| Brand | Rösle |
| Model | Videro G4S Vario |
| Product type | Gas barbecue |
| Usage | Outdoor use only |
| Firebox material | Porcelain-enamelled steel |
| Cooking grid material | VARIO+ enamelled cast iron |
| Heat diffuser | Stainless steel |
| Grease collection tray | Stainless steel, rear removal |
| Dimensions (L x W x H) | 138 x 60 x 118 cm |
| Main cooking area | 3100 cm² (70 x 45 cm) |
| Warming surface | 1120 cm² (70 x 16 cm) |
| Working height | 90 cm |
| Weight | Approx. 48 kg |
| Number of main burners | 4 |
| Power per main burner | 3.5 kW |
| Side burner power | 3.0 kW |
| Primezone burner power (infrared) | 3.5 kW |
| Total power | 20.5 kW |
| Gas consumption | 1498 g/h |
| Gas type | Butane (G30) / Propane (G31) |
| Service pressure | 30 or 50 mbar depending on country |
| Main burner ignition | Piezo-electric Jet-Flame |
| Primezone ignition | Electronic (AA battery) |
| Side burner ignition | Piezo-electric |
| Button lighting | LED, 4 AA batteries (white off, red on) |
| Side tables | Foldable, with quick gas coupling |
| Safety | Regulator, hose break safety, automatic shut-off on disconnection |
| Wheels | 4 wheels with brake |
| Lid thermometer | Yes, 60-350 °C |
| Gas bottle capacity (in cabinet) | Max. 11 kg |
| Warranty | Legal warranty (material/manufacturing defects) |
Frequently Asked Questions - Videro G4S Vario Rösle
How to light the main burners?
Open the lid, open the gas cylinder valve, push and turn the control knob to MAX until the click of the Jet-Flame ignition, hold for 2 seconds. If the burner does not light, wait 2 minutes before trying again.
What is the total power of the barbecue?
Total power is 20.5 kW: 4 main burners of 3.5 kW each, one side burner of 3.0 kW and one Primezone infrared burner of 3.5 kW.
Can I use the barbecue with natural gas?
No, this barbecue is designed only for LPG butane/propane. Using natural gas is dangerous and voids the warranty.
How to clean the cooking grids?
Let them cool completely. Brush off residue with a stainless steel brush, then wipe with a damp cloth. For enamelled cast iron grids, avoid thermal shock and do not put them in the dishwasher. Lightly oil after cleaning to prevent rust.
What safety distance must be maintained around the barbecue?
No flammable materials should be within 1.5 meters above, below, in front, or on the side of the barbecue during operation.
How to check for gas leaks?
Turn all knobs to OFF, open the cylinder valve, apply a soapy solution (50% water, 50% liquid soap) on all gas connections. Bubbles indicate a leak. Tighten connections or replace defective parts. Rinse after testing.
Can I use a gas cylinder larger than 11 kg?
No, the lower compartment accepts a cylinder with a maximum filling weight of 11 kg. Beyond that, the cylinder must be placed next to the barbecue, outdoors.
How to store the barbecue in winter?
Store it in a dry, ventilated room. Remove the gas cylinder. Clean and dry the grids, coat them with sunflower oil. Protect with a suitable Rösle cover. Remove the cover regularly to prevent humidity.
What to do in case of a grease fire?
Immediately close the gas cylinder and all knobs. Do not pour water. Leave the lid open if possible. Use a class F fire extinguisher or a wet cloth. If the fire persists, call the fire department.
How to replace the LED lighting batteries?
Open the right door of the lower cabinet. Slide the cover of the battery compartment and insert 4 AA batteries (1.5V) respecting polarity. The lighting turns on with the push button on the right side of the control panel.
