DISNORTION - Guitar effect pedal Pigtronix - Free user manual and instructions

Product type	Guitar effect pedal (Fuzz and Overdrive)
Brand	Pigtronix
Model	Disnortion OFM2
Power supply	9 V DC, center negative (adapter required)
Batteries	Not compatible (no battery compartment)
Controls	Gain, Volume, Drive Tone, Fuzz Shape, Series/Parallel switch
Main functions	Dual Fuzz/Overdrive circuit, series or parallel routing, 6-position passive filter on the Fuzz, self-oscillation possible in series mode
Overdrive circuit	6-stage CMOS
Fuzz circuit	Diode-clipping
Fuzz filter	6 analog positions
Routing	Series (Overdrive before Fuzz) or Parallel
Housing	Compact, for pedalboard
Care and cleaning	Clean with a soft, dry cloth. Avoid humidity and extreme temperatures.
Safety	Use only a 9 V DC center-negative power supply. Disconnect before cleaning.
Spare parts and repairability	Contact Pigtronix support for any repairs. Limited 1-year warranty.
Warranty	1 year, mandatory registration within 30 days of purchase
General information	Manufactured by Pigtronix (Bond Audio LLC). Support: [e-mail]

Frequently Asked Questions - DISNORTION Pigtronix

What is the difference between series and parallel mode?

In parallel mode, the Fuzz and Overdrive circuits are arranged in parallel for increased clarity and better punch. In series mode, the Overdrive is followed by the Fuzz, offering extreme saturation and more radical filter effects, including self-oscillations.

How to power the Disnortion pedal?

It requires a 9 V DC center-negative power supply. No battery is used.

Can I use a standard adapter?

Yes, any adapter delivering 9 V DC with a center negative tip works. Make sure the voltage and polarity are correct.

What are the controls available on the pedal?

The controls are Gain, Volume, Drive Tone, Fuzz Shape, and a Series/Parallel switch.

Is the pedal analog?

Yes, it is an analog pedal that combines a 6-stage CMOS saturation circuit and diode clipping.

What does the Drive Tone control do?

It adjusts the cutoff frequency of the low-pass filter located at the Overdrive output, allowing you to adjust the drive's tone.

What does the Fuzz Shape control do?

It selects among 6 different analog filters at the Fuzz output, modifying the shape of the fuzz sound.

How to maintain my pedal?

Clean the surface with a soft, dry cloth. Avoid humidity, extreme temperatures, and abrasive products.

What to do if the pedal does not work?

First check the power supply (9 V DC, center negative). If the problem persists, contact Pigtronix support at [e-mail].

How to register my warranty?

Go to http://pigtronix.com/warranty within 30 days of purchase and submit your proof of purchase.

USER MANUAL DISNORTION Pigtronix

PIGTRONIX

DISNORTION

User's Guide

CONTENTS

03

Introduction

04

Explanation of Controls

05

Warranty

07

Contact Information

ROLL AROUND IN THE FUZZ.

Disnortion is an analog Fuzz and Overdrive pedal offering gushing tone. A single gain knob controls the saturation of both the fuzz and overdrive circuits simultaneously. Disnortion features the ability to switch from parallel routing to a new, super-saturated series routing where the 6-stage CMOS overdrive circuit is cascaded into unique diode-clipping fuzz and then output through a 6-way passive filter network. The Parallel routing mode is ideal for players who like to pile on the gain without sacrificing clarity, dynamic response, punch or low end. It’s like double-tracking your guitar within a single pedal. The Series routing mode offers an even wider range of gain and more extreme filter effects for metal tones and beyond, including self-oscillating timbres that can be modulated by pickup selection and guitar control settings.

EXPLANATION OF CONTROLS

1

Gain: Sets the amount of Distortion in both Fuzz and Overdrive stages.

2

Volume: Sets the overall output volume.

3

Drive Tone: Sets the cutoff frequency for the low-pass filter on the output of the Overdrive.

4

Fuzz Shape: Selects between 6 different analog filters on the output of the Fuzz.

Series / Parallel: Selects between Overdrive routed before Fuzz or Parallel routing.

Disnortion requires a negative tip, 9VDC power supply.

Disnortion does not take batteries.

PIGTRONIX LIMITED WARRANTY

Your new Pigtronix product is warranted to be free from defects in materials and workmanship for 1 year from the original date of purchase. Warranty applies only to the original retail purchaser of a registered Pigtronix product, subject to the limitations contained in this warranty.

THIS WARRANTY IS EXTENDED TO THE ORIGINAL RETAIL PURCHASER OF PIGTRONIX PRODUCTS BOUGHT ON OR AFTER JANUARY 1, 2020 ONLY AND MAY NOT BE TRANSFERRED OR ASSIGNED TO SUBSEQUENT OWNERS. IN ORDER TO VALIDATE YOUR WARRANTY, AND AS A CONDITION PRECEDENT TO WARRANTY COVERAGE HEREUNDER, YOU MUST REGISTER YOUR PRODUCT WITHIN THIRTY (30) DAYS FOLLOWING THE ORIGINAL DATE OF PURCHASE. YOUR PROOF OF PURCHASE OR SALES RECEIPT MUST ACCOMPANY ALL REQUESTS FOR WARRANTY COVERAGE—YOU MAY SUBMIT YOUR RECEIPT ON THE REGISTRATION FORM. IF YOU DO NOT REGISTER THE PRODUCT WITHIN 30 DAYS OF PURCHASE, YOUR PRODUCT WILL NOT BE SERVICED UNDER WARRANTY.

If your product is destroyed, lost or damaged beyond repair while in the possession of Pigtronix for repair, Pigtronix will replace that product with one of the same or most similar style of a value not in excess of the original purchase price of your pedal. Any insurance covering the pedal, including but not limited to collector's value insurance, must be carried by you at your expense.

This warranty covers the cost of both labor and materials on repairs deemed necessary by our Customer Service Representative.

THIS WARRANTY DOES NOT COVER:

• Any product that has been altered or modified in any way or upon which the serial number has been tampered with or altered.
• Any product whose warranty has been altered or upon which false information has been given.
• Any product that has been damaged due to misuse, negligence, accident, or improper operation.
  • The subjective issue of tonal characteristics.
• Shipping damages of any kind.
• Any product that has been subjected to extremes of humidity or temperature
• Normal wear and tear
• Any product that has been purchased from an unauthorized dealer, or upon which unauthorized repair or service has been performed.

PIGTRONIX MAKES NO OTHER EXPRESS WARRANTY OF ANY KIND WHATSOEVER. ALL IMPLIED, WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, EXCEEDING THE SPECIFIC PROVISIONS OF THIS WARRANTY ARE HEREBY DISCLAIMED AND EXCLUDED FROM THIS WARRANTY. SOME STATES AND/OR COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES SO THAT THE ABOVE MAY NOT APPLY TO YOU. PIGTRONIX SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT CONSEQUENTIAL, INCIDENTAL OR OTHER SIMILAR DAMAGES SUFFERED BY THE PURCHASER OR ANY THIRD PARTY, INCLUDING, WITHOUT LIMITATION. DAMAGES FOR LOSS OF PROFITS OR BUSINESS OR DAMAGES RESULTING FROM USE OR PERFORMANCE OF THE PRODUCT, WHETHER IN CONTRACT OR IN TORT, EVEN IF PIGTRONIX OR ITS AUTHORIZED REPRESENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND PIGTRONIX SHALL NOT BE LIABLE FOR ANY EXPENSES, CLAIMS, OR SUITS ARISING OUT OF OR RELATING TO ANY OF THE FOREGOING.

Steps To File for Warranty Coverage:

1. Register your new guitar at http://pigtronix.com/warranty
2. Complete the warranty request form available at http://pigtronix.com/support and we will handle it from there!

CONTACT INFORMATION

Address

Bond Audio LLC

141 W 28th St, Floor 4

New York, NY, 10001

Phone

631-331-7447

Email

[e-mail]

Warranty Service Email

[e-mail]

Warranty Contact Form

pigtronix.com/warranty

Website

pigtronix.com

YouTube

youtube.com/pigtronix

Product manuals are offered digitally in an attempt to be mindful of our environment.

We ask that you consider the same before printing at home. Thank you!
