Sonicare AirFloss HX8221 - Interdental brush PHILIPS - Free user manual and instructions

Product Type	Interdental Brush (AirFloss)
Model	Philips Sonicare AirFloss HX8221
Dimensions (Handle)	Approx. 2.5 x 1.5 x 9.5 inches (6.4 x 3.8 x 24.1 cm)
Weight	Approx. 5.0 oz (142 g)
Power Source	Rechargeable Li-ion battery, 3.7 V
Charging Time	24 hours for full charge
Battery Life	Up to 2 weeks of typical use
Water Reservoir Capacity	0.42 fl oz (12.5 ml)
Pressure Settings	2 settings: Gentle and Normal
Modes	Single burst mode, double burst mode
Water Resistance	IPX7 (waterproof up to 1 meter for 30 minutes)
Nozzle Type	Standard interdental nozzle (replaceable)
Nozzle Replacement Indicator	Blue indicator fades to white; replace every 6 months
Cleaning Method	Use water or mouthwash; rinse reservoir and nozzle after use
Safety Features	Automatic shut-off after 2 minutes; overcharge protection
Spare Parts Available	Replacement nozzles (HX8240, HX8250), charging base
Warranty	2 years limited warranty
What's in the Box	AirFloss handle, charging base, 1 nozzle, user manual

Frequently Asked Questions - Sonicare AirFloss HX8221 PHILIPS

How do I charge the Philips Sonicare AirFloss HX8221?

Place the handle on the charging base. Plug the base into a power outlet. The battery indicator will flash during charging and become steady when fully charged. A full charge takes about 24 hours.

Can I use mouthwash in the AirFloss?

Yes, you can use mouthwash diluted with water (1:1 ratio) or water alone. Avoid using thick solutions that may clog the nozzle.

How often should I replace the nozzle?

Replace the nozzle every 6 months or when the blue indicator on the nozzle fades to white. Using a worn nozzle reduces effectiveness.

What do the different burst modes do?

The AirFloss has two modes: Single burst releases one burst per trigger, and Double burst releases two bursts in quick succession. Double burst is recommended for thorough cleaning.

How do I clean the AirFloss?

After each use, rinse the reservoir and nozzle with water. Once a week, clean the handle with a damp cloth. Do not submerge the handle. Use a toothpick to clean the nozzle hole if clogged.

Is the AirFloss waterproof?

Yes, the handle is IPX7 rated, meaning it can be rinsed under the tap. However, do not immerse in water for extended periods.

Why is the AirFloss not producing spray?

First, ensure the reservoir has water. If it’s empty, refill. If the nozzle is clogged, clean it with a pin. Also check that the battery is charged.

Can I travel with the AirFloss?

Yes, it is travel-friendly. Pack the handle, charging base, and nozzle. Note that the charging base is not waterproof and should be kept dry.

What is the difference between AirFloss and floss?

The AirFloss uses bursts of air and microdroplets to clean between teeth. It is easier for those with dexterity issues and can be faster than traditional floss, but it may not remove all plaque as effectively.

How do I know when the battery is low?

The battery indicator on the handle will flash amber when the battery is low. Charge it promptly.

USER MANUAL Sonicare AirFloss HX8221 PHILIPS

AirFloss

ソニッケア ーエアーフロス

電動デンタルフロス

HX8214/22, HX8221/02,

HX8211/02, HX8215/22,

HX8226/02, HX8216/02

取扱説明書

保証書付

保証書は、この取扱説

明書の最終 ページにつ

いておりますので お 買

い求めの販売店で記

入を 受 け てくだ さ い 。

はじめに

Guidance in English 15\~27

●保 証

保証とアフターサービス 28

仕様 29

無料修理規定 30

保証書 ...... 最終ページ

必ずお守り ください

HX8221/02 HX8211/02 HX8226/02 HX8216/02

HX8214/22 HX8215/22

H 充電器

5

エアーフロスの特長

歯間のクリーニングに

連続噴射機能

充電表示

充電催促表示

No plug adapter required.

□ □

Plug adapter required.

2. 洗浄します。

4. 充電器を拭きます。

注意

2. 水タンク内の水を捨てます。

廃棄するとき

1. ハンドルの上 部と下 部をそれぞれしっ

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Use AirFloss as part of your oral care routine. In addition to brushing, it helps reduce plaque.

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USE DANGERS

To reduce the risk of electrocution:

Do not place or store product where it can fall or - be pulled into water.

Do not place or drop charger into water or other liquids, unplug the charger immediately if this should occur.

After cleaning, make sure the charger is - completely dry before you connect it to an electrical outlet.

WARNINGS

To reduce the risk of burns, electrocution, fire, or physical injury:

DO NOT use isopropyl alcohol or other cleaning fluids in the reservoir as it may be an ingestion hazard.

DO NOT use attachments other than those - recommended by the manufacturer.

DO NOT plug the charger into an electrical - outlet with a voltage other than specified on the bottom of the charger. This product is designed to operate within a range of 100 to 240 volts.

ENGLISH

Voltage converters DO NOT warrant voltage compatibility.

DO NOT use hot water so as to avoid physical - injury.

DO NOT use the charger outdoors. -

DO NOT drop or insert any foreign objects into - the reservoir.

Never force the plug into an electrical outlet; if the - plug does not easily fit into the electrical outlet, discontinue use.

Keep the cord away from heated surfaces. -

Discontinue use if the nozzle, body, or charger - body/cord appears damaged in any way.

The mains cord cannot be replaced. If the mains - cord is damaged, discard the charger.

This product contains no user-serviceable parts. - Refer to chapter 'Warranty and service' if the appliance no longer works properly or needs repair.

Use this product only for its intended use as - described in this document or as recommended by your dental professional.

This product is not intended for use by persons - (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

- Children should be supervised to ensure that they do not play with the appliance.

-AirFloss is a personal care device and is not intended for use on multiple patients in a dental office or institution.

-Do not direct the spray under the tongue or into the ear, nose, eye, or other sensitive areas. This

ENGLISH

product may cause serious damage to these areas. See chapter 'Using your AirFloss' for correct usage. Avoid applying excessive pressure on the guidance - tip of the nozzle.

MEDICAL WARNINGS

Consult your dental professional before you use - this product if you: have any concern, recent oral or gum surgery, suffer from an ongoing dental condition or had extensive dental work in the previous two (2) months.

Contact your dental professional if excessive - bleeding occurs after using this product or bleeding continues to occur after one (1) week of use.

Discontinue use of this product and contact - a physician/dentist if discomfort or pain is experienced.

This product complies with the safety standards - for electromagnetic devices. If you have a pacemaker or other implanted device, contact your physician or the device manufacturer prior to use.

Consult your physician if you have other medical - concerns.

Electromagnetic fields (EMF)

This Philips product has been tested and is compliant with safety standards for electromagnetic devices. If handled properly and according to the instructions in this user manual, the product is safe to use.

SAVE THESE INSTRUCTIONS

Overview (Fig. 1)

1 Guidance tip
2 AirFloss nozzle

ENGLISH

3 Activation button
4 Reservoir and cover
5 Handle
6 Charge indicator
7 Power on/off button
8 Charger

Note: The contents of the box may vary based on the model purchased.

Charging

Charge AirFloss for 24 hours before first use.

1 Put the plug of the charger in the electrical outlet.

2 Place the handle on the charger.

The charge indicator flashes green to indicate that the appliance is charging.

Note: When it is fully charged, AirFloss has an operating time of up to 2 weeks (or 14 uses).

Note: When the charge indicator flashes yellow, the battery is low and needs to be recharged (fewer than 3 uses left).

ENGLISH

Preparing for use

1 Align the nozzle so the tip faces the front of the handle and press the nozzle down onto the handle ('click').

Note: Replace the nozzle every 6 months for optimal results. Also, replace the nozzle if it becomes loose or no longer 'clicks' onto the handle.

2 Open the cover of the reservoir ('click').

3 Fill the reservoir with mouthwash or water.

Note: To operate effectively, AirFloss must contain either mouthwash or water.

Tip: For a fresher experience, use mouthwash with your AirFloss.

Note: Do not use mouthwash that contains isopropyl myristate (e.g. Dentyl Active) or high concentrations of essential oils, as it may damage the appliance. This includes all mouthwash sold in glass and ceramic packaging.

4 Close the cover of the reservoir by pressing ('click').

5 Press the on/off button. The green light illuminates.

ENGLISH

6 Press and hold the activation button until spray comes out of the tip.

Using your AirFloss

1 Make sure the AirFloss is turned on.

2 Place the tip between the teeth and apply gentle pressure. Slightly close your lips over the nozzle when it is in place, to avoid splashing.

Tip: Use your finger to press the activation button.

3 Press the activation button to deliver a single burst of air and micro-droplets of mouthwash or water between the teeth. Alternatively, hold the activation button to deliver continuous bursts of mouthwash or water approximately every 1 second(select models).

4 Slide the guidance tip along the gum line until you feel it settle between the next two teeth.

ENGLISH

5 Continue this procedure for all spaces including behind your back teeth.

Note: AirFloss is intended to be used on the front/outside surface of the teeth only.

6 To turn off AirFloss, press the on/off button again.

Automatic shut-off function

The automatic shut-off function automatically turns off AirFloss if it has not been used for 4 minutes.

Cleaning

Do not clean the nozzle, handle or charger in the dishwasher.

Do not use cleaning agents to clean the appliance.

Handle and nozzle

1 Remove the nozzle from the handle. Rinse the nozzle after each use.

2 Open the reservoir and rinse it under a faucet to eliminate residue.

Tip: You can also use a cotton swab to wipe the reservoir.

Note: Do not immerse the handle in water.

ENGLISH

3 Wipe the entire surface of the handle with a damp cloth.

Charger

1 Unplug the charger before you clean it.

2 Wipe the surface of the charger with a damp cloth.

Storage

If you are not going to use AirFloss for an extended period of time, follow the steps below.

1 Open the cover of the reservoir and empty it.
2 Press the activation button until no more spray comes out.
3 Unplug the charger.
4 Clean AirFloss nozzle, handle and charger.
5 Store AirFloss in a cool, dry place away from direct sunlight.

ENGLISH

Environment

- Do not throw away the appliance with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment.

- The built-in rechargeable battery contains substances that may pollute the environment. Always remove the battery before you discard and hand in the appliance at an official collection point. Dispose of the battery at an official collection point for batteries. If you have trouble removing the battery, you can also take the appliance to a Philips service center. The staff of this center will remove the battery for you and will dispose of it in an environmentally safe way.

Removing the rechargeable battery

Please note that this process is not reversible.

1 To deplete the battery, repeatedly press the activation button until AirFloss no longer produces any bursts of air.

2 Use a screwdriver to pry open the handle.

ENGLISH

3 Cut the wires and remove the battery from the appliance. Observe basic safety precautions.

Warranty and service

www.philips.com/support

Philips warrants its products for two years after - the date of purchase. Defects due to faulty materials and workmanship will be replaced at Philips expense provided that convincing proof of purchase in the qualifying period is provided. - Contact our Consumer Care Center at 1-800-682-7664 (North America), outside North America contact your local Philips Consumer Care Center. Internet information: www.sonicare.com (North America) or www.philips.com (outside North America).

WARRANTY EXCLUSIONS

What is not covered under warranty: AirFloss nozzle - Damage caused by misuse, abuse, neglect, - alterations or unauthorized replacement. Normal wear and tear, including chips, scratches, - abrasions, discoloration or fading.

IMPLIED WARRANTIES

ANY IMPLIED WARRANTIES, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THE EXPRESS WARRANTIES SET FORTH ABOVE. IN

ENGLISH

SOME STATES LIMITATIONS ON DURATION OF IMPLIED WARRANTIES DO NOT APPLY.

LIMITATION OF REMEDIES

IN NO EVENT SHALL PHILIPS OR ANY OF ITS AFFILIATED OR SUBSIDIARY COMPANIES BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, LOSS OF SAVINGS OR REVENUE; LOSS OF PROFIT; LOSS OF USE; THE CLAIMS OF THIRD PARTIES INCLUDING, WITHOUT LIMITATION, DENTISTS AND DENTAL HYGIENISTS; AND COST OF ANY SUBSTITUTE EQUIPMENT OR SERVICES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Philips Oral Healthcare, Inc.

22100 Bothell Everett Hwy Bothell, WA 98021 U.S.A.

Phone:[phone]

Philips Oral Healthcare, Inc.

22100 Bothell Everett Hwy

Bothell, WA 98021 U.S.A.
