USER MANUAL MS2022DW LG

4. Safety lock system

MB-3827C MH-5827C MS-1927C Allows selection of desired power. Timer permits selection of the desired cooking time.

WARNING: THIS APPLIANCE MUST BE EARTHED

The oven cannot be operated with the door open due to the safety interlocks built in the door mechanism which switch off cooking functions when the door is opened. Operating the oven with the door open could result in harmful exposure to microwave energy. It is important not to tamper with the door mechanism. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. The oven should not be adjusted or repaired by anyone except qualified service personnel.

MICROWAVE ENERGY WARNING When heating liquids, e.g. soups, sauces and beverages in your microwave oven, delayed eruptive boiling can occur without evidence of bubbling. This could result in a sudden boil over of the hot liquid. To prevent this possibility the following steps should be taken:

1. Avoid using straight-sided containers with narrow necks.

3. Stir the liquid before placing the container in the oven and again halfway through the

4. After heating, allow to stand in the oven for a short time. Stir or shake the contents (especially feeding

bottles and baby foods) and carefully check the temperature before use.

1. Remove all packing materials and accessories.

2. Place the oven on a level surface a minimum of 85cm above the floor with at least 30cm above and 10cm rear

space to allow adequate ventilation. The side of the oven should be kept clear so there is air flow for ventilation. The front of the oven should be at least 8cm from the edge of the surface to prevent tipping. An exhaust outlet is located on top or side of the oven. Blocking the outlet can damage the oven.

3. Plug your oven into a standard voltage household outlet. Ensure that the electrical circuit is at least 10 amps (13

amps for model ) and that the oven is the only appliance on the circuit. NOTE: • This appliance should not be used for commercial catering purposes. The wires in the mains lead are coloured in accordance with the following code: Blue - Neutral Brown - Live Green and Yellow - Earth If the power cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid hazard.

M H6022D /MH6022DW 4Important Safety InStructIonS Please keep for future reference. Read and follow all instructions before using your oven to prevent the risk of re, electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. Always contact your service agent or manufacturer about problems that you do not understand. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION”. These word means : This symbol will alert you to hazards or unsafe practices which could cause bodily injury or property damage. This symbol will alert you to hazards or unsafe practices which could cause serious bodily harm or death. CAUTION WARNING WARNING WARNING 1 Do not attempt to tamper with, or make any adjustments or repairs to the door, door seals, control panel, safety interlock switches or any other part of the oven which would involve the removal of any cover protecting against exposure to of the microwave oven are faulty. Repairs should only be undertaken by a qualified service technician.

Unlike other appliances, the microwave oven is a high-voltage and a highelectrical- current piece of equipment. Improper use or repair could result in harmful exposure to excessive microwave energy or in electric shock. 2 Do not use the oven for the purpose of dehumidification. (ex. Operating the microwave oven with wet newspapers, clothes, toys, electric devices, pet or child etc.)

It can be the cause of serious damage to safety such as a fire, a burn or a sudden death due to an electric shock. 3 The appliance is not intended for use by young children or elderly persons. Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

Improper use may cause damage such as a fire, electric shock or burn. ENGLISH

Accessible parts may become hot during use. Young children should be kept away.

They may get a burn.

iquids or other foods must not be heated in sealed containers since they are liable to explode. Remove the plastic wrapping from food before cooking or defrosting. Note though that in some cases food should be covered with plastic film, for heating or cooking.

They could burst. 6 Be certain to use proper accessories on each operation mode

Improper use could result in damage to your oven and accessories, or could make spark and a fire.

he children should not allow to play with accessories or hang down from the door handle.

f the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

t is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

hen the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated. 1 You cannot operate your oven with the door open due to the safety interlocks built into the door mechanism. It is important not to tamper with the safety interlocks.

It could result in harmful exposure to excessive microwave energy. (Safety interlocks automatically switch off any cooking activity when the door is opened.) 2 Do not place any object (such as kitchen towels, napkins, etc.) between the oven front face and the door or allow food or cleaner residue to accumulate on sealing surfaces.

It could result in harmful exposure to excessive microwave energy. 3 Do not operate your oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the: (1) door(bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

It could result in harmful exposure to excessive microwave energy. 4 Please ensure cooking times are correctly set, Small amounts of food require shorter cooking or heating time.

Over cooking may result in the food catching on fire and subsequent damage to your oven. CAUTION

.5 When heating liquids, e.g. soups, sauces and beverages in your microwave oven,

• Avoid using straight sided containers with narrow necks.

• Stir the liquid before placing the container in the oven and again halfway through the heating time.

• After heating, let it stand in the oven for a short time; stir or shake it again carefully and check the temperature of it before consuming to avoid burns (especially, contents of feeding bottles and baby food jars).

Be careful when handling the container. Microwave heating of beverages can result in delayed eruptive boiling without evidence of bubbling. This could result in hot liquids suddenly boiling over.

An exhaust outlet is located on the top, bottom or side of the oven. Don’t block the outlet.

It could result in damage to your oven and poor cooking results. 7 Do not operate the oven when empty. It is best to leave a glass of water in the oven when not in use. The water will safely absorb all microwave energy, if the oven is accidentally started.

Improper use could result in damage to your oven. 8 Do not cook food wrapped in paper towels, unless your cook book contains instructions for the food you are cooking. And do not use newspaper in place of paper towels for cooking.

Improper use can cause an explosion or a fire. 9 Do not use wooden containers and ceramic containers that have metallic (e.g. gold or silver) inlays. Always remove metal twist ties. Check that the utensils are suitable for use in microwave ovens before use.

They may heat-up and char. Metal objects in particular may arc in the oven, which can cause serious damage. 10 Do not use recycled paper products.

• They may contain impurities which may cause sparks and/or fires when used in cooking.

Do not rinse the tray and rack by placing it in water just after cooking. This may cause breakage or damage.

• Improper use could result in damage to your oven.

Be certain to place the oven so the front of the door is 8 cm or more behind the edge of the surface on which it is placed, to avoid accidental tipping of the appliance.

Improper use could result in bodily injury and oven damage.

Before cooking, pierce the skin of potatoes, apples or any such fruit or vegetable.

Do not cook eggs in their shell. Eggs in their shell and whole hardboiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.

Pressure will build up inside the egg which will burst. ENGLISH

Do not attempt deep fat frying in your oven.

This could result in a sudden boil over of the hot liquid.

If smoke is observed, switch off or disconnect the oven from the power supply and keep the oven door closed in order to stifle any flames.

It can cause serious damage such as a re or electric shock.

When food is heated or cooked in disposable containers made of plastic, paper or other combustible materials, keep an eye on the oven and check it frequently.

Your food may be poured due to the possibility of container deterioration, which also can cause a re.

The temperature of accessible surfaces may be high when the appliance is operating. Do not touch the oven door, outer cabinet, rear cabinet, oven cavity, accessories and dishes during grill mode, convection mode and auto cook operations, before clearing make sure they are not hot.

As they will become hot, there is the danger of a burn unless wearing thick culinary gloves .

The oven should be cleaned regularly and any food deposits should be removed.

Failure to maintain the oven in a clean condition could lead to deterioration of the surface. This could adversely aect the life of the appliance and possibly result in a hazardous situation.

Only use the temperature probe recommended for this oven.

You can not ascertain that the temperature is accurate with an unsuitable temperature probe.

Follow exact directions given by each manufacturer for their popcorn product. Do not leave the oven unattended while the corn is being popped. If corn fails to pop after the suggested times, discontinue cooking. Never use a brown paper bag for popping corn. Never attempt to pop leftover kernels.

Overcooking could result in the corn catching a re.

This appliance must be earthed. The wires in the mains lead are colored in accordance with the following codes BLUE ~ Neutral BROWN ~ Live GREEN & YELLOW ~ Earth As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: The wire which is colored BLUE must be connected to the terminal which is marked with the letter N or Colored BLACK. The wire which is colored BROWN must be connected to the terminal which is marked with the letter L or colored RED. The wire which is colored GREEN & YELLOW or GREEN must be connected to the terminal which is marked with the letter E or

If the supply cord is damaged, it must be replaced by the manufacturer, a service agent or a similarly qualified person in order to avoid potential hazards.

Improper use may cause serious electric damage.

This oven should not be used for commercial catering purposes.

Improper use could result in damage to your oven.

The microwave oven must be operated with the decorative door open if the microwave oven is placed in a cabinet.

If the door is closed while operating, the airow will get worse possibly resulting in a re or damage to your oven and the cabinet.

The connection may be achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance with the wiring rules.

Using improper plug or switch can cause an electric shock or a re.

Should be monitored to ensure that children do not play with the device.

The devices are not intended to be operated by an external timer or by a separate control.

Only use utensils that are suitable for use in microwave ovens.

The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.Cleaning and user maintenance shall not be made by children unless they are aged from 8 years and above and supervised.

The microwave oven is intended to be used freestanding.

The temperature of accessible surfaces may be high when the appliance is operating.

Keep the appliance and its cord out of reach of children less than 8 years.

The door or the outer surface may get hot when the appliance is operating. ENGLISH 9Cooking Utensils COOKING UTENSILS Utensils should be checked to ensure that they are suitable for use in the microwave oven. The following chart summarises the proper use of cooking utensils in your oven: Microwave

1. Most glass, glass ceramic, and heat resistant

glassware utensils are excellent. Those with metal trim should not be used in a microwave oven.

2. Paper napkins, towels, plates, cups, cartons,

and cardboard can be used in the microwave oven. Do not use recycled paper products since they may contain impurities which may cause sparks and/or fires when used in cooking. (Consult your cookbook for correct use of these products.)

3. Plastic dishes, cups, freezer bags, and plastic

wraps may be used in the microwave oven. Follow the manufacturer’s instructions or the information given in the cookbook when using plastics in the microwave oven.

4. Metal utensils and utensils with metallic trim

should not be used in the microwave oven. For more information on the proper use of metal in your oven, please read the introduction section in the cookbook. If the use of aluminum foil, skewers, or utensils containing metal in the oven is specified in the recipe, allow at least 2.5cm clearance between the metal object and the interior oven wall. If arcing (sparks) occurs, remove immediately. Note: Consult your cookbook, individual recipes, and charts for correct use of cooking containers, products, and other useful information. Grill

1. Heat resistant glassware, ceramic and metal

cookware can be used.

2. Paper napkins, towels, and plastics should

• Care should be taken when removing utensils or the glass turntable, as they may become hot during cooking.

• Only use a thermometer that is designed or recommended for use in the microwave oven.

• Ensure the turntable is in place when you operate the oven.

Cooking utensils Microwave Grill Heat resistant glass, glass ceramic yes yes Ceramic, china yes yes (Do not use china with gold or silver trim.) Metal cookware no yes Non-heat resistant glass no no Microwave plastic yes no Plastic wrap yes no Paper (cup, plates, towels) yes no Straw, wicker and wood no noOther Helpful Instructions Cleaning and Care For best results and more enjoyable cooking, please read these comments thoroughly. For Best Results:

1. When determining the time for a particular food,

begin by using minimum time and checking con- dition occasionally. It is easy to overcook food because microwaves cook very quickly.

2. Small quantities of food, or foods with low water

content may dry out and become hard if cooked too long. Defrosting Frozen Foods:

1. Foods that have been frozen can be placed

directly in the oven for thawing. (Be certain to remove any metallic ties or wraps.)

2. Defrost according to the Defrosting Tips found in

3. For areas of the food thawing faster than others,

cover with small pieces of aluminium foil. This helps slow down or stop the defrosting process.

4. Some foods should not be completely thawed

before cooking. For example, fish cooks so quickly that it is sometimes better to begin cooking while still slightly frozen.

5. It may be necessary to increase or decrease the

cooking time in some recipes, depending on the starting temperature of the foods. NOTE: Air from the vent may become warm during cooking. Browning: There are a few foods which are not cooked long enough in the microwave oven to brown and may need additional colour. Coatings such as paprika, and browning agents such as Worcestershire sauce may be used on chops, meat patties or chicken pieces. Roasts, poultry or ham, cooked for 10-15 minutes or longer, will brown without extra additives. BE SURE THE OVEN IS TURNED OFF BEFORE CLEANING. Keep the oven interior surfaces clean and dry. As a general rule clean after each use. INTERIOR WALLS Remove any crumbs and food remains between the door and oven using a damp cloth. This area has to be particularly well cleaned to ensure the door will close properly. Remove any grease splashes with a soapy cloth then rinse and dry. Do not use abrasives which may scratch and damage the painted surface of the oven.

NEVER POUR WATER INTO THE OVEN

ROLLER REST The roller rest should be removed and cleaned in hot soapy water at least once a week to prevent grease restricting the rotation of the wheels. DOOR The door and door seals should be kept clean at all times. Use only warm, soapy water to rinse then dry thoroughly. DO NOT USE ABRASIVE MATERIALS, SUCH AS

CLEANING POWDERS OR STEEL AND PLASTIC

PADS. Metal parts will be easier to maintain if wiped frequently with a damp cloth. EXTERIOR Clean with mild soap and warm water, rinse and dry with a soft cloth. Do not use abrasive materials. Do not spill water in the vents. If the power lead becomes soiled wipe it with a damp cloth. Do not use any steam cleaner. ENGLISH 11MICROWAVE COOKING See page 3.

1. Open the oven door, place the food on the

turntable in the oven, and close the oven door.

2. Set the power selector () to the

desired power level. There are five power levels from Watts to max. The power selector can be set to any one of these positions.

3. Set the timer () to the desired cooking

time. The turntable begins to rotate and cooking starts. At the end of cooking time the bell will ring, and the lamp is turned off. Note:

• Each number on the scale represents one minute. To ensure accurate timing, it is advisable to turn the timer knob slightly past the desired cooking time and then back to the proposed setting.

• Press the door opener to check the cooking condition during oven operation. Opening the door during cooking automatically turns off the oven and stops the timer. If cooking is to continue, close the door - the oven will turn on and the timer will resume counting.

• The turntable may rotate in either direction.

See page 3. Defrosting frozen food is one of the benefits of a microwave oven. Defrosting using a microwave oven is much faster than in the refrigerator and safer than at room temperature, as it does not promote the growth of harmful bacteria. It is important to remember that defrosting takes longer than normal cooking. Check the food, turning it over at least once during defrosting.

2. Turn the timer knob () clockwise to set the

weight (kg) of food. NOTE: The oven starts working as soon as the timer knob is turned. Each number on the scale represents one kg. Operating Procedure MH602 2D / MH6022DW GRILL COOKINGSee page 3.1. Open the oven door, place the food on therack in the oven, and close the oven door.2. For models turn thefunction & power selector ( ) to grill mode ( ). 3. Set the timer () to the desired cookingtime. The turntable begins to rotate, cookingstarts, and the lamp is turned on. At theend of the cooking time you will hear the bellring and the lamp is turned off.• Refer to the note under MICROWAVECOOKING if you want to check the cookingcondition.• Don’t touch the viewing window during grill operation, because the temperature of theglass may rise up to 100°C.• Prevent children from touching the front screen!• When the grill is operated for the first timeafter purchasing the oven, some smoke maybe observed. This will soon disappear.Note:• Use of the grill rack is preferable, astime and performance of cooking willvary when turntable is used alone. M H6022D / MH6022DW

the defrosting mode. ( ) Questions and Answers Q. What’s wrong when the oven light will not glow?

Light bulb has blown.

Door is not closed. Q. Why is steam coming out of the air exhaust vent and/or why is water dripping from the bottom of the door? A. Steam is normally produced during cooking operations. The microwave has been made to vent this steam out of the side vent, occasionally this steam condenses on the door and water then drips out at the bottom of the door. This is quite normal and safe. Q. Does microwave energy pass through the viewing screen in the door? A. No. The metal screen reflects the energy to the oven cavity. The holes, or ports are made to allow light to pass; they do not let microwave energy through. Q. Will the microwave oven be damaged if it operates while empty? A. Yes. Never run it empty. Q. Why do eggs sometimes pop? A. When baking or poaching eggs, the yolk may pop due to steam build-up inside the yolk membrane. To prevent this, simply pierce the yolk with a toothpick before cooking. Never cook eggs witthout piercing their shells. Q. Why is standing time recommended after the cooking operation has been completed? A. Standing time is very important. With microwave cooking, the heat is in the food, not in the oven. Many foods build up enough internal heat to allow the cooking process to continue, even after the food is removed from the oven. Standing time for joints of meat, large vegetables and cakes is to allow the inside to cook completely, without overcooking the outside. Q. Why does my oven not always cook as fast as the microwave cooking guide says? A. Check your cooking guide again, to make sure you’ve followed directions exactly; and to see what might cause variations in cooking time. Cooking guide times and heat settings are suggestions, to help prevent over-cooking . . . the most common problem in getting used to a microwave oven. Variations in the size, shape and weights and dimensions could require longer cooking time. Use your own judgement along with the cooking guide suggestions to check whether the food has been properly cooked just as you would do with a conventional cooker. Q. Why do sparks and crackling (arcing) occur in the oven? A. There may be several reasons why sparks and crackling (arcing) within cavity happens.

You are using dishes with metal parts or trim (silver or gold).

You have left a fork or other metal utensil in the oven.

You are using a large amount of metal foil.

• Dimensions shown are approximate.

• Because we continually strive to improve our products we may change specifications without prior notice. Power Input Output (IEC 60705 RATING STANDARD) Microwave Frequency Outside Dimensions (W x H x D mm) Power Consumption Power Input Output (IEC 60705 RATING STANDARD) Microwave Frequency Outside Dimensions (W x H x D mm) Power Consumption Microwave Grill <English> Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the

European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and

human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. MS2022D / MS2022DW MH6022D / MH6022DW

2450 MHz +/- 50MHz(Group 2/Class B) 2450 MHz +/- 50MHz(Group 2/Class B) Group 2 equipment: group 2 contains all ISM RF equipment in which radio-frequency energy in the frequency range 9 kHz to 400GHz is intentionally generated and used or only used, in the form of electromagnetic radiation, inductive and / or capacitive coupling, for the treatment of material or inspection/analysis purposes.Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purposes.www.lg.com
