USER MANUAL RT46K6000WW SAMSUNG

Refrigerator User manual Free Standing Appliance Untitled-1 1 2018-07-18 8:14:49English2 Contents Contents Safety information 3 Important safety symbols and precautions: 5 Severe warning signs for transportation and site 5 Critical installation warnings 6 Installation cautions 10 Critical usage warnings 10 Usage cautions 15 Cleaning cautions 18 Critical disposal warnings 20 Additional tips for proper usage 21 Saving Energy Tips 22 This appliance is intended to be used in household and similar applications such as 23 Instructions about the WEEE 23 Installation 24 Refrigerator at a glance 24 Step-by-step installation 27 Operations 31 Feature panel 31 Special features 39 Maintenance 45 Handle and care 45 Cleaning 46 Replacement 46 Troubleshooting 47 General 47 Untitled-1 2 2018-07-18 8:14:49English 3 Safety information

• Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efciently.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or those who lack experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

• Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your appliance.

• Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or nd help and information online at www.samsung.com. Safety information Untitled-1 3 2018-07-18 8:14:49Safety information English4 Safety information

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. When this product contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used.

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m³ in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identication plate inside the appliance.

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked ames and move anything ammable away from the product and ventilate the room immediately. - Failing to do so may result in re or explosion.

• It is hazardous for anyone other than an Authorised Service Person to service this appliance. Warning; Risk of re / ammable materials Untitled-1 4 2018-07-18 8:14:49English 5 Safety information Important safety symbols and precautions: WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference. Severe warning signs for transportation and site WARNING

• When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the room in which the appliance is standing for several minutes. Untitled-1 5 2018-07-18 8:14:49Safety information English6 Safety information - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. Critical installation warnings WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a re hazard from overheated wires.

• If the wall socket is loose, do not insert the power plug. - There is a risk of electric shock of re.

• Do not use a power cord that has cracks or abrasion damage along its length or at either end. Untitled-1 6 2018-07-18 8:14:49English 7 Safety information

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or re.

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, re, and/ or electric shock.

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• Do not install this appliance near a heater or inammable material.

• Do not install this appliance in a location where gas may leak. - This may result in an electric shock or re.

• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a re or electric shock. Untitled-1 7 2018-07-18 8:14:49Safety information English8 Safety information

• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.

• Keep the packing materials out of reach of children. - There is a risk of death from suffocation if a child puts the packing materials on his or her head.

• The appliance must be positioned so that the plug is accessible after installation. - Failing to do so may result in an electric shock or re due to electric leakage.

• Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). - Deteriorated insulation of electrical parts may cause an electric shock or re.

• If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product in.

• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip. Keep the snap rings and water tube clips out of children’s reach. Untitled-1 8 2018-07-18 8:14:49English 9 Safety information

• The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - This may result in an electric shock, re, explosion, or problems with the product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re.

• If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents.

• The fuse on the refrigerator must be changed by a qualied technician or service company. - Failing to do so may result in an electric shock or personal injury.

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Untitled-1 9 2018-07-18 8:14:49Safety information English10 Safety information Installation cautions CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface. - Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions.

• Allow the appliance to stand for 2 hours before loading foods after installation and turning on.

• We strongly recommend you have a qualied technician or service company install the refrigerator. - Failing to do so may result in an electric shock, re, explosion, problems with the product, or injury.

• Overload on any one door may fell the refrigerator, causing physical injury. Critical usage warnings WARNING

• Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock.

• Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage.

• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator. - This may result in an electric shock or injury. Untitled-1 10 2018-07-18 8:14:49English 11 Safety information - Any sharp edges may cause a personal injury.

• Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. - This may cause frostbite.

• Do not put a container lled with water on the refrigerator. - If spilled, there is a risk of re or electric shock.

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator. - This refrigerator is for storing food only. - This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance. - Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury.

• Do not store pharmaceutical products, scientic materials, or temperature sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator. Untitled-1 11 2018-07-18 8:14:49Safety information English12 Safety information

• Do not place or use electrical appliance inside the refrigerator/freezer, unless they are of a type recommended by the manufacturer.

• If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center.

• If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not let children step on a drawer. - The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator.

• Do not allow babies or children go inside the drawer. - It can cause death from suffocation by entrapment or personal injury.

• Do not overll the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, re, or problems with the product.

• Do not use or place any substances sensitive to temperature such as ammable sprays, ammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator. Untitled-1 12 2018-07-18 8:14:49English 13 Safety information

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours. - This may result in an electric shock or re.

• Fill the water tank, ice tray and water cubes only with potable water (mineral water or puried water). - Do not ll the tank with tea, juice or sports drink, this may damage the refrigerator.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, re, problems with the product, or injury. Do not put a container lled with water on the appliance. - If spilled, there is a risk of re or electric shock.

• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Never stare directly at the UV LED lamp for long periods of time. - This may result in eye strain due to the ultraviolet rays.

• Do not put fridge shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop.

• Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area. Untitled-1 13 2018-07-18 8:14:49Safety information English14 Safety information

• If a gas leak is detected, avoid any naked ames or potential sources of ignition, and air the room in which the appliance is standing for several minutes. - Do not touch the appliance or power cord. - Do not use a ventilating fan. - A spark may result in explosion or re.

• Use only the LED Lamps provided by the manufacturer or its service agents.

• Bottles should be stored tightly together so that they do not fall out.

• This product is intended only for the storage of food in a domestic environment.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself. - Unauthorized modications can cause safety problems. To reverse an unauthorized modication, we will charge the full cost of parts and labor.

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.

• If your refrigerator needs to be repaired or reinstalled, contact your nearest service center. - Failing to do so may result in an electric shock, re, problems with the product, or injury.

• If the interior or exterior LED lamp has gone out, contact your nearest service center.

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or re hazards. Untitled-1 14 2018-07-18 8:14:49English 15 Safety information

• Pull the power plug out of the socket before changing the interior lamps of the refrigerator. - Otherwise, there is a risk of electric shock.

• If you experience difculty changing a non-LED light, contact a Samsung service center.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center.

• Plug the power plug into the wall socket rmly.

• Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in an electric shock or re. Usage cautions CAUTION

• Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or zzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury.

• Use only the ice maker provided with the refrigerator.

• To get the best performance from the product: - Do not place food too close to the vents at the rear of the refrigerator as this can obstruct free air circulation in the refrigerator compartment. - Wrap food up properly or place it in airtight containers before putting it into the refrigerator. Untitled-1 15 2018-07-18 8:14:49Safety information English16 Safety information - Do not place glass bottles or carbonated beverages into the freezer. They can freeze and break. Broken beverage containers can cause injury. - Please observe maximum storage times and expiration dates of frozen goods.

• Do not place glass or bottles or carbonated beverages into the freezer. - The container may freeze and break, and this may result in injury.

• Do not place carbonated or zzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury and property damage.

• Service Warranty and Modication. - Any changes or modications performed by a 3rd party on this nished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modications.

• Do not block the air vents inside the refrigerator. - If the air vents are blocked, especially with a plastic bag, the refrigerator can be over cooled. If a cooling period lasts too long, the water lter may break and cause water leakage.

• Use only the ice-maker provided with the refrigerator.

• Wipe excess moisture from the inside and leave the doors open. - Otherwise, odor and mold may develop. Untitled-1 16 2018-07-18 8:14:49English 17 Safety information

• If the refrigerator is disconnected from the power supply, you should wait for at least ve minutes before plugging it back in.

• When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center.

• Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea or a sports drink. This may damage the refrigerator.

• Be careful that your ngers are not caught in.

• The lamps in the freezer and refrigerator can be turned off if the doors of the freezer and refrigerator are left open for 2 seconds or longer. - The lamps will turn back on when the doors are closed and opened again.

• If the refrigerator is ooded, make sure to contact your nearest service center. - There is a risk of electric shock or re. Untitled-1 17 2018-07-18 8:14:50Safety information English18 Safety information

• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difcult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc. Cleaning cautions CAUTION

• Do not spray water directly on the inside or outside the refrigerator. - There is a risk of re or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Do not spray cleaning products directly on the display. - Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest service center. - Failing to do so may result in an electric shock or re. Untitled-1 18 2018-07-18 8:14:50English 19 Safety information

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of re or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox, Chloride for cleaning. - They may damage the surface of the appliance and may cause a re.

• Never put ngers or other objects into the dispenser hole. - It may cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failing to do so may result in an electric shock or re.

• Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator.

• Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, ammable uids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping. Untitled-1 19 2018-07-18 8:14:50Safety information English20 Safety information Critical disposal warnings WARNING

• Please dispose of the packaging material from this product in an environmentally friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. If this refrigerator contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• When disposing of this refrigerator, remove the door/ door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. If trapped inside, a child may get hurt or suffocate to death. - If trapped inside, the child may become injury and suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a bag over his or her head, the child could suffocate. Untitled-1 20 2018-07-18 8:14:50English 21 Safety information Additional tips for proper usage

• In the event of a power failure, call the local ofce of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. - Should the power failure last more than 24 hours, remove and discard all frozen food.

• The refrigerator might not operate consistently (frozen contents can thaw or temperatures can become too warm in the frozen food compartment) if sited for an extended period of time in a location where ambient air temperatures are constantly below the temperatures for which the appliance is designed.

• In case of particular foods, keeping it under refrigeration can have a bad effect on preservation due to its properties.

• Your appliance is frost free, which means there is no need to manually defrost your appliance. This will be carried out automatically.

• Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper.

• Do not re-freeze frozen foods that have thawed completely. Untitled-1 21 2018-07-18 8:14:50Safety information English22 Safety information

• The temperature of two star section (sections) or compartment (compartments) which have two star symbol ( ) is slightly higher than other freezer compartment (compartments). The two star section (sections) or compartment (compartments) is (are) based on the instruction and/or the condition as delivered. Saving Energy Tips

• Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example).

• Not to block any vents and grilles is recommended for energy efciency.

• Allow warm food to cool down before placing it in the appliance.

• Put frozen food in the refrigerator to thaw. You can then use the low temperatures of the frozen products to cool food in the refrigerator.

• Do not keep the door of the refrigerator open for too long when putting food in or taking food out. The shorter the time the door is open, the less frost build-up you’ll have in the freezer.

• It is recommended to install the refrigerator with clearance to the back and sides. This will help reduce power consumption and keep your energy bills lower. Untitled-1 22 2018-07-18 8:14:50English 23 Safety information

• For the most efcient use of energy, please keep the all inner ttings such as baskets, drawers, shelves on the position supplied by manufacturer. This appliance is intended to be used in household and similar applications such as

• staff kitchen areas in shops, ofces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications. Instructions about the WEEE Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government ofce, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Untitled-1 23 2018-07-18 8:14:50English24 Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING

• Use the refrigerator only for its intended purpose as described in this manual.

• Any servicing must be performed by a qualied technician.

• Dispose of the product packaging material in compliance with the local regulations. Refrigerator at a glance NOTE The actual image and provided component parts of the refrigerator may differ, depending on the model and the country.

• applicable models only Installation Untitled-1 24 2018-07-18 8:14:50English 25 Installation Optional accessories * Spacer: This helps keep the refrigerator cool. Cool pack: This helps keep the refrigerator cool. Ice tray: Used to make ice. Twist Ice Maker: Used to make ice.

• Your refrigerator may not include optional accessories listed above. Provision of optional accessories depends on the model and the country. To secure more room for storage in the freezer compartment Remove one or more optional accessories such as cool pack(s), shelf or shelves, twist ice maker(s), ice storage bins and their supports, all of which can be removed manually without a tool.

• These optional accessories do not affect thermal and mechanical performance.

• A declared storage volume of the freezer is based on the nonexistence of those optional accessories.

• To remove both ice makers, remove the right-handed one rst (applicable to Ice Max models).

• For best energy efciency, make sure all of shelves, drawers, and baskets are placed in their original position. Untitled-1 25 2018-07-18 8:14:51Installation English26 Installation Load limit indicator (applicable models only) The refrigerator has a load limit indicator on the top right side of the freezer compartment. CAUTION

• Do not put or keep food items over the load limit indicator. Otherwise, energy efciency may be affected. Untitled-1 26 2018-07-18 8:14:51English 27 Installation Step-by-step installation STEP 1 Select a site Site requirements:

• Solid, level surface without carpeting or ooring that may obstruct ventilation

• Away from direct sunlight

• Adequate room for opening and closing the door

• Away from a heat source

• Room for maintenance and servicing

• Temperature range: between 10 °C and 43 °C Effective temperature range The refrigerator is designed to operate normally in the temperature range specied by its class rating. Class Symbol Ambient Temperature range (°C) IEC 62552 (ISO 15502) ISO 8561 Extended Temperate SN +10 to +32 +10 to +32 Temperate N +16 to +32 +16 to +32 Subtropical ST +16 to +38 +18 to +38 Tropical T +16 to +43 +18 to +43 NOTE The cooling performance and power consumption of the refrigerator may be affected by the ambient temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the temperature settings as appropriate. Untitled-1 27 2018-07-18 8:14:51Installation English28 Installation Clearance See the pictures and table below for space requirements for installation.

Untitled-1 28 2018-07-18 8:14:51English 29 Installation STEP 2 Spacing (applicable models only)

1. Open the door and locate the provided

2. Unpack both spacers and attach them

to the rear of the refrigerator as shown. They help ventilate air to the rear wall and save power consumption. STEP 3 Flooring

• The surface to install the refrigerator must support a fully loaded refrigerator, or approximately 90 kg.

• To protect the oor, put a large piece of cardboard on each leg of the refrigerator.

• Once the refrigerator is in its nal position, do not move it unless necessary to protect the oor. If you have to, use a thick paper or cloth such as old carpets along the movement path. Untitled-1 29 2018-07-18 8:14:52Installation English30 Installation STEP 4 Adjust the levelling feet Level the refrigerator by manually adjusting the levelling feet. Turn the levelling feet clockwise to lower the position, or turn counter clockwise to raise. For safety reasons, adjust the front side a little higher than the rear side.

Leave the feet at 66 mm (A) from the oor as shown. STEP 5 Initial settings By completing the following steps, the refrigerator should be fully functioning.

1. Plug the power cord into the wall socket to turn the refrigerator on.

2. Open the door, and check if the interior light lights up.

3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be

slightly chilled, and the motor will run smoothly.

4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready

for use. STEP 6 Final check When installation is complete, conrm that:

• The refrigerator is plugged into an electrical outlet and grounded properly.

• The refrigerator is installed on a at, level surface with a reasonable clearance from the wall or the cabinet.

• The refrigerator is level and is sitting rmly on the oor.

• The door opens and closes freely, and the interior light turns on automatically when you open the door. Untitled-1 30 2018-07-18 8:14:52English 31 Operations Feature panel Button type

01 Freezer (Power Freeze) 02 Freezer Convert / Ice On/Off (applicable models only) 03 Fridge (Power Cool) Operations Untitled-1 31 2018-07-18 8:14:52Operations English32 Operations 01 Freezer (Power Freeze) Freezer The Freezer button can be used to set the freezer temperature between -15 °C and -23 °C. Each time you press the button, the temperature changes in this sequence: -23 °C -15 °C -17 °C -19 °C -21 °C -23 °C CAUTION

• To prevent system failure or food spoiling, do not set the temperature to -15 °C in summer (above 35 °C).

• Do not store glass bottles containing liquid in the freezer. Glass bottles will crack or break into pieces when the liquid freezes. Power Freeze Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for several hours and then returns to the previous temperature.

• To activate Power Freeze, press and hold Freezer for 3 seconds. The corresponding indicator ( ) lights up, and the refrigerator will speed up the cooling process for you.

• To deactivate, press and hold Freezer again for 3 seconds. The freezer returns to the previous temperature setting.

• To freeze large amounts of food, activate Power Freeze for at least 20 hours before putting food in the freezer.

• The freezer keeps running at full speed for 50 hours and then returns to the previous temperature. NOTE Using Power Freeze increases power consumption. Make sure you turn it off and return to the previous temperature if you do not intend to use it. Untitled-1 32 2018-07-18 8:14:52English 33 Operations 02 Freezer Convert / Ice On/Off (applicable models only) Freezer Convert You can use the entire refrigerator with Fridge mode, or turn off the freezer. To change the default freezer mode, press and hold Freezer Convert for 3 seconds to enter the selection mode. Then, press Freezer Convert to select a desired mode. The mode changes in this sequence: Fridge Off Freezer Off Fridge setting mode.

• If you select Fridge, the fridge indicator turns on. Power Freeze will be deactivated if active, and Ice On will turn off if enabled.

• If you select Off, the Off indicator turns on. The freezer will be turned off.

• If you select the freezer setting mode, the freezer temperature indicators turn on for your selection. Your changes will be set and activated after 10 seconds. To cancel or change the mode again, press and hold Freezer Convert again for 3 seconds. Then, follow the instructions as mentioned above. NOTE

• If you press and hold Freezer Convert for 3 seconds in Freezer mode, the refrigerator switches to Fridge mode and you can select a mode (selection mode).

• If you press and hold Freezer Convert for 3 seconds in other modes, the refrigerator switches to selection mode where you can press Freezer Convert to select a different mode.

• When refrigeration or freezing functions are at 'Off mode', the temperature of the fridge or freezer remains under 15 °C to prevent mold and odors, using low electricity.

• Fridge or Freezer cannot be powered off independently.

• Do not store food or beverage in refrigerator when refrigeration or freezing functions are at 'Off mode'. 15 °C is not cool enough to prevent spoilage. WARNING

• Do not put glass bottles containing liquid in the freezer. When cancelling Freezer Convert, the glass bottles may break or burst in the freezer.

• Make sure to remove frozen foods from the freezer before enabling the Freezer Convert. Frozen foods melt and spoil as the temperature increases (Freezer mode changes to Fridge mode).

• Make sure to remove chilled foods from the freezer before disabling the Freezer Convert. Chilled foods may freeze as the temperature decreases (Fridge mode changes to Freezer mode). NOTE If you want to use Freezer Convert, it is strongly recommend to use plastic containers to store food, especially vegetables. Untitled-1 33 2018-07-18 8:14:52Operations English34 Operations Ice On/Off (Applicable models only) By default, the refrigerator is set to make ice with the corresponding indicator off. To disable this function, press Ice On/Off to turn it off. We recommend disabling the function in the following cases:

• The ice bucket is already full of ice.

• You want to save power consumption.

• The water tank is empty. NOTE If you press Freezer Convert to select Fridge or Off, the refrigerator enters Ice Off mode. 03 Fridge (Power Cool) Fridge To adjust the fridge temperature, press Fridge to select the corresponding temperature. You can change the temperature between 1 °C and 7 °C. With the temperature set to 1 °C, press Fridge to turn the vacation indicator on. The temperature bar turns off. Press again to deactivate Vacation mode. The temperature bar displays 7 °C. CAUTION

• In winter, do not set the temperature control to 1 °C. This may cause problems with the cooling performance.

• In summer, do not set the temperature control to 5-7 °C. This may also cause problems with the cooling performance. Power Cool Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for several hours and then returns to the previous temperature.

• To activate Power Cool, press and hold Fridge for 3 seconds. The corresponding indicator ( ) lights up, and the refrigerator will speed up the cooling process for you.

• To deactivate Power Cool, press and hold Fridge again for 3 seconds. The fridge returns to the previous temperature setting.

• To cool large amounts of food completely, make sure you have activated Power Cool at least 24 hours in advance. NOTE Using Power Cool increases power consumption. Make sure you turn it off and return to the previous temperature if you don’t intend to use it. Untitled-1 34 2018-07-18 8:14:53English 35 Operations Vacation If you are going on vacation or a business trip, or if you do not intend to use the fridge for an extended time, use the Vacation mode.

• To activate Vacation mode, press Fridge with the 1 °C indicator selected. The vacation indicator ( ) turns on while the display of the fridge temperatures will turn off. The fridge temperature will be controlled under 17 °C, but the freezer remains active as previously set.

• To deactivate Vacation mode, press Fridge again. NOTE It is strongly recommended to empty the fridge compartment and make sure the door is closed. Untitled-1 35 2018-07-18 8:14:53Operations English36 Operations Dial type Fridge To ensure optimal performance, we recommend setting the temperature to Optimal or . TYPE A

• To decrease the temperature for strong cooling, set the temperature control to level 4-5.

• To increase the temperature for weak cooling, set the temperature control to level 1-2. TYPE B CAUTION

• In winter, do not set the temperature control to level 4-5. This may cause problems with the cooling performance.

• In summer, do not set the temperature control to level 1-2. This may also cause problems with the cooling performance. Untitled-1 36 2018-07-18 8:14:53English 37 Operations Vacation If you are going on vacation or a business trip, or if you do not intend to use the fridge for an extended time, use the Vacation mode. TYPE A To activate Vacation mode, turn the fridge dial to select Vacation or (vacation level). The fridge temperature will be controlled under 17 °C, but the freezer remains active as previously set. The Vacation mode will be deactivated automatically if you adjust the fridge temperature. TYPE B NOTE It is strongly recommended to empty the fridge compartment and make sure the door is closed. Untitled-1 37 2018-07-18 8:14:53Operations English38 Operations Freezer TYPE A

• To decrease the temperature for strong cooling, set the temperature control to level 4-5.

• To increase the temperature for weak cooling, set the temperature control to level 1-2. TYPE B CAUTION

• In winter, do not set the temperature control to level 4-5. This may cause problems with the cooling performance.

• In summer, do not set the temperature control to level 1-2. This may also cause problems with the cooling performance. Fridge (Convertible) You use the freezer as Fridge mode. To enable Fridge mode for the freezer, turn the Freezer Temp. Control dial to a Fridge (Convertible) or level. Once setup is complete, the temperature of the freezer is controlled to about 3 °C. NOTE It is strongly recommended to empty the fridge compartment and make sure the door is closed. Untitled-1 38 2018-07-18 8:14:54English 39 Operations Special features The actual image and special functions of your refrigerator may differ, depending on the model and the country. Ice making (applicable models only) Twist ice maker

1. Open the freezer door, and slide open

2. Fill the tray with water up to the

maximum level (A) marked on the inner rear of the tray.

3. Slide the tray back into position.

NOTE The ice making time depends on your temperature settings. NOTE

• Make sure the ice cube storage bin is in place under the ice tray.

• To dispense the ice cubes, turn the handle of the bin to the right to empty half of the ice cubes into the bin. Then, turn it to the left to empty the other half.

• Take out the bin by slightly twisting and pulling to the front. Tray type

To make ice cubes, ll the tray with water up to the maximum level (A) marked on the inner rear of the tray. Untitled-1 39 2018-07-18 8:14:54Operations English40 Operations To empty the ice tray, hold both ends of the tray and gently twist to remove the ice cubes. Water dispenser (applicable models only) With the water dispenser, you can dispense chilled water without opening the fridge door. NOTE If you keep pushing the dispenser lever for about 1 minute, the dispenser will stop operating for performance issues. To dispense more water, wait a few seconds and try again. To ll the water tank For rst-time use, clean the inner side of the water tank and dry well.

1. Hold both handgrips on the front of the

tank, and slide out as shown. A B

2. Open the front lid (A) of the cover or the

entire cover (B) and ll the tank with a max of 5 L water. CAUTION Do not exceed the max line. Water overows.

3. Reinsert the water tank and t into the

dispenser mechanism. Make sure the front side (with the front lid) of the tank faces to the front. Untitled-1 40 2018-07-18 8:14:55English 41 Operations CAUTION

• Make sure the water tank ts into the shelf. Otherwise, the water tank may not operate properly.

• Do not use the refrigerator without inserting the water tank. This may decrease the cooling performance.

• Fill the tank only with potable water such as mineral or puried water. Do not use other liquid.

• Use caution when moving a lled tank. Physical injury may occur if the tank is dropped.

• Do not try to disassemble the internal pump yourself. If the internal pump is damaged or disconnected from the water tank, the dispenser does not operate. For rst-time use

• Push the dispenser lever for 10 seconds to emit air from the hoses of the water supply system.

• Discard the rst six glasses of water to remove impurities in the water supply system. To dispense water Put a glass under the water outlet, and gently push against the dispenser lever with the glass. CAUTION

• Make sure the glass is in line with the dispenser to prevent the dispensed water from spilling out.

• If you do not use the water dispenser for 2-3 days, the dispensed water may have an abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of water. Untitled-1 41 2018-07-18 8:14:55Operations English42 Operations Auto ice maker (applicable models only) For rst-time use

• Let the ice maker make ice for 1-2 days.

• Discard the rst 1-2 buckets of ice to remove impurities in the water supply system.

• When the upper ice tray is full, use the lower ice tray. Test button

If the auto ice maker does not make ice, remove the ice bucket and press Test (A) to check if the auto ice maker operates properly. Untitled-1 42 2018-07-18 8:14:55English 43 Operations Water dispenser With the water dispenser, you can dispense water without opening the fridge door. The water tank must be lled with potable water before use. To ll the water tank with potable water Open the door and locate the water tank that is located in the door shelf area.

1. Hold the handgrips on both sides of the

water tank and lift up to remove.

2. Fill the water tank with potable water

up to 2.3 liters. You can remove either the top cap or the cover and pour water. NOTE For rst-time use, clean inside the water tank.

3. Reinsert the water tank and close the

door. Make sure the water outlet of the water tank faces forward. Untitled-1 43 2018-07-18 8:14:56Operations English44 Operations

4. Put a water glass under the water outlet

of the dispenser, and gently push the dispenser lever to dispense water. Make sure the water dispenser is unlocked. CAUTION

• The water dispenser is designed to dispense potable water. Fill the water tank only with potable water. Do not ll with any other liquids.

• Do not ll the water tank excessively, which causes an overow.

• Do not try to ll the water tank without removing it from the door.

• Make sure that water tank is seated properly.

• Do not use the refrigerator without the water tank. This may reduce performance and efciency.

• To prevent water bouncing, make sure the glass is in line with the dispenser lever. NOTE To secure more room, you can use the water tank to store food. In this case, remove the lid of the tank. Untitled-1 44 2018-07-18 8:14:56English 45 Maintenance Handle and care Ice tray provided models First remove the ice tray, and then lift up the freezer shelf to remove. Freezer and fridge shelves

• To remove a shelf, rst open the door completely. Pull the shelf forward, lift up, and then pull out.

• When reinserting the shelf, make sure the “Front” label of the shelf faces forward.

• Do not attempt to tilt the shelf into position. Door bins Slightly lift up and pull out the door bin. CAUTION To prevent accidents, empty the door bins before removing. Maintenance Untitled-1 45 2018-07-18 8:14:56Maintenance English46 Maintenance Cleaning Regularly use a dry cloth to remove all foreign substances such as dust or water from the power plug terminals and contact points.

1. Unplug the power cord of the refrigerator.

2. Use a moistened soft lint-free cloth or paper towel to clean the refrigerator’s interior

3. When done, use a dry cloth or paper towel to dry well.

4. Plug in the power cord of the refrigerator to turn the refrigerator on.

NOTE If you have removed any removable parts such as shelves for cleaning, refer to the overall layout in the What’s included section to make sure you have reinserted correctly. WARNING

• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a re.

• Do not spray water onto the refrigerator. This may cause electric shock.

• Do not put ngers or other objects into the dispenser hole. Replacement Deodorizer lter (applicable models only)

While holding the top and bottom sides of the lter case, unlock the lter case to reveal the deodorizer lter (A). Replace the lter, and then reinsert the case. Lamps The lamps are not user-serviceable. To replace the lamps of the refrigerator, contact a local Samsung service centre. Untitled-1 46 2018-07-18 8:14:56English 47 Troubleshooting If you encounter an abnormal situation with the refrigerator, rst check the table below and try the suggestions. General Symptom Action Does not operate or cool.

• Make sure the power cord is connected properly.

• Make sure the temperature control is set correctly.

• Make sure to keep the refrigerator away from direct sunlight or a heat source. Failing to do so may affect the cooling performance.

• Make sure the refrigerator has enough room from the rear and side walls or the cabinet. Failing to do so may affect the cooling performance.

• Too much food may block the ventilation of the refrigerator. To keep the refrigerator in normal operation, do not put too much food inside. Food in the fridge freezes.

• Check if the temperature control is set to the lowest temperature. If so, change the temperature to higher or optimal or .

• This happens if the ambient temperature is too low. Set the temperature higher.

• Check if food containing a high portion of water is put in the coldest area of the fridge or near the cooling vent. If this happens, move the food to other shelves in the fridge. Emits noises.

• Make sure the refrigerator is installed on a stable, at surface.

• Make sure the refrigerator has enough room from the rear and side walls or the cabinet.

• Make sure to keep the refrigerator from impurities or foreign objects inside or underneath.

• The refrigerator may produce a ticking sound from inside, which occurs when the various removable parts contract or expand. This is not a system failure. The front corners and sides become warm and form condensation.

• To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. This is not a system failure.

• Condensation may form on the exterior surface of the refrigerator if humid air comes into contact with the cool surface of the refrigerator. Troubleshooting Untitled-1 47 2018-07-18 8:14:56Troubleshooting English48 Troubleshooting Symptom Action The ice maker does not make ice.

• You must wait for 12 hours until the refrigerator makes ice.

• Make sure the ice maker is not stopped while making ice.

• Make sure the freezer is set below 0 °C (or -5 °C in warm ambient air).

• Make sure the water tank is lled with water. The water dispenser is not functioning.

• Check if the water tank is frozen. If so, select a higher fridge temperature.

• Make sure the water tank is lled with water.

• Make sure the water tank is installed properly.

• Make sure the water lter is installed properly. Produces a bubbling sound.

• The refrigerator makes this sound during the cooling process, which is normal. A bad smell comes from inside the refrigerator.

• Check for any spoiled food. We recommend cleaning the refrigerator on a regular basis and remove any spoiled or suspect food items.

• Make sure strong smelling food is wrapped up airtight. Frost forms on the interior walls.

• Make sure no food blocks the vents of the refrigerator. It is also important to arrange food items evenly for ventilation.

• Make sure the door is closed properly. Condensation forms on the interior walls or around vegetables.

• This happens when food containing a high portion of water is stored uncovered, or the door has been left open for a while.
