Product Type	Ultra Short Throw Projector (Laser TV)
Model	L9H 100L9H
Brand	Hisense
Display Technology	DLP
Light Source	Laser
Native Resolution	4K (3840 x 2160)
Brightness	3000 ANSI Lumens
Contrast Ratio	100,000:1
Screen Size	100 inches
Throw Ratio	0.25:1
Lamp Life	25,000 hours
Dimensions (W x D x H)	27.6 x 9.8 x 20.5 inches (700 x 250 x 520 mm)
Weight	55 lbs (25 kg)
Power Consumption	350W
Input Voltage	100-240V AC, 50/60Hz
Connectivity	HDMI (3), USB (2), LAN, Optical, Audio Out
Built-in Speakers	Yes, 2x10W
Smart TV Platform	Android TV
HDR Support	Dolby Vision, HDR10, HLG
Cleaning Instructions	Use a soft, dry cloth to clean the lens and vents. Do not use liquids.
Safety Features	Includes auto shut-off, child lock, and heat protection.
Spare Parts and Repairability	Replaceable laser module, power supply, and fan. Serviceable by authorized technicians.

Frequently Asked Questions - L9H 100L9H HISENSE

How do I set up the Hisense L9H 100L9H projector?

Place the projector on a stable surface about 15-20 cm from the wall. Connect to power and a source via HDMI. Use the focus and keystone adjustments to align the image. Refer to the quick setup guide for detailed steps.

What is the recommended screen size for the L9H?

The L9H is designed for a 100-inch screen, but can project from 80 to 120 inches. The optimal distance is 20 cm from the wall for 100 inches.

How long does the laser light source last?

The laser module has a lifespan of up to 25,000 hours, which equates to about 8-10 years of average use (4 hours/day).

Can I use the projector with a non-Hisense screen?

Yes, but for best picture quality, use an ambient light rejecting (ALR) screen designed for ultra-short throw projectors. Regular screens may cause hotspots.

Does the L9H support 3D content?

No, the Hisense L9H does not support 3D. It focuses on 4K HDR and smart features.

How do I update the firmware?

Go to Settings > System > System Update. Connect to the internet via Wi-Fi or Ethernet. Check for updates and install if available. Do not power off during the update.

Can I connect Bluetooth headphones?

Yes, the projector supports Bluetooth audio. Go to Settings > Bluetooth > Pair device. Ensure your headphones are in pairing mode.

What maintenance does the projector require?

Clean the lens and vents monthly with a soft, dry cloth to prevent dust buildup. Avoid using liquids. Replace the air filter every 5000 hours (if equipped).

Why is the image blurry?

Check the focus ring and adjust it. Ensure the projector is placed at the correct distance and angle. Also, clean the lens if dirty.

What should I do if the projector overheats?

The projector will shut down automatically. Ensure ventilation is not blocked and the environment is cool. Clean the vents. If problem persists, contact Hisense support.

USER MANUAL L9H 100L9H HISENSE

QUICK SETUP GUIDE

Read the guide carefully and ensure you have fully understood its contents before operating this device for the first time.

English

HISENSE LIMITED PTY WARRANTY AND DISCLAIMER

ACCEPTANCE OF TERMS: Laser Televisions

By using this Laser Television, you agree to the terms and conditions outlined in the Warranty and, where applicable, the Disclaimer. If you do not agree to the terms and conditions you have the option to return the Laser Television to the relevant retailer within 7 days of the original purchased date and obtain a refund, provided the Laser Television has not been used or damaged.

HISENSE DISCLAIMER

THIRD PARTY CONTENT AND SERVICES: Laser Televisions

What does this Disclaimer apply to?

1. This Disclaimer applies in relation to any laser television (together with any remote and other accessories supplied with it) (Laser Television) supplied by Hisense Australia Pty Ltd (Hisense) or an Authorised Retailer, and if you can access any third party software application, content and/or services (Third Party Content and Services) through the Laser Television.
2. This Disclaimer does not limit your rights under the Australian Consumer Laws (for Australian customers) or the Consumer Guarantees Act 1993 (for New Zealand customers).

The basis on which Third Party Content and Services are provided

1. Third Party Content and Services are accessed and used at your own risk, regardless of who installed the Third Party Content and Services on the Laser Television. To the maximum extent permitted by law, Hisense makes no warranty, guarantee, representation or undertaking in relation to any Third Party Content and Services.
2. You must comply with any terms and conditions relating to the Third Party Content and Services.
3. Hisense can restrict your access or use of certain Third Party Content and Services.
4. Hisense is not liable or responsible for your use of the Third Party Content and Services, including for any:

a. charges relating to your use of the Third Party Content and Services; b. claims, liabilities, loss and damage arising out of (or in connection with) any of the Third Party Content and Services; c. breach of the law or the rights of any other person or entity arising from the use of any Third Party Content and Services; d. customer service or support in relation to any Third Party Content and Services

7. You acknowledge and agree that:

a. the performance of the Third Party Content and Services will depend on variables beyond the control of Hisense; b. certain Third Party Content and Services may require internet access, express consent regarding the collection and use of personal information, other accessories which are sold separately and/or other requirements; c. the Third Party Content and Services (including their intellectual property rights) will remain the property of the relevant provider of the Third Party Content and Services (Third Party Provider).

8. Your other obligations: You must:

a. ensure that your use of the Third Party Content and Services complies with all applicable laws, and the intellectual property and other rights of the Third Party Provider; b. not modify, duplicate, publish, upload, distribute, translate, adapt, market or use any part of the Third Party Content and Services, without the prior written consent of the relevant Third Party Provider unless expressly permitted by this Disclaimer, the Warranty or any other applicable terms and conditions; c. adhere to any additional terms where a Third Party Content or Service requires internet access; d. pay any additional charges relating to the use of a Third Party Content and Service.

Important Notice

Paragraphs beginning with the symbol ▲ indicate important instructions, tips or conditions for the following settings.

For your own safety and the optimal performance of your device, ensure to read the safety instructions before performing any installation.

Compatibility with 3rd party products, software and services are not guaranteed. We cannot be held liable for any damage or loss suffered whilst operating, using or connecting to incompatible devices or apps.

The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights of the content you wish to record or playback.

Read these instructions

Follow all instructions

Heed all warnings

Keep these instructions

All rights reserved.

Safety Instructions

To ensure safe and correct use of this product, always comply with the following precautions to avoid dangerous situations and damage to your unit:

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The intended use and ambient conditions for this device

This device is intended for the rendering of video and audio signals, on a table-top, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration. The warranty is only valid if used as intended by the manufacturer.

WARNING

High humidity and dust concentration may lead to current leaks in the device. To reduce the risk of fire or electrical shock:

• Do not expose this unit to rain, moisture, dripping or splashing water, and do not place objects filled with liquids, such as vases, cups, etc. on or over the unit.
• Do not touch the device with wet hands.
• Do not expose to direct air-conditioning and keep candles or other naked flames away from the device at all times.

If the device is moved from a cold environment to a hot environment, leave it switched off for at least an hour to avoid condensation. If used outside, make sure it is protected from moisture.

If you notice anything unusual, immediately remove the power plug.

In case of fire, use preferably a CO₂ gas or powder fire extinguisher. If such extinguishers are not accessible, try to isolate the electrical supply before using a water fire extinguisher.

A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

• ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the television set.
• ALWAYS use furniture that can safely support the television set.
• ALWAYS ensure the television set is not overhanging the edge of the supporting furniture.
• ALWAYS educate children about the dangers of climbing on furniture to reach the television set or its controls.
• ALWAYS route cords and cables connected to your television so they cannot be tripped over, pulled or grabbed.
• NEVER place a television set in an unstable location.
• NEVER place the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and television set to a suitable support.
• NEVER place the television set on cloth or other materials that may be located between the television set and supporting furniture.
• NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the television or furniture on which the television is placed.

If your existing television set is being retained and relocated, the same considerations as above should be applied.

■ Power Supply

Incorrect voltages can damage the device. Only connect this unit to a power supply with the correct voltage and frequency noted on the type plate, using the supplied power cable.

The power plug must be easily accessible so that the device can be disconnected at all times. The unit is live, even if in standby mode, as long as the unit is connected to a power outlet.

It is recommended that this unit is placed on a dedicated circuit.

- Do not overload the power outlets by connecting too many appliances to the same outlet. Overloaded wall outlets, extension cords, etc. are dangerous and can result in electric shock and fire.

After power off, don't turn it on again within 5 seconds. Frequent switching of the power supply in a short period of time can cause abnormal device operation.

■ Power plug and power cable

• Do not touch the power plug with wet hands.
• Do not place heavy objects on the power cable. Route the cable so that it is not kinked or laid over sharp edges, walked on, or exposed to chemicals. A power cable with damaged insulation can cause electric shock and fire.
• Pull the power plug, NOT the cable, when disconnecting. The cable can become damaged and cause a short circuit if pulled on.
• Do not place the power cable near a high-temperature object.
• Do not move the device with the power cable plugged into a socket.
• Do not use a damaged or loose power cable, or a damaged socket outlet.
• Do not use any power cords other than the one supplied with this unit.
• The MAIN plug on the power cord is used as the disconnect device. The disconnect device and socket-outlet shall be easily accessible.

■ Air ventilation and high temperatures

Install your device only where there is proper ventilation, and ensure that there is at least 20 cm free space on the sides and 15 cm free space on the back of the unit for air circulation. Excessive heat and obstruction of ventilation could lead to fire or early failure of some electric components.

• Do not block any ventilation openings with newspapers, tablecloths, curtains, etc.
• Do not dry clothing etc. on top of the unit.
• Take care not to touch the ventilation openings since they may become hot.
• Do not insert foreign objects into the device through the vents.

■ Warning about off-gassing

New furniture, carpet, paint, building materials and electronics can release chemicals into the air through evaporation. After you set your device up and turn it on for the first time, you may notice a slight smell within a couple of hours. This is because some components of the device are heating up for the first time. The materials that we use fully meet the environmental requirements and regulations. Your device is working just fine and the fumes from the off-gassing will diminish eventually.

■ Supervision

• Do not let children play unsupervised close to the device. It could tip over, be pushed off or pulled down from the stand surface and injure someone.
• Do not allow a switched-on device to run unattended.

Volume

Loud music and noises can lead to irreversible damage to your ears. Avoid extreme volume, especially over long periods and when using headphones.

If you hear a drumming noise in your ears, turn down the volume or temporarily stop using headphones.

■ Thunderstorms

Pull out the power plug and all connected antenna cables from the device during a thunderstorm. Overvoltage caused by lightning strikes can damage the device via the antenna system, as well as the wall socket.

■ Long periods of absence

As long as the power plug is connected to a live socket outlet, the device will consume power even in standby mode. The power plug and all connected antenna cables should be disconnected during long periods of absence.

■ Cleaning and care

CAUTION:

Unplug the power cord prior to cleaning the device.

Clean the device, the screen, and the remote control with a soft, moist, clean and color-natural cloth only. Do not use any chemicals.

• Do not subject the surfaces to insect repellent, solvent, thinner or other volatile substances. This may degrade the surface quality.
• Do not spray water or other liquids directly on the device. Liquid inside the device could lead to product failure.
• The surface of the display panel is treated and may be easily damaged. Take care not to scratch it with fingernails or other hard objects.
• Also wipe the power plug with a dry cloth at regular intervals.

■ Service/Repair

Never remove the cover/back of the device; there are no user serviceable parts inside. Refer all service to qualified service personnel.

Packaging

Keep the anti-moisture materials and plastic bags out of reach of children.

Plastic bags can cause suffocation and the anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital.

■ Modification

Do not attempt to modify this product in any way. Unauthorized modification could void the warranty of this unit, cause electric shock and fires.

■ Remote Control batteries

• Incorrect installation may cause battery leakage, corrosion and explosion.
• Replace only with the same or equivalent type.
• Do not mix old and new batteries.
• Do not mix different battery types.
• Do not use rechargeable batteries.
• Do not burn or break up batteries.
• Be sure to dispose of batteries correctly.
• Do not expose batteries to excessive heat such as sunshine, fire or the like.

■ Outdoor Antenna Grounding

If an outdoor antenna is used, be sure the antenna system is protected against voltage surges and built-up static charges.

■ Disposal

Refer to the recycling section of this guide.

■ Laser

Do not look directly at the lens when this device is on because the laser light may damage your eyes!

- This product comes with a laser module. Do not tear or modify this device in any manner; otherwise, it may result in personal injury.

RG2

As with any bright light source, DO NOT STARE INTO THE BEAM IEC 62471-5: 2015

CLASS 1 LASER PRODUCT

λ = 459 471nm / 519 531nm / 635 651nm

Wavelength 459\~471nm/519\~531nm/635\~651nm

CLASS 1 LASER PRODUCT

IEC 60825-1: 2014

CAUTION:

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

• If this device requires repair, please wear laser eye protection with an optical density (OD) of 4 or higher and a wavelength of 459-651 nm.
• Do not place any water-containing vessel on this device, such as cosmetics or liquid medicine.
• If any object or water enters this device, please unplug this device and contact the service staff of Hisense.
• Do not place any exposed fire source (e.g., burning candle) on this device. Keep away from high temperature and heat.
• Do not expose the battery to direct sunlight or candle light.
• Keep air vents on both sides clear from any objects to prevent the device from overheating inside.
• To avoid a short circuit, product damage, or electric shock, do not use any sharp object or metal to touch the ports or other openings on the Laser TV.
• If this device has been in a warm environment, allow any built-up condensation to evaporate first BEFORE you switch the device on.
• Do not allow a child to stand on or climb up this device.
• Do not place any object above or in front of the lens because the laser light could cause the object to become flammable.
• Clean the lens periodically with a clean cloth and make sure the Laser TV is turned off before you start.

AC voltage: This symbol indicates that the rated voltage marked with the symbol is AC voltage.

Class II product: This symbol indicates that it does not require a safety connection of protective earthing (ground).

Congratulations on the purchase of your new Laser TV! This Guide will walk you through a few easy steps to set up your Laser TV.

Please visit Hisense official website for more details.

Product image is only for reference, actual product may vary in appearance.

Parts of the software function changes with the system upgrade.

Table of Contents

Accessories	List			2
Laser	TV	Diagram		3
STEP 1. Mount the Screen		4
STEP 2. Install the Laser TV		4
STEP 3. Adjust the Display Image and the Screen			9
STEP	4.	Use	Your	Remote	12
STEP 5. Proceed through the Screen Setup Menu			14
Maintenance & Quick Problem-Solving Tips			16
Product Specifications		18
Recycling / Licenses		19

Accessories List

• Laser TV × 1
• Remote control × 1 • AA or AAA batteries × 2
• Gloves for handling the Laser TV × 2
• Power cord × 1
• Wrench to adjust the bottom of the Laser TV × 1
• USB extension cable × 1
• Laser TV Quick Setup Guide × 1 • Laser TV Warranty Card × 1
• Cleaning kit for the lens × 1 • C-shape blocks × 2 • C-shaped Block Installing Instruction × 1

Additional items that come with the Laser TV in a separate package

• A Display Screen (optional equipment)*
• A set of Wall Mount Brackets (optional equipment)*

* Additional items you receive will be based upon your order.

NOTE: The accessories may be different from the list above due to different models, countries/regions. Please refer to the actual accessory bag.

Laser TV Diagram

We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device.

STEP 1 Mount the Screen

Screen installation please refer to the specific screen installation guide!

STEP 2 Install the Laser TV

We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device.

We recommend to connect all cables to the ports on the back of the Laser TV before positioning the Laser TV. (Audio, video, Ethernet cables and external devices are not included.)

Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can affect the quality of the picture image and colour.

NOTE:

• Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider's instructions.
• Do not repeatedly insert or remove the Common Access Module as this may damage the interface and cause a malfunction.
• You must obtain a CI+ module and card from the service provider of the channels you want to watch.
• Insert the CI+ module with the SmartCard in the direction marked on the module and SmartCard.
• CI+ is not supported in some countries and regions; check with your authorized dealer.

NOTE:

• When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply. Exceeding a total current consumption may result in damage. The USB1.1 and USB2.0 devices maximum current consumption are 500mA. The USB3.0 device maximum current consumption is 1A.
• For individual non-standard high-capacity mobile hard disk, if its impulse current is greater than or equal 1A, it may cause TV-rebooting or self-locking. So the TV does not support it. • The USB port supports a voltage of 5V. • Use the USB extension cable (included) for easier connection and disconnection.

LAN (Wired setup)

- Connect your Laser TV to your network by connecting the LAN port on the back of your Laser TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below.

Laser TV PORT

Wireless setup

- Connect your Laser TV to your network wirelessly, you need a wireless router or modem. See the illustration below.

NOTE:

• You must use the built-in Wireless LAN Adapter to use a wireless network because the set doesn't support external USB network adapters. If the wireless router supports DHCP, your Laser TV can connect more easily to the wireless network.
• If you apply a security system other than the systems listed below, it will not work with the Laser TV. Security systems: WPA, WEP, WPA2. In order to guarantee smooth network, the distance between router and Laser TV should be less than 10 metres.

Plug the power cord into a wall outlet.

Press the POWER button to turn on the Laser TV.

WARNING: Insufficient ventilation space will cause this device to overheat or become damaged.

- Do not block the air vents or place any object on this device. - Do not place this device in any narrow, enclosed or poorly ventilated space.

At a minimum, leave the amount of space shown in the diagram below for this device to have proper ventilation.

STEP 3 Adjust the Display Image and the Screen

• Follow the steps in the order shown below, only if they apply to your situation.
• Before adjusting, fold the wall-mount bracket wands so that screen is vertically level.
• Rotate feet from an overlooking view, but do not look directly at the lens when the Laser TV is on because the laser light may damage your eyes.

PARALLEL THE BOTTOM OF THE IMAGE WITH THE SCREEN

If the bottom of the image is lower on the left and higher on the right, rotate the device counterclockwise.

If the bottom of the image is lower on the right and higher on the left, rotate the device clockwise.

FIT THE BOTTOM OF THE IMAGE TO THE SCREEN

Make sure the bottom of the image always stays parallel with the screen. If not, rotate the TV following previous instructions.

If the image shifts to the left side, then move the Laser TV to the right.

If the image shifts to the right side, then move the Laser TV to the left.

If the bottom of the image is wider than the screen, then move the Laser TV closer to the screen.

If the bottom of the image is narrower than the screen, then move the Laser TV farther from the screen.

ADJUST THE UPPER-RIGHT CORNER OF THE IMAGE

1. If the top of the image is lower on the left and higher on the right, rotate the front-right foot and the back-right foot clockwise to the same height.

1. Now, rotate the TV counterclockwise so that the bottom of the image is parallel with the screen.

1. Repeat the steps above until the top of the image is parallel with the screen.
2. If the upper-right corner is inside the screen after adjusting, rotate the front-right foot and the back-right foot counterclockwise to the same height, and rotate the TV clockwise, to make the image parallel with the screen.

ADJUST THE UPPER-LEFT CORNER OF THE IMAGE

1. If the top of the image is higher on the left and lower on the right, rotate the front-left foot and the back-left foot of the TV clockwise to the same height.

1. Now, rotate the TV clockwise so that the bottom of the image is parallel with the screen.

1. Repeat the steps above until the top of the image is parallel with the screen.
2. If the upper-left corner is inside the screen after adjusting, rotate the front-left foot and the back-left foot counterclockwise to the same height, and rotate the TV counterclockwise, to make the image parallel with the screen.

FILL THE TOP OF THE IMAGE TO THE SCREEN

If the top of the image is wider than the screen, then rotate the left- and right-front feet of the Laser TV clockwise.

If the top of the image is narrower than the screen, then rotate the left- and right-back feet of the Laser TV clockwise, until the left and right borders of the image are parallel with the screen borders.

Next, move the projector further from the screen to fill the image to screen width.

If the back feet are already at their maximum height, rotate the left- and right-front feet counterclockwise.

STEP 4 Use Your Remote

BUTTONS ON YOUR TV REMOTE

NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the TV may differ from this diagram.

① POWER: Switch the TV on or into standby mode. ② INPUT: Select input sources. ③ APP: Quick access buttons to apps. EDIT: Custom to launch input or app. ④ Physical Switch (Side view): Turn on to activate hands-free wake-up feature*. ⑤ Special function buttons. ⑥ : Display the Quick setup menu. ⑦▶||: Media content control function button. ⑧ ∧/ √</ > : Allow you to navigate the on-screen menus and adjust the system settings to your preference. ⑨ OK: Confirm the selection in the on-screen menus. ⑩ BACK: Return to previous menu. ⑪ EXIT: Exit the menu. ⑫ HOME: Enter the Home screen. ⑬ VOL + / -: Adjust the volume. ⑭ CH ↗: Switch channel. ⑮ MIC: Activate the microphone.

⑯ SUBTITLE: Activate or deactivate the subtitle mode. ⑰ INFO: Display the present programme information. ⑱ MUTE: Mute or restore the TV sound. ⑲ Number buttons: Direct channel selection or numbers input. ⑳ GUIDE: Display the Electronic Programme Guide (DTV mode). ② CH.LIST: Display the Channel List on the screen.

When you do not use hands-free wake-up, please turn off the physical switch to lengthen the battery life.

NOTE: The included remote control will vary depending on models, countries/regions. Check information according to the actual remote control in the accessory bag.

1. Slide the back cover to open the battery compartment of the remote control.
2. Insert two AA or AAA size batteries. Make sure to match the (+) and (-) ends of the batteries with the (+) and (-) ends indicated in the battery compartment.
3. Close the battery compartment with the cover.

IMPORTANT INFORMATION ABOUT THE REMOTE AND BATTERIES

• Discard batteries in a designated disposal area. Do not throw them into a fire.
• Remove old batteries immediately to prevent them from leaking into the battery compartment.
• If you do not intend to use the remote control for a long time, then remove the batteries.
• Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with a cloth. If chemicals touch your skin then wash it immediately.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (NiCd, NiMH, etc.) batteries.
• Do not continue using the remote if it gets warm or hot.
• Call our Support Center immediately on the support website.

REMOTE CONTROL RANGE INFORMATION

• The remote control can work at a distance of up to 8 metres in front of the Laser TV. (This distance is used by infrared means in an unpaired state.)
• The remote control angle: taking the remote sensor as an apex, 6 metres away, its controlled horizontal angle is within ±30°, while the vertical angle is within ±15°. (This angle is used by infrared means in an unpaired state.)

PAIRING THE REMOTE CONTROL (ONLY FOR BLUETOOTH REMOTE CONTROL)

Pair the remote to the Laser TV after you power it on. Keep the remote control within 3 metres from the Laser TV. Press any button (except power and mic button) to pair.

NOTE:

• In special cases, press and hold [ E button to pair.
• If an unknown error occurred with the remote, then it could have been caused by interference. Try to remove what's causing the interference and pair it again.
• If an unknown error occurred in the remote control while the battery power is normal, you can take out the batteries, press any key for 1~2 seconds, and insert them back. Then the remote control will work normally.
• The remote cannot be paired to the Laser TV while the Laser TV is in standby mode.

STEP 5 Proceed through the Screen Setup Menu

PROJECTION MODE

If you need to flip the image over top-to-bottom and/or left-to-right, select the Projection Mode.

AUTO GEOMETRIC CORRECTION

Before you use the Auto Geometric Correction function, ensure that the Laser TV and your mobile device are connected to the same wireless network.

1. Adjust the Laser TV position by using the levelling feet as needed, and ensure the frame of the screen is located inside the rectangular border.

1. Click Next to continue.
2. Scan the QR Code with your mobile device to begin Automatic Geometric Correction. After a few moments, an alignment grid pattern will appear on the screen.

Alignment grid

1. Click "+" on your mobile device to take a photo of the full screen. For best results, stand about 10 feet away from the screen and use landscape mode.
2. Click "upload" on your mobile device to complete the Automatic Geometric Correction.

NOTE:

• Please ensure you are standing in front of the screen to take the photo, with no deviation of more than 25 degrees from the centre of the screen.
• Please ensure the whole screen is fully visible in the photo, including the frame of the display.
• Please ensure all 16 points of the grid on the screen are in focus when taking the photo.
• Please ensure the screen image takes up at least 60% of the overall photo size for correct geometric correction.

MANUAL GEOMETRIC CORRECTION

Select points and move them to fit the projected image into the screen.

NOTE:

Manual Geometric Correction may not be applicable in some models/countries/regions.

1. Press ∧/∨/</> buttons on your remote control to move focus, and press OK button to choose a point you need to adjust.
2. Long press ∧/∨/</> buttons: quick adjustment of the projected image;

Short press ∧/∨/</> buttons: precise adjustment of the projected image.

1. Press button to save your adjustment, and you can select other points to adjust the image.

If you want to return the image position to the factory default, select Reset on the screen.

EYE PROTECTION

In order to protect your eyes, keep the Eye Protection on, and do not look into the lens. If you get too close to the Laser TV, the light output will be temporarily disabled after 5 seconds.

Maintenance

• Do not touch this device when it is running or just turned off because it may be hot.
• Do not wipe this device with oil because it may deteriorate the exterior or damage the paint. Contact with rubber or ethylene products for a long time may cause stains on this device.
• If the outside of the TV is dirty, turn off the TV and wipe with a damped soft cloth.
• Do not touch the lens with your hands.
• Do not touch or wipe the lens with ordinary cleaning cloth. Use a dust blower to remove the dust on the lens. Grease, dirt and fingerprints should be cleaned carefully by the professional by using optical cleaning cloth, lens wiping paper or professional cleaning solutions to avoid destroying the optical filming and affecting the image quality.
• To turn off this device, press the Power button on the remote control. Do not cut off the power directly when the device is working.

Quick Problem-Solving Tips

When you experience an issue with your TV, turn it off and on again. If this does not resolve the problem, then refer to the tips below.

When I turn on my TV, there is a delay for a few seconds before the picture appears. Is this normal?

Yes, this is normal. The TV is initializing and searching for previous setting information.

The light output of the projector is disabled.

In this case, if the power indicator illuminates red light for 5 times, please check whether the foreign object detection window is covered or dirtied. If so, uncover or carefully clean the foreign object detection window.

No sound or picture

1. Check if the power cord is plugged into a powered AC outlet.
2. Press the Power button on the remote control to activate the unit from 'Standby' mode.
3. Check to see if the LED light is on or not. If it is, then the TV is receiving power.

I have connected an external source to my TV and I get no picture and/or sound.

1. Check for the correct output connection on the external source and for the correct input connection on the TV.
2. Make sure you have made the correct selection for the input mode for the incoming signal.

The picture is normal but there is no sound

1. Check the volume settings.
2. Check if 'Mute' mode is set to On.

Sound but no picture or black and white picture

1. If the picture is black and white, unplug the TV from the AC outlet and replug it after 60 seconds.
2. Check that the Colour is set to 50 or higher.
3. Try different TV channels.

The sound and/or picture is distorted or appears wavy

1. An electric appliance may be affecting the TV. Turn off any appliances that are nearby and move it farther away from the TV.
2. Insert the power plug of the TV set into another power outlet.

The sound and picture is blurry or cuts out

1. If using an external antenna, check the direction, position and connection of the antenna.
2. Adjust the direction of your antenna or reset or fine tune the channel.

The plastic cabinet makes a "clicking" type of sound

The 'click' sound can occur when the temperature of the television changes. This change causes the television cabinet to expand or contract, which makes the sound. This is normal and the TV is OK.

The remote control does not work

1. Confirm that TV still has power and is operational.
2. Change the batteries in the remote control.
3. Check if the batteries are correctly installed.

Product Specifications

Model Name		100" Laser TV
Dimension (W × H × D)		24.0 × 6.1 × 13.6 inches(610 × 155 × 346 mm)
Weight		24.7 lbs (11.2 kg)
Active Screen Size (Diagonal)		100 inches
Screen resolution		3840 × 2160
Audio power		2 × 20 W
Power consumption		300 W
Power supply		120-240V ~ 50/60Hz
Receiving systems	Analog	PAL-D/K, B/G, I, SECAM-D/K, B/G
	Digital	DVB-T/T2, DVB-C, DVB-S/S2
Environmental conditions		Temperature: 41°F - 104°F (5°C - 40°C)Humidity: 20% - 80% RHAtmospheric pressure: 86 kPa - 106 kPa
HDMI Input		RGB / 60 Hz (640×480, 800×600, 1024×768)YUV / 60 Hz (480i, 480p, 720p, 1080i, 1080p)YUV / 50Hz (576i, 720p, 1080i, 1080p)3840×2160 / 24Hz, 3840×2160 / 25Hz, 3840×2160 / 30Hz3840×2160 / 50Hz, 3840×2160 / 60Hz
Network Standby Power Consumption		≤ 2.0 W
Power Consumption in Standby Mode		≤ 0.5 W

Disclaimer: All products, product specifications, and data are subject to change without notice to improve reliability, function, design or otherwise.

Recycling / Licenses

This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 2012–2022 Dolby Laboratories. All rights reserved.

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO") AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM

ES-A2234Z0-1
