USER MANUAL C-123 Sven
Please read this User's Manual before using the unit and retain this User's Manual in a safe place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The information of this Manual is given on “as is” terms. The author and the publisher do not bear any liability to a person or an organization for loss or damage which has arisen from the information contained in this Manual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device for damage; if the product was damaged during transportation, address the firm which carried out the delivery; if the product functions incorrectly, address the dealer at once.
USAGE
SVEN C-123 USB car charger with two outputs it designed to power supply and charge batteries of portable devices (mobile telephones, smartphones, GPS navigators, MP3 players, pocket PCs, tablet PCs and other digital devices) through the cigarette lighter jack of the car on-board power system.
PACKAGE CONTENTS
- USB car charger – 1 pc
- User's Manual – 1 pc
- Warranty card – 1 pc
FEATURES
- Simultaneous safe power supply and charge of two USB devices
• Overload protection
• 12-24 V input voltage range - Power indicator
CONNECTION
- Insert the charger into the cigarette lighter jack and connect load to it. The lighting LED indicator means that the charger is connected to the car on-board power system and its normal service.
Attention. Do not use the charger at the instant of engine starting.
TECHNICAL SPECIFICATIONS
| Parameter, measurement unit | Value |
| Connector type | 2 × USB |
| Rated input voltage, V | 12 -24 |
| Output voltage, V | 5 ± 5 % |
| Maximum output current, mA | 2 × 1000 |
| Output power, W | 10 |
Notes:
- Technical specifications given in this table are supplemental information and cannot give occasion to claims.
- Technical specifications and package contents are subject to change without notice due to the improvement of SVEN production.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, N° 02-02, Singapore, 427447. Produced under the control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN Scandinavia Ltd. Finland.
