Product type	Freestanding cooker
Brand	Zanker
Model	KEE6040X
Width	60 cm
Height	85-90 cm
Depth	60 cm
Net weight	Approximately 55 kg
Power supply	230 V / 50 Hz
Total power	Approximately 10 kW
Cooking type	Electric (radiant or ceramic hob)
Number of burners	4
Oven type	Electric, fan-assisted or natural convection
Oven functions	Fan-assisted, bottom heat, top heat, grill, light
Oven capacity	Approximately 65-70 liters
Cleaning	Catalytic enamel (rear wall) or pyrolysis (depending on version)
Child safety	Control lock
Automatic shut-off	Yes, in case of overheating or non-use
Repairability index	Spare parts available, index from 7 to 10/10
Country of manufacture	Germany (Electrolux group)
Included accessories	Grid, drip tray, baking sheet

Frequently Asked Questions - KEE6040X ZANKER

What types of cooking hobs does the Zanker KEE6040X cooker offer?

The Zanker KEE6040X cooker is equipped with electric hobs (radiant or ceramic). Models vary by version, but it generally includes 4 burners of different sizes.

How to clean the oven of the Zanker KEE6040X?

The oven can be cleaned manually with white vinegar or a special oven cleaner. Some models have a catalytic rear wall that absorbs grease, making cleaning easier.

What to do if the cooker does not heat up?

First check the power supply (fuse, circuit breaker). If everything is normal, the problem may be with the thermostat or the heating element. Consult the manual or a professional.

How to use the child lock button?

The child lock button (often a padlock symbol) is located on the control panel. Press it for a few seconds to activate or deactivate. This prevents any changes to the settings by a child.

What is the oven capacity?

The Zanker KEE6040X oven offers a capacity of approximately 65 to 70 liters, allowing you to cook large dishes.

Are spare parts available?

Yes, Zanker offers a spare parts service. You can order heating elements, glass, handles, etc., through the official website or authorized dealers.

How to set the time on the cooker?

Press the 'Timer' or 'Clock' button (depending on model) then use the +/- buttons to set the time. Confirm by pressing again. Consult the manual for precise diagrams.

Is the Zanker KEE6040X cooker compatible with standard sockets?

No, it requires a special socket (often 32 A) or a direct connection to the electrical grid by a qualified electrician, as the power exceeds 3 kW.

What symbols appear on the control panel?

Symbols include: fan-assisted (fan), bottom heat (line at bottom), top heat (line at top), grill (zigzag), light (bulb). Refer to the manual for details.

How to replace the oven light bulb?

Unplug the appliance. Remove the glass cover, unscrew the defective bulb and replace it with a bulb resistant to 300°C. Reassemble everything.

USER MANUAL KEE6040X ZANKER

Diagram showing a circular object with downward arrows pointing to a plate with four circular holes, no text or symbols present.

Milieubescherming

Safety information	9
Safety instructions	10
Product description	11
Daily use	12
Helpful hints and tips	12

Care and cleaning	12
Troubleshooting	12
Installation	13
Environment concerns	14

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

Children and vulnerable people safety

⚠ Warning! Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates or when it cools down. Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you activate it.
• Cleaning and user maintenance shall not be made by children without supervision.

General Safety

• The appliance and its accessible parts become hot during use. Do not touch the heating elements.
• Do not operate the appliance by means of an external timer or separate remote-control system.

• Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.

• Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

• Do not store items on the cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.

Safety instructions

Installation

Warning! Only a qualified person must install this appliance.

• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Keep the minimum distance from the other appliances and units.
  • Always be careful when you move the appliance because it is heavy. Always wear safety gloves.
• Seal the cut surfaces with a sealant to prevent moisture to cause swelling.
• Protect the bottom of the appliance from steam and moisture.
• Do not install the appliance adjacent to a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is opened.
• If the appliance is installed above drawers make sure that the space, between the bottom of the appliance and the upper drawer, is sufficient for air circulation.
• The bottom of the appliance can get hot. We recommend to install a non-combustile separation panel under the appliance to prevent access to the bottom.

Electrical connection

Warning! Risk of fire and electrical shock.

- All electrical connections should be made by a qualified electrician.

• Before connecting the hob to an oven and before every wiring make sure the main terminals of both appliances are not live.
• Make sure the appliance is installed correctly. Loose and incorrect plug and socket can make the terminal become too hot.
• Make sure that a shock protection is installed.
• Do not let the electricity bonds touch the appliance or hot cookware, when you connect the appliance to the near sockets.
• Do not let the electricity bonds tangle.
• Use a strain relief clamp on cable.
• Use the correct mains cable.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the Service or an electrician to change a damaged mains cable.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.

Use

Warning! Risk of injury, burns or electric shock.

• Use this appliance in a household environment.
• Do not change the specification of this appliance.
• Do not let the appliance stay unattended during operation.

• Do not operate the appliance with wet hands or when it has contact with water.

• Do not put cutlery or saucepan lids on the cooking zones. They become hot.

• Set the cooking zone to "off" after use.
• Do not use the appliance as a work or as a storage surface.

Warning! Risk of fire or explosion.

• Fats and oil when heated can release flammable vapours. Keep flames or heated objects away from fats and oils when you cook with them.
• The vapours that very hot oil releases can cause spontaneous combustion.
• Used oil, that can contain food remnants, can cause fire at a lower temperature than oil used for the first time.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

Warning! Risk of damage to the appliance.

• Do not keep hot cookware on the control panel.
• Do not let cookware to boil dry.

• Do not activate the cooking zones with empty cookware or without cookware.

• Do not put aluminium foil on the appliance.

• Do not let acid liquids, for example vinegar, lemon juice or limescale remover touch the hob. This can cause matt patches.

Care and Cleaning

Warning! Risk of damage to the appliance.

• Clean regularly the appliance to prevent the deterioration of the surface material.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

Disposal

Warning! Risk of injury or suffocation.

• Contact your municipal authority for information on how to discard the appliance correctly.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.

Product description

General overview

1 Cooking zone 1500 W
2 Cooking zone 2000 W
3 Cooking zone 1500 W
4 Cooking zone 2000 W

Warning! The risk of burns from residual heat!

Daily use

You operate the hob with the knobs of the oven. The Daily Use chapter for the oven tells how to operate the hob.

Before first use

Put cookware containing water on each cooking zone, set the maximum position and operate the appliance for

10 min. This is to burn off the residue in the appliance. After that, operate the appliance at minimum position for 20 min. During this period, an odour and smoke can occur. This is normal. Make sure that the airflow is sufficient.

Helpful hints and tips

Cookware

- The bottom of the cookware must be as thick and flat as possible.

Energy saving

- If it is possible, always put the lids on the cookware.

• Put cookware on a solid hotplate before you start it.
• Stop the solid hotplate before the end of the cooking time to use residual heat.
• The bottom of pans and solid hotplates must have the same dimension.

Care and cleaning

Important! The risk of burns from residual heat! Let the appliance become sufficiently cool.

Scratches or dark stains on the surface cause no effect on how the appliance operates.

To remove the dirt:

1. Use the cleaning powder or the cleaning pad.
2. Clean the appliance with a moist cloth and some detergent.
3. Heat the hotplate to a low temperature and let it to dry.
4. To keep the hotplates in good shape, regularly rub in a sewing machine oil. Polish off the oil with absorbent paper.

Important! For stainless steel edges of the hob use the cleaning agent for stainless steel.

The stainless steel edge of the plate can change the colour as a result of the high temperature.

The stainless steel can become dirty if the temperature is too high. Because of this do not cook with the stone pots, earthenware pans or cast iron plates. Do not use the aluminium foil to prevent damage to the top during operation.

The Stainless steel parts wash with water, and then dry with a soft cloth.

Troubleshooting

Problem Possible cause Remedy
You cannot activate the appliance or operate it.	Check if the appliance is correctly	connected to the electrical supply (refer to connection diagram).
Problem with the house electrical system.		Examine the fuse in the electrical system of the house in the fuse box. If the fuses blow again and again, speak to qualified electrician.

If you tried the above solutions and cannot repair the problem, speak to your dealer or the customer service. Give the data from the rating plate, three digit letter code for the glass ceramic (it is in the corner of the glass surface) and an error message that comes on.

Make sure, you operated the appliance correctly. If not the servicing by a customer service technician or dealer will not be free of charge, also during the warranty period. The instructions about the customer service and conditions of guarantee are in the guarantee booklet.

Installation

Warning! Refer to the Safety chapters.
Before the installation, note down the serial number (Ser. Nr.) from the rating plate. The rating plate of the appliance is on its lower casing.

- Only use the built-in appliances after you assemble the appliance into correct built-in units and work surfaces that align to the standards.

Connection cable

• Use the correct mains cable of type H05BB-F Tmax 90°C (or higher) for a single phase or two phase connection.
• Replace the damaged mains cable with a special cable (type H05BB-F Tmax 90°C or higher). Speak to your local Service Centre.

Assembly

Diagram showing a mechanical setup with a circular component and a tray with four circular holes, no text or symbols present.

Environment concerns

The symbol ☒ on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

Packaging material

The packaging materials are friendly to the environment and can be recycled. The plastic compo- s are identified by marking: >PE<,>PS<, etc. Dis-

card the packaging materials as household waste at the waste disposal facilities in your municipality.
