Type	Security Camera
Brand	Costar
Model	CR4010XDI
Dimensions	Approximately 120 x 70 x 70 mm
Weight	Approximately 500 g
Power Supply	DC 12V, 1A
Video Resolution	1080p Full HD
Night Vision	Up to 30m with IR LEDs
Motion Detection	Yes, with adjustable sensitivity
Two-Way Audio	Built-in microphone and speaker
Field of View	100° horizontal
Storage	MicroSD card (up to 128GB) and cloud
Connectivity	Wi-Fi 2.4GHz, Ethernet
Weatherproof Rating	IP65 (indoor/outdoor use)
Operating Temperature	-20°C to 50°C
Mounting	Wall or ceiling mount included
Maintenance	Clean lens with soft, dry cloth
Safety	Use only supplied power adapter; do not expose to water
Spare Parts	Contact Costar support for replacement parts
Repairability	Designed for easy installation; internal repair by qualified technician

Frequently Asked Questions - CR4010XDI Costar

How do I reset the Costar CR4010XDI to factory defaults?

Press and hold the reset button on the back of the camera for 10 seconds until the LED blinks red.

What is the maximum SD card size supported?

The camera supports MicroSD cards up to 128GB (Class 10 or higher).

Can the CR4010XDI be used outdoors?

Yes, it has an IP65 rating, making it suitable for outdoor use, but avoid direct water spray.

How to connect the camera to Wi-Fi?

Download the Costar Cam app, power on the camera, and follow the in-app instructions to scan the QR code and connect to your 2.4GHz Wi-Fi network.

Does the camera support two-way audio?

Yes, it has a built-in microphone and speaker for two-way communication.

How to update firmware?

Firmware updates are pushed automatically via the app. Ensure the camera remains connected to the internet to receive the latest updates.

What is the night vision range?

The infrared LEDs provide clear night vision up to 30 meters in complete darkness.

Can I view the camera from multiple devices?

Yes, you can share access with multiple users via the Costar Cam app using the share feature.

How to clean the camera lens?

Use a soft, dry cloth to gently wipe the lens. Do not use any chemical cleaners.

What does the LED status indicator mean?

Solid green means connected; slow flashing green means ready to pair; red means not connected or error. Consult the manual for details.

USER MANUAL CR4010XDI Costar

Before reading this manual

This operation manual contains basic instructions on installing and using Network Video Recorder.

Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product. Safety warnings and precautions contained in this operation manual are intended to promote proper use of the product and thereby prevent accidents and property damage and must be followed at all times.

Once you have read this operation manual, keep it at an easily accessible location for future reference.

The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts and accessories or from the user's failure to comply with the instructions contained in this operation manual.

• It is recommended that first-time users of Network Video Recorder and individuals who are not familiar with its use seek technical assistance from their retailer regarding product installation and use.
• If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer and seek professional assistance.
• Both retailers and users should be aware that this product has been certified as being electromagnetically compatible for commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer version.

Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Important Safeguards

1. Read Instructions

All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions

The safety and operating instructions should be retained for future reference.

3. Cleaning

Unplug this equipment from the wall outlet before cleaning it. Do not use liquid aerosol cleaners. Use a damp soft cloth for cleaning.

4. Attachments

Never add any attachments and/or equipment without the approval of the manufacturer as such additions may result in the risk of fire, electric shock or other personal injury.

5. Water and/or Moisture

Do not use this equipment near water or in contact with water.

6. Ventilation

Place this equipment only in an upright position. This equipment has an open-frame Switching Mode Power Supply (SMP5), which can cause a fire or electric shock if anything is inserted through the ventilation holes on the side of the equipment.

7. Accessories

Do not place this equipment on an unstable cart, stand or table. The equipment may fall, causing serious injury to a child or adult, and serious damage to the equipment. Wall or shelf mounting should follow the manufacturer's instructions, and should use a mounting kit approved by the manufacturer.

This equipment and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the equipment and cart combination to overturn.

8. Power Sources

This equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power, please consult your equipment dealer or local power company.

You may want to install a UPS (Uninterruptible Power Supply) system for safe operation in order to prevent damage caused by an unexpected power stoppage. Any questions concerning UPS, consult your UPS retailer. This equipment should be remain readily operable.

9. Power Cords

Operator or installer must remove power and TNT connections before

14. Damage requiring Service

Unplug this equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions:

A. When the power-supply cord or the plug has been damaged.

B. If liquid is spilled, or objects have fallen into the equipment.

C. If the equipment has been exposed to rain or water.

D. If the equipment does not operate normally by following the operating instructions, adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the equipment to its normal operation.

E. If the equipment has been dropped, or the cabinet damaged.

F. When the equipment exhibits a distinct change in performance to this indicates a need for service.

15. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

16. Safety Check

Upon completion of any service or repairs to this equipment, ask the service technician to perform safety checks to determine that the equipment is in proper operating condition.

17. Field Installation

This installation should be made by a qualified service person and should conform to all local codes.

18. Correct Batteries

Warning: Risk of explosion if battery is replaced by an incorrect type. Replace only with the same or equivalent type. Dispose of used batteries according to the instructions. The battery shall not be exposed to excessive heat such as sunshine, fire or the like.

19. Tmra

A manufacturer's maximum recommended ambient temperature (Tmsa) for the equipment must be specified so that the customer and installer may determine a suitable maximum operating environment for the equipment.

20. Elevated Operating Ambient Temperature

If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer's maximum rated ambient temperature (Timra).

21. Reduced Air Flow

Before reading this manual

In-Text

Symbol Type Description
	Caution Important information concerning a specific function.
	Note Useful information concerning a specific function.

User's Caution Statement

Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

FCC Compliance Statement

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE. WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.

WEEE (Waste Electrical & Electronic Equipment)

Correct Disposal of This Product

Before reading this manual

Copyright

© 2017 Costar Video Systems

Costar Video Systems reserves all rights concerning this operation manual.

Use or duplication of this operation manual in part or whole without the prior consent of Costar Video Systems is strictly prohibited.

Contents of this operation manual are subject to change without prior notice.

Table of Contents

1

Part 1 - Getting Started ....9

Setup Wizard....9

Camera Registration....12

Camera Scan Button....12

Camera View Buttons....14

Camera List Area 15

Video Display Area 15

Apply/Cancel Buttons 16

Camera Registration Mode....16

Login 17

Live Mode....18

Live Menu 18

Zoom....22

PTZ Control 22

Dewarping Control 23

Event Monitoring 24

Covert Camera 24

Context Menu Access 24

Edit Group 25

Video Recording....25

Panic Recording....25

Audio Recording 25

Video Recording Playback 26

All Channel Blackrock 76

Table of Contents

System Setup ....28

General 28

Date/Time 29

User 30

Storage 32

Monitoring....32

Record Setup....34

General 34

Schedule....35

Pre-Event 36

Smart Failover....37

Event Setup 37

Video-Analytics 37

Alarm-In 40

Video Loss 41

Audio Detection 41

Recording Fail....42

Text-In....42

Camera System 43

Face Detection....44

Network Setup 44

General 44

WAN 46

FEN 47

RTSP 48

Device Setup....48

Alarm-Out 48

Dowarts Capital 40

Table of Contents

General 55

Advanced Setup 55

Stream....61

Audio....62

Upgrade....62

3

Part 3 - Search....63

Time-Lapse Search 63

Search Menu....64

Time-Lapse Search Menu....65

Context Menu....68

Print 68

Event Log Search....69

Overlapped Recording Search 70

4

Part 4 - WebGuard ....71

Web Monitoring Mode 72

Web Search Mode....75

5

Part 6 - Appendix....77

Index 77

Part 1 - Getting Started

Setup Wizard

Setup Wizard lets you configure basic settings required for operating the system.

Setup Wizard only appears during initial booting. When you login as an administrator account after initial booting, you can use Wizard to go to Live menu and select Wizard.

1 Select a system language.

Select Cancel from any of the Wizard screen to cancel the setup process and return to the main setup menu.

Quick Wizard

1 Select Quick Wizard.

2 Specify the current date and time and then click Next.

Part 1 - Getting Started
3 Choose the desired Recording Method and click Next.

• Recording resolutions used under each recording method and record video quality setting are as follows:

	High Video Quality Priority Profile	Standard Recording Profile	Longer Recording Time Priority Profile
Motion Event Record	Very high High Standard
Continuous & Motion Event Record	High (Continuous) / Very high (Motion)	Standard (Continuous) / High (Motion)	Low (Continuous) / Standard (Motion)
Continuous Very High High Low

4 Choose the desired Recording Quality and click Next.

5 Click Finish to exit Quick Wizard.

Network Wizard

- Higher recording quality uses up more disk space.
- Recording resolution is determined based on the

√ After exiting from Quick Wizard, the network with Network Wizard will start automatically.

1 Select Network Wizard.

Part 1 - Getting Started

2 Specify whether the system is connected to the Internet and click Next.

If you have chosen No, wait for the test to finish and then click Finish to exit Network Wizard.

3 Select Network Configuration and then click Next. Select either Auto Configuration or Manual Configuration and then click Test to test the system's current network configuration.

4 Enter in the Device Name field the NVR name to be registered on the FEN server and then click Check to check its availability.

- The device name you register on the FEN server will be a unique name used to identify the NVR. Once registered, the name can be used to access the NVR directly from clients such as iRAS. Check the name's availability to complete the registration process. The Finish button will then become activated.

- You will be prompted with an error message if you do not enter a name for the NVR or enter a name already registered on the FEN server.

- Depending on the network environment, FEN services may not be active and therefore prevent the NVR from connecting to the network. In this case, you will need to manually configure the ports. For more information on port configuration, refer to Network Setup on page 44.

5 Click Finish to exit Network Wizard.

Part 1 - Getting Started

Camera Registration

Once Network Setup Wizard is complete, the system will automatically enter Camera Registration mode and scan for cameras connected to the NVR.

1 Camera Scan Button
2 Camera View Menus
3 Camera List Area
4 Video Display Area
5 Apply/Cancel Buttons

You can also register the camera on the remote program. For more information on the remote camera registration, refer to the Registration on page 53.

Camera Scan Button

You can scan and search and register cameras that were not detected automatically or third party cameras.

Rescan

Scans for DirectIP™ cameras that were not scanned automatically.

Third Party Scan

Used to manually scan for third-party cameras that cannot be recognized by the auto scan feature.

√ Some functions may not be supported for the third-party cameras depending on their protocol and model.
Camera registration system is optimized in combination with DirectIP™ camera. If video settings exceed the system performance, certain function may be restricted and we cannot guarantee the recording quality. In this case, please configure the settings again to optimize the performance.

- Protocol: Select the protocol used by the camera (or video encoder) you wish to search for.

Even if the network device uses a protocol supported by the NVR, the device itself may not be visible for scanning and registration by the NVR. For more information about supported network devices and models, contact your retailer.

• Mode: Select the scan mode.

Part 1 - Getting Started

- Advanced Setup: If the camera is networked but not scanned, use this setup. This setup allows you to change the network setting of the NVR's VIDEO IN port which is camera's network environment. Check the camera's network setting first before you use this setup.

Make sure that this setting does not conflict with the WAN setting. For more information on the WAN setting, Refer to WAN on page WAN on page 46.

Link-local address: Indicates the default IP address.

- Manual: Allows you to enter the IP address and other network settings manually.

- DHCP Server: It makes the NVR run as a DHCP server. Check if there is another DHCP server on the same network. If there is no DHCP server, this option is enabled. The NVR allocates an IP address automatically in the range of 10.10.0.128 to 10.10.254.254 by using DHCP to the camera connected to the NVR's VIDEO IN port. On DHCP Server, Video In Network is connected between NVR and network cameras only, so Gateway does not have any meaning. Subnet Mask is 255.255.0.(Class B).

- When several NVRs exist in the same network, only one of NVRs has to be run as a DHCP server. If several DHCP servers are running, the redundant IP may be allocated to the camera. - The range of 10.10.0.1 to 10.10.0.127 is not recommended because NVR system already has the IP address.

1 Select Scan to commence scanning.

Only cameras that are connected to the NVR via VIDEO IN ports can be scanned and registered.

2 Select a camera from the scan list and then select AddCamera. The device begins window will open

Part 1 - Getting Started

Go To Camera

Moves the focus automatically to the camera using MAC address of camera in the camera list.

Auto Detection

Activated in Live mode. Automatically notifies the user of unregistered DirectIP™ camera connections.

Screen Auto. Assign

Assigns the detected cameras on the video display area.

Camera list

By using the camera information file, .csv, the user can register the cameras easily.

- Export: Exports the list of camera information on USB as a .csv file.

- Import: Imports a camera information file, .csv file. The

Camera View Buttons

- ALIGNMENT ☐ Button: Realigns camera screens displayed on the video display area in the order of Video In port connections.

- RESET Button: Refreshes the video display area and the camera list.

Selecting RESET clears all scanned devices from the list.

• TOOL Button: Displays network camera tool window and changes the camera protocol.

DirectIP™ cameras can be detected automatically but iNEX protocol cannot be detected automatically. We recommend you use the DirectIP protocol to detect the cameras automatically. Changing the protocol restarts the camera and registers the camera to NVR to use it. For more information on settings, refer to the network camera's user manual.

Part 1 - Getting Started

Camera List Area

① Screen Position/Registration Status: Identifies the camera's position in the video display area. A white background indicates a camera that is available for registration. A dark blue background indicates an already registered camera. Other registered cameras are shown in black background.
② Model: Indicates the camera's model.
③ MAC: Displays the last 6 digits of the camera's MAC address.

Video Display Area

Left-click on the video display area to toggle between split screen and single screen modes. Drag the camera screens around to rearrange them. The maximum number of the channels that can be registered on the NVR and the current registered camera channels display on the upper left corner of each screen.

Camera Screen

① Camera Title

Indicates the camera's title. Left-click on the title to

Part 1 - Getting Started

③ Screen Position/Registration Info

Flashes in orange if the camera has not been registered to the NVR.

• Information is not indicated on the bottom of the screen for cameras already registered to the NVR, and the Screen Position/Registration Info icon is shown with a black background.

- Screen Position/Registration Info icon for cameras registered to another NVR is shown with a steady orange background on top of a grey screen.

Camera Menu

Right-click on the video display area to bring up the camera menu.

• Remove Camera: Removes the registered camera.
• Remove Device: Removes the registered encoder.
• Authentication: Enter the necessary camera login info.
  • Color Control: Adjusts the camera's color settings.
  • Information: Displays the camera's basic information. • Title: Edits the camera's title.
• Remove All Cameras: Removes all the registered cameras.

You can drag & drop to add or remove cameras.

Camera Registration Mode

While in Live mode, right-click and select Camera Registration.

If Auto Detection has been enabled, a message will appear while in Live mode when a new camera is detected.

Select OK to enter Camera Registration mode.

Auto Detection should be disabled if no more camera connections are expected.

Part 1 - Getting Started

Login

Configuring the NVR's settings and accessing its searching and other functions require an authorized user login.

While in Live mode, right-click on the mouse and select Login and either press the SETUP button on the remote control.

2 Select a user, enter the password, and then select OK.

- There is no default password for the admin account. Select admin and then OK without entering a password to log in.

• Leaving the admin account unassigned with a password poses a security risk. Please assign a password at your earliest convenience. A warning message will continue to be displayed until a password is assigned.
- Click on the button next to the password field using the mouse. This will bring up a virtual keyboard you can use to assign a password. For more information on using the virtual keyboard, refer to the Text Input via Virtual Keyboard on page 27.

3 To log out, right-click on the mouse and select Logout.

Part 1 - Getting Started

Live Mode

Live Menu

Press the MENU button on the NVR's front panel while in Live mode to bring up the Live menu on the right edge of the screen. Press MENU button once more to hide the menu. Use the Arrow buttons on the remote control to select the menu options.

Part 1 - Getting Started

① Layout

Used to change the screen layout.

② Display

• OSD (On Screen Display): Enables/disables the OSD feature.
• Aspect Ratio: Select whether to enable the original aspect ratio of video transmitted from the camera.

③ Previous/Next Group

Loads the previous/next screen group.

④ Search Mode

• Time-Lapse Search: Select Search Mode > Time-Lapse Search to search for and play back saved data directly from the record table.
• Event Log Search: Select Search Mode > Event Log Search to search for event logs and play back associated event recordings.

⑤ Select Camera

Displays the selected camera in a single screen format.

⑥ Sequence

Initiates Sequence in the same manner as pressing the SEQUENCE button on the remote control while in Live mode. To exit, select Sequence once more or press the SEQUENCE button. The 🔒 icon is displayed on the bottom left part of the screen while Sequence is in progress.

Full Sequence

Displays all channels in sequence while in Live mode (single and split screen settings). In order to use the Full

⑦ Freeze

Freezes the screen. Select Freeze again to unfreeze.

⑧ Panic Recording

Activates/deactivates Panic Recording.

⑨ Alarm

Pressing this button while the alarm has been activated resets all NVR outputs, including the built-in buzzer.

Part 1 - Getting Started

⑩ Status

Event

This screen displays an overview of all events. When an event occurs, the corresponding channel flashes for 5 seconds.

Event Types

	Motion Trip Zone
	Tampering Alarm-In
	Video Loss Audio Detection
	Recording Fall Text-In
	Check Alarm-In Fan Error
	Face Detection

- Panic Record: Displays event status based on current Panic Record status.

- Check Recording: Displays event status based on System Monitoring settings. For more information, refer to the Monitoring on page 32.

- No Storage Found: It will be highlighted when no recordable storage device has been found.

Storage

Indicates each disk's status.

• Disk Bad

Not Formatted	A disk that has never been used before.
Good	Disk performing normally.If the HDD is partially damaged, indicates the bad sector percentage.
Error	If the HDD's bad sector ratio is higher than as designated by the user.Generates a system event.

• Temperature

N/A	Unable to detect the disk's temperature.
Good	Operating within normal temperature range.

Part 1 - Getting Started

Network

This page provides a complete overview of the network status in real-time.
    note right of A: Total Power Consumption: 6.0W (Max 16.0W)
    note left of A: Event: CONNECTED
    note right of A: Storage: EXCHANGES ID
    note right of A: Network: NETWORK

Information shown include camera connection status, LAN port link status, power consumption, number of connected clients, and network connection info.

Camera Connection
Video Encoder
LAN Port Link
	If receiving power from the NVR, the actual amount of power consumed by each camera is indicated under each camera icon. Total power consumption is shown at the top of the screen

Part 1 - Getting Started

⑪ Wizard

Launches the Setup Wizard.

⑫ Setup

Used to access the Setup menu.

⑬ Status Indication

Displays system status icons.

Status Indication

	Indicates remote control receptivity.
	Indicates connection to the NVR from a remote program.
	Indicates two-way audio connection between NVR and camera.
	Indicates two-way audio connention between NVR and PC.
	Indicates two-way audio connention between NVR, PC and camera.
	Indicates connection to the NVR using the VNC service.
	Indicates a zoomed in state.
	Indicates Freeze is in use.
	Indicates Sequence is in use.
1/4	Indicates the current screen's group.
	Indicates an event monitoring.
	Indicates HDD use. The icon to the left is shown if using the overwrite setting. Otherwise, remaining HDD space is shown as a percentage value.

- In Full Screen mode, activating Zoom automatically selects the current channel.

- To restore the channel to normal size, press the Zoom button again.

PTZ Control

While in Live mode, right-click and select PTZ from the context menu or press the PTZ button on the NVR's front panel or remote control to display the PTZ camera selection window.

1. CAM1

2. CAM2

3. CAM3

4. CAM4

Select the camera you wish to control. The ☐on will begin to flash on the selected camera's OSD window. Use the Arrow buttons to pan and tilt the camera up, down, left, and right.

Use the Camera 1 and 2 buttons to zoom in/out. Use the Camera 3 and 4 buttons to shift focus from nearby to far and vice versa.

You can also change the direction by dragging on the mouse.

Also, it's possible to use the mouse wheel to zoom in/out.

Logging in with an account that has PTZ Control Authority is necessary in order to control PTZ cameras.

Part 1 - Getting Started

Dewarping Control

While in Live mode, right-click and select Dewarping from the context menu. The icon will begin to flash on the selected camera's OSD window. You can change the direction by dragging on the mouse. In order to select dewarping type and mode, Video (Camera - Advanced Setup) must first be enabled.

This feature is supported only in fisheye camera Original mode does not support dewarping control feature.

Setting Up a PTZ Preset

While in PTZ mode, select the VIEW button on the remote control to display the Set Preset window and assign the current position as a preset.

While in PTZ mode, select the SAVE button on the remote control to display the Move to Preset window.

Advanced Settings

In PTZ mode, selecting a camera and then clicking Menu button loads the Advanced PTZ screen as shown below. You can load the Advanced PTZ screen also by pressing the Play/Pause button and then SETUP button on the front panel. This menu lists Speed, Auto Pan, and other advanced PTZ camera control options available for the camera. Also selecting Move Location button moves PTZ camera to the point that the user clicks. Options that are not available for the selected PTZ camera remain inactive.

You can use the mouse to control PTZ cameras. Left-click on the mouse and drag to move the camera in the desired direction and use the mouse wheel to zoom in/out.

While in PTZ mode, place the mouse pointer close to the bottom edge of the screen to display the PTZ Tools window.

Part 1 - Getting Started

命令和命令号	PTZ Camera Pan and Tilt
	Zoom In/Out
	Focus Near / Far
	IRIS Open / Close
	One Push
	Set / Move to Preset
	Device Menu supported by the camera

• The exact PTZ protocol supported by the camera must be specified in order to use the NVR's PTZ controls.
  • Drag and drop to reposition the PTZ Tools window.
• Select the icon to hide the PTZ Tools window.

Event Monitoring

When an event occurs, the NVR automatically changes to the camera screen linking event monitoring and shows the icon on the system status area on the bottom left portion of the screen. To use the Event Monitoring feature, navigate to Display Setup >

Covert Camera

Use this feature to assign Covert Camera View

permissions.

Navigate to Camera Setup > General and designate cameras as Covert 1 or Covert 2.

• Covert 1: Hides images from the camera in Live mode but does indicate the camera's title and status via icons.

- Covert 2: The camera is indicated as being inactive. Images from the camera are not shown. Camera title and status icons are not shown.

Users that have a cover Covert Camera View are

able to view both images from and status icons

for all Covert 1 and Covert 2 cameras.

Context Menu Access

While in Live mode, press the remote control's button and then the Menu button to display the Context Menu window. You can display the ContextMenu window also by pressing the Play/Pause button and then SETUP button on the front panel. Alternatively, right-click on the mouse to access the Context menu.

• PTZ: Access PTZ controls.
• Dewarp: Dewarps the fisheye camera image.
- Zoom:Zoom in.
- Audio: Enable/disable audio. (This function supports only in single screen.)
- Color Control: Select a channel to display its Color Control window. Adjust the selected camera's brightness contrast saturation and hue settings

Part 1 - Getting Started

• Information: Select a network channel to display information about the selected channel's device.
• Edit Group: Rearrange the split screen layout.
- Camera Registration: Activate Camera Registration mode.
- Login/Logout: Log into the account or log out of the account.

Edit Group

Edit Group lets you customize split screen pages in both Live and Search modes.

1 While displaying a split screen page, select the Edit Group option from the context menu. A yellow border is drawn around the page. Use the arrow buttons on the front panel or the mouse to select a different page.
2 Press a Camera button or select a camera after pressing the Menu button. Selected camera is then loaded on to the selected page. Repeat to assign other channels to the page.
3 Press the remote control's button to exit Edit Group. Alternatively, press the Menu button and then select Exit Group Edit to exit.

Edit Group will terminate automatically after 15 seconds of inactivity.

Video Recording

Video recording will only take place if all the connections are made correctly as per information contained in Part 2 of this operation manual. For more information on video recording settings, refer to the Record Setup on page 34.

Panic Recording

Select Live or Search menu's Panic Recording 1 icon or press the PANIC button on the front panel or the remote control to commence panic recording on all registered cameras.

To stop Panic Recording, select the Panic Recording icon or press the PANIC button again. If the Panic Recording Duration option under Record Setup > General has been configured, Panic Recording will automatically terminate after the specified duration

Record Setup on page 34.

• Panic Recording takes place irrespective of any recording schedule set up by the user.
• Panic Recording video profile from Record Setup – General applies to all Panic Recording videos.

Panic Recording will not take place if recording mode is not set to Recycle and the HDD has reached 100% of its capacity.

Part 1 - Getting Started

Video Recording Playback

You can play back video recordings by using mouse or remote control.

- Login with an account that has search permission is needed to playback video recordings.

• The initial video playback point in Search mode is the recording's last playback point or the end of the recording data.
  • Audio playback of the selected recording is available in full screen mode only.
  • Covert protection on cameras also applies to video recording playback.

All Channel Playback

1 Press the Menu button while in Live mode.
2 Select the Search Mode icon and then select Time-Lapse Search or Event Log Search.
3 The selected search mode will be initiated.

For more information on data search, refer to the Part

3 - Search on page 63.

Remote Control Buttons during Playback

1 Camera Button: Displays the selected recording in full screen.
2 Zoom Button: Allows you to zoom in on a specific area of the recording.
3 Layout Button: Cycle through 1x1, corridor format, 2x2 modes.

Context Menu

While in Search mode, press the remote control's

一

Part 2 - Configuration

Menu Use

Information contained in this section (Menu Use) applies to all other instructions found throughout Part 3 - Configuration.

Login with an ID that has permission to access the setup menu is needed to access and make changes to the Setup menu.

1 While in Live mode, press the remote control's SETUP button or select Live menu > Setup using the mouse.

System Setup
Record Setup
Event Setup
Network Setup
5 Device Setup

To apply default settings, select the Default button located on the left bottom corner of the setup window.

Text Input via Virtual Keyboard

Use the remote control's arrow buttons to select a virtual keyboard key and then press the remote control's button or click on the key using the mouse.

Toggle case.
← Deletes the character to the left of the cursor.
× Deletes the character to the right of the cursor.
Converts keyboard.

Part 2 - Configuration

Mouse

Using a mouse makes it easier to configure the settings. A mouse lets you make selections faster and use its wheel to scroll through long menus. You can also use the mouse wheel to increase/decrease numerical values.

System Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

General

This Setup menu contains general system options.

• Site: Used to enter a description about the system's installation site (no description by default). You can edit the information using the virtual keyboard.
• System ID: Used to identify the NVR apart from other NVRs. System ID is also used to control the NVR with the NVRs connected

If an upgrade attempt fails, an upgrade failure message will be displayed. Refer to Error Code Types in the installation manual for more details.

• Setup: Exports current NVR settings or imports existing settings.
• Import: Decide whether to import network settings as well. If you do not wish to change the current network settings, do not select Include Network Setup.

√ Selecting Setup Import does not change the settings below.

• Time-related settings (Date/Time, Time Zone, and Use Daylight Saving Time)
  • Camera-related Advanced Settings settings
• Camera-related Stream settings (Only if the resolution is different from the camera in exporting)

- Export: Exports the current system settings to a storage device connected to the system's USB port. You can designate a File Name for the export file.

For USB flash memory devices, the NVR supports the FAT32 file format only.

• Show System Log: Displays a searchable list of 5,000 most recent system log entries. For more information on types of system log entries, refer to the System Log Types in the installation manual. The 📁 icon appears next to log entries originating from a remote source. To export the system log select the Expert

Part 2 - Configuration

In order to display the system log.txt file, you must use the correct character encoding settings and use a fixed width font.

- Clear All Data: Erases all recording data. Selecting Clear All Data displays a confirmation window. Select Clear to proceed.

• Before you perform Clear All Data, make sure you are not accidentally deleting important data. Erased data cannot be recovered.
• Clear All Data does not affect the system log. Instead, the Clear All Data event will be added to the log.
• System Shutdown: Shuts down the system. When prompted, select System Shutdown.

Date/Time

• Time Zone: Used to designate the system's time zone.

Refer to the map displayed on the screen and change the time zone using the mouse or the arrow buttons.

• Use Daylight Saving Time: Enables DST correction.
• Time Sync.: Select a time server for the system to synchronize with.

1 Select Automatic Sync.
2 Enter the Time Server's IP address or domain name or select ▼ and then choose a server from the list of registered time servers.
3 Specify the server synchronization Interval.
4 Select OK to apply and exit.

- If you have configured the DNS Server setting under Network - WAN, you can enter the time server's domain name instead of its IP address.

- Selecting Run as Server sets the current NVR as a time server for other NVRs within the system.

• Holiday: Designate holidays. On specified holidays, recording takes place according to the holiday

Part 2 - Configuration

Select the ✗ on to delete the existing holiday date.

4 Select a group for the user and then enter a password. The password can be up to 16 characters in length and may include letters, symbols, and numbers.

User

Use this option to register users and assign permissions.

1 Select + Group and enter a group name. A group name can be up to 15 characters in length.

2 Specify the group's permission settings. For more information on permission settings, refer to the

5 If you wish to use RTSP function, set the password. For security, It is recommended that you set a different password for RTSP and User. For more information on RTSP, refer to the RTSP on page 48.

6 Configure Auto Login and Auto Logout settings.

7 Select Apply or OK to exit.

- Group names, user names, passwords, and email can be entered using the virtual keyboard. For more information on using the virtual keyboard, refer to the Text Input via Virtual Keyboard on page 27.

- To delete a registered user or group, select the icon on the right of the corresponding user/group Group Administrator and User admin cannot be deleted.

- Select the icon next to Group & User on the top of the screen to delete all groups and users

Part 2 - Configuration
Group Permissions

System Shutdown May shutdown the system from the system menu.
Upgrade May upgrade the system from the system menu (System Setup).
Color Control May adjust each camera's brightness, contrast, saturation, and hue settings.
System Check May view System Check results.
PTZ Control May control PTZ cameras.
Alarm-Out Control	May reset in the event of an alarm-out.Alarm-outs can be reset by pressing the Alarm button on the device or selecting the Alarm-Out Control button on the remote program.
Covert Camera View May access cover cameras in Live and Search modes.
Search Clip Copy	The user who has an permission for Clip Copy can perform Clip Copy. If the user does not have an permission, Clip Copy is not allowed but only search is allowed.
Setup	System Time ChangeMay change the system's date and time settings.
	Data Clear May clear data stored in the system.
	PTZ Setup May configure PTZ settings.
	Alarm-Out Setup May configure alarm-out settings.
	Covert Camera SetupMay configure convert camera settings.
	Record Setup May configure recording settings.
	VNC May access the NVR and control it remotely via network.
	Setup Import May import previously saved NVR settings.
	Setup Export May export current NVR settings.

Part 2 - Configuration

Storage

Use this option to configure storage settings.

• Type: Indicates the type of the installed disk.
  • Capacity: Indicates the disk's capacity.
• Format: If the disk has been formatted, indicates either Record or Not Using. If you have connected an unformatted storage device, the Use As value will be indicated as Not Formatted.
• Information: Indicates if the disk is being used for recording purposes. Disks that were used in different systems will show up as Other. Select Information to check the saved data's time information or select Delete to erase the data.

- Select Format to prepare the disk as a storage for data recording.

• Disks formatted with Use As set to Not Using will not be used for data recording.
  • This NVR supports SATA2 HDDs.
• Disks formatted with Use As set to Not Using will not be used for data recording.
  • This NVR supports SATA2 HDDs.

Monitoring

Use this option to configure Monitoring settings.

• Settings: Configure when and what the system should monitor for.
• Actions: Configure alarm-out (NVR alarm-out channel, NVR beep, camera alarm-out channel) and notification (email, LAN1 through 5, SNS, alert window) settings.

- Select Format to prepare the disk as a storage for data recording.

Part 2 - Configuration
Monitoring Options

System	Define monitoring times. If self-diagnosis is not performed on a regular basis, the system will assume an error.
Bootup, Restart, Shutdown	Define bootup, restart and shutdown actions.
Panic Record Define panic recording actions.
Check Recording	The system will assume an error if the system has been scheduled to record normally but recording does not take place during scheduled intervals.Select Schedule On and then configure the days of the week, times, and monitoring interval.Select the button on the bottom left of the screen to add a schedule. Select 12in to delete the schedule.
Check Alarm-In	The system will assume an error if the alarm-in status does not change during the specified monitoring interval while alarm-in is active.
Disk Almost Full Generates an event if the disk reaches the specified capacity (80% to 99%).
Disk Full Generates an event when all disks reach their maximum capacity.
Disk Bad	Generates an event when the specified percentage of the disk becomes damaged. Set to between 10% and 90% in 10% intervals.
Disk Temperature	Specify the threshold temperature. Once any disk reaches this threshold, the system will issue an alert.

Part 2 - Configuration

Record Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

General

Configure general recording settings.

• Recycle: When the recording disks become full, the system overwrites existing data with new data, starting with the oldest first. If Recycle is disabled, recording will simply stop when the recording disks reach their maximum capacity.
• Record Audio: The camera will record audio along with video.
• Event Record Dwell: If linked recording is designated as an event-triggered action, recording takes place for the duration specified under this setting.
• Auto Deletion: Configure this option to delete recording data automatically after the specified number of days has elapsed. Select between 1 day and 999 days.

disk has sufficient capacity and saves new data by overwriting Time Lapse Recording data that are older than as specified under Recycle mode.

- If the recording stored on the disk is shorter than the duration specified under Limit Time-Lapse Recording, the older of Event Recording or Time Recording data is deleted first.

- The system's recording time may change depending on recording quality, resolution, motion, and other configurations made by the user. The duration specified under Limit Time-Lapse Recording may not be guaranteed in certain situations.

• Use Panic Recording: Enable/disable Panic Recording.
• Panic Recording Duration: Disable Panic Recording automatically. Select between 5 mins and 1 hr. If you do not wish to disable the feature automatically, select No Limit.
  • Video Profile: Select a recording profile value for Panic Recording.

Part 2 - Configuration

Schedule

Disabling Schedule On suspends schedule recording regardless of the schedule and displays the 🎨 icon on the upper left corner of each camera screen. Pressing the PANIC button displays the 🔊 icon and commences panic recording.

Set Record Schedule mode as Simple Mode or Advanced Mode. Advanced Mode allows you to configure a unique recording schedule for each event. Select the ✗ icon to delete a schedule.

Simple Mode Options

- Mode: Select No Record, Time, Event, or Time & Event.

No Record	Unless the PANIC button is pressed, no recording will take place during the scheduled time frames on the scheduled days.
Time	Theicon appears on the upper left corner of the screen. Theicon appears at scheduled times to indicate recording is in progress.
Event	The(red) icon appears on the upper left corner of the screen. Theicon appears when the specified event occurs to indicate recording is in progress.if Pre-Event is enabled, the(yellow) and icons appear when recording is not in progress, or the(red) and icons appear when an event occurs and recording is in progress.
Time & Event	Theicon appears on the upper left corner of the screen and recording commences as per the video profile selected for time under Setup. When an event occurs, the icon changes into (yellow) icon and recording commences as per the video profile selected for events under Setup.

- Channel: Select which cameras to apply the schedule to.

Part 2 - Configuration

Advanced Mode Options

Select to configure event types and video profiles.

- Type: Event-specific and time recording icons are as follows:

	Time Lapse (Time)		Audio Detection
	Alarm-In Trip	Zone
	Motion Detection		Tampering
	Video Loss Test	In
	Recording Fail Fan Error
	Face Detection

• Video Profile: Configure the profile to use for recording.

• Dwell: Specify how long to record for after a corresponding event occurs.

- Upper-tier schedule's settings apply to unconfigured channels.

- If multiple events take place on a specific channel and different Video Profile and Dwell Time settings apply, highest settings apply to all event-linked recordings.

Pre-Event

When an event occurs, enabling this option includes the specified duration prior to the event in the event-triggered recording.

• No.: Select which cameras to apply Pre-Event to.
• Video Profile: Select a video profile for the recording.
• Dwell: Specify the duration of pre-event recording data.

- If no event mode schedule exists in the schedule, a warning message prompting you to add an event mode schedule will be displayed.

- The warning message will appear even in Time & Event mode.

Part 2 - Configuration

Smart Failover

When the connection is recovered again, Smart Fallover Service enables the data recorded on SD memory card to record on NVR.

• Recording Failover Service: Use this option to record the data recorded on SD memory card on NVR.
• Recorded Data: Indicates the time information of the recorded data.
• Status: Indicates the current status of the recorded data.

• This function supports only if selecting Recording Failover Service.
• This function is only supported for the cameras supporting Failover recording of SD memory card.
• If the camera is reconnected during recording, the video recording will restart from the beginning.

Event Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

Video-Analytics

Video-Analytics methods are Motion, Trip Zone, and Tampering.

Motion

• No.: Select which cameras to apply Motion Detection
- Sensitivity: Set daytime and nighttime sensitivity settings between 1 (Low) and 5 (High).

Part 2 - Configuration
• Zone: Define the motion detection block.

Grid of evenly spaced white dots on a black background (no text or symbols)

Use the remote control's arrow buttons to move the block selection window up, down, left, and right. The selection window consists of 8 blocks per row. Select/deselect individual blocks using the Camera buttons. You can use the mouse to drag the zone and then select, clear, or reverse the selection.

From the zone selection screen, press the ← button on the remote control or right-click on the mouse to open up the Zone Setup menu.

- Select: Confirm the block selection in the selection window.

- Clear: Clear the block selection in the selection window.

- Reverse: Clear the blocks selected within the selection window and select all unselected blocks within the selection window.

- Select All-Select all blocks

• Etc: Select to detect an event on PTZ movement.

- Actions: Specify which actions to take when motion is detected.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

- Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.

- Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.

- PTZ: Moves the PTZ camera to a specific preset position when an event occurs.

Event Monitoring: Selects the cameras to monitor when an event occurs.

In order to use the Callback feature, the NVR must be registered on the remote program.

- Motion Ignoring Time: The system does not produce event log entries or issues remote notifications regarding motion detected during the specified time following the initial motion detection. Set a value between 1 sec and 5 secs or choose Never.

Part 2 - Configuration

• No.: Select which cameras to apply Trip Zone to.
- Sensitivity: Set daytime and nighttime sensitivity settings between 1 (Low) and 5 (High).
• Zone: Define the motion detection block.

Grid of evenly spaced white dots on a black background, no text or symbols present

Use the remote control's arrow buttons to move the block selection window up, down, left, and right. The selection window consists of 8 blocks per row. Select/deselect individual blocks using the Camera buttons. You can use the mouse to drag the zone and then select, clear, or reverse the selection.

From the zone selection screen, press the ← button on the remote control or right-click on the mouse to open up the Zone Setup menu.

within the selection window.

• Select All: Select all blocks.
• Clear All: Clear all block selections.
• Reverse All: Clear all selected blocks within the
  screen and select all unselected blocks within the screen.
• Trip Direction: Define in which direction the motion has to occur in order for it to be considered an event. Select In for movements from outside the selection area in or Out for movements from inside the selection area out.
• OK: Save the changes and exit the menu.
• Cancel: Exit the menu without saving the changes.

- Actions: Specify which actions to take when Trip Zone is detected.

Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

- Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.

• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
  Event Monitoring: Selects the cameras to monitor when an event occurs.

In order to use the Callback feature, the NVR must be registered on the remote program.

- Trip Zone Ignoring Interval: The system does not produce event log entries or issues remote notifications regarding Trip Zone events detected

Part 2 - Configuration
Tampering

• No.: Select which cameras to apply Tampering to.
- Sensitivity: Set to between 1 (Low) and 5 (High).
- Activation Time: Specify how long tampering detection needs to last in order for it to be considered an event. Tampering detections that do not last for the specified duration of time will not be considered as events.
- Actions: Specify which actions to take when Tampering is detected.

Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
  Event Monitoring: Selects the cameras to monitor when an event occurs.

Alarm-In

• No.: Enable / disable alarm-ins.

This option includes both local and network camera alarm-ins. 1 through 4 are network camera alarm-ins, whereas 5 through 8 are local alarm-ins.

• Title: Use the virtual keyboard to enter titles.
• Type Change the alarm-in type.
- Actions: Specify which actions to take when Alarm-In is detected.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SN5, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
  Event Monitoring: Selects the cameras to monitor when an event occurs.

Part 2 - Configuration

Video Loss

• Activation Time: Specify how long video loss has to last in order for it to be considered as an event. When the video loss is not detected for the specified duration of time, it will not be considered as an event.
• Actions: Specify which actions to take when a Video Loss event occurs.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
  Event Monitoring: Selects the cameras to monitor when an event occurs.

In order to use the Callback feature, the NVR must be registered on the remote program.

Audio Detection

• No.: Select which cameras to apply Audio Detection to.
• Sensitivity: Set to between 1 (Low) and 5 (High).
• Activation Time: Specify how long audio detection has to last in order for it to be considered an event. Audio detections that do not last for the specified duration of time will not be considered as events.
• Actions: Specify which actions to take when audio detection events occur.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
  Event Monitoring: Selects the cameras to monitor when an event occurs.

Part 2 - Configuration

• Activation Time: Specify how long recording fail has to last in order for it to be considered as an event. When the recording fail is not detected for the specified duration of time, it will not be considered as an event.

• Actions: Specify which actions to take when a Recording Fall event occurs.

• Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
• Event Monitoring: Selects the cameras to monitor when an event occurs.

In order to use the Callback feature, the NVR must be registered on the remote program.

- Setup: Configure text-in devices.

- It's possible to batch configure all text-in devices with the exception for port settings.

- An influx of large amounts of text-in data from multiple channels can hinder system performance.

• Text-In Product: The setup window is updated so that the portion below the port setting matches the corresponding text-in device. Displayed screenshot illustrates Generic Text settings.
  • Transaction Start: Once Transaction Start has been designated, the system will reorganize the specification

• Line Delimiter: Designate a string to mark the end of a line. You can enter control strings by selecting and then entering , followed by a letter. For example, Carriage Return is M and Line Feed (new line) is J.

• Ignore String: Specify a string to ignore from transaction records.
• Case Sensitive: Ignores case in strings designated under Transaction Start, Transaction End, Line Delimiter, and Ignore String.

Case Sensitive does not apply to control strings.

• Time Out: Once Time Out has been enabled, the system will assume the end of a transaction if no new string is entered within the specified duration of time. Select between 5 secs and 15 mins.
  Selecting RS232, USB-Serial 1 through 8, or LAN 1 through 4 as the port activates the Port Setup button. Select Setup and configure the Baud Rate, Data Bit, Stop Bit, and Parity settings.
• If any one of LAN1 through 4 has been selected as the port, select the Port Setup button and configure the network port setting.
• If using a USB-serial port, the Text-In feature may malfunction if the USB cable is removed while the system is in operation.
  • Title: Designate a name for the text-in device.
• Actions: Specify which actions to take when text-in is detected.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

Camera System

The event occurs when the fan has stopped in the fan mounted camera.

• No.: Specify which camerass to take Fan Error to.
- Actions: Specify which actions to take when a Video Loss event occurs.

• Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.
• Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.
• Notify: Configure to be notified of events by Mail, LAN1 through 5, SNS, and/or Alert Window.
• PTZ: Moves the PTZ camera to a specific preset position when an event occurs.
• Event Monitoring: Selects the cameras to monitor when an event occurs.

• In order to use the Callback feature, the NVR must be registered on the remote program.
• In case of the camera that not supports camera

Part 2 - Configuration

Face Detection

When face detection event occurs in the selected camera, the area that the face is detected displays on the screen.

• No.: Specify which camerass to take Face Detection to.
- Sensitivity.: Set sensitivity settings between 1 (Low) and 5 (High).
• Max. Detect Count: Set the maximum detected number of face as 8 or 32.

When you set the Max. Detect Count as 32, the sensitivity feature will be disabled.

• Min. Face Size: Select 120 x 120, 150 x 150, 180 x 180, 210 x 210 or 240 x 240.
• Actions: Specify which actions to take when a Face Detection event occurs.

- Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

- Alarm-Out: Designate event-triggered alarm-out channels (each for the NVR and camera) and beeps.

after the initial motion was detected. Set the value between 1 sec and 5 secs or choose Never.

Network Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

General

- Remote Audio Channel: Transmits the selected channel's audio to the remote program. Select Select From Client to stream audio of the channel selected on the remote program.

Audio skipping and sync issues can occur under poor network conditions.

- Enable SSL for Transferring Data: Applies SSL (Secure Sockets Layer) protection on remote viewing and recording data transmissions.

Part 2 - Configuration

WebGuard on page 71.

- VNC: Use Virtual Network Computing (VNC) by clicking the Use VNC button to toggle between On and Off. You will be able to change the settings if Use VNC is enabled. VNC service allows you to access the NVR and control it remotely using a PC or mobile devices via Ethernet.

- Port: Configure the port number of the VNC server. - Password: Configure the Password to connect to the NVR from a remote locale.

Up to three users at a time can access a NVRI remotely via VNC service.

- Network Bandwidth limit: Configure the bandwidth to limit.

If you configured the Network Bandwidth limit, the live video may not be displayed smoothly in a remote program.

Enter or Return	Press the Enter or Return key to select the highlighted item or complete an entry that you have made during system setup. This is the same as pressing the Play/Pause button on the front panel.
d or PaceUP/PageDown	Press the d or PageUp or PageDown key to toggle between different display formats. This is the same as pressing the DISPLAY button on the front panel.
c or Home	Press the c or Home key to copy video clips. This is the same as pressing the CLIP-COPY button on the front panel.
F5	Press the F5 key to refresh the current VNC screen.

Key Function
← or h	Press the ← or h key to move to the left in the menu. This is the same as pressing the Left arrow button on the front panel.
→ or l	Press the → or i key to move to the right in the menu. This is the same as pressing the Right arrow buttons on the front panel.
↑ or k	Press the ↑ or k key to move up in the menu. This is the same as pressing the Up arrow button on the front panel.
↓ or j	Press the ↓ or j key to move down in the menu. This is the same as pressing the Down arrow button on the front

Part 2 - Configuration

WAN

Designate the IP address type as Manual or DHCP.

Manual

Set Type to Manual.

Manual lets you configure related settings manually. Configure IP Address, Gateway, and Subnet Mask settings manually using the remote control's arrow buttons or the virtual keyboard.

• DNS Server: Enter the DNS server's IP address. The IP address can also be entered using the virtual keyboard.
• Remote Port: The port used by the remote program to connect to the NVR. Choose a value between 1024 and 65535. The port number can also be entered using the virtual keyboard.
• Remote Callback: Set the port number using for remote callback. The port number can also be entered using the virtual keyboard.

• Ping Test: Select to test the current WAN settings you made.

7 Enter the IP address of the NVR.

2 Adjust the frequency of the ping test.

3 Select Run to do the test. The test result is displayed.

4 Select Close to exit.

- If using a firewall, select Change Port to change the port number to one that is permitted by the firewall.

- Changing the port temporarily severs the NVR's remote connection.

Remote point IP and port settings on the remote program must also be changed in order for it to connect to the NVR.

To use the UPnP (Universal Plug and Play) feature, select Use UPnP. If using an IP router (or NAT), UPnP service allows the device to automatically forward the port to the NVR

Part 2 - Configuration

DHCP

Select DHCP and then Save to retrieve IP address and other network settings automatically from the DHCP server. Once the network settings have been retrieved, the NVR's current IP address is displayed in the IP Address field.

• It may not be possible to retrieve the IP address if there is no DHCP server. If this is the case, contact your network administrator.
• With DHCP, the NVR's IP address might change with each startup.

There is a limit to the number of users allowed to connect remotely at the same time. Contact the service center for more information.

FEN

If using a dynamic IP address, FEN service makes it easy to connect to the NVR from a remote program without having to configure dynamic IP or router settings.

- You will not be able to save FEN settings unless you click on the Check button next to the NVR Name field and check the entered name's availability.

• You will be prompted with an error message if you do not enter NVR name or enter a name already registered to the FEN Server.
• If the device name contains the #, \ and/or % symbol, it might not be able to connect to the NVR from the WebGuard program.

- FEN Server: Enter the FEN server's IP address or domain name.

If you have configured the DNS Server setting under Network - WAN, you can enter the FEN server's domain name instead of its IP address in the FEN Server field.

• Port: Specify the FEN server's port number.

If using an IP router (or NAT), port configuration and other network functions will depend on the usage method of the IP router (or NAT).

- Status: Used to check the status of the device being registered to the FEN server.

Select Save after making changes to register the NVR's name to the FEN server.

If FEN has been configured correctly, the FEN server's help desk information will be displayed in the Help Desk field the next time you access the FEN Setup screen.

Part 2 - Configuration

RTSP

RTSP service allows you to monitor real-time using the Real-Time Streaming Protocol.

• RTSP Port: Set the port number of the RTSP server obtained from your system administrator.
• RTP Port: Set the start/end port number of the RTP server obtained from your system administrator.

- You can access a remote NVR and monitor live video images using media players, such as VLC Player, supporting RTSP service. Start the media player on your local PC and enter "rtsp://ID?Password@IP address:RTSP port number/trackID=channel number &streamID=Stream number" (e.g.: rtsp://admin:10.0.152.35:554/trackID=1&streamID=2)

• Video display on certain media players may not be smooth depending on the network status.
- RTSP service might not be supported, depending on the type of media player.

Device Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

Alarm-Out

Select the + icon at the bottom left corner of the screen to add a schedule.

You can apply different schedules for different Days of the week.

Select ✗ icon to delete the schedule.
- Dwell Time: Select a value between 5 secs and 15 mins as the alarm-out duration.

• Title: Designate a name for the alarm-out.
• Range: Change the schedule time frame.
• Mode: Select Event, On, or Off.

Event

Generates an alarm-out when an event

On Alarm-out is always on.

Off Alarm-out is always off

Part 2 - Configuration

Remote Control

• Port: Select None or RS232 nd then click the Setup button and then select the correct Baud Rate, Parity. Data Bits and Stop Bits for the device you are connecting to the NVR. You can select the device from the Remote Control Product list. If the RS232 port is in use for PTZ control, networking or text input, the remote keyboard cannot be configured. In this case, the warning message window will appear when other devices use the same port such as PTZ control, networking or text input. The message says that you cannot use other device because the ports are overlapped.

Display Setup

Refer to the Menu Use on page 27 for basic information on using the Setup menus.

OSD

Show OSD (On Screen Display) information on the bottom of the screen.

Status

• Date and Time: Displays the date and time.
- Remote Control: Displays remote control receptivity.
- Free Space: Displays whether or not the NVR is in the recycle mode, and displays the available storage space when not in the recycle mode.
- User Name: Displays the current user logged in.
• Background Panel: Displays background panel at the bottom of the screen in black.

Part 2 - Configuration

the text-in string. Text-in strings are shown on the single screen only.

• Resolution (Search): Displays the recording resolution in Plackback mode.
  • Zoom: Displays a zoomed in state.
  • Network: Displays the icon when the unit is connected to a network via Ethernet.

• Freeze & Sequence: Displays freeze and sequence icons.
  • Screen Group: Displays the current screen's group.

• Resolution: Select 1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 1200.

• Event Monitoring On: With Event Monitoring enabled, the camera screen linking event monitoring is shown. For more information on Event Monitoring, refer to the Event Monitoring on page 24.
• Event Alert: With Event Alert selected, the red line appears on the top of the camera screen linking event monitoring when an event occurs.

- Supported resolutions may be restricted depending on the monitor.

• We recommend that you use 1920 x 1080 resolution.

Main Monitor

Configure monitor-related settings.

• Mode: Select Full Sequence.
- Interval: Select between 3 secs and 2 mins. For more information on Sequence, refer to the 6 Sequence on page 19.
- Use BRP(Boost Remote Performance) mode: With BRP mode on, the camera full screen does not display in live mode and the nnetwork bandwidth can limit to 100Mbps.

Part 2 - Configuration

Notification Setup

Schedule

Select the + icon at the lower left corner of the screen to add a notification schedule.

• Day: Add different schedules for different days of the week.
- Range: Change the event notification time frame.
- Notify: Select which notifications to generate when an event occurs. Select Mail, LAN 1 through 5, SNS, and/or Summary.

• In order to use the Notification (Callback) feature, the NVR must be registered on the remote program.
• Select the icon to delete the existing schedule.

- Summary Email Interval: Transmit event summary emails to a remote destination at specified intervals.

Callback

Configure Callback settings.

Enter the IP address of the receiving server and set

Retry to between 1 and 10 in case of connection failure.

Part 2 - Configuration

Mail

Configure Mail settings.

Select the + icon at the bottom left corner of the screen to add a mail account.

Select Recipient and then enter the mail address and server information.

The recipient's mail address must be in the correct email format and contain the @ symbol.
Select the ☐ on to attach event recordings to outgoing mails.
Select the ✗ icon to remove the account.
Select MP4 Clip to attach event recordings to outgoing mails and set the time to record MP4 video clip.

The event recordings generated by a camera can be attached only. Select the MP4 Clip option at the bottom to attach .mp4 video clips.

SMTP Setup

Select SMTP Setup at the bottom right corner of the screen to configure an SMTP server.

1 Select the SMTP server Type.

2 Enter the SMTP Server's IP address or domain name and then configure the Port and Sender settings.

Default SMTP server port number is 25. Select Test to send out a test mail using the current settings. Select Use SSL/TLS to use an SMTP server that requires SSL connections.

If you have configured the DNS Server setting under Network-WAN, you can enter the STMP server's domain name instead of its IP address in the SMTP Server field.
- Address entered under Sender must be in the correct email format and include the @ symbol.
If user authentication is required by the SMTP server, select Use and then enter the User and Password information.

Part 2 - Configuration

SNS

This option enables the NVR to send out SNS messages.

The SNS (Social Network Service) feature sends out event-related messages to designated Twitter accounts. Select the + icon at the bottom left corner of the screen to add an SNS account. Select the ✗ icon on the right side of the list to remove the SNS account.

Enter the User Name and Password information.

Messages may not be transmitted successfully due to limitations in Twitter's services.

Camera Setup

Refer to the Menu Use on page 27 for basic

information on using the Setup menus.

Registration

You can register the cameras at remote locales. When selecting a No. in the list, you can move the camera position using the mouse wheel. At this time, the remaining camera position is automatically set.

• Title: Edits the camera's name.

• MAC Address: Displays the camera's MAC address registered to the NVR.
• Address: Displays the camera's IP Address registered to the NVR.
  • Model: Indicates the camera's Model.
• Scan: Selects Scan to scan and register the device connected to the NVR.

This feature is supported only when connected to the NVR from a remote program.

Part 2 - Configuration

Device Scan

Scan the device under Registration - Scan.

- Protocol: Select the protocol used by the camera (or video encoder) you wish to search for.

• Even if the network device uses a protocol supported by the NVR, the device itself may not be visible for scanning and registration by the NVR. For more information about supported network devices and models, contact your retailer.
- The supported scan modes may vary depending on selected protocol.

• Mode: Select the scan mode.

• Auto Scan(LAN): Lists cameras in a LAN environment. If Auto Scan (LAN) fails to recognize a camera, try using IP Address Scan Instead.
• IP Address: Enter the IP address of a camera. The NVR scans for the camera matching the specified address. If you enter IP address's range, the NVR scans for cameras falling under the specified address's range. By specifying an IP address, you can also specify which port to use with the Remote Admin feature. It is recommended that the camera not be networked via DHCP (Dynamic Host Configuration Protocol). If the camera is networked via DHCP, connection to the camera may not be

the Add Camera button to register the camera.

• MAC Address: Displays the scanned camera's MAC address.
• Address: Displays the scanned camera's IP Address.
  • Model: Indicates the camera's Model.
• Protocol: indicates the scanned camera's protocol.
• Name: Displays the scanned camera's IP Name.
• Status: "Registered" indicates the camera is registered to the NVR and "Not registered" indicates the camera is not registered to the NVR.

Login

When the password is set or you want to register the third party cameras, registering the device requires an authorized user login.

1 Selecting the desired device from the list and clicking the Add Camera button, then the login window will appear.
2 Select a user, enter the password and then select OK.

Part 2 - Configuration

General

Enable/disable the covert view and rename cameras.

• Title: Edit the camera's name.

- Use: Set the camera as Normal, Covert 1, or Covert 2. Live images and video recordings from cameras that have been set as Covert 1 or Covert 2 will not be available to users who do not have covert camera access. Setting a camera as Covert 1 hides its images but does display OSD Information about the camera. Setting a camera as Covert 2 hides its images as well as ODS information about the camera as if it has been deactivated completely.

Advanced Setup

Configure security and other advanced camera settings.

- Video: Adjust the camera image sensor settings such as white balance and exposure. Configuration options may differ depending on the camera model. - Privacy Masking: Enable/disable and configure privacy masking for the camera.

- SSL: Set the camera's security level as Unavailable, Standard, High, or Very High. Standard, High and Very High settings apply SSL (Secure Sockets Layer) protection to the camera.

- Reset: Resets the port or cameras.

- PoE Reset: Control the PoE Switch's port. This option is available when connecting to Video In/PoE port or using a DirectIP™ PoE Switch (optional). Select PoE Reset to reboot in the camera's power settings to restart the camera. It is not supported by video encoders.

- Soft Reset: Reboots the camera.

- Factory Reset: Resets the NVR to all its initial factory settings. It is supported by DirectIP™ cameras only.

- Mode: Select a resolution mode. It is supported by video encoder only

Part 2 - Configuration
PTZ Settings

- PTZ Product: Choose to select the model of installed PTZ device.

- ID: Choose to assign an ID to each PTZ device.

- Choose to set up Baud Rate, Data Bit, Stop Bit and Parity of the connected device.

Types of configuration options shown vary depending on the PTZ functions supported by the camera.

Numbers shown below Preset, Scan, Pattern, and Tour indicate the numbers of configured functions.

① Preset

- Use the buttons below to choose a preset position.

• Directional Buttons (✿✿✿✿✿✿✿): Used to tilt and pan the camera.
• Zoom (⊕) : Zoom in and out.
• Focus (○): Adjust camera focus to far or near.
• Speed: Specify the camera's panning and tilting speed.

Part 2 - Configuration

• Set: Choose a preset number and then enter a name. This saves the current preset under the specified preset number and name.
• Go to: Select a preset from the list and then click Go to to move the camera to the selected preset position.
  • Edit: Used to change the selected preset's name.
• Remove: Used to remove the selected preset.

② Scan

Used to set up a profile for moving the camera between two points. At least two presets must be available in order to use the scan feature.

- Set: Used to set up a scan profile.

Name: Enter a name for the scan profile.

- Start/Stop: Specify which presets to use as start and stop points.

- Dwell Time (sec.): Specify how long the camera will dwell at start and stop positions.

- Speed/Direction: Specify scanning speed and direction

③ Pattern

Used to set up a pattern profile for the camera to follow along.

- Start recording: Select a pattern number, enter a name for the pattern, and then click OK to save the pattern. Move the camera using directional, zoom, and focus buttons and then click Stop recording to save the pattern profile. You can record up to two minutes of movement.

- Directional Buttons (✿ 🙏 🐵 🐵 🐵 🐵): Used to tilt and pan the camera.

Zoom (+) : Zoom in and out.

Focus ☐ Adjust camera focus to far or near.

Speed: Specify the camera's panning and tilting speed.

• Test: Select a pattern profile and then click Test to test it.
• Edit: Used to edit the selected pattern profile.
• Remove: Used to remove the selected pattern profile.

④ Tour

Used to set up a tour profile of multiple functions in a designated sequence.

Part 2 - Configuration

• Name: Enter a name for the tour profile.
• Function: Indicates the order of the function in the tour sequence.
• Dwell Time (sec.): Specify how long to perform the selected function for.
• Speed: Specify the preset speed.
• Test: Select a tour profile and then click Test to test it.
  • Edit: Used to edit the selected tour profile.
• Remove: Used to remove the selected tour profile.
  √ Select Apply after setting up a preset, scan, pattern, or tour profile to see images from the concerned camera on the left side of the screen. Selecting Apply or OK displays a popup screen that indicates whether the profile has been set up successfully.
  ⑤ PTZ Reset: Reboots the camera's panning / tilting and zoom settings.
  ⑥ Home Position: Specify the camera's home position.
• Default: Uses the factory-default position as the camera's home position.
  ⑨ Auto Flip: Automatically flips the image when the camera tilts past 90° to prevent the objects from appearing upside down.
• Digital: Flips the image left to right or top to bottom.
• Mechanical: Automatically pans or tilts the camera.
  • Off: Disables Auto Flip.
  ⑩ Tilt-Range: Specify the camera's tilting range.
  ⑩ Restore: Specify whether to restore the camera to its last position or function. Enabling this option restores the camera to its last position or function after being restarted.

Privacy Masking Options

Select Name to rename the privacy masking area. Select the ✗ icon to delete the existing privacy masking area. Select Privacy Masking Setup to display additional privacy masking area options. You can drag on the area with the mouse to resize it or add up to 16 different areas.

Part 2 - Configuration

Image Sensor Options

• Product, Firmware Version: Displays the camera model name and firmware version.
  • Video Style: Select TV Color or PC Color
• Backlight Compensation: Enable/disable Backlight Compensation. If enabled, objects are exposed brighter in backlit situations.
• Auto Adjust: Selecting Auto allows the system to assess the lighting conditions and adjust the setting automatically. Selecting Manual allows the user to adjust the setting manually.
• Sharpness: Adjust the sharpness level. Adjust the contours to make the images look sharper. Increasing the value raises the sharpness level, but using too high a value can result in unwanted noise.
• Noise Filter: Select the noise filter level. Noise filter can reduce the noise in images taken under low-lighting conditions. Increasing the value reduces the noise, but using too high a value can result in blurry images.
  • 3DNR : Enable/disable 3DNR (3D Noise Removal). 3DNR reduces background noise in images taken

other times.

Schedule function may not be supported depending on the camera model.

- Refocus Mode: Readjust the focus of the camera when changing daytime to nighttime or nighttime to daytime.

- On/Off: Enable/disable Refocus Mode.

- DN Mode Shift: When image of the camera is switched to daytime or nighttime, the focus of the camera will be adjusted.

– IR Adaptive Shift: Readjust the focus of the camera when IR is detected by the camera.

• White LED Mode: Clicking on/off enables or disables White LED lighting when motion is detected by the PIR sensor. Also clicking auto allows the system to enable/disable White LED mode automatically.
• Black & White Mode: Display the images in greyscale for greater clarity in low-lighting conditions.

- On/Off: Enable/disable Black & White Mode.

- Auto: Allow the system to enable/disable Black & White Mode automatically.

• Pivot: A Enable this option and choose the direction of the pivot. You can turn the image by 90 in the clockwise or counterclockwise direction. If vertical resolution is less than 320, this feature is not supported. This feature is particularly effective when monitoring hallways, passages, and other confined spaces.
• Defog: Disable or enable the Defog feature. When it is enabled, image with a fog is adjusted.
• IR Strength: Adjust the IR LED's brightness level. Select a brightness level manually between 0% (darkest) and 100% (brightest).
• Advanced AE Mode: Select desired setup mode between Normal and Number Identification.

Part 2 - Configuration

• Switching Level: Controls the changing time of daytime / nighttime mode, depending on the Switching Level between 1 to 10. The higher the value is, day / nighttime mode is changed under high lighting conditions. Also the lower the value is, day / nighttime mode is changed under low-lighting conditions.
• Mirror: Select Horizontal or Vertical to flip the image horizontally and/or vertically.

Select Apply after setting up a camera to see images from the concerned camera on the left side of the screen. Selecting Apply or OK displays a popup screen that indicates whether the camera has been set up successfully or not.

White Balance Options

• Preset: Use preconfigured white balance settings.
• Auto: Allow the system to adjust the white balance automatically. The system will assess the lighting conditions and adjust the white balance automatically.
• Incandescent - Fluorescent Cold: Select a lighting type to apply the appropriate white balance.

Exposure Options

• AE Target Gain: Specify exposure compensation's target gain. Exposure is compensated automatically based on the specified target gain. Higher the gain, brighter the images.
• Local Exposure: Activate Local Exposure. Use Local Exposure on images that appear too dark due to backlighting conditions and on images containing over-exposed sections. Greater the value, clearer the image. e.g.) Dark parking lot entrances and gas station entrances at night (Local Exposure compensates for the bright light coming from incoming vehicle headlights and makes it possible to see the license plates).
• Anti-Flicker: If the lights in the area where the camera is located use alternating current, specify the frequency of the lights to minimize flickering. Matching the frequencies can eliminate flickering completely. (NTSC: 60Hz, PAL: 50Hz).
• Slow Shutter: Activate Slow Shutter. The slow shutter mode functions only under low lighting conditions. When the slow shutter mode is enabled, images are displayed bright even under the low-lighting conditions. There may be a difference in the way it function is called the light-shutter mode

Part 2 - Configuration

• Focus Mode: Used to change the focus movement format as Auto/Manual/Semi-Automatic. It may not be supported depending on the device.
• WDR: Disables or enables the WDR (Wide Dynamic Range). When the very dark and very bright areas exist simultaneously on the screen, WDR allows you to recognize the both areas.
• IRIS: Select the lens IRIS type. If a manual IRIS lens is mounted on the camera, select Manual. If a DC-type auto IRIS lens is mounted, select DC IRIS. Also if a P-type auto IRIS lens is mounted, select P IRIS.

• Shutter Speed Control: Adjust Shutter Speed. This option is available only when Anti-Flicker and Slow Shutter are both set to Off.

• Auto: The system will assess the lighting conditions and adjust the shutter speed automatically.

• Manual: Use the slider to select the desired shutter speed. Select the most suitable minimum and maximum shutter speeds for the lighting conditions in the area where the camera is located. (1/30 to 1/8000)

Select Apply after setting up a camera to see images from the concerned camera on the left side of the screen. Selecting Apply or OK displays a popup screen that indicates whether the camera has been set up successfully or not.

View Options

Miscellaneous

- Image Stabilizer: Activate Image Stabilizer. The Image Stabilizer reduces blurring caused by camera shake that results from external conditions such as the wind.

Stream

Configure the camera's live and recording resolution, encode, picture quality, transfer speed, and ips speed settings.

- Camera Channels: It's possible to configure a unique video profile for each camera.

Part 2 - Configuration

- Video Profile: Select Live 1, Live 2, Remote, or Custom (available from Record Video Profile only). Live 1 and Live 2 allows the user to change Bitrate and Quality settings only and configures the remaining settings automatically.

• Encode: Supports H.264.
• Resolution: Select a resolution supported by the camera. Maximum available resolution is chosen automatically based on the selected video profile.
• Quality: Select Very High, High, Standard, Basic or Manual. You can assign different Quality settings to different cameras.
• Bitrate: Select CBR or VBR. Transmitted data size is fixed with CBR but varies depending on the amount of movements in the images with VBR.
• ips: Select a value between 1 and 30. Maximum ips is determined automatically based on the selected video profile.

Audio

Configure audio recording settings for all cameras simultaneously.

• Associated Audio In: Associates the selected audio channel with the camera. It is supported by video encoders only.
• Audio In: Select an audio input source (microphone or line-in) and then adjust the volume.
  • Audio Out: Adjust the volume.

Cameras do not feature built-in audio amplifier units and therefore require the user to purchase a speaker system with a built-in amplifier separately.

[Non-Text]

Upgrade

Select Firmware Upgrade to display the USB search window.

Select the corresponding upgrade package from the storage device connected to the NVR's USB port. After selecting an upgrade package, select Apply to upgrade the camera.

- If an upgrade attempt fails, an upgrade failure message will be displayed. Refer to Error Code Types on page 62 for more details.

Part 3 - Search

Time-Lapse Search

While in Live mode, select the Search Mode ▶ icon and select Time-Laspe Search or Event Log Search.

1 Select MENU button on the remote control while in Search mode to display a menu from which you can select Control Area.
2 Press MENU button once more to move the Control Area.
3 In 2 seconds after moving the Control Area, the Control Area becomes selected and the corresponding menu disappears.

Part 3 - Search

Search Menu

① Layout

Used to change the screen layout to single screen, corridor format or 2x2. In order to use the Corridor Format feature, Corridor Format (Display Setup - Main monitor - Use Corridor Format) must first be enabled.

② Display

- OSD On/Off: Enables/disables the OSD feature.

- Aspect Ratio: Select whether to enable the original aspect ratio of video transmitted from the camera.

③ Previous/Next Group

Loads the previous/next screen group.

④ Search Mode

Search by changing Time-Lapse Search and Event Log Search.

⑤ Live Mode

Activates Live mode.

⑥ Move

Search video recordings based on date and time. Specify the date and time and then select Go to jump to the corresponding video recording. Select a 📄 (bookmark) button on the right side to move to the saved bookmark position.

⑦ Select Camera

Select a camera channel and display it as a single screen.

⑧ Zoom

Zoom in.

⑨ Panic Recording

Use the Disney-Dressd Feature

Part 3 - Search

Time-Lapse Search Menu

Interior view of a modern living room with white sofas and large windows, no visible text or symbols on the main objects.

① Record Table

Display the current channel's recording information.

Recording date and time are shown on the top of

window and displays all or minimum channels.

Using the scroll, the information of other channels

which is not shown can be checked in the minimum size of Time-Lapse search window.

Select ⊕ (zoom-in) to compose recording data

in 1-minute segments and select ⊖ (zoom-out)

to compose recording data in 3-minute segments.

Selecting zoom-out displays more time in one screen than zoom-in screen.

If recording from points in time prior or after the time

frame displayed on the screen is available, scrolls appear on both ends of the date and time information line.

Small using the arrow buttons on the remote control or

Part 3 - Search

② Playback Controls

Play and scan through video recordings. Playback controls have the same functions as their remote control counterparts.

- Jog Shuttle

Adjust the playback method and speed. Jog shuttle's vertical indicator indicates the current playback direction and speed. Vertical indicator placement to the right of the center means the video is being played back in the forward direction. Placement to the left means the opposite. Farther away the vertical indicator from the center, faster the playback speed. Click and drag the vertical indicator to adjust the playback speed. Releasing the mouse button returns the vertical indicator to the center and stops video playback.

③ Bookmark

Select Add Current Position to add a bookmark to the current playback position. Select Title and enter the name of the registered bookmark.

④ Calendar Search

<	2013			11		7
Sun	Mon	Tue	Wed	Thu	Fri	Sat
					1	?
3	4	5	8	7	8	9
10	11	12	13	14	15	16
17	18	19	20	21	22	23
24	25	26	27	28	29	30

Use the calendar to search for video recordings by specific dates.

Dates containing video recordings are highlighted in light grey. Selecting a date containing video recording data loads the earliest recording from that date (paused state). Selected date is highlighted in black of grey background.

⑤ Clip-Copy

• A-B Clip-Copy

Designate a start point and an end point and copy the data in between. The Clip-Copy Setup window will appear. Select A and B points are automatically applied as From and To values.

- Clip-Copy

Open up the Clip-Copy setup window. Specify the From and To settings. Pressing the remote control's CLIP COPY button while in Live or Playback mode will also open the Clip-Copy setup window.

Part 3 - Search

Special characters such as v_1,,v_n^,?_i|,^_i>,and| are not permitted.

- Include Text-In Data: Enabling this option will save the video clip along with any available text-in data.

- Use Site Info: Adds Site info to the Clip Copy file's name.

Special characters contained in the location info (such as v_i,,^* , ?, !, ", <, >, and |) will be replaced with _ when the information is added to the file name.

Selecting Start displays a calculation on the size of the data to be copied. Check the calculation and then select Continue to proceed. While Clip Copy is in progress, you can select Cancel to cancel the process or select Close to allow the window to run in the background. Selecting Close does not cancel Clip Copy. Once the process is complete, you will be prompted with a confirmation window.

One-Touch Clip Copy configures the storage range automatically based on the storage drive's capacity. If there is insufficient space available on the selected storage device, you will only be able to Clip Copy an amount of data equaling the remaining space available on the storage device.

• The NVR displays the volume as 30GB regardless of the actual disk volume and the maximum size limit on Clip Copy files is 30GB.
• Saving a segment that is more than 2GB in size produces multiple files that are up to 2GB in size, each.
• Clip Copy files can be played back on Windows systems. For more information, refer to the iRAS operation manual.
• For USB flash memory devices, the NVR supports the FAT32 file format only.

⑥ Motion Search

(This function supports only in single screen.) Motion Search cannot be performed while using a split screen layout. Select Single Screen mode.

• Select First under From and Last under To to search the recording from start to finish. Alternatively, you can uncheck the First and Last options and specify the search time frame manually.
• Type: Motion Search looks for motion in the selected area by comparing individual frames against their preceding frames. This means slow and gradual movements, no matter how long they persist, will not be recognized. In contrast, Museum Search looks for changes in the specified area by using the From frame as a reference. Museum Search, therefore, recognizes even minute deviations from the original From frame.
• The Zone setting can be configured in the Identical manner as the Zone setting under System Setup - Motion Detection. For more information, refer to the Motion on page 37.

Museum Search may not function properly if the edge of the object is included in the Zone. For more accurate search results, set the inside of the object's edge as the detection zone.

- Sensitivity: Set to between 1 (Low) and 5 (High).

Part 3 - Search

⑦ Text-In Search

Perform Text-In Search.

Select a Transaction to display the video recording that corresponds to the selected time and date (paused state).

Text in information is superimposed on the screen at normal playback speed. The information is not shown under any other playback speed.

Select Option... to configure Text-In Search options.

- Select First under From and Last under To to search the recording from start to finish. Alternatively, you

⑧ Slow Play Option

Search the playback screen at low speeds. Select the desired playback speed (x1/2, x1/3, x1/4, x1/6, x1/8) and then select Play.

Context Menu

Select the Menu button or right-click on the Camera screen to access the context menu.

- Zoom: Zoom in.

• Audio: Enable/disable audio. Audio playback of the selected camera is available in full screen mode only.
• Show/Hide Text-In: Show/hide text-in information contained in the recording.
- Edit Group: Rearrange the split screen layout.

Print

Save the current image as a .pdf file.

While in Search Mode, select Pause to pause playback. Select Print from the Search menu to open up the Print Setup window.

Part 3 - Search

Event Log Search

Select Search Mode > Event Log Search to bring up the Event Log Search window.

• Select an event to display the recording made on the selected time and date (paused state). Select the Play button in the middle of the screen to start playing back the recording. Use the drop-down menu above to load recordings from other cameras.
• Selecting the specific event displays the screen to be stationary. Clicking the button on the camera right, you can copy the event.
• You can uncheck the First and Last options at the top of the Event Log Search window and specify the search time frame manually.

Select First for From and Last for To to select the entire recording from start to end.

- If designating From or To settings manually, you will be able to enable/disable the Check Time Overlap option.

If the system's clock has been changed and the designated From or To point exists at more than one

Camera Filter

• Alarm-In: Select which channels to search alarm-in events in.
• Motion: Select which channels to search motion detection events in.
  • Video Loss: Select which channels to search video loss events in.
  • Audio Detection: Select which channels to search audio detection events in.
• Trip Zone: Select which channels to search trip zone events in.
• Tampering: Select which channels to search tampering events in.
• Text-In: Select which channels to search text-in events in.
• Record Channel: Select which record channels to search events in.
• Recording Fail: Select which channels to search recording fail events in.
• Fan Error: Select which channels to search fan error events in.
• Face Detection: Select which channels to search face detection events in.

√ Selected record channels are searched for events with at least one linked recording. If no camera is selected, only the events with no linked recording camera are searched.

Part 3 - Search

Overlapped Recording Search

If the system's clock is changed to a point in the past, overlapping recordings may be produced. Overlapped recordings have to be searched in segments.

For example, making a recording from 1 o'clock to 5 o'clock, changing the system's clock at 5 o'clock to 3 o'clock, and then continuing to record until 6 o'clock produces two recordings that overlap between 3 o'clock and 5 o'clock. This results in two segments for the period between 3 and 5.

When searching overlapped video recordings, you can choose a specific point in time or a time frame. If you use the Go to the Date/Time option and select a point within the overlapped time period (4 o'clock for example), you must specify 4 o'clock in which of the two existing segments.

If you use the Event Log Search or Motion Detection option and select a time frame within the overlapped time period (4 o'clock to 5 o'clock, for example), you must choose between the two redundant sets of From and To values. Selectable search ranges are as follows:

• 4 o'clock in segment 1 to 5 o'clock in segment 1
• 4 o'clock in segment 1 to 5 o'clock in segment 2

1. algebraic theorem 2 as 5 algebraic theorem 3

Part 4 - WebGuard

WebGuard is a program that allows you to view and search video from remote locations over the Internet and can be accessed on a regular web browser such as Internet Explorer.

System requirements for running WebGuard are as follows:

OS:MicrosoftWindows XP (Service Pack 3), Microsoft Windows Vista (Service Pack 1), Microsoft Windows 7
(Home Premium, Professional, Ultimate) or Microsoft Windows' 8 (Pro, Enterprise)

• CPU: Intel Pentium IV 2.4GHz or above (Core 2 Duo E4600 recommended)

• RAM: 1GB or more

• VGA: 128MB or more (1280x1024, 24bpp or above)

• Internet Explorer: Ver. 7.0 or above (32-Bit)

- WebGuard only works with Microsoft Internet Explorer and will NOT work with other browsers.

- WebGuard does not work in Microsoft Windows ^4 8 metro UI.

1 Launch Internet Explorer and then enter the following information in the address bar.

• http://IP Address:Port Number (NVR system's IP address and WebGuard port number configured under Network > General (Default Value: 12088))
  – http://FEN server address/FEN Name (FEN Name: NVR name configured on the FEN server)
• http://www.dvronline.net (will be prompted to enter NVR's IP address or FEN name registered to the FEN server upon login)

Contact your network administrator for the IP address of the NVR you wish to connect to and the WebGuard port number.

2 When prompted with the WebGuard login window, select WEBWATCH or WEBSEARCH as the desired mode.

Enter the ID and password and click LOGIN to sign in using the selected mode.

Part 4 - WebGuard

• Launching a new version of WebGuard for the first time can cause Internet Explorer to load information from the previous version. In this case, navigate to Tools → Internet Options → General, delete temporary Internet files, and then restart WebGuard.
• On Microsoft Windows Vista or above, lowered image transmission rate can prevent the screen from being displayed or updated. In this case, we recommend that you disable the computer's auto tuning function. Open the command prompt as an administrator. (Start → Accessories → Command Prompt → Right-Click and then select Run as administrator) Type in "netsh int tcp set global autotuninglevel=disable" and then press Enter. Restart the computer to apply the change. To enable auto tuning again, launch the command prompt as an administrator and then type in "netsh int tcp set global autotuninglevel=normal". Restart the computer to apply the change.

Web Monitoring Mode

A remote web monitoring program that allows you to monitor images from remote locales in real-time.

Part 4 - WebGuard

1	Press to log out WebGuard.
2	Click to switch over to Web Search mode.
3	Place the mouse pointer on the WebWatch logo to check WebGuard's version.
4	Displays the current time and login information of WebGuard.
5	Select the desired mode. Changing the mode places the selected camera in the first cell of the layout that will be changed.
6	Select the camera you wish to monitor.
7	Used to adjust live video quality.
8	Used to control a PTZ camera at a remote location.One push button- Press this button to find the optimum focus automatically.- It is recommended to get an approximate focus using the manual focusing button before pressing the one push button for fast and efficient focusing.- This button is not supported in the Onvif protocol.Zoom Out / InIris Close / OpenFocus Near / FarPTZ Preset / Preset ViewMay not be supported depending on the model.
9	Controls remote alarm out devices.
10	Click to configure rendering mode and OSD settings. Select rendering mode to adjust the video output rate or select which OSD elements to display on the screen from the OSD list.
11	Click to save the current video screen as an image file.
12	Click to configure event, camera, stream settings, etc of NVR at remote locales.
13	Event status window at the bottom of the screen displays a list of events detected at remote locales.

Part 4 - WebGuard

	Select a camera from the screen and right-click to bring up the pop-up menu. • Change Camera Title: Used to change the camera's name. ✓ Renaming the camera in Web Live mode does not affect the camera's name on the remote system. If no name is entered for the camera, the name used at the remote locale is shown on the screen.
	Enable Audio: Enables audio transmission with remote locales. Select to display ▼◀ buttons.
		Enables transmission of audio to the remote locale via microphone.
		Enables playback of audio from the remote locale on speakers.
	/	Enables two-way audio communication with the remote locale.
		Disables audio transmission.
		If the remote locale connected to supports audio transmission, ▼con appears on the corresponding camera screen.
	Aspect Ratio: Changes the aspect ratio of the video displayed on the screen. - Fit to Screen: Fit the video to the size of the camera screen. - Fit to Aspect Ratio: Resizes camera screen to original aspect ratio of the video. - Half Size (x0.5) - 4 Times Bigger (x4): Displays the camera videos in the selected size based on the original size of the video. For example, original size (x1) displays the video in its original size. Half size (x0.5) through 4 times larger (x4) options are only available if there is enough space on the camera screen to accommodate the selected size. Anti-Aliasing Screen: Removes stair step effect (blocks) that is caused when zooming a video to improve overall quality of video output.

Part 4 - WebGuard

Web Search Mode

A remote web search program that allows you to search for recordings from remote locales in real-time.

While in Web Search mode, connection to remote locales will terminate automatically after 30 minutes of inactivity.

D

...

The image is too blurry to recognize any text content.

-12

-

-

L7

[Unreadable]

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

D

...

The image is too blurry to recognize any text content.

-12

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

Part 4 - WebGuard

10	Use the playback controls to play back video.
	1	Go to First	2	Fast Forward
	3	Play by Frame (backwards)	4	Play by Frame (forwards)
	5	Rewind	6	Go to Last
	7	Play/Pause
8	Select the desired mode.
10	Use the calendar to search for video recordings by specific dates.Dates containing video recordings are highlighted in black. Selecting a date containing video recording data loads the earliest recording from that date(paused state). Selected date is highlighted in red.
11	Click 9 to designate recent recordings you wish to search and then jump to a specific point in the recording.
12	Select 10 to enable time lapse search mode and search/play back video recordings in chronological order.In Time Lapse Search mode, search is conducted by selecting days on the calendar. The time table at the bottom displays recording data information for the selected date. Select a point in time to display video from that moment. If multiple recordings are available for the selected point in time, you can select the desired segment.
13	Select 11 to enable event search mode and search for events matching user-designated parameters.
14	Click 12 to configure rendering mode and OSD settings. Select rendering mode to adjust the video output rate or select which OSD elements to display on the screen from the OSD list.
15	Click 13 to save the video recording as an executable file.
16	Click 14 to save the current video screen as an image file.
17	Click 15 to print the current video screen using a printer connected to the computer.
18	Click 16 to reload recent video recordings from remote locales.
19	Indicates the selected camera's recording data on a time bar. If the camera's system clock has been changed to a point in the past and more than one recording exists at the same point in time as a result,you will be able to choose which segment to search from the segment menu on the upper right portion of the time table.

Part 5 - Appendix

Index	R
	Recording	25
A	S
Alarm-In 40	Schedule	35
Alarm-Out 48	Search 63
Audio Recording 25	Storage	32
C	T
Camera Registration 12	Text-In 42
	Text-In Search	68
E	Timelapse Mode	63
Event Monitoring 24	Time-Lapse Search	65
F	V
FEN 47	Video-Analytics	37
L	W
Live Mode 22	WAN	46
Login 17	WebGuard	71
	Wizard	9
M
Motion Search 67
