USER MANUAL DPX304MBT KENWOOD

Data Size: B6L (182 mm x 128 mm)Book Size: B6L (182 mm x 128 mm) For your records Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial numbers whenever you call upon your Kenwood dealer for information or service on the product.Model DPX794BH/DPX594BT/DPX560BT/DPX524BT/DPX504BT/DPX304MBTSerial number US Residents Only Register Online Register your Kenwood product at http://www.kenwood.com/usa/ B5A-3149-00b (KN)© 2019 JVCKENWOOD Corporation DPX794BH DPX594BT DPX560BT

(For / / / / ) CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. In compliance with Federal Regulations, following are reproductions of labels on, or inside the product relating to laser product safety. JVCKENWOOD Corporation 2967-3, ISHIKAWA-MACHI,

HACHIOJI-SHI, TOKYO, JAPAN

THIS PRODUCT COMPLIES WITH DHHS RULES 21CFR SUBCHAPTER J IN EFFECT AT DATE OF MANUFACTURE. Location : Top Plate FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void theuser’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.

1. This device may not cause interference.

2. This device must accept any interference, including interference that may cause undesired

The software embedded in the Product (hereinafter the "Licensed Software") provided by Licensor is copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions which Users shall follow in order to use the Licensed Software. The User shall use the Licensed Software by agreeing with the terms of this Software License Agreement. This Agreement shall be deemed completed at the time the User (hereinafter the "User") initially used the Product in which the "Licensed Software" is embedded. The Licensed Software may include the software which has been licensed to the Licensor directly or indirectly from any third party. In such case, some third parties require the Users to follow their conditions for use separately from this Software License Agreement. Such software shall not be subject to this Agreement, and the Users are urged to read the "Important Notice concerning the Software" to be provided separately below. Article 1 General Provision The Licensor shall grant to the User a non-exclusive and non-transferable (other than the exceptional case referred to in Article 3, Paragraph 1) licensed to use the Licensed Software within the country of the User. (the country where the User bought the Product (hereinafter the "Country") Article 2 License

1. The license granted under this Agreement shall be the right to use the Licensed Software in the

Software and any related documents, whether in whole or in part.

3. The use of the Licensed Software shall be limited to personal purpose, and the Licensed Software shall

not be distributed, licensed or sub-licensed whether it is for commercial purpose or not.

4. The User shall use the Licensed Software according to the directions described in the operation

manual or help file, and is prohibited to use or duplicate any data in a manner violating the Copyright Law or any other laws and regulations by applying whole or a part of the Licensed Software. Article 3 Conditions for Grant of License

1. When the User transfers the Product, it may also transfer the license to use the Licensed Software

embedded in the Product (including any related materials, updates and upgrades) on condition that no original, copies or related materials continue in the possession of the User, and that the User shall cause the transferee to comply with this Software License Agreement.

2. The User shall not carry out reverse engineering, disassembling, decompiling or any other code

analysis works in connection with the Licensed Software. JS_KWD_DPX794BH_KN_C.indd iiJS_KWD_DPX794BH_KN_C.indd ii 7/4/2019 1:48:52 PM7/4/2019 1:48:52 PMData Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) iii Article 4 Right pertaining to the Licensed Software Any and all copyrights and other rights pertaining to the Licensed Software and related documents shall belong to the Licensor or the original holder of the right who granted to the Licensor the license or sublicense for the Licensed Software (hereinafter the "Original Rightholder"), and the User shall not be entitled to any right other than the license granted hereunder, in respect of the Licensed Software and any related documents. Article 5 Indemnification of Licensor

1. Neither the Licensor nor the Original Rightholder shall be liable for any damage incurred by the User

or any third party due to the exercise of the license granted to the User under this Agreement, unless otherwise restricted by law.

2. The Licensor will offer no guarantee for the merchantability, convertibility and consistency with

certain objective of the Licensed Software. Article 6 Liability to Third Party If any dispute has arisen with any third party due to an infringement upon a copyright, patent or any other intellectual property right that was caused by the User's use of the Licensed Software, the User shall settle such dispute at its own cost and hold the Licensor and the Original Rightholder harmless from any inconvenience it may cause. Article 7 Confidentiality The User shall keep the confidentiality of such portion of the Licensed Software, related documents thereof or any other information to be granted under this Agreement, as well as the conditions of this Agreement as has not yet entered the public domain, and shall not disclose or divulge the same to any third party without approval of the Licensor. Article 8 Termination In case the User falls under any of the events described in the following items, the Licensor may immediately terminate this Agreement or claim that the User compensates for the damage incurred by the Licensor due to such event: (1) when the User violated any provision of this Agreement; or (2) when a petition has been filed against the User for an attachment, provisional attachment, provisional disposition or any other compulsory execution. Article 9 Destruction of the Licensed Software If this Agreement is terminated pursuant to the provision of Article 8, the User shall destroy the Licensed Software, any related documents and copies thereof within two (2) weeks from such date of termination. Article 10 Protection of Copyright

1. The copyright and all the other intellectual property rights relating to the Licensed Software

shall belong to the Licensor and the Original Rightholder, and in no event shall they be under the ownership of the User.

2. The User shall, whenever it uses the Licensed Software, comply with any laws relating to the

1. It is prohibited to export the Licensed Software and any related documents outside the country

of the User (including transmission thereof outside the country of the User via Internet of other communication tools).

2. The User shall understand that the Licensed Software shall be subject to the export restrictions

adopted by the country of User and any other countries.

3. The User shall agree that the software will be subject to any and all applicable international and

domestic laws (including the export control regulation of the country of User and any other countries, and any restrictions concerning the end-users, the use by end-users and importing countries to be provided by the country of User and any other countries, and any other governmental authorities). Article 12 Miscellaneous

1. In the event any part of this Agreement is invalidated by operation of law, the residual provisions

shall continue in force.

2. Matters not stipulated in this Agreement or any ambiguity or question raised in the construction of

this Agreement shall be provided or settled upon good-faith consultation between the Licensor and the User.

3. The Licensor and the User hereby agree that this Agreement is governed by the laws of Japan, and

any dispute arising from, and relating to the rights and obligations under, this Agreement shall be submitted to the exclusive jurisdiction of the Tokyo District Court for its first instance. JS_KWD_DPX794BH_KN_C.indd iiiJS_KWD_DPX794BH_KN_C.indd iii 7/4/2019 1:48:52 PM7/4/2019 1:48:52 PMData Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm)

Important Notice concerning the Software -jansson Copyright (c) 2009-2012 Petri Lehtinen <petri@digip.org> Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. -cJSON Copyright (c) 2009 Dave Gamble Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. -CMP The MIT License (MIT) Copyright (c) 2014 Charles Gunyon Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. nanopb Copyright (c) 2011 Petteri Aimonen <jpa at nanopb.mail.kapsi.fi> This software is provided 'as-is', without any express or implied warranty. In no event will the authors be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it and redistribute it freely, subject to the following restrictions:

1. The origin of this software must not be misrepresented; you must not claim that you wrote

the original software. If you use this software in a product, an acknowledgment in the product documentation would be appreciated but is not required.

2. Altered source versions must be plainly marked as such, and must not be misrepresented as being the

3. This notice may not be removed or altered from any source distribution.

sha2 AUTHOR: Aaron D. Gifford - http://www.aarongifford.com/ Copyright (c) 2000-2001, Aaron D. Gifford All rights reserved. You may obtain a copy of the license at https://opensource.org/licenses/BSD-3-Clause THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. Posix Copyright (c) 1990, 1993 The Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the

following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and

the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following

acknowledgement: This product includes software developed by the University of California, Berkeley and its contributors.

4. Neither the name of the University nor the names of its contributors may be used to endorse or

promote products derived from this software without specific prior written permission. Copyright (C) 1993 by Sun Microsystems, Inc. All rights reserved. Developed at SunPro, a Sun Microsystems, Inc. business. Permission to use, copy, modify, and distribute this software is freely granted, provided that this notice is preserved. Copyright (C) 1991-2, RSA Data Security, Inc. Created 1991. All rights reserved. License to copy and use this software is granted provided that it is identified as the “RSA Data Security, Inc. MD4 Message-Digest Algorithm” in all material mentioning or referencing this software or this function. Copyright (c) 1995, 1996 Carnegie-Mellon University. All rights reserved. Author: Chris G. Demetriou Permission to use, copy, modify and distribute this software and its documentation is hereby granted, provided that both the copyright notice and this permission notice appear in all copies of the software, derivative works or modified versions, and any portions thereof, and that both notices appear in supporting documentation. CARNEGIE MELLON ALLOWS FREE USE OF THIS SOFTWARE IN ITS "AS IS" CONDITION. CARNEGIE MELLON DISCLAIMS ANY LIABILITY OF ANY KIND FOR ANY DAMAGES WHATSOEVER RESULTING FROM THE USE OF THIS SOFTWARE. Carnegie Mellon requests users of this software to return to Software Distribution Coordinator or Software.Distribution@CS.CMU.EDU School of Computer Science Carnegie Mellon University Pittsburgh PA 15213-3890 any improvements or extensions that they make and grant Carnegie the rights to redistribute these changes. License is also granted to make and use derivative works provided that such works are identified as "derived from the RSA Data Security, Inc. MD4 Message-Digest Algorithm" in all material mentioning or referencing the derived work. RSA Data Security, Inc. makes no representations concerning either the merchantability of this software or the suitability of this software for any particular purpose. It is provided "as is" without express or implied warranty of any kind. Copyright (c) 1993 Martin Birgmeier All rights reserved. You may redistribute unmodified or modified versions of this source code provided that the above copyright notice and this and the following conditions are retained. This software is provided ``as is'', and comes with no warranties of any kind. I shall in no event be liable for anything that happens to anyone/anything when using this software. These notices must be retained in any copies of any part of this documentation and/or software. JS_KWD_DPX794BH_KN_C.indd vJS_KWD_DPX794BH_KN_C.indd v 10/8/2019 10:57:36 AM10/8/2019 10:57:36 AMData Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm)

The displays and faceplates shown in this manual are examples used to provide clear explanations of the operations. For this reason, they may be different from the actual displays or faceplates.

Operations are explained mainly using buttons on the faceplate of

English indications are used for the purpose of explanation. You can select the display language from the [FUNCTION] menu. (Page7)

[XX] indicates the selected items.

(PageXX) indicates references are available on the stated page. This symbol on the product means there are important operating and maintenance instructions in this manual. Be sure to carefully read instructions in this manual. JS_KWD_DPX794BH_KN_EN.indd 2JS_KWD_DPX794BH_KN_EN.indd 2 8/8/2019 1:59:48 PM8/8/2019 1:59:48 PMENGLISH

To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe Warnings and Cautions in this manual.

Please keep the manual in a safe and accessible place for future reference. WARNING

Do not operate any function that takes your attention away from safe driving.

Do not ingest the battery, Chemical Burn Hazard. The remote control supplied with this product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. CAUTION Volume setting:

Adjust the volume so that you can hear sounds outside the car to prevent accidents.

Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level. General:

Avoid using the external device if it might hinder safe driving.

Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.

Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit.

If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.

Depending on the types of cars, the antenna will automatically extend when you turn on the unit with the antenna control wire connected (page38). Turn off the unit or change the source to STANDBY when parking at a low ceiling area. Remote control (RC-406):

Do not leave the remote control in hot places such as on the dashboard.

Risk of fire or explosion if the battery is replaced by an incorrect type. Ensure to replace only with the same type.

Risk of fire, explosion or the leakage of flammable liquid or gas if the battery is left in an extremely high temperature surrounding environment and/or subjected extremely low air pressure. The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

Risk of fire, explosion or the leakage of flammable liquid or gas if the battery is disposed into fire or a hot oven, recharged, shorted, mechanically crushed or cut of the battery.

If spilled fluid comes in contact with your eyes or on clothing, immediately rinse with water and consult a physician. JS_KWD_DPX794BH_KN_EN.indd 3JS_KWD_DPX794BH_KN_EN.indd 3 8/8/2019 1:59:53 PM8/8/2019 1:59:53 PM4 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Basics To On the faceplate Turn on the power Press B SRC.

Press and hold to turn off the power. Adjust the volume Turn the volume knob. Select a source

Press B SRC repeatedly.

Press B SRC, then turn the volume knob within 2 seconds. Change the display information*2 Press DISP repeatedly. (Page 42) How to reset Faceplate *1 Only for illustration purpose. *2 For : You can also turn off the display information by pressing DISP repeatedly. (Page 42) : USB cable from the rear of the unit (USB input terminal). Display window*1Loading slot Eject button Volume knob JS_KWD_DPX794BH_KN_EN.indd 4JS_KWD_DPX794BH_KN_EN.indd 4 9/10/2019 11:01:44 AM9/10/2019 11:01:44 AMENGLISH

Data Size: B6L (182 mm x 128 mm)Book Size: B6L (182 mm x 128 mm) Remote control (RC-406) (supplied for ) Pull out the insulation sheet when using for the first time. Remote sensor (Do not expose to bright sunlight.) / / / / : Can be remotely controlled with an optionally purchased remote control. Getting Started

Select the display language and cancel the demonstration When you turn on the power for the first time (or [FACTORY RESET] is set to [YES] , see page7), the display shows: “SEL LANGUAGE” “PRESS” “VOLUME KNOB” 1 Turn the volume knob to select [ENG] (English) / [SPA] (Spanish) / [FRE] (French), then press the knob. [ENG] is selected for the initial setup. Then, the display shows: “CANCEL DEMO” “PRESS” “VOLUME KNOB”. 2 Press the volume knob again. [YES] is selected for the initial setup. 3 Press the volume knob again. “DEMO OFF” appears. How to replace the battery To On the remote control Adjust the volume Press VOL or VOL .

Press and hold VOL to continuously increase the volume to 15. Press ATT during playback to attenuate the sound.

Press again to cancel. Select a source Press SRC repeatedly. Turn off the power Press and hold SRC to turn off the power. ( Pressing SRC does not turn on the power. ) Basics JS_KWD_DPX794BH_KN_EN.indd 5JS_KWD_DPX794BH_KN_EN.indd 5 9/10/2019 11:01:44 AM9/10/2019 11:01:44 AM6 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Default: [XX] [DISPLAY] [EASY MENU] When entering [FUNCTION]... [ON]: [LCD DISPLAY] illumination changes to white color. ; [OFF]: [LCD DISPLAY] illumination remains as [COLOR SELECT] color. (Page 33)

[KEY 1] and [KEY 2] illuminations change to light blue color when you enter [FUNCTION], irregardless of the [EASY MENU] setting.

Refer to the illustration on page 33 for zone identification. [TUNER SETTING] [PRESET TYPE] [NORMAL]: Memorizes one station for each preset button in each band (FM1/FM2/FM3/AM). ; [MIX]: Memorizes one station or SiriusXM channel for each preset button, regardless of the selected band or SiriusXM channel. [SYSTEM] [KEY BEEP] [ON]: Activates the keypress tone. ; [OFF]: Deactivates. [SOURCE SELECT] [PANDORA SRC] (Except for ) [ON]: Enables PANDORA FRONT/PANDORA REAR/PANDORA/ PANDORA BT in source selection. ; [OFF]: Disables. (Page 14) [SPOTIFY SRC] [ON]: Enables SPOTIFY FRONT/SPOTIFY REAR/SPOTIFY/SPOTIFY BT in source selection. ; [OFF]: Disables. (Page 15)

Set the clock and date

Set the other optional settings You can only set the following items while the unit is in STANDBY source. 1 Press B SRC repeatedly to enter STANDBY. 2 Press the volume knob to enter [FUNCTION]

3 Turn the volume knob to select an item (see the following table), then press the knob. 4 Repeat step 3 until the desired item is selected or activated. 5 Press and hold to exit. To return to the previous setting item, press

Data Size: B6L (182 mm x 128 mm)Book Size: B6L (182 mm x 128 mm) Getting Started [CD READ] (Except for ) [1]: Automatically distinguishes between audio file disc and music CD. ; [2]: Forces to play as a music CD. No sound can be heard if an audio file disc is played.

See page 34 for details.

[UPDATE SYSTEM]/[UPDATE HD] (for

[F/W UP xxxx]/ [F/W UP Vxx] [YES]: Starts upgrading the firmware. ; [NO]: Cancels (upgrading is not activated). For details on how to update the firmware, visit <www.kenwood.com/cs/ce/>. [FACTORY RESET] [YES]: Resets the settings to default (except the stored station). ; [NO]: Cancels. [ENGLISH] Select the display language for [FUNCTION] menu and music information if applicable. By default, [ENGLISH] is selected. [ESPANOL] [FRANCAIS] You can tune in to both conventional and HD Radio broadcasts.

To find HD Radio stations in your area, visit <http://www.hdradio.com>. Search for a station

Press B SRC repeatedly to select HD RADIO. 2 Press BAND repeatedly (or press #FM+/

AM– on the remote control) to select FM1/FM2/FM3/AM. 3 Press S / T (or press S / T (+) on the remote control) to search for a station or channel. You can store up to 18 stations for FM, 6 stations for AM and 18 channels for HD Radio.

To store a station or channel: Press and hold one of the number buttons (1 to 6).

To select a stored station or channel: Press one of the number buttons (1 to 6) (or press one of the number buttons (1 to 6) on the remote control). HD Radio™ Tuner (for ) JS_KWD_DPX794BH_KN_EN.indd 7JS_KWD_DPX794BH_KN_EN.indd 7 10/8/2019 11:03:21 AM10/8/2019 11:03:21 AM8 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) HD Radio™ Tuner (for ) Direct Access Tuning (using the remote control) 1 Press DIRECT to enter Direct Access Tuning. 2 Press the number buttons to enter a station frequency or channel number. 3 Press ENT IW to search for station or channel.

To cancel, press or DIRECT.

If no operation is done for 10 seconds after step 2, Direct Access Tuning is automatically canceled. Select an HD Radio multicast channel Many HD Radio stations offer more than one channel programming. This service is called multicasting. While receiving HD Radio multicast channels.... Press S / T to select your desired channel (HD1 to HD8). “LINKING” appears while linking to a multicast channel. Receive an Emergency Alert message You can receive an emergency alert message while listening to another source or while in STANDBY, via HD Radio Broadcast. Activate emergency alert message reception

Receive an emergency alert message When an emergency alert message is received, it appears and remains on the display until the user performs the “Ignore” function. Press B SRC (or press SRC on the remote control) to ignore the alert message. The same emergency alert message will not interrupt again for 12 hours. Display received emergency alert messages The received emergency alert messages are stored in the Alert Message List, and you can check them later. While listening to the HD RADIO source... 1 Press to display the Alert Message List. 2 Turn the volume knob to select a message. 3 Press the volume knob to display the information related to the message. 4 Press again to exit.

“NO LIST” appears when the list is empty.

This feature can store up to four messages in the list.

[YES] . (Page 7) Other settings

2 Turn the volume knob to select an item (page 9), then press the knob. 3 Repeat step 2 until the desired item is selected or activated. 4 Press and hold to exit. To return to the previous setting item, press

buttons when pressed. [AUTO1]: Automatically search for a station or channel. ; [AUTO2]: Search for a preset station or channel. ; [MANUAL]: Manually search for a station or channel. [IF BAND] [AUTO]: Increases the tuner selectivity to reduce interference noises from adjacent FM stations. (Stereo effect may be lost.) ; [WIDE]: Subjects to interference noises from adjacent FM stations, but sound quality will not be degraded and the stereo effect will remain. [AUTO MEMORY] [YES]: Automatically starts memorizing 6 stations with good reception. ; [NO]: Cancels.

Selectable only if [NORMAL] is selected for [PRESET TYPE]. (Page 6) [RECEIVE MODE] Sets the receive mode of the HD Radio receiver. [AUTO]: Automatically tunes to analog broadcast when there is no digital broadcast. ; [DIGITAL]: Tunes in to digital broadcast only. ; [ANALOG]: Tunes in to analog broadcast only.

The setting automatically returns to [AUTO] when you tune in to another broadcast. [CLOCK] [TIME SYNC] [ON]: Synchronizes the unit’s time to the Radio Broadcast Data System station time. ; [OFF]: Cancels. Radio (for / / / / )

“ST” indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

The unit switches to FM alarm automatically when receiving an alarm signal from FM broadcast. Search for a station

Press B SRC repeatedly to select RADIO. 2 Press BAND repeatedly (or press #FM+/

AM– on the remote control) to select FM1/FM2/FM3/AM. 3 Press S / T (or press S / T (+) on the remote control) to search for a station. You can store up to 18 stations for FM and 6 stations for AM.

To store a station: Press and hold one of the number buttons (1 to 6).

To select a stored station: Press one of the number buttons (1 to 6) (or press one of the number buttons (1 to 6) on the remote control). JS_KWD_DPX794BH_KN_EN.indd 9JS_KWD_DPX794BH_KN_EN.indd 9 10/8/2019 11:09:09 AM10/8/2019 11:09:09 AM10 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) [NEWS SET] (For ) [ON]: The unit will temporarily switch to News Programme if available. ; [OFF]: Cancels. [REGIONAL] (For ) [ON]: Switches to another station only in the specific region using the “AF” control. ; [OFF]: Cancels. [AF SET] (For ) [ON]: Automatically searches for another station broadcasting the same program in the same Radio Data System network with better reception when the current reception is poor. ; [OFF]: Cancels. [TI] [ON]: Allows the unit to temporarily switch to Traffic Information if available (“TI” indicator lights up). ; [OFF]: Cancels. [PTY SEARCH] (For / / / ) Select the available Program Type (for Radio Broadcast Data System, see page 41), then press

to start searching. [CLOCK] [TIME SYNC] [ON]: Synchronizes the unit’s time to the Radio Broadcast Data System/ Radio Data System station time. ; [OFF]: Cancels.

[PTY SEARCH] is selectable only when the band is FM1/FM2/FM3.

If the volume is adjusted during reception of traffic information or news bulletin, the adjusted volume is memorized automatically. It will be applied the next time traffic information or news bulletin is turned on. Direct Access Tuning (using the remote control) 1 Press DIRECT to enter Direct Access Tuning. 2 Press the number buttons to enter a station frequency. 3 Press ENT IW to search for a station.

To cancel, press or DIRECT.

If no operation is done for 10 seconds after step 2, Direct Access Tuning is automatically canceled. Other settings

2 Turn the volume knob to select an item (see the following table), then press the knob. 3 Repeat step 2 until the desired item is selected/activated or follow the instructions stated on the selected item. 4 Press and hold to exit. To return to the previous setting item, press

Default: [XX] [TUNER SETTING] [SEEK MODE] Selects the searching method for

buttons when pressed. [AUTO1]: Automatically search for a station. ; [AUTO2]: Search for a preset station. ; [MANUAL]: Manually search for a station. [AUTO MEMORY] [YES]: Automatically starts memorizing 6 stations with good reception. ; [NO]: Cancels.

Selectable only if [NORMAL] is selected for [PRESET TYPE]. (Page 6) [MONO SET] [ON]: Improves the FM reception, but the stereo effect will be lost. ; [OFF]: Cancels. Radio (for / / / / ) JS_KWD_DPX794BH_KN_EN.indd 10JS_KWD_DPX794BH_KN_EN.indd 10 9/10/2019 11:01:46 AM9/10/2019 11:01:46 AMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) CD/USB/iPod Connect an iPod/iPhone USB input terminal KCA-iP103 (optional accessory)*1 or accessory of the iPod/iPhone*2 iPod/ iPhone (For

You can also connect to the USB cable from the rear of the unit (USB input terminal). The source changes to iPod FRONT/iPod REAR/iPod USB automatically and playback starts.

You can also connect iPod/iPhone via Bluetooth. (Page22) *1 KCA-iP103: Lightning type *2 Do not leave the cable inside the car when not in use. Basic operations Selectable source:

: USB/iPodUSB or iPodBT Insert a disc (except for ) Eject disc Label side The source changes to CD automatically and playback starts. Connect a USB device USB device USB input terminal (For

You can also connect to the USB cable from the rear of the unit (USB input terminal). CA-U1EX (max.: 500 mA) (optional accessory)* The source changes to USB FRONT/USB REAR/USB automatically and playback starts.

[REPEAT OFF] : iPod Random play*2 Press 3 repeatedly. [DISCRANDOM]

[SHUFFLE OFF] : iPod Press and hold 3 to select [ALL RANDOM] .*1 *1 For CD: Only for MP3/WMA/AAC files. This does not work for iPod. *2 For iPod: Applicable only when [MODE OFF] is selected. Select music drive While in USB FRONT/USB REAR/USB source, press 5 repeatedly. Stored songs in the following drive will be played back.

Selected internal or external memory of a smartphone (Mass Storage Class).

Selected drive of a multiple drive device. You can also select the music drive from the [FUNCTION] menu. 1 Press the volume knob to enter [FUNCTION]

[DRIVE 4] ) is selected automatically and playback starts. 5 Repeat step 1 to step 4 to select the following drives. 6 Press and hold to exit. To return to the previous setting item, press

Select control mode While in iPodFRONT/iPodREAR/iPodUSB source (or iPodBT source), press 5 repeatedly. [MODE ON] : Control iPod/iPhone using the iPod/iPhone itself. However, you can still perform play/pause, file skip, fast-forward or fast-reverse from this unit. [MODE OFF] : Control iPod/iPhone from this unit. Direct Music Search (using the remote control) 1 Press DIRECT. 2 Press the number buttons to enter a track/file number. 3 Press ENT IW to search for music.

To cancel, press or DIRECT.

Not available if Random Play is selected.

[10%] The skip search ratio is shown as a percentage of the total files. 5 Press and hold to exit. Alphabet search (applicable only for iPodFRONT/iPodREAR/iPodUSB source and iPodBT source) You can search for a file according to the first character.

For iPod, applicable only when [MODE OFF] is selected. (Page 12) 1 Press . 2 Turn the volume knob to select a list, then press the knob. 3 Turn the volume knob quickly to enter character search. 4 Turn the volume knob to select the character.

” to search for a character other than A to Z, 0 to 9. 5 Press S / T to move to the entry position.

You can enter up to 3 characters. 6 Press the volume knob to start searching. 7 Turn the volume knob to select a file, then press the knob. Selected file starts playing.

CD/USB/iPod Select a file to play From a folder or list

For iPod, applicable only when [MODE OFF] is selected. (Page 12) 1 Press . 2 Turn the volume knob to select a folder/list, then press the knob. 3 Turn the volume knob to select a file, then press the knob. Selected file starts playing. Quick search (applicable only for CD source and USBFRONT/USBREAR/USB source) If you have many files, you can search through them quickly. 1 Press . 2 Turn the volume knob to select a folder/list, then press the knob. 3 Turn the volume knob quickly to browse through the list quickly. 4 Turn the volume knob to select a file, then press the knob. Selected file starts playing. Skip search (applicable only for iPodFRONT/iPodREAR/iPodUSB source and iPodBT source) If you have many files in the selected list, you can perform the following to search for a file by skipping through the list at a rate selected in [SKIP SEARCH]

For iPod, applicable only when [MODE OFF] is selected. (Page 12) 1 Press . 2 Turn the volume knob to select a list, then press the knob. 3 Press S / T to search at a preset skip search ratio.

Pressing and holding S / T searches at a 10% ratio irregardless of the [SKIP SEARCH] settings. 4 Turn the volume knob to select a file, then press the knob. Selected file starts playing. JS_KWD_DPX794BH_KN_EN.indd 13JS_KWD_DPX794BH_KN_EN.indd 13 9/10/2019 11:01:46 AM9/10/2019 11:01:46 AM14 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Pandora® (for / / / / ) You can listen to Pandora on iPhone/iPod touch (via Bluetooth or via USB input terminal) or Android device (via Bluetooth). Preparation:

Install the latest version of the Pandora application on your device (iPhone/iPod touch or Android device), then create an account and log in to Pandora.

Select [ON] for [PANDORASRC]

Start up the Pandora application on your device. 2 Connect your device to the USB input terminal. USB input terminal KCA-iP103 (optional accessory)*1 or accessory of the iPhone/iPod touch*2 iPhone/ iPod touch (For

You can also connect to the USB cable from the rear of the unit (USB input terminal). You can also connect the iPhone/iPod touch or Android device via Bluetooth. (Page 22)

Make sure the USB input terminal is not connected to any device when you connect via Bluetooth. 3 Press B SRC repeatedly to select PANDORAFRONT/PANDORAREAR/ PANDORA (for iPhone/iPod touch) or PANDORABT (for Android device). Broadcast starts automatically. To On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Skip a track Press T. Press T (+). Select thumbs up or thumbs down*3 Press 1 / 2 . Press #FM+/ AM–. *1 KCA-iP103: Lightning type *2 Do not leave the cable inside the car when not in use. *3 If thumbs down is selected, the current track is skipped. Create and store a new station

[FROM TRACK] , then press the knob. A new station is created based on the current artist or current song. 4 Press and hold one of the number buttons (3, 4 or 5) to store. To select a stored station: Press one of the number buttons (3, 4 or 5). Search for a registered station

Press . 2 Turn the volume knob to select an item, then press the knob. [SORT BYDATE] : According to the registered date

Install the latest version of the Spotify application on your device (iPhone/ iPod touch or Android device), then create an account and log in to Spotify.

Select [ON] for [SPOTIFY SRC]

Start up the Spotify application on your device. 2 Connect your device to the USB input terminal. USB input terminal KCA-iP103 (optional accessory)*1 or accessory of the iPhone/iPod touch*2 iPhone/ iPod touch (For

You can also connect to the USB cable from the rear of the unit (USB input terminal). You can also connect the iPhone/iPod touch or Android device via Bluetooth. (Page 22)

Make sure the USB input terminal is not connected to any device when you connect via Bluetooth. 3 Press B SRC repeatedly to select SPOTIFYFRONT/ SPOTIFYREAR/ SPOTIFY (for iPhone/iPod touch) or SPOTIFYBT (for Android device). Broadcast starts automatically. *1 KCA-iP103: Lightning type *2 Do not leave the cable inside the car when not in use. (for / / / / Pandora®

Bookmark current song information Press and hold the volume knob. “BOOKMARKED” appears and the information is stored to your device.

The bookmark is available on your Pandora account but not on this unit. Delete a station While listening to Pandora... 1 Press . 2 Turn the volume knob to select [STATION DEL] , then press the knob. 3 Turn the volume knob to select

Press . 2 Turn the volume knob to select a list type, then press the knob. The list types displayed differ depending on the information sent from Spotify. 3 Turn the volume knob (or press J/K on the remote control) to select the desired song or station. 4 Press the volume knob (or press ENT IW on the remote control) to confirm. You can browse through the list quickly by turning the volume knob quickly. To cancel, press and hold

To On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Skip a track Press S*1 / T. Press S*1 / T (+). Select thumbs up or thumbs down *2 Press 1 / 2 . Press #FM+/ AM–. Start radio Press and hold 5. ( Not available ) Repeat play*3 Press 4 repeatedly. [REPEAT ALL]

[SHUFFLEOFF] ( Not available ) *1 Available for premium account users only. *2 This feature is available for tracks in Radio only. If thumbs down is selected, the current track is skipped. *3 Available for tracks in Playlists only. Save favorite song information While listening to the Radio on Spotify... Press and hold the volume knob. “SAVED” appears and the information is stored to “Your Music” or “Your Library” on your Spotify account. To unsave, repeat the same procedure. “REMOVED” appears and the information is removed from “Your Music” or “Your Library” on your Spotify account. JS_KWD_DPX794BH_KN_EN.indd 16JS_KWD_DPX794BH_KN_EN.indd 16 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AMENGLISH

Press B SRC repeatedly to select SIRIUSXM. 2 Press BAND repeatedly to select a band. 3 Press . “ ” indicator lights up. 4 Turn the volume knob to select a category, then press the knob. If “ALL CHANNELS” is selected, all the available channels will be shown. 5 Turn the volume knob to select a channel, then press the knob. (or) Press S / T to search for a channel manually.

Pressing and holding S / T changes the channel rapidly. If a locked channel or a mature channel is selected, a pass code input screen appears. Enter the pass code to receive the channel. (Page19) Direct Access Tuning (using the remote control) 1 Press DIRECT to enter Direct Access Tuning. 2 Press the number buttons to enter a channel number. 3 Press ENT IW to search for the channel.

To cancel, press or DIRECT.

If no operation is done for 10 seconds after step 2, Direct Access Tuning is automatically canceled. Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy and entertainment. Welcome to the world of satellite radio. A SiriusXM Vehicle Tuner and Subscription are required.

For more information, visit <www.siriusxm.com>. Preparation: 1 Connect the optional SiriusXM Vehicle Tuner (commercially available). Antenna Expansion port on the rear panel SiriusXM Vehicle Tuner 2 Check your Radio ID for activation. The SiriusXM Radio ID is required for activation and can be found by tuning to Channel 0 as well as on the label found on the SiriusXM Vehicle Tuner and its packaging. The Radio ID does not include the letters I, O, S or F. 3 Activate the subscription. For users in the U.S.A.: Online: Go to <www.siriusxm.com> Phone: Call 1-866-635-2349 For users in Canada: Online: Go to <www.siriusxm.ca/subscribe-now> Phone: Call 1-877-438-9677 4 Press B SRC repeatedly to select SIRIUSXM to start updating. JS_KWD_DPX794BH_KN_EN.indd 17JS_KWD_DPX794BH_KN_EN.indd 17 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AM18 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) SmartFavorites and TuneStart™ User stored channels are recognized as SmartFavorite channels*. The SiriusXM Vehicle Tuner automatically buffers the broadcast content in the background.

SmartFavorites feature is available with SXV200 or later SiriusXM Vehicle Tuner.

SXV300 (and later) SiriusXM Vehicle Tuner can use all 18 stored channels as SmartFavorites. The SXV200 SiriusXM Vehicle Tuner can use 6 stored channels from the current band as SmartFavorites. When you select a SmartFavorite channel, you can rewind and replay up to 30 minutes of any of the missed news, talk, sports or music content.

Playback starts from the beginning of the song if [TUNE START] is set to [ON] (page 19) for most music channels stored as a SmartFavorite. Press one of the number buttons (1 to 6) to select a stored channel. TuneScan™ You can get a short preview of the songs that you have missed on each of your SmartFavorites music channels or a music channel currently tuned into. Press and hold BAND to start scanning the first 6 seconds of the recorded music contents.

To listen to the current song, press the volume knob to stop scanning. The unit continues playing the current song.

To select the previous/next song, press S / T.

To cancel scanning, press and hold the volume knob. Playback returns to the channel before you entered TuneScan. SiriusXM® Radio (for / / / ) SiriusXM Keymode Press and hold the volume knob to change the keymode (channel or replay). (Default: Channel keymode)

” indicator lights up when replay keymode is selected. When channel keymode is selected... To On the faceplate On the remote control Select a channel Press S / T. Press S / T (+). Change a channel rapidly Press and hold S /

Press and hold S / T (+). Store a channel of the current band Press and hold one of the number buttons (1 to 6). ( Not available ) Select a stored channel of the current band Press one of the number buttons (1 to 6). Press one of the number buttons (1 to 6). When replay keymode is selected... To On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Skip backward/ forward Press S / T. Press S / T (+). Rewind/Fast-forward Press and hold S /

Default: [XX] [SIRIUS XM] [SEEK MODE] Selects the tuning method for

buttons when pressed. [CHANNEL]: Manually search for a channel. ; [PRESET]: Search for a preset channel of the selected band. [CHANNEL LOCK] To unlock settings:

to move to the entry position.

Repeat step 1 and step 2 to enter the current pass code. (Initial pass code is 0000.)

Press the volume knob to confirm. [CODESET]

to move to the entry position.

Repeat step 1 and step 2 to enter a new 4-digit pass code.

Press the volume knob to confirm.

Repeat step 1 to step 4 to reconfirm the pass code.

Make a note of the new pass code to enter channel lock settings for next time. [LOCK SETTING] [MATURE CH]: Selects the SiriusXM-defined lock setting. ; [USER DEFINED]: Selects the individual channels the user wants to lock. ; [OFF]: Cancels. [CHANNEL EDIT]*1

Turn the volume knob to select a channel you want to lock, then press the knob. “L” appears in front of the channel number.

Press and hold to exit. [CHANNEL CLEAR]*1 [YES]: Clears all the locked channels. ; [NO]: Cancels. [TUNE START]*2 [ON]: All qualified music channels in the SmartFavorites will start playback from the beginning of the song. ; [OFF]: Cancels. [SIGNAL LEVEL] Shows the strength ([NO SIGNAL]/[WEAK]/[GOOD]/[STRONG]) of the current received signal. [BUFFER USAGE] Shows the memory usage ([0%] to [100%]) for Replay buffer. [SXM RESET] [YES]: Resets all SiriusXM settings to default. ; [NO]: Cancels. *1 Displayed only when [LOCK SETTING] is set to [USER DEFINED]. *2 Available only if the connected SiriusXM Vehicle Tuner is SXV200 or later which supports SmartFavorites. SiriusXM® Radio (for / / / ) JS_KWD_DPX794BH_KN_EN.indd 19JS_KWD_DPX794BH_KN_EN.indd 19 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AM20 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Using Other Applications KENWOOD Remote application You can control the KENWOOD car receiver from iPhone/iPod touch (via Bluetooth or via USB input terminal) or Android device (via Bluetooth) using KENWOOD Remote application.

For more information, visit <http://www.kenwood.com/cs/ce/>. Preparation: Install the latest version of KENWOOD Remote application on your device before connecting. Start using KENWOOD Remote application

Start up the KENWOOD Remote application on your device. 2 Connect your device.

For Android device: Pair the Android device with this unit via Bluetooth. (Page 22)

For iPhone/iPod touch: Connect iPhone/iPod touch to the USB input terminal. (Page 11) (or) Pair the iPhone/iPod touch with this unit via Bluetooth. (Page 22) (Make sure the USB input terminal is not connected to any device.) 3 Select the device to use from the [FUNCTION] menu. See “ Settings to use KENWOOD Remote application” on page 21. By default, [ANDROID] is selected. To use iPhone/iPod touch, select [YES] for [IOS]

You can listen to music from a portable audio player via the auxiliary input jack. Preparation: Select [ON] for [BUILT-IN AUX]

Connect a portable audio player (commercially available). Portable audio player

3.5 mm (1/8") stereo mini plug with “L”

shaped connector (commercially available) Auxiliary input jack 2 Press B SRC repeatedly to select AUX. 3 Turn on the portable audio player and start playback. Set the name of the external device While listening to a portable audio player connected to the unit... 1 Press the volume knob to enter [FUNCTION]

[TV] 5 Press and hold to exit. To return to the previous setting item, press

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Using Other Applications Settings to use KENWOOD Remote application

2 Turn the volume knob to select an item (see the following table), then press the knob. 3 Repeat step 2 until the desired item is selected or activated. 4 Press and hold to exit. To return to the previous setting item, press

Default: [XX] [REMOTE APP] [SELECT] Selects the device ([IOS] or [ANDROID]) to use the application. [IOS] [YES]: Selects iPhone/iPod touch to use the application via Bluetooth or connected via USB input terminal. ; [NO]: Cancels. If [IOS] is selected, select iPod BT source (or iPod FRONT/iPod REAR/iPod USB source if your iPhone/iPod touch is connected via USB input terminal) to activate the application.

The connectivity of the application will be interrupted or disconnected if: – You change from iPod BT source to any playback source connected via the USB input terminal. – You change from iPod FRONT/iPod REAR/iPod USB source to iPod BT source. [ANDROID] [YES]: Selects Android device to use the application via Bluetooth. ; [NO]: Cancels. [ANDROID LIST] Selects the Android device to use from the list.

Displayed only when [ANDROID] of [SELECT] is set to [YES]. [STATUS] Shows the status of the selected device. [IOS CONNECTED]: You are able to use the application using the iPhone/ iPod touch connected via Bluetooth or USB input terminal. [IOS NOT CONNECTED]: No iOS device is connected to use the application. [ANDROID CONNECTED]: You are able to use the application using the Android device connected via Bluetooth. [ANDROID NOT CONNECTED]: No Android device is connected to use the application. Tuneln Radio/Tuneln Radio Pro While listening to TuneIn Radio or TuneIn Radio Pro, connect the iPhone/ iPod touch to the USB input terminal of the unit so that the unit will output the sound from these applications. JS_KWD_DPX794BH_KN_EN.indd 21JS_KWD_DPX794BH_KN_EN.indd 21 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AM22 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Pair and connect a Bluetooth device for the first time

Press B SRC to turn on the unit. 2 Search and select the name of your receiver (“DPX794BH”/ “DPX594BT”/“DPX560BT”/“DPX524BT”/“DPX504BT”/“DPX304MBT”) on the Bluetooth device. “PAIRING” “PASS XXXXXX” “Device name” “PRESS” “VOLUME KNOB” appears on the display.

For some Bluetooth devices, you may need to enter the Personal Identification Number (PIN) code immediately after searching. 3 Press the volume knob to start pairing. “PAIRING OK” appears when pairing is completed. Once pairing is completed, Bluetooth connection is established automatically.

” and/or “ ” indicator on the display window lights up.

Depending on the settings made for [BATT/SIGNAL] (page 24), the strength of the battery and signal of the connected device are shown on the supplementary display (page 42).

This unit supports Secure Simple Pairing (SSP).

Up to five devices can be registered (paired) in total.

Once the pairing is completed, the Bluetooth device will remain registered in the unit even if you reset the unit. To delete the paired device, see [DEVICE DELETE] on page26.

A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at any time. To connect or disconnect the registered device, see [PHONE SELECT]

[BT MODE] . (Page 26) However, while in BT AUDIO source, you can connect to five Bluetooth audio devices and switch between these five devices. (Page27)

Some Bluetooth devices may not automatically connect to the unit after pairing. Connect the device to the unit manually.

Refer to the instruction manual of the Bluetooth device for more information.

Depending on the Bluetooth version, operating system and the firmware version of your mobile phone, Bluetooth features may not work with this unit.

Be sure to turn on the Bluetooth function of the device to make the following operations.

Signal conditions vary depending on the surroundings. Bluetooth — Connection Supported Bluetooth profiles – Hands-Free Profile (HFP) – Advanced Audio Distribution Profile (A2DP) – Audio/Video Remote Control Profile (AVRCP) – Serial Port Profile (SPP) – Phonebook Access Profile (PBAP) Supported Bluetooth codecs – Sub Band Codec (SBC) – Advanced Audio Coding (AAC) Connect the microphone Adjust the microphone angle Secure using cord clamps (not supplied) if necessary. Microphone input jack* Microphone (supplied) Rear panel

For the location of the microphone input terminal/microphone input jack, refer to page 39. Bluetooth® JS_KWD_DPX794BH_KN_EN.indd 22JS_KWD_DPX794BH_KN_EN.indd 22 10/8/2019 11:14:48 AM10/8/2019 11:14:48 AMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Auto Pairing When you connect iPhone/iPod touch to the USB input terminal, pairing request (via Bluetooth) is automatically activated if [AUTO PAIRING] is set to [ON] . (Page 26) Press the volume knob to pair once you have confirmed the device name. Bluetooth — Mobile phone Receive a call When there is an incoming call:

[KEY 1] zone and [KEY 2] zone illuminate in green color and flash.

The unit answers the call automatically if [AUTO ANSWER] is set to a selected time. (Page24) During a call:

[LCD DISPLAY] zone illuminates according to the settings made for [COLOR SELECT] (page33) while [KEY 1] zone and [KEY 2] zone illuminate in green color.

If you turn off the unit, Bluetooth is disconnected. Bluetooth® The following operations may differ or be unavailable depending on the connected phone. To On the faceplate On the remote control First incoming call... Answer a call Press or the volume knob or one of the number buttons (1 to 6). Press

While talking on the first incoming call... Answer another incoming call and hold the current call Press . Press . Reject another incoming call Press

While having two active calls... End current call and activate held call Press

Swap between the current call and held call Press . Press . JS_KWD_DPX794BH_KN_EN.indd 23JS_KWD_DPX794BH_KN_EN.indd 23 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AM24 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Make the setting for receiving a call

Press to enter Bluetooth mode. 2 Turn the volume knob to select an item (see the following table), then press the knob. 3 Repeat step 2 until the desired item is selected or activated. 4 Press and hold to exit. To return to the previous setting item, press

Default: [XX] [SETTINGS] [AUTO ANSWER] [1] to [30]: The unit answers incoming call automatically in the selected time (in seconds). ; [OFF]: Cancels. [BATT/SIGNAL]* [AUTO]: Shows the strength of the battery and signal on the supplementary display (page 42) when the unit detects a Bluetooth device and the Bluetooth device is connected. ; [OFF]: Cancels.

Functionality depends on the type of the phone used. Make a call You can make a call from the call history, phonebook, or dialing the number. Call by voice is also possible if your mobile phone has the feature. 1 Press to enter Bluetooth mode. “(First device name)” appears.

If two Bluetooth phones are connected, press again to switch to the other phone. “(Second device name)” appears. 2 Turn the volume knob to select an item (page 25), then press the knob. 3 Repeat step 2 until the desired item is selected/activated or follow the instructions stated on the selected item. 4 Press and hold to exit. To return to the previous setting item, press

Bluetooth® To On the faceplate On the remote control Adjust the phone volume*1 [00]

Turn the volume knob during a call. Press VOL

continuously increase the volume to 15. Switch between hands- free and private talk modes*2 Press 6 IW during a call. ( Not available ) *1 This adjustment will not affect the volume of the other sources. *2 Operations may vary according to the connected Bluetooth device. Improve the voice quality While talking on the phone... 1 Press the volume knob to enter [FUNCTION]

Default: [XX] [MIC GAIN] [LEVEL –10] to [LEVEL +10] ([LEVEL –4]): The sensitivity of the microphone increases as the number increases. [NR LEVEL] [LEVEL –5] to [LEVEL +5] ([LEVEL 0]): Adjust the noise reduction level until the least noise is being heard during a phone conversation. [ECHO CANCEL] [LEVEL –5] to [LEVEL +5] ([LEVEL 0]): Adjust the echo cancellation delay time until the least echo is being heard during a phone conversation. JS_KWD_DPX794BH_KN_EN.indd 24JS_KWD_DPX794BH_KN_EN.indd 24 10/8/2019 11:19:22 AM10/8/2019 11:19:22 AMENGLISH

“INCOMING,” “OUTGOING” or “MISSED” is shown on the lower part of the display to indicate the previous call status.

Press DISP to change the display category (NUMBER or NAME).

“NO DATA” appears if there is no recorded call history or call number.

Press the volume knob to call. [PHONE BOOK] (Applicable only if the phone supports PBAP.)

Turn the volume knob quickly to enter alphabet search mode (if the phonebook contains many contacts). The first menu (ABCDEFGHIJK) appears.

To go to the other menu (LMNOPQRSTUV or WXYZ1 ), press 1 /

, then press the knob. Select “1” to search with numbers and select “ ” to search with symbols.

For using phonebook with this unit, make sure to allow access to or transfer from your smartphone. Depending on the connected phone, the process may be different.

Contacts are categorized as: HOME, OFFICE, MOBILE, OTHER, GENERAL

This unit can display only non-accent letters. (Accent letters such as “Ú” are shown as “U”.) [NUMBER DIAL]

Turn the volume knob to select a number (0 to 9) or character ( , #, +).

to move the entry position. Repeat step 1 and step 2 until you finish entering the phone number.

Press the volume knob to call. (or using the remote control)

Press the number buttons (0 to 9) to enter the phone number.

Press to call. Bluetooth® [VOICE] Speak the name of the contact you want to call or the voice command to control the phone functions. (See also the following “Make a call using voice recognition”.) [LOW]/[MID]/[FULL]: Shows the strength of the battery.* [NO SIGNAL]/[LOW]/[MID]/[MAX]: Shows the strength of the current received signal.*

Functionality depends on the type of the phone used. Make a call using voice recognition

Press and hold VOICE to activate the voice recognition of the connected phone. 2 Speak the name of the contact you want to call or the voice command to control the phone functions.

Supported Voice Recognition features vary for each phone. Refer to the instruction manual of the connected phone for details. Store a contact in memory You can store up to 6 contacts into the number buttons (1 to 6). 1 Press to enter Bluetooth mode. 2 Turn the volume knob to select [CALL HISTORY]

[NUMBERDIAL] , then press the knob. 3 Turn the volume knob to select a contact or enter a phone number. If a contact is selected, press the volume knob to show the phone number. 4 Press and hold one of the number buttons (1 to 6). “STORED” appears when the contact is stored. To erase a contact from the preset memory, select [NUMBER DIAL] in step 2, store a blank number in step 3 and proceed to step 4. JS_KWD_DPX794BH_KN_EN.indd 25JS_KWD_DPX794BH_KN_EN.indd 25 9/10/2019 11:01:47 AM9/10/2019 11:01:47 AM26 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) [RECONNECT] [ON]: The unit is automatically reconnect when the last connected Bluetooth device is within the connectable range. ; [OFF]: Cancels. [AUTO PAIRING] [ON]: The unit is automatically paired with the supported Bluetooth device (iPhone/iPod touch) when it is connected through USB input terminal. Depending on the operating system of the connected device, this function may not work. ; [OFF]: Cancels. [INITIALIZE] [YES]: Initializes all the Bluetooth settings (including stored pairing, phonebook, and etc.). ; [NO]: Cancels. Bluetooth test mode You can check the connectivity of the supported profile between the Bluetooth device and the unit.

Make sure there is no Bluetooth device paired. 1 Press and hold . “PLEASE PAIR YOUR PHONE PIN 0000” appears on the display. 2 Search and select the name of your receiver (“DPX794BH”/ “DPX594BT”/“DPX560BT”/“DPX524BT”/“DPX504BT”/“DPX304MBT”) on the Bluetooth device. 3 Operate the Bluetooth device to confirm pairing. “TESTING” flashes on the display. The connectivity result (OK or NG) appears after the test. PAIRING: Pairing status HF CNT: Hands-Free Profile (HFP) compatibility AUD CNT: Advanced Audio Distribution Profile (A2DP) compatibility PB DL: Phonebook Access profile (PBAP) compatibility To cancel test mode, press and hold B SRC to turn off the unit. Bluetooth® Make a call to a registered number

Press to enter Bluetooth mode. 2 Press one of the number buttons (1 to 6). 3 Press the volume knob to call. “NO MEMORY” appears if there is no contact stored. Bluetooth mode settings

Default: [XX] [BT MODE] [PHONE SELECT] Selects the phone or audio device to connect or disconnect.

” appears in front of the device name when connected.

” appears in front of the current playback audio device.

You can connect a maximum of two Bluetooth phones and one Bluetooth audio device at a time. [AUDIO SELECT] [DEVICE DELETE]

Turn the volume knob to select a device to delete, then press the knob.

to move the entry position. Repeat step 1 and step 2 until you finish entering the PIN code.

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Bluetooth — Audio While in BT AUDIO source, you can connect to five Bluetooth audio devices and switch between these five devices. Listen to the audio player via Bluetooth

Press B SRC repeatedly (or press SRC on the remote control) to select BTAUDIO.

For : Pressing enters BT AUDIO directly. 2 Operate the audio player via Bluetooth to start playback. To On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Select group or folder Press 1 / 2 . Press #FM+/ AM–. Reverse skip/ Forward skip Press S / T. Press S / T (+). Reverse/Fast-forward Press and hold S /

Press and hold S / T (+). Bluetooth® To On the faceplate Repeat play Press 4 repeatedly. [ALLREPEAT]

[REPEATOFF] Random play Press and hold 3 to select [ALLRANDOM]

Press 3 to select [RANDOMOFF]. Select a file from a folder/list Refer to “Select a file to play” on page 13. Switch between connected Bluetooth audio devices Press 5. (Pressing the “Play” key on the connected device itself also causes switching of sound output from the device.)

Depending on the connected device, some devices may not support this feature. Operations and display indications may differ according to their availability on the connected device. Listen to iPod/iPhone via Bluetooth You can listen to the songs on the iPod/iPhone via Bluetooth on this unit. Press B SRC repeatedly to select iPodBT.

You can operate the iPod/iPhone in the same way as iPod/iPhone via USB input terminal. (Page11)

If you plug in an iPod/iPhone to the USB input terminal while listening to iPodBT source, the source automatically changes to iPodFRONT/ iPODREAR/iPodUSB source. Press B SRC to select iPodBT source if the device is still connected via Bluetooth. JS_KWD_DPX794BH_KN_EN.indd 27JS_KWD_DPX794BH_KN_EN.indd 27 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AM28 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) AMAZON ALEXA (for / / / / ) Alexa is the cloud-based voice service developed by Amazon. You can ask Alexa to play music, get weather reports, traffic information, control smart home devices, shop on Amazon, search the internet, set reminders and more. Preparation:

Create an account at <www.amazon.com>.

Install the latest version of the Alexa mobile application on your device (iPhone/iPod touch or Android device), then log in to the application.

Be sure to enable the internet connection on your smartphone. Setup for the first time For Android device 1 Pair your device with this unit via Bluetooth. (Page 22) 2 Start up the Alexa mobile application on your device. 3 Pair this unit to Alexa mobile application. Perform Option A or Option B. For iPhone/iPod touch 1 Pair your device with this unit via Bluetooth. (Page 22) 2 Start up the Alexa mobile application on your device. 3 Press on the unit to enter ALEXA source.

You may also press B SRC repeatedly to select iPod BT source. 4 Pair this unit to Alexa mobile application. Perform Option A or Option B. Option A: Direct Link Access the following URL or scan the QR code with your smartphone: https://www.kenwood.com/car/alexa Option B: Manual Pairing 1 Start up the Alexa mobile application and go to the “Devices” tab. 2 Tap the “ + ” icon at the top right corner. 3 Tap “Add Device”. 4 Tap “Automotive Accessory” or “Headphones” from the list of device types. 5 Tap the name of your receiver (

“DPX794BH”/“DPX594BT”/“DPX560BT”/

“DPX504BT”/“DPX304MBT”

) and follow the instructions. Once the setup process is completed, the Alexa mobile application will establish a connection with this unit.

The Alexa connection can be disconnected if: – A2DP profile is disconnected – Bluetooth is disconnected – This unit is turned off – Any other conditions depending on the connected device. To establish Alexa connection again, reconnect the A2DP profile.

Alexa connection cannot be established again if you: – Reinstall Alexa mobile application – Delete the paired device and perform pairing again (for Android device) To establish Alexa connection again, perform the setup process again.

You can check the Alexa connection from the Alexa mobile application. If the name of this unit appears on the screen of “ALL DEVICES”, you do not need to perform setup process again. Basic operations Once Alexa connection is established... JS_KWD_DPX794BH_KN_EN.indd 28JS_KWD_DPX794BH_KN_EN.indd 28 10/8/2019 11:59:52 AM10/8/2019 11:59:52 AMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) 1 Press on the unit to speak with Alexa. The display shows: “ALEXA” “LISTENING...”. 2 Communicate with Alexa via the connected microphone. (Page22) “THINKING...” appears when Alexa is processing your voice input. “SPEAKING...” appears while Alexa is responding to your voice input. “ALEXA” or display information such as playing time, song title, etc. appears while Alexa is in idle state.

To return to the previous source before ALEXA, press B SRC (or press SRC on the remote control).

To cancel current thinking/speaking states and go to listening state, press

Only one Alexa connection can be connected at one time.

“DISCONNECTED” appears if the unit is disconnected from Alexa mobile application or the Bluetooth connection is disconnected. Start listening While in Alexa idle state... 1 Press on the unit to activate Alexa. The display shows: “LISTENING...”. 2 Communicate with Alexa via the connected microphone. (Page22) 3 During music playback in ALEXA source, you can perform the following operations: To On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Reverse skip/Forward skip Press S / T. Press S / T (+). During music playback, press to pause the music and activate Alexa. You can now start to communicate with Alexa. AMAZON ALEXA Audio Settings 1 Press the volume knob to enter [FUNCTION]

2 Turn the volume knob to select an item (see the following table), then press the knob. 3 Repeat step 2 until the desired item is selected or activated. 4 Press and hold to exit. (or using the remote control) 1 Press AUD to enter [AUDIO CONTROL]

Default: [XX] [AUDIO CONTROL] [SUB-W LEVEL] [LEVEL –50] to [LEVEL +10] ([LEVEL 0]): Adjusts the subwoofer output level. [EASYEQ] Adjusts your own sound settings.

The settings are stored to [USER] in [PRESET EQ].

The settings made may affect the current settings of [MANUAL EQ]. [SW]: [LEVEL –50] to [LEVEL +10] (Default: [LEVEL 0] [BASS]: [LEVEL –9] to [LEVEL +9] [LEVEL 0] [MID]: [LEVEL –9] to [LEVEL +9] [LEVEL 0] [TRE]: [LEVEL –9] to [LEVEL +9] [LEVEL 0]) (for

The settings are stored to [USER] in [PRESET EQ].

The settings made may affect the current settings of [EASYEQ]. [62.5HZ] [LEVEL] [LEVEL–9] to [LEVEL+9] ([LEVEL0]): Adjusts the level to memorize for each source. (Before making an adjustment, select the source you want to adjust.) [BASS EXTEND] [ON]: Turns on the extended bass. ; [OFF]: Cancels. [100HZ]/[160HZ]/ [250HZ]/[400HZ]/ [630HZ]/[1KHZ]/ [1.6KHZ]/[2.5KHZ]/ [4KHZ]/[6.3KHZ]/ [10KHZ]/[16KHZ] [LEVEL –9] to [LEVEL +9] ([LEVEL 0]): Adjusts the level to memorize for each source. (Before making an adjustment, select the source you want to adjust.) [Q FACTOR] [1.35]/[1.50]/[2.00]: Adjusts the quality factor. [PRESET EQ] [NATURAL]/[ROCK]/[POPS]/[EASY]/[TOP40]/[JAZZ]/[POWERFUL]/ [USER]: Selects a preset equalizer suitable to the music genre. (Select [USER] to use the settings made in [EASY EQ] or [MANUALEQ].) [BASS BOOST] [LEVEL1] to [LEVEL5]: Selects your preferred bass boost level. ; [OFF]: Cancels. [LOUDNESS] [LEVEL1]/[LEVEL2]: Selects your preferred low or high frequencies boost to produce a well-balanced sound at low volume. ; [OFF]: Cancels. [SUBWOOFER SET] [ON]: Turns on the subwoofer output. ; [OFF]: Cancels. [FADER] [R15] to [F15] ([0]): Adjusts the front and rear speaker output balance. [BALANCE] [L15] to [R15] ([0]): Adjusts the left and right speaker output balance. [VOLUME OFFSET] [–15] to [+6] ([0]): Presets the initial volume level of each source by comparing to the FM volume level. (Before adjustment, select the source you want to adjust.) [SOUND EFFECT] [SOUNDRECNSTR] (Sound reconstruction) (Not applicable for RADIO source, AUX source and SIRIUS XM source.) [ON]: Creates realistic sound by compensating the high-frequency components and restoring the rise-time of the waveform that are lost in audio data compression. ; [OFF]: Cancels. [SPACE ENHANCE] (Not applicable for RADIO source.) [SMALL]/[MEDIUM]/[LARGE]: Virtually enhances the sound space. ; [OFF]: Cancels. [SND REALIZER] [LEVEL1]/[LEVEL2]/[LEVEL3]: Virtually makes the sound more realistic. ; [OFF]: Cancels. [STAGE EQ] [LOW]/[MIDDLE]/[HIGH]: Virtually adjusts the sound position heard from the speakers. ; [OFF]: Cancels. [DRIVE EQ] [ON]: Boosts the frequency to reduce the noise heard from outside the car or running noise of the tyres. ; [OFF]: Cancels. [SPEAKER SIZE] The frequency and slope settings are automatically set for the crossover of the selected speaker. [FRONT] [SIZE] [3.5”]/[4”]/[4.75”]/[5”]/[6.5”]/[6.75”]/[7”]/[4×6]/ [5×7]/[6×8]/[6×9]/[7×10]: Selects according to the connected speaker size for optimum performance. [TWEETER] [SMALL]/[MIDDLE]/[LARGE]: Selects according to the size range of the connected tweeter for optimum performance. ; [NONE]: Not connected. [REAR] [3.5”]/[4”]/[4.75”]/[5”]/[6.5”]/[6.75”]/[7”]/[4×6]/[5×7]/[6×8]/ [6×9]/[7×10]: Selects according to the connected speaker size for optimum performance. ; [NONE]: Not connected. [SUBWOOFER] [6.5”]/[8”]/[10”]/[12”]/[15” OVER]: Selects according to the connected speaker size for optimum performance. ; [NONE]: Not connected. Audio Settings JS_KWD_DPX794BH_KN_EN.indd 30JS_KWD_DPX794BH_KN_EN.indd 30 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Audio Settings [X ‘ OVER] [TWEETER] [FRQ]

[1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/[5KHZ]/

[6.3KHZ]/[8KHZ]/[10KHZ]/[12.5KHZ]: Adjusts the crossover frequency for the tweeter speaker. [GAIN LEFT] [–8] to [0]: Adjusts the output volume of the left tweeter. [GAIN RIGHT] [–8] to [0]: Adjusts the output volume of the right tweeter.

[FRONT HPF] [F-HPF FRQ]

[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/ [90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/ [220HZ]/[250HZ]: Adjusts the crossover frequency for the selected speakers (high pass filter). ; [THROUGH]: All signals are sent to the selected speakers. [F-HPF SLOPE] [–6DB]/[–12DB]/[–18DB]/[–24DB]: Adjusts the crossover slope. (Selectable only if a setting other than [THROUGH] is selected for [F - HPF FRQ].) [F-HPF GAIN] [–8] to [0]: Adjusts the output volume of the selected speaker.

[REAR HPF] [R-HPF FRQ]

Configure the settings for the rear speakers similarly to the front speakers. [R-HPF SLOPE] [R-HPF GAIN]

[SUBWOOFER LPF] [SW LPF FRQ]

[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/ [90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/ [220HZ]/[250HZ]: Adjusts the crossover frequency for the subwoofer (low pass filter). ; [THROUGH]: All signals are sent to the subwoofer. [SW LPF SLOPE] [–6DB]/[–12DB]/[–18DB]/[–24DB]: Adjusts the crossover slope. (Selectable only if a setting other than [THROUGH] is selected for [SW LPF FRQ].) [SW LPF PHASE] [REVERSE] (180°)/[NORMAL] (0°): Selects the phase of the subwoofer output to be in line with the speaker output for optimum performance.

[–8] to [0]: Adjusts the output volume of the subwoofer. [DTA SETTINGS] For settings, see “Digital Time Alignment settings” on page 32. [CAR SETTINGS]

The following item is selectable only if [SUBWOOFER SET] is set to [ON] (page30):

The following item is selectable only if a setting other than [NONE]

selected for [TWEETER]

[X ‘ OVER] JS_KWD_DPX794BH_KN_EN.indd 31JS_KWD_DPX794BH_KN_EN.indd 31 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AM32 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Audio Settings Digital Time Alignment settings Digital Time Alignment sets the delay time of the speaker output to create a more suitable environment for your vehicle.

For more information, see the following “Determining the delay time automatically”. [DTA SETTINGS] [POSITION] Selects your listening position (reference point). [ALL]: Not compensating ; [FRONT RIGHT]: Front right seat ; [FRONT LEFT]: Front left seat ; [FRONT ALL]: Front seats [DISTANCE] [0FT] to [20.01FT]: Fine adjust the distance to compensate. (Before making an adjustment, select the speaker you want to adjust.) [GAIN] [–8DB] to [0DB]: Fine adjust the output volume of the selected speaker. (Before making an adjustment, select the speaker you want to adjust.) [DTA RESET] [YES]: Resets the settings ([DISTANCE] and [GAIN]) of the selected [POSITION] to default. ; [NO]: Cancels. [CAR SETTINGS] Identify your car type and rear speaker location in order to make the adjustment for [DTA SETTINGS]. [CAR TYPE] [COMPACT]/[FULL SIZE CAR]/[WAGON]/[MINIVAN]/[SUV]/ [MINIVAN(LONG)]: Selects the type of vehicle. ; [OFF]: Not compensating. [R-SP LOCATION] Selects the location of the rear speakers in your vehicle to calculate the furthest distance from the listening position selected (reference point).

[DOOR]/[REAR DECK]: Selectable only when [CAR TYPE] is selected as [OFF], [COMPACT], [FULL SIZE CAR], [WAGON] or [SUV].

[2ND ROW]/[3RD ROW]: Selectable only when [CAR TYPE] is selected as [MINIVAN] or [MINIVAN(LONG)].

Before making an adjustment for [DISTANCE] and [GAIN]

select the speaker you want to adjust: [FRONT LEFT]

[SUBWOOFER] – You can only select [REAR LEFT]

[REAR RIGHT] and [SUBWOOFER] if a setting other than [NONE] is selected for [REAR] and [SUBWOOFER]

[CAR SETTING] is selectable only if a setting other than [NONE] is selected for [REAR]

Determining the delay time automatically If you specify the distance from the currently set listening position to every speaker, the delay time will be automatically calculated.

Set [POSITION] and determine the listening position as the reference point (the reference point for [FRONT ALL] will be the center between the right and left in the front seats).

Measure the distances from the reference point to the speakers.

Calculate the distance between the furthest speaker (subwoofer on the illustration) and other speakers.

Sets the [DISTANCE] calculated in step 3 for individual speakers.

Adjusts [GAIN] for individual speakers. Example: When [FRONT ALL] is selected as the listening position. JS_KWD_DPX794BH_KN_EN.indd 32JS_KWD_DPX794BH_KN_EN.indd 32 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Display Settings Zone identification for color settings and brightness settings Set the dimmer Press and hold DISP (DIM) to turn on or off the dimmer.

Default: [XX] [DISPLAY] [COLOR SELECT] Selects illumination colors for [ALLZONE], [LCDDISPLAY], [KEY1] and [KEY2] separately.

Select a zone. (See the illustration on left column.)

Select a preset color for the selected zone. (Page 34) Default: [VARIABLE SCAN] To make your own color, select [CUSTOM R/G/B]. The color you have made will be stored in [CUSTOM R/G/B].

Press the volume knob to enter the detailed color adjustment.

to select the color ([R]/[G]/[B]) to adjust.

Turn the volume knob to adjust the level ([0] to [9]), then press the knob. [DIMMER] Dims the illumination. [ON]: Dimmer is turned on. [OFF]: Dimmer is turned off. [DIMMER TIME]: Set the time to turn on dimmer and to turn off dimmer.

Turn the volume knob to adjust the [OFF] time, then press the knob. Default: [ON]: [PM6:00] ; [OFF]: [AM6:00] [BRIGHTNESS] Sets the brightness for day and night separately.

[DAY]/[NIGHT]: Select day or night.

Select a zone. (See the illustration on left column.)

[LEVEL00] to [LEVEL31]: Set the brightness level. [TEXT SCROLL] [ONCE]: Scrolls the display information once. ; [AUTO]: Repeats scrolling at 5-second intervals. ; [OFF]: Cancels. JS_KWD_DPX794BH_KN_EN.indd 33JS_KWD_DPX794BH_KN_EN.indd 33 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AM34 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Display Settings Learning Steering Remote Control (for ) You can control the unit with the steering remote control keys on your vehicle. After connection, you can configure the control keys according to your preference.

You can only make this configuration if your vehicle is equipped with the electrical steering remote control.

If the steering remote control in your car is not compatible, configuration may not be completed and an error message may appear. (Page 43) Make the connection Steering remote cable (supplied) Learning steering remote input terminal Rear panel Bright green/red Purple/red Gray/red Connect to your vehicle’s steering remote harness. Contact your KENWOOD dealer for details. Configure the control keys

Press B SRC repeatedly to enter STANDBY. 2 Press the volume knob to enter [FUNCTION]

[K## NONE] : No function has been assigned. 6 Turn the volume knob to select any key from the key list to assign the function, then press the knob. “PRESS KEY TO ASSIGN K##” appears. [CLOCK] [CLOCK DISPLAY] [ON]: The clock time is shown on the display even when the unit is turned off. ; [OFF]: Cancels. [DEMO MODE] [ON]: Activates the display demonstration automatically if no operation is done for about 15 seconds. ; [OFF]: Deactivates. Preset color: [INITIAL COLOR]

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Learning Steering Remote Control (for ) 7 Press and hold any control keys on your steering remote control which you want to assign. A list of key functions will appear on the display. [NONE] (default)/ [ATT]

[ENTER] 8 Turn the volume knob to select a function to assign, then press the knob. The selected key function is assigned to the steering remote control key you have selected in step 7. The display returns to the key list as on step 5.

[K## (Function)] : When certain function has been assigned to a key. 9 Repeat step 6 to step 8 to assign other control keys. 10 Press and hold to exit. Reassign the control keys

Press B SRC repeatedly to enter STANDBY. 2 Press the volume knob to enter [FUNCTION]

, then press the knob. 5 Turn the volume knob to select [RESET KEY] , then press the knob. 6 Turn the volume knob to select [YES] , then press the knob. All the control keys will be reset. Selecting [NO] will cancel the operation. When [FACTORY RESET] is set to [YES] (page 7), it will also reset the learning steering remote control. To return to the previous setting item, press . This section is for the professional installer. For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer. WARNING

The unit can only be used with a 12V DC power supply, negative ground.

Disconnect the battery’s negative terminal before wiring and mounting.

Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire (black) to prevent a short circuit.

To prevent short circuit: – Insulate unconnected wires with vinyl tape. – Be sure to ground this unit to the car’s chassis again after installation. – Secure the wires with cable clamps and wrap vinyl tape around the wires that comes into contact with metal parts to protect the wires. CAUTION

Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during and shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.

Do not connect the wires of speakers to the car chassis or Ground wire (black), or connect them in parallel.

Mount the unit at an angle of less than 30°.

If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red) to the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned on and off by the ignition key.

Keep all cables away from heat dissipate metal parts.

After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are working properly.

If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old fuse with one that has the same rating. Installation/Connection JS_KWD_DPX794BH_KN_EN.indd 35JS_KWD_DPX794BH_KN_EN.indd 35 9/10/2019 11:01:48 AM9/10/2019 11:01:48 AM36 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Part list for installation (Parts supplied for / / ) (A) Mounting sleeve ( ×1 ) (B) Trim plate ( ×1 ) (C) Trim plate (only for Toyota car) ( ×1 ) (D) Extraction key ( ×2 ) (Parts supplied for all models) (E) Round head screw ( ×6 )

(F) Flat head screw ( ×6 )

(G) Wiring harness ( ×1 ) Installation/Connection Basic procedure 1 Remove the key from the ignition switch, then disconnect the terminal of the car battery. 2 Connect the wires properly. See “Wiring connection” on page38. 3 Install the unit to your car. See the following “Installing the unit (in-dash mounting)”. 4 Connect the terminal of the car battery. 5 Press B SRC to turn on the power. 6 Reset the unit. (Page4) Installing the unit (in-dash mounting) (For / / ) Do the required wiring. (Page 38) Dashboard of your car Bend the appropriate tabs to hold the mounting sleeve firmly in place. JS_KWD_DPX794BH_KN_EN.indd 36JS_KWD_DPX794BH_KN_EN.indd 36 9/10/2019 3:08:28 PM9/10/2019 3:08:28 PMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Installation/Connection Removing the unit (For / / ) 1 Fit the catch pin on the extraction keys into the holes on both sides of the trim plate, then pull it out. 2 Insert the extraction keys deeply into the slots on each side, then follow the arrows as shown on the illustration. Installing the unit (without mounting sleeve) Align the holes in the unit (on both sides) with the vehicle mounting bracket and secure the unit with screws (supplied).

For / / : Remove the mounting sleeve and trim plate from the unit before installing. Use only the specified screws. Using wrong screws might damage the unit. (For / / / / ) (For ) Installing in Toyota cars (For / / ) Install onto the car brackets using screws (E) or (F) (supplied). Use the mounting holes ( ) or ( ) that fit the car brackets. Then, install the supplied trim plate (C). Do the required wiring. (Page 38) Dashboard of your car Car bracket*

Only for illustration purpose. JS_KWD_DPX794BH_KN_EN.indd 37JS_KWD_DPX794BH_KN_EN.indd 37 9/10/2019 3:08:31 PM9/10/2019 3:08:31 PM38 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Wiring connection Brown (Mute control wire) To connect the Kenwood navigation system, refer your navigation manual To the power control terminal when using the optional power amplifier or to the antenna control terminal in the vehicle To the steering wheel remote control adapter Light blue/yellow (Steering remote control wire) To the metallic body or chassis of the car Black (Ground wire) Yellow (Battery wire) Red (Ignition wire) Purple/Black Purple Green/Black Gray/Black White/Black White Gray Green Car fuse box Ignition switch To front speaker (left) To rear speaker (left) To front speaker (right) To rear speaker (right) Car fuse box Blue/White (Power control wire/ Antenna control wire) (12 V 350 mA) Fuse (10 A) Antenna terminal IMPORTANT We recommend installing the unit with a commercially available custom wiring harness specific for your car and leave this job to professionals for your safety. Consult your car audio dealer. Installation/Connection Battery If no connections are made, do not let the wire come out from the tab. JS_KWD_DPX794BH_KN_EN.indd 38JS_KWD_DPX794BH_KN_EN.indd 38 8/8/2019 1:59:57 PM8/8/2019 1:59:57 PMENGLISH

When connecting an external amplifier to the output terminals of this unit, securely connect the amplifier ground wire to the car chassis to prevent damage to the unit. (For

When connecting an external amplifier to the output terminals of this unit, securely connect the amplifier ground wire to the car chassis to prevent damage to the unit.

Do not touch the recording surface of the disc.

Do not stick tape etc. on the disc, or use a disc with tape stuck on it.

Do not use any accessories for the disc.

Clean from the center of the disc and move outward.

Clean the disc with a dry silicone or soft cloth. Do not use any solvents.

When removing a disc from this unit, pull it out horizontally.

Remove burrs from the center hole and disc edge before inserting a disc. More information For: – Latest firmware updates and latest compatible item list – KENWOOD original application – Any other latest information Visit <www.kenwood.com/cs/ce/>. General

This unit can only play the following CDs:

For detailed information and notes about the playable audio files, visit <www.kenwood.com/cs/ce/audiofile/>. Playable files

Playable USB device file system: FAT12, FAT16, FAT32 Even when audio files comply with the standards listed above, playback may be impossible depending on the types or conditions of media or devices. The AAC (.m4a) file in a CD encoded by iTunes cannot be played on this unit. Unplayable discs

Discs that are not round.

Discs with coloring on the recording surface or discs that are dirty.

Recordable/ReWritable discs that have not been finalized.

8 cm CD. Attempting to insert using an adapter may cause malfunction. About USB devices

You cannot connect a USB device via a USB hub.

Connecting a cable whose total length is longer than 5 m may result in abnormal playback.

This unit cannot recognize a USB device whose rating is other than 5 V and exceeds 1.5 A. About iPod/iPhone

Made for – iPod touch (6th generation) – iPhone 5S, 6, 6 Plus, 6S, 6S Plus, SE, 7, 7 Plus, 8, 8 Plus, X, XS, XS MAX, XR (iOS 12.1 or later)

It is not possible to browse video files on the “Videos” menu in [MODE OFF].

The song order displayed on the selection menu of this unit may differ from that of the iPod/ iPhone.

You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod.

Depending on the version of the operating system of the iPod/iPhone, some functions may not operate on this unit. JS_KWD_DPX794BH_KN_EN.indd 40JS_KWD_DPX794BH_KN_EN.indd 40 8/8/2019 1:59:57 PM8/8/2019 1:59:57 PMENGLISH

Pandora is only available in certain countries. For more information, visit <www.pandora.com/legal>.

Because Pandora is a third-party service, the specifications are subject to change without prior notice. Accordingly, compatibility may be impaired, or some or all of the services may become unavailable.

Some functions of Pandora cannot be operated from this unit.

For issues using the application, please contact Pandora at <pandora-support@pandora.com>. About Spotify

Spotify application supports: – iPhone 5S, 6, 6 Plus, 6S, 6S Plus, SE, 7, 7 Plus, 8, 8 Plus, X, XS, XS MAX, XR (iOS 12.1 or later) – iPod touch (6th generation) – Android OS 4.0.3 or above

Spotify is a third party service, therefore the specifications are subject to change without prior notice. Accordingly, compatibility may be impaired or some or all of the services may become unavailable.

Some functions of Spotify cannot be operated from this unit.

For issues using the application, please contact Spotify at <www.spotify.com>. About AMAZON ALEXA

Alexa is a third party service, therefore the specifications are subject to change without prior notice. Accordingly, compatibility may be impaired or some or all of the services may become unavailable. About Program Type For Radio Broadcast Data System: [SPEECH]: [NEWS], [INFORM] (information), [SPORTS], [TALK], [LANGUAGE], [REL TALK] (religious talk), [PERSNLTY] (personality), [PUBLIC], [COLLEGE], [HABL ESP] (spanish talk), [WEATHER] [MUSIC]: [ROCK], [CLS ROCK] (classic rock), [ADLT HIT] (adult hits), [SOFT RCK] (softrock), [TOP 40], [COUNTRY], [OLDIES], [SOFT], [NOSTALGA] (nostalgia), [JAZZ], [CLASSICL] (classical), [R & B] (rhythm and blues), [SOFT R&B] (soft rhythm and blues), [REL MUSC] (religious music), [MUSC ESP] (spanish music), [HIP HOP] For Radio Data System: [SPEECH]: [NEWS], [AFFAIRS], [INFO] (information), [SPORT], [EDUCATE], [DRAMA], [CULTURE], [SCIENCE], [VARIED], [WEATHER], [FINANCE], [CHILDREN], [SOCIAL], [RELIGION],

[PHONE IN], [TRAVEL], [LEISURE], [DOCUMENT]

[MUSIC]: [POP M] (music), [ROCK M] (music), [EASY M] (music), [LIGHT M] (music), [CLASSICS], [OTHER M] (music), [JAZZ], [COUNTRY], [NATION M] (music), [OLDIES], [FOLK M] (music) The unit will search for the Program Type categorized under [SPEECH] or [MUSIC] if selected. About HD Radio™ Technology

Adjacent to traditional main stations are extra local FM channels. These HD2/HD3 Channels provide new, original music as well as deep cuts into traditional genre.

Digital, CD-quality sound. HD Radio Technology enables local radio stations to broadcast a clean digital signal. AM sounds like today’s FM and FM sounds like a CD.

Program Info provides song name, artist, station ID, and other relevant data to enrich the listening experience.

Emergency Alert delivers critical and life-saving messages to the public during emergency situations. JS_KWD_DPX794BH_KN_EN.indd 41JS_KWD_DPX794BH_KN_EN.indd 41 8/8/2019 1:59:57 PM8/8/2019 1:59:57 PM42 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) References Change the display information Each time you press DISP, the display information changes.

If the information is unavailable or not recorded, “NO TEXT”, “NO INFO”, or other information (eg. station name) appears or display will be blank. Main display Supplementary display Clock time Source name Display information: Main display (supplementary) STANDBY Source name (Date) Turns off the display* back to the beginning HD RADIO (For

For digital stations only: Station name/Program type (Date) Song title (Artist) Song title (Album title) Song title (Date) Frequency (Date) back to the beginning For FM Radio Broadcast Data System stations only: Station name/Program type (Date) Radio text+ song title (Radio text+ artist) Radio text+ song title (Album title) Radio text+ title (Date) Frequency (Date) back to the beginning RADIO (For

Frequency (Date) Turns off the display* back to the beginning For FM Radio Broadcast Data System/FM Radio Data System stations only: Station name/Program type (Date) Radio text (Date) Radio text+ (Radio text+) Song title (Artist) Song title (Date) Frequency (Date) Turns off the display* back to the beginning Source name Display information: Main display (supplementary) CD / USB FRONT/ USB REAR/ USB For CD-DA: Track title (Artist) Track title (Disc title) Track title (Date) Playing time (Date) Turns off the display* back to the beginning For MP3/WMA/AAC/WAV/FLAC files: Song title (Artist) Song title (Album title) Song title (Date) File name (Folder name) File name (Date) Playing time (Date) Turns off the display* back to the beginning iPod FRONT/ iPod REAR/ iPod USB/iPod BT When [MODE OFF] is selected (page 12): Song title (Artist) Song title (Album title) Song title (Date) Playing time (Date) Turns off the display* back to the beginning PANDORA FRONT/ PANDORA REAR/ PANDORA/ PANDORA BT Station name (Date) Shared/Radio (Date) Song title (Artist) Song title (Album title) Song title (Date) Playing time (Date) back to the beginning SPOTIFY FRONT/ SPOTIFY REAR/ SPOTIFY/ SPOTIFY BT Context title (Date) Song title (Artist) Song title (Album title) Song title (Date) Playing Time (Date) Turns off the display* back to the beginning SIRIUS XM Channel number (Status) Channel name (Status) Artist (Status) Song title (Status) Content information (Status) Category name (Status) Date (Status) back to the beginning BT AUDIO/ ALEXA Song title (Artist) Song title (Album title) Song title (Date) Playing time (Date) Turns off the display* back to the beginning AUX Source name (Date) Turns off the display* back to the beginning

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Symptom Remedy General Sound cannot be heard. • Adjust the volume to the optimum level.

Check the cords and connections.

“MISWIRING CHECK WIRING

THEN PWR ON” appears. Turn the power off, then check to be sure the terminals of the speaker wires are insulated properly. Turn the power on again. “PROTECTING SEND SERVICE” appears. Send the unit to the nearest service center. Source cannot be selected. Check the [SOURCESELECT] setting. (Page 6) The unit does not work at all. Reset the unit. (Page 4) Correct characters are not displayed.

This unit can only display uppercase letters, numbers, and a limited number of symbols.

Depending on the display language you have selected (page 7), some characters may not be displayed correctly. (For

“ERROR”/”FAILED” Your steering remote controller is not compatible, learning may not be completed. Consult your car audio dealer for details. HD Radio Tuner/Radio

Radio reception is poor.

Static noise while listening to the radio. Connect the antenna firmly. CD/USB/iPod Disc cannot be ejected. Press and hold to forcibly eject the disc. Be careful not to drop the disc when it is ejected. If this does not solve the problem, reset the unit (page 4). Noise is generated. Skip to another track or change the disc. “PLEASE EJECT” appears. Reset the unit (page 4). If this does not solve the problem, consult your nearest service center. Troubleshooting Symptom Remedy CD/USB/iPod Playback order is not as intended. The playback order is determined by the order in which files were recorded (disc) or the file name (USB). Elapsed playing time is not correct. This depends on the recording process earlier (disc/USB). “READING” keeps flashing. • Do not use too many hierarchical levels and folders.

Reload the disc or reattach the device (USB/iPod/ iPhone). “UNSUPPORTED DEVICE” appears.

Check whether the connected USB device is compatible with this unit and ensure the file systems are in supported formats. (Page 40)

Reattach the USB device. “UNRESPONSIVE DEVICE” appears. Make sure the USB device is not malfunction and reattach the USB device.

SUPPORTED” appears. This unit cannot support a USB device connected via a USB hub.

The source does not change to “USB” when you connect a USB device while listening to another source.

“USB ERROR” appears. The USB port is drawing more power than the design limit. Turn the power off and unplug the USB device. Then, turn on the power and reattach the USB device. If this does not solve the problem, turn the power off and on (or reset the unit) before replacing with another USB device. The iPod/iPhone does not turn on or does not work.

Check the connection between this unit and iPod/iPhone.

Disconnect and reset the iPod/iPhone using hard reset. “LOADING” appears when you enter search mode by pressing

This unit is still preparing the iPod/iPhone music list. It may take some time to load, try again later. “NO DISC” Insert a playable disc into the loading slot. “TOC ERROR” Make sure the disc is clean and inserted properly. JS_KWD_DPX794BH_KN_EN.indd 43JS_KWD_DPX794BH_KN_EN.indd 43 8/8/2019 1:59:58 PM8/8/2019 1:59:58 PM44 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Symptom Remedy CD/USB/iPod “NA FILE” Make sure the media (disc/USB) contain supported audio files. (Page 40) “COPY PRO” A copy-protected file is played (disc/USB). “NO DEVICE” Connect a device (USB/iPod/iPhone), and change the source to USB/iPod FRONT/iPod REAR/iPod USB again. “NO MUSIC” Connect a device (USB/iPod/iPhone) that contains playable audio files. “iPod ERROR” • Reconnect the iPod.

Reset the iPod. “MEMORY FULL” You have reached the maximum storage limit of your iPod/iPhone. Pandora “ADD ERROR” New station creation is unsuccessful. “CHECK DEVICE” Check the Pandora application on your device. “NO SKIPS” The skip limit has been reached. “NO STATIONS” No stations are found. “STATION LIMIT” The number of registered stations has reached its limit. Retry after deleting unnecessary stations from your device. “UPGRADE APP” Make sure you have installed the latest version of the Pandora application on your device. “CONNECT ERROR” Communication is unstable. “RATING ERROR” Registration of thumbs up/thumbs down has failed due to insufficient network connectivity. “THUMBS N/A” Registration of thumbs up/thumbs down is not allowed. “LICENSE ERROR” You try to access from a country which Pandora is not deliverable. Symptom Remedy Spotify “DISCONNECTED” USB is disconnected from the head unit. Please make sure the device is connected properly through USB. “CONNECTING” • Connected via USB input terminal: The device is connecting to the head unit. Please wait.

Connected via Bluetooth: The Bluetooth is disconnected. Please check Bluetooth connection and make sure both the device and unit are paired and connected. “CHECK APP” The Spotify application is not connected properly or user is not login. End the Spotify application and restart. Then, log in to your Spotify account. SiriusXM® Radio “CH LOCKED LOCK CODE?” The selected channel is locked. Enter the correct pass code to unlock. (Page 19) “CHAN UNSUB” The selected channel is unsubscribed. Call 1-866-635-2349 in the U.S.A. or 1-877-438-9677 in Canada to subscribe. (Page 17) “CH UNAVAIL” The selected channel is unavailable. For more information about the SiriusXM channel lineup, visit <www.siriusxm.com>. “CHECK ANTENNA” Check that the antenna and its connection are in good condition. “CHECK TUNER” Make sure the SiriusXM Vehicle Tuner is connected to the unit. “NO SIGNAL” Make sure the antenna is mounted outside the vehicle. “SUBSCRIPTION UPDATED –

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Troubleshooting Symptom Remedy SiriusXM® Radio “CODE ERROR” Make sure you have entered the correct pass code. (Page 19) “NO CONTENT” There is insufficient content to start TuneScan. “SCAN CANCEL” TuneScan has been aborted. Bluetooth® No Bluetooth device is detected.

Search from the Bluetooth device again.

Reset the unit. (Page 4) Bluetooth pairing cannot be made.

Make sure you have entered the same PIN code to both the unit and Bluetooth device.

Delete pairing information from both the unit and the Bluetooth device, then perform pairing again. (Page 22) Echo or noise is heard during a phone conversation.

Adjust the microphone unit’s position. (Page 22)

Check the [ECHO CANCEL] setting. (Page 24) Phone sound quality is poor. • Reduce the distance between the unit and the Bluetooth device.

Move the car to a place where you can get a better signal reception. Voice calling method is not successful.

Use voice calling method in a more quiet environment.

Reduce the distance from the microphone when you speak the name.

Make sure the same voice as the registered voice tag is used. Sound is being interrupted or skipped during playback of a Bluetooth audio player.

Reduce the distance between the unit and the Bluetooth audio player.

Turn off, then turn on the unit and try to connect again.

Other Bluetooth devices might be trying to connect to the unit. Symptom Remedy Bluetooth® The connected Bluetooth audio player cannot be controlled.

Check whether the connected Bluetooth audio player supports Audio/Video Remote Control Profile (AVRCP). (Refer to the instructions of your audio player.)

Disconnect and connect the Bluetooth player again. “NOT SUPPORT” The connected phone does not support Voice Recognition feature or phonebook transfer. “NO ENTRY”/“NO PAIR” There is no registered device connected/found via Bluetooth. “ERROR” Try the operation again. If “ERROR” appears again, check if the device supports the function you have tried. “NO INFO”/“NO DATA” Bluetooth device cannot get the contact information.

“BT ERROR” Reset the unit and try the operation again. If this does not solve the problem, consult your nearest service center. “SWITCHING NG” The connected phones might not support phone switching feature. The Bluetooth connection between the Bluetooth device and the unit is unstable. Delete the unused registered Bluetooth device from the unit. (Page 26) JS_KWD_DPX794BH_KN_EN.indd 45JS_KWD_DPX794BH_KN_EN.indd 45 8/8/2019 1:59:58 PM8/8/2019 1:59:58 PM46 ENGLISH Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Specifications Tuner

FM Frequency Range 87.9 MHz — 107.9 MHz (200 kHz step) Usable Sensitivity (S/N = 30 dB)

7.2 dBf (0.63 μV/75 Ω)

Quieting Sensitivity (DIN S/N = 46 dB)

Frequency Range 530 kHz — 1 700 kHz (10 kHz step) Frequency Response (±3 dB) 40 Hz — 15 kHz Signal-to-Noise Ratio (STEREO) 70 dB Troubleshooting Symptom Remedy AMAZON ALEXA No response from Alexa after the voice input. Amazon cloud was unable to analyze the voice input. Wrong response from Alexa. Alexa misunderstood what was said or did not catch the entire request or sentence spoken. Please try again. (Page 28) “DISCONNECTED” Be sure to connect your smartphone to the unit via Bluetooth. (Page 22) Not able to connect or reconnect to Alexa mobile application.

Be sure the audio device is connected via Bluetooth. Select the audio device from [AUDIO SELECT] in [BTMODE]. (Page 26)

Perform the one-time setup process again. See “Setup for the first time” on page 28.

Turn off, then turn on the unit and try to connect again.

For iOS device, make sure ALEXA source or iPod BT source is selected. JS_KWD_DPX794BH_KN_EN.indd 46JS_KWD_DPX794BH_KN_EN.indd 46 8/8/2019 1:59:58 PM8/8/2019 1:59:58 PMENGLISH

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) Specifications CD player (except for ) Laser Diode GaAIAs Digital Filter (D/A) 8 times over sampling Spindle Speed 500 rpm — 200 rpm (CLV) Wow & Flutter Below measurable limit Frequency Response (±1 dB) 20 Hz — 20 kHz Total Harmonic Distortion (1 kHz) 0.01 % Signal-to-Noise Ratio (1 kHz)

92 dB Channel Separation

90 dB MP3 Decode Compliant with MPEG-1/2 Audio Layer-3 WMA Decode Compliant with Windows Media Audio AAC Decode AAC-LC “.aac” files

Tuner FM Frequency Range

87.9 MHz — 107.9 MHz (200 kHz step)

87.5 MHz — 108.0 MHz (50 kHz step)

Usable Sensitivity (S/N = 30 dB)

8.2 dBf (0.71 μV/75 Ω)

Quieting Sensitivity (DIN S/N = 46 dB)

2 500 mV/10 kΩ Preout Impedance ≤ 600 Ω Specifications USB USB Standard USB 1.1, USB 2.0 (High speed) File System FAT12/16/32 Maximum Supply Current DC 5 V

Data Size: B6L (182 mm x 128 mm) Book Size: B6L (182 mm x 128 mm) General Operating Voltage 12 V DC car battery Installation Size (W × H × D)

(includes Trimplate, Mounting Sleeve)

“DPX504BT”/“DPX304MBT”

[SUBWOOFER LPF] [SWLPFFRQ]

Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

HD Radio Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. For patents see http://dts.com/patents. HD Radio™ and the HD, HD Radio, and “ARC” logos are registered trademarks or trademarks of iBiquity Digital Corporation in the United States and/or other countries.

Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with an Apple product may affect wireless performance.

Apple, iPhone, iPod, iPod touch, iTunes, and Lightning are trademarks of Apple Inc., registered in the U.S. and other countries.

IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.

Android is a trademark of Google LLC.

SPOTIFY and the Spotify logo are among the registered trademarks of Spotify AB.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by JVCKENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners.

Amazon Alexa is not available in all languages and countries.

Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. JS_KWD_DPX794BH_KN_C00b.indd 2JS_KWD_DPX794BH_KN_C00b.indd 2 4/23/2021 2:53:50 PM4/23/2021 2:53:50 PM
