Product Type	Built-in Microwave Oven with Grill and Convection
Brand	Teka
Model	MCL 32 BIS
Capacity	32 Litres
Microwave Power	900 W
Grill Power	1100 W
Convection Power	1800 W
Dimensions (H x W x D)	455 x 595 x 520 mm
Cut-out Dimensions (H x W x D)	450 x 560 x 500 mm
Weight	25 kg
Electrical Supply	230 V, 50 Hz, 16 A
Display	Digital LED with Clock and Timer
Controls	Touch Control Panel
Functions	Microwave, Grill, Convection, Combi Cooking, Auto Menus, Defrost, Keep Warm
Cleaning & Maintenance	Easy-clean enamel interior, removable glass turntable, stainless steel cavity
Safety Features	Child Lock, Door Interlock, Overheat Protection
Spare Parts & Repairability	Spare parts available through Teka service network. Repairability score: 7.0/10
General Information	Black stainless steel finish, integrated cooling system, energy class E

Frequently Asked Questions - MCL 32 BIS TEKA

How do I set the clock on my Teka MCL 32 BIS microwave?

Press the Clock button, then use the + and - buttons to set the hours and minutes. Confirm with Clock again.

What is the maximum cooking time for microwave mode?

The maximum cooking time is 95 minutes. If longer is needed, use the Defrost or Auto Menu functions.

Can I use metal containers in the microwave?

No, metal containers can cause sparks and damage the appliance. Only use microwave-safe glass, ceramic, or plastic containers.

How do I activate the child lock?

Press and hold the Stop/Clear button for 3 seconds until you hear a beep. The lock icon will appear on the display.

Why is my microwave making a loud noise?

Check that the turntable is correctly seated and the support is clean. If noise persists, the cooling fan or magnetron may require service.

How do I clean the interior?

Use a damp cloth with mild detergent. Avoid abrasive cleaners. Place a bowl of water with lemon juice and heat for 5 minutes to loosen stains.

What does the 'Combi' function do?

The Combi function combines microwave, grill, and convection for faster, crispier results. Select the desired program from the menu.

My microwave display shows 'E' error code, what does it mean?

Error codes indicate a malfunction. E typically means a sensor or connection issue. Contact Teka support for diagnosis.

Can I install the microwave above a gas hob?

Yes, if the minimum clearance requirements are met (at least 650mm between hob and microwave). Check installation manual for details.

Where can I download the user manual?

The manual is available for free on notice-facile.com in PDF format. Visit the product page to download.

USER MANUAL MCL 32 BIS TEKA

Dear Customer,

Before going any further, we want to thank you for choosing our product. We are confident that this modern, functional, and practical microwave oven, manufactured with high-quality materials, will fully meet your expectations.

Please read the instructions in this booklet very carefully, as this will allow you to get the best results from using your microwave oven.

KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.

Always keep the instruction manual handy. If you lend the microwave oven to someone else, give them the manual as well!

Environmental protection

Disposal of the packaging

The packaging bears the Green Point mark.

Dispose of all packaging materials such as cardboard, expanded polystyrene, and plastic wrapping in the appropriate bins. In this way, you can be sure that the packaging materials will be re-used.

Disposal of equipment no longer used

According to European Directive 2002/96/EC on the management of waste electrical and electronic equipment (WEEE), home electrical appliances should not be put into the normal systems for disposal of solid urban waste.

Outdated appliances should be collected separately to optimise component material recovery and recycling rates and to prevent potential harm to human health and the environment. The symbol of a rubbish container superimposed by a diagonal cross should be put on all such products to remind people of their obligation to have such items collected separately.

Consumers should contact their local authorities or point of sale and request information on the appropriate places to leave their old home electrical appliances.

Before disposing of your appliance, render it non-usable by pulling out the power cable, cutting this, and disposing of it.

EN

Contents

Installation instructions ....3

Before installation....3 After installation....3

Microwave safety 4

The advantages of microwaves....6

Description of your oven....7

Function Description....8

Basic settings 9

Setting the clock 9 Hiding/Displaying the Clock....9 Safety blocking 9

Basic Functions....10

Microwaves....10 Grill 11 Microwave + Grill....11 Microwave + Hot-Air 12 Defrosting by time (manual)....13 Grill + Fan....13 Defrosting by weight (automatic) 14 Memory function....15

Using the Browning Plate 16

When the oven is working....17

Interrupting a cooking cycle....17 Altering parameters 17 End of a cooking cycle....17

Defrosting....18

General instructions for defrosting....19

Cooking with a microwave oven 20

Cooking with the grill 22

Roasting 25

What kind of ovenware can be used? 27

Microwave function....27 Grill and Hot-Air functions....27 Combined functions....27 Aluminium containers and foil 27 Lids....27

Oven Cleaning and Maintenance....29

Front surface 29 Oven interior 29 Oven ceiling....30 Accessories 30

What should I do if the oven doesn't work? 31

Substitution of light bulb 31

Technical characteristics....32

Specifications 32

Installation....65

Before installation

Check that the input voltage indicated on the characteristics plate is the same as the voltage of the power outlet you are going to use.

Open the oven door and take out all the accessories and remove the packing material.

Do not remove the mica cover on the ceiling of the interior! This cover stops fat and pieces of food damaging the microwave generator.

Warning! The front surface of the oven may be wrapped with a protective film. Before using the oven for the first time, carefully remove this film, starting on the inside.

Make sure that the oven is not damaged in any way. Check that the oven door closes correctly and that the interior of the door and the front of the oven opening are not damaged. If you find any damage contact the Technical Assistance Service.

DO NOT USE THE OVEN if the power cable or the plug are damaged, if the oven does not function correctly or if it has been damaged or dropped. Contact the Technical Assistance Service.

Put the oven on a flat and stable surface. The oven must not be put close to any sources of heat, radios or televisions.

During installation, make sure that the power cable does not come into contact with any moisture or objects with sharp edges behind the oven. High temperatures can damage the cable.

Warning: after the oven is installed you must make sure you can access the plug.

After installation

The oven is equipped with a power cable and a plug for single phase current.

If the oven is to be installed on a permanent basis it should be installed by a qualified technician. In such a case, the oven should be connected to a circuit with an all-pole circuit breaker with a minimum separation of 3 mm between contacts.

WARNING: THE OVEN MUST BE EARTHED.

The manufacturer and retailers do not accept responsibility for any damage that may be caused to people, animals or property if these installation instructions are not observed.

The oven only functions when the door is closed correctly.

After the first use, clean the inside of the oven and the accessories, following the cleaning instructions given in the section “Oven cleaning and maintenance”.

Fit the Turntable support (1) in the centre of the oven cavity and put the Turntable ring (2) and the Turntable plate (3) on top, making sure they slot in. Whenever you use the microwave, the turntable plate and the respective accessories must be inside and correctly fitted. The turntable plate can rotate in both directions.

During installation, follow the instructions supplied separately.

• Warning! Never leave the oven unwatched, especially when using paper, plastic or other combustible materials. These materials can char and may fire. FIRE RISK!
• Warning! If you see smoke or fire, keep the door closed in order to smother the flames. Switch off the oven and take the plug out of the socket or cut off the oven power supply.
• Warning! Do not heat pure alcohol or alcoholic drinks in the microwave. FIRE RISK!
• Warning! Do not heat liquids or other foods in closed containers since these may explode readily.
• Warning! This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Warning! Children should be supervised to ensure that they do not play with the appliance.
• Warning! If the oven has a combined function mode (microwave with other means of heating), children should not be allowed to use the oven without adult supervision on account of the high temperatures generated.
• Warning! The oven cannot be used if:
• The door is not closed correctly;
• The door hinges are damaged;
• The surfaces of the contact between the door and the oven front are damaged;
• The door window glass is damaged;
• There is frequent electrical arcing inside the oven even though there is no metal object inside.
• The oven can only be used again after it has been repaired by a Technical Assistance Service technician.
• During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
• Warning: Accessible parts may become hot during use. Young children should be kept away.

Beware!

• Never heat baby foods or drinks in bottles or jars with the teats or lids on them. After heating the food mix or shake well so that the heat is spread evenly. Check the food temperature before feeding this to the child. DANGER OF BURNING!
• To avoid food overheating or burning it is very important not to select long time periods or power levels that are too high when heating small quantities of food. For example, a bread roll can burn after 3 minutes if the power selected is too high.
• For toasting, use just the grilling function and watch the oven all the time. If you use a combined function to toast bread it will catch fire in a very short time.
• Make sure you never catch the power cables of other electrical appliances in the hot door or the oven. The cable insulation may melt. Danger of short-circuiting!

Take care when heating liquids!

When liquids (water, coffee, tea, milk, etc.) are nearly at boiling point inside the oven and are taken out suddenly, they may spurt out of their containers. DANGER OF INJURIES AND BURNS!

To avoid that type of situation when heating liquids, put a teaspoon or glass rod inside the container.

Microwave safety

This oven is exclusively for domestic use!

Use the oven only for preparing meals.

Avoid damaging the oven or other dangerous situations by following these instructions:

• Do not switch on the oven without the turntable support, the turntable ring and the respective plate being in place.
• Never switch on the microwave when it is empty. If there is no food inside there may be an electrical overcharge and the oven could be damaged. RISK OF DAMAGE!
• For carrying out oven programming tests put a glass of water inside the oven. The water will absorb the microwaves and the oven will not be damaged.
• Do not cover or obstruct the ventilation openings.
• Use only dishes suitable for microwaves. Before using dishes and containers in the microwave, check that these are suitable (see the section on types of dishes).
• Never remove the mica cover on the ceiling of the oven interior! This cover stops fat and pieces of food damaging the microwave generator.
• Do not keep any inflammable object inside the oven as it may burn if the oven is switched on.
• Do not use the oven as a pantry.
• Eggs with their shells and whole boiled eggs must not be heated in microwave ovens because they may explode.
• Do not use the oven for frying as it is impossible to control the temperature of oil heated by microwaves.
• To avoid being burnt, always use oven gloves for handling dishes and containers and touching the oven.
• Do not lean or sit on the open oven door. This may damage the oven, especially in the hinge zone. The door can bear a maximum weight of 8 kg.

- The turntable and the grills can bear a maximum load of 8 kg. To avoid damaging the oven, do not exceed this load.

Cleaning:

• Warning! Your microwave oven must be cleaned regularly. All food remains must be removed (see section on Oven Cleaning). If the microwave oven is not kept clean its surface may deteriorate and this may shorten the oven's working life and could even result in a dangerous situation.
• Warning! Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
• The door contact surfaces (the front of the cavity and the inside part of the doors) must be kept very clean in order to ensure the oven functions correctly.
• Please follow the instructions regarding cleaning in the section "Oven Cleaning and Maintenance".

Repairs:

• Warning – Microwaves! The outer protection of the oven must not be removed. It is dangerous for anyone not authorised by the manufacturer to carry out any kind of repair or maintenance work.
• If the power cable is damaged it should be substituted by the manufacturer, authorised agents or technicians qualified for this task in order to avoid dangerous situations. Furthermore, special tools are required for this task.
• Repair and maintenance work, especially of current carrying parts, can only be carried out by technicians authorised by the manufacturer.

In conventional ovens, heat radiated by electrical elements or gas burners slowly penetrates the food from outside to inside. On account of this there is a major amount of energy is wasted heating the air, the oven components and the food containers.

In a microwave oven, heat is generated by the food itself and the heat travels from inside to outside. No heat is lost to the air, the walls of the oven cavity or the dishes and containers (if these are suitable for use in microwave oven), in other words, only the food is heated.

Microwave ovens have the following advantages:

1. Shorter cooking times; in general these are up to 3/4 less than the time required for conventional cooking.
2. Ultra-fast food defrosting, thus reducing the danger of bacterial development.
3. Energy savings.
4. Conservation of the nutritional value of foods due to the shorter cooking times.
5. Easy to clean.

How a microwave oven works

In a microwave oven there is a high tension valve called a magnetron which converts electrical energy into microwave energy. These electromagnetic waves are channelled to the interior of the oven through a wave guide and distributed by a metallic spreader or through a turntable.

Inside the oven the microwaves propagate in all directions and are reflected by the metal walls, uniformly penetrating the food.

Why food heats up

Most foods contain water and water molecules vibrate when subjected to microwaves.

The friction between molecules produces heat which raises the temperature of the food, defreezing it, cooking it or keeping it hot.

Since the heat arises inside the food:

• This can be cooked with little or no liquid or fats/oils;
• De-freezing, heating or cooking in a microwave oven is quicker than in a conventional oven;
• The vitamins, minerals and nutritional substances in the food are conserved;
• The natural colour and aroma of the food are unchanged.

Microwaves pass through china, glass, cardboard or plastic but do not go through metal. For this reason, metal containers or ones with metal parts must not be used in a microwave oven.

Microwaves are reflected by metal...

... but go through glass and china...

... and are absorbed by foods.

Description of your oven

1. – Control Panel 7. – Turntable ring
2. Door window glass 8. - Turntable plate
3. – Lateral supports 9. – Rectangular Glass Tray
4. – Catches 10. – Rectangular Rack
5. – Hot Air output 11. – Browning Plate
6. – Turntable Support

1. Function selection knob
2. Safety Block key
3. Start key
4. OK key

A. Clock indicator B. Function indicator C. Cooking Memories indicators D. Minus key E. Duration indicator F. Plus key G. Special Function indicator H. Defrost by time indicator

I. Defrost by weight indicator J. Weight indicator K. Power indicator L. Temperature indicator M. Power/Weight display N. Safety Block indicator - Clock/Duration display

Function Description

Symbol	Function	Microwave Power Output	Foods
	Microwave	200 W	Slow defrosting for delicate foods; keeping food hot
		400 W	Cooking with little heat; boiling riceRapid defrosting
		600 W	Melting butterHeating baby food
		800 W	Cooking vegetables and foodCooking and heating carefully,Heating and cooking small portions of foodHeating delicate food
		1000 W	Cooking and rapidly heating liquids and pre-cooked foods
	Microwave + Grill	200 W	Toasting food
		400 W	Grilling poultry and meat
		600 W	Cooking pies and cheese-topped dishes
	Grill		Grilling food
	Microwaves + Hot-Air	200	Meat roast and simmer
		400	Poultry roast
		600	Other fast roasts
	Hot-Air	---	Roast and bake
	Grill + Fan	---	Food even browning

Basic settings

Setting the clock

After your microwave oven is first plugged in or after a power failure, the clock display will flash to indicate that the time shown is not correct. To set the clock, proceed as follows:

1. Press the Clock key (5) when the Clock/Duration display is showing the clock. The hour numbers will start to flash.
2. Press the "+" and "-" keys to set the correct hour value.
3. Press again the Clock key (5) to set the minutes. The minute numbers will start to flash.
4. Press the "+" and "-" keys to set the correct minute value.
5. To finish, press the Clock key (5) again.

Hiding/Displaying the Clock

If the clock display disturbs you, you can hide it by pressing the Clock key for 3 seconds. The dots that separate the hours and minutes will flash but the rest of the clock display will be hidden.

If you want to see the clock display again, press the Clock key again for 3 seconds.

Safety blocking

The oven operation can be blocked (for example, to stop it from being used by children).

1. To block the oven, press the Safety Block key (2) for 3 seconds. You will hear a sound signal and Safety Block indicator will illuminate. The oven is blocked in this state and cannot be used.
2. To unblock the oven, press the Safety Block key (2) again for 3 seconds. You will hear a sound signal and the Safety Block indicator will turn off.

EN Basic Functions

Microwaves

Use this function to cook and heat vegetables, potatoes, rice, fish and meat.

1. Turn the Function Selector knob (1) until the Microwave function indicator flashes. The Duration display shows 1:00 flashing.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate. The microwaves power value flashes on the Power display. The microwaves power indicator starts to flash.
4. Turn the Rotating knob (7) in either direction to set the microwaves power level. If you do

Do not turn this knob, the oven operates at 850 W power.

1. Press the OK key (4) to validate.
2. Press the Start key (3). The oven will start to operate.

NOTE:

The start button may be pressed at any time in the above sequence and the oven will start the cooking process with the displayed parameters.

Basic Functions

Grill

Use this function to brown the top of food quickly.

1. Turn the Function Selector knob (1) until the Grill function indicator flashes. The Duration display shows 15:00 flashing.
2. Turn the Rotating knob (7) in either direction to set the duration.

Microwave + Grill

Use this function to cook lasagne, poultry, roast potatoes and toasted foods.

1. Turn the Function Selector knob (1) until the Microwave + Grill function indicator flashes. The Duration display shows 10:00 flashing.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate. The microwaves power value flashes on the Power display. The microwaves power indicator starts to flash.
4. Turn the Rotating knob (7) in either direction to set the microwaves power level. If you do not turn this knob, the oven operates at

360W power. The maximum power that can be selected is 600 W.

1. Press the OK key (4) to validate.
2. Press the Start key (3). The oven will start to operate.

NOTE:

The start button may be pressed at anytime in the above sequence and the oven will start the cooking process with the displayed parameters.

EN Basic Functions

Hot-Air

Use this function to bake food.

1. Turn the Function Selector knob (1) until the Hot-Air function indicator flashes.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate. The temperature value flashes. Turn the Rotating knob (7) in either direction to set the temperature.
4. The temperature value flashes. Turn the Rotating knob (7) in either direction to set the temperature.
5. Press the OK key (4) to validate.
6. Press the Start key (3). The oven will start to operate.

Microwave + Hot-Air

Use this function to rapidly bake the foods.

1. Turn the Function Selector knob (1) until the Microwave + Grill function indicator flashes. The Duration display shows 10:00 flashing.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate. The microwaves power value flashes on the Power display. The microwaves power indicator starts to flash.
4. Turn the Rotating knob (7) in either direction to set the microwave's power level. If you do not turn this knob, the oven operates at

360W power. The maximum power that can be selected is 600 W.

1. Press the OK key (4) to validate.
2. The temperature value flashes. Turn the Rotating knob (7) in either direction to set the temperature.
3. Press the OK key (4) to validate.
4. Press the Start key (3). The oven will start to operate.

Basic Functions

Defrosting by time (manual)

Use this function to defrost any type of food quickly.

1. Turn the Function Selector knob (1) until the Defrost by Time function indicator flashes. The Duration display shows 10:00 flashing.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate.
4. Press the Start key (3). The oven will start to operate.
5. Turn the food whenever the oven lets out a beep and the display flashes the word "turn".

Grill + Fan

Use this function to bake evenly the food and at the same time brown their surface.

1. Turn the Function Selector knob (1) until the Grill + Fan function indicator flashes.
2. Turn the Rotating knob (7) in either direction to set the duration.
3. Press the OK key (4) to validate. The temperature value flashes. Turn the Rotating

knob (7) in either direction to set the temperature.

1. The temperature value flashes. Turn the Rotating knob (7) in either direction to set the temperature.
2. Press the OK key (4) to validate.
3. Press the Start key (3). The oven will start to operate.

EN Basic Functions

Defrosting by weight (automatic)

Use this function to defrost meat, poultry, fish, fruit and bread quickly.

1. Turn the Function Selector knob (1) until the Defrost by Weight function indicator flashes. The Duration display shows the food type "Pr 1" flashing.
2. Turn the Rotating knob (7) in either direction to set the food type. If you do not turn this knob, the oven operates with food type "Pr 1".
3. Press the OK key (4) to validate. The food weight value flashes on the Weight display. The weight indicator starts to flash.
4. Turn the Rotating knob (7) in either direction to set the food weight. If you do not turn this knob, the oven operates with 200 g.
5. Press the OK key (4) to validate.
6. Press the Start key (3). The oven will start to operate.
7. Turn the food whenever the oven lets out a beep and the Weight display flashes the word: turn

The following table shows the defrosting by weight function programmes, indicating weight intervals, and defrosting and standing times (in order to ensure the food is of a uniform temperature).

Programme	Food	Weight (g)	Time (min)	Standing time (min)
Pr 01 Meat	100 – 2000	2 – 43		20 – 30
Pr 02 Poultry	100 – 2500	2 – 58	20 – 30
Pr 03	Fish	100 – 2000	2 – 40	20 – 30
Pr 04	Fruit	100 – 500	2 – 13	10 – 20
Pr 05	Bread	100 – 800	2 – 19	10 – 20

Important Note: see "General instructions for defrosting".

Basic Functions

Memory function

Define and store a memory

1. With the Function Selector (1), select one of the Basic functions.
2. Set the desired parameters with the Rotating Knob (7)
3. Press the Clock key (5) for 5 seconds. The memory symbol "M1" starts blinking.
4. With the Rotating Knob (8) select in which memory you want to store the defined parameters (M1, M2 or M3)
5. Press the Ok Key (4) to confirm and store the memory.

Recalling a memorized function

1. Rotate the function Selector (1) to select the stored memory.
2. Press the start Key (3). The oven will start to operate.

Delete a memory:

1. With the oven in stand-by, select the desired memory by turning the Function Selector (1).
2. Press the Clock key (5) for 3 seconds. The power/weight display shows the message "DEL" for 3 seconds.

Using the Browning Plate

Normally when cooking food, such as pizzas or pies, on a grill or in a microwave oven, the dough or pastry becomes soggy. This can be avoided by using a browning plate. As a high temperature is reached quickly on the bottom of the browning plate, the crust turns crisp and brown.

The browning plate can also be used for bacon, eggs, sausages, etc.

VERY IMPORTANT NOTES:

• Use oven gloves at all times as the browning plate will become very hot.
• Never place the browning plate in the oven without the glass plate.
• Do not place any recipients on the browning plate that are not heat-resistant (plastic bowls for example).

How to cook with the browning plate:

1. Preheat the browning plate by selecting the Microwave and Grill function for 3 to 5 minutes with a 600 W microwaves power level.
2. Brush the browning plate with oil in order to brown the food nicely.
3. Place the fresh or frozen food directly on the browning plate.
4. Place the browning plate on the glass turntable in the microwave oven.
5. Select the Microwaves and Grill function and the cooking time as described below.

Food Weight		Cooking Time	Standing Time	Recommendation
Pizza	200 g 4 - 5 min ---			If the pizza is thin.
	300 g 5 - 6 min ---			If the pizza is high increase the time by 1 – 2 minutes
	400 g 7 – 8 min ---
Quiches and Pies	200 g 3 – 4 min 2 – 3 min
	300 g 5 - 6 min 2 – 3 min
Hamburgers	150 - 200 8 - 10 min	5 – 8 min	Turn 2 x
Oven chips	400 g 6 -8 min	---	Turn 1 x

VERY IMPORTANT NOTES:

As the browning plate has a Teflon layer, if you use it incorrectly, it can be damaged.

Never cut the food on the plate. Remove the food from the plate prior to cutting.

Cleaning:

The best way to clean the browning plate is to wash it with hot water and detergent and rinse off with clean water. Do not use a scrubbing brush or a hard sponge otherwise the top layer will be damaged.

When the oven is working...

Interrupting a cooking cycle

You can stop the cooking process at any time by pressing the Start/Stop key once or by opening the oven door.

In both cases:

• Microwave emission is stopped immediately.
• The grill is de-activated but is still very hot. Danger of burning!
• The timer stops and the display shows the remaining amount of operating time.

If you wish, at this time you can:

1. Turn or stir the food to ensure it will be evenly cooked.
2. Change the process parameters.
3. Cancel the process by pressing the Start/Stop key.

To restart the process, close the door and press the Start/Stop key.

Altering parameters

The operating parameters (time, weight, power, etc.) can be altered when the oven is operating or when the cooking process has been interrupted by proceeding as follows:

1. To alter the time, turn the rotating knob. The new time defined is immediately valid.
2. To alter the power, press the Weight/Power Selection key. The respective light starts to flash. Alter the parameter by pressing the “-” and “+” keys and confirm by pressing the Power Selection key again.

Cancelling a cooking cycle

If you wish to cancel the cooking process, press the Start/Stop key for 3 seconds.

You will then hear a beep and the time will appear on the display.

End of a cooking cycle

At the end of the process you will hear three beeps and the display will show the word "End".

The beeps are repeated every 30 seconds until the door is opened or the Start/Stop key is pressed.

EN Defrosting

The table below shows different defrosting and standing times (in order to ensure the food

temperature is evenly distributed) for different types and weights of food, plus recommendations.

Food	Weight (g)	Defrosting time (min)	Standing time (min)	Recommendation
Portions of meat, veal, beef, pork	100	2-3	5-10	Tu
	200	4-5	5-10	Tu
	500	10-12	10-15	Turn
	1000	21-23	20-30	Turn
	1500	32-34	20-30	Turn
	2000	43-45	25-35	Turn three times
Goulash	500	8-10	10-15	Turn twice
	1000	17-19	20-30	Turn three times
Minced meat	100	2-4	10-15	Turn twice
	500	10-14	20-30	Turn three times
Sausages	200	4-6	10-15	Turn once
	500	9-12	15-20	Turn twice
Poultry (portions)	250	5-6	5-10	Turn once
Chicken	1000	20-24	20-30	Turn twice
Poularde	2500	38-42	25-35	Turn three times
Fish fillet	200	4-5	5-10	Turn once
Trout	250	5-6	5-10	Turn once
Prawns	100	2-3	5-10	Turn once
	500	8-11	15-20	Turn twice
Fruit	200	4-5	5-10	Turn once
	300	8-9	5-10	Tu
	500	11-14	10-20	Turn
Bread	200	4-5	5-10	Tu
	500	10-12	10-15	Turn
	800	15-17	10-20	Turn
Butter	250	8-10	10-15
Cream cheese	250	6-8	10-15
Creams	250	7-8	10-15

Defrosting

General instructions for defrosting

1. When defrosting, use only dishes that are appropriate for microwaves (china, glass, suitable plastic).
2. The defrost function by weight and the tables refer to the defrosting of raw food.
3. The defrosting time depends on the quantity and thickness of the food. When freezing food keep the defrosting process in mind. Distribute the food evenly in the container.
4. Distribute the food as best as possible inside the oven. The thickest parts of fish or chicken drumsticks should be turned towards the outside. You can protect the most delicate parts of food with pieces of aluminium foil. Important: The aluminium foil must not come into contact with the oven cavity interior as this can cause electrical arcing.
5. Thick portions of food should be turned several times.
6. Distribute the frozen food as evenly as possible since narrow and thin portions defrost more quickly than the thicker and broader parts.
7. Fat-rich foods such as butter, cream cheese and cream should not be completely defrosted. If they are kept at room temperature they will be ready to be served in a few minutes. With ultra-frozen cream, if you find small pieces of ice in it, you should mix these in before serving.
8. Place poultry on an upturned plate so that the meat juices can run off more easily.
9. Bread should be wrapped in a napkin so that it does not become too dry.
10. Turn the food whenever the oven lets out a beep and the display flashes the word: turn.
11. Remove frozen food from its wrapping and do not forget to take off any metal twist-tags. For containers that are used to keep frozen food in the freezer and which can also be used for heating and cooking, all you need to do is take off the lid. For all other cases you should put the food into containers that are suitable for microwave use.
12. The liquid resulting from defrosting, principally that from poultry, should be discarded. In no event should such liquids be allowed to come into contact with other foods.
13. Do not forget that by using the defrosting function you need to allow for standing time until the food is completely defrosted.

Warning! Read the section "Microwave Safety" before cooking with your microwave.

Follow these recommendations when cooking with your microwave:

• Before heating or cooking foods with peel or skin (e.g. apples, tomatoes, potatoes, sausages) prick them so that they do not burst. Cut the food up before starting to prepare it.
• Before using a container or dish make sure that it is suitable for microwave use (see the section on types of ovenware).
• When cooking food with very little moisture (e.g. defrosting bread, making popcorn, etc.) evaporation is very quick. The oven then works as if it was empty and the food may burn. The oven and the container may be damaged in such a situation. You should therefore set just the cooking time necessary and you must keep a close eye on the cooking process.
• It is not possible to heat large quantities of oil (frying) in the microwave.
• Remove pre-cooked food from the containers they come in since these are not always heat resistant. Follow the food manufacturer's instructions.
• If you have several containers, such as cups, for example, set them out uniformly on the turntable plate.
• Do not close plastic bags with metal clips. Use plastic clips instead. Prick the bags several times so that the steam can escape easily.
• When heating or cooking foods, check that they reach at least a temperature of 70° C.
• During cooking, steam may form on the oven door window and may start to drip. This situation is normal and may be more noticeable if the room temperature is low. The oven's safe working is not affected by this. After you have finished cooking, clean up the water coming from the condensation

- When heating liquids, use containers with a wide opening, so that the steam can evaporate easily.

Prepare the foods as per the instructions and keep in mind the cooking times and power levels indicated in the tables.

Keep in mind that the figures given are only indicative and can vary depending on the initial state, temperature, moisture and type of food. It is advisable to adjust the times and power levels to each situation. Depending on the exact characteristics of the food you may need to increase or shorten the cooking times or increase or decrease the power levels.

Cooling with microwaves...

1. The greater the amount of food, the longer the cooking time. Keep in mind that:
2. Double the quantity » double the time
3. Half the quantity » half the time
4. The lower the temperature, the longer the cooking time.
5. Foods containing a lot of liquid heat up more quickly.
6. Cooking will be more uniform if the food is evenly distributed on the turntable. If you put dense foods on the outside part of the plate and less dense ones on the centre of the plate, you can heat up different types of food simultaneously.
7. You can open the oven door at any time. When you do this the oven switches off automatically. The microwave will only start working again when you close the door and press the start key.
8. Foods that are covered require less cooking time and retain their characteristics better. The lids used must let microwaves pass through and have small holes that allow steam to escape.

Cooking with a microwave oven

Tables and suggestions – Cooking vegetables

Food	Quantity (g)	Addition of liquids	Power (Watt)	Time (min.)	Standing Time (min.)	Instructions
Cauliflower	500	100 ml	800	9-11	2-3	Cut into slices.
Broccoli	300	50 ml	800	6-8	2-3
Mushrooms	250	25 ml	800	6-8	2-3	Keep covered.
Peas & carrots	300	100 ml	800	7-9	2-3	Cut into chunks or slices.Keep covered.
Frozen carrots	250	25 ml	800	8-10	2-3
Potatoes	250	25 ml	800	5-7	2-3	Peel and cut into equal sized pieces. Keep covered.
Paprika	250	25 ml	800	5-7	2-3	Cut into chunks or slices
Leek	250	50 ml	800	5-7	2-3	Keep covered.
Frozen Brussels sprouts	300	50 ml	800	6-8	2-3	Keep covered.
Sauerkraut	250	25		ml	800	Keep covered. 2-3

Tables and suggestions – Cooking fish

Food	Quantity (g)	Power (Watt)	Time (min.)	Standing Time (min.)	Instructions
Fish fillets	500	600	10-12	3	Cook covered over. Turn after half of cooking time.
Whole fish	800	800	2-3	2-3	Cook covered over. Turn after half of cooking time. You may wish to cover up the small edges of the fish.
		400	7-9

Cooking with the grill

For good results with the grill, use the grid iron supplied with the oven.

Fit the grid iron in such a way that it doesn't come into contact with the metal surfaces of the oven cavity since if it does there is a danger of electric arcing which may damage the oven.

IMPORTANT POINTS:

1. When the microwave grill is used for the first time there will be some smoke and a smell coming from the oils used during oven manufacture.
2. The oven door window becomes very hot when the grill is working. Keep children away.
3. When the grill is operating, the cavity walls and the grid iron become very hot. You should use oven gloves.
4. If the grill is used for extended period of time it is normal to find that the elements will switch themselves off temporarily due to the safety thermostat.
5. Important! When food is to be grilled or cooked in containers you must check that the container in question is suitable for microwave use. See the section on types of ovenware!
6. When the grill is used, some splashes of fat may go onto the elements and be burnt. This is normal and does not indicate any operating fault.
7. After cooking, clean the interior and accessories to prevent cooking residues from becoming encrusted.

Cooking with the Grill

Tables and suggestions – Grill without microwave

Fish	Quantity (g)	Time (min.)	Instructions
Fish
Bass	800	18-24	Spread lightly with butter. After half of cooking time turn and spread with seasoning.
Sardines/gurnard	6-8 fish.	15-20
Meat
Sausages	6-8 units	22-26	Prick after half cooking time and turn.
Frozen hamburgers	3 units	18-20
Spare rib (approx. 3 cm thick)	400	25-30	After half of cooking time, baste and turn.
Others
Toast Watch toasting. 4 units		11/2 -3
Toasted sandwiches 2 units 5-10 Watch toasting.

Preheat the grill for 2 minutes. Unless otherwise indicated, use the grid iron. Place the grid on a bowl to collect water and fat. The times given are indicative and may vary depending on the composition and quantity of food, as well as the desired final condition. Fish and meat taste better if brushed with vegetable oil, spices, and herbs, and left to marinate for a few hours before grilling. Add salt only after grilling.

Sausages will not burst if pricked with a fork before grilling.

After half the grilling time, check the cooking progress and turn the food if necessary.

The grill is especially suitable for cooking thin portions of meat and fish. Thin portions only need to be turned once, but thicker portions should be turned several times.

Tables and suggestions – Microwave + Grill

The microwave + grill function is ideal for quick cooking and browning foods. It also allows grilling and cooking cheese-covered dishes.

The microwave and grill work simultaneously: the microwave cooks while the grill toasts.

Food	Quantity (g)	Dish	Power (Watt)	Time (min.)	Standing time (min.)
Cheese topped pasta	500	Low dish	400	12-17	3-5
Cheese topped potatoes	800	Low dish	600	20-22	3-5
Lasagne	approx. 800	Low dish	600	15-20	3-5
Grilled cream cheese	approx. 500	Low dish	400	18-20	3-5
2 fresh chicken legs (grilled)	200 each	Low dish	400	10-15	3-5
Chicken	approx. 1000	Low and wide dish	400	35-40	3-5
Cheese topped onion soup	2 x 200 g cups	Soup bowls	400	2-4	3-5

Before using a dish in the microwave oven, ensure it is suitable for microwave use. Only use dishes or containers that are microwave-safe.

The dish used in the combined function must be suitable for both microwave and grill use. See the section on types of ovenware.

Keep in mind that the figures given are indicative and may vary depending on the initial state, temperature, moisture, and type of food.

If the time is not enough to brown the food well, place it under the grill for another 5 to 10 minutes.

Please follow the standing times and don't forget to turn the meat pieces.

Unless indicated to the contrary, use the turntable plate for cooking.

The values given in the tables are valid when the oven cavity is cold (it is not necessary to pre-heat the oven).

Tables and suggestions – Roasting

Tables and suggestions – Roasting

Type	Quantity (g)	Power (Watt)	Temperature °C	Time (min)	Standing Time (min)	Comments
Beef stew	1000	200	160/170	80/90	10	Do not put lid on container
Pork loin	500/600	200	180/190	35/40	10	Do not put lid on container
Whole chicken	100/1200	400	200	30/40	10	Put lid on container. Breast facing upwards. Do not turn.
Chicken portions	800	400	200	25/35	10	Do not put lid on container. Arrange portions with skin facing upwards. Do not turn.
Duck	1500/1700	200	200	70/80	10	Put lid on container. Do not turn.

Advice for roasting meat

Turn the pieces of meat halfway through the cooking time. When the roasted meat is ready you should let it stand for 10 minutes in the oven with this switched off and closed. This will ensure the juices in the meat are well distributed.

Add 2 to 3 soup spoons of gravy or similar liquid to lean meat and 8 to 10 soup spoons to stews, depending on the amount of meat in question.

The roasting temperature and time required depends on the type and amount of meat being cooked.

If the weight of the meat to be roasted does not appear on the table choose the settings for the weight immediately below and extend the cooking times.

Advice on ovenware

Check that the ovenware fits inside the oven.

Hot glass containers should be put on a dry kitchen cloth. If such containers are put on a cold or wet surface the glass may crack and break. Use oven gloves to take the ovenware out of the oven.

Tables and suggestions – Baking

Tables and suggestions – Cakes

Type	Container	Level	Temperature	Time (min)
Walnut cake	Spring-form type tin	1	170/180	30/35
Fruit tart	Spring-form type tin	2	150/160	35/45
Fruit cakes	Cake tin with central hole	1	170/190	30/45
Savoury tarts	Spring-form type tin	2	160/180	50/70
Simple cake (sponge cake)	Spring-form type tin	1	160/170	40/45
Almond cakes	Cake tray	2	110	35/45
Puff pastry	Cake tray 2 170/180 35/45

Advice on cake baking ware

The most commonly used type of baking ware is black metal tins. If you are also going to use the microwave, use glass, ceramic or plastic baking ware. These must be able to withstand temperatures up to 250° C. If you use these types of baking ware the cakes are not browned as much.

Advice on how to bake cakes

Different amounts and types of pastry require different temperatures and baking times. Try low settings first of all and then, if necessary, use higher temperatures next time. A lower temperature will result in more uniform baking. Always put the cake tray in the centre of the turntable.

Baking suggestions

How to check if the cake is properly cooked

Start sticking a tooth pick in the highest part of the cake 10 minutes before the end of the baking time. When no dough sticks to the tooth pick the cake is ready.

If the cake is very dark on the outside

Next time choose a lower temperature and let the cake bake for a longer time.

If the cake is very dry

Make small holes in the cake with a tooth pick after baking has finished. Then sprinkle the cake with some fruit juice or alcoholic drink. Next time increase the temperature by about 10^o and reduce the baking time.

If the cake does not come free when turned

Let the cake cool down for 5 to 10 minutes after baking and it will come out of the tin more easily. If the cake still does not come free run a knife carefully around the edges. Next time grease the cake tin well.

What kind of ovenware can be used?

Microwave function

For the microwave function, keep in mind that microwaves are reflected by metal surfaces. Glass, china, clay, plastic, and paper let microwaves pass.

For this reason, metal pans and dishes or containers with metal parts or decorations cannot be used in the microwave. Glassware and clay with metallic decoration or content (e.g., lead crystal) cannot be used in microwave ovens.

The ideal materials for use in microwave ovens are glass, refractory china or clay, or heat-resistant plastic. Very thin, fragile glass or china should only be used for short periods of time (e.g., heating).

Hot food transmits heat to the dishes, which can become very hot. You should, therefore, always use an oven glove!

How to test ovenware you want to use

Put the item you want to use in the oven for 20 seconds at maximum microwave power. After that time, if it is cold or just slightly warm, it is suitable to use. However, if it heats up a lot or causes electric arcing, it is not suitable for microwave use.

Grill and Hot-Air functions

In the case of the grill function, the ovenware must be resistant to temperatures of at least 300°C.

Plastic dishes are not suitable for use in the grill.

Combined functions

In the microwave + grill function, the ovenware used must be suitable for use in both the microwave and the grill.

Aluminium containers and foil

Pre-cooked food in aluminium containers or in aluminium foil can be put in the microwave if the following aspects are respected:

- Keep in mind the manufacturer's recommendations written on the packaging.

- The aluminium containers cannot be more than 3 cm high or come in contact with the cavity walls (minimum distance 3 cm). Any aluminium lid or top must be removed.

- Put the aluminium container directly on top of the turntable plate. If you use the grid iron, put the container on a china plate. Never put the container directly on the grid iron!

- The cooking time is longer because the microwaves only enter the food from the top. If you have any doubts, it is best to use only dishes suitable for microwave use.

- Aluminium foil can be used to reflect microwaves during the defrosting process. Delicate food, such as poultry or minced meat, can be protected from excessive heat by covering the respective extremities/edges.

- Important: aluminium foil cannot come into contact with the cavity walls since this may cause electrical arcing.

Lids

We recommend you use glass or plastic lids or cling film since:

1. This will stop excessive evaporation (mainly during very long cooking times);
2. The cooking times are shorter;
3. The food does not become dry;
4. The aroma is preserved.

The lid should have holes or openings so that no pressure develops. Plastic bags must also be opened. Baby feeding bottles or jars with baby food and similar containers can only be heated without their tops / lids otherwise they can burst.

What kind of ovenware can be used?

Table of Ovenware

The table below gives you a general idea of what type of ovenware is suitable for each situation.

Operating modeType of ovenware	Microwave		Grill	Microwave + Grill
	Defrosting / heating	Cooking
Glass and china 1)Home use, not flame resistant, can be used in dish washer	yes	Yes	no
Glazed chinaFlame resistant glass and china	yes	Yes	yes	yes
China, stone ware 2)Unglazed or glazed without metallic decorations	yes	Yes	no
Clay dishes 2)GlazedUnglazed	yesno	yesno	nono	nono
Plastic dishes 2)Heat resistant to 100°CHeat resistant to 250°C	yesyes	noyes	nono	nono
Plastic films 3)Plastic film for foodCellophane	noyes	noyes	nono	nono
Paper, cardboard, parchment 4)	yes	No	no
MetalAluminium foilAluminium wrappings 5)Accessories	yesnoyes	noyesyes	yesyesyes	noyesyes

1. Without any gold or silver leaf edging; no lead crystal.
2. Keep the manufacturer's instructions in mind!
3. Do not use metal clips for closing bags. Make holes in the bags. Use the films only to cover the food.
4. Do not use paper plates.
5. Only shallow aluminium containers without lids/tops. The aluminium cannot come into contact with the cavity walls.

Oven Cleaning and Maintenance

Cleaning is the only maintenance normally required.

Warning! Your microwave oven should be cleaned regularly, with all food remains being removed. If the microwave is not kept clean its surfaces may deteriorate, reducing the oven's working life and possibly resulting in a dangerous situation.

Warning! Cleaning should be done with the oven power switched off. Take the plug out of the socket or switch off the oven's power circuit.

Do not use aggressive or abrasive cleaning products, scourers that scratch surfaces or sharp objects, since stains may appear.

Do not use high pressure or steam jet cleaning appliances.

Front surface

Normally you just need to clean the oven with a damp cloth. If it is very dirty, add a few drops of dishwashing liquid to the cleaning water. Afterwards, wipe the oven with a dry cloth.

In an oven with an aluminium front, use a glass cleaning product and a soft cloth that does not release any fibres or threads. Wipe from side to side without exerting any pressure on the surface.

Immediately remove lime, fat, starch or egg white stains. Corrosion can occur under these stains.

Do not let any water get inside the oven.

Oven interior

After each time the oven is used, clean the inside walls with a damp cloth since this is the easiest way to remove splashes or spots of food that may have stuck to the inside.

To remove dirt that is harder to shift, use a non-aggressive cleaning product. Do not use oven sprays or other aggressive or abrasive cleaning products.

Always keep the door and the oven front very clean to ensure that the door opens and closes properly.

Make sure water does not enter the microwave ventilation holes.

Regularly take out the turntable plate and the respective support and clean the cavity base, especially after any liquid spillage.

Do not switch on the oven without the turntable and the respective support being in place.

If the oven cavity is very dirty, put a glass of water on the turntable and switch on the microwave oven for 2 or 3 minutes at maximum power. The steam released will soften the dirt which can then be cleaned easily using a soft cloth.

Unpleasant odours (e.g. after cooking fish) can be eliminated easily. Put a few drops of lemon juice in a cup with water. Put a spoonful of coffee in the cup to avoid the water boiling over. Heat the water for 2 to 3 minutes at maximum microwave power.

EN Oven Cleaning and Maintenance

Oven ceiling

To avoid the danger of burning, wait until the grill is cold before starting to clean.

The mica cover (3) located in the ceiling must always be kept clean. Any food remains that collect on the mica cover can cause damage or provoke sparks.

Do not use abrasive cleaning products or sharp objects.

To avoid any risk, do not remove the mica cover.

The glass lamp cover (4) is located on the oven ceiling and can be removed easily for cleaning. For this you just need to unscrew it and clean it with water and dishwashing liquid.

Accessories

Clean the accessories after each use. If they are very dirty, soak them first of all and then use a brush and sponge. The accessories can be washed in a dish washing machine.

Make sure that the turntable plate and the respective support are always clean. Do not switch on the oven unless the turntable and the respective support are in place.

What should I do if the oven doesn't work?

WARNING! Any type of repair must only be done by a specialised technician. Any repair done by a person not authorised by the manufacturer is dangerous.

You do not need to contact Technical Assistance to resolve the following questions:

• The display is not showing! Check if:

- The time indication has been switched off (see section on Basic Settings).

- Nothing happens when I press the keys! Check if:

- The Safety Block is active (see section on Basic Settings).

• The oven does not work! Check if:

- The plug is correctly fitted in the socket.

- The oven's power is switched on.

- The door is completely closed. The door should close with an audible click.

- There are any foreign bodies between the door and the cavity front.

- When the oven is operating I can hear some strange noises! Check if:

- There is any electrical arcing inside the oven caused by foreign metallic objects (see section on type of ovenware).

- The ovenware is touching the oven walls.

- There are any loose items of cutlery or cooking tools inside the oven.

- The food doesn't heat up or heats very slowly! Check if:

- You have inadvertently used metal ovenware.

- You have selected the correct operating times and power level.

- The food you have put inside the oven is a larger amount or colder than you usually put in.

- The food is too hot, dried out or burnt! Check if you selected the correct operating time and power level.

- I hear some noises after the cooking process is finished! This is not a problem. The cooling fan keeps on working for some time. When the temperature has dropped sufficiently, the fan will switch itself off.

- The oven switches on but the interior light does not go on! If all the functions work properly it is probable that the lamp has blown. You can keep on using the oven.

Substitution of light bulb

To substitute the light bulb, proceed as follows:

• Disconnect the oven from the power supply. Take the plug out of the socket or switch off the oven's power circuit.
• Unscrew and remove the glass light cover (1).
• Remove the halogen light bulb (2). Warning! The bulb may be very hot.
• Fit a new 12V / 10W halogen bulb. Warning! Do not touch the light bulb surface directly with your fingers because you may damage the bulb. Follow the lamp manufacturer's instructions.
• Screw the glass light cover into place (1).
• Connect the oven again to the power supply.

EN

Technical characteristics

Specifications

• AC Voltage...... (see characteristics plate) • Power required.... 3400 W
• Grill power.... 1500 W
• Hot-Air power.... 1600 W
• Microwave output power. 1000 W
• Microwave frequency.... 2450 MHz
• Exterior dimensions (W×H×D).... 595 × 455 × 520 mm
• Interior dimensions (W×H×D).... 420 × 210 × 390 mm
• Oven capacity. 38 ltr • Weight...... 35 kg

Dear customer,

1. Stop taste

DE

• Push oven completely into the cabinet and centre it.
• Open microwave door and fasten the appliance to the cabinet using the four screws provided. Insert the screws through the front holes.

Teka Subsidiaries

Country Subsidiary Address City Phone

AustriaKüppersbusch Austria	Eitnergasse, 13	1231 Wien	[phone]
BelgiumKüppersbusch Belgium S.P.R.L.	Doomveld Industrie, Asse 3, No. 11 - Boite 7	1731 Zellik	[phone]
BulgariaTeka Bulgaria EOOD	Blvd. "Tsarigradsko Shosse" 135	1784 Sofia	[phone]
ChileTeka Chile S.A.	Avd El Retiro Parque los Maitenes, 1237. Parque Enea	Pudahuel, Santiago de Chile	+ 56 24 386 000
ChinaTeka International Trading (Shanghai) Co. Ltd.	6/F. Datong Business Center, No. 369 Fuxing Middle Rd.	200025 Shanghai	[phone]
Czech RepublicTeka CZ S.R.O.	V Holesovickách, 593	182 00 Praha 8 - Liben	[phone]
DenmarkJuvél A/S	Københavnsvej 222	DK-4600 Køge	[phone]
EcuadorTeka Ecuador S.A.	Parque Ind. California 2, Via a Daule Km 12	Guayaquil	[phone]
GermanyTeka Küchentechnik GmbH	Sechsheldener Str. 122	35708 Haiger	[phone]
Great BritainTeka Products Ltd.	177 Milton Park	0X14 4SE Milton, Abingdon	[phone]
GreeceTeka Hellas A.E.	Thesi Roupaki - Aspropyrgos	193 00 Athens	[phone]
HungaryTeka Hungary Kft.	Bajcsy Zsilinszky u. 53	1065 Budapest	[phone]
IndonesiaPT Teka Buana	Jalan Menteng Raya, Kantor Taman A9 Unit A3	12950 Jakarta	[phone]
MalaysiaTeka Küchentechnik (Malaysia) Sdn Bhd	10 Jalan Kartunis U1/47, Temasya Park, Off Glenmarie	40150 Shah Alam, Selangor Darul Ehsan	[phone]
MexicoTeka Mexicana S.A. de C.V.	Ferrocarril 200, Esquina Norte 29, Col. Moctezuma	15500 Mexico D.F.	[phone]
MoroccoTeka Maroc S.A.	73, Bd. Slimane, Depôt 33, Route de Ain Sebaa	Casablanca	[phone]
NetherlandsTeka B.V.	Wijkermeerstraat, 34	2131 HA Hoofddorp	+ 31 235 656 480
NorwayIntra, A.S	Storsand	7563 Malvik	[phone]
PolandTeka Polska Sp. ZO.O.	ul. 3-go Maja 8 / A2	05-800 Pruszków	[phone]
PortugalTeka Portugal S.A.	Estrada da Mota - Apdo 533	3834-909 Ilhavo, Aveiro	[phone]
RomaniaS.C. Teka Küchentechnik Romania S.R.L.	Sevastopol str., no 24, 5th floor, of. 15	010992 Bucharest Sector 1	[phone]
RussiaTeka Rus LLC	Barklaya str. 6, bld. 3, Barklay plaza center, office 402	121087 Moscow âTM Russia	[phone]
SingaporeTeka Singapore PTE Ltd	Clemenceau Avenue, 83, 01-33/34 UE Square	239920 Singapore	[phone]
SpainTeka Industrial, S.A.	C/ Cajo,17	39011 Santander	[phone]
SwedenIntra Mölntorp AB	Säbyvägen, 8	734 93 Kolbäck	[phone]
ThailandTeka (Thailand) Co. Ltd.	364/8 Sri-Ayuttaya Road, Phayathai, Ratchatavee	10400 Bangkok	[phone]
TurkeyTeka Teknik Mutfak Aletleri Sanayi Ve	Büyükdere Cad. 24/13	80290 Mecidiyeköy, Istanbul	[phone]
UkraineTeka Ukranie LLC	86-e, Bozhenko Str .2nd floor,4th entrance	03150 Kyiv	[phone]
United Arab EmiratesTeka Middle East Fze	Building LOB 16, Office 417	P.O. Box 18251 Dubai	[phone]
United Arab EmiratesTeka Küchentechnik U.A.E LLC	Bin Khedia Centre	P.O. Box 35142 Dubai	[phone]
VenezuelaTeka Andina S.A.	Ctra. Petare-Santa Lucia, km 3 (El Limoncito)	1070 Caracas	[phone]
VietnamTEKA Vietnam Co., Ltd.	803 Dai Minh Convention Tower, 8th Floor	77 Hoang Van Thai, District 7, Ho Chi Minh	[phone]
