USER MANUAL K Mini Kärcher

Register your product www.kaercher.com/welcome

91 dB(A) EU-Konformitätserklärung Produkt: Hochdruckreiniger Typ: 1.600-xxx Einschlägige EU-Richtlinien 2006/42/EG (+2009/127/EG) 2014/30/EU 2011/65/EU 2000/14/EG Angewandte harmonisierte Normen EN 60335–1 EN 60335–2–79 EN 62233: 2008 EN 55014–1: 2017 EN 55014–2: 2015 EN 61000–3–2: 2014 EN 61000–3–3: 2013 EN 50581 Angewandtes Konformitätsbewertungsverfahren 2000/14/EG: Anhang V Schallleistungspegel dB(A) Gemessen: 89 Garantiert: 91 Winnenden, 2020/08/01 Chairman of the Board of Management Director Regulatory Affairs & Certification 7DE– 4 Please read these original operating in- structions and the enclosed safety in- structions prior to the initial use of your device. Proceed accordingly. Keep both booklets for future reference or subsequent owners. 몇 CAUTION Safety installations serve the protection of the user and may not be modified or bypassed. The appliance switch prevents unintentional operation of the appliance. This lock locks the lever of the trigger gun and prevents the inadvertent start of the appliance. The overflow valve prevents the permissible working pressure from being exceeded. If the lever on the trigger gun is released the pressure switch turns off the pump, the high pressure jet is stopped. If the lever is pulled the pump is turned on again. This high pressure cleaner is designed for domestic use only. – for cleaning machines, vehicles, buildings, tools, facades, terraces, gardening tools, etc. by means of a high-pressure water jet (if necessary, with ad- ditional cleaning agents). – with accessories, replacement parts and cleaning agents approved by KÄRCHER. Please observe the information accompanying the cleaning agents. Only use original accessories and spare parts, they en- sure the safe and trouble-free operation of the device. For information about accessories and spare parts, please visit www.kaercher.com. Notes about the ingredients (REACH) You will find current information about the ingredients at: www.kaercher.com/REACH Contents Safety ... EN 4 Proper use... EN 4 Accessories and Spare Parts ... EN 4 Environmental protection... EN 4 Description of the Appliance ... EN 5 Assembly... EN 5 Start up ... EN 5 Operation...EN5 Transport ...EN6 Storage ... EN 6 Care and maintenance ... EN 6 Troubleshooting... EN 6 Warranty ...EN7 Technical specifications... EN 7 EU Declaration of Conformity ... EN 7 Safety Symbols on the machine The high pressure jet must not be directed at persons, animals, live electrical equipment or at the appliance itself. Protect the appliance against frost. The appliance must not be directly connect- ed to the public drinking water network. Safety Devices Appliance switch Lock trigger gun Overflow valve with pressure switch Proper use Accessories and Spare Parts Environmental protection The packaging material can be recycled. Please arrange for the environmentally appropriate dis- posal of the packaging. Old appliances contain valuable recyclable mate- rials that should be recycled properly. Please ar- range for the environmentally appropriate disposal of the old devices. Electrical and electronic devices often contain components which could potentially pose a dan- ger to human health and the environment if han- dled or disposed of incorrectly. However, these components are necessary for the proper opera- tion of the device. Devices marked with this sym- bol must not be disposed of with regular house- hold rubbish. Cleaning operations which produce oily waste wa- ter, e.g. engine washes, underbody washes, may only be carried out using washing stations equipped with an oil separator. 8 EN– 5 The scope of delivery of your appliance is illustrated on the packaging. Check the contents of the appliance for completeness when unpacking. In the event of missing accessories or any transport damage, please contact your dealer. Illustrations on Page 2 1 Water connection with integrated sieve 2 Coupling element for water connection 3 High pressure connection 4 Accessory compartment 5 Carrying handle 6 Mains cable with mains plug 7 Cable clip 8 Storage for mains cable 9 Appliance switch „0/OFF“ / „I/ON“ 10 Trigger gun 11 Lock trigger gun 12 Clamp for high pressure hose 13 Safety cover 14 Spray lance extension 15 Spray lance with pressure regulation (Vario Power) The working pressure can be continuously in- creased from "SOFT" to "HARD". To adjust the working pressure, release the trigger gun lever and turn the spray lance to the desired position. 16 High pressure hose Mount loose parts delivered with appliance prior to start- up. Illustrations on Page 3 Illustration Screw the coupling element to the water connec- tion on the appliance. Illustration Pull out the clamp for the high pressure hose from the trigger gun. Illustration Connect high pressure hose to trigger gun. Push the clamp in until it locks. Check the secure connection by pulling on the high-pressure hose. Park the appliance on an even surface. Illustration Connect the high pressure hose to the high pres- sure connection of the appliance. Check the secure connection by pulling on the high pressure hose. Insert the mains plug into the socket. For connection values, see type plate/technical data. Observe regulations of water supplier. ATTENTION Impurities in the water can damage the high-pressure pump and the accessories. For protection, the use of the KÄRCHER water filter (optional accessory, order no. 4.730-059) is recommended. Attach the water supply hose to the coupling on the water connection. Connect the water supply hose to the water supply. Completely open the water tap. ATTENTION Dry running of more than 2 minutes leads to damage of the high-pressure pump. If the appliance does not build up pressure within 2 minutes, switch the appliance off and proceed in accordance with the instructions in Chapter "Troubleshooting". 몇 CAUTION Keep a distance of at least 30 cm when using the jet for cleaning painted surfaces to avoid damage. Illustration Push the spray lance extension into the trigger gun and fasten it by a 90° rotation. Illustration Tighten the safety cover. Illustration Push the spray lance into the spray lance extension and fasten it by a 90° rotation. Turn on the appliance “I/ON”. Unlock the lever on the trigger gun. Pull on the lever of the trigger gun; the device will switch on. Note: Release the lever of the trigger gun; the de- vice will switch off again. High pressure remains in the system. Release the lever on the trigger gun. Lock the lever on the trigger gun. During longer breaks (more than 5 minutes), also turn the appliance off using the "0/OFF" switch. Description of the Appliance

• Additionally required 17 Fabric-reinforced water hose with commercially available coupling. – Minimum diameter, 1/2 inches (13 mm). – Minimum length 7.5 m. Assembly Start up Water supply Operation High pressure operation Interrupting operation 9EN– 6 몇 CAUTION Only separate the high-pressure hose from the trigger gun or the appliance when there is no pressure in the system. Release the lever on the trigger gun. Turn off the appliance "0/OFF". Disconnect the mains plug from the socket. Turn off tap. Press the lever on the trigger gun to release any re- maining pressure in the system. Lock the lever on the trigger gun. Detach the appliance from the water supply. 몇 CAUTION Risk of personal injury or damage! Mind the weight of the appliance during transport. Lift appliance by the carrying handle and carry it. Secure the appliance against shifting and tipping over. 몇 CAUTION Risk of personal injury or damage! Consider the weight of the appliance when storing it. Prior to extended storage periods, as during the winter, also observe the instructions in the Care section. Park the machine on an even surface. Remove the high pressure hose from the high pres- sure connection. Detach spray lance from the trigger gun. Stow away the accessories in the accessory hold- er. Wrap the mains cable around the storage and at- tach the mains plug with the cable clamp. ATTENTION Appliances and accessories that are not completely drained can be destroyed by frost. Completely drain ap- pliance and accessories and protect them against frost. To avoid damage: Completely drain all water from the appliance: Switch the appliance on with detached high pres- sure hose and detached water supply (max. 1 min- ute) and wait, until no more water exits at the high pressure connection. Turn off the appliance. Store the appliance and the entire accessories in a frost free room. DANGER Risk of electric shock. Prior to all work on the appliance, switch off the ap- pliance and pull the power plug. Clean the sieve in the water connection regularly. ATTENTION The sieve must not be damaged. Remove coupling from the water connection. Illustration Pull the sieve out using flat pliers. Clean the sieve under running water. Reinsert the sieve into the water connection. The appliance is maintenance free. You can rectify minor faults yourself with the help of the following overview. If in doubt, please consult the authorized customer ser- vice. DANGER Risk of electric shock. Prior to all work on the appliance, switch off the ap- pliance and pull the power plug. Pull on the lever of the trigger gun; the device will switch on. Check whether the voltage indicated on the type plate corresponds to the voltage of the mains sup- ply. Check the mains connection cable for damages. Check setting at the spray lance. Check water supply for adequate delivery rate. Appliance ventilation: Switch the appliance on with the high-pressure hose detached and operate (max. 2 minutes) until the water exits the high-pres- sure connection without bubbles. Switch off appli- ance and reconnect high-pressure hose. Pull out the sieve in the water connection using flat- nose pliers and clean under running water. Clean high-pressure nozzle: Remove dirt and de- bris from the nozzle bore, using a needle and rinse through with water from the front. Check water flow quantity. Gear defective, contact Customer Service. Slight leakage from the appliance pump is normal. If the leakage increases contact the authorized customer service. Finish operation Transport When transporting by hand When transporting in vehicles Storage Storing the Appliance Frost protection Care and maintenance Clean the sieve in the water connection Maintenance Troubleshooting Appliance is not running Pressure does not build up in the appliance Strong pressure fluctuations Unusual operating noises Appliance is leaking 10 EN– 7 The warranty terms published by the relevant sales company are applicable in each country. We will repair potential failures of your appliance within the warranty period free of charge, provided that such failure is caused by faulty material or defects in manufacturing. In the event of a warranty claim please contact your dealer or the nearest authorized Customer Service center. Please submit the proof of purchase. Addresses can be found under: www.kaercher.com/dealersearch Subject to technical changes. We hereby declare that the machine described below complies with the relevant basic safety and health re- quirements of the EU Directives, both in its basic design and construction as well as in the version put into circu- lation by us. This declaration shall cease to be valid if the machine is modified without our prior approval. The signatories act on behalf of and with the authority of the company management. Documentation supervisor: S. Reiser Alfred Kärcher SE & Co. KG Alfred-Kärcher-Straße 28-40 71364 Winnenden (Germany) Tel.: +49 7195 14-0 Fax: +49 7195 14-2212 Warranty Technical specifications Electrical connection Voltage 220-240 1~50-60

Sound pressure level L

www.kaercher.com/REACH
