is U444-06N-DVIBAM. Performance is identical.

What to do if no image displays on the monitor?

Check that your source device supports USB DisplayPort Alternate Mode. Ensure the DVI cable is properly connected. Adjust your computer's display settings to extend or duplicate the screen.

Is this adapter compatible with MacBook?

Yes, it is compatible with MacBook and other Apple computers with a USB-C port supporting DisplayPort Alternate Mode.

What is the warranty on this adapter?

Tripp Lite offers a limited 3-year warranty against defects in materials and workmanship.

USER MANUAL U44406NDVIAM Tripp Lite

USB 3.1 Gen 1 to DVI Alternate Mode Adapter

Model: U444-06N-DVI-AM (White), U444-06N-DVIBAM (Black)

Español 8 • Français 14 • Русский 20

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

TRIPP·LITE

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved.

Product Features

• Connects your existing DVI TV, monitor or projector to the USB-C or Thunderbolt 3 port on your tablet, laptop, notebook, MacBook, Chromebook, smartphone or PC
• Supports USB DisplayPort Alternate Mode for transmitting video
  • Supports USB 3.1 Gen 1 data transfer rates up to 5 Gbps
  • Supports HD video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
  • Supports 36-bit Deep Color (12 bits per channel)
• Supports DVI transfer rates up to 6.75 Gbps (2.25 Gbps per channel)
• Plug-and-play adapter—no software, drivers or external power required

USB Type-C ^™ and USB-C ^™ are trademarks of USB Implementers Forum.

Package Contents

• U444-06N-DVI-AM (White) or U444-06N-DVIBAM (Black)
- Quick Start Guide

System Requirements

• USB Type-C (USB-C) device that supports USB DisplayPort Alternate Mode
  • DVI-enabled monitor

Installation

1. Connect the adapter's USB Type-C connector to the USB Type-C port on your tablet, laptop, notebook, MacBook, Chromebook, smartphone or PC.
2. Connect the adapter's DVI port to a monitor using a DVI cable (such as Tripp Lite's P561-Series cables).
3. The video image will appear on the add-on monitor. Customize how video is displayed on the add-on monitor using your device's display settings.

Specifications

Connectors
USB USB Type-C (Male)
Display DVI-D (Female)
Video
Maximum Resolution 1920 x	1080 (1080p)
Color Depth 36-bit Deep Color	(12-bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 5% to 90%	RH, Non-Condensing
Power Requirements
External Power Supply No

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
