DO9057W - Waffle Maker DOMO - Free user manual and instructions

Product type	Waffle maker
Brand	DOMO
Model	DO9057W
Color	White
Material	Stainless steel and plastic
Plate coating	Non-stick
Power	900 W
Voltage	220-240 V ~ 50/60 Hz
Number of waffles	2
Dimensions (L x W x H)	25 x 22 x 9 cm
Weight	1.5 kg
Cable length	70 cm
Indicator light	Yes, heating indicator
Adjustable thermostat	Yes, 5 positions
Locking system	Yes, closing clip
Cleaning	Wipe with a damp cloth after cooling
Cool-touch handle	Yes
Cord storage	Wrap-around base
Spare parts	Not available separately
Warranty	2 years

Frequently Asked Questions - DO9057W DOMO

How to clean my DOMO DO9057W waffle maker?

Let the appliance cool down completely. Wipe the plates with a non-abrasive damp cloth. Never use metal sponges or harsh products. For stubborn residue, apply a little vegetable oil and wipe off after a few minutes.

Can I use non-stick spray on the plates?

No, it is not necessary as the plates are already non-stick. Using spray can damage the coating over time. If you wish to grease, lightly brush the plates with a brush dipped in oil.

What to do before first use?

Remove all packaging. Clean the plates with a damp cloth. Plug in the empty appliance and heat for about 10 minutes to eliminate new smells. Let it cool, then clean again.

Why are my waffles sticking to the plates?

This may be due to a lack of preheating or batter that is too liquid. Make sure the green light has turned on before pouring the batter. Also check that the plates are clean and lightly oiled.

How to set the thermostat for perfect cooking?

Turn the thermostat to the desired position (from 1 to 5). The higher the number, the more golden and crispy the waffle will be. Start at 3 and adjust according to your taste. The light goes off when the temperature is reached.

Can I prepare other foods besides waffles?

This waffle maker is designed only for classic waffles. Do not put foods that are too liquid or large, as this could damage the appliance or cause overflow.

The light turns on but the appliance does not heat up, what to do?

Check that the plug is properly connected and that the thermostat is not at position 0. If the problem persists, contact DOMO after-sales service.

How long does it take to cook a waffle?

Cooking time varies depending on the thermostat setting, typically between 3 and 5 minutes. The ready light comes on when the waffle is cooked. Open and check the color.

How to store the power cord?

Under the appliance there is a cord wrap. Wrap the cable around the provided cleats. Do not bend the cable too tightly.

Where to find spare parts for my DOMO waffle maker?

Spare parts are not sold individually for this model. In case of failure, contact DOMO customer service via the official website or the retailer.

USER MANUAL DO9057W DOMO

Exterior view of a silver rectangular electronic device with a black clip and control buttons (no visible text or symbols)

DO9057W

PRODUCT OF LINEA 2000

GARANTIEVOORWAARDEN

CONDITIONS DE GARANTIE

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures that are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The guarantee is issued with the original till receipt. All parts, which are subject to wear, are excluded from the warranty.

If your device breaks down within the 2-year warranty period, you can return the device together with your receipt to the shop where you purchased it.

CONDICIONES DE GARANTÍA

RECYCLAGE-INFORMATIE

Simple line drawing of a trash bin with two crossed lines indicating no waste or prohibition (no text or symbols)

RECYCLING INFORMATIONEN

Recycling symbol composed of three chasing arrows forming a triangle (no text or labels)

RECYCLING INFORMATION

This symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it must be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

The packaging is recyclable. Please treat package ecologically.

Simple line drawing of a trash bin with crossed lines indicating no waste or discharge (no text or symbols)

Recycling symbol composed of three chasing arrows forming a triangle (no text or labels)

Simple black line drawing of a plug with a curved wire (no text or symbols)

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard.

Warning symbol depicting steam rising inside a triangle (no text or numbers)

AVANT L'UTILISATION

Warning symbol depicting steam rising inside a triangle (no text or numbers)

VOR DEM GEBRAUCH

This appliance may be used by children from the age of 8 and up, and also by persons with a physical or sensory limitation, as well as mentally limited persons or persons with a lack of experience and knowledge. But only on the condition that these persons have received the necessary instructions on how to use this appliance in a safe way and know the dangers that can occur by using this appliance.

Children cannot be allowed to play with the appliance. Maintenance and cleaning of the appliance may not be done by children, unless they are older than 8 years old and are under supervision. Keep the appliance out of reach of children younger than 8 years old.

This appliance is suitable to be used in a household environment and in similar surroundings such as:

• Kitchen for personnel of shops, offices or other similar professional surroundings
• Farms
• Hotel or motel rooms and other surroundings with a residential character
• Guest rooms or similar

Attention: This appliance cannot be used with an external timer or a separate remote control.

The appliance can become hot during use. Keep the power cord away from hot parts and don't cover the appliance.

• Read all instructions before use.
• Check if the voltage stated on the appliance corresponds with the voltage of the power net at your home.
• Strict supervision is necessary when the appliance is used near or by children.
• The use of accessories that are not recommended or sold by the manufacturer may cause fire, electric shock or injuries.
• Unplug the appliance when it is not in use, before assembling or disassembling parts and before cleaning the appliance. Unplug by pulling the plug. Never unplug by pulling the cord.
• Do not leave a working appliance unattended.
• Never put this appliance on top of or near a gas stove or electrical stove or in a place where it may come into contact with an electric oven or another warm appliance.
• Do not use the appliance outdoors.
• Only use the appliance for the purpose for which it is intended.
• Check the appliance for possible damage. Never use

the appliance when the cord or plug is damaged, after malfunction or when the appliance itself is damaged. Take the appliance to the nearest qualified service center for check-up and repair.

• Never immerse the appliance or parts of it in water or any other liquid.
• Do not touch hot surfaces, only use the handle to lift the lid.
  • Always place the appliance on a steady, level, dry surface.
• Make sure that the appliance is well ventilated all around when you use it.
• Use a heat-resistant mat on heat-sensitive surfaces.
• Do not let the cord hang over a table or counter top or do not let it come into contact with hot surfaces.

PARTS

1. Handle
2. Lid
3. Power indicator light
4. Temperature indicator light
5. Anti-skid feet
6. Storage clip
7. Baking plates

PREPARE FOR USE

1. Check the baking plates on the inside of the appliance to make sure that they are clean and free of dust. Clean them with a damp cloth. Use indoors only. If the

appliance is switched on, d o not leave it unattended.

1. Lightly grease both sides of the baking plates.
2. Plug into the socket. The red light will light up.
3. Before you can start baking, you need to preheat the waffle maker. The green light will turn on indicating that the waffle maker has reached the correct temperature.
4. When using the appliance for the first time there may be a slight smell and light smoke from the baking plates. This is normal.

For hygienic reasons, do not eat the very first waffles that are made with the waffle maker. Throw them away.

BAKING WAFFLES

1. When the green light goes on, pour the waffle batter into the middle of the lower baking plate. Use a wooden or heatproof plastic spatula to distribute the batter evenly over the baking plates. Then use the handle to close.
2. Once the waffles are ready, remove them gently with a wooden or heatproof plastic spatula to loosen the sides. Never use metal objects, because they can damage the specially coated non-stick surface.
3. If you have finished baking, remove the plug from the socket.

CLEANING AND MAINTENANCE

• Do not use harsh abrasive or corrosive cleaning agents.
• Clean the appliance after each use.
• Unplug the electric lead and wait until the appliance has cooled sufficiently. Carefully clean the specially coated metal baking plates with a soft cloth to remove baking deposits.
• When not in use, store the appliance on a flat dry surface.

PRECAUCIONES IMPORTANTES

Warning symbol depicting steam rising inside a triangle (no text or numbers)

ANTES DEL USO

PŘED POUŽITÍM
