USER MANUAL KA HD 4000 DC KALORIK

1. Non-slip-insert
2. Air intake grille
3. Off/Low/Hi switch
4. Hanging ring
5. Cord
6. Cool shot button
7. Air output
8. Air concentrator
9. Diffuser
10. 3 Heat settings

F

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register!

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The page must reproduced and folded in order to obtain a mini booklet B5 (+ / - 150mm width x 210mm height). The page must be folded in order to keep the good numbering when you turn the page of the I/B. Don't change the page numbering. Keep the languages integrity.

Please read these instructions carefully before using the appliance.

Check that your mains voltage corresponds to that stated on the appliance.

Never leave the appliance unsupervised when in use. Keep out of reach of children or incompetent persons.

From time to time check the cord for damages. Never use the appliance if cord or appliance show any signs of damage.

Only use the appliance for domestic purposes and in the way indicated in these instructions.

Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.

• Never use the appliance near hot surfaces.

Should the cord be damaged, it must be replaced by a competent qualified electrician

Before cleaning, always unplug the appliance from the power supply.

All repairs should be made by a competent qualified electrician (^*)

Never use the appliance outside and always place it in a dry environment.

To ensure a major security, it is recommended to set up a current flight jump 30mA in the electric circuit which supplies the bathroom.

• Never use accessories which are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.

Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.

Never use the appliance in bath, shower or above a sink filled with water! However, should the appliance happen to fall into the water:

• immediately unplug it
• do not put your hands into the water
• make sure your appliance is verified by a competent qualified electrician (°) before using it again.

When using the hairdryer in the bathroom, always unplug it when not in use as the proximity of water could constitute a danger even when the hairdryer is switched off.
Always make sure your appliance is not wet (water splashes, ...) and never handle it with wet hands.
Unplug the appliance when not in use or even if you put it down only for a moment.
- Inevitably the air intake grille becomes hot when using the appliance. Make sure the cord does not come into contact with the air intake grille when using the appliance.
The air intake and outgoing openings must never be blocked. However should the air ventilation get blocked, the safety device will stop the appliance immediately. The latter will restart when it has cooled down. You will have to wait a couple of minutes.
The safety grille in the air intake opening prevents the hairs from being sucked in. If you notice after some time that the grille gets blocked by dust, you have to clean it. If you don't clean it, the air flux will progressively decrease and the appliance might get damaged.
Make sure the hair does not come into direct contact with the air intake opening.
If your appliance can function with 2 voltages (visible by a small 2 position switch graded to the 2 most frequent voltages), you have to verify that the tension switch is set to the position that corresponds with the voltage of your region). Otherwise the appliance might suffer serious damages which will not be covered by the guarantee.

Fax [phone]

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register! Copies of the I/B. Please reproduce them without any chan except under special instruction from Team International BELGIUM. The page must reproduced and folded in order obtain a mini booklet B5 (+/- 150 mm width x 210 mm hei The page must be folded in order to keep the good numberi when you turn the page of the I/B . Don't change the page numbering. Keep the languages integrity.

Competent qualified electrician : after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

UK STYLE PLUG WIRING INSTRUCTIONS (IN THE UK ONLY)

This product must only be used from a 13 amp power socket. If a BS1363 approved 13 amp plug is used, it should be fitted with a 13 amp fuse. The wires on the power cord are colour coded: bluc = neutral, brown = live, green or green & yellow = earth. The blue wire must be connected to the terminal marked N or coloured in black. The brown wire must be connected to the terminal marked L or coloured in red. The green (& yellow) wire must be connected to the terminal marked E or coloured in green (& yellow).

SPECIAL ATTENTION

Your new appliance is designed with a protective coating around the heating coils. When plugged in and operating for the first time, there may be a little momentary smoking while this coating is initially heated. This presents no danger to the user and does not indicate a defect in the unit. When using for the first time, allow the appliance to continue running until the smoke dissipates. This should last only about 30 seconds.

HOW TO USE YOUR STYLING DRYER

AIR CONCENTRATOR : The air concentrator attaches easily onto the barrel of your dryer and allows you to direct the airflow on a small section of hair at a time as you style and shape hair with a vent brush or comb. You can also build body and fullness into fine, thin hair by directing the airflow against the natural growth of the hair.

DIFFUSER : The finger diffuser attachment snaps onto the air chamber of the unit to give you precise styling control whole you lift and shape the hair as it dries. It's ideal for drying or finishing naturally curly or permed hair and for adding body and volume to any hairstyle.

WHILE USING : Untwist cord from time to time to avoid tangling.

TO CLEAN: Unplug unit and allow to cool. Use a soft, slightly damp cloth to wipe the surfaces. Do not allow water or any other liquid to get into the unit. Intake grille must be cleared of any build-up of lint or hair with a small brush.

TO STORE: Unplug appliance, allow to cool, and store in its box or in a dry place. Never store it while it is hot or still plugged in. Never wrap the cord lightly around the appliance. Never hang unit by the cord - use the hanging ring provided. Do not put any stress on the cord were it enters the unit, as it could cause the cord to fray and break.

SERVICE NOTE: Before returning your unit for service, please make sure the air intake grille is free of lint and hair. If it is not, clean with a small brush and try to operate the unit again.

Speed switch

Temperature switch

Cool switch

MODED'EMPLOI

POUR VOTRE SECURITE

IN = Froid/Ticdc
OUT = Chaud

GEBRUKSAANWIZING

BELANGRIJKE VEILIGHEIDSVOORSCHRIFTEN

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register! Copies of the I/B. Please reproduce them without any change except under special instruction from Team International BELGIUM. The page must reproduced and folded in order to obtain a mini booklet B5 (+/- 150 mm width x 210 mm height. The page must be folded in order to keep the good numbering when you turn the page of the I/B. Don't change the page numbering. Keep the languages integrity.

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register!

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The page must reproduced and folded in order to obtain a mini booklet B5 (+ / - 150mm width x 210mm height). The page must be folded in order to keep the good numbering when you turn the page of the I/B. Don't change the page numbering. Keep the languages integrity.

Interruptor temperature

= Aire frio

Airc tenplado

Aire caliente

Interruptor aire frio

IN = Frio/Tenplado

OUT = Caliente

INSTRUCOES PARA UTILIZACAO

PENSANDO NA VOSSA SEGURANCA

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register!

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The page must reproduced and folded in order to obtain a mini booklet B5 (+/- 150 mm width x 210 mm height). The page must be folded in order to keep the good numbering when you turn the page of the I/B. Don't change the page numbering. Keep the languages integrity.

ATENÇAO
