USER MANUAL FK 83.1 XHA HOTPOINT ARISTON

FK 837J X/HA FK 837J /HA FK 93J X /HA FK 93J /HA FK 939J X /HA FK 939J /HA FK 932C X /HA FK 932C /HA Contents Installation, 14-15 Positioning Electrical connection Data plate Description of the appliance, 16 Overall view Control panel Start-up and use, 17 Starting the oven The electronic cooking programmer, 18 Modes, 19-21 Cooking modes Practical cooking advice Cooking advice table Precautions and tips, 22 General safety Disposal Respecting and conserving the environment Care and maintenance, 23 Switching the appliance off Cleaning the appliance Cleaning the oven door Replacing the light bulb Sliding rack kit assembly Assistance Operating Instructions Italiano, 1 Français, 24 Espanol, 35 Portuges, 47 English,13 IT GB FR ES PT KZ14

! Please keep this instruction booklet in a safe place for future reference. If the appliance is sold, given away or moved, please make sure the booklet is also passed on to the new owners so that they may benefit from the advice contained within it. ! Please read this instruction manual carefully: it contains important information on installation, operation and safety. Positioning ! Do not let children play with the packaging material; it should be disposed of in accordance with local separated waste collection standards (see Precautions and tips). ! The appliance must be installed by a qualified professional in accordance with the instructions provided. Incorrect installation may damage property or cause harm to people or animals. Built-in appliances Use an appropriate cabinet to ensure that the appliance functions properly.

• The panels adjacent to the oven must be made of heat-resistant material.

• Cabinets with a veneer exterior must be assembled with glues which can withstand temperatures of up to 100°C.

• To install the oven under the counter (see diagram) or in a kitchen unit, the cabinet must have the following dimensions: 597 mm. 595 mm.22,5 mm.*20,5 mm.550 mm. 570 mm. 20 mm. 575-585 mm. 45 mm.558 mm. min.550 mm. min.

• Only inox models ! The appliance must not come into contact with electrical parts once it has been installed. The indications for consumption given on the data plate have been calculated for this type of installation. Ventilation To ensure adequate ventilation is provided, the back panel of the cabinet must be removed. It is advisable to install the oven so that it rests on two strips of wood, or on a completely flat surface with an opening of at least 45 x 560 mm (see diagrams). Centring and fixing Secure the appliance to the cabinet:

• Remove the 2 rubber plugs covering the fixing holes on the perimeter frame.

• Fix the oven to the cabinet using the 2 wood screws.

• Replace the rubber plugs. ! All parts which ensure the safe operation of the appliance must not be removable without the aid of a tool. 560 mm. 45 mm. InstallationGB

APPLIANCE SPECIFICATIONSDimensionswidth 43.5 cmheight 32 cm depth 41.5 cmVolume 58 l ElectricalconnectionsVoltage at 220-240 V~ 50/60 Hz or50 Hz (see data plate)maximum power absorbed 2800 WENERGYLABELDirective 2002/40/EEC on thelabel of electric ovens. Standard EN 50304 Energy consumption for Naturalconvection – heating mode:Traditional mode Declared energy consumptionForced convection class -heating mode:Baking.This appliance conforms to thefollowing EEC Directives:2006/95/EEC dated 12/12/06(Low Voltage) and subsequentamendments - 2004/108/EECdated 15/12/04 (ElectromagneticCompatibility) and subsequentamendments - 93/68/EEC dated22/07/93 and subsequentamendments. 2002/96/EECand subsequent amendments.

Electrical connection ! Ovens equipped with a three-pole power supply cable are designed to operate with alternating current at the voltage and frequency indicated on the data plate located on the appliance (see below). Fitting the power supply cable

1. Open the terminal

board by inserting a screwdriver into the side tabs of the cover. Use the screwdriver as a lever by pushing it down to open the cover (see diagram).

2. Install the power

supply cable by loosening the cable clamp screw and the three wire contact screws L-N-

Connect the wires to the corresponding terminals: the Blue wire to the terminal marked (N), the Brown wire to the terminal marked (L) and the Yellow/Green wire to the terminal marked (see diagram).

3. Secure the cable by fastening the clamp screw.

4. Close the cover of the terminal board.

Connecting the electricity supply cable to the mains Install a standardised plug corresponding to the load indicated on the data plate (see table). The appliance must be directly connected to the mains using an omnipolar switch with a minimum contact opening of 3 mm installed between the appliance and the mains. The switch must be suitable for the charge indicated and must comply with current electrical regulations (the earthing wire must not be interrupted by the switch). The supply cable must be positioned so that it does not come into contact with temperatures higher than 50°C at any point. ! The installer must ensure that the correct electrical connection has been performed and that it is fully compliant with safety regulations. Before connecting the appliance to the power supply, make sure that:

• the appliance is earthed and the plug is compliant with the law;

• the socket can withstand the maximum power of the appliance, which is indicated on the data plate (see below);

• the voltage is in the range between the values indicated on the data plate (see below);

• the socket is compatible with the plug of the appliance. If the socket is incompatible with the plug, ask an authorised technician to replace it. Do not use extension cords or multiple sockets. ! Once the appliance has been installed, the power supply cable and the electrical socket must be easily accessible. ! The cable must not be bent or compressed. ! The cable must be checked regularly and replaced by authorised technicians only (see Assistance). ! The manufacturer declines any liability should these safety measures not be observed.16

! The first time you use your appliance, heat the empty oven with its door closed at its maximum temperature for at least half an hour. Make sure that the room is well ventilated before switching the oven off and opening the oven door. The appliance may emit a slightly unpleasant odour caused by protective substances used during the manufacturing process burning away. Starting the oven

1. Select the desired cooking mode by turning the

2. Select the desired temperature using the

THERMOSTAT knob. A list detailing cooking modes and suggested cooking temperatures can be found in the Cooking advice table (see Cooking modes).

3. The THERMOSTAT indicator light indicates that the

oven is heating up to the temperature set.

4. During cooking it is always possible to:

- change the cooking mode by turning the SELECTOR knob; - adjust the temperature by turning the THERMOSTAT knob; - stop cooking by turning the SELECTOR knob to the “0” position. ! Never put objects directly on the bottom of the oven; this will prevent the enamel coating from being damaged. ! Always place cookware on the rack(s) provided. Cooling ventilation In order to cool down the external temperature of the oven, a cooling fan blows a stream of air between the control panel and the oven door, as well as towards the bottom of the oven door. ! Once cooking has been completed, the cooling fan continues to operate until the oven has cooled down sufficiently. Oven light When selecting with the SELECTOR knob the oven light goes on. It remains lit when a cooking mode is selected. Start-up and use18

Setting the clock ! The clock may be set when the oven is switched off or when it is switched on, provided that a the end time of a cooking cycle has not been programmed previously. After the appliance has been connected to the mains, or after a blackout, the icon and the four numerical digits on the DISPLAY will begin to flash.

button several times until the icon and the four digits on the display begin to flash.

2. Use the “+” and “-” buttons to adjust the time; if

you press and hold either button, the display will scroll through the values more quickly, making it quicker and easier to set the desired value.

3. Wait for 10 seconds or press the

button again to finalise the setting. Setting the timer ! This function does not interrupt cooking and does not affect the oven; it is simply used to activate the buzzer when the set amount of time has elapsed.

button several times until the icon and the three digits on the display begin to flash.

2. Use the “+” and “-” buttons to set the desired

time; if you press and hold either button, the display will scroll through the values more quickly, making it quicker and easier to set the value.

3. Wait for 10 seconds or press the

button again to finalise the setting. The display will then show the time as it counts down. When this period of time has elapsed the buzzer will be activated. Programming cooking ! A cooking mode must be selected before programming can take place. Programming the cooking duration

button several times until the icon and the three digits on the DISPLAY begin to flash.

2. Use the “+” and “-” buttons to set the desired

duration; if you press and hold either button, the display will scroll through the values more quickly, making it quicker and easier to set the value.

3. Wait for 10 seconds or press the

button again to finalise the setting.

4. When the set time has elapsed, the text END

appears on the DISPLAY, the oven will stop cooking and a buzzer sounds. Press any button to stop it.

• For example: it is 9:00 a.m. and a time of 1 hour and 15 minutes is programmed. The programme will stop automatically at 10:15 a.m. Setting the end time for a cooking mode ! A cooking duration must be set before the cooking end time can be scheduled.

1. Follow steps 1 to 3 to set the duration as detailed

button until the icon and the four digits on the DISPLAY begin to flash.

3. use the “+” and “-” buttons to adjust the cooking

end time; if you press and hold either button, the display will scroll through the values more quickly, making it quicker and easier to set the desired value.

4. Wait for 10 seconds or press the

button again to finalise the setting.

5. When the set time has elapsed, the text END

appears on the DISPLAY, the oven will stop cooking and a buzzer sounds. Press any button to stop it. Programming has been set when the and buttons are illuminated. The DISPLAY shows the cooking end time and the cooking duration alternately.

• For example: It is 9:00 a.m. and a duration of 1 hour has been programmed. 12:30 is scheduled as the end time. The programme will start automatically at 11:30 a.m. Cancelling a programme To cancel a programme:

• press the button until the icon corresponding to the setting you wish to cancel and the digits on the display are no longer flashing. Press the “-” button until the digits 00:00 appear on the display.

• Press and hold the “+” and “-” buttons; this will cancel all the settings selected previously, including timer settings.GB

Cooking modes ! A temperature value between 60°C and MAX can be set for all cooking modes except the following:

• GRILL (recommended: set only to MAX power level)

• GRATIN (recommended: do not exceed 200°C). DEFROST mode The fan at the bottom of the oven circulates room- temperature air around the food. This mode is suitable for defrosting any type of food, especially delicate items that should not be heated, for example: ice-cream cakes or cakes made with custard, cream or fruit. The defrosting time will be approximately halved. When defrosting meat, fish or bread, the process may be accelerated by selecting the “multilevel” mode and setting a temperature between 80°C and 100°C. TRADITIONAL OVEN mode Both the top and bottom heating elements will come on. When using this traditional cooking mode, it is best to use one cooking rack only. If more than one rack is used, the heat will be distributed unevenly. BAKING mode The rear heating element and the fan are switched on, thus guaranteeing the distribution of heat in a delicate and uniform manner throughout the entire oven. This mode is ideal for baking temperature sensitive foods (such as cakes, which need to rise) and for the preparation of “bitesize pastries” on 3 shelves simultaneously. FAST COOKING mode The heating elements and the fan are activated, guaranteeing the distribution of heat consistently and uniformly throughout the oven. Preheating is not necessary for this cooking mode. This mode is particularly suitable for cooking pre- packed food quickly (frozen or pre-cooked). The best results are achieved using one cooking rack only. MULTILEVEL mode All the heating elements (top, bottom and circular) switch on and the fan begins to operate. Since the heat remains constant throughout the oven, the air cooks and browns food in a uniform manner. A maximum of two racks may be used at the same time. PIZZA OVEN mode The circular heating elements and the elements at the bottom of the oven are switched on and the fan is activated. This combination heats the oven rapidly by producing a considerable amount of heat, particularly from the element at the bottom. If you use more than one rack at a time, switch the position of the dishes halfway through the cooking process. GRILL mode The top heating element and the rotisserie (where present) come on. The high and direct temperature of the grill is recommended for food which requires a high surface temperature. Always cook in this mode with the oven door closed. FAN GRILLING mode The top heating element as well as the fan and the rotisserie (where present) come on. This combination of features increases the effectiveness of the unidirectional thermal radiation provided by the heating elements through forced circulation of the air throughout the oven. This helps prevent food from burning on the surface and allows the heat to penetrate right into the food. Always cook in this mode with the oven door closed. The Rotisserie (only available on certain models) To operate the rotisserie (see diagram) proceed as follows:

1. Place the dripping

support in position 3 and insert the spit in the hole provided on the back panel of the oven.

3. Start the rotisserie

using the knob to select MODE or . Practical cooking advice ! Do not place racks in position 1 or 5 during fan- assisted cooking. Excessive direct heat can burn temperature sensitive foods. ! When using the GRILL and GRATIN modes, place the dripping pan in position 1 to collect cooking residues (sauces and/or fats). MULTILEVEL

• Use positions 2 and 4, placing the food which requires more heat on the rack in position 2.

• Place the dripping pan on the bottom and the rack on top. Modes20

• Place the rack in position 3 or 4. Make sure the food is in the centre of the rack.

• We recommend that the power level is set to maximum. The top heating element is regulated by a thermostat and may not always operate constantly. PIZZA OVEN

• Use a lightweight aluminium pizza pan. Place it on the rack provided. For a crispy crust, do not use the dripping pan as this extends the total cooking duration and prevents the crust from forming.

• If the pizza has a lot of toppings, we recommend adding the mozzarella cheese to the top of the pizza halfway through the cooking process.GB

Modes Foods Weight(in kg)Position ofshelvesPreheating(minutes)RecommendedtemperatureCookingduration(minutes)DefrostingAll frozen foodsTraditional Duck Roast veal or beefRoast porkBiscuits (shortcrust pastry)Tarts

65-7570-7570-8015-2030-35BakingTartsFruit cakesSponge cake made with yoghurtSponge cakeStuffed pancakes (on 2 racks)Small cakes (on 2 racks)Cheese puffs (on 2 racks)Cream puffs (on 3 racks)Biscuits (on 3 racks)Meringues (on 3 racks)

1 and 31 and 31 and 31, 2 and 41, 2 and 41, 2 and 4

25-3015-20Pre-cooked foodGolden chicken wings0.4 1 - 200 20-25Fresh FoodBiscuits (shortcrust pastry)Sponge cake made with yoghurtCheese puffs

15-18 10-12MultilevelPizza (on 2 racks)Lasagne Lamb Roast chicken + potatoesMackerelSponge cake made with yoghurtCream puffs (on 2 racks)Biscuits (on 2 racks)Sponge cake (on 1 rack)Sponge cake (on 2 racks)Savoury pies

1 and 31 and 21 and 21 and 31 and 31 and 21 and 3

15-2025-3060-70GrillSoles and cuttlefish Squid and prawn kebabs Cuttlefish Cod filet Grilled vegetables Veal steak Sausages Hamburgers Mackerels Toasted sandwiches (or toast)

55-60 30-35 With rotisserie (where present) Veal on the spit Lamb on the spit Chicken on the spit + potatoes (roasted)

70-80 70-80 70-75 70-75 ! cooking times are approximate and may vary according to personal taste. When cooking using the grill or gratin, the dripping pan must always be placed on the 1st oven rack from the bottom. Cooking advice table22

Precautions and tips ! This appliance has been designed and manufactured in compliance with international safety standards. The following warnings are provided for safety reasons and must be read carefully. General safety

• The appliance was designed for domestic use inside the home and is not intended for commercial or industrial use.

• The appliance must not be installed outdoors, even in covered areas. It is extremely dangerous to leave the appliance exposed to rain and storms.

• When moving or positioning the appliance, always use the handles provided on the sides of the oven.

• Do not touch the appliance when barefoot or with wet or damp hands and feet.

• The appliance must be used by adults only for the preparation of food, in accordance with the instructions provided in this booklet. Any other use of the appliance (e.g. for heating the room) constitutes improper use and is dangerous. The manufacturer may not be held responsible for any damage caused as a result of improper, incorrect and unreasonable use of the appliance.

• Do not touch the heating elements or certain parts of the oven door when the appliance is in use; these parts become extremely hot. Keep children well away from the appliance.

• Make sure that the power supply cables of other electrical appliances do not come into contact with the hot parts of the oven.

• The ventilation and heat dispersal openings must never be obstructed.

• Always grip the oven door handle in the centre: the ends may be hot.

• Always use oven gloves when placing cookware in the oven or when removing it.

• Do not use aluminium foil to line the bottom of the oven.

• Do not place flammable materials in the oven: if the appliance is switched on accidentally, the materials could catch fire.

• Always make sure the knobs are in the “”/“ position when the appliance is not in use.

• When unplugging the appliance, always pull the plug from the mains socket; do not pull on the cable.

• Do not perform any cleaning or maintenance work without having disconnected the appliance from the electricity mains.

• If the event of malfunctions, under no circumstances should you attempt to perform the repairs yourself. Contact an authorised Service Centre (see Assistance).

• Do not rest heavy objects on the open oven door.

• The appliance should not be operated by people (including children) with reduced physical, sensory or mental capacities, by inexperienced individuals or by anyone who is not familiar with the product. These individuals should, at the very least, be supervised by someone who assumes responsibility for their safety or receive preliminary instructions relating to the operation of the appliance.

• Do not let children play with the appliance. Disposal

• When disposing of packaging material: observe local legislation so that the packaging may be reused.

• The European Directive 2002/96/EC relating to Waste Electrical and Electronic Equipment (WEEE) states that household appliances should not be disposed of using the normal solid urban waste cycle. Exhausted appliances should be collected separately in order to optimise the cost of re-using and recycling the materials inside the machine, while preventing potential damage to the atmosphere and to public health. The crossed-out dustbin is marked on all products to remind the owner of their obligations regarding separated waste collection. For further information relating to the correct disposal of exhausted household appliances, owners may contact the relevant public service or their local dealer. Respecting and conserving the environment

• You can help to reduce the peak load of the electricity supply network companies by using the oven in the hours between late afternoon and the early hours of the morning.

• Always keep the oven door closed when using the GRILL and GRATIN modes: this will achieve improved results while saving energy (approximately 10%).

• Check the door seals regularly and wipe them clean to ensure they are free of debris so that they adhere properly to the door, thus avoiding the dispersal of heat.GB

Switching the appliance off Disconnect your appliance from the electricity supply before carrying out any work on it. Cleaning the appliance

• The stainless steel or enamel-coated external parts and the rubber seals may be cleaned using a sponge that has been soaked in lukewarm water and neutral soap. Use specialised products for the removal of stubborn stains. After cleaning, rinse and dry thoroughly. Do not use abrasive powders or corrosive substances.

• The inside of the oven should ideally be cleaned after each use, while it is still lukewarm. Use hot water and detergent, then rinse well and dry with a soft cloth. Do not use abrasive products.

• All accessories - with the exception of the sliding racks - can be washed like everyday crockery, and are even dishwasher safe. ! Never use steam cleaners or pressure cleaners on the appliance. Cleaning the oven door Clean the glass part of the oven door using a sponge and a non-abrasive cleaning product, then dry thoroughly with a soft cloth. Do not use rough abrasive material or sharp metal scrapers as these could scratch the surface and cause the glass to crack. For more thorough cleaning purposes, the oven door may be removed:

1. Open the oven door fully (see diagram).

2. Use a screwdriver to lift up and turn the small

levers F F F F F located on the two hinges (see diagram).

3. Grip the door on the two

outer sides and close it approximately half way. Pull the door towards you, lifting it out of its slot (see diagram). To replace the door, reverse this sequence. Inspecting the seals Check the door seals around the oven regularly. If the seals are damaged, please contact your nearest Service Centre (see Assistance). We recommend that the oven is not used until the seals have been replaced. Replacing the light bulb To replace the oven light bulb:

glass cover of the lamp-holder.

light bulb and replace it with a similar one: Wattage 25 W, cap E 14.

glass cover (see diagram). Sliding rack kit assembly To assemble the sliding racks:

1. Remove the two frames,

lifting them away from the spacers A (see figure).

2. Choose which shelf to use

with the sliding rack. Paying attention to the direction in which the sliding rack is to be extracted, position joint B and then joint C on the frame.

3. Secure the two frames with

the guide rails using the holes provided on the oven walls (see diagram). The holes for the left frame are situated at the top, while the holes for the right frame are at the bottom.

4. Finally, fit the frames on the spacers A.

! Do not place the sliding racks in position 5. Assistance ! Never use the services of an unauthorised technician. Please have the following information to hand:

• The type of problem encountered.

• The appliance model (Mod.).

• The serial number (S/N). The latter two pieces of information can be found on the data plate located on the appliance. Care and maintenance
