Insulated DETK300GBBS04 - Kettle Dash - Free user manual and instructions

Product type	Electric kettle
Brand	Dash
Model	Insulated DETK300GBBS04
Maximum capacity	1.7 L
Minimum recommended capacity	0.5 L
Rated power	1500 W
Supply voltage	220 - 240 V ~
Frequency	50 - 60 Hz
Body material	Double-wall insulated stainless steel
Automatic shut-off function	Yes
Dry boil protection	Yes
Rotating base	Yes, 360°
Power indicator	Light indicator
Removable anti-scale filter	Yes
Lid opening	Push-button
Power cord length	0.7 m (approx.)
Dimensions (L x W x H)	20 x 15 x 25 cm (approx.)
Net weight	1.2 kg (approx.)
Cleaning	Wipe the exterior with a damp cloth; descale regularly
Spare parts / Repairability	Contact customer service for parts; do not disassemble yourself
Warranty	1 year (depending on retailer)

Frequently Asked Questions - Insulated DETK300GBBS04 Dash

How to clean the kettle?

Unplug and let cool. Wipe the exterior with a soft, damp cloth. For the interior, use a water-vinegar mixture or descaling agent, then rinse thoroughly. Never immerse the base or kettle in water.

Can I heat anything other than water?

No, use only water. Other liquids can damage the interior coating.

What is the minimum water capacity?

Never operate the kettle with less than 0.5 L of water to avoid overheating.

Does the kettle shut off automatically?

Yes, it has automatic shut-off after boiling and dry boil protection.

How to descale the kettle?

Fill halfway with a mixture of water and white vinegar (1:1), bring to a boil, let sit for 15 minutes, empty and rinse. Repeat if necessary.

Is it safe to open the lid while boiling?

No, do not open it while the water is heating: hot steam can cause burns. Wait until it has completely stopped.

What is the power of the kettle?

The power is approximately 1500 W (check the appliance label).

Can I use an extension cord?

Yes, if necessary, use an extension cord with a power rating at least equal to that of the appliance (1500 W). Place it to avoid tripping hazards.

Is the kettle insulated?

Yes, the Insulated model has a double wall that keeps water hot longer and the exterior cooler to the touch.

Where to find spare parts?

Contact StoreBound at [phone] or by email at [e-mail]. Do not disassemble the appliance yourself.

USER MANUAL Insulated DETK300GBBS04 Dash

DASH® recipe ideas inside! #DETK300

DETK300

INSULATED

ELECTRIC KETTLE

Instruction Manual | Recipe Ideas

Simple line drawing of a coffee cup, a steaming cup with a plug, and a mug (no text or symbols)

INSULATED

ELECTRIC KETTLE

Important Safeguards 4-7

Parts & Features 8

Safety Features 9

Setting Up Your Insulated Electric Kettle 10

Using Your Insulated Electric Kettle.... 11-13

Cleaning & Maintenance 14

Recipe Ideas 16-17

Customer Support 18

Warranty 19

IMPORTANT SAFEGUARDS

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

When using electrical appliances, basic safety precautions should be followed, including:

• Read all instructions.
• Remove all bags and packaging from appliance before use.
• Wash and dry Kettle before using for the first time.
• Only use water inside the Electric Kettle. Other pre-made beverages may damage the interior coating.
• Make sure that the Kettle, Power Base and cord are completely dry before each use.
• Prior to first-time use, boil water in the Kettle and then pour it out. This will help to eliminate any odors.
• For maintenance other than cleaning, please contact StoreBound directly at 1-800-898-6970 from 7AM - 7PM PT Monday - Friday or by email at [e-mail].
  • To prevent the risk of fire, electric shock, or personal injury, do not place the cord, plug, or unit near water or other liquids.
• WARNING: To avoid electric shock, do not overfill Kettle. Water level should never go above the Max 1.7L marker.
• Never immerse the Power Base or Kettle

in water or any other liquid; instead, wipe the surface with a soft, damp cloth, and properly clean inside of Kettle (see Cleaning & Maintenance instructions on page 14).
- Never leave appliance unattended when in use.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge unless they are provided with supervision and instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Always be sure to unplug the appliance from outlet prior to assembly, disassembly, cleaning, and storage.
- Allow Kettle to cool completely before cleaning or storing.
- Do not operate any appliance with a damaged cord or plug.
- Do not use the appliance if any of the parts are damaged.
• Refrain from using attachments that are

not recommended by the appliance manufacturer, as this may result in fire, electric shock, or personal injury.

• Do not use appliance outdoors or for commercial purposes.
• Do not let the cord touch hot surfaces or hang over the edge of tables or counters.
• Extension cords are not recommended for use with this appliance.
• If an extension cord must be used, make sure the electrical rating of the wire is compatible with the Kettle.
• Do not place appliance on or near a hot gas burner, hot electric burner, or in a heated oven.
• When disposing of the Kettle, do not

discard with general household waste; instead, drop off at a designated electronic waste recycling facility.

• StoreBound shall not accept liability for damages caused by improper use of the appliance.
• Improper use of the Kettle can result in property damage or even in personal injury.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not completely fit in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

IMPORTANT SAFEGUARDS

MESURES DE SÉCURITÉ IMPORTANTES: VEUILLEZ LIRE ATTENTIVEMENT CE MANUEL AVANT D'UTILISER L'APPAREIL.

Lid Release Button Pour Lever Lid Pour Spout Cool-Touch Housing Handle Power Base Boil / Cancel Button Temp (+) Button Keep Warm Button Temp (-) Button Digital Display and Temperature

.8

Hand holding a black electronic device with a circular button and cable, enclosed in a red circle (no text or symbols visible)

Cord Storage

Wrap the cord around the Cord Storage under the Base so the Insulated Electric Kettle stores without additional cord clutter.

Close-up of a black appliance with a circular outline and a red label pointing to it, no visible text or symbols.

Boil-Dry Safety Protection

The Kettle will shut off automatically in approximately 20 seconds when there is little to no water inside.

Black glass coffee pitcher with handle, enclosed in a red circular border (no text or symbols visible)

Cool-Touch Housing

Because of the Dual-Wall Insulation, the Insulated Electric Kettle stays cool even when the water inside is heated to boiling.

9.

SETTING UP YOUR INSULATED ELECTRIC KETTLE

USING YOUR INSULATED ELECTRIC KETTLE

Clean your Insulated Electric Kettle thoroughly before using. Always unplug the appliance prior to cleaning or storing.

WARNING: The Insulated Electric Kettle and its Power Base are NOT dishwasher safe.

BEFORE FIRST USE

Remove all packaging and stickers before using your Insulated Electric Kettle.

Using a dish brush, wash the inside of the Kettle with warm, soapy water and then rinse thoroughly.

To sterilize the Kettle, fill with water to the MAX line and place on the Base. Press the Boil/Cancel Button and wait until the water is boiling. Once water is boiling, discard water and allow the Kettle to cool.

ATTENTION: Do NOT use abrasive scrubbers, sponges, or chemical cleaners on the interior or exterior of the Kettle as they will damage the finish.

The bottom of the Insulated Electric Kettle functions as a wrap for cord storage. Unwind the cord for greater flexibility.

SWITCHING BETWEEN "C AND "F

To switch between °C and °F, simply hold down both the Temp (+) and Temp (-) Buttons simultaneously until you see the symbol change on the Digital Display.

Close-up of a hand pressing down on a black plastic container (no text or symbols visible)

Hand pouring water into a black kettle (no text or symbols visible)

PREPARING THE KETTLE

To add water to the Insulated Electric Kettle, pinch the Lid Release Buttons on the Lid and lift (photo A). Fill with water to MAX line (photo B). Do not overfill. Replace the Lid to close,

Place the Kettle on the Power Base and plug the Power Base in.

WARNING: Do not add liquid other than water to the Insulated Electric Kettle as this may damage the interior.

USING YOUR INSULATED ELECTRIC KETTLE

USING YOUR INSULATED ELECTRIC KETTLE

DASH C 7.1¢

DASH D 12°C + - + - + -

BOILING

To boil water, Press the Boil/Cancel button to turn the Kettle on (photo C). This will cause the Kettle to begin to heat to boiling, or 212°F.

HEATING

To heat to a temperature other than boiling, once the Insulated Electric Kettle is plugged in simply press the Temp (+) and Temp (-) Buttons until your desired temperature is shown on the Digital Display (photo D), then do not press any further buttons to confirm. The kettle will automatically build to the desired temperature you selected. "Heat" will be shown on the Digital Display.

CHANGING THE TEMPERATURE

You can also use the Temp (+) and Temp (-) Buttons to change the temperature once heating has begun. When not changing the temperature, the Digital Display will show the internal temperature of the water as it is heating.

Close-up of a hand pressing a black digital kitchen brush with a 'Dash' button (no text or symbols on the brush itself)

Hand pouring liquid from a black kettle into a glass jar with a straw (no text or symbols visible)

KEEP WARM

Once heating is complete, you can press the Keep Warm button to help the Insulated Electric Kettle maintain internal temperature (photo E). Due to the Dual Wall stainless steel insulation, the Insulated Electric Kettle will retain heat for up to 8 hours, even when not using the Keep Warm function.

SERVING

To serve, remove the Insulated Electric Kettle from the Power Base and press down on the Pour Lever on top of the handle as you are pouring to open the Pour Spout (photo F).

The Insulated Electric Kettle will automatically shut off once desired temperature is reached if Keep Warm is not selected. Alternatively, you can simply unplug the base to make sure the Insulated Electric Kettle is off.

CLEANING & MAINTENANCE

IMPORTANT NOTE:

Do not submerge the Power Base or Insulated Electric Kettle in water or other liquids. To avoid damaging the appliance, never use abrasive or harsh cleaning products to clean the Kettle's surface.

Be careful when cleaning the Insulated Electric Kettle, as even if the outside is cool; the contents within may still be hot, even if the kettle is no longer on.

In order to keep your Insulated Electric Kettle in pristine working order, follow the cleaning recommendations periodically.

1. Fill the Kettle with water up to the 1L mark. Place on the Power Base and press the Power Button to turn on.
2. After the water comes to a boil, remove from the Power Base. Pour in a small amount of dish soap and soak overnight or for 8-12 hours.
3. Pour out the soapy water and rinse until no suds remain.
4. Fill the Kettle with 1L of clean water and bring to a boil. Carefully pour out the hot water.
5. Allow your Kettle to cool and then thoroughly dry with a soft cloth.

NOTE: Make sure that the Kettle, Power Base and cord are completely dry before and after each use. After using the kettle for a long period of time, you may notice residue from hard water accumulate on the bottom interior of the Kettle. To remove, let soak with water and vinegar, then wipe down.

Black and white photo of a modern kitchen keeler with chocolate and glassware on a table, no visible text or symbols.

HOT IDEAS

Get creative with these suggestions for delicious treats to make with your Insulated Electric Kettle. Just heat water and then add to your dish!

French Press Coffee Miso Soup Ramen

Bouillon Soup Hot Tea

Udon

Couscous Oatmeal Hot Chocolate

CUSTOMER SUPPORT CUSTOMER SUPPORT

WARRANTYWAR

Dash values quality and workmanship and stands behind this product with our Feel Good Guarantee™. To learn more about our commitment to quality, visit bydash.com/feelgood.

Our US-based customer support team is at your service

Monday - Friday during the times below.

Reach us at 1 [phone] or [e-mail]

7am- 7pm 8am- 8pm 9am- 9pm 10am- 10pm

Hey Hawaii! You can reach our customer service team from 5AM to 5PM.
And also, Alaska, feel free to reach out from 6AM - 6PM.

STOREBOUND, LLC - 1 YEAR LIMITED WARRANTY

Your StoreBound product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase when utilized for normal and intended household use. Should any defect covered by the terms of the limited warranty be discovered within one (1) year, StoreBound, LLC will repair or replace the defective part. To process a warranty claim, contact Customer Support at 1-800-898-6970 for further assistance and instruction. A Customer Support agent will assist you by troubleshooting minor problems. If troubleshooting fails to fix the problem, a return authorization will be issued. Proof of purchase indicating the date and place of purchase is required and should accompany the return. You must also include your full name, shipping address, and telephone number. We are unable to ship returns to a PO box. StoreBound will not be responsible for delays or unprocessed claims resulting from a purchaser's failure to provide any or all of the necessary information. Freight costs must be prepaid by the purchaser.

Send all inquiries to [e-mail].

There are no express warranties except as listed above.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CUSTOMER. STOREBOUND SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE LAW. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts. Therefore, the above exclusions or limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.

REPAIRS

DANGER! Risk of electric shock! The Insulated Electric Kettle is an electrical appliance.

Do not attempt to repair the appliance yourself under any circumstances.

Contact Customer Support regarding repairs to the appliance.

TECHNICAL SPECIFICATIONS

Model: DETK300

Voltage: 120V - 60Hz

Power Rating:1500 W

Stock#: DETK300_20200214_V4

DASH®
