USER MANUAL DOH141 LIVOO

Thank you for choosing a Livoo product! Your blender, your barbecue, and your headphones are not just objects, they are extensions of yourself, allowing you to get closer to your friends and family, to bring them together, to laugh and to share experiences. Livoo's aim is to help you live your life to the fullest, whatever wishes you have throughout the year. Winter raclette, summer barbecue. Or the other way around. It's up to you. Take advantage of this freedom for feel good moments every day. That's why we're constantly innovating and creating clever products full of zest, but most of all, accessible. Find our entire collection on our website www.livoo.en. Livoo, your daily companion till social networks @livoo_officiel

Safety Instructions Please, take time to read well the instruction sheet before the first use and keep them for a future use. A misuse of the appliance can damage it or hurt the user. Assure that you use the appliance for the use for which it is designed. We refuse any responsibilities as for the damages by an incorrect use or a bad manipulation.

1. The appliance is intended for domestic use only.

Commercial and industrial use may cause damages and will void warranty

2. Plug in your appliance to an earth socket.

3. Any use not respecting the usual precautions of

the device removes any responsibility to the retailer of the importer or the manufacturer.

4. Before use check that the voltage of your wall

outlet correspond to the rated voltage manner.

5. If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. (*)

6. Do not immerse in water for cleaning

7. Close supervision is necessary when your

appliance is being used near children or infirm persons.

8. Do not use the appliance if your hands are wet.

Never use the appliance if gets wet and unplug itwww.livoo.fr immediately.

9. Do not use the device if appliance fell, if there are

visible signs of damage.

10. Do not make roll on its cable

11. Do not use this device to suck up incandescent or

sharp objects (cigarette ends of cigarettes, lit (switched on) matches, hot ashes, nails).

12. Do not use this vacuum cleaner to suck up pins,

threads, cement, plaster, or quite different material of construction or decoration.

13. Never suck up liquid products nor toxic matter,

cleaners or gasoline (essence) or dangerous or flammable products. You would risk to damage seriously your device.

14. This appliance can be used by children aged

from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

15. Keep the appliance and its cord out of reach ofwww.livoo.fr

children less than 8 years.

16. Never use the appliance on somebody or on

17. Make sure to block never the zones of air inlets.

18. Keep the appliance away from heating surface

19. Never use the electric cable to raise, transport or

disconnect the device.

20. The plug must be removed from the socket-

outlet before cleaning or maintaining the appliance.

21. The appliance is not intended to be operated by

means of external timer or separate remote control system.

22. Do not use to suck water

23. The adaptor must be removed from the socket-

outlet before cleaning or maintaining the appliance.

24. Warning: risk of entrapment.

25. The appliance should only be used with the

power supply supplied with the appliance.

26. WARNING: For the purposes of recharging the

battery, only use the detachable supply unit < CZH013270050EUWP> provided with this appliance.

27. This appliance contains batteries which may

only be replaced by skilled person.www.livoo.fr

28. Read the manual carefully.

29. This appliance is intended to be used in

household and similar applications such as:

• staff kitchen areas in shops, offices and other working environments

• by clients in hotels, motels and other residential type environments

• bed and breakfast type environments

Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

- Do not lift by the vacuum hose. - Keep hair, loose clothing, fingers away from openings and moving parts. Technical Specifications Vacuum motor: 22.2 V 150 W Charging input: 100-240V~50/60 Hz Battery output: 27 V 500 mA Technical specifications Adapter – ERP Information published Value and precision Unit DELTA BP61071 67452 Mundolsheim – France

Indoor use Logo indicating the polarity of the output. Drawing of the device 1 on/off button 7

Dust bin release button

Use of the device Assembly (Figures 2 ) To connect the motor and dust container to the tube, insert the end of the tube into the slot provided on the motor and dust container assembly until you hear a 'click'. To connect the floor brush to the tube, insert the end of the tube into the slot on the floor brush until it clicks into place. Before use Before using the device for the first time, charge it for 3 to 4 hours. Choose your accessory according to your needs: Floor brush: ideal for hard floors and easily accessible spaces Nozzle: ideal for small, hard-to-reach areas Brush attachment: ideal for fabrics (sofas, carpets, etc.)Choose your accessory according to your needs Press the on-off button (button 1 figure 1) to switch on the appliance and start vacuuming.www.livoo.fr Press the "button (button 2 figure 1) to change the suction power (normal or turbo). (normal or turbo). Note: after Note: After use, recharge your appliance. Cleaning and maintenance Unplug the appliance before cleaning and wait for it to cool down. Clean the body of the appliance with a damp cloth and leave to dry. Do not use solvents, abrasive products or aerosols to clean the appliance. Never immerse the appliance in water or any other liquid. Cleaning the dust tray Remove the tube from the motor and dust container assembly (figure 4). If you wish, you can also separate the dust container alone from the handle motor assembly (figure 3). Empty the dust container( Figure 3). Clean the filter: Then separate the motor from the dust container by rotating the top part anti-clockwise and pulling it out. Remove the filters from the centre of the dust container. Remove the paper filter in the centre of the filter assembly by turning it anticlockwise(Figure 5). Clean the paper filter by lightly tapping it or vacuuming it with another appliance. Clean the metal filter and dust tank with a lint-free cloth. You can also rinse the metal filter and dust tank if necessary. Dry both parts thoroughly before use. Clean these parts regularly, at least every 5 uses, to ensure that the appliance works properly. Cleaning the floor brush and roller : See figure 6 Correct disposal of the unit (Electrical and Electronic Equipment). (Applicable in the European Union and the rest of Europe that have adopted separate collection systems countries). The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal household waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The symbol of the crossed out dustbin is marked on all products to remind the obligations of separate collection. Consumers should contact their local authority or retailer for information concerning the correct disposal of their product.
