Product TypeFreestanding Refrigerator-Freezer
BrandCandy
ModelCFTE 3450 LE
Total Gross Capacity345 liters (approx.)
Fridge Capacity250 liters (approx.)
Freezer Capacity95 liters (approx.)
Energy ClassE (typical for this model)
Annual Energy Consumption190 kWh (approx.)
Noise Level40 dB (approx.)
Climate ClassN-ST
Defrost Type FridgeAutomatic (No Frost or Frost Free not specified, likely automatic)
Defrost Type FreezerManual (typical for this class)
Number of Shelves4 (approx.)
Number of Drawers2 (approx.)
Reversible DoorYes
Dimensions (HxWxD)1850 x 595 x 600 mm (approx.)
Weight62 kg (approx.)
Power Supply220-240 V, 50 Hz
RefrigerantR600a
Spare Parts AvailabilityStandard (up to 10 years after production)
MaintenanceClean with mild soap and water; avoid abrasive cleaners
Safety FeaturesChild lock (if equipped), stabilized glass shelves

Frequently Asked Questions - CFTE 3450 LE CANDY

What is the total capacity of the Candy CFTE 3450 LE fridge?
The total gross capacity is approximately 345 liters, with about 250 liters for the fridge and 95 liters for the freezer compartment.
How do I reverse the door on this refrigerator?
The door is reversible. You can change the opening direction by following the instructions in the manual: unscrew the hinges, swap the door handles, and reattach the hinges on the opposite side. Ensure the appliance is unplugged before starting.
What is the energy efficiency class?
The Candy CFTE 3450 LE has an energy efficiency class of E (on a scale from A to G, where A is most efficient). Annual consumption is around 190 kWh.
Does the fridge have a No Frost function?
This model does not feature No Frost. The fridge compartment defrosts automatically, but the freezer requires manual defrosting when ice build-up reaches about 5 mm.
What are the dimensions of the Candy CFTE 3450 LE?
Approximate dimensions: height 1850 mm, width 595 mm, depth 600 mm. Always check the exact measurements in the manual to ensure proper fit.
How do I adjust the temperature?
The temperature control is usually a dial inside the fridge compartment. Turn it to a higher number for colder temperatures. For optimal performance, set the fridge to 4°C and the freezer to -18°C.
Why is my refrigerator not cooling properly?
Check if the thermostat is set correctly, ensure the door seals are clean and tight, and that there is adequate ventilation around the appliance. Also, verify that the condenser coils are not dusty.
How do I clean the refrigerator?
Unplug the appliance. Remove shelves and drawers and wash them with warm soapy water. Wipe the interior with a solution of baking soda and water. Dry thoroughly before replacing parts.
Where can I find spare parts?
Spare parts are available from Candy authorized service centers or online spare parts retailers. Use the model number CFTE 3450 LE when ordering.
What should I do if the door is not sealing properly?
Clean the door gasket with mild detergent and water. If the seal is damaged or deformed, it may need to be replaced. Adjust the door hinges if the door is misaligned.

User questions about CFTE 3450 LE CANDY

0 question about this device. Answer the ones you know or ask your own.

Ask a new question about this device

Your email remains private: it is only used to notify you if someone answers your question.

No questions yet. Be the first to ask one.

Download the instructions for your Refrigerator in PDF format for free! Find your manual CFTE 3450 LE - CANDY and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. CFTE 3450 LE by CANDY.

USER MANUAL CFTE 3450 LE CANDY

SAFETY INFORMATION 2

Old and out-of-order fridges .... 5

Safety warnings....5

Installing and operating your fridge 6

Before Using your Fridge 7

THE VARIOUS FUNCTION AND POSSIBILITIES .... 7

Thermostat Setting 7

Display Panel 8

Turning On The Appliance 8

Warnings about Temperature Adjustments 8

Accessories....9

Ice tray 9

Bottle holder 9

ARRANGING FOOD IN THE APPLIANCE 9

Refrigerator Compartment....9

Freezer Compartment 10

CLEANING AND MAINTENANCE 11

Defrosting refrigerator compartment 11

Defrosting the Freezer Compartment 12

Replacing the Refrigerator Light Bulb 12

TRANSPORTATION AND CHANGING OF 13

INSTALLATION POSITION 13

Transportation and Changing of Installation Position 13

Repositioning the door 13

BEFORE CALLING YOUR AFTER SALES SERVICE 13

Tips For Saving Energy 14

THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS 15

Thank you for purchasing this product.

Before using your refrigerator, please carefully read this instruction manual in order to maximize its performance. Store all documentation for subsequent use or for other owners. This product is intended solely for household use or similar applications such as:

the kitchen area for personnel in shops, offices and other working environments on farms, by clientele of hotels, motels and other environments of a residential type at bed and breakfasts (B & B)

for catering services and similar applications not for retail sale.

This appliance must be used only for purposes of storage of food, any other use is considered dangerous and the manufacturer will not be responsible for any omissions. Also, it is recommended that you take note of the warranty conditions.

PART- 1. BEFORE USING THE APPLIANCE

SAFETY INFORMATION

The refrigerator contains a refrigerant gas (R600a: isobutane) and insulating gas (cyclopentane), with high compatibility with the environment, that are, however, flammable.

We recommend that you follow the following regulations so as to avoid situations dangerous to you:

Before performing any operation, unplug the power cord from the power socket.

- The refrigeration system positioned behind and inside the Wine Coolers contains refrigerant. Therefore, avoid damaging the tubes.

- If in the refrigeration system a leak is noted, do not touch the wall outlet and do not use open flames. Open the window and let air into the room. Then call a service centre to ask for repair.

- Do not scrape with a knife or sharp object to remove frost or ice that occurs. With these, the refrigerant circuit can be damaged, the spill from which can cause a fire or damage your eyes.

- Do not install the appliance in humid, oily or dusty places, nor expose it to direct sunlight and to water.

  • Do not install the appliance near heaters or inflammable materials.
  • Do not use extension cords or adapters.
  • Do not excessively pull or fold the power cord or touch the plug with wet hands.
  • Do not damage the plug and/or the power cord; this could cause electrical shocks or fires.
  • It is recommended to keep the plug clean, as any excessive dust residues on the plug can be the cause of fire.

WARNING: Do not use mechanical devices or other equipment to hasten the defrosting process.

  • Absolutely avoid the use of open flame or electrical equipment, such as heaters, steam cleaners, candles, oil lamps and the like, in order to speed up the defrosting phase.
  • Do not use or store inflammable sprays, such as spray paint, near the Wine Coolers. It could cause an explosion or fire.

WARNING: Do not use electrical appliances inside the food storage compartments, unless they are of the type recommended by the manufacturer.

  • Do not place or store inflammable and highly volatile materials such as ether, petrol, LPG, propane gas, aerosol spray cans, adhesives, pure alcohol, etc. These materials may cause an explosion.
  • Do not store medicine or research materials in the Wine Coolers. When the material that requires a strict control of storage temperatures is to be stored, it is possible that it will deteriorate or an uncontrolled reaction may occur that can cause risks.
  • Maintain the ventilation openings in the appliance enclosure or in the built-in structure, free of obstruction.

- Do not place objects and/or containers filled with water on the top of the appliance.

- Do not perform repairs on this Wine Coolers. All interventions must be performed solely by qualified personnel.

- This appliance can be used by children aged from 8 years and above and by persons with reduced physical, sensory or mental capabilities or with a lack of experience and knowledge; provided that they have been given adequate supervision or instruction concerning how to use the appliance in a safe way and understand the hazards involved.

- Children should not play with the appliance. Cleaning and user maintenance should not be made by children without supervision.

WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not damage the refrigerant circuit.

- If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid a hazard.

- A specially grounded plug has been connected to the power cable of your refrigerator. This plug should be used with a specially grounded socket of 16 amperes. If there is no such socket in your house, please have one installed by an authorised electrician.

- If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service agent or similar qualified persons, in order to avoid a hazard.

- This appliance is not intended for use at altitudes exceeding 2000 m.

Old and out-of-order fridges

Pure electrical circuit lines without any symbols

- If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident.

- Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC. Therefore, take care not to harm environment when you are discarding your old fridges.

Please ask your municipal authority about the disposal of the WEEE reuse, recycle and recovery purposes.

Notes:

- Please read the instruction manual carefully before installing and using your appliance. We are not responsible for the damage occurred due to misuse.

- Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.

- This appliance is produced to be used in homes and it can only be used in domestic environments and for the specified purposes. It is not suitable for commercial or common use. Such use will cause the guarantee of the appliance to be cancelled and our company will not be responsible for losses incurred.

- This appliance is produced to be used in houses and it is only suitable for cooling / storing food. It is not suitable for commercial or common use and/or for storing substances except for food. Our company is not responsible for losses to be incurred in the contrary case.

Safety warnings

- Do not connect your Fridge Freezer to the mains electricity supply using an extension lead.

- Do not plug in damaged, torn or old plugs.

- Do not pull, bend or damage the cord.

Cartoon illustration of an electric plug with a warning sign and plug, showing electrical hazard (no text or symbols)

Illustration of four different techniques for using a tool, showing hand positioning and cutting process (no text or symbols)

- This appliance is designed for use by adults. Do not allow children to play with the appliance or hang off the door.

- Never touch the power cord or plug with wet hands, as this could cause a short circuit or electric shock.

- Do not place glass bottles or beverage cans in the ice-making compartment, as they can burst when the contents freeze.

- Do not place explosive or flammable materials in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and ensure their tops are tightly closed.

- When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts.

Cartoon illustration of a person inside a refrigerator with arms outstretched (no text or symbols)

Simple line drawing of a hand holding a smiling face, a crossed-out prohibition symbol, and a small icon (no text or labels)

Simple line drawing of two bottles and a glass with bubbles, no text or symbols present

- Do not touch frozen goods with wet hands. Do not eat ice cream or ice cubes immediately after taking them out of the ice-making compartment.

- Do not re-freeze frozen goods after they have melted. This may cause health issues such as food poisoning.

- Do not cover the body or top of the fridge with lace. This affects the performance of your fridge.

- Secure any accessories in the fridge during transportation to prevent damage to the accessories.

Installing and operating your fridge

Before using your fridge, you should pay attention to the following points:

• The operating voltage for your fridge is 220-240 V at 50Hz.

- The mains cord of your fridge is fitted with a grounded plug. This plug should be used with a grounded receptacle that has a 16 ampere fuse minimum. If you don't have a receptacle that conforms to this, contact a qualified electrician.

- We do not accept responsibility for any damages that occur due to ungrounded usage.

- Place your fridge where it will not be exposed to direct sunlight.

- Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores, and at least 5 cm away from electrical ovens.

- Your fridge should never be used outdoors or exposed to rain.

- When your fridge is placed next to a deep freezer, there should be at least 2 cm between them to prevent humidity forming on the outer surface.

- Do not place anything on your fridge, and install your fridge in a suitable place so that at least 15 cm of free space is available above it.

- Use the adjustable front legs to make sure your appliance is level and stable. You can adjust the legs by turning them in either direction. This should be done before placing food in the fridge.

- Before using your fridge, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate, then rinse with clean water and dry.

Place all parts in the fridge after cleaning.

- Install the plastic distance guide (the part with black vanes at the rear) by turning it 90° (as shown in the figure) to prevent the condenser from touching the wall.

- The refrigerator should be placed against a wall with a free space not exceeding 75 mm.

Cartoon illustration of a distressed container with arms and legs, holding a box labeled 'KG' (no text or symbols beyond the label)

CANDY CFTE 3450 LE - Installing and operating your fridge - 2

CANDY CFTE 3450 LE - Installing and operating your fridge - 3

Before Using Your Fridge

Simple line drawing of a hand holding a smiling square character (no text or symbols)

- When using your fridge for the first time, or after transportation, keep it in an upright position for at least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the compressor.

- Your fridge may have a smell when it is operated for the first time. This is normal.

PART 2. THE VARIOUS FUNCTIONS AND POSSIBILITIES

Thermostat Setting

FREEZER & REFRIGERATOR THERMOSTAT

Freezer Control Refrigerator Control Freezer Control LED Indicator FREE ZE R POWER COOLER

Freezer and refrigerator thermostat automatically regulates the inside temperature of the compartments. By rotating the knob from position 1 to 5, colder temperatures can be obtained.

Important note: Do not try to rotate knob beyond 1 position it will stop your appliance.

Freezer Thermostat Setting;

1-2: For short-term storage of food in the freezer compartment, you can set the knob between minimum and medium position.

3-4 : For long-term storage of food in the freezer compartment, you can set knob medium position.

5 : For freezing the fresh food. The appliance will work longer. So after you get the cold condition you must position to previous position.

Refrigerator Thermostat Setting;

1-2: For less coldly conditions.

3-4 : For normal conditions.

5 : For colder conditions.

Note that: the ambient temperature, temperature of the freshly stored food and how often the door is opened, affects the temperature in the refrigerator and freezer compartment. If required, change the temperature setting.

Display Panel

Combi models have double compressors as one of them is for refrigerator compartment, and the other is for freezer compartment.

ORANGE LAMP: When the freezer compartment is on operation, the orange lamp will turn on until the compartment reaches to temperature you wanted.

GREEN LAMP: When the appliance is connected to the power supply, the green lamp on the display panel will turn on automatically.

ORANGE LAMP: When the refrigerator compartment is in operation, the orange lamp will turn on until the compartment reaches the temperature you wanted.

Turning On The Appliance

Once the appliance has been connected to the power supply, make sure that the GREEN lamp is on. Then turn the refrigerator thermostat dial and the freezer thermostat dial to a position between 2-4. (Note that for best internal temperature, the indicator on the refrigerator and freezer thermostat should be positioned between 2 and 4.)

Warnings about Temperature Adjustments

  • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency.
  • Temperature adjustments should be made according to the frequency of door openings and the quantity of food kept inside the fridge.
  • Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after being plugged in to be completely cooled. Do not open the doors of your fridge frequently and do not place much food inside it during this period.
  • A 5-minute delaying function is applied to prevent damage to the compressor of your fridge when you take the plug off and then plug it on again to operate it, or

when an energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.

- Your fridge is designed to operate in the ambient temperature intervals stated in the standards, according to the climate class stated in the information label. We do not recommend operating your fridge outside the stated temperature value limits in

terms of cooling effectiveness.

- This appliance is designed for use at an ambient temperature within the 16°C - 32°C range.

Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
N Between 16 and 32 (°C)
SNBetween 10 and 32 (°C)

Accessories

Ice tray

- Fill the ice tray with water and place it in the freezer compartment.

- After the water has completely turned into ice, you can twist the tray as shown below to get the ice cubes.

Illustration showing three steps of a dental tool: pressing a tooth into a tray, moving a tray with arrows indicating rotation, and removing a tooth with a black X mark (no text or symbols)

Bottle holder (only on some models)

To prevent bottles from slipping or falling over, you can use the bottle holder. This also helps reduce noise when opening or closing the door.

Simple line drawing of a bottle mounted on a base (no text or symbols)

PART 3: ARRANGING FOOD IN THE APPLIANCE

Refrigerator Compartment

- To reduce humidity and the resulting increase in frost, never place liquids in unsealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporator and will eventually require more frequent defrosting.

- Never place warm food in the refrigerator. Warm food should be allowed to cool to room temperature and should be arranged to ensure adequate air circulation in the refrigerator compartment.

- Nothing should touch the back wall of the refrigerator, as this can cause frost and packages may stick to it. Do not open the refrigerator door too frequently.

- Arrange meat and cleaned fish (wrapped in packages or plastic sheets) that you will use within 1-2 days.

- You can place fruits and vegetables in the crisper without packing.

Freezer Compartment

  • The freezer is used for storing deep-frozen or frozen food for long periods and for making ice cubes.
  • Do not place fresh and warm food in the freezer door shelves to be frozen. These shelves are only for storing frozen food.
  • Do not place fresh and warm food next to frozen food, as it can thaw the frozen food.
  • When freezing fresh food (i.e., meat, fish, and mincemeat), divide it into portions that you will use at one time.
  • For storing frozen food, always follow the instructions on the frozen food packages carefully. If no information is provided, the food should not be stored for more than 3 months from the purchase date.
  • When buying frozen food, ensure that it has been frozen at suitable temperatures and that the packaging is intact.
  • Frozen food should be transported in appropriate containers to maintain its quality and should be returned to the freezing surfaces of the unit in the shortest possible time.
  • If a package of frozen food shows signs of humidity and abnormal swelling, it is probable that it has been previously stored at an unsuitable temperature and that the contents have deteriorated.
  • The storage life of frozen food depends on the room temperature, thermostat setting, how often the door is opened, the type of food, and the length of time required to transport the product from the shop to your home. Always follow the instructions printed on the package and never exceed the maximum storage life indicated.
  • When freezing food, the maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated on the appliance label.
  • For optimum appliance performance to reach maximum freezing capacity, turn the thermostat knob to position max 24 hours before placing fresh food in the freezer. After placing fresh food in the freezer, 24 hours on max position is generally sufficient. After 24 hours, you do not need to set the thermostat knob to position max.
  • Attention: In order to save energy, when freezing small amounts of food, you do not need to set the thermostat knob to position max.
  • Use the fast freezing shelf to freeze home cooking (and the food you want to freeze) more quickly because of the freezing room's greater freezing power. Fast freezing shelves are the middle drawers of the freezer compartment.

PART 4. CLEANING AND MAINTENANCE

- Disconnect the unit from the power supply before cleaning.

- Do not clean the appliance by pouring water.

- Make sure that no water enters the lamp housing and other electrical components.

- The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water.

Cartoon illustration of a smiling refrigerator with sunglasses and a bowl of cleaning items (no text or symbols)

- Clean the accessories separately with soap and water. Do not clean them in the dishwasher.

- Do not use abrasive products, detergents, or soaps. After washing, rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug to the mains supply with dry hands.

- Clean the condenser with a broom at least twice a year. This will help you save on energy costs and increase productivity.

THE POWER SUPPLY MUST BE DISCONNECTED.

ning. solution

Line drawing of a multi-tiered refrigerator with red crosshair lines indicating storage zones (no text or symbols)

Cartoon illustration of a smiling book character and two puffer-like figures (no text or symbols)

Illustration of a hand cleaning a metal rack.

Defrosting refrigerator compartment

  • Defrosting occurs fully automatically in the refrigerator compartment during operation; the defrosted water is collected by the evaporating tray and evaporates automatically.
  • The evaporating tray and water drain hole (back of the refrigerator crisper shelf) should be cleaned periodically to prevent water from collecting on the bottom of the refrigerator instead of flowing out.

Simple line drawing of a mechanical component or bracket.

Diagram showing a hand pressing down on a mechanical component with an arrow indicating direction.

Defrosting the Freezer Compartment

- The frost that covers the shelves of the freezer compartment should be removed periodically.

- Do not use sharp metal objects for this operation. They could puncture the refrigerator circuit and cause irreparable damage to the unit. Use the plastic scraper provided.

- When there is more than 5 mm of frost on the shelves, defrosting must be carried out.

- Before defrosting, place the frozen food in a cool place after wrapping it in sheets of newspaper (this will help the food maintain its temperature for longer).

- To accelerate the defrosting process, place one or more bowls of warm water in the freezer compartment.

Line drawing of a kitchen appliance interior with a hand cleaning the tray.

- Dry the inside of the compartment with a sponge or a clean cloth.

- Once the unit has been defrosted, place the food into the freezer and remember to consume it in a short period of time.

Replacing the Refrigerator Light Bulb

  1. Unplug the unit from the power supply.
  2. Remove the refrigerator light cover (A) by pressing the hooks placed on both sides of the cover.
  3. Replace the current light bulb (B) with a new one (not exceeding 15 W).
  4. Place the light cover back in its position and plug the unit back in.

Technical diagram showing a door opening with labeled parts A and B, including a magnified view of the interior.

Replacing LED Lighting

If your refrigerator has LED lighting, contact the help desk, as this should only be changed by authorized personnel.

PART-5.

TRANSPORTATION AND CHANGING OF INSTALLATION POSITION

Transportation and Changing of Installation Position

  • The original packaging and foamed polystyrene (PS) can be retained if needed.
  • During transportation, the appliance should be secured with a wide strap or a strong rope. The instructions on the corrugated box must be followed while transporting.

- Before transporting or changing the installation position, all moving objects (e.g., shelves, crisper, etc.) should be taken out or fixed with bands to prevent damage.

Carry your refrigerator in an upright position.

Simple line drawing of two children playing with a large block together.

Repositioning the Door

  • It is not possible to change the opening direction of your refrigerator door if the door handle is installed on the front surface of the door.
  • It is possible to change the opening direction of the door on models without handles.
  • If the opening direction of your refrigerator door can be changed, you should contact the nearest Authorised Service Agent to have it changed.

PART 6. BEFORE CALLING YOUR AFTER-SALES SERVICE

If your refrigerator is not working properly, it may be a minor problem. Therefore, check the following before calling an electrician to save time and money.

What to do if your appliance does not operate:

Check that:

• There is no power (green lamp is off) - The general switch in your home is disconnected, - The thermostat setting is on the « • » position, - The socket is not sufficient. To check this, plug in another appliance that you know is working into the same socket.

What to do if your appliance performs poorly (red lamp is on):

Check that:

  • You have overloaded the appliance,
  • The thermostat setting is on "1" position (if so, set the thermostat dial to a suitable value) • The doors are closed perfectly,
  • There is no dust on the condenser,
  • There is enough space at the rear and side walls.

If there is noise:

The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling sound) even when the compressor is not running. Do not worry, this is quite normal. If these sounds are different, check that:

• The appliance is well leveled - Nothing is touching the rear. - The items on the appliance are vibrating.

If there is water in the lower part of the refrigerator,

Check that:

- The drain hole for defrost water is not clogged (Use defrost drain plug to clean the drain hole)

Important notes:

  • If the appliance is not used for a long time (for example during the summer holidays), unplug and clean the appliance and leave the door open to prevent the formation of mildew and smell.
  • To stop the appliance completely, unplug from the main socket (for cleaning and when the doors are left open)
  • If there is still a problem with your refrigerator although you have followed the instructions in this book, please consult your nearest authorized service center.
  • The life cycle of this product as determined and proclaimed by the Ministry of Industry (the period for making spare parts available for the product to be able to fulfill its functions) is 10 years.

Conformity

By placing the mark on this product, we are confirming compliance to all relevant

European safety, health and environmental requirements which are applicable in legislation for this product.

Tips For Saving Energy

  1. For better energy saving we suggest:
  2. Install the appliance away from heat sources, not exposed to direct sunlight, and in a well-ventilated room.
  3. Avoid putting hot food into the refrigerator to prevent increasing the internal temperature and causing continuous operation of the compressor.
  4. Do not overstuff foods to ensure proper air circulation.
  5. Defrost the appliance when there is ice to facilitate cold transfer. In case of a power outage, it is advisable to keep the refrigerator door closed. Open or keep the doors of the appliance open as little as possible.
  6. Avoid setting the temperature too cold.
  7. Remove dust from the rear of the appliance.

PART-7.

THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS

A) Fridge compartment B) Freezer compartment

1) Display panel 2) Freezer thermostat dial 3) Refrigerator thermostat dial 4) Refrigerator lamp & cover 5) Refrigerator shelves 6) Crisper shelf 7) Crispers 8) Bottle shelf 9) Bottle holder 10) Door shelves 11) Egg holder 12) Ice tray 13) Freezer room cover 14) Freezer compartment drawer 15) Freezer compartment bottom drawer 16) Levelling foot

This presentation is only for information about the parts of the appliance.

Parts may vary according to the appliance model.

Technical diagram of a refrigerator with numbered parts and labeled interior features.

This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model.

SCRAPPING OLD APPLIANCES

Warning symbol showing a waste bin with crossbones and a flame inside a triangle.

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

WEEE contains both polluting substances (which can cause negative consequences for the environment) and basic components (which can be re-used). It is important to have WEEE subjected to specific treatments, in order to remove and dispose properly all pollutants, and recover and recycle all materials.

Individuals can play an important role in ensuring that WEEE does not become an environmental issue; it is essential to follow some basic rules:

  • WEEE should not be treated as household waste;
  • WEEE should be handed over to the relevant collection points managed by the municipality or by registered companies. In many countries, for large WEEE, home collection could be present.

In many countries, when you buy a new appliance, the old one may be returned to the retailer who has to collect it free of charge on a one-to-one basis, as long as the equipment is of equivalent type and has the same functions as the supplied equipment.

Contents

SAFETY INFORMATION 19

Cartoon illustration of an electric plug with a sad face, showing electrical shock.

Safety warning illustration showing a smiling face, a crossed-out hand holding a prohibition symbol, and a hand waving.

PART 2. DIFFERENT FUNCTIONS AND POSSIBILITIES

Temperature adjustment

PART 3. PLACING FOOD IN THE APPLIANCE

Refrigerator compartment

Cartoon illustration of a smiling refrigerator with cleaning tools and a cup (no text or symbols)

Cartoon illustration of a smiling cube with eyes, hands pointing at it, and a bowl nearby (no text or symbols)

Cartoon illustration of a distressed refrigerator with two smaller bottles nearby (no text or symbols)

Diagram showing a hand holding a circular object with an arrow pointing to a textured surface (no text or symbols)

Defrosting the freezer compartment

LED LIGHTING

Technical diagram of a refrigerator with numbered components and airflow indicators

Thermostat setting 42

Display 43

Accessories 44

Ice cube tray 44

Bottle holder 44

ARRANGING FOOD IN THE APPLIANCE 44

Refrigerator compartment 44

Freezer compartment 45

CLEANING AND MAINTENANCE 46

Cartoon illustration of a character inside a refrigerator with arms and legs (no text or symbols).

Illustration of a hand holding a smiling face icon next to a prohibition symbol (no text or numbers present).

Simple line drawing of two bottles and a glass with bubbles, no text or symbols present.

Diagram illustrating heat transfer in a coiled tube with labeled components and directional arrows.

PART 2. THE DIFFERENT FUNCTIONS AND POSSIBILITIES

Thermostat setting

THERMOSTAT FOR FREEZER AND REFRIGERATORControl button for refrigerator, control button for freezer, LED indicator, FREEZER, POWER, COOLER.

PART 3. ARRANGING FOOD IN THE APPLIANCE

Refrigerator compartment

Cartoon illustration of a smiling refrigerator with arms and legs, accompanied by two smaller bottles (no text or symbols).

THE POWER SUPPLY MUST BE DISCONNECTED

Defrosting the refrigerator compartment

Diagram showing a hand holding a circular object over a textured surface, with an arrow indicating direction (no text or symbols present).

Defrosting the freezer compartment

If this product is equipped with LED lamps, contact technical support service if they need to be replaced.

This product is marked in accordance with the European Directive 2012/19/EC on waste electrical and electronic equipment (WEEE).

Table of contents Click a title to access it
Manual assistant
Powered by Anthropic
Waiting for your message
Product information

Brand : CANDY

Model : CFTE 3450 LE

Category : Refrigerator
