EWA7100B - Kettle AEG - Free user manual and instructions

Product Type	Kettle
Brand	AEG
Model	EWA7100B
Capacity	1.7 L
Power	2200 W
Voltage	220-240 V
Frequency	50/60 Hz
Cord Length	0.75 m
Base Type	360° cordless base
Dimensions (H x W x D)	25 x 22 x 15 cm
Weight	1.2 kg
Material	Plastic and stainless steel
Color	Black/Silver
Features	Boil-dry protection, auto shut-off, water level indicator, concealed heating element
Filter	Removable scale filter
Safety	Automatic shut-off, boil-dry prevention
Maintenance	Descale regularly, wipe with damp cloth
Spare Parts	Lid, base, filter (replaceable)
Certification	CE
Warranty	2 years

Frequently Asked Questions - EWA7100B AEG

What is the capacity of the AEG EWA7100B kettle?

The AEG EWA7100B kettle has a capacity of 1.7 liters, ideal for boiling water for several cups of tea or coffee.

Does it have automatic shut-off?

Yes, it features automatic shut-off and boil-dry protection, ensuring safety when the water has boiled or if the kettle is empty.

How do I descale the kettle?

To descale, fill the kettle with a mixture of water and descaling solution or equal parts water and vinegar, boil, and let it sit. Pour out, rinse thoroughly, and repeat if needed.

Can I open the lid while boiling?

No, the lid is locked during boiling for safety. It can only be opened when the kettle is not in use or after it has cooled down.

Is the base cordless?

Yes, it has a 360° cordless base, allowing you to lift the kettle easily and place it back from any angle.

How do I clean the scale filter?

The removable scale filter can be taken out and rinsed under running water. Use a soft brush if needed to remove limescale deposits.

What is the power consumption?

The kettle consumes 2200W of power, providing fast boiling times.

Does it have a water level indicator?

Yes, there is a clear water level window on the side, so you can easily see how much water is inside.

Can I use it with different voltages?

The kettle is designed for 220-240V voltage. Check your local supply; using it outside this range may damage the appliance.

Does it come with a warranty?

Typically, the AEG EWA7100B comes with a 2-year warranty, covering manufacturing defects but not wear and tear or misuse.

USER MANUAL EWA7100B AEG

GB Instruction book....11–15

Before using the appliance for the first time, please read the safety advice on page 12 carefully.

1. Place the base on a stable, flat surface. Plug the power cord into a wall outlet. Any excess cable can be wound around the underside of the base.
2. Place the base on a stable, flat surface. Plug the power cord into a wall outlet. Any excess cable can be wound around the underside of the base.
3. Place the base on a stable, flat surface. Plug the power cord into a wall outlet. Any excess cable can be wound around the underside of the base.
4. Place the base on a stable, flat surface. Plug the power cord into a wall outlet. If the power cord is too long, you can wind it around the base.

1. Press the button to open the lid, then fill the kettle with water. The water level should be visible on the water level indicator, but should not exceed the top mark.
2. Press the button to open the lid and fill the kettle with water. Make sure the water level is visible on the water level indicator, but does not exceed the Max mark.
3. Press the button to open the lid and pour water into the kettle. Make sure the water level stays within the water level indicators, and does not go above the Max mark.
4. To open the lid, press the button, then pour water into the kettle. Make sure the water level indicator is visible, so as not to exceed the Max mark.

1. Close the lid and make sure it clicks into place. Otherwise, the automatic shut-off will not work reliably. Place the kettle on the base. Press the ON/OFF switch down; the indicator light will illuminate and the kettle will begin heating.
2. Close the lid and make sure it locks properly. Otherwise, the automatic shut-off function will not work properly. Place the kettle on the base. Press the ON/OFF switch. The indicator light will turn on and the kettle will begin heating.
3. Close the lid so that it clicks into place properly. Otherwise, the automatic shut-off function will not work properly. Place the kettle on the base. Press the ON/OFF switch down; the indicator light will come on and the kettle will heat up.
4. Close the lid and make sure it is properly closed. If the lid is not correctly engaged, the automatic shut-off will not work properly. Place the kettle on its base. Press the on/off switch; the indicator light comes on and the kettle starts heating.

1. Depending on water hardness, the appliance should be descaled regularly. Fill the kettle with water and descaler according to the product instructions. Do not let the solution boil, as it may foam over. Then rinse the kettle thoroughly with fresh water.
2. Descaling is recommended regularly, depending on water hardness. Fill the kettle with water and descaler according to the descaler's instructions. Do not boil the solution as it may overflow. Then rinse the kettle thoroughly with running water.
3. Descale regularly, preferably depending on water hardness. Fill the kettle with water and descaler, following the instructions of the descaling product. Do not let the solution boil, as it may foam. Afterwards, rinse the kettle thoroughly with clean water.
4. It is recommended to descale regularly depending on water hardness. Fill the kettle with water and descaler, following the usage instructions of the descaling product. Do not let the solution boil, as the foam may overflow. Then rinse the inside of the kettle thoroughly with clean water.

Components

A. Jug B. Removable mesh filter C. Spout D. Lid E. Opening lid button F. Handle G. Water level indicator H. ON/OFF switch I. Separate base and mains cable

Read the following instructions carefully before using the appliance for the first time.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
• The appliance may only be connected to a power supply whose voltage and frequency comply with the specifications on the rating plate!
• Never use or pick up the appliance if the supply cord is damaged, or the housing is damaged.
• The appliance must only be connected to an earthed socket. If necessary, an extension cable suitable for 10 A can be used.
• If the appliance or the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person, in order to avoid hazard.

Always place the appliance on a flat, level surface. The appliance must be switched off and the mains plug withdrawn before cleaning and maintenance. The appliance and accessories become hot during operation. Use only designated handles and knobs. Allow to cool down before cleaning or storage. The mains cable must not come into contact with any hot parts of the appliance. Do not immerse the appliance in water or any other liquid. Attention: If the kettle is overfilled there is a risk that the boiling water may spray out, which could scald or burn! Therefore never fill the kettle above the maximum marking. Never operate appliance with open lid. Do not use or place the appliance on a hot surface or near source of heat. Only use the kettle for heating water! The kettle can only be used with the stand provided. Appliance is for indoor use only.

This appliance is intended for domestic use only. The manufacturer cannot accept any liability for possible damage caused by improper or incorrect use.

1. Before first use, wipe the inside and outside of the kettle with a damp cloth.

1. Place the base unit on a firm and flat surface. Plug the mains plug into a wall socket. Redundant cord can be wound up at the bottom of base unit.

1. Press the button to open the lid, pour water into the kettle. Make sure water level is visible in the water level indicator, but not exceeding the Max. mark.

1. Close the lid and make sure it snaps in correctly. Otherwise the auto switch off function will not work reliably. Place the kettle onto the base. Press down the ON/OFF switch; the indicator light will illuminate and the kettle will start to heat up.

1. The automatic switch off function. When the water has boiled or the kettle is moved from the base, it will switch off automatically. If you wish to stop the heating process before the water is boiling, simply lift up the ON/OFF switch to the OFF position.

Cleaning

1. Before cleaning, always unplug the appliance. Never rinse or immerse the kettle or base unit in water. Just wipe with a damp cloth, using no abrasive detergents. Occasionally rinse out the kettle with clean water.

1. To clean the mesh filter, grab the strainer insert and lift out. Cleaning the heating plate – superficial spots of rust may appear on the heating plate. Remove with a stainless steel cleaning agent.

1. Decalcifying is recommended regularly, depending on water hardness. Fill the kettle with water and decalcifier according to decalcifier product instructions. Do not boil the solution as it could foam over. Afterwards, rinse kettle thoroughly with fresh water.

Troubleshooting

Problem Possible cause Solution
The appliance switches off before boiling. Too much lime scale at the heating element of the kettle.	Run the decalcifying procedure.
The appliance does not switch off. Close lid until it locks.
	Instert the strainer correctly.
The appliance cannot be switched on. After operating with little or no water, the appliance has not cooled down sufficiently.	Allow to cool a short time and try again.

Disposal

Packaging materials

The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose the packaging materials in the appropriate container at the community waste disposal facilities.

Old appliance

The symbol 📄 on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
