BQ-2819 - Barbecue TRISTAR - Free user manual and instructions

USER MANUAL BQ-2819 TRISTAR

Black tristar power tool holder with coiled cable, no visible text or symbols on the device itself

EN Instruction manual
NL Gebruiksaanwijzing
FR Mode d'emploi
DE Bedienungsanleitung
ES Manual de usuario
PT Manual de utilizador
PL Instrukcja obsługi
IT Manuale utente
SV Bruksanvisning

BQ-2819

*** TRISTAR

Dear customer,

Congratulations and thank you for purchasing this high quality product. Please read the instruction manual carefully so that you will be able to make the best possible use of the appliance. This manual includes all the necessary instructions and advice for using, cleaning and maintaining the appliance. If you follow these instructions you will be guaranteed of an excellent result, it saves you time and will avoid problems. We hope you will have a great deal of pleasure from using this appliance.

SAFETY INSTRUCTIONS

• Please read the instruction manual carefully before using the device. Please keep these instructions, the guarantee certificate, the sales receipt and, if possible, the carton with the inner packaging.
• This appliance is not intended to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instructions concerning the use of the appliance by a person that is responsible for their safety.
• By ignoring the safety instructions the manufacturer can not be hold responsible for the damage.
  • To protect children against the dangers of an electrical appliance, please make sure that you never leave the appliance unattended. Therefore you have to select a storage place for the appliance where children are not able to grab it. Make sure that the cable is not hanging in a downward position.
• This appliance is only to be used for household purposes and only for the purpose it is made for.

• The appliance must be placed on a stable, level surface.

• Do not use when the appliance is fallen, if there are any signs of damage or when it leaks.

• Do not touch hot surfaces. Use handles or knobs.
• Never use the device unsupervised.
• All repairs should be made by a competent qualified electrician(*).
• Make sure that the appliance is stored in a dry environment.
• Check if the voltage of the appliance corresponds to the main voltage of your home. Rated voltage: AC220-240V 50Hz. The socket must be at least 16A or 10 A slow-protected.
• This appliance complies with all standards regarding electromagnetic fields (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientific evidence available today.
• The use of accessory that are not recommended by the manufacturer can cause injuries and will invalidate any warranty that you may have.
• Never move the appliance by pulling the cord and make sure the cord can not become entangled.
• Do not wind the cord around the appliance and do not bend it.
• Allow the appliance to cool down before you clean or store it.
• To protect yourself against an electric shock, do not immerse the cord, plug or appliance in the water or any other liquid.
• Do not use this appliance with a damaged cord or plug or when the appliance has malfunctions, or has been damaged in any manner. To avoid a hazard make sure that a damaged cord or plug will be replaced by an authorized technician(*). Do not repair this appliance yourself.
• Do not use this appliance near direct heat sources.
• Unplug the appliance from the socket when you are not using it.
• Note: To avoid danger by accidental resetting the thermal protection, this appliance may not be powered through an external switching device, such as a timer, or connected to a circuit that regularly will be switched on or off.

\*\*\* TRISTAR Instruction manual

• Make sure that the cord is not hanging over the edge of the table or counter, does not touch any hot surfaces or is coming directly into contact with the hot parts of the appliance. Do not place the appliance underneath or close to curtains, window coverings etc.
• Make sure the cord does not touch the hot parts of the appliance.
  • We advise to place a heat resistant coating between your table and the appliance (this way you don't get burns on your table or table cloth).
• Be careful with oil and fat preparations, because they might catch fire by overheating. Provide proper ventilation when using the appliance.
• Do not use this appliance in the bathroom or near a sink filled with water. If this appliance has fallen into the water do not under no circumstances directly grab this appliance, but first pull the plug from the socket.
  * Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

PARTS DESCRIPTION

1. Cord
2. Handle
3. Heating element
4. Holder

Diagram of a thermocouple device with labeled parts including a cable and heating element

BEFORE FIRST USE

• Take the appliance and the accessories out of the box. Remove the stickers, protective foil or plastic from the device.
- Before use, clean the appliance and all the spare parts with a damp cloth.

USE

1. Fill about half of the grill tray with charcoal.
2. Place the heating element on the fuel in such a way that the handle of the firelighter remains outside the grill tray.
3. Now fill the grill tray with the remaining charcoal. Handle and cord shouldn't come into contact with the fuel.
4. Check again if appliance and cord are in the right position.
5. Put the plug in an earthed power outlet.
6. After about 2 minutes the charcoal starts to smoke, after 4-5 minutes there arise some flames. After about 9 minutes the flames will disappear and charcoal begin to glow. After 8-12 minutes the coals are white, indicating that they have reached the right temperature.
7. Unplug the appliance, then remove it carefully from the grill tray. Grab the handle with one hand only and let the appliance cool down on its holder, which should stand on a sufficiently large and heat-resistant surface.

SHORT CORD INSTRUCTIONS

• A short power supply cord is provided to reduce the risk resulting from becoming entangled in, or tripping over a longer cord. Extension cords may be used if care is exercised in their use.
• The electrical rating of the extension cord should be at least that of the appliance.
• The longer cord should be placed in such a way that children can not pull it or trip over it..

CLEANING

• Before cleaning the grill, please pull out the cord first and allow the appliance to cool down completely, then dissemble all the loose parts and clean one by one.
• Clean the outside of the appliance with a soft and slightly moistened cloth.
• Do not use any toxic or abrasive cleaning supplies like petrol, scrubbing powder or solvent. Regular kitchen cleaner or dishwashing liquid with water is enough.
• Do never immerse the appliance in water or any other liquid. Never use the dishwasher for cleaning the appliance.

GUARANTEE

• Tristar is not liable for damages occurred through:
  o In case the appliance has fallen.
  o In case the appliance has been technically changed by the owner or another third party.
  o In case of improper use of the appliance.
  o In case of normal wear of the appliance.
• By executing repairs the original warranty period of 2 years will not

be extended, nor the right to a complied new warranty. This warranty is only legal on European soil. This warranty does not overrule the European directive 1944/44CE.

• Always keep your receipt, without this receipt you can not claim any form of warranty whatsoever.
• Damage caused by not following the instruction manual will lead to a void of warranty, if this results in consequential damages Tristar will not be liable.
• Tristar will not be liable for material damage or personal injury caused by improper use or if the safety instructions are not properly executed.
• Cleaning, as mentioned in this manual, is the only necessary maintenance for this appliance.
• When the appliance should be repaired, make sure that this will be performed by an authorized company.
• This appliance may not be amended or changed.
• If problems arise during the 2 years from the date of purchase, which are covered by the factory warranty, you can go back to the point of purchase to replace it for a new one.
• For questions or compliances please contact your retailer "point of purchase."
• This appliance is covered with a 24 month guarantee starting on the date of purchase (receipt).
• Only material or manufacturing defects are included in this warranty.
• If you wish to make a claim please return the entire machine in the original packaging to your dealer together with the receipt.
• Damage to accessories does not mean automatic free replacement of the whole appliance. In such cases please contact our hotline. Broken glass or breakage of plastic parts are always subject to a charge.
• Defects to consumables or parts subject to wearing, as well as cleaning, maintenance or the replacement of these parts are not covered by the guarantee and hence are to be paid!

TRISTAR Instruction manual

• The guarantee lapses in case of unauthorized tampering.
  • After the expiry of the guarantee repairs can be carried by the competent dealer or repair service against the payment of the ensuing costs.

GUIDELINES FOR PROTECTION OF THE ENVIRONMENT

This appliance should not be put into the domestic garbage at the end of its durability, but must be offered at a central

point for the recycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection.

Packaging

The packaging is 100% recyclable, return the packaging separated.

Product

This device is equipped with a mark according to the European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring that this product will be correctly processed into waste, it will help prevent possible negative consequences for the environment and human health.

EC declaration of conformity

This device is designed, manufactured and marketed in accordance with the safety objectives of the Low Voltage Directive "No 2006/95/EC", the protection requirements of the EMC Directive 2004/108/EC "Electromagnetic Compatibility" and the requirement of Directive 93/68/EEC.

Geachte klant,

Four-panel black-and-white photo sequence showing food preparation: boiling pan, stir-frying dish, and stir-frying pan (no text or symbols)

OPMERKING

Labeled diagram of a heating element with numbered parts: coil, fuse, and plug

AVANT LA PREMIÈRE UTILISATION

Diagram of a device with labeled components, showing four numbered parts connected to a cable or connector.

VOR DEM ERSTGEBRAUCH

Diagram of a thermal relay with labeled components including a battery and cable

PRZED PIERWSZYM UŻYCIEM

Diagram of a thermal relay or sensor device with labeled components 1 to 4

PRIMA DEL PRIMO UTILIZZO
