| Product type | Electric slicer |
| Brand | Exquisit |
| Model | AS 3301 gri |
| Color | Grey |
| Power supply | 220-240 V ~ 50 Hz |
| Blade | Stainless steel circular blade |
| Tray material | Stainless steel |
| Cutting thickness | Adjustable via knob |
| Safety device | Thumb guard, carriage with guide |
| Switch | On/Off (positions I and 0) |
| Recommended break | At least 10 minutes |
| Suitable foods | Cheeses, boneless meats, bread, preparations |
| Unsuitable foods | Frozen foods, bones, pits, packaging |
| Cleaning | Removable blade, hand washing, not dishwasher safe |
| Maintenance | Oil or moisten the blade before use |
| Ambient conditions | 0 to +40°C |
| Estimated weight | Approximately 3.5 kg |
| Estimated dimensions (LxWxH) | Approximately 30 x 25 x 25 cm |
| Included accessories | Carriage, guide, thumb guard |
| After-sales service | www.ggv-service.de |
| Warranty | Legal, covers manufacturing and material defects |
| Approval | Directive 2012/19/EU (WEEE) |
Frequently Asked Questions - AS 3301 gri Exquisit
How to use the Exquisit AS 3301 gri slicer?
Place the appliance on a flat, stable surface. Attach the guide to the carriage. Plug in the appliance. Place a plate behind the blade. Place the food on the tray, push it with the guide and adjust the thickness with the knob. Turn the switch to position I. Guide the food towards the blade using the carriage. To stop, turn the switch to position 0.
How to clean the Exquisit AS 3301 gri slicer?
Before cleaning, unplug the appliance and set the switch to 0. Clean with a soft cloth or paper towel. Never immerse the appliance in water and do not put it in the dishwasher. For thorough cleaning, you can disassemble the blade by turning the locking device in the middle. Be careful as the blade is very sharp.
How to disassemble the blade of the slicer?
Set the switch to 0, unplug the appliance, then turn the locking device located in the middle of the blade. After cleaning, put the blade back in its initial position and release the lock. Caution: the blade is extremely sharp, handle with care.
What foods can I cut with this slicer?
You can cut cheeses, boneless meats, bread and preparations. Do not cut frozen foods, with bones, large pits, or packaging like aluminum foil.
What is the maximum continuous operation time?
The maximum continuous operation time is indicated on the rating plate by 'KB xx min'. Respect breaks of at least 10 minutes to avoid damaging the motor.
How to adjust the cutting thickness?
Use the adjustment knob (mark 5) to set the slice thickness according to your need.
Can I use the slicer without the carriage and guide?
It is strongly recommended to use the carriage and guide to protect your hands. If the food is too large, hold it firmly as far away from the blade as possible.
What to do if the blade jams or slows down?
Slightly pull back the food and start again, slowly advancing towards the blade. Lightly moisten or oil the blade to prevent food from sticking.
How to maintain the slicer?
Before each use, lightly moisten or oil the blade. After use, clean it with a soft cloth. Store the appliance in a dry place.
Where can I get spare parts or repair?
For defective parts under warranty, order only the accessory from www.ggv-service.de. After warranty, contact a qualified service. The site also offers a service portal.
