USER MANUAL GR 2275 FRITEL

Attentively read the user manual before using the appliance!

Keep the manual carefully.

GEBRAUCHSANWEISUNG

Description appliance

1. Non-skid feet
2. Slider
3. Removable baking plates
4. Thermostat
5. Drip trays
6. Fat outlet
7. Push button to remove baking plates
8. Red and green pilot lamp
9. Cool touch handle

Congratulations! You have just bought a high quality appliance, which will guarantee you years of pleasure. Please read the instruction manual carefully before you take the appliance into use. Save these instructions carefully!

All persons who have not read the instruction manual are not allowed to use this appliance.

Pay ATTENTION to the warranty conditions.

1. SAFETY PRESCRIPTIONS

This appliance has been built in accordance with the European CE safety standards and is compliant with the general recognized standards and prescriptions with regard to the safety of appliances. As for all electrical appliances, the necessary precautions need to be taken in order to avoid accidents or damages.

• Attention! Buming danger! When using this appliance, certain surfaces will get hot. Only touch the handle or the thermostat button while the appliance is in use.
• Attention! Even after switching off the appliance, some surfaces will remain hot for some time, causing the risk of bums. ALWAYS let the appliance cool off entirely before moving, cleaning or storing it.
• This appliance may be used by children of min. 8 years old, by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge they are supervised and instructed to use the appliance in a safe way and under the hazards involved. Children may not play with the appliance. Cleaning and maintenance shall not be made by children unless they are older than 8 years supervised. Keep the appliance and its cord out of reach of children less than 8 years.
• The appliance is only intended for household use and similar applications, excluding: staff kitchens in shops, offices and other work environments; farms; clients motels and other residential environments; bed & breakfast environments.
• NEVER touch the control button, electrical power cord and plug with wet hands.
• NEVER immerse the appliance, the power cord or the plug in water or any liquid. They are only to be cleaned with a damp cloth. In case the appliance does get wet or moist, immediately disconnect the plug from the power socket.
• A damaged power cord can cause electric shocks. NEVER use the appliance if it is damaged, fallen or shows a malfunction, or if the power cord or plug are da
• In all these cases return the appliance to your sales point or recognized after sales service.

• NEVER use separate timers or remote control systems.

• ALWAYS place the appliance on a solid and flat base, such as a kitchen counter or table, so that the appliance will not move or turn over.

• After use remove the plug from the power point. Also proceed this way when the appliance is not in use, before cleaning and moving.
• NEVER use the appliance outdoor.
• NEVER use extension cords or sockets. Place the appliance near a power point and connect it directly. ALWAYS completely unroll the power cord.
• NEVER let the cord hang over the edge of the table or the counter.
  NEVER place the power supply cord near heat sources such as cookers,加热器 or ovens.
• Only use the appliance on the mains voltage as indicated on the identification label.
• This appliance is only suited for indoor household use, and not for professional use.
• Only use the appliance for grill purposes.
• The appliance may not be used for other purposes or with other appliances!
• Only use the original accessories.
• The appliance may only be used if both baking plates have been placed correctly.

2.DESCRIPTION PARTS

A. Thermostat + pilot lamps (Fig. A)

The appliance is equipped with a continuously adjustable thermostat, red and green pilot lamp (8). The red pilot lamp (8) lights up when the appliance is plugged in and the green pilot lamp (8) lights up when the chosen temperature is reached.

B. Slider

By means of the slider (2) you can put the appliance in the chosen position

• Positions 'LOW' to 'HIGH'(4 positions) (Fig. B): Adjust the height of the upper plate according to the thickness of the food to be grilled

• Position 'OPEN' (Fig. C): In this position the upper cover will remain open vertically (hands free)

• Position '180°' (Fig. D): For use of the appliance as a BBQ, pull the slider (2) towards you while opening the appliance completely.

• Position 'LOCK (Fig. E): Lock the appliance so that it can easily be moved or to store it vertically (space saving)

C. Removable baking plates (Fig. F)

By pressing the push buttons (7) you can remove the baking plates (3) from the appliance for an easy cleaning.

D. Drip tray (Fig. G)

The cooking fat and juices released during the grilling are collected in the drip trays(5) through the outlet (6) on the baking plate= healthy and fatfree!

3. BEFORE THE FIRST USE

• Check if the mains voltage of your appliance (230 Volt) corresponds with the mains voltage in your home.
• Remove all packagings and stickers.
• Remove the plates (3) from the appliance by means of the push buttons (7). Clean the plates (3) as described under 'Cleaning' before the first use.

• Put the plates (3) back into the appliance.

• The appliance is now ready for use.

• ATTENTION : While warming up the appliance, it must ALWAYS be in closed position.
• ATTENTION: Upon the first use, there might be a slight odour or smoke output. This is normal.

4. START TO GRILL

• Completely unroll the power cord, and plug in the appliance in a 230 V socket.
• The red pilot lamp (8) lights up when you plug in the appliance. NEVER plug in the appliance when the plates (3) are removed.
• Then turn the thermostat (4) onto the chosen position.
• ATTENTION: the appliance will now get hot. Only touch the thermostat (4) and the handles.
• The green pilot lamp (8) will light up as soon as the chosen temperature has been reached.
• You can now add the toast, panini, steak, ... ATTENTION: do not use frozen food!
• Place the drip tray (5) in front of the fat outlet (6) on the baking plate.
• Do not use sharp utensils to (re)move the food as they could damage the non-stick coating of the plates.
• Close the appliance after use, lock it by means of the slider (2) (LOCK position) and pull out the plug.
• Let the appliance cool off for at least 30 minutes before moving it, removing the baking plates (3) or cleaning it.

5. CLEANING

• Pull the plug from the socket.
• Let the appliance cool off entirely before removing the plates (3) by means of the push button (7).
• The baking plates (3) are dishwasher proof. However, we recommend to clean them in warm soapy water for a longer life. Make sure NEVER to use stiff washing-up brushes, only a soft cloth!
• The base and the housing of the appliance can be cleaned with a damp cloth. NEVER immerse these parts in water or in any other liquid.

6. USEFUL TIPS IN CASE OF MALFUNCTIONS

Do not use the appliance in case of a malfunction. First go through the following:

The appliance doesn't warm or the control lamps don't light up:

• Check if your appliance is connected to the right mains voltage, whether there is mains voltage, and if the appliance was plugged in correctly.
  If there is still a malfunction, please return the appliance to your sales point.
  If the power cord is damaged, don't use your appliance and return it to your sales point immediately.

THE APPLIANCE HAS BEEN DESIGNED FOR DOMESTIC USE. THE WARRANTY CONDITIONS EXPIRE UPON PROFESSIONAL USE.

DEFECTS AND/OR DAMAGES FOLLOWING TO THE NON OBSERVANCE OF THE USER MANUAL ARE NOT COVERED BY THE WARRANTY.

7. WARRANTY CONDITIONS

Your warranty starts on the day of purchase and is valid for 2 years.

The user is responsible for cleaning and proper packaging of the defective appliance before presenting it for repair. It is insufficient to wrap the device in cardboard packaging with paper. Fritel is not liable for damage resulting from insufficient packaging, which also irrevocably invalidates the warranty.

Determination of the warranty:

• The warranty covers every repair and/or replacement free of charge of the parts recognized defective by our technical department and if the damage is due to faulty manufacture, construction or material. The knives are not covered by the guarantee, as they are subject to wear and tear.
• The warranty is only valid for the first/original user.
• The transport costs, in case of reparation, are at the expenses of the purchaser.
• The warranty is only granted after presentation of your purchase invoice.
• The warranty cannot be invoked for normal wear and tear.

The warranty expires in the following cases:

• Incorrect connection, e.g. electric voltages.
• Abnormal or professional use or misuse handling.
• In case of insufficient packaging and bad transport in case of return shipping.
• Lack of care and cleaning.
• Modifications or repairs made to the appliance by persons not authorized by us as a manufacturer.
• When reference numbers have been altered or been removed.
• For faults not due to the appliance itself, but to an external cause, collision, damage, fire, earthquake, flood, lightning, etc.
• When not respecting the instructions in the user instructions.

For appliances that are not under warranty for any of the above reasons, all costs (transport, administration, research, handling) will be charged.

8. ENVIRONMENT

Do not throw the appliance away with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this you will help to preserve the environment.

9. LIABILITIES

All liabilities, towards both consumer(s) and third parties, that could result from not observing all the safety regulations prescribed in this user manual, can under no circumstances be charged to the manufacturer. In case of non-observance of these safety regulations, the user of the appliance, or any other person not having observed these safety regulations, protects the manufacturer from all responsibilities that he could be charged with.

10. ACCESSORIES, SPARE PARTS AND OTHER FRITEL PRODUCTS

Visit our webshop on www.fritel.com and discover our FAQ's, available spare parts and accessories, as well as all other products in the FRITEL range for even more FRITEL fun!
