HL-6182DWT - Printer BROTHER - Free user manual and instructions

USER MANUAL HL-6182DWT BROTHER

MODELS COVERED BY THIS MANUAL

HL-1***	1050/1070/1110/1111/1112/1118/1200/1201/1202/1208/1210W/1210WE/1210WR/1211W/1212W/1212WR/1218W/1250/1270N/1450/1470N/1650/1660e/1670N/1850/1870N/	HL-B***	B2050DN/B2080DW
HL-2***	2060/2070N/2130/2140/2150N/2170W/2240D/2250DN/2260/2260D/2270DW/2400C/2400Ce/2460/2560DN/2569DW/2590DN/2595DW/2600CN/2700CN	HL-L2***	L2300/L2300D/L2305W/L2320D/L2321D/L2340DW/L2360DN/L2360DW/L2361DN/L2365DW/L2366DW/L2370DN/L2370DW/L2371DN/L2372DN/L2375DW/L2376DW/L2385DW/L2386DW
HL-3***	3040CN/3045CN/3070CW/3075CW/3140CW/3150CDN/3150CDW/3160CDW/3170CDW/3190CDW/3260N/3400CN/3450CN	HL-L3***	L3210CW/L3230CDN/L3230CDW/L3270CDW
HL-4***	4040CN/4050CDN/4070CDW/4140CN/4150CDN/4570CDW	HL-L5***	L5000D/L5100DN(T)/L5102DW/L5200DW(T)/L5202DW
HL-5***	5040/5050/5070N/5140/5150D/5170DN/5240/5250DN/5270DN/5280DW/5340D/5350DN/5370DW/5380DN/5440D/5450DN/5470DW/5580D/5585D/5590DN/5595DN	HL-L6***	L6200DW(T)/L6202DW/L6250DN/L6250DW/L6300DW(T)/L6400DW(T)/L6402DW
HL-6***	6050/6050D/6050DN/6180DW	HL-L8***	L8250CDN/L8260CDN/L8260CDW/L8350CDW(T)/L8360CDW(T)
HL-7***	7050	HL-L9***	L9200CDW(T)/L9300CDW(T)/L9310CDW
HL-8***	8050N	HL-P***	P2500
		HL-S***	S7000DN

First version	August, 1999 Created for HL-1050/1070/1250/1270N/1450/1470N/P2500/1660e/2060/2400C
Ver. A March	2000 Revised for Addition of HL-2400Ce/3400CN
Ver. B March	2001 Revised for Addition of HL-1650/1670N/3260N/2460
Ver. C October	2001 Revised for Addition of HL-1450/1470N
Ver. D June	2003 Revised for Addition of HL-7050/1850/1870N/5050/5070N
Ver. E September	2003 Revised for Addition of HL-2600CN/3450CN.
Ver. F October	2003 Revised for Addition of HL-5040.
Ver. G January	2004 Correct Paper Source command of PCL5.
Ver. H February	2004 Correct Epson & IBM emulation, PJL and Barcode.
Ver. I June	2004 Revised for Addition of HL-6050/6050D/6050DN/8050N/2700CN.
Ver. J	July, 2004	Revised for Addition of HL-5140/5150D/5150DN and addition of a section of Carbon Copy and addition of a table of Tray Selection of TRAYCOMMAND Special.
Ver. K December	2004 Revised for Addition of HL-2070N.
Ver. L	March, 2006 Revised for Addition of HL-5240/5250DN/5270DN/5280DW.
Ver. M	June, 2007 Revised for Addition of HL-4040CN/4050CDN/4070CDW.
Ver. N April	2009 Revised for Addition of HL-2140/2150N/2170W.
Ver. O April	2009 Revised for Addition of HL-5340D/5350DN/5370DW/5380DN.
Ver. P	June, 2009 Revised for Addition of HL-3040CN/3070CW
Ver. Q June	2010 Revised for Addition of HL-2130/2240D/2250DN/2270DW/4140CN/4150CDN/4570CDW
Ver. R November	2011 Revised for Addition of HL-3045CN/3075CW/5440D/5450DN/5470DW/6180DW
Ver. S	March, 2012 Revised for Addition of HL-S7000DN
Ver. T October	2012 Revised for Addition of HL-3150CDW/HL-3150CDN/HL-3170CDW
Ver. U March	2013 Revised for Addition of HL-1110/1111/1112/1118
Ver. V	November, 2013 Revised for Addition of HL-L8250CDN/L8350CDW(T)/L9200CDW(T)
Ver.W March	2014 Revised for Addition of HL-L2300/L2300D/L2320D/L2321D/2260/2260D/L2305W/L2340DW/L2360DN/L2361DN/2560DN/L2360DW/L2365DW/L2366DW/2569DW
Ver.X	June, 2014	Revised for Addition of HL-HL-1212W/1210W/1210WR/1212WR/1210WE/1211W/1218W/1200/1201/1202/1208
Ver.Y	November, 2014 Revised for Addition of HL-L9300CDW(T)
Ver.Z	October, 2015	Revised for Addition of HL-L5000D/5580D/5585D/5595DN/L5102DW/L5100DN(T)/5590DN/L5200DW(T)/L5202DW/L6200DW(T)/L6202DW/L6250DN/L6250DW/L6300DW(T)/L6400DW(T)/L6402DW
Ver.AA	January, 2017	Revised for Addition of HL-L8260CDN/L8260CDW/L8360CDW(T)/L9310CDW
Ver.AB	July, 2017	Revised for Addition of HL-L2370DN/L2371DN/L2372DN/2590DN/B2050DN/L2370DW/L2375DW/L2376DW/B2080DW/L2385DW/L2386DW/2595DW
Ver.AC	March, 2018	Revised for Addition of HL-L3270CDW/L3230CDW/L3230CDN/L3210CW/3190CDW/3160CDW
Ver.AD Dec	mber, 2019	Revised for Addition about PJL for SF-4000(Finisher).

© Copyright Brother Industries, Ltd. 2019

ALL RIGHTS RESERVED

Trademark acknowledgments

Brother is a registered trademark of Brother Industries Ltd.

PostScript is a registered trademark of Adobe Incorporated.

Epson is a registered trademark and FX-850 a trademark of Seiko Epson Corporation.

Hewlett Packard, HP, LaserJet and PCL are registered trademarks and LaserJet, HP-GL, and HP-GL/2 are trademarks of Hewlett Packard Company.

IBM is a registered trademark and Proprinter XL is a trademark of International Business Machines Corporation.

Microsoft, MS-DOS and Windows are registered trademarks.

Intellifont is a registered trademark of Agfa Corporation.

TrueType is a trademark of Apple Computer, Inc.

All other brand and product names mentioned in this manual are registered trademarks or trademarks of respective companies.

Compilation and Publication

Under the supervision of Brother Industries Ltd., this manual has been compiled and published, covering the latest product's descriptions and specifications.

The contents of this manual and the specifications of this product are subjected to change without notice.

Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.

TABLE OF CONTENTS

GLOSSARY

CHAPTER 1 INTRODUCTION

1. ABOUT THE MANUAL 3
2. AREAS OF USE 4

CHAPTER 2 PCL PRINTER CONTROL LANGUAGE

1. COMMAND LIST 7
2. INTRODUCTION 10
3. CONTROLLING THE PRINTER----11
4. JOB CONTROL 15
5. USING FONTS----47
6. USING GRAPHICS 81
7. MACROS 102
8. STATUS READBACK 108
9. INDEX 116

CHAPTER 3 PCL5C

1. INTRODUCTION 3
2. COLOR MODES 4
3. COLOR PALLETS----10
4. COLOR GRAPHICS 12
5. ENHANCE OUTPUT 14
6. HP-GL/2----16
7. INDEX 18

CHAPTER 4 HP-GL/2 GRAPHICS LANGUAGE

1. COMMOAND LIST 4
2. INTRODUCTION 6
3. TERMINOLOGY 7
4. COMMAND SYNTAX----9
5. THE HP-GL GRAPHICS WINDOW----10
6. PREPARING TO PRINT GRAPHIC IMAGES----11
7. COMMANDS----12
8. INDEX 52

CHAPTER 5 PJL PRINTER JOB LANGUAGE

1. INTRODUCTION 4
2. HOW TO USE PJL 8
3. COMMAND GROUP----9
4. KERNEL COMMANDS----10
5. JOB SEPARATION COMMANDS----13
6. ENVIRONMENT COMMANDS----15
7. STATUS READBACK COMMANDS----61
8. DEVICE ATTENDANCE COMMANDS ----78
9. INDEX 81

CHAPTER 6 EPSON FX-850

1. COMMAND LIST 3
2. INTRODUCTION 5
3. EMULATION DETAILS 6
4. TERMINOLOGY 7
5. CONTROLLING THE PRINTER 8
6. COMMANDS----9
7. INDEX 28

CHAPTER 7 IBM PROPRINTER XL

1. COMMAND LIST 3
2. INTRODUCTION 5
3. EMULATION DETAILS 6
4. NOTATION USED IN THIS EMULATION DESCRIPTION ---- 7
5. COMMANDS----8
6. INDEX 21

CHAPTER 8 BAR CODE CONTROL

1. INTRODUCTION 3
2. PRINT BAR CODES OR EXPANDED CHARACTERS----4
3. DEFINITION OF PARAMETERS 5
4. EXAMPLE PROGRAM LISTINGS ----12

CHAPTER 9 HP-GL GRAPHICS LANGUAGE

1. COMMAND LIST 3
2. INTRODUCTION 4
3. COMMANDS----6
4. INDEX 27

CHAPTER 10 CARBON COPY FUNCTION

1. OUTLINE 3
2. SPECIFICATIONS 4
3. DETAILED INFORMATION----10

APPENDIX A COMPARISON LIST

APPENDIX B FLASH/PCMCIA CARD COMMANDS

APPENDIX C HBP MODE COMMANDS

APPENDIX D REFERENCE LIST OF MX-2000/4000/5000/7000

SERIES UNIQUE COMMANDS

APPENDIX E REFERENCE LIST OF FS-5050 UNIQUE COMMANDS
