USER MANUAL Intel® Dual Band Wireless-AC 8265 INTEL

This version of Intel® PROSet/Wireless WiFi Software is compatible with the adapters listed below. Note that newer features provided in this software are generally not supported on older generations of wireless adapters.

i Adapter Information Guide

The following adapters are supported in Windows* 10:

Intel® Dual Band Wireless-AC 3165

With your WiFi network card, you can access WiFi networks, share files or printers, or even share your Internet connection. All these features can be explored using a WiFi network in your home or office. This WiFi network solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change.

This guide contains basic information about Intel adapters. Intel® wireless adapters enable fast connectivity without wires for desktop and notebook PCs.

Regulatory and Safety Information Specifications

Depending on the model of your Intel WiFi adapter, your adapter is compatible with 802.11a, 802.11b, 802.119, 802.11n, 802.11ac and 802.11ax wireless standards. Operating at 5GHz or 2.4GHz frequency, you can now connect your computer to existing high-speed networks that use multiple access points within large or small environments. Your WiFi adapter maintains automatic data rate control according to the access point location and signal strength to achieve the fastest possible connection.

Information in this document is subject to change without notice.

Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein.

IMPORTANT NOTICE FOR ALL USERS OR DISTRIBUTORS:

Intel wireless LAN adapters are engineered, manufactured, tested, and quality checked to ensure that they meet all necessary local and governmental regulatory agency requirements for the regions that they are designated and/or marked to ship into. Because wireless LANS are generally unlicensed devices that share spectrum with radars, satellites, and other licensed and unlicensed devices, it is sometimes necessary to dynamically detect, avoid, and limit usage to avoid interference with these devices. In many instances Intel is required to provide test data to prove

index.htm[8/25/2022 4:59:17 PM]

Intel(R) WiFi Adapter Information Guide

regional and local compliance to regional and governmental regulations before certification or approval to use the product is granted. Intel's wireless LAN's EEPROM, firmware, and software driver are designed to carefully control parameters that affect radio operation and to ensure electromagnetic compliance (EMC). These parameters include, without limitation, RF power, spectrum usage, channel scanning, and human exposure.

For these reasons Intel cannot permit any manipulation by third parties of the software provided in binary format with the wireless LAN adapters (e.g., the EEPROM and firmware). Furthermore, if you use any patches, utilities, or code with the Intel wireless LAN adapters that have been manipulated by an unauthorized party (i.e., patches, utilities, or code (including open source code modifications) which have not been validated by Intel), (i) you will be solely responsible for ensuring the regulatory compliance of the products, (ii) Intel will bear no liability, under any theory of liability for any issues associated with the modified products, including without limitation, claims under the warranty and/or issues arising from regulatory non-compliance, and (iii) Intel will not provide or be required to assist in providing support to any third parties for such modified products.

Note: Many regulatory agencies consider Wireless LAN adapters to be "modules", and accordingly, condition system-

level regulatory approval upon receipt and review of test data documenting that the antennas and system configuration do not cause the EMC and radio operation to be non-compliant.

Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries. *Other names and brands may be claimed as the property of others.

index.htm[8/25/2022 4:59:17 PM]

Adapter Settings Back to Contents

The Advanced tab displays the device properties for the WiFi adapter installed on your computer. How to Access

Double-click on the Intel WiFi adapter in the Network adapters section of the Device Manager and select the Advanced tab.

A description of the WiFi adapter settings on the Advanced tab can be found here:

https://www.intel.com/content/www/us/en/support/articles/000005585/network-and-i-o/wireless-networking.html

Trademarks and Disclaimers

adaptusr.htm[8/25/2022 4:59:18 PM]

Regulatory Information

This section provides regulatory information for the following wireless adapters:

Intel® Centrino® Wireless-N 100 Intel® Centrino® Wireless-N 105 Intel® Centrino® Wireless-N 130 Intel® Centrino® 135 1000

NOTE: Due to the evolving state of regulations and standards in the wireless LAN field (IEEE 802.11 and similar standards), the information provided herein is subject to change. Intel Corporation assumes no responsibility for errors or omissions in this document.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Intel WiFi/ WiMAX Wireless Adapters

Information in this section supports the following wireless adapters:

+ Intel® Centrino® Wireless-N + WiMAX 6150 + Intel® Centrino® Advanced-N + WiMAX 6250

See Specifications for complete wireless adapter specifications. NOTE: In this section, all references to the “wireless adapter" refer to all adapters listed above. The following information is provided:

Information for the User

Regulatory Information

Regulatory ID Information for OEMs and Host Integrators

INFORMATION FOR THE USER Safety Notices USA FCC Radio Frequency Exposure

The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. The wireless adapter meets the Human Exposure requirements found in FCC Part 2, 15C, 15E along with guidance from KDB 447498, KDB 248227 and KDB 616217. Proper operation of this radio according to the instructions found in this manual will result in exposure substantially below the FCC's recommended limits.

The following safety precautions should be observed:

* Do not touch or move antenna while the unit is transmitting or receiving. Do not hold any component containing the radio such that the antenna is very close or touching any exposed parts of the body, especially the face or eyes, while transmitting. + Do not operate the radio or attempt to transmit data unless the antenna is connected; this behavior may cause damage to the radio. «+ Use in specific environments: + The use of wireless adapters in hazardous locations is limited by the constraints posed by the safety directors of such environments. + The use of electronic devices equipped with wireless adapters on airplanes is governed by rules for each commercial airline operator. + The use of wireless adapters in hospitals is restricted to the limits set forth by each hospital.

Explosive Device Proximity Warning

À Warning: Do not operate a portable transmitter (including this wireless adapter) near unshielded blasting caps or in an explosive environment unless the transmitter has been modified to be qualified for such use.

À Warning: The wireless adapter is not designed for use with high-gain directional antennas. Use On Aircraft Caution

À Caution: Regulations of commercial airline operators may prohibit airborne operation of certain electronic devices equipped with radio-frequency wireless devices (wireless adapters) because their signals could interfere with critical aircraft instruments.

À Caution: 60 GHz/802.11ad equipment is not permitted on aircraft per FCC 815.255. OEM and host integrators should consider this FCC rule in host devices.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Other Wireless Devices Safety Notices for Other Devices in the Wireless Network: See the documentation supplied with wireless adapters or other devices in the wireless network.

Local Restrictions on 802.11a, 802.11b, 802.11d, 802.119, 802.11n, 802.11ac, and 802.16e Radio Usage

À Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11d, 802.119, 802.11n, 802.11ac, and 802.16e wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11d, 802.119, 802.11n, 802.11ac, and 802.16e products are designed for use only in specific countries, and are not allowed to be operated in countries other than those of designated use. As a user of these products, you are responsible for ensuring that the products are used only in the countries for which they were intended and for verifying that they are configured with the correct selection of frequency and channel for the country of use. The device transmit power control (TPC) interface is part of the Intel® PROSet/Wireless WiFi Connection Utility Software. Operational restrictions for Equivalent Isotropic Radiated Power (EIRP) are provided by the system manufacturer. Any deviation from the permissible power and frequency settings for the country of use is an infringement of national law and may be punished as such.

Wireless Interoperability The wireless adapter is designed to be interoperable with other wireless LAN products that are based on direct sequence spread spectrum (DSSS) radio technology and to comply with the following standards:

+ IEEE Std. 802.11b compliant Standard on Wireless LAN

+ IEEE 802.16e-2005 Wave 2 compliant

« Wireless Fidelity certification, as defined by the Wi-Fi Alliance + WiMAX certification as defined by the WiMAX Forum

The Wireless Adapter and Your Health

The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by the wireless adapter, however, is less than the electromagnetic energy emitted by other wireless devices such as mobile phones. The wireless adapter operates within the guidelines found in radio frequency safety standards and recommendations. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of the wireless adapter may be restricted by the proprietor of the building or responsible representatives of the applicable organization. Examples of such situations may include:

+ Using the wireless adapter on board airplanes, or + Using the wireless adapter in any other environment where the risk of interference with other devices or services is perceived or identified as being harmful.

If you are uncertain of the policy that applies to the use of wireless adapters in a specific organization or environment (an airport, for example), you are encouraged to ask for authorization to use the adapter before you turn it on.

REGULATORY INFORMATION USA - Federal Communications Commission (FCC)

No configuration controls are provided for Intel® wireless adapters allowing any change in the frequency of operations outside the FCC grant of authorization for U.S. operation according to Part 15.407 of the FCC rules.

«+ Intel® wireless adapters are intended for OEM integrators only. «+ Intel® wireless adapters cannot be co-located with any other transmitter unless approved by the FCC.

This wireless adapter complies with Part 15 of the FCC Rules. Operation of the device is subject to the following two conditions:

+ This device may not cause harmful interference. + This device must accept any interference that may cause undesired operation.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Class B Device Interference Statement

This wireless adapter has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This wireless adapter generates, uses, and can radiate radio frequency energy. If the wireless adapter is not installed and used in accordance with the instructions, the wireless adapter may cause harmful interference to radio communications. There is no guarantee, however, that such interference will not occur in a particular installation. 1f this wireless adapter does cause harmful interference to radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the interference by taking one or more of the following measures:

* _Reorient or relocate the receiving antenna of the equipment experiencing the interference.

+ Increase the distance between the wireless adapter and the equipment experiencing the interference.

+ Connect the computer with the wireless adapter to an outlet on a circuit different from that to which the equipment experiencing the interference is connected. + _Consult the dealer or an experienced radio/TV technician for help.

NOTE: The adapter must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product. Any other installation or use will violate FCC Part 15 regulations.

Safety Approval Considerations

This device has been safety approved as à component and is for use only in complete equipment where the acceptability of the combination is determined by the appropriate safety agencies. When installed, consideration must be given to the following:

+ It must be installed into a compliant host device meeting the requirement of UL/EN/IEC 60950-1 2nd edition including the general provisions of enclosure design 1.6.2 and specifically paragraph 1.2.6.2 (Fire Enclosure).

. The device shall be supplied by a SELV source when installed in the end-use equipment.

+ A heating test shall be considered in the end-use product for meeting the requirement of UL/EN/IEC 60950-1 2nd edition.

Applies only to brominated and chlorinated flame retardants (BFRs/CFRs) and PVC in the final product. Intel components as well as purchased components on the finished assembly meet JS-709 requirements, and the PCB / substrate meet IEC 61249-2-21 requirements. The replacement of halogenated flame retardants and/or PVC may not be better for the environment.

To determine whether you are allowed to use your wireless network device in a specific country, please check to see if the radio type number that is printed on the identification label of your device is listed in the manufacturer's OEM Regulatory Guidance document.

Modular Regulatory Certification Country Markings

A list of countries requiring regulatory markings is available. Note that the lists include only countries requiring marking but not all certified countries. To find the regulatory country marking information for your adapter, perform these steps:

1. Open this web site: http://www.intel.com/content/www/us/en/support/network-and-i-o/wireless-networking/000007443.html 2. Click on the link for your adapter. 3. Click on Regulatory Marking Document for your adapter.

INFORMATION FOR OEMs and HOST INTEGRATORS The guidelines described within this document are provided to OEM integrators installing Intel® wireless adapters in notebook and tablet PC host platforms. Adherence to these requirements is necessary to meet the conditions of compliance with FCC rules, including RF exposure. When all antenna type and placement guidelines described herein are fulfilled the Intel® wireless adapters may be incorporated into notebook and tablet PC host platforms with no further restrictions. 1f any of the guidelines described herein are not satisfied it may be necessary for the OEM or integrator to perform additional testing and/or obtain additional approval. The OEM or integrator is responsible to determine the required host regulatory testing and/or obtaining the required host approvals for compliance.

«+ Intel® wireless adapters are intended for OEMs and host integrators only.

- The Intel® wireless adapter FCC Grant of Authorization describes any limited conditions of modular approval.

. The Intel® wireless adapters must be operated with an access point that has been approved for the country of operation.

+ Changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties is not permitted. Any changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties will void authorization to operate the adapter.

Antenna Type and Gains

Only antennas of the same type and with equal or less gains as 3dBi for the 2.4GHz band and 5dBi for the 5GHz band shall be used with the Intel® wireless adapters. Other types of antennas and/or higher gain antennas may require additional authorization for operation. For testing purposes the following dual band antenna that approximates closely the above limits was used:

Antenna Antenna Location 2.4GHz Peak Gain in 5.2GHz Peak Gain in 5.5GHz Peak Gain in 5.7GHz Peak Gain in Type (Main/ Aux) dBi* dBi* dBi* dBi* PIFA Main Ï Ï Ï | ] [ Aux I 3.24 I 3.73 I 4.77 I 4.77 ] MIMO Ï Î Î Î ] [AIT antenna gains include cable loss. ]

Antenna Placement Within the Host Platform

To ensure RF exposure compliance the antenna(s) used with the Intel® wireless adapters must be installed in notebook or tablet PC host platforms to provide a minimum separation distance from all persons, in all operating modes and orientations of the host platform, with strict adherence to the table below. The antenna separation distance applies to both horizontal and vertical orientation of the antenna when installed in the host system.

F Tr il regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information [ Intel® Wireless Adapter Il [intel® Centrino® Wireless-N + WiMAX 6150 || 18 mm ] [intel® Centrino® Wireless-N + WiMAX 6350 || 17 mm ]

um required antenna-to-user separation distance ]

Simultaneous Transmission of Intel® Wireless Adapters with Other Integrated or Plug-In Transmitters

Based upon FCC Knowledge Database publication number 616217 when there are multiple transmitting devices installed in a host device, an RF exposure transmitting assessment shall be performed to determine the necessary application and test requirements. OEM integrators must identify all possible combinations of simultaneous transmission configurations for all transmitters and antennas installed in the host system. This includes transmitters installed in the host as mobile devices (>20 cm separation from user) and portable devices (<20 cm separation from user). OEM integrators should consult the actual FCC KDB 616217 document for all details in making this assessment to determine if any additional requirements for testing or FCC approval is necessary.

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to the end user of the product or system incorporating the Intel® wireless adapter, in compliance with local regulations. Host system must be labeled with "Contains FCC ID: XXXXXXXX", FCC ID displayed on label.

The Intel® wireless adapter must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product. Intel Corporation is not responsible for any radio or television interference caused by unauthorized modification of the devices included with the wireless adapter kit or the substitution or attachment of connecting cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these guidelines.

RUE SRE ATR IAE ARRETE De ELLE NERO RÉEL RER AE UT Local Restriction of 802.11a, 802.11b, 802.119, 802.11n, and 802.11e Radio Usage The following statement on local restrictions must be published as part of the compliance documentation for all 802.11a, 802.11b, 802.119 and 802.11n products.

À Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.119, 802.11n, and 802.16e wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.119, 802.11n, and 802.16e products are designed for use only in specific countries, and are not allowed to be operated in countries other than those of designated use. As a user of these products, you are responsible for ensuring that the products are used only in the countries for which they were intended and for verifying that they are configured with the correct selection of frequency and channel for the country of use. Any deviation from the permissible power and frequency settings for the country of use is an infringement of national law and may be punished as such.

Intel WiFi Adapters - 802.11n, 802.11ac and 802.11ax Combpliant

The information in this section applies to the following products:

Regulatory Information

+ Intel® Tri-Band Wireless-AC 18260

+ Intel® Wireless Gigabit Sink W13100

+ Intel® Wi-Fi 6E AX411

Information for the User

. + Regulatory Information

+ Information for OEMs and Host Integrators + Statements of European Compliance

INFORMATION FOR THE USER Safety Notices

USA FCC Radio Frequency Exposure

The following safety precautions should be observed:

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Do not touch or move antenna while the unit is transmitting or receiving.

Do not hold any component containing the radio such that the antenna is very close or touching any exposed parts of the body, especially the face or eyes, while transmitting.

. Do not operate the radio or attempt to transmit data unless the antenna is connected; this behavior may cause damage to the radio.

* Use in specific environments:

+ The use of wireless adapters in hazardous locations is limited by the constraints posed by the safety directors of such environments.

+ The use of wireless adapters on airplanes is governed by the Federal Aviation Administration (FAA).

+ The use of wireless adapters in hospitals is restricted to the limits set forth by each hospital.

Explosive Device Proximity Warning

À Warning: The wireless adapter is not designed for use with high-gain directional antennas.

Use On Aircraft Caution

À Caution: 60 GHz/802.11ad equipment is not permitted on aircraft per FCC 815.255. OEM and host integrators should consider this FCC rule in host devices. Other Wireless Devices Safety Notices for Other Devices in the Wireless Network: See the documentation supplied with wireless adapters or other devices in the wireless network.

Local Restrictions on 802.11a, 802.11b, 802.11d, 802.119, 802.11n, and 802.11ac Radio Usage

À Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11d, 802.119, 802.11n, and 802.11ac wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11d, 802.119, 802.11n, and 802.11ac products are designed for use only in specific countries, and are not allowed to be operated in countries other than those of designated use. As a user of these products, you are responsible for ensuring that the products are used only in the countries for which they were intended and for verifying that they are configured with the correct selection of frequency and channel for the country of use. The device transmit power control (TPC) interface is part of the Intel® PROSet/Wireless WiFi Connection Utility Software. Operational restrictions for Equivalent Isotropic Radiated Power (EIRP) are provided by the system manufacturer. Any deviation from the permissible power and frequency settings for the country of use is an infringement of national law and may be punished as such.

Wireless Interoperabi

The wireless adapter is designed to be interoperable with other wireless LAN products that are based on direct sequence spread spectrum (DSSS) radio technology and to comply with the following standards:

+ IEEE Std. 802.11ac draft compliant on Wireless LAN

+ Wireless Fidelity certification, as defined by the Wi-Fi Alliance

The Wireless Adapter and Your Health

The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by the wireless adapter, however, is less than the

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

electromagnetic energy emitted by other wireless devices such as mobile phones. The wireless adapter operates within the guidelines found in radio frequency safety standards and recommendations. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of the wireless adapter may be restricted by the proprietor of the building or responsible representatives of the applicable organization. Examples of such situations may include:

+ Using the wireless adapter on board airplanes, or «+ Using the wireless adapter in any other environment where the risk of interference with other devices or services is perceived or identified as being harmful.

REGULATORY INFORMATION USA - Federal Communications Commission (FCC)

This wireless adapter is restricted to indoor use due to its operation in the 5.85 to 5.895 and 5.925 to 7.125GHz frequency ranges. No configuration controls are provided for

Intel® wireless adapters allowing any change in the frequency of operations outside the FCC grant of authorization for U.S. operation according to Part 15.407 of the FCC rules.

+ Intel® wireless adapters are intended for OEM integrators only. + Intel® wireless adapters cannot be co-located with any other transmitter unless approved by the FCC.

This wireless adapter complies with Part 15 of the FCC Rules. Operation of the device is subject to the following two conditions:

+ This device may not cause harmful interference. + This device must accept any interference that may cause undesired operation.

NOTE: The radiated output power of the adapter is far below the FCC radio frequency exposure limits. Nevertheless, the adapter should be used in such à manner that the potential for human contact during normal operation is minimized. To avoid the possibility of exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 20cm between you (or any other person in the vicinity), or the minimum separation distance as specified by the FCC grant conditions, and the antenna that is built into the computer. Details of the authorized configurations can be found at http://www.fcc.gov/oet/ea/ by entering the FCC ID number on the device.

Class B Device Interference Statement

< _Reorient or relocate the receiving antenna of the equipment experiencing the interference.

+ Increase the distance between the wireless adapter and the equipment experiencing the interference.

Safety Approval Considerations

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

- The device shall be supplied by a SELV source when installed in the end-use equipment. + A heating test shall be considered in the end-use product for meeting the requirement of UL/EN/IEC 60950-1 2nd edition.

Canada - Industry Canada (IC)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Cet appareil se conforme aux normes Canada d'Industrie de RSS permis-exempt. L'utilisation est assujetti aux deux conditions suivantes: (1) cet appareil ne peut pas causer d'interférences, et (2) cet appareil doit accepter des interférences , y compris des interférences qui peuvent causer desopérations non désirées de l'appareil.

Caution: When using IEEE 802.11a wireless LAN, this product is restricted to indoor use due to its operation in the 5.15- to 5.25-GHz frequency range. Industry Canada requires this product to be used indoors for the frequency range of 5.15GHz to 5.25GHz to reduce the potential for harmful interference to co-channel mobile satellite systems. High power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65 to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device. The maximum allowed antenna gain for use with this device is 6dBi in order to comply with the E.I.R.P limit for the 5.25- to 5.35 and 5.725 to 5.85GHz frequency range in point-to-point operation. To comply with RF exposure requirements all antennas should be located at a minimum distance of 20cm, or the minimum separation distance allowed by the module approval, from the body of all persons.

Attention: l'utilisation d'un réseau sans fil IEEE802.11a est restreinte à une utilisation en intérieur à cause du fonctionnement dans la bande de fréquence 5.15-5.25 GHz. Industry Canada requiert que ce produit soit utilisé à l'intérieur des bâtiments pour la bande de fréquence 5.15-5.25 GHz afin de réduire les possibilités d'interférences nuisibles aux canaux co-existants des systèmes de transmission satellites. Les radars de puissances ont fait l'objet d'une allocation primaire de fréquences dans les bandes 5.25-5.35 GHz et 5.65-5.85 GHz. Ces stations radar peuvent créer des interférences avec ce produit et/ou lui être nuisible. Le gain d'antenne maximum permissible pour une utilisation avec ce produit est de 6 dBi afin d'être conforme aux limites de puissance isotropique rayonnée équivalente (P.I.R.E.) applicable dans les bandes 5.25-5.35 GHz et 5.725-5.85 GHz en fonctionnement point-à-point. Pour se conformer aux conditions d'exposition de RF toutes les antennes devraient être localisées à une distance minimum de 20 cm, ou la distance de séparation minimum permise par l'approbation du module, du corps de toutes les personnes.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

gain approuvé pour l'émetteur par Canada d'Industrie. Pour réduire lesinterférences radio potentielles avec les autres utilisateurs, le type d'antenne et son gain devraient être choisis de façon à ce que la puissance isotrope rayonnée équivalente(P.I.R.E.) ne soit pas supérieure à celle qui est nécessaire pour une communication réussie.

The low band 5.15 - 5.35GHz is for indoor use only. The 6E band 5.925 - 6.425GHZz is for Low Power in-door (LPI)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

AT|B8E|8G|cH|cy| cz | DE DK|EE|EL|ES| F1] FR|HR HU| EE lisfiri ul cr |iu LwmT|nc|PL|PT| RO | SE si | SK | TR | UK (NI)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU. See Statements of European Union Compliance.

European Union Declarations of Conformity

To view the European Union Declaration of Conformity for your adapter, perform these steps.

1. Open this web site: http://www.intel.com/content/www/us/en/support/network-and-i-0/wireless-networking/000007443.html 2. Click on “User Guide." 3. Scroll to your adapter.

To view additional regulatory information for your adapter, perform these steps:

Waste Electrical and Electronic Equipment Directive (WEEE)

Restriction of Hazardous Substances Directive (RoHS) Compliant All products described herein are compliant with the European Union's RoHS Directive. For CE Mark-Related Questions related to the wireless adapter, contact:

Intel Corporation Attn: Corporate Quality 2200 Mission College Blvd. Santa Clara, CA 95054-1549 USA Japan

Regulatory Information

La operacién de este equipo esté sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operacién no deseada.

The operation of this product in the radio channel 2 (2417 MHz) is not authorized in the following cities:

Agadir, Assa-Zag, Cabo Negro, Chaouen, Goulmima, Oujda, Tan Tan, Taourirt, Taroudant, Taza.

The operation of this product in the radio channels 4, 5, 6 et 7 (2425 - 2442 MHz) is not authorized in the following cities:

Aéroport Mohamed V, Agadir, Aguelmous, Anza, Benslimane, Béni Hafida, Cabo Negro, Casablanca, Fès, Lakbab, Marrakech, Merchich, Mohammédia, Rabat, Salé, Tanger, Tan Tan, Taounate, Tit Mellil, Zag.

“PTA APPROVED MODEL"

BUS ZEN JE AT. SRRERÉNFRSEÉBSERX . MADENSE RAT ZÉAERINÉE - HDRMNREMNZEMFENERMETATRSRES MRRAT BRSE ÆUNÉR RÉERFIRATSÉRER -RSREÉ ERERBIEANE/KIZMRREN - (CDRNRANARSÉREENLX . SARRRAESENMÉEMNR2T EEE Singapore

Complies with IDA Standards DB 02941

Modular Regulatory Certification Country Markings

1. Open this web site: http://www.intel.com/content/www/us/en/support/network-and-i-o/wireless-networking/000007443.html

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

2. Click on the link for your adapter. 3. Click on Regulatory Marking Document for your adapter.

Regulatory 1 D Europe: Models 3160HMW, 3160NGW, 3160SDW, 3165NGW, 7260SDW, 7260NGW, 7260HMW, 7265D2W, 7265NGW, 8260D2W, 8260NGW, 8260NGWH, 18260NGW Software Version Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions (WiFi/ BT) Intel® Wireless Dock Manager 3.x and previous versions (WiGig)

IEEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver. Not supported by the models: 3160HMW, 3160NGW, 3160SDW, 3165NGW, 7265D2W, 7265NGW

(57 - 64 GHz) 25 dBm EIRP max IEEE802.11 ad mode

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Intel® Dual Band Wireless-AC 3165

Due to the very small size of the 3165D2W/3165NGW (12x16), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

5.15-5.35GHz: Indoor use only DL | (Except communicate to high power radio)

5.15-5.35GHz: Indoor use only L | (Except communicate to high power radio)

Regulatory Information

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 3165D2W Singapore:

Model 3165D2W Complies with IDA Standards DB 02941

Regulatory Information

Model 3165NGW CNE COMISION NACIONAL DE COMUNICACIONES CNCID: C-14446

Due to the very small size of the 3168NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable. Japan: Model 3168NGW

5.264287 — DB 27 ARBRIAPE SM PAUSE MES SIBS ER [R] 003-160024

D | (Except communicate to high power radio)

[Software Version JL'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions ] [ Maximum Power Output ]

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 3168NGW CN O COMISION NACIONAL DE COMUNICACIONES CNCID: C-16378

Due to the very small size of the 7265D2W/7265NGW (12x16), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

52h NT — PME AT AIMNIAPE EI PNE ITS DIS ER [R] 003-140134

5.15-5.35GHz: Indoor use only

D | (Except communicate to high power radio)

Model 7265D2W CNE COMISION NACIONAL DE COMUNICACIONES CNC ID: C-13902

Intel® Wireless Gigabit Sink W13100

Due to the very small size of the 13100NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

[ Software Version |] Intel® Wireless Dock Manager 3.x and previous versions |

[Maximum Power Output ]

(57 - 64 GHz) 25 dBm EIRP max 1EEE802.11 ad mode

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Complies with IDA Standards DB 02941

Intel® Tri-Band Wireless-AC 17265

Due to the very small size of the 17265NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Model 17265NGW Software Version Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions (WiFi/ BT) Intel® Wireless Dock Manager 3.x and previous versions (WiGig) [ Maximum Power Output (2400 - 2483.5 MHz) 20dBm EIRP max (100mW) 1EEE802.11 b/g/n mode Bluetooth (2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE (5150 - 5725 MHz) 23dBm EIRP max (200mW) 1EEE802.11 a/n/ac mode | The low band 5.15 - 5.35 GHz is for indoor use only (5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver (57 - 64 GHz) 25 dBm EIRP max 1EEE802.11 ad mode

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Complies with IDA Standards DB 02941

Intel® Dual Band Wireless-AC 8260

Due to the very small size of the 8260D2W (12x16), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

USA: Model 8260D2W, FCC ID: PD98260D2 (FCC 1D without suffix "U" denotes factory installation only);

FCC ID: PD98260D2U (FCC 1D with suffix “U” denotes user installation or replacement permitted and supported by bios locking feature) Canada:

Model 8260D2W IC: 1000M-8260D2 Japan:

RS (Except communicate to high power radio)

Regulatory Information

Due to the very small size of the 8260NGWH/8260NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

DL | (Except communicate to high power radio)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Model 8260NGWH

SAME ÈS — PME AT AIMER ISA PAE ES BIS EIRC [R] 003-150154

DL | (Except communicate to high power radio)

Intel® Dual Band Wireless-AC 8265

Due to the very small size of the 8265NGW (22mm x 30mm x 2.4mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

USA: Model 8265NGW + FCC ID: PD98265NG (FCC 1D without suffix "U" denotes factory installation only) + FCC ID: PD98265NGU (FCC ID with suffix “U” denotes user installation or replacement permitted and supported by BIOS locking feature)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

SE (Except communicate to high power radio)

Model 8265NGW/8265D2W

[Software Version JL'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions

[ regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

[ Maximum Power Output (2400 - 2483.5 MHz) 20dBm EIRP max (100mW) 1EEE802.11 b/g/n mode Bluetooth (2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE (5150 - 5725 MHz) 23dBm EIRP max (200mW) 1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only (5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver (57 - 64 GHz) 25 dBm EIRP max 1EEE802.11 ad mode

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Singapore:

Model 8265NGW Complies with IDA Standards DB 02941

Pakistan: Model 8265NGW

“PTA APPROVED MODEL"

Due to the very small size of the 8265D2W (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

LL (Except communicate to high power radio)

Regulatory Information

Model 8265D2W Brazil:

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Singapore:

Model 8265D2W Complies with IDA Standards DB 02941

Pakistan: Model 8265D2W “PTA APPROVED MODEL"

Intel® Wireless-AC 9260 (9260NGW)

Due to the very small size of the 9260NGW (22mm x 30mm x 2.4mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

(5725 - 5875 MHz) 1EEE802.11 a/n/ac mode

13.98 dBm EIRP Max (25mW) For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9260NGW Singapore:

Model 9260NGW Complies with

IMDA Standards DB02941

Intel® Wireless-AC 9260 (9260D2WL)

Due to the very small size of the 9260D2WL (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

USA: Model 9260D2WL FCC ID: PD99260D2L Canada: Model 9260D2WL IC: 1000M-9260D2L Japan: Model 9260D2WL + _RF: 003-190024 + TEL: D190023003

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

5.15-5.35GHz: Indoor use only EE (Except communicate to high power radio)

[ Software Version JL 'ntel@ PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9260D2WL Brazil:

Regulatory Information

Model 9260D2WL ANATEL: 05831-17-04423 Singapore:

Model 9260D2WL Complies with IMDA Standards DB02941

Due to the very small size of the 9461NGW (22mm x 30mm x 2.4mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

52642 8427 — 28227 ARBRIAPE HIS PAU E MIE T SIBS ER

5.15-5.35GHz: Indoor use only

DL | (Except communicate to high power radio)

[Software Version [L'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information | 1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9461NGW Singapore:

Model 9461NGW Complies with IMDA Standards DB02941

Intel® Wireless-AC 9461 (9461D2W)

Due to the very small size of the 9461D2W (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

5.264247 — DB 27 ARBRIAPE HIS PARUS E MIE T SBS ER [R] 003-170203

5.15-5.35GHz: Indoor use only

LL | (Except communicate to high power radio)

[ Software Version JL 'ntel@ PROSet/ Wireless WiFi Software 20.x and subsequent versions

[ Maximum Power Output

(2400 - 2483.5 MHz) 20dBm EIRP max (100mW) 1EEE802.11 b/g/n mode Bluetooth

(2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE

Regulatory Information

(5150 - 5725 MHz) 23dBm EIRP max (200mW)

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9461D2W Singapore:

Model 9461D2W Complies with IMDA Standards DB02941

Intel® Wireless-AC 9462 (9462NGW)

Due to the very small size of the 9462NGW (22mm x 30mm x 2.4mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

L (Except communicate to high power radio)

[Software Version [L'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

Regulatory Information

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9462NGW Singapore:

Model 9462NGW Complies with

IMDA Standards DB02941

Intel® Wireless-AC 9462 (9462D2W)

Due to the very small size of the 9462D2W (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

LL | (Except communicate to high power radio)

[Software Version JL'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions

[ Maximum Power Output

(2400 - 2483.5 MHz) 1EEE802.11 b/g/n mode

20dBm EIRP max (100mW)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

| Bluetooth I (2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE (5150 - 5725 MHz) 23dBm EIRP max (200mW) 1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only (5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9462D2W Singapore:

Model 9462D2W Complies with IMDA Standards DB02941

Intel® Wireless-AC 9560 (9560NGW)

Due to the very small size of the 9560NGW (22mm x 30mm x 2.4mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Model 9560NGW FCC ID: PD99560NG Canada:

Regulatory Information

DL | (Except communicate to high power radio)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

| Software Version ]L_'ntel® PROSet/ Wireless WiFi Software 20.x and subsequent versions | [ Maximum Power Output |

(2400 - 2483.5 MHz) 20dBm EIRP max (100mW)

1EEE802.11 a/n/ac mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9560NGW Singapore:

Model 9560NGW Complies with

IMDA Standards DB02941

Intel® Wireless-AC 9560 (9560D2W)

Due to the very small size of the 9560D2W (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

LL | (Except communicate to high power radio)

Model 9560D2W CMIIT ID: 2017AJ7598 (M)

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9560D2W Singapore:

Model 9560D2W Complies with IMDA Standards DB02941

Intel® Wireless-AC 9560 (9560D2WL)

Due to the very small size of the 9560D2WL (12mm x 16mm x 1.8mm), the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

DL | (Except communicate to high power radio)

1EEE802.11 a/n/ac mode || The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 9560D2WL Singapore:

Model 9560D2WL Complies with IMDA Standards DB02941

Intel® Tri-band Wireless AC 18265

Due to the very small size of the 18265NGW module, the regulatory marking has been placed in this user manual because the product label on the device is considered too small to be readable

USA: Model 18265NGW, FCC ID: PD918265NG (This module is for factory installation only) Canada: Model 18265NGW

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions (WiFi/ BT) Intel® Wireless Dock Manager 3.x and previous versions (WiGig)

23dBm EIRP max (200mW) The low band 5.15 - 5.35 GHz is for indoor use only

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver (57 - 64 GHz) 25 dBm EIRP max

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 18265NGW Complies with IDA Standards DB 02941

Intel® Wireless Gigabit 11000

Due to the very small size of the 11000D2W/11000D2W LC, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

Model 11000D2W Singapore:

Model 11000D2W/11000D2W LC Complies with IDA Standards DB 02941

Intel® Wireless Gigabit Sink W13110VR Due to the very small size of the 13110NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

[Software Version || Intel® Wireless VR dashboard 4.x | [ Maximum Power Output ]

(57 - 64 GHz) 25 dBm EIRP max 1EEE802.11 ad mode

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 13110NGW Complies with

IMDA Standards DB02941

Intel® Wireless Gigabit 11100VR Due to the very small size of the 11100D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model 11100D2W Singapore:

Model 11100D2W Complies with IMDA Standards DB02941

Intel® Wi-Fi 6 AX101 (AX101NGW)

Due to the very small size of the AX101NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

TBD Intel® Wi-Fi 6 AX101 (AX101D2W)

Due to the very small size of the AX101D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

TBD Intel® Wi-Fi 6 AX200 (AX200D2WL)

Due to the very small size of the AX200D2WL, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

FR (Except communicate to high power radio)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

R-C-INT-AX200D2WL Taiwan:

Model AX200D2WL GccariocPo720To

Software 20.x and subsequent versions

The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 1EEE802.11 a/n/ac/ax mode

13.98 dBm EIRP Max (25mW)

For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Regulatory Information

Model AX200D2WL Complies with IMDA Standards DB02941

Due to the very small size of the AX200NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

5.15-5.35GHz: Indoor use only Rs (Except communicate to high power radio)

Model AX200NGW R-C-INT-AX200NGW Taiwan:

Model AX200NGW GccaHiocP085070

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

[Software Version JL Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

(2400 - 2483.5 MHz) 20dBm EIRP max (100mW)

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX200NGW Brazil:

Model AX200NGW Complies with IMDA Standards DB02941

Regulatory Information Argentina:

Model AX200NGW CN O COMISION NACIONAL DE COMUNICACIONES CNC ID: C-22838

Pakistan: Model AX200NGW APPROVED BY PTA: 9.9211/2019

Intel® Wi-Fi 6 AX201 (AX201NGW) Due to the very small size of the AX201NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be

readable. USA: Model AX201NGW FCC ID: PD9AX201NG Canada: Model AX201NGW IC: 1000M-AX201NG Japan: Model AX201NGW

+ _RF: 003-180232 + TEL: D180131003

DL | (Except communicate to high power radio)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Model AX201NGW R-C-INT-AX201NGW Taiwan:

Model AX201NGW GcAH st Ps52072

[Software Version ]_ Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Regulatory Information

Model AX201NGW ANATEL: 06970-18-04423 Singapore:

Model AX201NGW Complies with IMDA Standards DB02941

Due to the very small size of the AX201D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information Model AX201D2W

5.264247 — DB 27 ARBBRIAPE SM PAUSE MES SIBS ER [R] 003-180233

LL (Except communicate to high power radio)

Model AX201D2W R-C-INT-AX201D2W Taiwan:

[Software Version ]L Intel® PROSet/ Wireless WiFi Software 20.x and subsequent versions [ Maximum Power Output

(2400 - 2483.5 MHz) 20dBm EIRP max (100mW) 1EEE802.11 b/g/n/ax mode

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

| Bluetooth I (2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE (5150 - 5725 MHz) 23dBm EIRP max (200mW) 1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only (5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX201D2W Brazil:

Model AX201D2W ANATEL: 07039-18-04423 Singapore:

Model AX201D2W Complies with IMDA Standards DB02941

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Model AX201D2W APPROVED BY PTA: 9.9115/2019

Intel® Wi-Fi 6 AX201 (AX201D2WL)

Due to the very small size of the AX201D2WL, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

DL | (Except communicate to high power radio)

Regulatory Information

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Model AX201D2WL Complies with

IMDA Standards DB02941

Model AX201D2WL CN o COMISIÔN NACIONAL DE COMUNICACIONES CNCID: C-22504

Pakistan: Model AX201D2WL APPROVED BY PTA: 9.9110/2019

Intel® Wi-Fi 6 AX203 (AX203NGW)

Due to the very small size of the AX203NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Korea:

Model AX203NGW R-C-INT-AX203NGW

7} & 2 INTEL CORPORATION

Model AX203NGW CMIIT ID:

202047115321 A) Europe:

[Software Version ]L Intel® PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Australia:

Model AX203NGW Brazil:

Model AX203NGW TBD Singapore:

Model AX203NGW Complies with

IMDA Standards DB02941

Model AX203NGW LI RAMATEL C-25825 Pakistan:

Model AX203NGW PTA APPROVED BY PTA: 9.162/ 2021

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Intel® Wi-Fi 6 AX203 (AX203D2W)

Due to the very small size of the AX203D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

[Software Version JL 1ntel® PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX203D2W Brazil:

Model AX203D2W TBD Singapore:

Model AX203D2W Complies with IMDA Standards D802941

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Model AX203D2W RAMATEL C-25827

Model AX203D2W APPROVED BY PTA: 9.158/ 2021

Intel® Wi-Fi 6 AX204 (AX204NGW) Due to the very small size of the AX203NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be

TBD Intel® Wi-Fi 6 AX204 (AX204D2W) Due to the very small size of the AX203D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be

TBD Intel® Wi-Fi 6E AX210 (AX210NGW) Due to the very small size of the AX210NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be

pr] (Except communicate to high power radio) L TID200188003

[ Software Version JL 'ntel@ PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 23 dBm EIRP max (200mW)

1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX210NGW Complies with IMDA Standards

Due to the very small size of the AX210D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

RS (Except communicate to high power radio)

Regulatory Information

Model AX210D2W CMIIT ID: 2020A/J15108(M) Europe:

[ Software Version JL 'ntel@ PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 23 dBm EIRP max (200mW)

1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Complies with IMDA Standards

Due to the very small size of the AX211NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

[Software Version ]L1ntel® PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode || The low band 5.15 - 5.35 GHz is for indoor use only

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver (5925 - 6425 MHz) 23 dBm EIRP max (200mW)

1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX211NGW TBD Singapore:

Model AX211NGW Complies with

IMDA Standards DB02941

Model AX211NGW TBD Pakistan:

Due to the very small size of the AX211D2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

[ Software Version JL'ntel@ PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

(2400 - 2483.5 MHz) 20dBm EIRP max (100mW)

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode || For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 23 dBm EIRP max (200mW)

1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Model AX211D2W Brazil:

Model AX211D2W TBD Singapore:

Model AX211D2W Complies with

IMDA Standards DB802941

Due to the very small size of the AX211D2WH, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Europe: [Software Version JL 1ntel® PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output (2400 - 2483.5 MHz) 20dBm EIRP max (100mW) 1EEE802.11 b/g/n/ax mode Bluetooth (2400 - 2483.5 MHz) 10dBm EIRP max (10mW) BLE (5150 - 5725 MHz) 23dBm EIRP max (200mW) 1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only (5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW) 1EEE802.11 a/n/ac/ax mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver (5925 - 6425 MHz) 23 dBm EIRP max (200mW) 1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Complies with IMDA Standards

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

APPROVED BY PTA: 9.805/ 2022

Due to the very small size of the AX211D2WL, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

Regulatory Information

Model AX211D2WL TBD Europe:

[ Software Version JL 'ntel@ PROSet/ Wireless WiFi Software 22.x and subsequent versions [ Maximum Power Output

1EEE802.11 a/n/ac/ax mode | The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 13.98 dBm EIRP Max (25mW)

1EEE802.11 a/n/ac/ax mode For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 23 dBm EIRP max (200mW)

1EEE802.11ax The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

Model AX211D2WL Complies with IMDA Standards D802941

Model AX211D2WL LI RAMATEL C-26123 Pakistan:

Due to the very small size of the AX411NGW, the marking has been placed in this user manual because the product label on the device is considered too small to be readable.

[Software Version [L'ntel® PROSet/ Wireless WiFi Software 22.x and subsequent versions ] [Maximum Power Output

Regulatory Information

10dBm EIRP max (10mW)

23dBm EIRP max (200mW) The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 1EEE802.11 a/n/ac/ax mode

13.98 dBm EIRP Max (25mW) For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 1EEE802.11ax

23 dBm EIRP max (200mW) The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

Intel® Wi-Fi 6E AX411 (AX411E2W)

Due to the very small size of the AX411E2W, the marking has been placed in this user manual because the product label on the device is considered too small to be readable

JL Intel® PROSet/ Wireless WiFi Software 22.x and subsequent versions

23dBm EIRP max (200mW) The low band 5.15 - 5.35 GHz is for indoor use only

(5725 - 5875 MHz) 1EEE802.11 a/n/ac/ax mode

13.98 dBm EIRP Max (25mW) For the standard EN 300 440, the device operating in 5.8 GHz is considered a category 2 receiver

(5925 - 6425 MHz) 1EEE802.11ax

23 dBm EIRP max (200mW) The band 5.925 - 6.425GHz is for LPI (Low Power in-door)

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

This equipment complies with the essential requirements of the European Union directive 2014/53/EU.

INFORMATION FOR OEMS and HOST INTEGRATORS The guidelines described within this document are provided to OEM integrators installing Intel® wireless adapters in notebook and tablet PC host platforms. Adherence to these requirements is necessary to meet the conditions of compliance with FCC rules, including RF exposure. When all antenna type and placement guidelines described herein are fulfilled the Intel® wireless adapters may be incorporated into notebook and tablet PC host platforms with no further restrictions. 1f any of the guidelines described herein are not satisfied it may be necessary for the OEM or integrator to perform additional testing and/or obtain additional approval. The OEM or integrator is responsible to determine the required host regulatory testing and/or obtaining the required host approvals for compliance. If needed, please contact the applicant/grantee (Intel) regarding detailed information on how to setup the device for any compliance testing that the OEM integrator is responsible per KDB 996369 DO4

Intel® wireless adapters are intended for OEMs and host integrators only.

The Intel® wireless adapter FCC Grant of Authorization describes any limited conditions of modular approval.

The Intel® wireless adapters must be operated with an access point that has been approved for the country of operation.

Changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties is not permitted. Any changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties will void authorization to operate the adapter.

Antenna Type and Gains

Antenna | Antenna 2.4GHz 5.2GHz 5.5GHz 5.7GHz 6.2GHz 6.5GHz 6.7GHz 7GHz Peak Type Location Peak Gain Peak Gain Peak Gain Peak Gain Peak Gain Peak Gain in Peak Gain in Gain in (Main/ Aux) in dBi* in dBi* in dBi* in dBi* in dBi* dBi* dBi* dBi* PIFA Î Main ] Î Î | ] Ï Ï Î ] [ AUX Î 3.24 Î 3.73 I 4.77 I 4.77 Î 4.83 I 4.30 I 5.37 L_s5 | RC | Î Ï Ï Î Î Î Ï ]

Antenna Type and Gains for AX211D2WH Only

Antenna | Antenna 2.4GHZ | 2.43GHz | 2.47GHz | 2.483GHz | 5.2GHz | 5.4GHz | 5.6GHz | 5.8GHz | 6.2GHz | 6.5GHz | 6.6GHz | 7GHz Type Location Peak Peak Peak Peak Peak Peak Peak Peak Peak Peak Peak Peak (Main/ Aux) | Gainin | Gainin Gain in Gain in Gainin | Gainin Gainin | Gainin | Gainin | Gainin Gainin | Gain dBi* dBi* dBi* dBi* dBi* dBi* dBi* dBi* dBi* dBi* dBi* in dBi* C_PIFA J Main/aux | 5.99 | 6.23 | 6.4 | 615 | 8 {| 8o7 | 819 | 839 | 7.88 | 81 | 775 {|| 8.08

*AIl antenna gains include cable loss.

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information Simultaneous Transmission of Intel® Wireless Adapters with Other Integrated or Plug-In Transmitters

Based upon FCC Knowledge Database publication number 616217, when there are multiple transmitting devices installed in a host device, an RF exposure transmitting assessment shall be performed to determine the necessary application and test requirements. OEM integrators must identify all possible combinations of simultaneous transmission configurations for all transmitters and antennas installed in the host system. This includes transmitters installed in the host as mobile devices (>20 cm separation from user) and portable devices (<20 cm separation from user). OEM integrators should consult the actual FCC KDB 616217 document for all details in making this assessment to determine if any additional requirements for testing or FCC approval is necessary.

Antenna Placement Within the Host Platform

Any separation distances less than those shown will require additional evaluation and FCC authorization. For WiFi/Bluetooth combination adapters it is recommended that a 5 cm separation distance between transmitting antennas be provided within the host system to maintain

an adequate separation ratio for simultaneous WiFi and Bluetooth transmission. For less than 5 cm separation the separation ratio must be verified according to FCC publication KDB 447498 for the specific adapter.

[Wireless Adapter Ï Minimum required antenna-to-user separation distance ] [intel® Centrino® Wireless-N 100 I 9 mm ] [intel® Centrino® Wireless-N 105 I 9 mm ] [intel® Centrino® Wireless-N 130 I 8 mm ] [Lintel® Centrino® Wireless-N 135 I 9 mm ] [intel® Centrino® Wireless-N 1000* (Il 20 mm ] [intel® Centrino® Wireless-N 1030 (Il 8 mm ] L'intel® Centrino® Wireless-N 2200 I 9 mm ] ['intel® Centrino® Wireless-N 2230 I 6 mm ] [L'intel® Centrino® Advanced-N 6200* I 20 mm ] [L'intel® Centrino® Advanced-N 6205 I 12 mm ] L'intel® Centrino® Advanced-N 6230 I 12 mm ] [Lintel® Centrino® Advanced-N 6235 I 8 mm ] [intel® Centrino® Ultimate-N 6300 I 13 mm ] ['intel® Dual Band Wireless-AC 7260 I 8 mm ] [intel® Dual Band Wireless-N 7260 l 8 mm ] [Lintel® Wireless-N 7260 I 8 mm ] ['intel® Dual Band Wireless-AC 3160 I 8 mm ] ['intel® Dual Band Wireless-AC 3165 I 8 mm ] [intel® Dual Band Wireless-AC 7265 I 8 mm ] [ntel® Dual Band Wireless-N 7265 (Il 8 mm ] [intel® Wireless-N 7265 (Il 8 mm ] ['intel® Dual Band Wireless-AC 8260 I 8 mm ] ['ntel® Dual Band Wireless-AC 8265 I 8 mm ] ['intel® Wireless-AC 9260 I 14 mm ] ['intel® Wireless-AC 9461 (9161NGW) Î 19 mm |

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

['intel® Wireless-AC 9461 (9161D2W) I 12 mm | L'intel® Wireless-AC 9462 (9162NGW) Î 14 mm ] ['intel® Wireless-AC 9462 (9162D2W) Î 15 mm ] ['intel® Wireless-AC 9560 (9560NGW) I 18 mm ] ['intel® Wireless-AC 9560 (9560D2W) Î 15 mm | ['intel® Wireless-AC 9560 (9560D2WL) I 15 mm | ['intel® Tri-Band Wireless-AC 17265 I 8 mm ] ['intel® Tri-Band Wireless-AC 18260 I 8 mm ] [intel® Tri-Band Wireless-AC 18265 I 8 mm ] [intel® Wireless Gigabit Sink W13100 I 8 mm ] [Lintel® Wireless Gigabit 11000 I 8 mm ] [Lintel® Wireless Gigabit Sink W13110VR I 8 mm ] ['intel® Wireless Gigabit 11100VR I 8 mm ] ['intel® Wi-Fi 6E AX101 (AX10INGW) I 30 mm ] [Lintel@® Wi-Fi 6E AX101 (AX101D2W) Î 27 mm | [intel® Wi-Fi 6 AX200 (AX200NGW) Î 18 mm ] L'intel® Wi-Fi 6 AX200 (AX200D2WL) Î 19 mm ] L'intel® Wi-Fi 6 AX201 (AX201D2W) Î 12 mm | L'intel® Wi-Fi 6 AX201 (AX201D2WL) Î 15 mm | L'intel® Wi-Fi 6 AX201 (AX201NGW) Î 17 mm ] L'intel® Wi-Fi 6E AX203 (AX203NGW) Î 28 mm ] ['intel® Wi-Fi 6E AX203 (AX203D2W) I 30 mm ] ['intel® Wi-Fi 6E AX204 (AX204NGW) I 14 mm ] [Lintel@® Wi-Fi 6E AX204 (AX204D2W) Î 19 mm | ['intel® Wi-Fi 6E AX210 (AX210NGW) I 13 mm | ['intel@® Wi-Fi 6E AX210 (AX210D2W) I 17 mm | ['intel® Wi-Fi 6E AX211 (AX211NGW) Î 14 mm | [Lintel@® Wi-Fi 6E AX211 (AX211D2W) Î 14 mm ] L'intel® Wi-Fi 6E AX211 (AX211D2WH) Î >20 cm ] L'intel® Wi-Fi 6E AX211 (AX211D2WL) Î 15 mm ] L'intel® Wi-Fi 6E AX411 (AX41INGW) Î 15 mm ] L'intel® Wi-Fi 6E AX411 (AX411E2W) Î 15 mm ] [ * This wireless adapter may be installed in mobile devices only (requires > 20 cm antenna separation from the body of user) ]

Additional regulatory authorization process may be required if wishing to place the 60 GHz/802.11ad RFEM (antenna array) closer than 20 cm to the user.

Information To Be Supplied to the End User by the OEM or Integrator

The wireless adapter must be installed and used in strict accordance with the manufacturer's instructions as described in the user documentation that comes with the product. For country-specific approvals, see Radio Approvals. Intel Corporation is not responsible for any radio or television interference caused by unauthorized modification

regs.htm[8/25/2022 4:59:25 PM]

Regulatory Information

of the devices included with the wireless adapter kit or the substitution or attachment of connecting cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these guidelines.

RÉEL SBCÉHA ACER A RUE ARE DEATÈMA TURN ILERNEÉ MÉHLE EEAU RTE S RÉ L'ILE RATER TEE DUO Local Restriction of 802.11a, 802.11b, 802.119, 802.11n, and 802.11ad Radio Usage

The following statement on local restrictions must be published as part of the compliance documentation for all 802.11a, 802.11b, 802.119, 802.11n, and 802.11ad products.

À Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.119, 802.11n, and 802.11ad wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.119 and 802.11n products are designed for use only in specific countries, and are not allowed to be operated in countries other than those of designated use. As a user of these products, you are responsible for ensuring that the products are used only in the countries for which they were intended and for verifying that they are configured with the correct selection of frequency and channel for the country of use. Any deviation from permissible settings and restrictions in the country of use could be an infringement of national law and may be punished as such.

Statements of European Compliance

Each of the adapters listed below comply with the essential requirements of the European Union directive 2014/53/EU.

+ Intel® Centrino® Wireless-N 100

+ Intel® Wireless Gigabit Sink W13100

+ Intel® Wireless Gigabit Sink W13110VR + Intel® Wireless Gigabit 11100VR

Regulatory Information

Intel® Wi-Fi 6 AX101 Intel® Wi-Fi 6 AX200 Intel® Wi-Fi 6 AX201 Intel® Wi-Fi 6 AX203 Intel® Wi-Fi 6 AX204 Intel® Wi-Fi 6E AX210 Intel® Wi-Fi 6E AX211 Intel® Wi-Fi 6E AX411

Trademarks and Disclaimers

regs.htm(8/25/2022 4:59:25 PM]

This section provides specification information for the family of Intel® wireless adapters. The following list may not be all inclusive.

[ Form Factor I PCI Express* Half-Mini Card

specs.htm[8/25/2022 4:59:28 PM]

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm) Antenna Interface Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 Connector [ Antenna Diversity I On-board diversity ] Connector 52-pin Mini Card edge connector Interface [ Voltage L33V ] Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 95% non-condensing (at temperatures of 25 °C to 35 °C) ] [WiFi ] Frequency 2.4 GHz (802.11b/g/n) Modulation

2.4 GHZ ISM: Orthogonal Frequency Division Multiplexing (OFDM)

Infrastructure or ad hoc (peer-to-peer) operating modes

WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP

EAP-AKA Product Safety

JL PCI Express* Mini Card and Half-Mini Card

JL 1intel® Centrino® Wireless-N 1000 - 1X2 MC/HMC Dimensions

Mini Card: Width 2.0 in x Length 1.18 in x Height 0.18 in (50.80 mm x 30 mm x 4.5 mm)

Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm)

Antenna Interface Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

|] I 52-pin Mini Card edge connector L33V

Operating Temperature

0 to +80 degrees Celsius

I 50% to 90% non-condensing (at temperatures of 25 °C to 35 °C)

Frequency Modulation

Il BPSK, QPSK, 16 QAM, 64 QAM, CCK, DQPSK, DBPSK Wireless Medium

I 2.4 GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

Channels Il All channels as defined by the relevant specification and country rules.

IEEE 802.11n Data 300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, Rates 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.119 Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps

Wi-Fi Alliance* certification

Wi-Fi* certification for 802.11b, 802.119, 802.11n, WPA-Personal, WPA-Enterprise,

WPA2-Personal, WPA2-Enterprise, WMM, WPS Cisco Compatible

Extensions certification

Cisco Compatible Extensions, v4.0

2230 [ Form Factor I PCI Express* Half-Mini Card ] Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x

specs.htm[8/25/2022 4:59:28 PM]

Antenna Interface | Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity I On-board diversity

Connector 52-pin Mini Card edge connector

[ Voltage 33 V Operating 0 to +80 degrees Celsius

(Adapter Shield) [Humidity 150% to 95% non-condensing (at temperatures of 25 C to 35 °C) [WiFi

Frequency 2.4 GHz (802.11b/g/n)

Modulation [ Frequency band |] 2.400 - 2.4835 GHz (dependent on country) ] [_ Modulation JL BPSK, QPSK, 16 QAM, 64 QAM Ï| CCK, DOPSK, DBPSK ] [ Wireless Medium I 2.4 GHZ ISM: Orthogonal Frequency Division Multiplexing (OFDM) ] [ Channels I All channels as defined by the relevant specification and country rules. ]

[ Form Factor I PCI Express* Half-Mini Card Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm)

I Infrastructure or ad hoc (peer-to-peer) operating modes

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm) Antenna Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 Interface Connector Antenna On-board diversity Diversity Network 802.11a/b/g/n and Bluetooth 4.0 Standards Connector 52-pin Mini Card edge connector Interface [ Voltage 13.3 V Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 95% non-condensing (at temperatures of 25 °C to 35 °C) Frequency 5 GHz (802.11a/n) 2.4 GHz (802.11b/ g/n)

Frequency 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country) band [ Modulation || BPSK, QPSK, 16 QAM, 64 QAM JL CCK, DQPSK, DBPSK Wireless 5 GHz UNIT: Orthogonal Frequency Division 2.4 GHZ ISM: Orthogonal Frequency Division Medium Multiplexing (OFDM) Multiplexing (OFDM) [ Channels Î All channels as defined by the relevant specification and country rules. IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11b 11, 5.5, 2, 1 Mbps Data Rates [ Bluetooth ]_ Bluetooth Version 4.0 (3.0 +HS ) [ General

specs.htm[8/25/2022 4:59:28 PM]

Operating Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (32-bit and

Architecture I Infrastructure or ad hoc (peer-to-peer) operating modes

[ Form Factor I PCI Express* Half-Mini Card Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm) Antenna Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 Interface Connector Antenna On-board diversity Diversity Connector 52-pin Mini Card edge connector Interface [ Voltage L33V Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity Ï 50% to 95% non-condensing (at temperatures of 25 2C to 35 °C)

Infrastructure or ad hoc (peer-to-peer) operating modes

WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-

AKA Product Safety ]

UL, C-UL, CB (IEC/EN 60950-1)

System Profile Feature set

Operating + Microsoft Windows* XP (32-bit and 64-bit) Systems + Windows Vista* (32-bit and 64-bit) + Windows* 7 (32-bit and 64-bit) + Windows* 8 (32-bit and 64-bit) + Windows* 8.1 (32-bit and 64-bit) Standard 802.16e-2005 Corrigenda 2 (D4) Compliance WiMAX Intel® Centrino® Wireless-N + WiMAX 6150:

Mobile WiMAX release 1, Wave 11. Supports 3A and 14/B profiles

Form Factor Intel® Centrino® Advanced-N 6200, Intel® Centrino® Ultimate-N 6300: PCI Express* Full-Mini Card and Half-Mini Card. Intel® Centrino® Advanced-N 6205: PCI Express* Half-Mini Card.

Dimensions Full-Mini Card: Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm) Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm)

Antenna Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna On-board diversity

Connector 52-pin Mini Card edge connector

[ Voltage L33V Operating 0 to +80 degrees Celsius

[ Humidity I 50% to 95% non-condensing (at temperatures of 25 2C to 35 °C) ] Frequency 5 GHz (802.11a/n) 2.4 GHz (802.11b/ g/n)

Modulation Frequency 5.15 GHz - 5.85 GHz (dependent on 2.400 - 2.4835 GHz (dependent on country) band country)

[ Modulation JL BPSK, QPSK, 16 QAM, 64 QAM JL CCK, DQPSK, DBPSK ] Wireless 5 GHz UNIT: Orthogonal Frequency Division 2.4 GHz ISM: Orthogonal Frequency Division Medium Multiplexing (OFDM) Multiplexing (OFDM)

[ Channels I All channels as defined by the relevant specification and country rules. ] IEEE 802.11n Intel® Centrino® Ultimate-N 6300:

[ Product Safety ]] UL, C-UL, CB (IEC/EN 60950-1)

Intel® Dual Band Wireless-AC 7260

[ Form Factors I Half-Mini Card and M.2 (Next Generation Form Factor - NGFF) ]

[ Electrical interfaces Ï PCle and USB 2.0 for both form factors ]

| Antenna Interface | Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 |

specs.htm[8/25/2022 4:59:28 PM]

I On-board diversity

5GHZ UNII: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

Intel® Dual Band Wireless-AC 7260: 2 X 2

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b Data Rates

Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the following adapters + Model 7260HMW + Model 7260NGW General

Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (64- bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

]L.64-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* Encryption and Authentication

PCle, USB 2.0 for both form factors

Antenna Interface Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

+ Model 7260HMW BN - 802.11agn, 2x2, Bluetooth 4.0, PCle, USB, M.2 -< Model 7260NGW BN - 802.11bgn, 2x2, Bluetooth 4.0, PCIe, USB, M.2

Operating Temperature (Adapter Shield)

0 to +80 degrees Celsius

50% to 95% non-condensing (at temperatures of 25 °C to 35 °C)

Frequency Modulation (See above, not all bands supported by all adapters)

5GHz (802.11a/n) 2.4GHz (802.11b/g/n)

5GHZ UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

802.11n spatial streams

All adapters: 2 X 2 spatial streams

All data rates are theoretical maximums.

Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the

Windows* 7 (32-bit and 64-bit), Windows 8 (32-bit and 64-bit), Windows* 8.1 (64- bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Î Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

JL 64-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* Encryption and Authentication

JL UL, C-UL, CB (IEC/EN 60950-1)

Intel® Dual Band Wireless-AC 3160

Form Factors I Half-Mini Card and M.2 (Next Generation Form Factor - NGFF)

Electrical interfaces I PCle and USB 2.0 for both form factors

Antenna Interface Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity I On-board diversity

5GHZ UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

specs.htm[8/25/2022 4:59:28 PM]

[_ Spatial streams [L1ntel® Dual Band Wireless-AC 3160: 1 X 1 [ Data Rates I All data rates are theoretical maximums. IEEE 802.11ac Data Intel® Dual Band Wireless-AC 3160: Up to 433 Mbps Rates IEEE 802.11n Data Tx/Rx (Mbps): 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, Rates 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates IEEE 802.119 Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates IEEE 802.11b Data 11, 5.5, 2, 1 Mbps Rates Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the

+ Model 3160HMW + Model 3160NGW

[ Operating Systems I Windows* 7 (32-bit and 64-bit), Windows 8 (32-bit and 64-bit), Windows* 8.1 (64-bit) Wi-Fi Alliance* Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, certification Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Cisco Compatible Cisco Compatible Extensions, v4.0 Extensions certification [ Security [ Authentication Î WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA Authentication PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2 Protocols

[Encryption ]L64-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Encryption and Authentication

UL, C-UL, CB (IEC/EN 60950-1)

[ Form Factors I M.2 (Next Generation Form Factor - NGFF) [ Electrical interfaces I PCle and USB 2.0 Antenna Interface Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 Connector [ Antenna Diversity Î On-board diversity IEEE 802.11 802.11abgn, 802.11ac, 802.11d, 802.11e, 802.11i, 802.11h, 802.11w Networking Standards Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C)

specs.htm[8/25/2022 4:59:28 PM]

Frequency Modulation

5GHZ UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

Intel® Dual Band Wireless-AC 3165: 1 X 1

All data rates are theoretical maximums.

Intel® Dual Band Wireless-AC 3165: Up to 433 Mbps

Tx/Rx (Mbps): 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (64- bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Encryption and Authentication

[ Encryption ]L 54-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Product Safety

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

]L On-board diversity

| Standards | Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C) Frequency 5GHz (802.1lac/n) 2.4GHz (802.11b/ g/n)

5GHZ UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

I All channels as defined by the relevant specification and country rules.

[Intel® Dual Band Wireless-AC 3168: 1 X 1

I All data rates are theoretical maximums.

Intel® Dual Band Wireless-AC 3168: Up to 433 Mbps

Tx/Rx (Mbps): 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

I Linux, Windows* 8.1 (64-bit), Windows* 10 (64-bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

I Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Encryption and Authentication

[_Encryption ] 54-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Product Safety

[ Electrical interfaces

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

5GHZ UNII: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

Intel® Dual Band Wireless-AC 7265: 2 X 2

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b Data Rates

Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the following adapters + Model 7265NGW General

Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (64- bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

[_Encryption 1. 64-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Specifications

Encryption and Authentication

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

-< Model 7265NGW BN - 802.11bgn, 2x2, Bluetooth 4.0, PCIe, USB, M.2

Operating Temperature (Adapter Shield)

0 to +80 degrees Celsius

50% to 90% non-condensing (at temperatures of 25 2C to 35 °C)

Frequency Modulation (See above, not all bands supported by all adapters)

5GHZ UNIT: Orthogonal Frequency Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

802.11n spatial streams

All adapters: 2 X 2 spatial streams

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the

+ Model 7265NGW AN + Model 7265NGW NB + Model 7265NGW BN

2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

[ General Operating Systems Windows* 7 (32-bit and 64-bit), Windows 8 (32-bit and 64-bit), Windows* 8.1 (64- bit) Wi-Fi Alliance* Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS certification 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Cisco Compatible Cisco Compatible Extensions, v4.0 Extensions certification

[ Security Authentication WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP- AKA ['Authentication Protocols ]] PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2

[_Encryption ]L64-bit and 128-bit WEP, AES-CCMP, TKIP Wi-Fi Direct* Encryption WPA2, AES-CCMP and Authentication

Product Safety Ï UL, C-UL, CB (IEC/EN 60950-1)

Intel® Dual Band Wireless-AC 8260

[ Form Factors Ï Half-Mini Card and M.2 (Next Generation Form Factor - NGFF) [ Electrical interfaces I PCle and USB 2.0 for both form factors Antenna Interface Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066 Connector

IEEE 802.11 Intel® Dual Band Wireless-AC 8260 Networking Standards + Model 8260NGW - 802.11agn, ac, 2x2, Bluetooth 4.0, PCIe, USB, M.2 Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [Humidity 150% to 95% non-condensing (at temperatures of 25 2C to 35 °C) Frequency 5GHz (802.1lac/n) 2.4GHz (802.11b/ g/n) Modulation Frequency band 5.15GHz - 5.85GHz (dependent on 2.400 - 2.4835GHz (dependent on country) country) [ Modulation ]L BPSK, QPSK, 16 QAM, 64 QAM, 256 QAM | CCK, DQPSK, DBPSK Wireless Medium 5GHZ UNII: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM) Division Multiplexing (OFDM) [ Channels [ All channels as defined by the relevant specification and country rules.

Intel® Dual Band Wireless-AC 8260: 2 X 2

|] Spatial streams ] |

specs.htm[8/25/2022 4:59:28 PM]

Rates I IEEE 802.119 Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates IEEE 802.11b Data 11, 5.5, 2, 1 Mbps Rates Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the following adapters + Model 8260NGW General

Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (64- bit)

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Encryption and Authentication

Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [Humidity 150% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C)

Wi-Fi Alliance* Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA*, WPA2*, WPS2*, Protected certification Management Frames, Wi-Fi Direct* for peer to peer device connections, Wi-Fi Miracast* as Source. IEEE WLAN IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, Standard 802.11k, 802.11v pending OS support; Fine Timing Measurement based on 802.11REVmc [ Roaming I Supports seamless roaming between access points [ Bluetooth ]L Dual Mode Bluetooth* 4.2, BLE [ Security

WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA,

EAP-AKA Authentication

PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2

Encryption and Authentication

Encryption I 64-bit and 128-bit WEP, 128-bit AES-CCMP Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

5GHz UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Division Multiplexing (OFDM) Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

Antenna Diversity I Supported

Radio ON/OFF Control

Connector Interface I M.2: PCIe, USB Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [Humidity 150% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) ] [ Operating Systems I Microsoft Windows 10*, Linux* (limited feature support), Chrome* ] Wi-Fi Alliance* Wi-Fi CERTIFIED* a/b/g/n/ac with wave 2 features, WMM*, WMM-PS*, WPA*, WPA2*, certification WPS2*, Protected Management Frames, Wi-Fi Miracast* as Source, and Wi-Fi Direct*.

IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, 802.11k, 802.11v pending OS support; Fine Timing Measurement based on 802.11REVmc

[ Roaming I Supports seamless roaming between access points ] [ Bluetooth ]L Bluetooth* 5 ] [ Security ] [ |

Encryption and Authentication

Protocols [ Encryption ]L64-bit and 128-bit WEP, 128-bit AES-CCMP ]

Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

I All channels as defined by the relevant specification and country rules.

[L1ntel® Wireless-AC 9260: 2 x 2

I All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Dimensions (H x W x D)

[ Antenna Diversity I Supported ] Radio ON/OFF Supported Control

[ Connector Interface I M.2: CNVio ]

Operating O2C to +802C Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C) ] [ Operating Systems I Microsoft Windows 10*, Linux* (limited feature support), Chrome ] Wi-Fi Alliance* Wi-Fi CERTIFIEDX* a/b/g/n/ac with wave 2 features, WMM*, WMM-PS*, WPA*, WPA2*, certification WPS2*, Protected Management Frames, Wi-Fi Miracast* as Source, and Wi-Fi Direct

IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, 802.11k, 802.11v pending OS support; Fine Timing Measurement based on 802.11REVmc

[ Roaming I Supports seamless roaming between access points ] [ Bluetooth [| Bluetooth* 5 ] [ Security ] [ |

PAP, CHAP, TLS, MS-CHAP*, MS-CHAPv2

Encryption and Authentication

Protocols [_Encryption [L54-bit and 128-bit WEP, 128-bit AES-CCMP ]

Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

specs.htm[8/25/2022 4:59:28 PM]

I For a list of country approvals, please contact your local Intel representatives.

QAM CCK, DOPSK, DBPSK Wireless Medium

5GHz UNII: Orthogonal Frequency Division Multiplexing (OFDM)

2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

I All channels as defined by the relevant specification and country rules.

[ Antenna Diversity I Supported ] Radio ON/OFF Supported Control

[ Connector Interface I M.2: CNVio ]

Operating O2C to +802C Temperature (Adapter Shield) [Humidity ]L50% to 90% RH non-condensing (at temperatures of 25 £C to 35 £C) ]

Wi-Fi Alliance* certification

Wi-Fi CERTIFIEDX* a/b/g/n/ac with wave 2 features, WMM*, WMM-PS*, WPA*, WPA2*, WPS2*, Protected Management Frames, Wi-Fi Miracast* as Source, and Wi-Fi Direct

IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, 802.11k, 802.11v pending OS support; Fine Timing Measurement based on 802.11REVmc

[ Roaming I Supports seamless roaming between access points ] [ Bluetooth I Bluetooth* 5 ] [ Security ] [ |

Encryption and Authentication

Protocols [_Encryption ]L 64-bit and 128-bit WEP, 128-bit AES-CCMP ]

Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

For a list of country approvals, please contact your local Intel representatives.

Frequency Modulation

5GHz UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Division Multiplexing (OFDM) Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

Intel® Wireless-AC 9462: 1 X 1

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Dimensions (H x e M.2 2230: 22 mm x 30 mm x 2.4 mm W x D) + M.2 1216: 12 mm x 16 mm x 1.8 mm Weight + M.2 2230: 2.6g + M.2 1216: 0.6g

Antenna Diversity |] Supported

Radio ON/OFF Supported

Connector M.2: CNVio

Operating 0 to +80 degrees Celsius

(Adapter Shield) [ Humidity | 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C)

Operating Microsoft Windows 10*, Linux* (limited feature support), Chrome*

Wi-Fi Alliance* Wi-Fi CERTIFIED* a/b/g/n/ac with wave 2 features, WMM*, WMM-PS*, WPA*, WPA2*,

certification WPS2*, Protected Management Frames, Wi-Fi Miracast* as Source, and Wi-Fi Direct* (For

Microsoft Windows* only).

IEEE WLAN IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r, 802.11Kk,

Standard 802.11v pending OS support; Fine Timing Measurement based on 802.11-2016 [_Roaming ]_ Supports seamless roaming between access points ] [ Bluetooth I Bluetooth* 5 ] [ Security ]

PAP, CHAP, TLS, MS-CHAP*, MS-CHAPv2*

Encryption and Authentication

Protocols [_Encryption [L54-bit and 128-bit WEP, 128-bit AES-CCMP ]

Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

CCK, DQPSK, DBPSK Wireless Medium

5GHz UNIT: Orthogonal Frequency Division Multiplexing (OFDM)

2.4GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

All channels as defined by the relevant specification and country rules.

specs.htm[8/25/2022 4:59:28 PM]

Spatial streams I Intel® Wireless-AC 9560: 2 X 2

M.2 Key 1-DP: 2xPCle, USB, DP. Interface to Intel® Wireless Gigabit-Antenna M10041 Module using X-FL, and one dedicated for Bluetooth

Operating 0 to +80 degrees Celsius

[ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C)

Modulation DPSK, BPSK, BPSK, QPSK, 16 QAM, 64 CCK, DQPSK, DBPSK QPSK, 16 QAM, QAM, 256 QAM Wireless Medium DMG control PHY, 5GHz UNIT: Orthogonal 2.4GHz ISM: Orthogonal DMG SC PHY Frequency Division Frequency Division Multiplexing

Multiplexing (OFDM) (OFDM)

Channels 1, 2 and 3, All channels as defined by the relevant specification and country subject to country rules. rules

[_ Spatial streams IL N/A [Lintel® Tri-Band Wireless-AC 17265

[ Data Rates I All data rates are theoretical maximums. IEEE 802.11ac Data Intel® Tri-Band Wireless-AC 17265: Up to 867 Mbps Rates IEEE 802.11ad Data 4620, 3850, 3080, 2503, 2310, 1925, 1540, 1251, 1155, 963, 770, 385 Mbps Rates IEEE 802.11n Data Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, Rates 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

54, 48, 36, 24, 18, 12, 9, 6 Mbps

specs.htm[8/25/2022 4:59:28 PM]

Rates I IEEE 802.119 Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates

Operating Systems ] Microsoft Windows 7*, Microsoft Windows 8.1* with connected standby

Wi-Fi Alliance* Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, certification Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Cisco Compatible Cisco Compatible Extensions, v4.0 Extensions certification [ Security [ Authentication I WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA Authentication PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2 Protocols

[_Encryption 1 64-bit and 128-bit WEP, AES-CCMP, AES-GCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Encryption and Authentication

Electrical interfaces M.2 Key 1-DP: 2xPCle, USB, DP. Interface to Intel® Wireless Gigabit-Antenna M10041 Module using X-FL, and one dedicated for Bluetooth

Channels 1, 2 and 3, All channels as defined by the relevant specification and country subject to country rules. rules [ Spatial streams N/A [L'intel® Tri-Band Wireless-AC 17265

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Microsoft Windows 7*, Microsoft Windows 8.1* with connected standby

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Encryption and Authentication

[Encryption 1. 54-bit and 128-bit WEP, AES-CCMP, AES-GCMP, TKIP Wi-Fi Direct* WPA2, AES-CCMP Product Safety ]

M.2 Key 1-DP: 2xPCle, USB, DP. Interface to Intel® Wireless Gigabit-Antenna M10041 or M10042 Module using X-FL (single coax cable to carry power, IF and control)

Antenna Diversity I On-board diversity

IEEE 802.11 IEEE 802.11abgn, 802.11ac, 802.11ad, 802.114, 802.11e, 802.11i, 802.11h, 802.11w Networking

Operating 0 to +80 degrees Celsius

specs.htm[8/25/2022 4:59:28 PM]

Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C) Frequency 60GHz 5GHz (802.1lac/n) 2.4GHz (802.11b/ g/n) Modulation (802.11ad) Frequency band 57GHz - 64GHz 5.15GHz - 5.85GHz 2.400 - 2.4835GHz (dependent (dependent on (dependent on country) on country) country) Modulation DPSK, BPSK, BPSK, QPSK, 16 QAM, 64 CCK, DQPSK, DBPSK QPSK, 16 QAM, QAM, 256 QAM Wireless Medium DMG control PHY, 5GHz UNIT: Orthogonal 2.4GHz ISM: Orthogonal DMG SC PHY Frequency Division Frequency Division Multiplexing Multiplexing (OFDM) (OFDM) Channels 1, 2 and 3, All channels as defined by the relevant specification and country subject to country rules. rules [ Spatial streams IL N/A JL 1ntel® Tri-Band Wireless-AC 18260

All data rates are theoretical maximums.

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Microsoft Windows 7*, Microsoft Windows 8.1* with connected standby

Wi-Fi Alliance* certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Encryption and Authentication

Intel® Tri-Band Wireless-AC 18265 (18265NGW)

[ General Dimensions (H x W M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5mm Max (Top Side)/ 0.1mm Max (Bottom x D) Side)] [ Weight ]LM.2 2230: 2.4g [_Antenna Diversity |] Supported Radio ON/OFF Supported Control

Connector interface M.2: PCle, USB Interface to Intel® Wireless Gigabit-Antenna M10101 Module using X-FL (single coax cable to carry power, IF and control)

Operating 0 to +80 degrees Celsius

Humidity Non- 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating

Operating Systems Microsoft Windows 7*, Microsoft Windows 8.1*, Microsoft Windows 10, Linux* (limited feature support), Android

Wi-Fi Alliance Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA*, WPA2*, WPS2, Protected Management Frames, Wi-Fi Direct* for peer to peer device connections, Wi-Fi Miracast as Source

IEEE WLAN IEEE 802.11a/b/g/n/ac, 802.11d, 802.11e, 802.11h, 802.11i, 802.11w; 802.11r,

Standard 802.11k, 802.11v pending OS support; Fine Timing Measurement based on

[ Roaming Il Supports seamless roaming between respective access points [ Bluetooth ]L Dual Mode Bluetooth* 4.2, BLE Frequency 60GHz 5GHz (802.1lac/n) 2.4GHz (802.11b/g/n) Modulation (802.11ad) Frequency band 57GHz - 64GHz 5.15GHzZ - 5.85GHz 2.400 - 2.4835GHz (dependent (dependent on (dependent on country) on country) country) Modulation DPSK, BPSK, BPSK, QPSK, 16 QAM, 64 CCK, DQPSK, DBPSK QPSK, 16 QAM, QAM, 256 QAM Wireless Medium DMG control PHY, 5GHz UNII: Orthogonal 2.4GHz ISM: Orthogonal DMG SC PHY Frequency Division Frequency Division Multiplexing Multiplexing (OFDM) (OFDM) Channels 1, 2 and 3, All channels as defined by the relevant specification and country subject to country rules. rules [ Spatial streams JLN/A [Lintel@ Tri-Band Wireless-AC 18265 [ Data Rates ]L AI data rates are theoretical maximums. IEEE 802.11ac Data Up to 867 Mbps Rates IEEE 802.11ad Data 4620, 3850, 3080, 2503, 2310, 1925, 1540, 1251, 1155, 963, 770, 385 Mbps Rates IEEE 802.11n Data Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, Rates 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates IEEE 802.119 Data 54, 48, 36, 24, 18, 12, 9, 6 Mbps Rates

PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2

Encryption and Authentication

Protocols [ Encryption ]L 64-bit and 128-bit WEP, AES-CCMP ]

Wi-Fi Direct* WPA2-PSK, AES-CCMP Compliance

Product Safety I UL, C-UL, CB (IEC 60950-1)

M.2 Key 1-DP: 2xPCle, USB, DP. Interface to Intel® Wireless Gigabit-Antenna M10041 Module using X-FL, and one dedicated for Bluetooth

802.11ac, 802.11ad, 802.11abgn, 802.11a, 802.11d, 802.11e, 802.11i, 802.11h,

Operating Temperature (Adapter Shield)

0 to +80 degrees Celsius

50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C)

Frequency Modulation

JL DMG control PHY, DMG SC PHY Channels

I 1, 2 and 3, subject to country rules

]L WPA2-Personal (WSC - WiFi Simple Configuration)

| 128-bit AES-GCMP Additional Crypto Functions

I Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

20.5 mm x 14.2 mm x 1.8 mm (shield included)

Soldered module has a proprietary land plan. Interface to Intel® Wireless Gigabit Antenna-M 10042R using X-FL (single coax cable to carry power, IF and control)

IEEE 802.11 802.11ad Networking Standards Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 2C to 35 °C) ] Frequency 60GHz (802.11ad)

57GHz - 64GHz (dependent on country)

[ Î [ Modulation JL DPSK, BPSK, QPSK, 16 QAM, ] [ Channels I 1, 2 and 3, subject to country rules ] [ Data Rates I All data rates are theoretical maximums. ] IEEE 802.11ad Data 4620, 3850, 3080, 2503, 2310, 1925, 1540, 1251, 1155, 963, 770, 385 Mbps Rates

Over-the-Air Security

WPA2-Personal (WSC - WiFi Simple Configuration)

[ Weight I 5.16 grams Radio ON/OFF Hardware Support Control

Electrical interfaces

M.2 Key G (User Defined). Interface to Intel® Wireless Gigabit Antenna-M 10101 Module

using X-FL (single coax cable to carry power, IF and control), up to 2 modules

Driving 2 LEDs or Multicolor LED with 4 states, Recovery button, Activity button with

Operating 0 to +80 degrees Celsius

Humidity Non- 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating

Frequency 60GHz (802.1lad)

Frequency band 57GHz - 64GHZ (dependent on country)

[ Ï [ Modulation JL DPSK, BPSK, QPSK, 16 QAM, [ Channels I 1, 2 and 3, subject to country rules [ Data Rates I All data rates are theoretical maximums. IEEE 802.11ad Data 4620, 3850, 3080, 2503, 2310, 1925, 1540, 1251, 1155, 963, 770, 385 Mbps Rates [ Operating Systems I None Wi-Fi Alliance* N/A certification Over-the-Air Security Authentication I WPA2-Personal (WSC - WiFi Simple Configuration)

Encryption ]L128-bit AES-GCMP Additional Crypto Functions

Public Key Decrypt || RSA-2048

Intel® Wireless Gigabit Antenna-M 10101R Module

Dimensions (H x W 7 mm x 19.3 mm x 1.8 mm x D) [ Weight ]L1 gram Antenna Connector X.FL Interface Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) Humidity Non- 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Intel® Wireless Gigabit 11100VR Dimensions (H x W 20.5 mm x 14.2 mm x 1.8 mm (shield included) x D) [ Weight ]L2 grams Radio ON/OFF Supported in both hardware and software Control

Electrical interfaces Soldered module has a proprietary land plan. Interface to Intel® Wireless Gigabit Antenna-M 10042 Module using X-FL (single coax cable to carry power, IF and control)

Operating 0 to +80 degrees Celsius Temperature

specs.htm[8/25/2022 4:59:28 PM]

Humidity Non- 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating

Frequency 60GHz (802.11ad)

[ [ Modulation Ï_DPSK, BPSK, QPSK, 16 QAM, ] [ Channels I 1, 2 and 3, subject to country rules ] [ Data Rates JL AI data rates are theoretical maximums. ] IEEE 802.11ad Data 4620, 3850, 3080, 2503, 2310, 1925, 1540, 1251, 1155, 963, 770, 385 Mbps Rates

I Microsoft Windows 10* with connected standby

Over-the-Air Security

Î| WPA2-Personal (WSC - WiFi Simple Configuration)

]L128-bit AES-GCMP Additional Crypto Functions

Dimensions (H x W 7.5 mm x 24.5 mm x 1.8 mm x D) [ Weight I 1 gram ] Antenna Connector X.FL Interface Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) Humidity Non- 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating

Humidity I 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Microsoft Windows 10*, Linux*, Chrome OS* Systems Wi-Fi Alliance* Wi-Fi CERTIFIED* 6, Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA*, WPA2*, certification WPA3*, WPS*, PMF*, Wi-Fi Direct*, Wi-Fi Agile Multiband*, Wi-Fi Optimized Connectivity*, Wi-Fi Location*, and Wi-Fi TimeSync* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax; Fine Timing Measurement based on 802.11-2016 [ Bluetooth ÎL Bluetooth* 5.1 ] [ Security ] [ Authentication I WPA* and WPA2* Personal and Enterprise; WPA3* (pending OS support) ] Authentication 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPvO/EAP-MSCHAPV2 (EAP-SIM, EAP-AKA, EAP- Protocols AKA')

Encryption Ï 64-bit and 128-bit WEP, TKIP, 128-bit AES-CCMP, 256-bit AES-GCMP Compliance

For a list of country approvals, please contact your local Intel representatives.

US Government I FIPS 140-2

IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w, ai; Fine Timing Measurement based on 802.11-2016 [ Bluetooth ]_ Bluetooth* 5 [ Security

WPA* and WPA2* Personal and Enterprise; WPA3* (pending OS support)

[ Regulatory I For a list of country approvals, please contact your local Intel representatives. Us FIPS 140-2, FISMA Government Product UL, C-UL, CB (IEC 60950-1) Safety

band (dependent on country) (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM, 256 QAM, CCK, DQPSK, DBPSK, 16 QAM, 64 QAM, 256

1024 QAM QAM, 1024 QAM Wireless 5GHz UNII: Orthogonal Frequency Division 2.4GHz ISM: Orthogonal Frequency Division

Medium Multiple Access (OFDMA) Multiple Access (OFDMA)

[ Channels I All channels as defined by the relevant specification and country rules. [ Data Rates I All data rates are theoretical maximums.

IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117,

Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps

Radio ON/OFF Supported Control Connector M.2: CNVio2 Interface Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Microsoft Windows 10*, Linux*, Chrome OS* Systems Wi-Fi Wi-Fi CERTIFIED* a/b/g/n/ac with wave 2 features, WMM*, WMM-PS*, WPA*, WPA2*, WPS*, Alliance* PMF*, Wi-Fi Direct*, Wi-Fi Miracast*, Wi-Fi Agile Multiband*, Wi-Fi Optimized Connectivity*, certification Wi-Fi Location*, Passpoint*, Wi-Fi Aware*, and Wi-Fi TimeSync* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w, ai; Fine Timing Measurement based on 802.11-2016 [ Bluetooth ]_ Bluetooth* 5 [ Security

WPA* and WPA2* Personal and Enterprise; WPA3* (pending OS support)

[ Regulatory I For a list of country approvals, please contact your local Intel representatives. Us FIPS 140-2, FISMA Government Product UL, C-UL, CB (IEC 60950-1) Safety

band (dependent on country) (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM, 256 QAM, CCK, DQPSK, DBPSK, 16 QAM, 64 QAM, 256

1024 QAM QAM, 1024 QAM Wireless 5GHz UNII: Orthogonal Frequency Division 2.4GHz ISM: Orthogonal Frequency Division

specs.htm[8/25/2022 4:59:28 PM]

[_ Medium || Muitiple Access (OFDMA) || Muitiple Access (OFDMA) [ Channels I All channels as defined by the relevant specification and country rules. [ Data Rates I All data rates are theoretical maximums. IEEE Up to 2.4 Gbps 802.11ax Data Rates IEEE Up to 867 Mbps 802.11ac Data Rates IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11b 11, 5.5, 2, 1 Mbps Data Rates

[ General Dimensions (H + M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5 mm max (top side)/ 0.1 mm max (bottom x W x D) side)] + M.2 1216: 12 mm x 16 mm x 1.65 (+0.05) mm Weight + M.2 2230: 2.33 (+0.3) g

Radio ON/OFF Supported Control Connector M.2: CNVio2 Interface Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Microsoft Windows 10*, Linux*, Chrome OS* Systems Wi-Fi Alliance* Wi-Fi CERTIFIED* 6, Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA*, WPA2*, certification WPA3*, WPS*, PMF*, Wi-Fi Direct*, Wi-Fi Agile Multiband*, Wi-Fi Optimized Connectivity*, Wi-Fi Location*, and Wi-Fi TimeSync* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax; Fine Timing Measurement based on 802.11-2016 [ Bluetooth I Bluetooth* 5.1 [ Security

WPA* and WPA2* Personal and Enterprise; WPA3* (pending OS support)

Regulatory I For a list of country approvals, please contact your local Intel representatives.

128-bit AES-CCMP, 256-bit AES-GCMP Compliance

Regulatory I For a list of country approvals, please contact your local Intel representatives.

US Government I FIPS 140-2

Product Safety I UL, C-UL, CB (IEC 60950-1)

Frequency Modulation

(dependent on country) (dependent on country)

5GHZ UNIT: Orthogonal Frequency 2.4GHz ISM: Orthogonal Frequency Division Multiple Access (OFDMA) Division Multiple Access (OFDMA)

All channels as defined by the relevant specification and country rules.

Data Rates I All data rates are theoretical maximums.

IEEE 802.11ax Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.119 Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

Radio ON/OFF Supported Control Î Connector Î M.2: PCle, USB

specs.htm[8/25/2022 4:59:28 PM]

| Interface I Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [ Humidity I 50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Microsoft Windows 10*, Linux* Systems Wi-Fi Alliance* Wi-Fi CERTIFIEDX* a/b/g/n/ac, WMM*, WMM-PS*, WPA2*, WPA3*, WPS*, PMF*, Wi-Fi certification Direct*, Wi-Fi Agile Multiband* and Wi-Fi TimeSync* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w; Fine Timing Measurement based on 802.11-2016 802.11-2016, Wi-Fi Location R2 (802.11az) HW readiness [ Bluetooth JL Bluetooth* 5.2 ] [ Security ]

For a list of country approvals, please contact your local Intel representatives.

US Government I FIPS 140-2

AX210D2W I Wi-Fi 6E (6GHz), 2x2, Bluetooth* 5.2, M.2 1216

Frequency Modulation

6-7GHz (802.11ax R2)

5GHz (802.11a/ n/ ac/ ax)

(dependent on country)

specs.htm[8/25/2022 4:59:28 PM]

Modulation BPSK, QPSK, 16 QAM, 64 BPSK, QPSK, 16 QAM, 64 CCK, DOPSK, DBPSK, 16 QAM, 256 QAM, 1024 QAM QAM, 256 QAM, 1024 QAM QAM, 64 QAM, 256 QAM, 1024 QAM Wireless 6-7GHz: Orthogonal 5GHZ UNIT: Orthogonal 2.4GHz ISM: Orthogonal Medium Frequency Division Multiple Frequency Division Multiple Frequency Division Multiple Access (OFDMA) Access (OFDMA) Access (OFDMA) [ Channels I All channels as defined by the relevant specification and country rules. ] [ Data Rates JL AI data rates are theoretical maximums. ] IEEE 802.11ax Up to 2.4 Gbps Data Rates IEEE 802.11ac Up to 867 Mbps Data Rates IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps

Data Rates I IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates

[ General Dimensions (H e M.2 2230: 22 mm x 30 mm x 2.4 mm [1.5 mm max (top side)/ 0.1 mm max (bottom x W x D) side)] + M.2 1216: 12 mm x 16 mm x 1.7 (+0.1) mm Weight e M.2 2230: 2.83 (+0.3) g + M.2 1216: 0.67 (+0.1) g Radio ON/OFF Supported Control Connector M.2: CNVio2 Interface Operating 0 to +80 degrees Celsius Temperature (Adapter Shield) [Humidity ]L50% to 90% RH non-condensing (at temperatures of 25 °C to 35 °C) Operating Microsoft Windows 10*, Linux* Systems Wi-Fi Alliance* Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA3*, PMF*, Wi-Fi Direct*, and Wi-Fi certification Agile Multiband* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w; Fine Timing Measurement based on 802.11-2016 Wi-Fi Location R2 (802.11az) HW readiness [ Bluetooth I Bluetooth* 5.2 [ Security ['Authentication ]] WPA2* and WPA3* Authentication 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPvO/EAP-MSCHAPv2 (EAP-SIM, EAP-AKA, EAP- Protocols AKA')

Encryption ]128-bit AES-CCMP, 256-bit AES-GCMP Compliance

Regulatory Î For a list of country approvals, please contact your local Intel representatives.

AX211D2WL I Wi-Fi 6E (6GHz), 2x2, Bluetooth* 5.2, M.2 1216, LTE Coex

Frequency Modulation

6-7GHz (802.11ax R2)

5GHz (802.11a/ n/ ac/ ax)

(dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 BPSK, QPSK, 16 QAM, 64 CCK, DOPSK, DBPSK, 16

QAM, 256 QAM, 1024 QAM QAM, 256 QAM, 1024 QAM QAM, 64 QAM, 256 QAM,

1024 QAM Wireless 6-7GHz: Orthogonal 5GHZ UNIT: Orthogonal 2.4GHz ISM: Orthogonal

Medium Frequency Division Multiple Frequency Division Multiple Frequency Division Multiple Access (OFDMA) Access (OFDMA) Access (OFDMA)

[ Channels I All channels as defined by the relevant specification and country rules. [ Data Rates Î All data rates are theoretical maximums.

IEEE 802.11ax Up to 2.4 Gbps

IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117,

Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps

Systems I Wi-Fi Alliance* Wi-Fi CERTIFIED* 6, Wi-Fi CERTIFIED* a/b/g/n/ac, WMM*, WMM-PS*, WPA3*, PMF*, Wi-Fi certification Direct*, and Wi-Fi Agile Multiband* IEEE WLAN IEEE 802.11-2016 and select amendments (selected feature coverage) Standard IEEE 802.11a, b, g, n, ac, ax, d, e, h, i, k, r, u, v, w; Fine Timing Measurement based on 802.11-2016 Wi-Fi Location R2 (802.11az) HW readiness [ Bluetooth I Bluetooth* 5.2 ] [ Security ]

For a list of country approvals, please contact your local Intel representatives.

Models L'AXALINGW JLWi-Fi 6E (6GHz), 2x2, Bluetooth* 5.2, M.2 2230 L'AX411E2W JLWi-Fi 6E (6GHz), 2x2, Bluetooth* 5.2, M.2 1625 Frequency 6-7GHz (802.11ax R2) 5GHz (802.11a/ n/ ac/ ax) 2.4GHz (802.11b/ g/ n/ ax) Modulation Frequency band ECC: 5.925GHz-7.125GHz 5.15GHz - 5.895GHzZ 2.400 - 2.4835GHz EU: 5925GHz- 6.425GHz (dependent on country) (dependent on country) (dependent on country) Modulation BPSK, QPSK, 16 QAM, 64 BPSK, QPSK, 16 QAM, 64 CCK, DOPSK, DBPSK, 16 QAM, 256 QAM, 1024 QAM QAM, 256 QAM, 1024 QAM QAM, 64 QAM, 256 QAM, 1024 QAM Wireless 6-7GHz: Orthogonal 5GHZ UNIT: Orthogonal 2.4GHz ISM: Orthogonal Medium Frequency Division Multiple Frequency Division Multiple Frequency Division Multiple Access (OFDMA) Access (OFDMA) Access (OFDMA) [ Channels I All channels as defined by the relevant specification and country rules. ] [ Data Rates I All data rates are theoretical maximums. ] IEEE 802.11ax Up to 2.4 Gbps Data Rates IEEE 802.11ac Up to 867 Mbps Data Rates IEEE 802.11n Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, Data Rates 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rates IEEE 802.11b 11, 5.5, 2, 1 Mbps Data Rates Back to Top

Intel support is available online or by telephone. Available services include the most up-to-date product information, installation instructions about specific products, and troubleshooting tips.

Trademarks and Disclaimers

support.htm[8/25/2022 4:59:30 PM]

Warranty Information

One-Year Limited Hardware Warranty Limited Warranty

In this warranty statement, the term "Product" applies to the wireless adapters listed in Specifications.

Intel warrants to the purchaser of the Product that the Product, if properly used and installed, will be free from defects in material and workmanship and will substantially conform to Intel's publicly available specifications for the Product for a period of one (1) year beginning on the date the Product was purchased in its original sealed packaging.

SOFTWARE OF ANY KIND DELIVERED WITH OR AS PART OF THE PRODUCT IS EXPRESSLY PROVIDED "AS IS", SPECIFICALLY EXCLUDING ALL OTHER WARRANTIES, EXPRESS, IMPLIED (INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE), provided however, that Intel warrants that the media on which the software is furnished will be free from defects for a period of ninety (90) days from the date of delivery. 1f such a defect appears within the warranty period, you may return the defective media to Intel for replacement or alternative delivery of the software at Intel's discretion and without charge. Intel does not warrant or assume responsibility for the accuracy or completeness of any information, text, graphics, links or other items contained within the software.

If the Product which is the subject of this Limited Warranty fails during the warranty period for reasons covered by this Limited Warranty, Intel, at its option, will:

° REPAIR the Product by means of hardware and/or software; OR

e REPLACE the Product with another product, OR, if Intel is unable to repair or replace the Product,

e REFUND the then-current Intel price for the Product at the time a claim for warranty service is made to Intel under this Limited Warranty.

THIS LIMITED WARRANTY, AND ANY IMPLIED WARRANTIES THAT MAY EXIST UNDER APPLICABLE STATE, NATIONAL, PROVINCIAL OR LOCAL LAW, APPLY ONLY TO YOU AS THE ORIGINAL PURCHASER OF THE PRODUCT.

Extent of Limited Warranty

Intel does not warrant that the Product, whether purchased stand-alone or integrated with other products, including without limitation, semi-conductor components, will be free from design defects or errors known as "errata." Current characterized errata are available upon request. Further, this Limited Warranty does NOT cover: (i) any costs associated with the replacement or repair of the Product, including labor, installation or other costs incurred by you, and in particular, any costs relating to the removal or replacement of any Product soldered or otherwise permanently affixed to any printed circuit board or integrated with other products; (ii) damage to the Product due to external causes, including accident, problems with electrical power, abnormal, mechanical or environmental conditions, usage not in accordance with product instructions, misuse, neglect, accident, abuse, alteration, repair, improper or unauthorized installation or improper testing, or (iii) any Product which has been modified or operated outside of Intel's publicly available specifications or where the original product identification markings (trademark or serial number) have been removed, altered or obliterated from the Product; or (iv) issues resulting from modification (other than by Intel) of software products provided or included in the Product, (v) incorporation of software products, other than those software products provided or included in the Product by Intel, or (vi) failure to apply Intel-supplied modifications or corrections to any software provided with or included in the Product.

How to Obtain Warranty Service

To obtain warranty service for the Product, you may contact your original place of purchase in accordance with its instructions or you may contact Intel. To request warranty service from Intel, you must contact the Intel Customer Support ("ICS") center in your region (http://www.intel.com/support/wireless/) within the warranty period during normal business hours (local time), excluding holidays and return the Product to the designated ICS center. Please be prepared to provide: (1) your name, mailing address, email address, telephone numbers and, in the USA, valid

warranty.htm[8/25/2022 4:59:30 PM]

Warranty Information

credit card information; (2) proof of purchase; (3) model name and product identification number found on the Product; and (4) an explanation of the problem. The Customer Service Representative may need additional information from you depending on the nature of the problem. Upon ICS's verification that the Product is eligible for warranty service, you will be issued a Return Material Authorization ("RMA") number and provided with instructions for returning the Product to the designated ICS center. When you return the Product to the ICS center, you must include the RMA number on the outside of the package. Intel will not accept any returned Product without an RMA number, or that has an invalid RMA number, on the package. You must deliver the returned Product to the designated ICS center in the original or equivalent packaging, with shipping charges pre-paid (within the USA), and assume the risk of damage or loss during shipment. Intel may elect to repair or replace the Product with either a new or reconditioned Product or components, as Intel deems appropriate. The repaired or replaced product will be shipped to you at the expense of Intel within a reasonable period of time after receipt of the returned Product by ICS. The returned Product shall become Intel's property on receipt by ICS. The replacement product is warranted under this written warranty and is subject to the same limitations of liability and exclusions for ninety (90) days or the remainder of the original warranty period, whichever is longer. 1f Intel replaces the Product, the Limited Warranty period for the replacement Product is not extended.

WARRANTY LIMITATIONS AND EXCLUSIONS THIS WARRANTY REPLACES ALL OTHER WARRANTIES FOR THE PRODUCT AND INTEL DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT, COURSE OF DEALING AND USAGE OF TRADE. Some states (or jurisdictions) do not allow the exclusion of implied warranties so this limitation may not apply to you. ALL EXPRESS AND IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE LIMITED WARRANTY PERIOD. NO WARRANTIES APPLY AFTER THAT PERIOD. Some states (or jurisdictions) do not allow limitations on how long an implied warranty lasts, so this limitation may not apply to you.

LIMITATIONS OF LIABILITY INTEL'S RESPONSIBILITY UNDER THIS OR ANY OTHER WARRANTY, IMPLIED OR EXPRESS, IS LIMITED TO REPAIR, REPLACEMENT OR REFUND, AS SET FORTH ABOVE. THESE REMEDIES ARE THE SOLE AND EXCLUSIVE REMEDIES FOR ANY BREACH OF WARRANTY. TO THE MAXIMUM EXTENT PERMITTED BY LAW, INTEL IS NOT RESPONSIBLE FOR ANY DIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR UNDER ANY OTHER LEGAL THEORY (INCLUDING WITHOUT LIMITATION, LOST PROFITS, DOWNTIME, LOSS OF GOODWILL, DAMAGE TO OR REPLACEMENT OF EQUIPMENT AND PROPERTY, AND ANY COSTS OF RECOVERING, REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH A SYSTEM CONTAINING THE PRODUCT), EVEN IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states (or jurisdictions) do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY STATE OR JURISDICTION. ANY AND ALL DISPUTES ARISING UNDER OR RELATED TO THIS LIMITED WARRANTY SHALL BE ADJUDICATED IN THE FOLLOWING FORUMS AND GOVERNED BY THE FOLLOWING LAWS: FOR THE UNITED STATES OF AMERICA, CANADA, NORTH AMERICA AND SOUTH AMERICA, THE FORUM SHALL BE SANTA CLARA, CALIFORNIA, USA AND THE APPLICABLE LAW SHALL BE THAT OF THE STATE OF DELAWARE. FOR THE ASIA PACIFIC REGION (EXCEPT FOR MAINLAND CHINA), THE FORUM SHALL BE SINGAPORE AND THE APPLICABLE LAW SHALL BE THAT OF SINGAPORE. FOR EUROPE AND THE REST OF THE WORLD, THE FORUM SHALL BE LONDON AND THE APPLICABLE LAW SHALL BE THAT OF ENGLAND AND WALES IN THE EVENT OF ANY CONFLICT BETWEEN THE ENGLISH LANGUAGE VERSION AND ANY OTHER TRANSLATED VERSION(S)OF THIS LIMITED WARRANTY (WITH THE EXCEPTION OF THE SIMPLIFIED CHINESE VERSION), THE ENGLISH LANGUAGE VERSION SHALL CONTROL.

warranty.htm[8/25/2022 4:59:30 PM]

Warranty Information

Trademarks and Disclaimers
