| Brand | Hoover |
| Model | HHOB 500 HVG6DSB |
| Product Type | Built-in Gas Hob |
| Number of Burners | 4 |
| Dimensions (W x D x H) | 595 x 505 x 42 mm |
| Weight | Approximately 12 kg |
| Power Supply | 220-240 V ~ 50/60 Hz |
| Electric Power | 1 W (electronic ignition) |
| Compatible Gas Types | Natural gas (G20) 20 mbar / Butane (G30) 28-30 mbar / Propane (G31) 37 mbar |
| Total Burner Power | 7.2 kW |
| Safety Device | Thermocouple safety (FFD) on each burner |
| Ignition | Integrated electronic |
| Surface Material | Real glass (ceramic)? No, enameled cast iron grates, steel or glass plate? The manual mentions chrome grates and burners. Stainless steel or glass surface? Not explicitly stated. Estimated stainless steel. |
| Cleaning | Removable burners washable with soapy water; enamel or stainless steel surface with non-abrasive products |
| Cut-out Dimensions | 560 x 480 mm (minimum) |
| Installation Class | Class 3 (built-in) |
| Spare Parts Available | Yes, through Hoover after-sales service (injectors, burners, grates, etc.) |
| Warranty | 2 years (to verify) |
| Standards | CE, Directive 2009/142/EC (GAD), Regulation 2016/426 (GAR) |
Frequently Asked Questions - HHOB 500 HVG6DSB HOOVER
What types of gas are compatible with the Hoover HHOB 500 HVG6DSB hob?
The hob is compatible with natural gas (G20) at 20 mbar, butane (G30) at 28-30 mbar, and propane (G31) at 37 mbar. Conversion is possible by changing the injectors and adjusting the minimum flame.
How do I convert the hob to use butane/propane gas?
Remove the grates, caps, and burner bodies. Unscrew the injectors using a 7 mm box spanner and replace them with those suitable for the desired gas (supplied). Tighten fully and adjust the air ring if necessary. Then adjust the minimum flame by turning the adjustment screw (diagram 9). For butane/propane, screw fully clockwise until it stops.
What is the power of the hob burners?
The hob is equipped with four burners: one auxiliary (1.00 kW), one semi-rapid (1.75 kW), and two rapid (2.70 kW each), for a total power of 7.2 kW. Recommended pan diameters: 10-18 cm for auxiliary, 10-22 cm for semi-rapid, and 16-26 cm for rapid.
How do I light a burner in case of a power failure?
In the absence of electricity, use a match or lighter. Approach the flame to the burner, push and turn the knob towards the largest flame symbol (⬆) and keep it pressed for 5 seconds after ignition. If the burner does not light after 5 seconds, wait at least 1 minute before trying again.
What safety precautions should I follow during use?
Never leave the hob unattended during cooking, especially with oil or grease. Do not extinguish a fire with water; cover the flame with a lid or fire blanket. Keep children under 8 away. Do not store objects on the cooking surface. If the glass surface is cracked, turn off the appliance and do not touch it.
How do I clean the burners and surface of the hob?
Before cleaning, ensure the hob is cool and disconnect it. Remove the grates and burners. Wash the burners with soapy water, rinse, and dry thoroughly. For the enamel or stainless steel surface, use warm soapy water or a non-corrosive detergent. Never use abrasive products or steam. For stainless steel, a specific cleaner can restore shine.
What should I do if I smell gas?
Immediately shut off the gas supply and electricity. Do not search for a leak with a flame. Open windows to ventilate and contact a qualified installer or after-sales service. Do not use the appliance until the cause is identified and repaired.
What are the required cut-out dimensions?
The worktop cut-out must be at least 560 x 480 mm. The worktop thickness should be between 25 and 45 mm. Maintain a minimum distance of 70 mm from the back wall and 70 cm from a hood or cabinet above. The cabinet must withstand temperatures up to 100 °C.
How do I replace the power supply cord?
Replacement of the power cord must be carried out only by the manufacturer, its after-sales service, or a qualified technician to avoid any risk. Use a cable type H05 GG-F or H05-V2V2-F suitable for the power (see rating plate). The earth wire (yellow/green) must be 10 mm longer than the other wires.
Where can I find spare parts for this hob?
Spare parts (injectors, burners, grates, etc.) are available from the Hoover after-sales service. Contact your dealer or visit the official Hoover website. Keep the appliance serial number to identify compatible parts.
