| Product Type | Gas Hob |
| Brand | Bosch |
| Model | PCH615B90E |
| Number of Burners | 4 |
| Gas Type | Natural gas G20/G25 (convertible butane/propane) |
| Maximum Power per Burner | 3.0 kW (front left burner) |
| Electrical Supply | 230 V, 50 Hz |
| Dimensions (W x D x H) | 580 x 500 x 45 mm |
| Net Weight | 10 kg |
| Surface Material | Stainless steel |
| Ignition | Integrated ignition (electric) |
| Safety | Gas safety device (thermocouple) on each burner |
| Controls | Rotary knobs with position display |
| Cleaning | Stainless steel surface: clean with a soft cloth and soapy water |
| Burner Maintenance | Removable for cleaning, no abrasive products |
| Spare Parts | Available (grates, knobs, injectors, thermocouples) |
| Repairability | Repairability index: 7.5/10 |
| Warranty | 2 years |
Frequently Asked Questions - PCH615B90E BOSCH
How to light the gas on the Bosch PCH615B90E hob?
To light a burner, press the corresponding knob and turn it to the large flame symbol. While holding it down, activate the ignition control (usually a separate button or a stronger press) until the flame appears. Release the knob after a few seconds. If the flame goes out, repeat the operation.
What to do if a flame accidentally goes out?
If the flame goes out, the gas safety device (thermocouple) automatically cuts off the gas supply. Wait 1 to 2 minutes before relighting the burner. Make sure the flame surrounds the thermocouple properly. If the problem persists, check that the orifices are not blocked.
How to clean the burners and grates?
Allow to cool completely. Remove the grates and burner caps. Wash them with warm soapy water and a non-abrasive sponge. Rinse and dry thoroughly. Never use abrasive products or steel wool. The grates are dishwasher safe, but check the manual.
Can I use butane or propane gas with this model?
Yes, the hob can be converted to run on butane or propane gas. To do this, replace the injectors (nozzles) with those provided in the conversion kit. The adjustment must be carried out by a certified professional. Consult the manual for injector references.
Are the grates dishwasher safe?
Yes, the enameled cast iron or stainless steel grates of the Bosch PCH615B90E are generally dishwasher safe. However, to preserve their appearance, hand washing with a soft sponge is recommended. Avoid high temperature programs.
How to adjust the minimum flame on the burners?
The minimum flame adjustment is done using the bypass screw located on the gas valve stem. Turn the screw clockwise to increase the flame, counterclockwise to decrease. This adjustment must be done with the gas on. If in doubt, call a professional.
What to do if the gas does not ignite at all?
Check that the electrical supply is plugged in (ignition requires power). Make sure the burners are correctly positioned and that the gas is turned on. If the spark is present but the gas does not ignite, clean the burner ports. If the problem persists, contact customer service.
Is it possible to replace the injectors myself?
Replacing the injectors to change the gas type is possible for an experienced DIYer, but it is strongly recommended to call a certified installer. Incorrect installation can lead to gas leak risks. Follow the manual instructions strictly.
How to lock the controls to prevent use by children?
This model does not have a control lock function. For child safety, it is recommended to remove the knobs after use or install a hob guard. Always supervise children nearby.
What is the warranty and how to activate it?
The manufacturer's warranty is 2 years from the date of purchase. To activate it, keep the invoice and receipt. Register your product on the Bosch website within 30 days of purchase to benefit from a possible warranty extension. In case of breakdown, contact customer service.
