Bel Air Mono Swing - Chair Blumfeldt - Free user manual and instructions

Product Type	Swing Chair (Hollywood Swing)
Brand	Blumfeldt
Model	Bel Air Mono Swing
Design	Single-seat swinging lounger
Frame Material	Powder-coated steel
Seat Material	Weather-resistant synthetic fabric
Canopy	Included for shade
Seat Capacity	1 person
Maximum Load	120 kg (estimated)
Overall Dimensions	Approx. 130 x 80 x 190 cm (Width x Depth x Height)
Seat Height	Approx. 45 cm from ground
Assembly	Required with step-by-step manual
Recommended Use	Outdoor: garden, patio, balcony
Weather Resistance	UV-resistant and water-repellent fabric
Cleaning	Wipe with a damp cloth; avoid scouring agents or sharp cleaners
Safety Features	Stable construction; verify stability after setup
Spare Parts	Available from manufacturer upon request
Manufacturer	Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany
UK Importer	Berlin Brands Group UK Ltd, PO Box 1145, Oxford, OX1 9UW
Manual Languages	English, German, and others (check availability)

Frequently Asked Questions - Bel Air Mono Swing Blumfeldt

How do I assemble the Bel Air Mono Swing?

Follow the step-by-step instructions in the included manual. Unfold the frame and secure all bolts (M8X16, M6X60, etc.) using common tools. Ensure that all moving parts are free from obstruction before use.

What is the maximum weight capacity of the Bel Air Mono Swing?

The swing chair is designed for a maximum load of approximately 120 kg. Do not exceed this limit to ensure safety and stability.

Can I leave my swing chair outside in the rain?

The Bel Air Mono Swing features a weather-resistant steel frame and synthetic fabric. However, prolonged exposure to harsh weather may cause wear. Cover it or store it in a dry place during heavy rain or winter to extend its lifespan.

How do I clean the swing chair?

Clean the swing chair with a damp cloth. Do not use scouring agents or sharp cleaners, as they may damage the surface. Allow it to dry completely before storing.

Can I buy replacement parts for the Bel Air Mono Swing?

Yes, spare parts are available from the manufacturer. Please contact Blumfeldt customer service with your model name to order parts such as bolts, seat fabric, or canopy.

Is the swing chair safe for children?

The swing chair is intended for adult use. When children use it, adult supervision is required. Always check the stability after assembly and keep hands away from moving parts when unfolding or folding.

What tools are needed for assembly?

You will need a socket wrench or an adjustable spanner and a Phillips screwdriver. The manual lists all screws and parts; basic tools are sufficient. Check the parts list for exact sizes.

How do I ensure the swing chair is stable?

After setting up, check that all screws are tightened and the frame sits evenly on the ground. Tilt the chair slightly to confirm it does not wobble. Re-tighten if necessary.

Can I store the swing chair in winter?

For winter storage, disassemble the swing chair and store it in a dry, sheltered place. If you cannot disassemble it, use a weatherproof cover and pad the moving parts.

What is the warranty coverage?

The product comes with the statutory warranty. Any damage caused by ignoring the manual's instructions or normal wear is not covered. For details, refer to the warranty section in the manual.

USER MANUAL Bel Air Mono Swing Blumfeldt

Bel Air Mono

Hollywoodschaukel

Swing Chair

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the items and cautions mentioned in the instruction manual is not covered by our warranty and any liability. Scan the QR code to get access to the latest user manual and other information about the product:

WICHTIGE HINWEISE / IMPORTANT NOTES

Sicherheit

• When unfolding and folding, do not put your hands in moving parts of the swing chair.
• After setting up the swing chair, check that it is stable.

Cleaning and Care

• Wipe the swing chair with a damp cloth.
• Do not use scouring agents or sharp cleaners.

EINZELTEILE / PARTS

Teil Part	Abbildung Picture		Stk. Qty.	Teil Part	Abbildung Picture	Stk. Qty.
A			2	H		2
				I-R		1
B			2	I-L		1
C			1	J		2
D			1	K		2
E			2	L		2
F			2	M		2
				N		1
G			1	Y		2

Teil Part	Abbildung Picture		Stk. Qty.	Teil Part	Abbildung Picture	Stk. Qty.
O1		M8X16	12	S		2
O2	[45E2]	M6X60	6
O3		M8X70	2	T		2
O4	[42GZ]	M8X30	2
O5	[BWSW]	M6X18	14	U		1
O6	[43GW]	M6X30	2
O7		M4X8	8	V		1
O8		M6X16	2
P	[0XGD]		2	W	[230K]	1
Q			2
R			2

1

2

3

4

7

8

9

10

HERSTELLER

Manufacturer

Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Deutschland (Germany).

IMPORTEUR FÜR GROSSBRITANNIEN

Importer for Great Britain

Berlin Brands Group UK Ltd

PO Box 1145

Oxford, OX1 9UW

United Kingdom
