USER MANUAL MKC2157AS KITCHENAID

INSTALLATION INSTRUCTIONS Built-In Trim Kit Models MKC2157, MKC2150 UL listed for use over any electric or gas built-in oven, up to 30" (76.2 cm) wide

• Table of Contents / Table des matières MICROWAVE OVEN SAFETY p. 1
• INSTALLATION INSTRUCTIONS p. 2
• Tools and Parts p. 2
• Location Requirements p. 2
• Required Cutout Dimensions p. 2
• Trim Kit Frame Dimensions p. 2
• Electrical Requirements p. 3
• Prepare Microwave Oven p. 3
• Prepare Cutout/Cabinet Opening p. 4
• Install the Microwave Oven p. 5
• Install Trim Kit Frame p. 6
• SÉCURITÉ DU FOUR À MICRO-ONDES p. 7
• INSTRUCTIONS D’INSTALLATION p. 7
• Outillage et pièces p. 7
• Exigences d'emplacement p. 7
• Dimensions nécessaires de l'ouverture d'encastrement p. 8
• Dimensions du cadre de la trousse de garniture p. 8
• Spécifications électriques p. 8
• Préparation du four à micro-ondes p. 9
• Préparation de l'ouverture d’encastrement/dans le placard p. 10
• Installation du four à micro-ondes p. 11
• Installation du cadre de garniture W10694207A You can be killed or seriously injured if you don't immediately You can be killed or seriously injured if you don'tfollow All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed. Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.This is the safety alert symbol.This symbol alerts you to potential hazards that can kill or hurt you and others.All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”These words mean:follow instructions.instructions. DANGER WARNING2 INSTALLATION INSTRUCTIONS Tools and Parts Tools Needed Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Parts Supplied (not shown to scale Location Requirements The microwave oven may be installed over a built-in oven. If installing over a built-in oven, make sure there is a minimum of 3" (7.6 cm) between the top of the lower oven cutout and the microwave oven cutout floor. The microwave oven may also be installed in a cabinet by itself (without a built-in oven below). For best usability, we recommend a minimum distance of 36" (91.4 cm) from the floor to the cutout floor. Make sure the surrounding cabinetry has clearance to open and close freely. Allow a clearance of at least 1⁹⁄₁₆" (4.0 cm) below the cutout floor (3" [7.6 cm] for installation above a built-in oven), and a clearance of at least 2" (5.1 cm) above the cutout opening. Required Cutout Dimensions NOTES: ■ Depth requirements depend upon receptacle and its location within or outside of recommended region. See illustration and chart above. ■ Height dimension is critical: 17" (43.2 cm) minimum, 17¹⁄₈" (43.5 cm) maximum. ■ Width measurement has ±1/16" (2 mm) tolerance. ■ 3" (7.6 cm) minimum dimension is from lower oven cutout ceiling to microwave oven cutout floor. ■ Trim kit frame extends 1¹⁄₁₆" (2.7 cm) above and below the cutout opening. Trim Kit Frame Dimensions *27" (68.6 cm) trim kit **30" (76.2 cm) trim kit ■ Measuring tape■ Pencil■ Phillips screwdriver■ Drill■ 7/64" drill bitRear duct Bottom duct Rails (2)Short screws (19)(16 + 3 extra)Long wood screws (6 - painted) (4 + 2 extra)Trim kit frameA. Upper cabinetB. Microwave oven cutoutC. Lower oven cutoutD. Lower cabinetsE. Floor 3"(7.6 cm) p. 12

A. Trim kit frame overhangB. Cutout for lower ovenC. Recommended region for receptacle location (no less than 7" [17.8 cm] to the right of cutout centerline)D. Cutout centerline Receptacle Location Minimum Depth Within recommended region 20" (50.8 cm) with flush receptacle; 22" (55.9 cm) with non-flush receptacle Outside recommended region 22" (55.9 cm) with flush receptacle; 24" (61.0 cm) with non-flush receptacle 3"(7.6 cm 7"(17.8 cm) 1¹⁄₁₆"(2.7 cm)1¹⁄₁₆"(2.7 cm)

1. Unplug microwave oven before proceeding with installation.

2. Remove any loose items inside microwave oven.

3. Gently turn microwave oven onto its top, with the door facing

forward (toward installer).

4. Align the two rails on the microwave oven bottom, as shown,

making sure the flanges are forward and pointing up.5. Secure the rails to the microwave oven bottom using four short screws. Attach Rear Duct 1. Gently return microwave oven to its upright position.2. Align the rear duct with the back of microwave oven, as shown. Electrical Shock HazardPlug into a grounded 3 prong outlet.Do not remove ground prong.Do not use an adapter.Do not use an extension cord.Failure to follow these instructions can result in death, fire, or electrical shock. WARNING GROUNDING INSTRUCTIONS

SAVE THESE INSTRUCTIONS

For all cord connected appliances:The microwave oven must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. The microwave oven is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

WARNING: Improper use of the grounding plug can

result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the microwave oven is properly grounded. Do not use an extension cord. If the power supply cord is too short, have a qualified electrician or serviceman install an outlet near the microwave oven. A. Rails (2) B. Microwave oven bottom C. Short screws (4) D. Flanges E. Door ABC DE4

3. Slide two tabs into the slots on the right side of the back of

4. Use two short screws to secure top of rear duct to the back of

microwave oven, as shown.

5. Use three short screws to secure back of rear duct to the back

of microwave oven, as shown. Prepare Cutout/Cabinet Opening

1. On the cutout floor, find and mark the centerline.

2. Place the bottom duct in the opening, with the flange resting

against the bottom front facing of the opening.

3. Align the center arrows on the bottom duct with the centerline

drawn in Step 1 above. A. Rear duct tabsB. SlotsA. Short screws (2)B. Rear ductC. Back of microwave ovenA. Short screws (3)B. Rear ductC. Back of microwave oven A B A B C A B C A. Cutout floorB. CenterlineC. Bottom ductD. Bottom duct flangeE. Front facingA. Bottom ductB. Center arrows, aligned with centerline

4. Mark the three mounting holes through the bottom duct onto

5. Using 7/64" drill, drill pilot holes into the three holes marked in

6. Realign and install the bottom duct with three short screws.

7. Using 7/64" drill, drill pilot holes through the four mounting holes of the bottom duct flange into the bottom front facing of the cutout/cabinet opening. Install the Microwave Oven 1. Position microwave oven near cutout opening.2. Plug in microwave oven.3. Align the rails with the rail guides on the bottom duct.4. Slide the microwave oven back and into place. The mounting holes of the rail flanges and bottom duct flange will align against the bottom front facing of the cutout/cabinet opening.

5. Secure the microwave oven to the cutout/cabinet by installing

four short screws into the mounting holes.A. Short screws (3)B. Bottom duct mounting holesA. Bottom duct flangeB. Mounting holes

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock. WARNING A. Rail guidesB. RailsA. Mounting holesB. Short screws (4)

1. Position trim kit frame over the opening so that the upper tabs

fit inside the rails, as shown.

2. To vertically center the trim kit frame, slide it upward, against

the opening, until the upper tabs catch against the top of the rails.

3. Holding the trim kit frame firmly in place, use 7/64" drill to drill

four pilot holes into the front facing of the cutout/cabinet through the mounting hole guides in the upper and lower corners of the trim kit frame. NOTES: ■ To ensure vertical centering, drill the lower holes first. ■ The holes will be drilled upward from the bottom, and downward from the top at an angle of about 45°.

4. Secure trim kit frame to cutout/cabinet by installing four long

wood screws (painted) into the pilot holes drilled in Step 3 above. NOTES: ■ To ensure vertical centering, install the lower screws first. ■ To avoid damage to the trim kit frame, do not overtighten screws. Installation is now complete. Replace any loose items that have been removed from microwave oven cavity. Save these Installation Instructions for future reference. A. Front of trim kit frameB. Upper tabC. RailD. Lower tabA. Trim kit frameB. Upper tabC. RailD. Cutout floorE. Long wood screw (4 - painted)F. Mounting hole guide
