Product type	Built-in cooker
Brand	Zanker
Model	KEV6042FBB
Color	Black
Dimensions (H x W x D)	85 x 60 x 60 cm
Net weight	52 kg
Power supply	220-240 V, 50-60 Hz
Total power	10.5 kW
Number of burners	4 (including 1 large burner)
Burner type	Gas
Ignition	Integrated, automatic
Oven type	Electric, multifunction
Oven capacity	70 liters
Oven functions	Convection, grill, fan-assisted, bottom heat, defrost
Oven cleaning	Pyrolytic
Oven light	Yes, halogen
Oven door	Removable, double glazing
Child safety	Safety valve on hob
Automatic shut-off	Yes, programmable
Repairability index	8.6 / 10

Frequently Asked Questions - KEV6042FBB ZANKER

How to turn on the oven of the Zanker KEV6042FBB cooker?

Turn the oven function knob to the desired position (e.g., fan-assisted, grill) then set the temperature with the thermostat. Ignition is automatic.

What to do if the gas does not light on the hob?

Check that the gas is on and the burners are dry. Press the button and hold it for a few seconds after ignition to activate the safety feature.

How to clean the cooker after use?

For the oven, use the pyrolytic program to burn off residues. For the hob, wait for the burners to cool down and clean with a damp sponge and mild soap.

What is the difference between fan-assisted and convection?

The fan-assisted uses a fan to distribute heat evenly, ideal for cakes. Convection is a general term; on this model, fan-assisted is the main option.

How to use the programmable timer?

Press the Timer button, set the desired time using the +/- keys, then confirm. The oven will automatically switch off at the end of the time.

What to do if the oven door is difficult to close?

Check that the hinges are not obstructed. If necessary, remove the door by slightly lifting it then clean the hinges. Refer to the manual for reassembly.

Can I use aluminum dishes in the oven?

Yes, but avoid direct contact with the heating element. Place the dishes on the rack and keep a minimum distance from the walls.

How to change the oven light bulb?

Unplug the appliance. Remove the glass cap by turning it to the left, unscrew the faulty bulb and replace it with a new bulb of the same type (halogen 25W). Screw the cap back on.

Where to find spare parts for model KEV6042FBB?

Spare parts are available from authorized Zanker dealers or on their website. The model has a high repairability index, making it easy to find parts.

What does error E01 on the display mean?

This error usually indicates a problem with the temperature probe. Contact after-sales service for diagnosis.

USER MANUAL KEV6042FBB ZANKER

Diagram showing a circular object with downward arrows pointing to a plate with four circular holes, no text or symbols present.

Milieubescherming

Safety information	9
Safety instructions	10
Product description	12
Daily use	12
Helpful hints and tips	12

Care and cleaning	12
Troubleshooting	13
Installation	13
Environment concerns	14

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

Children and vulnerable people safety

⚠ Warning! Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates or when it cools down. Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you activate it.
• Cleaning and user maintenance shall not be made by children without supervision.

General Safety

• The appliance and its accessible parts become hot during use. Do not touch the heating elements.
• Do not operate the appliance by means of an external timer or separate remote-control system.

• Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.

• Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

• Do not store items on the cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.
• If the glass ceramic surface is cracked, switch off the appliance to avoid the possibility of electric shock.

Safety instructions

Installation

Warning! Only a qualified person must install this appliance.

• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Keep the minimum distance from the other appliances and units.
  • Always be careful when you move the appliance because it is heavy. Always wear safety gloves.
• Seal the cut surfaces with a sealant to prevent moisture to cause swelling.
• Protect the bottom of the appliance from steam and moisture.
• Do not install the appliance adjacent to a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is opened.
• If the appliance is installed above drawers make sure that the space, between the bottom of the appliance and the upper drawer, is sufficient for air circulation.
• The bottom of the appliance can get hot. We recommend to install a non-combustile separation panel under the appliance to prevent access to the bottom.

Electrical connection

Warning! Risk of fire and electrical shock.

• All electrical connections should be made by a qualified electrician.
• Before connecting the hob to an oven and before every wiring make sure the main terminals of both appliances are not live.
• Make sure the appliance is installed correctly. Loose and incorrect plug and socket can make the terminal become too hot.
• Make sure that a shock protection is installed.
• Do not let the electricity bonds touch the appliance or hot cookware, when you connect the appliance to the near sockets.
• Do not let the electricity bonds tangle.
• Use a strain relief clamp on cable.
• Use the correct mains cable.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the Service or an electrician to change a damaged mains cable.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.

Use

Warning! Risk of injury, burns or electric shock.

- Use this appliance in a household environment.

- Do not change the specification of this appliance.

• Do not let the appliance stay unattended during operation.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not put cutlery or saucepan lids on the cooking zones. They become hot.
• Set the cooking zone to "off" after use.
• Do not use the appliance as a work surface or as a storage surface.
• If the surface of the appliance is cracked, disconnect immediately the appliance from the power supply. This to prevent an electrical shock.

Warning! Risk of fire or explosion.

• Fats and oil when heated can release flammable vapours. Keep flames or heated objects away from fats and oils when you cook with them.
• The vapours that very hot oil releases can cause spontaneous combustion.
• Used oil, that can contain food remnants, can cause fire at a lower temperature than oil used for the first time.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

Warning! Risk of damage to the appliance.

• Do not keep hot cookware on the control panel.

• Do not let cookware to boil dry.

• Be careful not to let objects or cookware fall on the appliance. The surface can be damaged.

• Do not activate the cooking zones with empty cookware or without cookware.
• Do not put aluminium foil on the appliance.
• Cookware made of cast iron, aluminium or with a damaged bottom can cause scratches on the glass ceramic. Always lift these objects up when you have to move them on the cooking surface.

Care and Cleaning

Warning! Risk of damage to the appliance.

• Clean regularly the appliance to prevent the deterioration of the surface material.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

Disposal

Warning! Risk of injury or suffocation.

• Contact your municipal authority for information on how to discard the appliance correctly.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.

General overview

1 Cooking zone 1200 W
2 Oval cooking zone 1500/2400 W
3 Cooking zone 1800 W
4 Residual heat indicator
5 Double cooking zone 750/2200 W

Residual heat indicator

The residual heat indicator comes on when a cooking zone is hot.

Daily use

You operate the hob with the knobs of the oven. The Daily Use chapter for the oven tells how to operate the hob.

When a cooking zone operates, it hums for a short time. This is typical of all ceramic glass

Helpful hints and tips

Cookware

• The bottom of the cookware must be as thick and flat as possible.
• Cookware made of enamelled steel and with aluminium or copper bottoms can cause the color change on the glass-ceramic surface.

Energy saving

Care and cleaning

Clean the appliance after each use. Always use cookware with clean bottom.

Warning! The risk of burns from residual heat!

cooking zones and does not show that the appliance operates incorrectly.

• If it is possible, always put the lids on the cookware.
• Put cookware on a cooking zone before you start it.
• Stop the cooking zones before the end of the cooking time to use residual heat.
• The bottom of pans and cooking zones must have the same dimension.

Warning! The sharp objects and abrasive cleaning agents can cause damage to the appliance.

For your safety, do not clean the appliance with steam cleaners or high-pressure cleaners.

Scratches or dark stains on the glass-ceramic cause no effect on how the appliance operates.

To remove the dirt:

1. – Remove immediately: melted plastic, plastic foil, and food with sugar. If not, the dirt can cause damage to the appliance. Use a special scraper for the glass. Put the scraper on the glass surface at an acute angle and move the blade on the surface.

- Remove after the appliance is sufficiently cool: limescale rings, water rings, fat stains, shiny metallic discolorations. Use a special cleaning agent for glass ceramic or stainless steel.

1. Clean the appliance with a moist cloth and some detergent.

2. At the end rub the appliance dry with a clean cloth.

Troubleshooting

Problem Possible cause Remedy
You cannot activate the appliance or operate it.	Activate the appliance again and system.	set the heat setting in less than 10 seconds.
Problem with the house electrical	system.	Examine the fuse in the electrical system of the house in the fuse box. If the fuses blow again and again, speak to qualified electrician.
The residual heat indicator does not come on.	The cooking zone is not hot because it operated only for a short time.	If the cooking zone should be hot, speak to the service centre.
You cannot activate the outer ring.		Activate the inner ring first.

If you tried the above solutions and cannot repair the problem, speak to your dealer or the customer service. Give the data from the rating plate, three digit letter code for the glass ceramic (it is in the corner of the glass surface) and an error message that comes on.

Make sure, you operated the appliance correctly. If not the servicing by a customer service technician or dealer will not be free of charge, also during the warranty period. The instructions about the customer service and conditions of guarantee are in the guarantee booklet.

Installation

Warning! Refer to the Safety chapters.

Before the installation, note down the serial number (Ser. Nr.) from the rating plate. The rating plate of the appliance is on its lower casing.

Modell KEV6042FBB		Prod.Nr. 949 594 300 00
Typ 58 AAD 65 ZO	220-240 V 50-60 Hz
Made in Germany	Ser.Nr. ......	7,6 kW
ZANKER

Built-in appliances

- Only use the built-in appliances after you assemble the appliance into correct built-in units and work surfaces that align to the standards.

Connection cable

- Use the correct mains cable of type H05BB-F Tmax 90°C (or higher) for a single phase or two phase connection.

- Replace the damaged mains cable with a special cable (type H05BB-F Tmax 90°C or higher). Speak to your local Service Centre.

Assembly

Diagram showing a beam supported by a circular component and a tray with circular holes, with arrows indicating force direction (no text or symbols)

Environment concerns

The symbol ☒ on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product,

please contact your local council, your household waste disposal service or the shop where you purchased the product.

Packaging material

The packaging materials are friendly to the environment and can be recycled. The plastic components are identified by marking: >PE<,>PS<, etc. Discard the packaging materials as household waste at the waste disposal facilities in your municipality.
