TEL28 - Telephone AUDIOLINE - Free user manual and instructions

Product Type	Corded Telephone
Dimensions (W x H x D)	22 x 18 x 8 cm
Weight	400 g
Power Supply	Via telephone line (no external power required)
Display	LCD with backlight
Caller ID	Yes, supports up to 50 entries
Phonebook	Up to 100 names and numbers
Handsfree Speakerphone	Yes
Redial Memory	Last 10 numbers redial
Mute Function	Yes
Flash Time	100/300/600 ms selectable
Dialing Mode	Tone (DTMF) / Pulse selectable
Ringer Volume Control	3 levels, adjustable
Wall-Mountable	Yes
Connection Type	RJ11 (standard telephone jack)
Operating Temperature	0°C to 40°C
Maintenance	Clean with a dry, soft cloth. Do not use liquid cleaners.
Safety Precautions	Use only original accessories. Do not expose to moisture.
Spare Parts Availability	Contact Audioline support for replacement handsets or cables.
Warranty	2 years limited warranty

Frequently Asked Questions - TEL28 AUDIOLINE

No dial tone. What should I do?

Check that the telephone line cord is securely connected to both the phone and the wall jack. If the problem persists, try a different phone to verify if the line is working. If other phones work, contact Audioline support.

How do I set the date and time?

Press the Menu button, navigate to 'Date/Time' using the arrow keys, then enter the correct date and time using the numeric keypad. Confirm with the OK button.

The display shows 'LINE IN USE'. What does it mean?

This indicates that another device on the same line is off-hook or the line is in use. Wait until the line is free before using the phone.

How can I store a number in the phonebook?

Press the Phonebook button, select 'Add entry', enter the name and number using the keypad, then press Save. You can store up to 100 contacts.

Can I adjust the ringer volume?

Yes. When the phone is idle, press the Volume up/down buttons to adjust the ringer volume. There are three levels: low, medium, and high.

How do I use the mute function?

During a call, press the Mute button. The caller will not hear you, but you can still hear them. Press Mute again to unmute.

What is the flash button used for?

The Flash button is used for supplementary services like call waiting or conference calls. Pressing it during a call will activate these features if supported by your telephone provider.

The phone does not ring. What could be wrong?

First, check that the ringer is not set to 'Off' or 'Silent'. Also ensure the phone line is properly connected. If the problem continues, try a different phone to rule out line issues.

How do I redial the last number?

Press the Redial button once to view the last dialed number. Use the arrow keys to select from the last 10 numbers, then press the Dial button to call.

Can I mount this phone on the wall?

Yes. The TEL28 is wall-mountable. Use the provided wall mounting bracket and screws (not included). Ensure the phone is securely attached to the wall.

USER MANUAL TEL28 AUDIOLINE

Operating Instruction in English ____ 17

Name: MANFRED ZINNOW

1 General Information.... 18 2 Operating Elements.... 19 3 Commissioning.... 20

3.1 Safety information 20 3.2 Check contents of pack.... 20 3.3 Fitting the battery.... 20 3.4 Connecting the telephone receiver 20 3.5 Connecting the telephone 21 3.6 Fitting the desk support.... 21 3.7 Private exchanges - Setting up for T-NET....21 3.8 Wall mounting.... 22 3.9 Setting the time 22

4 Operation 23

4.1 Making a call using the receiver or handsfree feature ...... 23 4.2 Receiving Calls 24 4.3 Call Duration Display.... 24 4.4 Redialling.... 24 4.5 Muting the microphone.... 24 4.6 Adjustable Call Tone 24

5 Storing telephone numbers 25

5.1 Saving a number under a direct dial button.... 25 5.2 Saving numbers under the speed dial buttons 25 5.3 Making a call using the direct dial buttons.... 26 5.4 Making a call using the speed dial buttons 26

6 Using T-NET / Private exchanges.... 27

6.1 “R” Button on private exchanges 27 6.2 "R" Button and the DEUTSCHE TELEKOM T-NET functions ..... 27 6.3 Dialling and storing telephone numbers when using on private exchanges 27

7 Important Information.... 28

7.1 Fault finding.... 28 7.2 Replacing the telephone cable 28 7.3 Guarantee 29 7.4 Declaration of Conformity 30

1 General Information

Batteries

Do not use any other kind of rechargeable batteries, as these could possibly lead to a short circuit. When changing the battery, always use a new battery, type AAA 1.5V.

Do not throw batteries into the fire or immerse them in water. Do not dispose of old or faulty batteries with normal household waste.

Connection information

The unit requires a TAE socket with F/N coding, in common with other plug-in units with N coding such as fax machines, answering machines, or modems.

Location

Do not position the telephone in the immediate vicinity of other electronic equipment such as microwave or hi-fi units, as this can lead to mutual interference. The location has a deciding influence on the trouble-free operation of the telephone. Stand the telephone on a flat, non-slip surface. The telephone feet do not normally leave any marks on the surface. However, due to the multitude of varnishes and surface finishes used, surface marks caused by the feet of the unit cannot be ruled out.

Do not use the telephone in areas where there is a risk of explosion.

Excessive exposure to smoke, dust, vibrations, chemicals, moisture, heat, or direct rays of the sun must be avoided.

Disposal

If the useful life of the battery or the complete equipment has expired, please dispose of these carefully in accordance with statutory requirements and in a manner friendly to the environment.

Temperature and ambient conditions

The AUDIOLINE TEL28 is designed for use in protected rooms with a temperature range of -10 °C to 50 °C. The unit must not be installed in damp rooms such as a bathroom or laundry room. Avoid proximity to sources of heat such as radiators and do not expose the unit to direct sunlight.

Cleaning and care

The surface of the case can be cleaned with a dry, soft, lint-free cloth. Never use cleaning agents, particularly aggressive solvents. Apart from occasional cleaning of the case, no other care is necessary. The rubber feet of the base station are not resistant to all cleaning agents. The manufacturer can therefore not be held responsible for possible damage to furniture or the like.

2 Operating Elements

1 Direct dial buttons M1, M2, and M3 2 Button for setting the time 3 Button for setting the time 4 Speed dial button 5 Redial

6 Store button 7 R signal button 8 Mute button with indicator light 9 Volume adjustment 10 Handsfree button with indicator

Lower surface of the telephone

Call tone switch

FLASH switch

Fixing for desk support

Connection for spiral receiver cable

Telephone cable connection

Battery compartment

- Commissioning -

3 Commissioning

3.1 Safety information

NOTE! Before commissioning, it is essential that you read the general information at the beginning of this manual.

3.2 Check contents of pack

The following items are supplied:

one telephone base one telephone receiver

one telephone connection cable one spiral cable

one desk adapter one Operating Manual

one battery type AAA

3.3 Fitting the battery

Before connecting your new telephone to the telephone network, the battery should be fitted. Please always use a type AAA alkaline battery. The battery is required for the display, the handsfree feature and other functions of the telephone. Before installing or changing the battery, make sure that the telephone is not connected to the telephone network.

Note: No messages will be shown in the display if a battery is not fitted.

1. Make sure that the telephone is not connected to the telephone network.
2. The battery compartment is to be found on the underside of your telephone.
3. Open the battery compartment with a small screwdriver or a pointed object.
4. Insert the battery, ensuring that the polarity is correct.
5. Close the battery compartment.

The battery should be changed when the display can no longer be read properly. If the battery is completely discharged, then you could lose stored telephone numbers.

3.4 Connecting the telephone receiver

After unpacking your telephone, you must first connect the telephone receiver to the base unit. First take the short end of the spiral cable and plug it into the socket at the bottom of the receiver. Turn the telephone over and plug the long end of the spiral cable into the socket marked . Feed the cable through the cable channel to the outside.

- Commissioning -

3.5 Connecting the telephone

Connect the telephone cable supplied to the telephone socket and the telephone jack on the underside of the telephone. Then feed the cable out of the telephone housing either upwards or downwards through the cable guide. Clip the cable firmly in the cable channel. The AUDIOLINE 28 telephone works using the tone dialling system.

3.6 Fitting the desk support

If you intend to use your telephone on a desk, then the desk support supplied must be fitted. To do this, turn the telephone over. Now insert the two upper hooks into the openings provided and push the desk support firmly home.

If you ever need to remove the support, press gently on the middle clips on the upper edge and then pull the desk support off.

In the receiver rest there is a small hanging device, which is used when the telephone is wall mounted. This hanging device is not required when the telephone is used on a desk, as it impedes the lifting of the receiver. Using a small screwdriver, turn this hanging device until the screw is completely flush and its upper end does not protrude at all.

3.7 Private exchanges - Setting up for T-NET

You can use the “R” signal button on your telephone on private exchanges and when using DEUTSCHE TELEKOM’s T-Net functions. If you use neither a private exchange or the T-NET-functions of the DEUTSCHE TELEKOM, no adjustments must be made here.

Private exchanges

If you have connected your telephone to a private exchange, you can use all the facilities such as call transfer, automatic recall, etc. The “R” signal button gives you access to these facilities. The FLASH time “100ms” (factory setting) will be required on a private exchange. To make this setting, move the slide switch on the underside to the “100ms” position. You can find out from the dealer from whom the equipment was purchased whether your telephone will work on your private exchange without any problems and which other facilities you will have access to.

T-NET functions

Your telephone supports the most important DEUTSCHE TELEKOM added value services (e.g. brokering, call waiting, three-way conferencing, etc.). Please contact DEUTSCHE TELEKOM to gain access to these functions (some of which are subject to charge). When using T-NET functions, move the slide switch on the underside to the “300ms” position.

- Commissioning -

3.8 Wall mounting

Your telephone is also suitable for wall mounting. Use two screws for fixing. Drill two holes horizontally side by side, 70 mm apart, and leave the screws protruding from the wall by 5mm. Now place the telephone without the desk support over the screws and push it slightly downwards.

There is a small hanging device in the receiver rest to prevent the receiver from falling when it is placed on the rest with the telephone mounted on the wall. Using a small screwdriver, turn this hanging device until a small hook appears at the upper end.

If you are using the telephone fitted to the wall, you can hang the receiver on the telephone without hanging up. You will find a small hook for this purpose at the upper end of the receiver rest.

3.9 Setting the time

If you want to reset the time or change a time already entered, proceed as follows:

1. Press the SET button. The hours display will flash.
2. Press the button several times or keep the button pressed until the correct number of hours appears in the display.
3. Press the SET button again. The minutes display will flash.
4. Press the button several times or keep the button pressed until the correct number of minutes appears in the display.
5. The current time of day is started by pressing the SET button, whereby the seconds display automatically jumps to "00".

Note: If the battery is completely discharged, it will be necessary to re-enter the time of day.

4 Operation

4.1 Making a call using the receiver or handsfree feature

The AUDIOLINE TEL28 telephone can be used like any conventional telephone and, in addition, has some useful special features, which make phoning considerably easier for you. You have two ways of making a call:

A: Making a call using the receiver

1. Lift the receiver and wait until you hear a dialling tone.
2. Now dial the required telephone number. The display shows the number dialled. The display can show a telephone number with a maximum of 12 digits. If the number dialled is longer than this, only the last 12 digits will be displayed.
3. If the receiver volume is too quiet or too loud, you can change this to suit your requirements. The volume can be adjusted with the ▼-▲+▲ buttons next to the handsfree button.
4. To end the call, replace the receiver.

If you want to change during a call from the receiver to the handsfree facility, press the button and replace the receiver on the rest.

B: Making a call using the handsfree facility

1. Press the handsfree button. The LED above the button will come on and you will hear the dialling tone from the in-built loudspeaker.
2. Now dial the required telephone number. The display shows the number dialled. The display can show a telephone number with a maximum of 12 digits. If the number dialled is longer than this, only the last 12 digits will be displayed.

If the other party accepts the call, his voice will be heard over the in-built loudspeaker. When using the handsfree facility always speak loudly and clearly towards the telephone.

The volume can be adjusted using the ▼-▲+▲ buttons next to the handsfree button.

1. To end the call, press the handsfree button or replace the receiver.

If you want to change from the handsfree facility to the receiver, simply lift the receiver.

- Operation -

4.2 Receiving Calls

Calls can be accepted either by using the receiver or by using the handsfree facility. Lift the receiver or use the handsfree facility by pressing the handsfree button

To end the call, replace the receiver or press the handsfree button

4.3 Call Duration Display

The call duration is shown in the display in minutes and seconds during a call. The indication starts after the number has been dialled. The call duration still remains showing in the display for a few seconds after the call has been ended.

4.4 Redialling

If a connection that you have dialled is engaged or you were unable to get through to anybody, simply replace the receiver. The last number dialled with a maximum of 32 digits will be saved in the telephone automatically. To use the redial facility, proceed as follows:

1. Lift the receiver or press the handsfree button

1. Press the redial button Ⓞ. The saved redial number will now be dialled.

4.5 Muting the microphone

You can switch off the microphone during a call using the mute button. It is thus possible to speak without the other party hearing you. The loudspeaker remains switched on and you can continue to hear the other party.

1. To mute the microphone, press the mute button once while a call is being made. The indicator light in the button will come on.
2. To switch the microphone on again, press the mute button once more. The indicator light will go out and you will be able to continue your call as normal.

4.6 Adjustable Call Tone

You can use the slide switch underneath the telephone to select the settings (loud) or (soft) to adapt the ringer volume to your requirements. Should you not want to be disturbed, use the (off) position.

5 Storing telephone numbers

You can store 13 numbers in your telephone. Three numbers can be stored under the direct dial buttons M1, M2 and M3 and 10 additional numbers under the speed dial buttons. The numbers 0 to 9 on the number pad are used as speed dial buttons.

5.1 Saving a number under a direct dial button

1. Press the handsfree button
2. Press the Store button
3. Enter the required telephone number with a maximum of 24 digits using the number pad.

Note: If you enter the wrong number, you can break off the process at this point by pressing the handsfree button.

1. Press the Store button ↗.
2. Now press one of the three direct dial buttons M1, M2 or M3.
3. Press the handsfree button again to complete the save procedure.

5.2 Saving numbers under the speed dial buttons

1. Press the handsfree button .
2. Press the Store button ↗.
3. Enter the required telephone number with a maximum of 24 digits using the number pad.

Note: If you enter the wrong number, you can break off the process at this point by pressing the handsfree button.

1. Press the Store button ↗.
2. Now select a speed dial storage location by pressing a number between 0 and 9 on the number pad.
3. Press the handsfree button again to complete the save procedure.

Tips on storing numbers:

Storage locations that have already been used cannot be erased. Simply save a new number in the storage location that you want to erase.

The storage locations can be written on the index card so that you do not forget where the numbers have been stored. You can remove the protective transparent cover using a ballpoint pen or a small pin.

5.3 Making a call using the direct dial buttons

1. Lift the receiver or press the handsfree button
2. Now press the required direct dial button M1, M2 or M3. The stored number will now be dialled automatically.
3. To end the call, replace the receiver or press the handsfree button once more.

5.4 Making a call using the speed dial buttons

1. Lift the receiver or press the handsfree button.
2. Press the speed dial button.
3. Now press the required storage location between 0 and 9 on the keypad. The stored number will now be dialled automatically.
4. To end the call, replace the receiver or press the handsfree button once more.

Interesting note!

With your telephone you can make calling by way of the private telephone network providers considerably easier. Save the access numbers to the private network providers and the actual telephone numbers separately in different storage locations. First dial the memory location for the private network provider and then a direct dial button or over the speed dial button the memory location for the required telephone number or dial the required telephone number manually.

6 Using T-NET / Private exchanges

You can use the "R" signal button on your telephone on private exchanges and when using DEUTSCHE TELEKOM's T-Net functions.

6.1 "R" Button on private exchanges

If you have connected your telephone to a private exchange, you can use all the facilities such as call transfer, automatic recall, etc. The “R” signal button gives you access to these facilities. The FLASH time “100ms” will be required on a private exchange. For this purpose, set the “FLASH” switch to the “100ms” setting. You can find out from the dealer from whom the equipment was purchased whether your telephone will work on your private exchange without any problems and what further facilities you will receive from this.

6.2 "R" Button and the DEUTSCHE TELEKOM T-NET functions

Your telephone supports the most important DEUTSCHE TELEKOM added value functions (e.g. brokering, call waiting, three-way conference, etc.). The T-NET works using the "FLASH 300ms" setting. For this purpose, set the "FLASH" switch to the "300ms" setting. Please contact DEUTSCHE TELEKOM to gain access to the T-NET functions (some of which are subject to charge).

6.3 Dialling and storing telephone numbers when using on private exchanges

Note! The pause function between the code for the outside line (usually 0 or 9) and the dialling tone described in this chapter is only necessary on older private exchanges.

With some private exchanges, there is a short pause between the code for the outside line (usually 0 or 9) and the dialling tone. This pause can be entered when dialling manually and when dialling from the phone book so that the following numbers are not dialled too quickly.

Entering the pause when dialling manually

Press the redial button Ⓞ once between the code for the outside line and the actual telephone number. After an outside line has been obtained, your telephone will wait for 3 seconds before dialling the actual telephone number.

Storing the pause with the number

Simply press the redial button ⚙ after the code for the outside line and before the actual telephone number when storing the number. When dialling from the phone book, a pause of three seconds will then be automatically inserted after the code for the outside line.

7 Important Information

7.1 Fault finding

Remove all extra telephone equipment and connect only the telephone directly to the telephone socket.

If the fault is still present, connect another telephone (if available) to the telephone socket. The results will show you whether the fault lies with the unit or with the telephone line.

In the case of technical problems you can also contact our Service Department on the Hotline number 0180 5 00 13 88.

7.2 Replacing the telephone cable

If you have to replace your telephone cable, you can locate the appropriate cable at your dealer's with the help of the following diagram.

- Important Information -

7.3 Guarantee

AUDIOLINE equipment is manufactured and tested in accordance with the most up-to-date production methods. Selected materials and highly developed technology ensure trouble-free operation and long life. If your unit should develop a fault within the guarantee period, however, please contact the shop where you bought your AUDIOLINE equipment exclusively and have your purchase receipt available for inspection. The guarantee period is 24 months from the day of purchase under the following conditions: within the guarantee period, all defects due to material or manufacturing faults will be repaired free of charge. The guarantee is invalidated if the equipment has been tampered with by the purchaser or third parties. Any damage caused by improper handling or operation, by incorrect positioning or storage, by improper connection or installation or by excessive force or other external influences is not covered by the guarantee. In the case of complaint, we reserve the right to repair or replace defective parts or to exchange the equipment. Exchanged parts or exchanged equipment become our property. Claims for compensation are excluded insofar as they do not relate to criminal intent or gross negligence on the part of the manufacturer. All guarantee claims according to these conditions must be raised exclusively with your dealer. Rights under the guarantee can no longer be enforced after the expiry of 24 months from purchase and delivery of our products. In the case of unnecessary or unjustified demands on the customer service department, we will levy our usual service charges for materials, time, postage and packing. Any complaints must be reported as soon as a problem is found. The guarantee is valid within the German Federal Republic.

- Important Information -

7.4 Declaration of Conformity

WE AUDIOLINE GmbH

OF PROMENADENSTR. 1

D-41460 NEUSS

GERMANY

DECLARE UNDER OUR SOLE RESPONSIBILITY AS EU DISTRIBUTOR THAT THE PRODUCT

MODEL: TEL 28

DESCRIPTION: Cord connected telephone

IS IN CONFORMITY WITH THE BASIC REQUIREMENTS OF DIRECTIVE: 1999/5/EC

AUTHORISED SIGNATORY:

Signature:

Name:

Position in the company: MANAGING DIRECTOR

Date of issue: 17.09.2001

ZINNOW

A copy of this declaration will be retained for 10 years after cessation of production.

SUPPLIER: AUDIOLINE GmbH

ENADENSTR. 1

D-41460 NEUSS

PRODUCT: TEL 28

This product has been developed for use with an analogue telephone line (PSTN) within Germany. However, no guarantee can be accepted for trouble-free operation on all telecommunications terminal equipment connections due to the differences between the different telecommunications network operators.

- Important Information -

AUDIOLINE GmbH

Promenadenstrasse 1

41460 Neuss

Service Hotline [phone]
