USER MANUAL DINOVO MINI LOGITECH

diNovo Mini at a glance (top)

Tips and troubleshooting

Compliance and FCC statement

Logitech hardware product limited warranty

Product package diNovo Mini Power supply USB mini-receiver Rechargeable lithium-ion battery diNovo CD-ROM with SetPoint™ software

Cleaning cloth English Your diNovo Mini The Logitech® diNovo Mini™ puts you in total control of your PC entertainment with a palmsized keyboard plus media remote and ClickPad™. Sit back and enjoy movies and music, share photos, and surf the Web—from anywhere in the room. Bluetooth® wireless technology delivers reliable operation from up to 30 feet (10 meters) under most conditions. The diNovo Mini gives you all the advantages of a full-size keyboard. Type search text, URLs, and IM messages. Automatic backlighting allows effortless text entry, even in low light. English Convenient media controls make the diNovo Mini the perfect remote control for PC entertainment. The dual-purpose ClickPad gives you more ways to enjoy your digital life. Use it as a touch pad to point, scroll, and click, or as a directional pad to navigate your favorite media (perfect for Windows Media® Center). Advanced lithium-ion batteries recharge faster and last longer—up to one month between charges. Compact and stylish, the diNovo Mini helps keep your home free of clutter.

diNovo Mini at a glance (top) Protective cover Close to place diNovo Mini in standby Bluetooth® light Battery indicator light Solid green when connected, red when not connected Blinking green while charging, solid green when fully charged, red when battery is low Mode slider Left-click ClickPad Convenient for left thumb Behaves as D-pad or touch pad Illuminated keypad Fully functional keyboard

English diNovo Mini at a glance (base) Power port (on side) Connect button Press to discover Bluetooth® devices Platform switch Preset for PC; move right to use diNovo Mini with PLAYSTATION®3 Battery compartment Mini-receiver compartment Back cover English

Installation Insert battery 1Open the back cover of the diNovo Mini by sliding the tab up. Insert the lithium-ion battery as shown in the illustration. Replace the back cover. Note: If you are going to use your diNovo Mini with a PLAYSTATION®3, move the platform switch to the right to enable the device for use with the console. (See page 7.)

English Installation Connect power 1Plug the AC cable into the power port on the side of the diNovo Mini. Plug the AC adapter into a wall socket to start charging the lithium-ion battery. A full charge is about four hours for up to one month of use. A ten-minute charge provides about one day of use. Connect mini-receiver

• Plug the mini-receiver into a USB port on your computer. Note: The mini-receiver is not required for a PLAYSTATION®3 or PC with built-in Bluetooth® wireless technology. Follow the host device instructions for discovering Bluetooth® devices. When prompted, press the red connect button on the base of the diNovo Mini to make it discoverable. However, for best results we recommend that you use the USB mini-receiver. English

Installation Install the SetPoint software Insert the provided CD-ROM and follow the instructions for installing the device drivers and setup software. Check for updates to SetPoint at www.logitech.com/downloads

English Configuration Depending on your monitor resolution and computing environment, you may want to adjust pointer speed and reassign hot keys. Follow these steps to configure your diNovo Mini (PC only):

Start SetPoint Double-click the SetPoint shortcut on your desktop. Adjust pointer speed 1Click the My Mouse tab, and then click the Mouse Movement subtab on the left of the SetPoint window. Change hot key settings Choose diNovo Mini from the Select Mouse pull-down menu. From the Select Task column select an option or choose an application for assignment. Drag the slider to adjust pointer speed. Click OK to apply the new settings. English 1Click the My Keyboard Tab. Select a key from the Hot Key column.

Using diNovo Mini Changing modes The diNovo Mini offers two operating modes, a media remote mode for navigating the Windows Media Center and a cursor mode for familiar keyboard and touch pad functions. diNovo Mini in media remote mode Controls lit in green. Best for Windows Media Center. Switch between modes by moving the mode slider at the top of the keypad. Move the slider to the left to place the diNovo Mini in media remote mode. Move the slider to the right for cursor mode. diNovo Mini in cursor mode Controls lit in orange. Best for browsing the Web and using PC applications.

English Using diNovo Mini Controls in media remote mode Volume and mute controls Media transport hot keys

Back Select an item. (Use your left thumb for faster selection.) Press while holding down FN key to get contextual menu. ClickPad Operates as a D-pad. Use four direction arrows for navigation. Press OK (center) to select an item in Media Center. Next/Previous

• Page Up and Page Down for navigating media.
• Channel Up and Channel Down while watching TV.
• Press while holding down FN key to zoom in or out. English Keypad FN key Press a letter key to select names that begin with that letter. Hold down to enable functions labeled in blue. Press to turn on backlighting. Launch Windows Media Center

Using diNovo Mini Controls in cursor mode Application and sleep hot keys Press while holding down FN key to launch Web browser/media player or put computer to sleep Delete Press while holding down FN key OK/Enter Backspace Left-click. Press while holding down FN key to get contextual menu (right-click). ClickPad Operates as a track pad. Press to perform left-click. Page Up/Page Down Scrolls through web pages. Press while holding down FN key to zoom in or out on documents and images.

Windows key FN key Hold down to enable functions labeled in blue. Press to turn on backlighting. CTRL key Enter key Press while holding down FN key to enter CTRL+ALT+DEL key combination. English Using diNovo Mini Illumination Backlighting makes your diNovo Mini easy to use—even in a darkened room. The keyboard and ClickPad illuminate when you use them, and dim to conserve power when they are not being used. Color-coding identifies the current mode and provides quick access to controls. The keyboard and ClickPad automatically illuminate when you: Backlighting fades out when you either close the cover of your diNovo Mini or stop using the keys and ClickPad for about five seconds. Note: The diNovo Mini uses an ambient light sensor to measure current light levels. If the available light is sufficient for viewing the keyboard and controls, the diNovo Mini suppresses backlighting to conserve power.

• Press any key English

Using diNovo Mini ClickPad backlighting In media remote mode, the ClickPad direction arrows and OK in the center of the pad are backlighted in green, indicating that the pad is functioning as a D-pad for navigating media. In cursor mode, the perimeter of the ClickPad is backlighted in orange to indicate that it is functioning as a touch pad for moving the cursor. ClickPad in media remote mode Keyboard backlighting Keyboard keys are always backlighted in orange. ClickPad in cursor mode

English Tips and troubleshooting If a problem should occur, you can usually solve it quickly in one of the following ways:

• Plug the USB mini-receiver into a different USB port (page 9).

• The battery LED should be lit when you lift the cover (page 6). Check whether the lithium-ion battery is correctly inserted (page 8).

• Restart the diNovo Mini by removing and reinserting the lithium-ion battery (page 8).

• Press the red connect button to the right of the mini-receiver compartment (page 7).

• Check the position of the platform switch and confirm that is properly set for a PC or PLAYSTATION®3 (page 7).

• Restart your computer or console.

Service and support General support For service and discussion forums, visit www.logitech.com/support Software downloads Visit www.logitech.com/downloads Using SetPoint™ Go to Start, Programs, Logitech, Mouse and Keyboard, Help Center. In Contents, expand the section “Using the SetPoint software.” Registering your diNovo Mini Visit www.logitech.com/register

Compliance and FCC statement Important ergonomic information. Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech® Software CD. Power supply warning. The power supply for this product is for indoor use only. Use the power supply that comes with your product; do not use any other power supply. Do not use a damaged power supply or attempt to repair one that is damaged. Do not immerse the power supply in water or subject it to physical abuse. Inspect the power supply regularly for damage to its cable, plug, and body.

Battery warning. Your product uses a rechargeable lithium-ion battery. Use this battery and no other. Exercise care when handling the battery. Do not open or mutilate it. When a battery is misused, it may leak or explode causing burns and personal injury. Conducting materials can also short out a battery causing it to overheat and leak. Do not put the battery in a fire, expose it to heat above 130 F (54 C), or immerse it in water. If the battery leaks or it will not recharge, use caution and discard the battery immediately according to your local laws. Battery charge may vary depending on usage. When not using your product for long periods of time, remove the battery and store it in a cool, dry place at normal room temperature. UL testing. Your product is UL tested (and CE certified) and should only be used with other UL listed devices. Compliance on the Web. For additional compliance information, go to http://www.logitech.com/compliance. English Compliance and FCC statement FCC statement. FCC Compliance and Advisory Statement: This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) this device may not cause harmful interference,

and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) reorient or relocate the receiving antenna; 2) increase

the separation between the equipment and the receiver;

3) connect the equipment to an outlet on a circuit

different from that to which the receiver is connected; English

4) consult the dealer or an experienced radio/TV

technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canadian Doc Statement: This digital device does not exceed the Class B limits for radio noise emissions from digital apparatus specified in the interferencecausing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications. This device complies with RSS-210 of Industry and Science Canada. Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device.

Logitech Hardware Product Limited Warranty Logitech warrants that your Logitech hardware product shall be free from defects in material and workmanship for three (3) years, beginning from the date of purchase. Except where prohibited by applicable law, this warranty is nontransferable and is limited to the original purchaser. This warranty gives you specific legal rights, and you may also have other rights that vary under local laws. Remedies Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, (1) to repair or replace the hardware, or (2) to refund the price paid, provided that the hardware is returned to the point of purchase or such other place as Logitech may direct with a copy of the sales receipt or dated itemized receipt. Shipping and handling charges may apply except where prohibited by applicable law. Logitech may, at its option, use new or refurbished or used parts in good working condition to repair or replace any hardware product. Any replacement hardware product will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer or for any additional period of time that may be applicable in your jurisdiction. This warranty does not cover problems or damage resulting from (1) accident, abuse, misapplication, or any unauthorized repair, modification or disassembly; (2) improper operation or maintenance, usage not in accordance with product instructions or connection to improper voltage supply; or (3) use of consumables, such as replacement batteries, not supplied by Logitech except where such restriction is prohibited by applicable law. How to Obtain Warranty Support Before submitting a warranty claim, we recommend you visit the support section at www.logitech.com for technical assistance. Valid warranty claims are generally processed through the point of purchase during the first thirty (30) days after purchase; however, this period of time may vary depending on where you purchased your product – please check with Logitech or the retailer where you purchased your product for details. Warranty claims that cannot be processed through the point of purchase and any other product related questions should be addressed directly to Logitech. The addresses and customer service contact information for Logitech can be found in the documentation accompanying your product and on the web at www.logitech.com/contactus.

Limitation of Liability LOGITECH SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS, REVENUE OR DATA (WHETHER DIRECT OR INDIRECT) OR COMMERCIAL LOSS FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON YOUR PRODUCT EVEN IF LOGITECH HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow the exclusion or limitation of special, indirect, incidental or consequential damages, so the above limitation or exclusion may not apply to you. Duration of Implied Warranties EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS HARDWARE PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THE APPLICABLE LIMITED WARRANTY PERIOD FOR YOUR PRODUCT. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. National Statutory Rights Consumers have legal rights under applicable national legislation governing the sale of consumer goods. Such rights are not affected by the warranties in this Limited Warranty. No Other Warranties No Logitech dealer, agent, or employee is authorized to make any modification, extension, or addition to this warranty. Logitech Address Logitech, Inc., 6505 Kaiser Drive, Fremont, California 94555, U.S.A. Logitech Europe S.A., Z.I. Moulin du Choc D, 1122 Romanel/Morges, Switzerland © 2007 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in any manual or on this website. Information contained herein is subject to change without notice. English Bienvenue Vous venez d’acheter la clavier Logitech® diNovo Mini™ et nous vous en félicitons. Ce document fournit des explications détaillées sur l’utilisation du nouveau clavier diNovo Mini. Pour plus d’informations sur ce produit, rendez-vous sur www.logitech.com. Français
