USER MANUAL SI2 Duronic

Si2 - Travel Steam Iron

PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

Contents

English Manual 5
Manuel d'utilisation en français 13
Gebrauchsanleitung auf Deutsch 21
Manual de Instrucciones en Espanol 29
Manuale D'istruzioni In Italiano 37
Instrukcja obslugi. Polski 45
Gebruikershandleiding Nederlands 53
Türkçé Kullanim Kilavuzu 61
69

English Manual

Features and Specifications

MODEL POWER	VOLTAGE	RATING	WATER TANK CAPACITY
Si2 375W	220-240V ~	50/60Hz	40ml to max line, 50ml to full

• Steam burst: activated by press button
  Water tank capacity: 35ml
  Temperature range: 65^ 230^ c

• Soleplate size: 7.3cm squared

• Power light indicator: red

• Self-standing design
  Size: L33 x W76 xH78 mm
  Weight: 495g
  Power cable length: 190cm

Components

1. Sole plate
2. Standing heels
3. Body
4. Power cable
5. Handle
6. Control dial

7. Water tank

8. Water inlet

9. Steam burst button
10. Power indicator light
11. Water filler jug
12. Brush attachment
13. Storage bag

Safety Instructions

PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE

• This appliance is for light or occasional indoor/household use only. This iron is not intended for professional laundry services.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be closely supervised at all times to ensure that they do not play with the appliance.

• Do not operate this appliance if the power cable or plug is damaged. If either is damaged return it to Duronic for service or repair by professional technician.

• Please ensure the mains power supply is 220 - 240 V 50/60Hz

• Never try to replace the parts or repair the appliance by yourself.

• To reduce the risk of electric shock, never operate this product with wet hands, spill liquid on the appliance or submerge it in water or any other liquid.

• Do not place the appliance on or near a hot gas or on a heated oven.

• Do not let the power cable hang over the edge of a table or counter or touch a hot surface.

• Pay close attention to the iron whilst in use. The iron must not be left unattended while it is connected to the mains socket.

• Ensure that the iron is switched off and unplugged from the electrical mains socket and fully cooled down before removing the brush attachment.

• Do not use any attachments which are not listed in this manual.

• Always hold the iron by the handle. Keep the hot soleplate away from body parts and heat sensitive objects.

DURONIC

• Do not turn the iron upside down; there may be hot water in the water tank.
• Do not leave water in the water tank when not in use - this can corrode and damage the soleplate.
  Water will drip out of the iron if the temperature dial is not set.
• Keep the appliance well away from surfaces and objects that can be damaged by heat.
• Ensure there is adequate space to operate the iron.
• When not ironing, do not leave the iron face down. Stand it upright on its heel, on a level heatproof surface.
• Use this iron only with a purpose-built ironing board.
• Observe all of the ironing instructions and ironing temperature dot settings given by the garment manufacturer. These guidelines are normally on the label/s inside the garment.
  Always ensure the water filling does not exceed the MAX mark.
  Always unplug the iron when refilling the water reservoir.
• Do not iron buttons or fasteners. This could damage the iron.
• During operation do not use when the light is on. When the light turns off, the iron has reached the correct temperature.
• Do not iron directly onto synthetic fabric - instead iron the fabric inside out or with the synthetic fabric covered by other material to protect it.

Ironing Temperatures

Garment Label Fabric Type Thermostat		Regulation
	Synthetic Low temperature
	Silk-wool Medium temperature
	Cotton-linen High temperature
	Fabric not to be ironed

How to Use

FILLING THE IRON

1. Make sure the iron is switched off and unplugged from the mains socket.
2. Fill the water jug with fresh water from the tap. If you live in a hard water area, it is advisable to use distilled water. Avoid using water containing softeners, perfumes or additives.
3. Open the water inlet cap on the top of the iron and slowly pour the water in from the jug.
4. Close the cap.

USING THE IRON

1. Plug the cable into the mains socket and switch on.
2. Check the label inside the garment to find out what heat setting you require for the fabric.
3. Turn the control dial to the temperature you require.
4. Stand the iron on its heel and wait for it to heat up. When it has reached the set temperature, the indicator light will go off.

DURONIC

1. Iron your garment/fabric as you normally would.
2. If the water level goes low and you haven't yet finished ironing, unplug the iron and refill it using the water jug provided. Then plug it back in and commence with ironing.
3. When you have finished ironing, turn the control dial to the MIN position. Unplug it from the mains socket.
4. Stand the iron on its heel and leave to cool down. Once cool, empty the water tank.
5. To store away, wrap the cable around the iron. Store away using the bag provided.

STEAM BURST FUNCTION

The steam burst function is mainly used for thick materials or fabrics with stubborn creases.

If you want to use the steam burst function, you will need to set the control dial to the MAX setting.

Press the steam burst button a few times before using the iron at each ironing session. This will clean the steam vents.

Place the iron onto the fabric and press the steam push button to release a powerful burst of steam. Wait a few seconds for the steam to penetrate the fabric before pressing the button again.

DURONIC

Ironing Tips

For heat sensitive fabric, cover the clothing with a piece of cotton fabric to avoid damage.

If you are unsure about how the iron will work on a particular fabric, start by using a low heat setting first.

Use an ironing board - using any other type of board might damage the clothing, the board or the iron.

If the iron is too hot, it might leave yellow traces on your clothing. If this happens, humidify the stains with oxidised water, then rinse and dry.

When ironing black or dark coloured clothing, turn them inside out first before ironing. This will avoid leaving trace marks on the fabric.

Cleaning & Maintenance

If you need to clean your iron, unplug it and allow it to cool completely.

Using a damp well-wrung cloth wipe the soleplate and other parts.

Then use a dry cloth to dry off any dampness.

DURONIC

Warranty

1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products. NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER

This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only

This product is fitted with CE:1363 plug and fuse. Imported by Shine-Mart Ltd, RM3 8SB

Information on waste Disposal for Consumers of

Electrical & Electronic Equipment.

This mark on a product and/or accompanying documents indicates that when it

is to be disposed of, it must be treated as Waste

Electrical & Electronic Equipment, (WEEE).

Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.

For proper treatment, recovery and recycling; please take all WEEE marked waste to your Local Authority Civic waste site.

where it will be accepted free of charge.

If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.
