USER MANUAL AV1200WIFI MILL

Assembly and instruction manual Series: PTC Fan Heater

This product is only suitable for well insulated spaces or occasional use.

Dit product is alleen geschikt voor goed geïsoleerde ruimtes ofincidenteel gebruik. Ce produit est seulement approprié aux espaces bien isolés ouà l'utilisation occasionnelle. Dieses Produkt ist nur für gut isolierte Räume oder gelegentlichenGebrauch geeignet. Ta izdelek je primerensamo za dobro izolirane prostore aliobčasno uporabo. See toode sobib kasutamiseks ainult hästi soojustatud ruumidesvõi lühiajaliseks kütmiseks. Please read the instructions carefully before use. Take good care of this manual for later use.

Šis produkts ir piemērots tikai labi izolētām telpām vai nepatstāvigailietošanai. Šis gaminys tinkamas naudoti tik gerai izoliuotose vietose arnorint naudoti retkarčiais.Thanks for buying Mill Our company was founded in Norway in 1992 by Cato Bryn, specializing in distribution sell to many of the largest retailers in the Nordic countries. In 2010, Cato’s son, Phillip joined the company. Philip looked at the heating industry with fresh new eyes and wondered why there had been so little change with the appearance of portable heaters in the last 20 years, especially since interior design in general had changed dramatically over the years. Philip thought consumers should have more styles to choose from other than the typical old-fashioned, traditional heaters. Since heaters are part of so many homes, Philip and Cato decided to use their extensive knowledge to re-invent the design of heaters. They wanted to create beautiful, modern and minimalistic heaters, using the most advanced technology, that would complement people’s homes. They launched the brand “Mill” in 2012. to complement our line of products to meet consumers’ demand. Prospering on our success in the Nordics we decided to promote Mill at some of the world’s largest electronic fairs and home shows in 2015 and 2016 - the feedback from retailers and distributors all over the world were amazing. We are proud to say that consumers in over 25 countries can now keep warm with style! Follow us on social media: @millheat millheat.com post@millheat.com @P. 7 P. 7 P. 7 MaintenanceWarrantyWaste disposal

Please read the instructions carefully before use. Take good care of this manual for later use. IN ORDER TO AVOID OVERHEATING, DO NOT COVER THE HEATER.

CASING WITH WET HANDS!2

You must obey common safety guidelines when using electrical products, especially in the presence of children. WARNING! To avoid electric shock or damage due to the heat, always make sure the plug is pulled out before the heater is moved or cleaned.

READ THE INSTRUCTIONS CAREFULLY

• The product is intended for home use only.

• Make sure the heater is connected to the house's regular mains as indicated on the heater.

• Check for any pieces of packing foam or cardboard that may have fallen into the heating elements of the heater. These pieces must be removed to avoid unpleasant odors.

• Prevent the heater from overheating – do not cover.

long period of time.

• Pay special attention if the heater is used in rooms where children, the handicapped or elderly reside.

• The heater should not be set up directly beneath an electrical socket outlet.

• The cord must not be laid under any kind of carpet. Make sure the cord is laid in such a way that nobody can trip on it.

• The heater must not be used if either the cord or plug is damaged.

is damaged in any other way causing it to malfunction.

• The cord must be repaired by the manufacturer or by an expert if it has been damaged, to avoid dangerous situations.

• Avoid using extension cords, which may overheat and could

by making sure the air intakes are not blocked or covered. The

• The heater should not be installed in close proximity to Important safety information3 millheat.com

ATTENTION! This heater is only meant to be used as a supplementary heating source, and must not be used without supervision

• The heater must never be used in rooms where gasoline, paint or

• Never touch an electric heater with wet hands. The heater should be installed so a person showering or taking a bath cannot come into direct contact with it.

• Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

heater must cool down before it is moved.

• Avoid overloading the mains (the circuit) where the heater is connected. The heater may overload the electrical circuit if other electrical devices are plugged into the same socket outlet.

• Do not use this heater in small rooms when they are occupied by persons not capable to leaving the room on their own, unless constant supervision is provided.

• The product cannot be used by children under 8 years of age and persons with reduced physical or mental abilities or lack of experience and knowledge unless they have been given supervision or instruction in the safe use of the product and understand the hazards involved.

• Children should not play with the product. Cleaning and maintenance should not be done by unsupervised children.

• Children under the age of 3 should be kept away from the product, unless they are under constant supervision.

• Children aged 3 to 8 years are only permitted to turn the product ON/OFF, assuming the heater is mounted according to the assembly instructions and the children have received instruction or supervision in the safe use of the product and understand the hazards involved.

• Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.Specifications

First use Description of heater transport. Contact the retailer or importer if you discover any visible damages to the product. Keep the outer packaging to transport the heater in the future. If you want to dispose the packaging, make sure it is done properly. Keep plastic bags away from children. d period without use, the heater can produce a burnt odor for a short time. This is normal. Please read all the instructions carefully before use. Save the instruction manual for future use. With aluminium foot Without aluminium foot Model Thermostat Color Amperage Aluminium foot Power (W) CUS1800MECWA Mechanical Mechanical Mechanical Mechanical Mechanical Mechanical White CUS1800MECBA Black CUS1800MECGA Silver White Black Silver CUS1800MECW CUS1800MECB CUS1800MECG

See figure 2 on separate illustration sheet Parts for models with aluminium foot

• 8 screws (4 pre-mounted)

• 2 rails for the feetSee figure 4 on separate illustration sheet See figure 3 on separate illustration sheet

1. Remove the pre-mounted screws on both legs before you insert them into the

brackets, so that you get a stable foot.

2. Attach the legs to the brackets by tightening 2 screws into each bracket. Do not tighten

completely in order to fit the foot into the square tracks of the heater.

3. Place the heater gently on its head and use the supplied screws to mount

4. Place the foot in the square tracks and fasten each foot bracket with two screws.

Wait to tighten the screws until all four screws have been fastened. You can now tighten the screws attaching the legs and brackets.

O: OFF Fan (only fan, no heating) I: 1200W II: 1800W WARNING! BE SURE THE FOOT IS FITTED CORRECTLY AND ACCORDING TO THE INSTRUCTIONS BEFORE USING THE HEATER! ATTENTION! This heater is only meant to be used as a supplementary heating source, and must not be used without supervision

1. Set the output selector to the OFF position (O) and the thermostat to minimum. Plug the heater

into a grounded outlet.

2. Set the output selector to position for fan only (no heating).

3. Set the output selector to position I or II. Turn the thermostat up to the maximum position.

When the desired room temperature has been reached, turn the thermostat slowely down until you hear a click. The thermostat can now remain in this position until a dierent room temperature is desired. As soon as the room temperature falls below this level, the heater will automatically switch on again. When the room has again reached the desired temperature, the heater will switch o again.

4. lf you wish to change the room temperature, repeat the instructions in step 3.

5. The heater has on overheat protection that turns the device o if any parts become

6. To switch the heater o, turn the output selector to the O position. lf the heater will be le

unused for a longer period of time, pull the plug. Usage6 Seasonal energy eciency

Information requirement for the electric local space heaters Model identifier(s): CUS1800MECWA, CUS1800MECW, CUS1800MECBA,

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

1. For cleaning, always unplug the heater and leave it to cool.

2. Wipe the heater regularly with a damp cloth and dry the surface before turning on

3. The heater must be cleaned at least once a month during the heating season.

CAUTION! The heater should never be immersed in water. Avoid using detergents to clean the heater. Never let any water get inside the heater; this can be hazardous.

5. The heater can be stored in a dry and clean place.

6. If the heater stops working, do not attempt to repair it yourself because it can

The warranty is valid for 2 years. The heater will be repaired or replaced during this time should any malfunction occur. The warranty applies if the heater is used according to these instructions and the customer can present a purchase receipt. If the heater malfunctions in any way, please contact the store where it was purchased or the importer. The symbol indicates that this product is not to be disposed of together with household waste. This product must be delivered to a recycling service or container for electrical appliances and electronic equipment. This is done to avoid health risks and prevent harm to the environment. Local businesses (or the environmental station in your neighborhood) are required by law to accept and recycle such products, as a means of environmentally sound disposal.OM OVERVERHITTING TE VOORKOMEN, DEK DE KACHEL NIET AF.

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor

Seasonal energy eciency Information requirement for the electric local space heatersNL

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency Information requirement for the electric local space heaters

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency

1. Remove the pre-mounted screws on both legs before you insert them into the brackets, so

that you get a stable foot.

2. Attach the legs to the brackets by tightening 2 screws into each bracket. Do not tighten

completely in order to fit the the foot into the square tacks of the heater.

3. Place the heater gently on its head and use the supplied screws to mount the feet.

4. Place the foot in the square tracks and fasten each foot bracket with two screws. Wait to

tighten the screws until all four screws have been fastened. You can now tighten the screws attaching the legs and brackets.

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency

Type of heat output/room temperature control (select one)

single stage heat output and no room temperature control

Two or more manual stages, no room temperature control Yes with mechanic thermostat room temperature control

with electronic room temperature control electronic room temperature control plus day timer

electronic room temperature control plus week timer room temperature control, with presence detection room temperature control, with open window detection Other control options (multiple selections possible) ηs 36 % Seasonal space heating energy eciency Minimum heat output (indicative) Pmin 0,0 kW No manual heat charge control with room and/or outdoor temperature feedback Maximum continuous heat output Pmax,c 1,8 kW

electronic heat charge control with room and/or outdoor tempe- rature feedback

fan assisted heat output with distance control option

with adaptive start control

with working time limitation

with black bulb sensor Seasonal energy eciency
