HMWE FS23 GC BK - Microwave TEKA - Free user manual and instructions

Product type	Microwave oven
Brand	Teka
Model	HMWE FS23 GC BK
Color	Black
Capacity	23 liters
Microwave power	900 W
Grill power	1000 W
Control type	Touch electronic
Dimensions (W x H x D)	490 x 290 x 400 mm
Net weight	14 kg
Supply voltage	230 V / 50 Hz
Main functions	Microwave, grill, combination cooking, defrosting, automatic programs
Care and cleaning	Clean with a damp cloth and mild detergent
Safety	Child lock, automatic stop at end of cooking
Spare parts	Available through Teka after-sales service
Repairability	Repairability index available on Teka website
Energy class	A
Installation type	Built-in or on worktop

Frequently Asked Questions - HMWE FS23 GC BK TEKA

How to use the grill function?

Press the Grill button and select the cooking time. The grill turns on to brown your dishes.

Can I use metal containers?

No, metal containers or those with metal parts can cause arcing. Use microwave-safe dishes.

How to clean the inside of the oven?

Use a damp cloth with a little mild detergent. Avoid abrasive products. For odors, heat a bowl of water with lemon.

What to do if the oven no longer heats?

Check that the door is properly closed and the child lock is not activated. If the problem persists, contact Teka after-sales service.

How to defrost food?

Use the Defrost function by entering the weight of the food. The oven automatically adjusts the time and power.

Can I cook popcorn?

Yes, use the automatic Popcorn program or manually set 800 W for 2 to 3 minutes. Monitor cooking to avoid burning.

How to activate the child lock?

Press and hold the Stop/Clear button for 3 seconds. A padlock symbol appears on the screen.

What is the maximum power in combination mode?

In microwave + grill combination mode, the microwave power is limited to 600 W to avoid overheating.

How to replace the oven light bulb?

Unplug the appliance, unscrew the bulb cover (located at the back or side) and replace with a bulb of the same type (25 W/230 V).

Where to find the full user manual?

The full manual is available for free on the notice-facile.com website for the Teka model HMWE FS23 GC BK.

USER MANUAL HMWE FS23 GC BK TEKA

User Manual

HMWE FS23 GC BK

EN FR DE ES PT

Microwave Oven

Notes:

1	C-1	●		●
2	C-2	●	●
3	C-3		●	●
4	C-4	●	●	●

INSTRUCTION MANUAL

Model: M E FS2 GC

A) Safety Lock System

1) Glass Turntable

Notes:

Control Panel

Microwave Air Fry

Grill/Combi./Conv.

Defrost

Timer/Clock

Low Temperature Control

Stop/Cancel

Start/+30 Sec.

OPERATIONAL

1	C-1	●		●
2	C-2	●	●
3	C-3		●	●
4	C-4	●	●	●

(1) In standby mode, press “▶” to cook food at 100% power level for 30 seconds. Each press on the same key can increase 30 seconds and the maximum time value is “95:00”. (2) In standby mode, turn the knob left to set a cooking time at 100% power. Continue to turn the knob to adjust the cooking time. Then press “☐” to start cooking. The maximum time value is “95:00”.

Note: In the cooking state and defrosting by time state, each more press on "▶" can increase the cooking time by 30 seconds (except for defrosting by weight, the auto menu, the microwave cooking at 0% power and the first stage of multi-stage cooking).

Read these instructions carefully before using your microwave oven, and keep it carefully.

If you follow the instructions, your oven will provide you with many years of good service.

SAVE THESE INSTRUCTIONS CAREFULLY

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

ADDENDUM

If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation.

SPECIFICATIONS

Model	HMWE FS23 GC BK
Rated Voltage/Frequency	230 V~ 50 Hz
Microwave Input	1450 W
Microwave Output	900 W
Grill	1000 W
Convection	1680 W

IMPORTANT SAFETY INSTRUCTIONS WARNING

To reduce the risk of fire, electric shock, injury to persons, or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

1. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
2. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
3. Keep the appliance and its cord out of reach of children less than 8 years.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
5. WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.
6. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
7. WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave ovens.
10. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
11. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
12. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
14. The oven should be cleaned regularly and any food deposits removed.
15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
16. The appliance must not be installed behind a decorative door in order to avoid overheating. (This is not applicable for appliances with decorative door.)
17. Only use the temperature probe recommended for this oven. (for ovens provided with a facility to use a temperature-sensing probe.)
18. The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.
19. The microwave oven must be operated with the

decorative door open. (for ovens with a decorative door.)

1. This appliance is intended to be used in household and similar applications such as:
2. staff kitchen areas in shops, offices and other working environments;
3. by clients in hotels, motels and other residential type environments;
4. farm houses;
5. bed and breakfast type environments.
6. The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
7. Metallic containers for food and beverages are not allowed during microwave cooking.
8. The appliance shall not be cleaned with a steam cleaner.
9. The appliance is intended to be used freestanding.
10. The rear surface of appliances shall be placed against a wall.
11. The appliances are not intended to be operated by means of an external timer or separate remote-control system.
12. The temperature of accessible surfaces may be high when the appliance is operating.
13. WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.

READ CAREFULLY AND KEEP FOR FUTURE

REFERENCE

HOUSEHOLD USE ONLY

(NOT FOR COMMERCIAL USE)

TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION

DANGER

Electric Shock Hazard

Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard

Improper use of the grounding can result in electric shock.

Do not plug into an outlet until appliance is properly installed and grounded.

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded.

If it is necessary to use an extension cord, use only a 3-wire extension cord.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:

1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

2) The extension cord must be a grounding-type 3-wire cord.

3) The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

CLEANING

Be sure to unplug the appliance from the power supply.

1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.

UTENSILS

CAUTION

Personal Injury Hazard

It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

Materials you can use in microwave oven

Utensils Remarks

Browning dish	Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware	Microwave-safe only. Follow manufacturer's instructions.Do not use cracked or chipped dishes.
Glass jars	Always remove lid. Use only to heat food until just warm.Most glass jars are not heat resistant and may break.
Glassware	Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags	Follow manufacturer's instructions. Do not close with metal tie.Make slits to allow steam to escape.
Paper plates and cups	Use for short-term cooking/warming only. Do not leave oven unattended while cooking.
Paper towels	Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Parchment paper	Use as a cover to prevent splattering or a wrap for steaming.
Plastic	Microwave-safe only. Follow the manufacturer's instructions.Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Plastic wrap	Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
Thermometers	Microwave-safe only ( meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray	May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties	May cause arcing and could cause a fire in the oven.
Paper bags	May cause a fire in the oven.
Plastic foam	Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood	Wood will dry out when used in the microwave oven and may split or crack.

NAMES OF OVEN PARTS AND ACCESSORIES

(In case of any differences between the appliance and the pictures in this manual, the product shall prevail.)

Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories:

Glass Tray

Turntable Ring Assembly

Instruction Manual

Higher Grill Rack (Cannot be used in microwave function and must be placed on the glass tray.)

Lower Grill Rack (Cannot be used in microwave function and must be placed on the glass tray.)

Bake Tray (Cannot be used in conjunction with microwave function and can be placed on the grill rack.)

A) Safety interlock system

B) Observation window

C) Door assembly

D) Oven cavity

E) Turntable Ring Assembly

F) Control panel

NAMES OF OVEN PARTS AND ACCESSORIES

Cleaning the cooking compartment and putting the turntable in place. For new installations, make sure all packaging and shipping tape has been removed. Before using the appliance to prepare food for the first time, you will need to put the turntable in place correctly. You must clean the cooking compartment and accessories.

1) Glass Tray

2) Turntable Ring Assembly

Notes:

1. Never use the appliance without the turntable. Make sure that it is properly engaged. The turntable can turn clockwise or anti-clockwise.
2. Never place the glass tray upside down. The glass tray should never be restricted.
3. Both glass tray and turntable ring assembly must always be used during cooking.
4. All food and containers of food are always placed on the glass tray for cooking.
5. Never restrict the movement of the turntable.
6. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.

Countertop Installation

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the waveguide cover that is attached to the oven cavity to protect the magnetron.

Installation

1. Select a level surface that provides enough open space for the intake and/or outlet vents.

(1) The minimum installation height is 85cm. (2) The rear surface of the appliance shall be placed against a wall.

Leave a minimum clearance of 30cm above the oven, and a minimum clearance of 20cm is required between the oven and any adjacent walls.

(3) Do not remove the legs from the bottom of the oven. (4) Blocking the intake and/or outlet openings can damage the oven.

(5) Place the oven as far away from radios and TVs as possible. Operation of the microwave oven may cause interference to your radio or TV reception. 2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency are the same as the voltage and the frequency on the rating label.

WARNING: Do not install the oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be

void.

The accessible surface may be hot during operation.

Control Panel

OPERATION

1. Setting the Clock

(1) Press “ 📊/clock” twice and then “00:00” will display. (2) Turn the knob to set the hour figures. (3) Press “ 📤/clock ” to confirm. (4) Turn the knob to set the minute figures. (5) Press “ 📋/clock ” to confirm. The clock is set.

Notes:

(1) The clock is a 24-hour display. If the clock is not set, it will not work when powered.

(2) To reset the clock, please repeat step 1 to step 5.

2. Setting the Kitchen Timer

(1) Press “ 📋/ lightning” once and then “00:00” will display. (2) Turn the knob to set the desired time. The maximum time value is "95:00". (3) Press “ ▶ ” to confirm. The timer starts counting down.

3. Microwave Cooking

6 power levels are available.

Power	100%	80%	50%	30%	10%	0%
Display	P100	P80	P50	P30	P10	P0

(1) Press “ ≈ ≈ ” once and then “P100” will display. (2) Press “ ≈ ≈ ” repeatedly or turn the knob to set the power level.

The 6 power levels are available.

(3) Press “ ▶” to confirm the power level. (4) Turn the knob to set the cooking time. The maximum time value is "95:00". (5) Press “ ▶ ” to start cooking.

Note : If "P0" is selected, the oven will work with a fan for no power. You can use this level to remove the odor of the oven. Default cooking time at the "P0" power level is 5 minutes and it cannot be changed, please skip the steps 3-4.

4. Grill Cooking

(1) Press “∽/∅” once and then “G-1” will display. (2) Press “▶” to confirm the mode. (3) Turn the knob to set the cooking time. The maximum time value is "95:00". (4) Press “▶” to start cooking.

Note: The buzzer will sound to remind you to turn the food over during grill cooking. If no operation, the oven will continue working.

5. Combination Cooking

(1) Press “∪/⊕” twice and then “C-1” will display. (2) Turn the knob to choose the mode and then "C-2", "C-3", "C-4", and "C-1" will display in order. (3) Press “▶” to confirm the mode. (4) Turn the knob to set the cooking time. The maximum time value is "95:00". (5) Press “▶” to start cooking.

Combination Cooking Chart

Instructions	Display	Microwave	Grill	Convection
1	C-1
2	C-2
3	C-3
4	C-4

6. Defrost by Time

(1) Press “=” twice and then the screen will display “dEF2”. (2) Turn the knob to set the desired defrost time. The maximum time value is "95:00". (3) Press “▶” to start defrosting.

Notes:

(1) The buzzer will sound to remind you to turn the food over during defrosting. If no operation, the oven will continue working. (2) The default power level is P30 and it cannot be changed.

7. Defrost by Weight

(1) Press “= (*)” once and then the screen will display “dEF1”. (2) Turn the knob to set the weight of the food. The range of weight is 100 to 2000g. (3) Press “▶” to start defrosting.

Note: The buzzer will sound to remind you to turn the food over during defrosting. If no operation, the oven will continue working.

8. Multi-Stage Cooking

Notes: (1) Two cooking stages can be set in multi-stage cooking.

(2) If you set the defrost function, it will work automatically in the first stage. (3) The kitchen timer, the auto menu, preheating and the speedy cooking cannot be set as one of the multi-stage.

Example: Defrost food for 5 minutes and then cook with 80% microwave power for 7 minutes.

(1) Press " =*" twice and then the screen will display "dEF2". (2) Turn the knob to set the desired defrost time to 5 minutes. (3) Press " ≈ ≈ " once and then "P100" will display. (4) Press " ≈ ≈ " repeatedly or turn the knob to set the power level to P80. (5) Press " ▶ " to confirm the microwave power. (6) Turn the knob to set the cooking time to 7 minutes. (7) Press " ▶ " to start cooking.

9. Speedy Cooking

(1) In standby mode, press " ▶ " to cook food at 100% power level for 30 seconds. Each press on the same key can increase 30 seconds and the maximum time value is "95:00". (2) In standby mode, turn the knob left to set a cooking time at 100% power.

Continue to turn the knob to adjust the cooking time. Then press " ▶ " to start cooking. The maximum time value is "95:00".

Note: In the cooking state and defrosting by time state, each more press on " ▶ " can increase the cooking time by 30 seconds (except for defrosting by weight, the auto menu, the microwave cooking at 0% power and the first stage of multi-stage cooking).

10. Lock Function for Children

You can use this function to prevent children from accidentally turning the oven on.

To activate the lock:

In standby mode, press and hold "☐" for three seconds. A long beep sounds and the locked icon will display.

To deactivate the lock:

In a locked state, press and hold " || " for three seconds. A long beep sounds.

11. Convection Cooking (with preheating & without preheating)

(1) Press " ∽/" three times, and then "110°C" will display. (2) Turn the knob to set the temperature. The 10 options are available, including "110, 120, 130, 140, 150, 160, 170, 180, 190, 200" (°C). (3) Press " ▶ " to confirm the temperature. (4) Press " ▶ " again to start preheating. When preheating is completed, the oven will beep twice. Open the door and place food in the oven. Then close the door. (If preheating is not needed, please skip this step.) (5) Turn the knob to set the cooking time. The maximum time value is "95:00". (6) Press " ▶ " to start cooking.

12. ECO Function

To enter ECO mode:

In standby mode, press “☐” once or if there is no operation within ten minutes.

The screen will turn off.

To cancel ECO mode:

In ECO mode, pressing any key, or opening the door will cancel it.

13. Auto Menu

(1) Turn the knob right and then the screen will display "A-1". (2) Continue to turn the knob to choose the menu you need. The 10 auto menus are available.

(3) Press " ▶ " to confirm.

(4) Turn the knob to set the weight of the food.

(5) Press “ ▶ ” to start cooking.

Auto Menu Chart

Menu	Weight	Display Power
A-1 Auto Reheat	150g	150g	P100
	250g	250g
	350g	350g
	450g	450g
	600g	600g
A-2 Potato	1 (230g)	1
	2 (460g)	2
	3 (690g)	3
A-3 Meat	150g	150g	P80
	300g	300g
	450g	450g
	600g	600g
A-4 Vegetable	150g	150g	P100
	350g	350g
	500g	500g
A-5 Fish	150g 150g		P80
	250g	250g
	350g	350g
	450g	450g
	650g	650g
Menu	Weight	Display Power
A-6 Pasta	50g(with 450g cold water)	50g	P80
	100g(with 800g cold water)	100g
	150g(with 1200g cold water)	150g
A-7 Soup	200ml	200g	P100
	400ml	400g
	600ml	600g
A-8 Cake	475g 475g		Conv.160°C with preheating
A-9 Pizza	100g	100g	P100+ Conv.200°C
	200g	200g
	300g	300g
A-10 Chicken	500g	500g
	750g	750g
	1000g	1000g
	1200g	1200g

Notes: (1) For the menu “A-10”, the buzzer will sound to remind you to turn the food over during cooking. If no operation, the oven will continue working. (2) For the menu“A-8”, please skip the step 4.

14. Deodoriser Function

(1) Press " ≈ ≈ " once, the screen will display " P100 ". (2) Turn the knob to set the power level to "P0". (3) Press " ▶ " to start working.

Note: The default time is 5 minutes, and it can not be changed.

15. Low Temp Control

(1) Press "

" once and then " L1 " will display.

(2) Turn the knob to select the menu from "L1 to L5". The 5 menus are available.

(3) Press "

" to confirm.

(4) Turn the knob to set the temperature.

(5) Press "

" to confirm the temperature.

(6) Turn the knob to set the cooking time.

(7) Press "

" to start cooking.

Low Temp Control Menu

Menu	Display	Temperature Range	The Maximum Time Value
Slow cook	L1	90°C/100°C/110°C	12 hours (12:0H)
Keep warm	L2	60°C/70°C/80°C	95:00
Food dry	L3	40°C-90°C	12 hours (12:0H)
Yogurt	L4	40°C	12 hours (12:0H)
Warming box	L5	40°C-100°C	95:00

16. Inquiring Function

(1) If the clock has been set, the current time will display for three seconds by pressing

“ ℃/ ℃ ” in the cooking state.

(2) In the microwave, grill, and combination cooking state, press “ ≈ ≈ ” or “ ≈ ≈ / ⊕ ≈ ”

to inquire about the power level or cooking mode. It will display for three seconds.

17. Air Fry

For air fry cooking you will need to select & confirm the type of food, please refer to the chart below.

(1) Press " ☐ " once and then " AF-1 " will display. (2) Press " 📋 " repeatedly or turn the knob to select the menu.

The 9 menus are available.

(3) Press " ▶ " to confirm.

(4) Press " ▶ " again to start cooking.

Note: For the menus "AF-1, AF-5, AF-6, and AF-9", the buzzer will sound to remind you to turn the food over during cooking. If no operation, the oven will continue working.

Air Fry Menu

Menu Weight(g)	Display		Power
Frozen Chips	AF-1 300		Conv.
Frozen Potato Balls	AF-2	350
Frozen Squid Rings	AF-3	300
Frozen Onion Rings	AF-4	250
Frozen Chicken Nuggets	AF-5	350
Steak	AF-6	400
Shrimps	AF-7	250
Vegetable	AF-8	200
Spring Rolls	AF-9	300

Troubleshooting

Normal
Microwave oven interfering TV reception	Radio and TV reception may be interfered when microwave oven operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal.
Dim oven light	In low power microwave cooking, oven light may become dim. It is normal.
Steam accumulating on door, hot air out of vents	In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal.
Oven started accidentally with no food in.	It is forbidden to run the unit without any food inside. It is very dangerous.

Trouble Possible Cause Remedy
Oven cannot be started.	(1) Power cord is not plugged in tightly.	Unplug. Then plug again after 10 seconds.
	(2) Fuse blowing or circuit breaker works.	Replace fuse or reset circuit breaker (repaired by professional personnel of our company)
	(3) Trouble with outlet.	Test outlet with other electrical appliances.
Oven does not heat.	(4) Door is not closed well.	Close door well.

According to the Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in the future you need to dispose of this product, please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available.

1) Glass Tray

Remarks:

Control panel

Microwave Frying

Grill/Combi/Convection

Defrost

Timer/Clock

Instructions Display Microwave Grill Convection

1	C-1	●		●
2	C-2	●	●
3	C-3		●	●
4	C-4	●	●	●

1) Glass tray

2) Turntable ring

Note:

1	C-1	●		●
2	C-2	●	●
3	C-3		●	●
4	C-4	●	●	●

Country Subsidiary Address City Phone

AustriaKüppersbusch Austria	Eitnergasse, 13	1231 Wien	[phone]
BelgiumKüppersbusch Belgium S.P.R.L.	Doomveld Industrie, Asse 3, No. 11 - Boite 7	1731 Zellik	[phone]
BulgariaTeka Bulgaria EOOD	Blvd. "Tsarigradsko Shosse" 135	1784 Sofia	[phone]
ChileTeka Chile S.A.	Avd El Retiro Parque los Maitenes, 1237. Parque Enea	Pudahuel, Santiago de Chile	[phone]
ChinaTeka International Trading (Shanghai) Co. Ltd.	No.1506, Shengyuan Henghua Bldg. No.200 Wending Rd.	Xuhui, Dist. 200030 Shanghai	[phone]
Czech RepublicTeka CZ S.R.O.	V Holesovickách, 593	182 00 Praha 8 - Liben	[phone]
EcuadorTeka Ecuador S.A.	Parque Ind. California 2, Via a Daule Km 12	Guayaquil	[phone]
GreeceTeka Hellas A.E.	Thesi Roupaki - Aspropyrgos	193 00 Athens	[phone]
HungaryTeka Magyarország Zrt.	Terv u. 92	9200 Mosonmagyaróvár	[phone]
IndonesiaPT Teka Buana	Jalan Menteng Raya, Kantor Taman A9 Unit A3	12950 Jakarta	[phone]
MalaysiaTeka Küchentechnik (Malaysia) Sdn Bhd	10 Jalan Kartunis U1/47, Temasya Park, Off Glenmarie	40150 Shah Alam, Selangor Darul Ehsan	[phone]
MexicoTeka Mexicana S.A. de C.V.	Blvd Manuel A. Camacho 126, Piso 3 Col. Chapultepec	11000 Mexico D.F.	[phone]
MoroccoTeka Maroc S.A.	73, Bd. Slimane, Depôt 33, Route de Ain Sebaa	Casablanca	[phone]
PeruTeka Küchentechnik Perú S.A.	Av. El Polo 670 local A 201, CC El polo, Surco	Lima	[phone]
PolandTeka Polska Sp. ZO.O.	ul. 3-go Maja 8 / A2	05-800 Pruszkow	[phone]
PortugalTeka Portugal S.A.	Estrada da Mota - Apdo 533	3834-909 Ilhavo, Aveiro	[phone]
RomaniaS.C. Teka Küchentechnik Romania S.R.L.	Sevastopol str., no 24, 5th floor, of. 15	010992 Bucharest Sector 1	[phone]
Russia/PоссияTeka Rus LLC/OOO "Teka Рус"	Neverovskogo 9, Office 417, 121170, Moscow, Russia	121087 Россия, Москва	[phone]
SingaporeTeka Singapore PTE Ltd	Clemenceau Avenue, 83, 01-33/34 UE Square	239920 Singapore	[phone]
SpainTeka Industrial, S.A.	C/ Cajo,17	39011 Santander	[phone]
ThailandTeka (Thailand) Co. Ltd.	364/8 Sri-Ayuttaya Road, Phayathai, Ratchatavee	10400 Bangkok	[phone]
TurkeyTeka Teknik Mutfak Aletleri Sanayi Ve	Büyükdere Cad. 24/13	80290 Mecidiyeköy, Istanbul	[phone]
UkraineTeka Ukraine LLC	86-e, Bozhenko Str .2nd floor,4th entrance	03150 Kyiv	[phone]
United Arab EmiratesTeka Middle East Fze	Building LOB 16, Office 417	P.O. Box 18251 Dubai	[phone]
United Arab EmiratesTeka Küchentechnik U.A.E LLC	Bin Khedia Centre	P.O. Box 35142 Dubai	[phone]
VenezuelaTeka Andina S.A.	Ctra. Petare-Santa Lucia, km 3 (El Limoncito)	1070 Caracas	[phone]
VietnamTEKA Vietnam Co., Ltd.	803, FI 8th, Daiminh Convention Center, 77, Hoang Van	Thai, Tan Phu Ward, District 7, Ho Chi Minh	[phone]

'TEKA

TEKA

teka.com
