Atmel | SMART General Purpose Cortex Microcontrollers

SAM D ARM® Cortex®-M0+ based MCUs 18

SAM S ARM Cortex-M7, M4 and M3 based MCUs 20

SAM N ARM Cortex-M4 and M3 based MCUs 24

Atmel | SMART Ultra Low Power Cortex Microcontrollers

SAM L ARM Cortex-M0+ based MCUs 26

SAM G ARM Cortex-M4F based MCUs 28

Atmel | SMART 5V Cortex Microcontrollers

SAM C ARM Cortex-M0+ based MCUs 30

Atmel | SMART Connectivity Cortex Microcontrollers

SAM E ARM Cortex-M7, M4F based MCUs 32

SAM3A ARM Cortex-M3 based MCUs 34

SAM3U ARM Cortex-M3 based MCUs 34

SAM3X ARM Cortex-M3 based MCUs 34

AVR UC3 32-bit Microcontrollers 36

Atmel | SMART and AVR Wireless Solutions 40

Atmel Tools 41

Atmel®

Broad Portfolio of Microcontrollers for an Array of Applications

With Atmel ^® microcontrollers, you have robust performance, low power, high-speed connectivity and innovative features at your disposal. Our AVR ^® 8- and 32-bit devices are based on the industry's most code-efficient architecture for C and assembly programming.

Our Atmel | SMART ARM ^® -based microcontrollers are flexible, highly integrated and designed to optimize system control, user interface management and ease of use. Both architectures share a single integrated development platform, Atmel Studio, which provides time-saving example projects with source code, access to debuggers/simulators, integration with

QTouch® tools for capacitive touch applications and access to the Atmel Gallery online apps store for embedded software and extensions. Also part of our microcontroller portfolio are 8-bit devices based on the 8051 instruction set. Whether you are working on legacy, existing or new designs, you'll get the latest features and functionality from more than 50 part numbers.

Atmel Flash Microcontrollers

Product Portfolio

Atmel®

Atmel AVR

tinyAVR 8-bit Microcontrollers

Product	Flash (KB)	EEPROM (Bytes)	SRAM (Bytes)	picoPower ^®	QTouch ^® channels	I/O Pins	UART/USART	SPI/TWI by USI	TWI (PC Compliant)	8-bit Timers	16-bit Timers
ATtiny4 0.5 -- 32 -- 1 4 -- -- -- -- 1
ATtiny5 0.5 -- 32 -- 1 4 -- -- -- -- 1
ATtiny9 1 -- 32 -- 1 4 -- -- -- -- 1
ATtiny10 1 -- 32 -- 1 4 -- -- -- -- 1
ATtiny13A 1 64 64 Yes	-- 6 -- -- -- 1 --
ATtiny20 2 --	128	Yes 5 12 -- 1 1 1 1
ATtiny24A	2	128	128	Yes	4	12	--	1	--	1	1
ATtiny25	2	128	128	--	4	6	--	1	--	2 (c)	--
ATtiny25V	2	128	128	--	4	6	--	1	--	2 (c)	--
ATtiny26 2 128	128	-- -- 16 -- 1 -- 2 --
ATtiny26L	2	128	128	--	--	16	--	1	--	2	--
ATtiny28L	2	--	(b)	--	--	11	--	--	--	1	--
ATtiny28V	2	--	(b)	--	--	11	--	--	--	1	--
ATtiny40 4 --	128	Yes 12 18 -- 1 1 1		1
ATtiny43U	4	64	256	--	8	16	--	1	--	2	--
ATtiny44A	4	256	256	Yes	6	12	--	1	--	1	1
ATtiny45	4	256	256	--	3	6	--	1	--	2 (c)	--
ATtiny45V	4	256	256	--	3	6	--	1	--	2 (c)	--
ATtiny48	4	64	256	Yes	12	28 (f)	--	--	1	1	1
ATtiny84A	8	512	512	Yes	6	12	--	1	--	1	1
ATtiny85	8	512	512	--	3	6	--	1	--	2 (c)	--
ATtiny85V	8	512	512	--	3	6	--	1	--	2 (c)	--
ATtiny87	8	512	512	--	--	16	1(LIN)	1	--	1	1
ATtiny88	8	64	512	Yes	12	28 (f)	--	--	1	1	1
ATtiny167	16	512	512	--	8	16	1(LIN)	1	--	1	1
ATtiny261A	2	128	128	Yes	4	16	--	1	--	1 (c)	1
ATtiny441	4	256	128	Yes	1	14	2	1	1	1	2
ATtiny461A	4	256	256	Yes	6	16	--	1	--	1 (c)	1
ATtiny828	8	256	512	Yes	-/-	28	1		1	1	1
ATtiny841	8	512	128	Yes	1	14	2	1	1	1	2
ATtiny861A	8	512	512	Yes	8	16	--	1	--	1 (c)	1
ATtiny1634	16	256	1K Yes 12 18 2 1 1 1								1
ATtiny2313A	2	128	128	Yes	--	18	1	1	--	1	1
ATtiny4313	4	256	256	Yes	--	18	1	1	--	1	1

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide-free and fully green.
(b) The AVR core has 32 internal registers that can be used as RAM storage.
(c) One high-speed 8-bit timer/counter.
(d) Two high-frequency, 250kHz, PWM outputs.
(e) Three high-frequency PWM outputs for BLDC motor control.
(f) 28 programmable I/O lines in 32-lead TQFP and 32-pad QFN/MLF package, 24 programmable I/O lines in 28-pin PDIP and 28-pad QFN/MLF package.
(g) ATtiny5 and ATtiny10 include a 4-channel 8-bit ADC.
(h) 0.7 - 1.8V via on-chip boost converter, 1.8 - 5.5V with the boost converter bypassed.

Atmel Flash Microcontrollers

Product Portfolio

PWM (Ch.)	10-bit ADC (Ch.)	Analog Gain Stage	DebugWire/ OCD	Vcc Range (V)	Clock Speed (MHz)	Green Packages (a)	Temp. Range
2 -- -- 1.8 - 5.5 12 SOT-23 (6-pins), UDFN8 -40°C to +85°C
2 4 (g) --- 1.8 - 5.5 12 SOT-23 (6-pins), UDFN8 -40°C to +85°C
2 --- --- 1.8 - 5.5 12 SOT-23 (6-pins), UDFN8 -40°C to +85°C
2 4 (g) --- 1.8 - 5.5 12 SOT-23 (6-pins), UDFN8 -40°C to +85°C
2 4 -- Yes 1.8 - 5.5 20 PDIP8, SOIC8, WQFN20, UDFN10 -40°C to +85°C
4 8 --- 1.8 - 5.5 12 SOIC14, TSSOP14, VQFN20, UFBGA15, WLCSP12 -40°C to +85°C
4	8	Yes	Yes	1.8 - 5.5	20	PDIP14, SOIC14, WQFN20, VQNF20	-40°C to +85°C
4 (d)	4	Yes	Yes	2.7 - 5.5	20	PDIP8, SOIC8, WQFN20	-40°C to +85°C
4 (d)	4	Yes	Yes	1.8 - 5.5	10	PDIP8, SOIC8, WQFN20	-40°C to +85°C
2 11 Yes --- 4.5 - 5.5 16 PDIP20, SOIC20, VQFN32						-40°C to +85°C
2 11 Yes --- 2.7 - 5.5 8 PDIP20, SOIC20, VQFN32						-40°C to +85°C
--	--	--	--	2.7 - 5.5	4	PDIP28, VQFN32, TQFP32	-40°C to +85°C
--	--	--	--	1.8 - 5.5	1.2	PDIP28, VQFN32, TQFP32	-40°C to +85°C
2 12 --- 1.8 - 5.5 12 SOIC20, TSSOP20, VQFN20						-40°C to +85°C
4	4	--	Yes	0.7 - 1.8(h)	8	SOIC20, WQFN20	-40°C to +85°C
4	8	Yes	Yes	1.8 - 5.5	20	PDIP14, SOIC14, VQFN20 , WQFN20	-40°C to +85°C
4 (d)	4	Yes	Yes	2.7 - 5.5	20	PDIP8, TSSOP8, SOIC8, WQFN20	-40°C to +85°C
4 (d)	4	Yes	Yes	1.8 - 5.5	10	PDIP8, TSSOP8, SOIC8, WQFN20	-40°C to +85°C
2	8	--	Yes	1.8 - 5.5	12	PDIP28, VQFN28, VQFN32, TQFP32	-40°C to +85°C
4	8	Yes	Yes	1.8 - 5.5	20	PDIP14, SOIC14, QFN20	-40°C to +85°C
4 (d)	4	Yes	Yes	2.7 - 5.5	20	PDIP8, SOIC8, WQFN20	-40°C to +85°C
4 (d)	4	Yes	Yes	1.8 - 5.5	10	PDIP8, SOIC8, WQFN2O	-40°C to +85°C
5	11	Yes	Yes	1.8 - 5.5	16	VQFN32, TSSOP20, SOIC20	-40°C to +85°C
2	8	--	Yes	1.8 - 5.5	12	PDIP28, VQFN28, VQFN32, TQFP32	-40°C to +85°C
5	11	Yes	Yes	1.8 - 5.5	16	VQFN32, TSSOP20, SOIC20	-40°C to +85°C
5 (e)	11	Yes	Yes	1.8 - 5.5	20	PDIP20, SOIC20, VQFN32, TSSOP20	-40°C to +85°C
2	12	Yes	Yes	1.7 - 5.5	16	SOIC14, VQFN20 , WQFN20	-40°C to +85°C
5 (e)	11	Yes	Yes	1.8 - 5.5	20	PDIP20, SOIC20, VQFN32, TSSOP20	-40°C to +85°C
4 28		Yes 1.7 - 5.5 20 VQFN32, TQFP32				-40°C to +85°C
2	12	Yes	Yes	1.7 - 5.5	16	SOIC14, VQFN20, WQFN20	-40°C to +85°C
5 (e)	11	Yes	Yes	1.8 - 5.5	20	PDIP20, SOIC20, VQFN32, TSSOP20	-40°C to +85°C
4	12	Yes	--	1.8 - 5.5	12	VQFN20, SOIC20	-40°C to +85°C
4	--	--	Yes	1.8 - 5.5	20	PDIP20, SOIC20, WQFN20, VQNF20	-40°C to +85°C

Atmel AVR

megaAVR 8-bit Microcontrollers

Product	Flash (Kbytes)	SRAM (Kbytes)	EEPROM (Bytes)	picoPower	QTouch Channels	Max I/O Pins	Ext Interrupts	USB	SPI	TWI (1°C)	UART	CAN	LIN
ATmega8 8 1 512 --	12 23 2 --	1 1 1 -- --
ATmega8A 8 1 512 --	12 23 2 --	1 1 1 -- --
ATmega8515 8 0.5 512 --	16 35 3 --	1 -- 1 -- --
ATmega8535 8 0.5 512 --	16 32 3 --	1 1 1 -- --
ATmega16 16 1 512 --	16 32 3 --	1 1 1 -- --
ATmega16A 16 1 512 --	16 32 3 --	1 1 1 -- --
ATmega32	32	2	1024	--	16	32	3	--	1	1	1	--	--
ATmega32A 32 2	1024	--	16 32 3 --	1 1 1 -- --
ATmega64 64 4	2048	--	16 53 8 --	1 1 2 -- --
ATmega64A 64 4	2048	--	16 53 8 --	1 1 2 -- --
ATmega128 128 4	4096	--	16 53 8 --	1 1 2 -- --
ATmega128A	128	4	4096	--	16	53	8	--	1	1	2	--	--
ATmega1284	128	16	4096	--	16	32	32	--	3	1	2	--	--
ATmega1284P	128	16	4096	Yes	16	32	32	--	3	1	2	--	--
ATmega162	16 1 512 --	16 35	3 --	1 -- 2 -- --
ATmega48	4 0.5 256 --	12 23	24 --	2 1 1 -- --
ATmega48A	4 0.5 256 --	12 23	24 --	2 1 1 -- --
ATmega48P	4	0.5	256	Yes	12	23	24	--	2	1	1	--	--
ATmega48PB	4	0.5	256	Yes	12	27	24	--	2	1	1	--	--
ATmega48PA	4	0.5	256	Yes	12	23	24	--	2	1	1	--	--
ATmega88	8 1 512 --	12 23	24 --	2 1 1 -- --
ATmega88A	8 1 512 --	12 23	24 --	2 1 1 -- --
ATmega88P	8	1	512	Yes	12	23	24	--	2	1	1	--	--
ATmega88PB	8	1	512	Yes	12	27	24	--	2	1	1	--	--
ATmega88PA	8	1	512	Yes	12	23	24	--	2	1	1	--	--
ATmega168	16 1 512 --	16 23	24 --	2 1 1 -- --
ATmega168A	16 1 512 --	16 23	24 --	2 1 1 -- --
ATmega168P	16 1 512	Yes	16			23 24 --	2 1 1 -- --
ATmega168PB	16	1	512	Yes	16	27	24	--	2	1	1	--	--
ATmega168PA	16	1	512	Yes	16	23	24	--	2	1	1	--	--
ATmega328	32	2	1024	--	16	23	24	--	2	1	1	--	--
ATmega328P	32	2	1024	Yes	16	23	24	--	2	1	1	--	--
ATmega165P	16	1	512	Yes	16	54	17	--	2	1	1	--	--
ATmega165PA	16	1	512	Yes	16	54	17	--	2	1	1	--	--

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.
(b) Only 6 ADC in PDIP packages.
(c) One of these is a 10-bit timer/counter.
(d) Two of these are 12-bit timer/counters.
(e) Three of these are 12-bit timer/counters.

Atmel Flash Microcontrollers

Product Portfolio

Segment LCD	ADC Channels	Analog Comparators	DAC Channels	8-bit Timers	16-bit Timers	PWM Channels	Operating Voltage (Vcc)	Max. Operating Frequency	Green Packages(a)	Temp. Range
-- 8 1	-- 2 1 3	2.7 -5.5 16	VQFN32, TQFP32, PDIP28 -40°C to +85°C
-- 8 1	-- 2 1 3	2.7 -5.5 16	VQFN32, TQFP32, PDIP28 -40°C to +85°C
-- --	-- -- 2 1 3	2.7 -5.5 16	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 4	2.7 -5.5 16	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 4	2.7 -5.5 16	VQFN44, TQFP44, PDIP40 -40°C to +85°C			-- 8 1	-- 2 1 4	-- 2 1 4	-- 2 1 4	-- 2 1 4
-- 8 1	-- 2 1 4	2.7 -5.5 16	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 4	2.7 -5.5 16	VQFN44, TQFP44	-- 2 1 4	-- 2 1 4	-- 8 1	-- 2 1 4	-- 2 1 4	-- 2 1 4	-- 2 1 4
-- 8 1	-- 2 1 4	2.7 -5.5 16	VQFN44, TQFP44, PDIP40 -40°C to +85°C

Atmel AVR

megaAVR 8-bit Microcontrollers - Continued

Product

Flash (Kbytes)

SRAM (Kbytes)

EEPROM (Bytes)

picoPower

QTouch Channels

Max I/O Pins

Ext Interrupts

USB

SPI

TWI (12C)

UART

CAN

LIN

ATmega325 32 2 1024 -- 16 54 17 -- 2 1 1 ---

ATmega325A 32 2 1024 -- 16 54 17 -- 2 1 1 ---

ATmega325P 32 2 1024 Yes 16 54 17 -- 2 1 1 ---

ATmega3250 32 2 1024 -- 16 69 25 -- 2 1 1 ---

ATmega3250A 32 2 1024 -- 16 69 25 -- 2 1 1 ---

ATmega3250P 32 2 1024 Yes 16 69 25 -- 2 1 1 ---

ATmega645 64 4 2048 -- 16 54 17 -- 2 1 1 ---

ATmega645A 64 4 2048 -- 16 54 17 -- 2 1 1 ---

ATmega645P 64 4 2048 Yes 16 54 17 -- 2 1 1 ---

ATmega6450 64 4 2048 -- -- 69 25 -- 2 1 1 ---

ATmega6450A 64 4 2048 -- -- 69 25 -- 2 1 1 ---

ATmega6450P 64 4 2048 Yes -- 69 25 -- 2 1 1 ---

ATmega640 64 8 4096 -- 16 86 32 -- 5 1 4 ---

ATmega1281

128 8 4096 -- 16 54 17 -- 3 1 2 ---

ATmega1280

128 8 4096 -- 16 86 32 -- 5 1 4 ---

ATmega2561

256 8 4096 -- -- 54 17 -- 3 1 2 ---

ATmega2560

256 8 4096 -- -- 86 32 -- 5 1 4 ---

ATmega164A 16 1 512

-- 16 32 32 -- 3 1 2 ---

ATmega164P 16 1 512

Yes 16 32 32 -- 3 1 2 ---

ATmega164PA 16 1 512

Yes 16 32 32 -- 3 1 2 ---

ATmega324A 32 2 1024 --

16 32 32 -- 3 1 2 ---

ATmega324P 32 2 1024 Yes 16 32 32 -- 3 1 2 ---

ATmega324PA 32 2 1024 Yes 16 32 32 -- 3 1 2 ---

ATmega644 64 4 2048 -- 16 32 32 -- 3 1 1 ---

ATmega644A 64 4 2048 -- 16 32 32 -- 3 1 2 ---

ATmega644P 64 4 2048 Yes 16 32 32 -- 3 1 2 ---

ATmega644PA 64 4 2048 Yes 16 32 32 -- 3 1 2 ---

ATmega169A 16 1 512

-- 16

54 17 -- 2 1 1 ---

ATmega169P 16 1 512

Yes 16 54 17 -- 2 1 1 ---

ATmega169PA 16 1 512

Yes 16 54 17 -- 2 1 1 ---

ATmega329 32 2 1024 --

16 54 17 -- 2 1 1 ---

ATmega329A 32 2 1024 -- 16 54 17 -- 2 1 1 ---

ATmega329P 32 2 1024 Yes 16 54 17 -- 2 1 1 ---

ATmega329PA 32 2 1024 Yes 16 54 17 -- 2 1 1 ---

ATmega3290 32 2 1024 -- 16 69 32 -- 2 1 1 ---

ATmega3290A 32 2 1024 -- 16 69 32 -- 2 1 1 ---

ATmega3290P 32 2 1024 Yes 16 69 32 -- 2 1 1 ---

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.
(b) Only 6 ADC in PDIP packages.
(c) One of these is a 10-bit timer/counter.
(d) Two of these are 12-bit timer/counters.
(e) Three of these are 12-bit timer/counters.

Atmel Flash Microcontrollers

Product Portfolio

Segment LCD	ADC Channels	Analog Comparators	DAC Channels	8-bit Timers	16-bit Timers	PWM Channels	Operating Voltage (Vcc)	Max. Operating Frequency	Green Packages (a)	Temp. Range
-- 8 1	-- 2 1 4	1.8 -5.5 16	VQFN64, TQFP64 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 20	VQFN64, TQFP64 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 20	VQFN64, TQFP64 -40°C to +85°C
-- 8 1	-- 2 1 4 1.8 -5.5 16	TQFP 100 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 20	TQFP 100 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 20	TQFP 100 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 16	VQFN64, TQFP64 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 16	VQFN64, TQFP64 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 16	TQFP 100 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5 20	TQFP 100 -40°C to +85°C
-- 8 1	-- 2 1 4	1.8 -5.5	TQFP 100 -40°C to +85°C
-- 16 1	-- 2 4 15	1.8 -5.5 16	TQFP100, CBGA100 -40°C to +85°C
-- 8 1	-- 2 4 8	1.8 -5.5 16	VQFN64, TQFP64 -40°C to +85°C
-- 16 1	-- 2 4 15	1.8 -5.5 16	TQFP100, CBGA100 -40°C to +85°C
-- 8 1	-- 2 4 8	1.8 -5.5 20	VQFN64, TQFP64 -40°C to +85°C
-- 16 1	-- 2 4 15	1.8 -5.5 16	TQFP100, CBGA100 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, QFN44, VFBGA49, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, QFN44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, QFN44, VFBGA49, PDIP40 -40°C to +85°C
-- 8 1	-- 1 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, QFN44, VFBGA49, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN44, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 2 1 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C	-40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQPFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQPFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	TQFP44, QFN44, VFGA49, PDIP40
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, QFN44, VFGA49, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8-5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C
-- 8 1	-- 21 6	1.8 -5.5 20	VQFN43, TQFP44, PDIP40 -40°C to +85°C

Atmel AVR

megaAVR 8-bit Microcontrollers - Continued

Product	Flash (Kbytes)	SRAM (Kbytes)	EEPROM (Bytes)	picoPower	QTouch Channels	Max I/O Pins	Ext Interrupts	USB	SPI	TWI (12C)	UART	CAN	LIN
ATmega649 64 4 2048 -- 16 54 17 -- 2 1 1 -- --
ATmega649A 64 4 2048 -- 16 54 17 -- 2 1 1 -- --
ATmega649P 64 4 2048 Yes 16 54 17 -- 2 1 1 -- --
ATmega6490 64 4 2048 -- 16 69 32 -- 2 1 1 -- --
ATmega6490A 64 4 2048 -- 16 69 32 -- 2 1 1 -- --
ATmega6490P 64 4 2048 Yes 16 69 32 -- 2 1 1 -- --
ATmega8U2	8	0.5	512	--	--	22	20	Full Speed Device	2	--	1	--	--
ATmega16U2	16	0.5	512	--	12	22	21	Full Speed Device	2	--	1	--	--
ATmega32U2 32 1 1024 -- 12 22 20 Full Speed Device					2 -- 1 -- --
ATmega16U4	16	2.1	512	--	14	26	13	Full Speed Device	2	1	1	--	--
ATmega32U4 32	3.3 1024 -- 14 26 13 Full Speed Device					2 1 1 -- --
AT90USB82	8	0.5	512	--	--	22	21	Full Speed Device	2	--	1	--	--
AT90USB162	16	0.5	512	--	8	22	21	Full Speed Device	2	--	1	--	--
AT90USB646 64 4 2048 -- 16 48 16 Full Speed Device						2 1 1 -- --
AT90USB1286	128 8 4096 -- 16 48 16 Full Speed Device					2 1 1 -- --
AT90USB1287	128 8 4096 -- 16 48 16 Full Speed Device + OTG 2 1 1 -- --
AT90USB647 64 4 2048 -- 16 48 16 Full Speed Device + OTG 2 1 1 -- --
AT90CAN32	32 2 1024 -- 16 53 8				-- 1 1 2 1 --
AT90CAN64	64 4 2048 -- 16 53 8				-- 1 1 2 1 --
AT90CAN128	128 4 4096 -- 16 53 8				-- 1 1 2 1 --
ATmega16M1	16	1	512	--	12	27	27	--	1	--	1	1	1
ATmega32M1	32 2 1024 -- 12 27 27 -- 1 -- 1 1 1
ATmega64M1	64 4 2048 -- 12 27 27 -- 1 -- 1 1 1
AT90PWM1	8	0.5	512	--	8	19	4	--	1	--	--	--	--
AT90PWM216	16	1	512	--	12	19	4	--	1	--	1	--	--
AT90PWM316	16	1	512	--	--	27	4	--	1	--	1	--	--
AT90PWM3B	8	0.5	512	--	--	27	4	--	1	--	1	--	--
AT90PWM2B	8 0.5 512	--	8			19 4		-- 1 -- 1 -- --
AT90PWM81	8	0.25	512	--	--	20	3	--	1	--	--	--	--
AT90PWM161	16	0.25	512	--	--	20	3	--	1	--	--	--	--

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.
(b) Only 6 ADC in PDIP packages.
(c) One of these is a 10-bit timer/counter.
(d) Two of these are 12-bit timer/counters.
(e) Three of these are 12-bit timer/counters.

Atmel Flash Microcontrollers

Product Portfolio

Segment LCD	ADC Channels	Analog Comparators	DAC Channels	8-bit Timers	16-bit Timers	PWM Channels	Operating Voltage (Vcc)	Max. Operating Frequency	Green Packages(a)	Temp. Range
100 8	1 -- 2 1 4	1.8 -5.5	16 VQFN64, TQFP64	-40°C to +85°C
100 8	1 -- 2 1 4	1.8 -5.5	16 VQFN64, TQFP64	-40°C to +85°C
100 8	1 -- 2 1 4	1.8 -5.5	16 VQFN64, TQFP64	-40°C TO +85°C
160 8	1 -- 2 1 4	1.8 -5.5	16 TQFP	100 -40°C to +85°C
160 8	1 -- 2 1 4	1.8 -5.5	20 TQFP	100 -40°C to +85°C
160 8	1 -- 2 1 4	1.8 -5.5	20 TQFP	100 -40°C to +85°C
-- --	1 -- 1 1 4	2.7 -5.5	16 TQFP32, VQFN32	-40°C to +85°C
-- --	1 -- 1 1 4	2.7 -5.5	16 TQFP32, VQFN32	-40°C to +85°C
-- --	1 -- 1 1 4	2.7 -5.5	16 TQFP32, VQFN32	-40°C to +85°C
-- 12	1 -- 2(c)	2 8 2.7	-5.5	16 TQFP44, VQFN44	-40°C to +85°C
-- 12	1 -- 2(c)	2 8 2.7	-5.5	16 TQFP44, VQFN44	-40°C to +85°C
-- --	1 -- 1 1 4	2.7 -5.5	16 TQFP32, VQFN32	-40°C to +85°C
-- --	1 -- 1 1 4	2.7 -5.5	16 TQFP32, VQFN32	-40°C to+85°C
-- 8	1 -- 2 2 9	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 8	1 -- 2 2 9	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 8	1 -- 2 2 9	2.7 -5.5	16 TQFP64, VQFN64 -40°C to +85°C
-- 8	1 -- 2 2 9	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 8	1 -- 2 2 7	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 8	1 -- 2 2 7	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 8	1-- 2 2 7	2.7 -5.5	16 TQFP64, VQFN64	-40°C to +85°C
-- 11	4 1 1 1	10 2.7 -5.5	16 VQFN32, TQFP32	-40°C to +85°C
-- 11	4 1 1 1	10 2.7 -5.5	16 VQFN32, TQFP32	-40°C to +85°C
-- 11	4 1 1 1	10 2.7 -5.5	VQFN32, TQFP32	-40°C to +85°C
-- 8	2 -- 3(d)	1 7 2.7 -5.5	16 SOIC24, QFN32	-40°C to 105°C
-- 8	2 1 3(d)	1+PSC	7 2.7 -5.5	16 SOIC 24				-40°C to 105°C
-- 11	3 1 4(e)	1+PSC	12 2.7 -5.5	16 VQFN32, SOIC32				-40°C to 105°C
-- 11	3 1 4(e)	1+PSC	12 2.7 -5.5	16 VQFN32, SOIC32				-40°C to 105°C
-- 8	2 1 3(d)	1+PSC	12 2.7 -5.5	16 SOIC 24				-40°C to 105°C
-- 11	3 1 --	1+PSC	6 2.7 -5.5	16 SOIC20, QFN32	-40°C to 125°C
-- 11	3 1 --	1+PSC	6 2.7 -5.5	16 SOIC20, QFN32	-40°C to 125°C

Atmel AVR

AVR XMEGA 8/16-bit Microcontrollers

Product	Flash (KB)	Boot Code (KB)	EEPROM (KB)	SRAM (KB)	picoPower	DMA Channels	Event System Channels	Crypto Engine	QTouch channels	USB	SPI	TWI (1°C)	USART
ATxmega64A1U 64 4 2 4 Yes 4 8 AES/DES 56 FS device 4+8 USART master 4 8
ATxmega128A1U 128 8 2 8 Yes 4 8 AES/DES 56 FS device 4+8 USART master 4 8
ATxmega64A3U 64 4 2 4 Yes 4 8 AES/DES 56 FS device 3+7 USART master 2 7
ATxmega128A3U 128 8 2 8 Yes 4 8 AES/DES 56 FS device 3+7 USART master 2 7
ATxmega192A3U 192 8 2 16 Yes 4 8 AES/DES 56 FS device 3+7 USART master 2 7
ATxmega256A3U 256 8 4 16 Yes 4 8 AES/DES 56 FS device 3+7 USART master 2 7
ATxmega256A3BU 256 8 4 16 Yes 4 8 AES/DES 56 FS device 2+6 USART master 2 6
ATxmega16A4U 16 4 1 2 Yes 4 8 AES/DES 56 FS device 2+5 USART master 2 5
ATxmega32A4U 32 4 1 4 Yes 4 8 AES/DES 56 FS device 2+5 USART master 2 5
ATxmega64A4U 64 4 2 4 Yes 4 8 AES/DES 56 FS device 2+5 USART master 2 5
ATxmega128A4U 128 8 2 8 Yes 4 8 AES/DES 56 FS device 2+5 USART master 2 5
ATxmega64B1 64 4 2 4 Yes 2 4 AES/DES 16 FS device 1+2 USART master 1 2
ATxmega128B1 128 8 2 8 Yes 2 4 AES/DES 16 FS device 1+2 USART master 1 2
ATxmega64B3 64 4 2 4 Yes 2 4 AES/DES 16 FS device 1+1 USART master 1 1
ATxmega128B3 128 8 2 8 Yes 2 4 AES/DES 16 FS device 1+1 USART master 1 1
ATxmega64C3 64 8 2 4 Yes -- 4 -- 56 FS device 2+3 USART master 2 3
ATxmega128C3 128 8 2 16 Yes -- 4 -- 56 FS device 2+3 USART master 2 3
ATxmega192C3 192 8 2 16 Yes -- 4 -- 56 FS device 2+3 USART master 2 3
ATxmega256C3 256 8 4 16 Yes -- 4 -- 56 FS device 2+3 USART master 2 3
ATxmega384C3	384	8	4	32	Yes	2	4	AES	56	FS device	2+3 USART master	2	3
ATxmega16C4 16 4 1 2 Yes -- 4 -- 16 FS device 2+3 USART master 2 3
ATxmega32C4 32 4 1 4 Yes -- 4 -- 16 FS device 2+3 USART master 2 3
ATxmega64D3 64 4 2 4 Yes -- 4 -- 56			--		2+3 USART master 2 3
ATxmega128D3	128	8	2	8	Yes	--	4	--	16	--	2+3 USART master	2	3
ATxmega192D3	192	8	2	16	Yes	--	4	--	16	--	2+3 USART master	2	3
ATxmega256D3	256	8	4	16	Yes	--	4	--	16	--	2+3 USART master	2	3
ATxmega384D3	384	8	4	32	Yes	2	4	--	56	--	2+3 USART master	2	3
ATxmega16D4 16 4 1				2	Yes	--	4	--	56	--	2+2 USART master	2	2
ATxmega32D4	32	4	1	4	Yes	--	4	--	56	--	2+2 USART master	2	2
ATxmega64D4	64	4	2	4	Yes	--	4	--	16	--	2+2 USART master	2	2
ATxmega128D4	128	8	2	8	Yes	--	4	--	16	--	2+2 USART master	2	2
ATxmega8E5	8	2	0.5	1	Yes	4	8	--	56	--	1+2 USART master	1	2
ATxmega16E5	16	4	1	2	Yes	4	8	--	56	--	1+2 USART master	1	2
ATxmega32E5	32	4	1	4	Yes	4	8	--	56	--	1+2 USART master	1	2

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.
(b) RTC also includes a built in battery backup function.
(c) Has two additional 8-bit timer/counters in the XMEGA custom logic module.
(d) DAC is 10-bit 300kSPS.

Atmel Flash Microcontrollers

Product Portfolio

RTC	16-bit Timers	PWM Channels	12-bit ADC Channels	12-bit DAC Channels	Analog Comparators	LCD Controller	I/O Pins	F.max (MHz)	Vcc (V)	Green Packages(a)	Temp. Range
16-bit 8 32	16 4 4	-- 78 32	1.6 - 3.6	TQFP100, VFBGA100 -40°C to +85°C
16-bit 8 32	16 4 4	-- 78 32	1.6 - 3.6	TQFP100, VFBGA100 -40°C to +85°C
16-bit 7 32	16 2 4	-- 50 32	1.6 -3.6	TQFP64, VQFN64 -40°C to +85°C
16-bit 7 32	16 2 4	-- 50 32	1.6 - 3.6	TQFP64, VQFN64 -40°C to +85°C
16-bit 7 32	16 2 4	-- 50 32	1.6 - 3.6	TQFP64, VQFN64 -40°C to +85°C
32-bit(b)	7 29	16 2 4	-- 47 32	1.6 - 3.6	TQFP64, VQFN64 -40°C to +85°C
16-bit 5 20	12 2 2	-- 34 32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44 -40°C to +85°C
16-bit 5 20	12 2 2	-- 34 32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44 -40°C to +85°C
16-bit 5 20	12 2 2	-- 34 22	1.6 - 3.6	TQFP44, VFBGA49, VQFN44 -40°C to +85°C
16-bit 5 20	12 2 2	-- 34 32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44 -41°C to +85°C
16-bit	3	16	16	--	4	160 Segment	53	32	1.6 - 3.6	TQFP100	-40°C to +85°C
16-bit	3	16	16	--	4	160 Segment	53	32	1.6 - 3.6	TQFP100	-40°C to +85°C
16-bit	2	8	8	--	2	100 Segment	36	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	2	8	8	--	2	100 Segment	36	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5.5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-30°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6
16-bit	4	20	12	--	2	--	34	32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	4	20	12	--	2	--	34	32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 -3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	2	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	5	32	16	--	--	--	50	32	1.6 - 3.6	TQFP64, VQFN64	-40°C to +85°C
16-bit	4	20	12	--	2	--	34	32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	4	20	12	--	2	--	34	32	1.6 - 3.6	TOFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	4	20	12	--	2	--	34	32	1.6 - 3.6	TQFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	4	20	12	--	2	--	34	31	1.6 - 3.6	TQFP44, VFBGA49, VQFN44	-40°C to +85°C
16-bit	3 (c)	12	16	2 (d)	2	--	26	32	1.6 - 3.6	TQFP32, QFN32	-40°C to +85°C
16-bit	3 (c)	12 16		2 (d)	2	--	26	32	1.6 - 3.6	TQFP32, QFN32	-40°C to +85°C
16-bit	3 (c)	12	16	2 (d)	2	--	26	32	1.6 - 3.6	TQFP32, QFN32	-40°C to +85°C

8051 8-bit Microcontrollers

Device Name	Flash (Kbytes)	Pin Count	Max. Operating Frequency	CPU	Max I/O Pins	USB Transceiver	USB Speed	USB Interface	SPI	TWI (12C)	UART	CAN	ADC channels	ADC Resolution(bits)	ADC Speed (ksps)
AT80C51RD2 44 60 8051-12C 32 1 1
AT83C5134 32 48 8051-12C 34 1 Full Speed Device 1 1 1
AT83C5135 32 48 8051-12C 34 1 Full Speed Device 1 1 1
AT83C5136 64 48 8051-12C 34 1 Full Speed Device 1 1 1
AT83EB5114 20 40 8051-12C 12 6 10 50
AT89C2051 2 20 24 8051-12C 15							1
AT89C4051 4 20 24 8051-12C 15							1
AT89C5115	16	32	40	8051-12C	20						1		8	10	62.5
AT89C5130A-M	16	64	48 8051-12C	34	1 Full Speed Device 1 1 1
AT89C5131A-L	32	64	48 8051-12C	34	1 Full Speed Device 1 1 1
AT89C5131A-M	32	64	48 8051-12C	34	1 Full Speed Device 1 1 1
AT89C51AC2	32	44	40	8051-12C	34						1		8	10	62.5
AT89C51AC3	64	64	60 8051-12C	32	1 1 8 10	62.5
AT89C51CC01	32	44	40	8051-12C	34						1	1	8	10	62.5
AT89C51CC02	16	32	40	8051-12C	20						1	1	8	10	62.5
AT89C51CC03	64	64	40 8051-12C	37	1 1 1 8 10	62.5
AT89C51ED2	64	44	60 8051-12C	32	1 1
AT89C51IC2	32	44	60 8051-12C	34	1 1 1
AT89C51ID2	64	44	60 8051-12C	32	1 1 1
AT89C51RB2	16	44	60 8051-12C	32	1 1
AT89C51RC	32	44	24 8051-12C	32				1
AT89C51RC2	32	44	60 8051-12C	32	1 1
AT89C51RD2	64	44	60 8051-12C	32	1 1
AT89C55WD	20	44	24 8051-12C	32				1
AT89EB5114	4	20	40 8051-12C	12	6 10 50
AT89LP2052	2	20	20 8051-1C	15	1 1
AT89LP213	2	14	20 8051-1C	14	1
AT89LP214	2	14	20 8051-1C	12	1 1
AT89LP216	2	16	20 8051-1C	14	1 1
AT89LP3240	32	44	20	8051-1C	38				1	1	1		8	10	153.8
AT89LP4052	4	20	20 8051-1C	15	1 1
AT89LP428	4	32	25 8051-1C	30	1 1
AT89LP51	4	44	20 8051-1C	36					1
AT89LP51ED2	64	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP51IC2	32	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP51ID2	64	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP51RB2	24	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP51RC2	32	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP51RD2	64	44	20	8051-1C	42				1	1	1		7	10	153.8
AT89LP52	8	44	20 8051-1C	36							1
AT89LP6440	64	44	20	8051-1C	38				1	1	1		8	10	153.8
AT89LP828	8	32	25 8051-1C	30	1 1
AT89LS51	4	44	16 8051-12C	32				1
AT89LS52	8	44	16 8051-12C	32				1
AT89S2051	2	20	24 8051-12C	15				1
AT89S4051	4	20	24 8051-12C	15				1
AT89S51	4	44	24 8051-12C	32				1
AT89S52	8	44	24 8051-12C	32				1
AT89S8253	12	44	24 8051-12C	32	1 1

Atmel Flash Microcontrollers

Product Portfolio

SRAM (Kbytes)	EEPROM (Bytes)	Self Program Memory	Operating Voltage (Vcc)	Timers	ISP	Mask ROM (Kbytes)	Watchdog	Packages
1.25 2.7 to 5.5 4 Yes LQFP RL 44, PDIP 3C 40, PLCC SL 44
1.25 512 2.7 to 3.6 4 8 Yes QFN32
1.25 512 2.7 to 3.6 4 16 Yes QFN32
1.25 512 2.7 to 3.6 4 32 Yes QFN32, QFN48, SO28, LQFP64
0.25 256 3.0 to 3.6 4 4 Yes SOIC TG 20
0.125 2.7 to 6.0 2 PDIP 20P3 20, SOIC 20S2 20
0.125 2.7 to 6.0 2 PDIP 20P3 20, SOIC 20S2 20
0.5 2048 API 3.0 to 5.5 4 UART Yes LQFP RA 32, PLCC SI 28, SOIC TI 28
1.25	1024	API	2.7 to 5.5	4	UART/USB		Yes	LQFP RD 64, PLCC S3 52, VQFN (Punched) PU 32
1.25	1024	API	3.0 to 3.6	4	UART/USB		Yes	LQFP RD 64, PLCC S3 52, SOIC TI 28
1.25	1024	API	2.7 to 5.5	4	UART/USB		Yes	LQFP RD 64, PLCC S3 52, VQFN (Punched) PU 32
1.25 2048 API 3.0 to 5.5 4 UART Yes LQFP RL 44, PLCC SL 44
2.25 2048 API 3.0 to 5.5 4 UART Yes LQFP RD 64, LQFP RL 44, PLCC S3 52, PLCC SL 44
1.25	2048	API	3.0 to 5.5	4	UART/CAN		Yes	LQFP RL 44, PLCC SL 44
0.5	2048	API	3.0 to 5.5	4	UART/CAN		Yes	LQFP RA 32, PLCC SI 28, SOIC TI 28
2.25	2048	API	3.0 to 5.5	4	UART/CAN		Yes	LQFP RD 64, LQFP RL 44, PLCC S3 52, PLCC SL 44
2	2048	API	2.7 to 5.5	4	UART		Yes	LQFP RD 64, LQFP RL 44, PLCC SL 44, PLCC SM 68
1.25	API 2.7 to 5.5 4 UART Yes LQFP RL 44, PLCC SL 44
2	2048 API 2.7 to 5.5 4 UART Yes LQFP RL 44, PLCC SL 44
1.25	API 2.7 to 5.5 4 UART Yes LQFP RL 44, PDIP 3C 40, PLCC SL 44
0.5			4.0 to 6.0 3 Yes PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
1.25	API 2.7 to 5.5 4 UART Yes LQFP RL 44, PDIP 3C 40, PLCC SL 44
2 API 2.7 to 5.5 4 UART Yes LQFP RL 44, PLCC SL 44
0.25 4.0 to 6.0 3 Yes PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
0.25 256 3.0 to 3.6 4 Yes SOIC TG 20
0.25			2.4 to 5.5	2	SPI		Yes	PDIP 20P3 20, SOIC 20S2 20, TSSOP 20X 20
0.125			2.4 to 5.5	2	SPI/OCD		Yes	PDIP 14P3 14, TSSOP 14X 14
0.125			2.4 to 5.0	2	SPI/OCD		Yes	PDIP 14P3 14, TSSOP 14X 14
0.125			2.4 to 5.5	2	SPI/OCD		Yes	PDIP 16P3 16, TSSOP 16X 16
4.25	8192	IAP	2.4 to 3.6	3	SPI/OCD		Yes	MLF (VQFN) 44M1 44, PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
0.25			2.4 to 5.5	2	SPI		Yes	PDIP 20P3 20, SOIC 20S2 20, TSSOP 20X 20
0.75	512	IAP	2.4 to 5.5	3	SPI/OCD		Yes	MLF (VQFN) 32M1-A 32, PDIP 28P3 28, PLCC 32J 32, TQFP 32A 32
0.25	256	IAP	2.4 to 5.5	3	SPI		Yes	MLF (VQFN) 44M1 44, PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
2.25	4096	API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44,MLF (VQFN) 44M1 44, PDIP 3C 40, PLCC SL 44, TQFP 44A 44
1.375		API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44, MLF (VQFN) 44M1 44,P LCC SL 44,T QFP 44A 44
2.25	4096	API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44, MLF (VQFN) 44M1 44, PLCC SL 44, TQFP 44A 44
	0	API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44, MLF (VQFN) 44M1 44, PDIP 3C 40, PLCC SL 44, TQFP 44A 44
1.375	0	API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44, MLF (VQFN) 44M1 44, PDIP 3C 40, PLCC SL 44, TQFP 44A 44
2.25	0	API	2.4 to 5.5	4	SPI/OCD/UART		Yes	LQFP RL 44, MLF (VQFN) 44M1 44, PDIP 3C 40, PLCC SL 44, TQFP 44A 44
0.25	256	IAP	2.4 to 5.5	3	SPI		Yes	MLF (VQFN) 44M1 44, PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
4.25	8192	IAP	2.4 to 3.6	3	SPI/OCD		Yes	MLF (VQFN) 44M1 44, PDIP 40P6 40, PLCC 44J 44, TQFP 44A 44
0.75	1024	IAP	2.4 to 5.5	3	SPI/OCD		Yes	MLF (VQFN) 32M1-A 32, PDIP 28P3 28, PLCC 32J 32, TQFP 32A 32
0.125			2.7 to 4.0	2	SPI		Yes	PDIP 40P6 40,PLCC 44J 44,TQFP 44A 44
0.25			2.7 to 4.0	3	SPI		Yes	PDIP 40P6 40,PLCC 44J 44,TQFP 44A 44
0.25			2.7 to 5.5	2	SPI			PDIP 20P3 20,SOIC 20S2 20
0.25			2.7 to 5.5	2	SPI			PDIP 20P3 20,SOIC 20S2 20
0.125			4.0 to 5.5	2	SPI		Yes	PDIP 40P6 40,PLCC 44J 44,TQFP 44A 44
0.25			4.0 to 5.5	3	SPI		Yes	PDIP 40P6 40,PLCC 44J 44,TQFP 44A 44
0.25	2048		2.7 to 5.5	3	SPI		Yes	PDIP 40P6 40,PLCC 44J 44,TQFP 44A 44

Atmel SMART™

Atmel | SMART SAM D ARM Cortex-M0+ Based Microcontrollers

Device Name

Flash (Kbytes)

SRAM (Kbytes)

CPU

SPI

TWI (12C)

UART

Full Speed USB

event system channels

DMA

32-bit RTC

16-bit T/C

16-bit T/CC

ATSAMD20J18 256 32 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20J17 128 16 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20J16 64 8 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20J15 32 4 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20J14 16 2 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20G18 256 32 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20G17 128 16 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20G16 64 8 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20G15 32 4 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20G14 16 2 Cortex-M0+ up to 6 up to 6 up to 6 8 Yes 8

ATSAMD20E18 256 32 Cortex-M0+ up to 4 up to 4 up to 4 8 Yes 6

ATSAMD20E17 128 16 Cortex-M0+ up to 4 up to 4 up to 4 8 Yes 6

ATSAMD20E16 64 8 Cortex-M0+ up to 4 up to 4 up to 4 8 Yes 6

ATSAMD20E15 32 4 Cortex-M0+ up to 4 up to 4 up to 4 8 Yes 6

ATSAMD20E14 16 2 Cortex-M0+ up to 4 up to 4 up to 4 8 Yes 6

ATSAMD21J18

256

32

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

5

3

ATSAMD21J17

128

16

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

5

3

ATSAMD21J16

64

8

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

5

3

ATSAMD21J15

32

4

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

5

3

ATSAMD21G18

256

32

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

3

3

ATSAMD21G17

128

16

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

3

3

ATSAMD21G16

64

8

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

3

3

ATSAMD21G15

32

4

Cortex-M0+

up to 6

up to 6

up to 6

H&D

12

12 ch

Yes

3

3

ATSAMD21E18

256

32

Cortex-M0+

up to 4

up to 4

up to 4

H&D

12

12 ch

Yes

3

3

ATSAMD21E17

128

16

Cortex-M0+

up to 4

up to 4

up to 4

H&D

12

12 ch

Yes

3

3

ATSAMD21E16

64

8

Cortex-M0+

up to 4

up to 4

up to 4

H&D

12

12 ch

Yes

3

3

ATSAMD21E15

32

4

Cortex-M0+

up to 4

up to 4

up to 4

H&D

12

12 ch

Yes

3

3

ATSAMD10D14 16 4 Cortex-M0+ up to 3 up to 3 up to 3 6 6 ch Yes 2

1

ATSAMD10D13

8

4

Cortex-M0+

up to 3

up to 3

up to 3

6

6 ch

Yes

2

1

ATSAMD10C14

16

4

Cortex-M0+

up to 2

up to 2

up to 2

6

6 ch

Yes

2

1

ATSAMD10C13

8 4 Cortex-M0+ up to 2 up to 2 up to 2 6 6 ch Yes 2

1

ATSAMD11D14

16

4

Cortex-M0+

up to 3

up to 3

up to 3

D

6

6 ch

Yes

2

1

ATSAMD11C14

16

4

Cortex-M0+

up to 2

up to 2

up to 2

D

6

6 ch

Yes

2

1

Atmel Flash Microcontrollers

Product Portfolio

PWM Channels	12-bit 350 ksps ADC channels	10-bit DAC channels	Analog Comparators	# of Touch Channels	Max I/O Pins	F.max (MHz)	Vcc (V)	Green Packages	Temp. Range
16 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +105°C
16 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +105°C
16 20	1ch 350 ksps 2 256 52 48 1,62 to 3.63 TQFP64, QFN64 -40°C to +105°C
16 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +105°C
16 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +105°C
16 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +105°C
16 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +105°C
16 14	1ch 300 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +105°C
16 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48,QFN48 -40°C to +105°C
16 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +105°C
10 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +105°C
10 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +105°C
10 10	1ch 35O ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +105°C
10 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFNN2 -40°C to +105°C
10 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +105°C
24 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +125°C
24 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +125°C
24 20	1ch 350 ksps 2 266 52 48 1.62 to 3.63 TQFP64, QFN64 -40°C to +125°C
24 20	1ch 350 ksps 2 256 52 48 1.62 to 3.63 TQFP64, QFN64 -40C to +125°C
20 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +125°C
20 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +125°C
20 14	1ch 350 ksps2 120 38 48 1.62 to 3.63 TQFP48, QFN48 -40°C to +125°C
20 14	1ch 350 ksps 2 120 38 48 1.62 to 3.63 TQFP48, QFN4B -40°C to +125°C
18 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +125°C
18 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +125°C
18 10	1ch 35O ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFN32 -40°C to +125°C
18 10	1ch 350 ksps 2 60 26 48 1.62 to 3.63 TQFP32, QFNN2 -40°C to +125°C
12	10/8	1ch 350 ksps	2	72/42	22/18	48	1.62 to 3.63	QFN24/SOIC20	-40°C to +85°C
12	10/8	1ch 350 ksps	2	72/42	22/18	48	1.62 to 3.63	QFN24/SOIC20	-40°C to +85°C
12	8	1ch 350 ksps	2	12	12	48	1.62 to 3.63	SOIC14	-40°C to +85°C
12	8	1ch 350 ksps	2	12	12	48	1.62 to 3.63	SOIC14	-40°C to +85°C
12	10/8	1ch 350 ksps	2	72/42	22/18	48	1.62 to 3.63	QFN24/SOIC20	-40°C to +85°C
12	8	1ch 350 ksps	2	12	48	1.62 to 3.63	SOIC14	-40°C to +85°C

Atmel SMART™

Atmel | SMART SAM S70 ARM Cortex-M7 Based Microcontrollers

Product	CPU	Flash (Kbytes)	SRAM (Kbytes)	Max. Operating Freq. (MHz)	FPU	MPU / MMU	Pin Count	USB Transceiver	USB Speed	USB Interface	SPI	QSPI	TWI (I2C)	UART	CAN	CAN-FD	LIN	Timers	PWM Channels	I2S
ATSAMS70J19	Cortex-M7	512	256	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	0	No	2	14	8	Yes
ATSAMS70J20	Cortex-M7	1024	384	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	0	No	2	14	8	Yes
ATSAMS70J21	Cortex-M7	2048	384	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	0	No	2	14	8	Yes
ATSAMS70N19	Cortex-M7	512	256	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	0	No	3	14	8	Yes
ATSAMS70N20	Cortex-M7	1024	384	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	0	No	3	14	8	Yes
ATSAMS70N21	Cortex-M7	2048	384	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	0	No	3	14	8	Yes
ATSAMS70Q19	Cortex-M7	512	256	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	0	No	3	14	8	Yes
ATSAMS70Q20	Cortex-M7	1024	384	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	0	No	3	14	8	Yes
ATSAMS70Q21	Cortex-M7	2048	384	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	0	No	3	14	8	Yes

Atmel | SMART SAM3S ARM Cortex-M3 Based Microcontrollers

Product	CPU	Flash (Kbytes)	SRAM (Kbytes)	USB Transceiver	USB Speed	USB Interface	Q Touch Channels	Quadrature Decoder Channels	SPI	TWI (12C)	UART	SSC	SD / eMMC	Timers	Output Compare channels	Input Capture Channels	PWM Channels	Ext Interrupts	ADC channels	ADCResolution (bits)
ATSAM3S1A	Cortex-M3	64	16	1	Full Speed	Device	17	1	2	2	3	1	--	3	3	3	4	34	8	12
ATSAM3S1B	Cortex-M3	64	16	1	Full Speed	Device	23	1	3	2	4	1	1	3	3	3	4	47	10	12
ATSAM3S1C	Cortex-M3	64	16	1	Full Speed	Device	32	2	3	2	4	1	1	6	6	6	4	79	16	12
ATSAM3S2A	Cortex-M3	128	32	1	Full Speed	Device	17	1	2	2	3	1	--	3	3	3	4	34	8	12
ATSAM3S2B	Cortex-M3	128	32	1	Full Speed	Device	23	1	3	2	4	1	1	3	3	3	4	47	10	12
ATSAM3S2C	Cortex-M3	128	32	1	Full Speed	Device	32	2	3	2	4	1	1	6	6	6	4	79	16	12
ATSAM3S4A	Cortex-M3	256	48	1	Full Speed	Device	17	1	3	2	3	1	--	3	3	3	4	34	8	12
ATSAM3S4B	Cortex-M3	256	48	1	Full Speed	Device	23	1	3	2	4	1	1	3	3	3	4	47	10	12
ATSAM3S4C	Cortex-M3	256	48	1	Full Speed	Device	32	2	3	2	4	1	1	6	6	6	4	79	16	12
ATSAM3S8B	Cortex-M3	512	64	1	Full Speed	Device	23	1	3	2	4	1	1	3	3	3	4	47	10	12
ATSAM3S8C	Cortex-M3	512	64	1	Full Speed	Device	32	1	3	2	4	1	1	6	6	6	4	79	16	12
ATSAM3SD8B	Cortex-M3	512	64	1	Full Speed	Device	23	1	3	2	4	1	1	3	3	3	4	47	10	12
ATSAM3SD8C	Cortex-M3	512	64	1	Full Speed	Device	32	1	4	2	5	1	1	6	6	6	4	79	16	12

Atmel Flash Microcontrollers

Product Portfolio

SSC

Ethernet

Ethernet AVB

SD / eMMC

Camera Interface

32kHz RTC

ADC Channels

ADC Resolution (bits)

ADC Speed (ksps)

Analog Comparators

DAC Channels

DAC Resolution (bits)

Crypto Engine

External Bus Interface

DRAM Memory

Temp. Range (deg C)

I/O Supply Class

Operating Voltage (Vcc)

Max I/O Pins

Packages

1

1 No

0 Yes

Yes 5

12 2000

1

1 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

44

LQFP64, QFN64

1

0 No

0 Yes

Yes 5

12 2000

1

1 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

44

LQFP64, QFN64

1

0 No

0 Yes

Yes 5

12 20O0

1

1 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

44

LQFP64, QFN64

1

0 No

1 Yes

Yes 10

12 2000

1

2 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

75

LQFP100, TFBGA100, VFBGA100

1

0 No

1 Yes

Yes 10

12 2000

1

2 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

75

LQFP100, TFBGA100, VFBGA100

l

0 No

1 Yes

Yes 10

12 2000

1

2 12

AES/SHA/TRNG 0

No -40 to 105

1.8/3.3

1.7 to 3.6

75

LQFP100, TFBGA100, VFBGA100

1

0 No 1 Yes

Yes 24

12 2000

1

2 12

AES/SHA/TRNG 1

Yes -40 to 105

1.8/3.3

1.7 to 3.6

114 LQFP144, LFBGA144

1

0 No

1 Yes

Yes 24

12 2000

1

2 12

AES/SHA/TRNG 1

Yes -40 to 105

1.8/3.3

1.7 to 3.6

114 LQFP144, LFBGA144

1

0 No

1 Yes

Yes 24

12 2000

1

2 12

AES/SHA/TRNG 1

Yes -40 to 105

1.8/3.3

1.7 to 3.6

114 LQFP144, LFBGA144

ADC Speed (ksps)	Analog Comparators	DAC Channels	DAC Resolution (bits)	Temp. Sensor	External Bus Interface	NAND Interface	32kHz RTC	Calibrated RC Oscillator	Clock Speed (MHz)	Max I/O Pins	Pin Count	I/O Supply Class	Vcc Range (V)	Green Packages	Temp. Range (°C)
1000	1	--	--	Yes	--	Yes	Yes	Yes	64	34	48	1.8/3.3	1.62 to 3.6	LQFP 48	-40 to 85
1000	1	2	12	Yes	--	Yes	Yes	Yes	64	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
1000	1	2	12	Yes	1	Yes	Yes	Yes	64	79	100	1.8/3.3	1.62 to 3.6	LQFP 100.TFBGA 100	-40 to 85
1000	1	--	--	Yes	--	Yes	Yes	Yes	64	34	48	1.8/3.3	1.62 to 3.6	LQFP 48	-40 to 85
1000	1	2	12	Yes	--	Yes	Yes	Yes	64	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
1000	1	2	12	Yes	1	Yes	Yes	Yes	64	79	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to 85
1000	1	--	--	Yes	--	Yes	Yes	Yes	64	34	48	1.8/3.3	1.62 to 3.6	LQFP 48, QFN 48	-40 to 85
1000	1	2	12	Yes	--	Yes	Yes	Yes	64	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
1000	1	2	12	Yes		Yes	Yes	Yes	64	79	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to 85
1000	1	2	12	Yes	--	Yes	Yes	Yes	64	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to +85
1000	1	2	12	Yes	1	Yes	Yes	Yes	64	79	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to +85
1000	1	2	12	Yes	--	Yes	Yes	Yes	64	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to +85
1000	1	2	12	Yes	1	Yes	Yes	Yes	Yes	64	79	100	1.8/3.3	LQFP 100, TFBGA 100	-40 to +85

Atmel SMART™

Atmel | SMART SAM4S ARM Cortex-M4 Based Microcontrollers

Product

CPU

Flash (Kbytes)

SRAM (Kbytes)

USB Transceiver

USB Speed

USB Interface

QTouch Channels

Quadrature Decoder Channels

SPI

TWI (iC)

UART

SSC

SD / eMMC

Timers

Output Compare channels

Input Capture Channels

PWM Channels

Ext Interrupts

ADC channels

ADC Resolution (bits)

ATSAM4S2A Cortex-M4 128 64 1 Full Speed Device 17 2 2 2 3 1 0 3 3 3 4 34 8 12

ATSAM4S4A Cortex-M4 256 64 1 Full Speed Device 17 2 2 2 3 1 0 3 3 3 4 34 8 12

ATSAM4S2B Cortex-M4 128 64 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4S4B Cortex-M4 256 64 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4S8B Cortex-M4 512 128 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4S2C Cortex-M4 128 64 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4S4C Cortex-M4 256 64 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4S8C Cortex-M4 512 128 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4S16B Cortex-M4 1024 128 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4S16C Cortex-M4 1024 128 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4SA16B Cortex-M4 1024 160 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4SA16C Cortex-M4 1024 160 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4SD16B Cortex-M4 1024 160 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4SD16C Cortex-M4 1024 160 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

ATSAM4SD32B Cortex-M4 2048 160 1 Full Speed Device 27 2 3 2 4 1 1 3 3 3 4 47 11 12

ATSAM4SD32C Cortex-M4 2048 160 1 Full Speed Device 32 2 3 2 4 1 1 6 6 6 4 79 16 12

The QFP package has a -40°C to 105°C option. Also available upon request for any other package type.

Atmel Flash Microcontrollers

Product Portfolio

ADC Speed (ksps)

Analog Comparators

DAC Channels

DAC Resolution (bits)

Temp. Sensor

External Bus Interface

NAND Interface

32KHz RTC

Calibrated RC Oscillator

Clock Speed (MHz)

Max I/O Pins

Pin Count

I/O Supply Class

Operating Voltage (Vcc)

Green Packages

Temp. Range (deg C)

1000

1 0 12 Yes --

Yes

Yes Yes

120

34 48

1.8/3.3

1.62 to

3.6 LQFP

48, QFN

48 -40 to +105

1000

1 0 12 Yes --

Yes

Yes Yes

120

34 48

1.8/3.3

1.62 to

3.6 LQFP

48, QFN

48 -40 to +105

1000

1 2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64, WLCSP

64 -40 to +105

1000

1 2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64, WLCSP

64 -40 to +105

1000

1 2 12 Yes--

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64, WLCSP

64 -40 to +105

1000

1 2 12 Yes --

Yes

Yes Yes

120

79 100

1.8/3.3

1.62 to

3.6 LQFP

100, VFBGA

100, TFBGA

100, WLCSP

64 -40 to +105

1000

1 2 12 Yes 1

Yes

Yes Yes

120

79 100

1.8/3.3

1.62 to

3.6 LQFP

100, VFBGA

100, TFBGA

100, WLCSP

64 -40 to +105

1000

1

2

12

Yes

1

Yes

Yes

Yes

120

79

100

1.8/3.3

1.62 to 3.6

LQFP 100, VFBGA 100, TFBGA 100

-40 to +105

1000

1 2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64, WLCSP

64 -40 to +105

1000

1

2

12

Yes

1

Yes

Yes

Yes

120

79

100

1.8/3.3

1.62 to 3.6

LQFP 100, VFBGA 100, TFBGA 100

-40 to +105

1000

1 2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64 -40 to +105

1000

1

2

12

Yes

1

Yes

Yes

Yes

120

79

100

1.8/3.3

1.62 to 3.6

LQFP 100, VFBGA 100, TFBGA 100

-40 to +105

1000

1

2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64 -40 to +105

1000

1

2

12

Yes

1

Yes

Yes

Yes

120

79

100

1.8/3.3

1.62 to 3.6

LQFP 100, VFBGA 100, TFBGA 100

-40 to +15

1000

1 2 12 Yes --

Yes

Yes Yes

120

47 64

1.8/3.3

1.62 to

3.6 LQFP

64, QFN

64 -40 to +105

1000

1

2

12

Yes

1

Yes

Yes

Yes

120

79

10O

1.8/3.3

1.62 to 3.6

LQFP 100, VFBGA 100, TFBGA 100

-40 to +105

Atmel SMART™

Atmel | SMART SAM3N ARM Cortex-M3 Based Microcontrollers

Product

CPU

Flash (Kbytes)

SRAM (Kbytes)

QTouch Channels

Quadrature Decoder Channels

SPI

TWI (12C)

UART

SSC

Timers

Output Compare channels

Input Capture Channels

PWM Channels

Ext Interrupts

ATSAM3N00A Cortex-M3 16 4 17 -- 2 2 3 1 6 2 2 4 34

ATSAM3N00B Cortex-M3 16 4 23 1 3 2 4 1 6 3 3 4 47

ATSAM3N0A Cortex-M3 32 8 17 -- 2 2 3 1 6 2 2 4 34

ATSAM3N0B Cortex-M3 32 8 23 1 3 2 4 1 6 3 3 4 47

ATSAM3N0C Cortex-M3 32 8 32 2 3 2 4 1 6 6 6 4 79

ATSAM3N1A Cortex-M3 64 8 17 -- 2 2 3 1 6 2 2 4 34

ATSAM3N1B Cortex-M3 64 8 23 1 3 2 4 1 6 3 3 4 47

ATSAM3N1C Cortex-M3 64 8 32 2 3 2 4 1 6 6 6 4 79

ATSAM3N2A Cortex-M3 128 16 17 -- 2 2 3 1 6 2 2 4 34

ATSAM3N2B Cortex-M3 128 16 23 1 3 2 4 1 6 3 3 4 47

ATSAM3N2C Cortex-M3 128 16 32 2 3 2 4 1 6 6 6 4 79

ATSAM3N4A Cortex-M3 256 24 17 -- 2 2 3 1 6 2 2 4 34

ATSAM3N4B Cortex-M3 256 24 23 1 3 2 4 1 6 3 3 4 47

ATSAM3N4C Cortex-M3 256 24 32 2 3 2 4 1 6 6 6 4 79

Atmel | SMART SAM4N ARM Cortex-M4 Based Microcontrollers

Device Name	Flash (Kbytes)	Pin Count	Max. Operating Frequency	CPU	# of Touch Channels	Max I/O Pins	Ext Interrupts	SPI	TWI (12C)	UART	ADC channels	ADC Resolution (bits) + HW Averaging	ADC Speed (ksps)	DAC Channels	DAC Resolution (bits)	Temp. Sensor	SRAM (Kbytes)
ATSAM4N16B	1024	64	100	Cortex-M4	23	47	47	3	3	6	10	10 + 2	510	1	10	Yes	80
ATSAM4N16C	1024	100	100	Cortex-M4	32	79	79	4	3	7	16	10 + 2	510	1	10	Yes	80
ATSAM4N8A	512	48	100	Cortex-M4	17	34	34	2	3	5	8	10 + 2	510	0	--	Yes	64
ATSAM4N8B	512	64	100	Cortex-M4	23	47	47	3	3	6	10	10 + 2	510	1	10	Yes	64
ATSAM4N8C	512	100	100	Cortex-M4	32	79	79	4	3	7	16	10 + 2	510	1	10	Yes	64

Atmel Flash Microcontrollers

Product Portfolio

ADC channels	ADC Resolution (bits)	ADC Speed (ksps)	DAC Channels	DAC Resolution (bits)	32kHz RTC	Calibrated RC Oscillator	Clock Speed (MHz)	Max I/O Pins	Pin Count	I/O Supply Class	Vcc Range (V)	Green Packages	Temp. Range (°C)
8 10	384 --	Yes Yes	48 34 48	1.8/3.3	1.62 to 3.6	QFN 48 -40 to +85
10 10	384 1	10 Yes Yes	48 47 64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64 -40 to +85
8 10	384 --	Yes Yes	48 34 48	1.8/3.3	1.62 to 3.6	QFN E 48 -40 to +85
10 10	384 1	10 Yes Yes	48 47 64	1.8/3.3	1.62 to 3.6	LQFP R-64, QFN 64 -40 to +85
16	10	384	1	10	Yes	Yes	48	79	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to +85
8 10	384 --	Yes Yes	48 34 48	1.8/3.3	1.62 to 3.6	QFN 48 -40 to +85
10	10	384	1	10	Yes	Yes	48	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
16	10	384	1	10	Yes	Yes	48	79	100	1.8/3.3	1.62 to 3.6	LQFP 100,TFBGA 100	-40 to 85
8 10	384 --	Yes Yes	48 34 48	1.8/3.3	1.62 to 3.6	QFN 48			-40 to 85
10	10	384	1	10	Yes	Yes	48	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
16	10	384	1	10	Yes	Yes	48	78	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to 85
8 10	384 --	Yes Yes	48 34 48	1.8/3.3	1.62 to 3.6	QFN 48			-40 to 85
10	10	384	1	10	Yes	Yes	47	64	1.8/3.3	1.62 to 3.6	LQFP 64, QFN 64	-40 to 85
16	10	384	1	10	Yes	Yes	48	79	100	1.8/3.3	1.62 to 3.6	LQFP 100, TFBGA 100	-40 to 85

Self Program Memory	Temp. Range (deg C)	Device Name	I/O Supply Class	Operating Voltage (Vcc)	MPU / MMU	Timers	PWM Channels	32KHz RTC	Calibrated RC Oscillator	Packages
Yes	-40 to 85	ATSAM4N16B	1.8/3.3	1.62 to 3.6	Yes / No	6	4	Yes	Yes	LQFP64_L,QFN64_V
Yes	-40 to 85	ATSAM4N16C	1.8/3.3	1.62 to 3.6	Yes / No	6	4	Yes	Yes	LQFP100_P,TFBGA100_AH,VFBGA100_D
Yes	-40 to 85	ATSAM4N8A	1.8/3.3	1.62 to 3.6	Yes / No	6	4	Yes	Yes	LQFP48_L,QFN48_V
Yes	-40 to 85	ATSAM4N8B	1.8/3.3	1.62 to 3.6	Yes / No	6	4	Yes	Yes	LQFP64_L,QFN64_V
Yes	-40 to 85	ATSAM4N8C	1.8/3.3	1.62 to 3.6	Yes / No	6	4	Yes	Yes	LQFP100_P,TFBGA100_AH,VFBGA100_D

Atmel ^® SMART ^™

Atmel | SMART SAM L ARM Cortex-M0+ Based Microcontrollers

Device Name	Flash (Kbytes)	Pin Count	Max. Operating Freq. (MHz)	CPU	# of Touch Channels	Hardware QTouch Acquisition	Event System Channels	DMA	Max I/O Pins	Ext Interrupts	USB Transceiver	USB Speed	USB Interface	SPI	TWI (12C)	UART	ISO781	LIN	Segment LCD	ADC Channels	ADC Resolution (bits)	ADC Speed (ksps)	Diff. ADC Inputs	ADC Gain Stage	Analog Comparators
ATSAML21E18A	256	32	48	Cortex-M0+ 60 Y	12	16	25	16	1 FS					Host, Device	4	4	4	0	4	0	10	12	1000	Y opAmps 2
ATSAML21E17A	128	32	48	Cortex-M0+ 60 Y	12	16	25	16	1 FS					Host, Device	4	4	4	0	4	0	10	12	1000	Y opAmps 2
ATSAML21E16A	64	32	48	Cortex-M0+ 60 Y	12	16	25	16	1 FS					Host, Device	4	4	4	0	4	0	10	12	1000	Y opAmps 2
ATSAML21E15A	32	32	48	Cortex-M0+ 60 Y	12	16	25	16	1 FS					Host, Device	4	4	4	0	4	0	10	12	1000	Y opAmps 2
ATSAML21G18A	256	48	48	Cortex-M0+ 96 Y	12	16	37	16	1 FS					Host, Device	6	6	6	0	6	0	14	12	1000	Y opAmps 2
ATSAML21G17A	128	48	48	Cortex-M0+ 96 Y	12	16	37	16	1 FS					Host, Device	6	6	6	0	6	0	14	12	1000	Y opAmps 2
ATSAML21G16A	64	48	48	Cortex-M0+ 96 Y	12	16	37	16	1 FS					Host, Device	6	6	6	0	6	0	14	12	1000	Y opAmps 2
ATSAML21J18A	256	64	48	Cortex-M0+ 192 Y	12	16	51	16	1 FS					Host, Device	6	6	6	0	6	0	20	12	1000	Y opAmps 2
ATSAML21J17A	128	64	48	Cortex-M0+ 192 Y	12	16	51	16	1 FS					Host, Device	6	6	6	0	6	0	20	12	1000	Y opAmps 2
ATSAML21J16A	64	64	48	Cortex-M0+ 192 Y	12	16	51	16	1 FS					Host, Device	6	6	6	0	6	0	20	12	1000	Y opAmps 2
SAML22G18A	256	48	32	Cortex-M0+	132	Y	8	16	36	16	1	FS	Device	3	2	3	3	0	120	10	12	1000	Y	0	2
SAML22G17A	128	48	32	Cortex-M0+	132	Y	8	16	36	16	1	FS	Device	3	2	3	3	0	120	10	12	1000	Y	0	2
SAML22G16A	64	48	32	Cortex-M0+	132	Y	8	16	36	16	1	FS	Device	3	2	3	3	0	120	10	12	1000	Y	0	2
SAML22J18A	256	64	32	Cortex-M0+	182	Y	8	16	50	16	1	FS	Device	4	4	4	4	0	184	16	12	1000	Y	0	2
SAML22J17A	128	64	32	Cortex-M0+	182	Y	8	16	50	16	1	FS	Device	4	4	4	4	0	184	16	12	1000	Y	0	2
SAML22J16A	64	64	32	Cortex-M0+	182	Y	8	16	50	16	1	FS	Device	4	4	4	4	0	184	16	12	1000	Y	0	2
SAML22N18A	256	100	32	Cortex-M0+	256	Y	8	16	82	16	1	FS	Device	6	4	6	6	0	320	20	12	1000	Y	0	2
SAML22N17A	128	100	32	Cortex-M0+	256	Y	8	16	82	16	1	FS	Device	6	4	6	6	0	320	20	12	1000	Y	0	2
SAML22N16A	64	100	32	Cortex-M0+	256	Y	8	16	82	16	1	FS	Device	6	4	6	6	0	320	20	12	1000	Y	0	2

(a) * VFBGA100 Package available end of February 2016
(b) Y-Yes
(c) N-No

Atmel Flash Microcontrollers

Product Portfolio

N

2 12 Y

AES,TRNG

N

8 2

N N

Y SWD

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

32 8

N N

Y SWD

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

16 4

N N

Y SWD

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

8 2

N

Y SWD

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

4 2

N

Y SWD

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

32 8

N N

Y SW D

-40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

16 4

N N

Y SWD

- 40 to 85

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

8 2

N

Y SWD

-40 to 8 5

1.62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

32 8

N N

Y SWD

-40 to 85

1 .62 to 3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

16 4

N N

Y SWD

-40 to 85

1.62 to3.63

N N Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

8 2

N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

32 8

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

16 4

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

8 2

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

32 8

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC|Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

16 4

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC| Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

N

2 12 Y

AES,TRNG

N

8 2

N N

Y SWD

-40 to 85

1.62 to 3.63

NN Y/N 5 12 12 12 Y

RTC| Counter/ Clock+Cal

5

Y Y Y

TQFP100, VFBGA100*

Atmel SMART™

Atmel | SMART SAM4L ARM Cortex-M4 Based Microcontrollers

Product

CPU

Flash (Kbytes)

SRAM (Kbytes)

picoPower

USB Transceiver

USB Speed

USB Interface

QTouch Channels

Hardware QTouch Acquisition

I^2S

SPI

TWI ( ^12C )

UART

Timers

Output Compare channels

Input Capture Channels

32kHz RTC

ATSAM4LC2A Cortex-M4 128 32 Yes 1 Full Speed Host 13 Yes 1 1 2 3 3 9 6 Yes

ATSAM4LC2B Cortex-M4 128 32 Yes 1 Full Speed Host 21 Yes 1 1 4 4 3 9 6 Yes

ATSAM4LC2C Cortex-M4 128 32 Yes 1 Full Speed Host 32 Yes 1 1 4 4 6 18 12 Yes

ATSAM4LC4A Cortex-M4 256 32 Yes 1 Full Speed Host 13 Yes 1 1 2 3 3 9 6 Yes

ATSAM4LC4B Cortex-M4 256 32 Yes 1 Full Speed Host 21 Yes 1 1 4 4 3 9 6 Yes

ATSAM4LC4C Cortex-M4 256 32 Yes 1 Full Speed Host 32 Yes 1 1 4 4 6 18 12 Yes

ATSAM4LS2A Cortex-M4 128 32 Yes 1 Full Speed Device 32 Yes 1 1 2 3 3 9 6 Yes

ATSAM4LS2B Cortex-M4 128 32 Yes 1 Full Speed Device 32 Yes 1 1 4 4 3 9 6 Yes

ATSAM4LS2C Cortex-M4 128 32 Yes 1 Full Speed Device 32 Yes 1 1 4 4 6 18 12 Yes

ATSAM4LS4A Cortex-M4 256 32 Yes 1 Full Speed Device 32 Yes 1 1 2 3 3 9 6 Yes

ATSAM4LS4B Cortex-M4 256 32 Yes 1 Full Speed Device 32 Yes 1 1 4 4 3 9 6 Yes

ATSAM4LS4C Cortex-M4 256 32 Yes 1 Full Speed Device 32 Yes 1 1 4 4 6 18 12 Yes

SAM G ARM Cortex-M4F Based Microcontrollers

Product	CPU	FPU	Frequency	Flash	SRAM	SPI	TWI (I2C)	UART	USB Host	USB Device	Timers	RTC	EXT interrupts	I/O pins	12-bit ADC	I2S / PDM	Packages
SAMG51	Cortex-M4	Yes	48	256	64	2	3	3	-	-	6	Yes	38	38	8	-	49-pin WLCSP, 100-pin QFP
SAMG53	Cortex-M4	Yes	48	512	96	2	3	3	-	-	6	Yes	38	38	8	2 / 2	49-pin WLCSP, 100-pin QFP
SAMG54	Cortex-M4	Yes	96	512	96	2	3	3	-	-	6	Yes	38	38	8	2 / 2	49-pin WLCSP, 100-pin QFP
SAMG55	Cortex-M4	Yes	120	512	176	8	8	8	Yes	Yes	6	Yes	48	48	8	2 / 2	49-pin WLCSP, 64-pin QFP, 64-pin QFN

Atmel Flash Microcontrollers

Product Portfolio

Calibrated RC Oscillator	Ext Interrupts	Segment LCD	ADC channels	ADC Resolution (bits)	ADC Speed (ksps)	Analog Comparators	DAC Channels	DAC Resolution (bits)	Temp. Sensor	Crypto (AES)	Vcc Range (V)	Clock Speed (MHz)	Max I/O Pins	Pin Count	Green Packages	Temp. Range (°C)
Yes 27	13 3	12 300	1 1 10	Yes Yes	1.68 - 3.6	48 27	48 TQFP	48, VQFN	48 -40 to +85
Yes 43	23 7	12 300	2 1 10	Yes Yes	1.68 - 3.6	48 43	64 LQFP	64, VQFN	64 -40 to +85
Yes 75	40 15	12 300	4 1 10	Yes Yes	1.68 - 3.6	48 75	100 TQFP	100 -40 to +85
Yes 27	13 3	12 300	2 1 10	Yes Yes	1.68 - 3.6	48 27	48 TQFP	48, VQFN	48 -40 to +85
Yes 43	23 7	12 300	2 1 10	Yes Yes	1.68 - 3.6	48 43 64 LQFP	64, VQFN	64 -40 to +85
Yes 75	40 15	12 300	4 1 10	Yes Yes	1.68 - 3.6	48 75	100 TQFP	100 -40 to +85
Yes 32	-- 3	12 300	1 1 10	Yes --	1.68 - 3.6	48 32	48 TQFP	48,VQFN	48 -40 to +85
Yes 48	-- 7	12 300	2 1 10	Yes --	1.68 - 3.6	48 48	64 LQFP	64, VQFN	64 -40 to +85
Yes 80	--	15 12	300 4	1 10 Yes	-- 1.68 - 3.6	48	80 100 TQFP	100 -40 to +85
Yes 32	-- 3	12 300	1 1 10	Yes --	1.68 - 3.6	48 32	48 TQFP	48, VQFN	48 -40 to +85
Yes 48	-- 7	12 300	2 1 10	Yes --	1.68 - 3.6	48 48	64 LQFP	64, VQFN	64 -40 to +85
Yes 8O	--	15 12	300 4	1 10 Yes	-- 1.68 - 3.6	48 80	100 TQFP	100 -40 to +85

Atmel ^® SMART ^TM

Atmel | SMART SAM C ARM Cortex-M0+ Based Microcontrollers

Device Name	Flash (Kbytes)	Pin Count	Max. Operating Freq. (MHz)	CPU	# of Touch Channels	Hardware QTouch Acquisition	Max I/O Pins	Ext Interrupts	USB Transceiver	USB Speed	USB Interface	SPI	TWI (12C)	UART	CAN	LIN	ADC channels	ADC Resolution (bits)	ADC Speed (ksps)	Diff. ADC Inputs	ADC Gain Stage	Analog Comparators	Resistive Touch Screen	DAC Channels	DAC Resolution (bits)
ATSAMC20E18A 256	32	48	Cortex-M0+ 60 Y 26	16	0	0	4	4	0	4	10	12	1000	Y	N	2	N	0	10
ATSAMC20E17A 128	32	48	Cortex-M0+ 60 Y 26	16	0	0	4	4	0	4	10	12	1000	Y	N	2	N	0	10
ATSAMC20E16A 64	32	48	Cortex-M0+ 60 Y 26	16	0	0	4	4	0	4	10	12	1000	Y	N	2	N	0	10
ATSAMC20E15A 32	32	48	Cortex-M0+ 60 Y 26	16	0	0	4	4	0	4	10	12	1000	Y	N	2	N	0	10
ATSAMC20G18A 256	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	4	4	0	4	14	12	1000	Y	N	2	N	0	10
ATSAMC20G17A 128	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	4	4	0	4	14	12	1000	Y	N	2	N	0	10
ATSAMC20G16A 64	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	4	4	0	4	14	12	1000	Y	N	2	N	0	10
ATSAMC20G15A 32	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	4	4	0	4	14	12	1000	Y	N	2	N	0	10
ATSAMC20J18A 256	64	48	Cortex-M0+ 256 Y 52	16	0	0	0	4	4	0	4	20	12	1000	Y	N	2	N	0	10
ATSAMC20J17A 128	64	48	Cortex-M0+ 256 Y 52	16	0	0	0	4	4	0	4	20	12	1000	Y	N	2	N	0	10
ATSAMC20J16A	64	64	48	Cortex-M0+	256	Y	52	16	0	0	0	4	4	4	0	4	20	12	1000	Y	N	2	N	0	10
ATSAMC20J15A	32	64	48	Cortex-M0+	256	Y	52	16	0	0	0	4	4	4	0	4	20	12	1000	Y	N	2	N	0	10
ATSAMC21E18A 256	32	48	Cortex-M0+ 60 Y 26	16	0	0	0	4	4	1	4	10	12	1000	Y	N	3	N	1	10
ATSAMC21E17A 128	32	48	Cortex-M0+ 60 Y 26	16	0	0	0	4	4	1	4	10	12	1000	Y	N	3	N	1	10
ATSAMC21E16A 64	32	48	Cortex-M0+ 60 Y 26	16	0							0	0	4	4	4	1	4	10	12	1000	Y	N	3	N
ATSAMC21E15A 32	32	48	Cortex-M0+ 60 Y 26	16	0	0	0	4	4	1	4	10	12	1000	Y	N	3	N	1	10
ATSAMC21G18A 256	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	6	6	6	2	6	14	12	1000	Y	N	4	N	1	10
ATSAMC21G17A 128	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	6	6	6	2	6	14	12	1000	Y	N	4	N	1	10
ATSAMC21G16A 64	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	6	6	6	2	6	14	12	1000	Y	N	4	N	1	10
ATSAMC21G15A 32	48	48	Cortex-M0+ 120 Y 38	16	0	0	0	6	6	6	2	6	14	12	1000	Y	N	4	N	1	10
ATSAMC21J18A 256	64	48	Cortex-M0+ 256 Y 52	16	0	0	0	6	6	6	2	6	20	12	1000	Y	N	4	N	1	10
ATSAMC21J17A 128	64	48	Cortex-M0+ 256 Y 52	16	0	0	0	6	6	6	2	6	20	12	1000	Y	N	4	N	1	10
ATSAMC21J16A	64	64	48	Cortex-M0+	256	Y	52	16	0	0	0	6	6	6	2	6	20	12	1000	Y	N	4	N	1	10
ATSAMC21J15A	32	64	48	Cortex-M0+	256	Y	52	16	0	0	0	6	6	6	2	6	20	12	1000	Y	N	4	N	1	10

(a) Y-Yes
(b) N-No

Atmel Flash Microcontrollers

Product Portfolio

Temp. Sensor	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
Crypto Engine	N N 8 4 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 8 4 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
ARM Trust Zone	N N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
SRAM (Kbytes)	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
EEPROM (Bytes)	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
Self Program Memory	N N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
External Bus Interface	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
DRAM Memory	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
NAND Interface	N N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
picoPower	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
Debug Interface	N N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
Temp. Range (deg C)	N N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	N N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
Operating Voltage (Vcc)	Y N 4 2 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 O N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 16 6 0 O N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 16 6 0 N N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 16 6 0 N N SWD-41 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 90 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 A N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 106 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 16 6 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2,7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 105 2.7 to105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to 110 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N SWD-40 to105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD -40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40to105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to105,2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y
	Y N 32 8 0 N N SWD-40 to 105 2.7 to 5.5 N N N/S 5 10 5 Y Y Y Y Y	Y N 32 8 0 N N SWD-40 to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105,2.7to105 ,

Atmel SMART™

Atmel | SMART SAM4E ARM Cortex-M4 Based Microcontrollers

Device Name	CPU	Flash (Kbytes)	SRAM (Kbytes)	Clock Speed (MHz)	QTouch Channels	Quadrature Decoder Channels	USB Transceiver	USB Speed	USB Interface	SPI	TWI ( ^12C )	UART	CAN	Ethernet	SD / eMMC	Timers	Output Compare Channels	Input Capture Channels	PWM Channels	Ext Interrupts	ADC channels	ADC Resolution (bits)+ Averaging (bits)
ATSAM4E8C Cortex-M4 512 128	120 32	2 1 Full Speed Device 3	2 4	1 1 3 3 4	79 6+4	12+4
ATSAM4E8E Cortex-M4	512	128	120	32	2	1	Full Speed	Device	3	2	4	2	1	1	9	9	9	4	117	16+8	12+4
ATSAM4E16C Cortex-M4 1024	128 120	32 2 Full Speed Device 3	2	4 1 1 3 3	4 79 6+4	12+4
ATSAM4E16E Cortex-M4	1024	128	120	32	2	1	Full Speed	Device	3	2	4	2	1	1	9	9	9	4	117	16+8	12+4

The QFP package has a -40°C to 105°C option. Also available upon request for any other package type.

Atmel | SMART SAM E70 ARM Cortex-M7 Based Microcontrollers

Product	CPU	Flash (Kbytes)	SRAM (Kbytes)	Max. Operating Freq. (MHz)	FPU	MPU / MMU	Pin Count	USB Transceiver	USB Speed	USB Interface	SPI	QSPI	TWI (I2C)	UART	CAN	CAN-FD	LIN	Timers	PWM Channels	I2S
ATSAME70J19	Cortex-M7	512	256	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	1	Yes	2	14	8	Yes
ATSAME70J20	Cortex-M7	1024	384	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	1	Yes	2	14	8	Yes
ATSAME70J21	Cortex-M7	2048	384	300	Yes	Yes / No	64	1	Full Speed	Host, Device	1	0	2	5	1	Yes	2	14	8	Yes
ATSAME70N19	Cortex-M7	512	256	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	2	Yes	3	14	8	Yes
ATSAME70N20	Cortex-M7	1024	384	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	2	Yes	3	14	8	Yes
ATSAME70N21	Cortex-M7	2048	384	300	Yes	Yes / No	100	1	Hi-Speed	Host, Device	4	1	3	8	2	Yes	3	14	8	Yes
ATSAME70Q19	Cortex-M7	512	256	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	2	Yes	3	14	8	Yes
ATSAME70Q20	Cortex-M7	1024	384	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	2	Yes	3	14	8	Yes
ATSAME70Q21	Cortex-M7	2048	384	300	Yes	Yes / No	144	1	Hi-Speed	Host, Device	5	1	3	8	2	Yes	3	14	8	Yes

Atmel Flash Microcontrollers

Product Portfolio

ADC Speed (ksps)

Analog Comparators

DAC Channels

DAC Resolution (bits)

Temp. Sensor

Crypto Engine

External Bus Interface

NAND Interface

FPU

MPU / MMU

32kHz RTC

Calibrated RC Oscillator

Max I/O Pins

Pin Count

I/O Supply Class

Operating Voltage (Vcc)

Packages

Temp. Range (deg C)

1000

1

2

12 Yes AES

-- No Yes

Yes / No Yes

Yes 79

100

1.8/3.3

1.6 to

3.6 LQFP100, LFBGA100 -40 to +105

1000

1

2

12 Yes AES

1 Yes Yes

Yes / No Yes

Yes 117

144

1.8/3.3

1.6 to

3.6 LQFP144, LFBGA144 -40 to +105

1000

1

2

12 Yes AES

-- No Yes

Yes / No Yes

Yes 79

100

1.8/3.3

1.6 to

3.6 LQFP100, LFBGA100 -40 to +105

1000

1

2

12 Yes AES

1 Yes

Yes Yes / No Yes

Yes 117

144

1.8/3.3

1.6 to

3.6 LQFP144, LFBGA144 -40 to +105

SSC	Ethernet	Ethernet AVB	SD / eMMC	Camera Interface	32kHz RTC	ADC Channels	ADC Resolution (bits)	ADC Speed (ksps)	Analog Comparators	DAC Channels	DAC Resolution (bits)	Crypto Engine	External Bus Interface	DRAM Memory	Temp. Range (deg C)	I/O Supply Class	Operating Voltage (Vcc)	Max I/O Pins	Packages
1	1	Yes	0	Yes	Yes	5	12	2000	1	1	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	44	LQFP64, QFN64
1	1	Yes	0	Yes	Yes	5	12	2000	1	1	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	44	LQFP64, QFN64
1	1	Yes	0	Yes	Yes	5	112	2000	1	1	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	44	LQFP64, QFN64
1	1	Yes	1	Yes	Yes	10	12	2000	1	2	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	75	LQFP100, TFBGA100
1	1	Yes	1	Yes	Yes	10	12	2000	1	2	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	75	LQFP100, TFBGA100
1	1	Yes	1	Yes	Yes		10	2000	1	2	12	AES/SHA/TRNG	0	No	-40 to 105	1.8/3.3	1.7 to 3.6	75	LQFP100, TFBGA100
1	1	Yes	1	Yes	Yes	24	12	2000	1	2	12	AES/SHA/TRNG	1	Yes	-40 to 105	1.8/3.3	1.7 to 3.6	114	LQFP144, LFBGA144
1	1	Yes	1	Yes	Yes	24	12	2000	1	2	12	AES/SHA/TRNG	1	Yes	-40 to 105	1.8/3.3	1.7 to 3.6	114	LQFP144, LFBGA144
1	1	Yes	1	Yes	yes	24	12	2000	1	2	12	AES/SHA/TRNG	1	Yes	-40 to 105	1.8/3.3	1.7 to 3.6	114	LQFP144, LFBGA144

Atmel SMART™

Atmel | SMART SAM3A ARM Cortex-M3 Based Microcontrollers

Product

CPU

Flash (Kbytes)

SRAM (Kbytes)

USB Transceiver

USB Speed

USB Interface

QTouch Channels

Quadrature Decoder Channels

SPI

TWI (12C)

UART

CAN

LIN

SSC

SD / eMMC

Timers

Output Compare channels

Input Capture Channels

PWM Channels

Ext Interrupts

ATSAM3A4C Cortex-M3 256 64

1 Hi-Speed Host, Device 31 2 4 2 4 2 3 1 1 9 9 9 8 63

ATSAM3A8C Cortex-M3 512 96

1 Hi-Speed Host, Device 31 2 4 2 4 2 3 1 1 9 9 9 8 63

Atmel | SMART SAM3U ARM Cortex-M3 Based Microcontrollers

Product	CPU	Flash (Kbytes)	SRAM (Kbytes)	USB Transceiver	USB Speed	USB Interface	Q Touch Channels	Quadrature Decoder Channels	SPI	TWI ( ^ )	UART	SSC	SD / eMMC	Timers	Output Compare channels	Input Capture Channels	PWM Channels
ATSAM3U1C	Cortex-M3	64	20	1	Hi-Speed	Device	28	1	4	1	4	1	1	3	3	3	4
ATSAM3U1E	Cortex-M3	64	20	1	Hi-Speed	Device	32	1	5	2	5	1	1	3	3	3	4
ATSAM3U2C	Cortex-M3	128	36	1	Hi-Speed	Device	28	1	4	1	4	1	1	3	3	3	4
ATSAM3U2E	Cortex-M3	128	36	1	Hi-Speed	Device	32	1	5	2	5	1	1	3	3	3	4
ATSAM3U4C	Cortex-M3	256	52	1	Hi-Speed	Device	28	1	4	1	4	1	1	3	3	3	4
ATSAM3U4E	Cortex-M3	256	52	1	Hi-Speed	Device	32	1	5	2	5	1	1	3	3	3	4

Atmel | SMART SAM3X ARM Cortex-M3 Based Microcontrollers

Product	CPU	Flash (Kbytes)	SRAM (Kbytes)	USB Transceiver	USB Speed	USB Interface	QTouch Channels	Quadrature Decoder Channels	SPI	TWI ( ^12C )	UART	CAN	LIN	SSC	Ethernet	SD / eMMC	Timers	Output Compare channels	Input Capture Channels	PWM Channels
ATSAM3X4C	Cortex-M3	256	64	1	Hi-Speed	Host	31	2	4	2	4	2	3	1	1	1	9	6	6	8
ATSAM3X4E	Cortex-M3	256	64	1	Hi-Speed	Host	32	2	4	2	5	2	3	1	1	1	9	3	3	8
ATSAM3X8C	Cortex-M3	512	96	1	Hi-Speed	Host	31	2	4	2	4	2	3	1	1	1	9	6	6	8
ATSAM3X8E	Cortex-M3	512	96	1	Hi-Speed	Host	32	2	4	2	5	2	3	1	1	1	9	3	3	8

Atmel Flash Microcontrollers

Product Portfolio

16 12 1000 2 12 Yes Yes Yes Yes Yes 84 63 100 18/3.3 162 to 36 LQFP 100, LFBGA 100 -40 to +85	ADC channels
	ADC Resolution (bits)
	ADC Speed (ksps)
	DAC Channels
	DAC Resolution (bits)
	Temp. Sensor
	32kHz RTC
	Calibrated RC Oscillator
	Clock Speed (MHz)
	Max I/O Pins
	Pin Count
	I/O Supply Class (V)
	Vcc Range (V)
	Green Packages
	Temp. Range (°C)

57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Ext Interrupts
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	ADC channels
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	ADC Resolution (bits)
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	ADC Speed (ksps)
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	External Bus Interface
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	NAND Interface
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	32kHz RTC
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Calibrated RC Oscillator
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Clock Speed (MHz)
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Max I/O Pins
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Pin Count
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	I/O Supply Class
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Operating Voltage (Vcc)
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Packages
57 8 12 1000 1 Yes Yes Yes 96 57 100 1.8/3.3 1.62 to 3.6 LQFP 100, TFBGA 100 -40 to 85	Temp. Range (°C)

63	Ext Interrupts
16	ADC channels
12	ADC Resolution (bits)
1000	ADC Speed (ksps)
2	DAC Channels
12	DAC Resolution (bits)
Yes	Temp. Sensor
1	External Bus Interface
Yes	NAND Interface
Yes	32kHz RTC
Yes	Calibrated RC Oscillator
84	Clock Speed (MHz)
63	Max I/O Pins
100	Pin Count
144	I/O Supply Class
18/3.3	Vcc Range (MHz)
162 to 3.6	LOFP 100, LFBGA 100
100	Green Packages
18/3.3	LQFP 144, LFBGA 144
162 to 3.6	-40 to +85
100	-40 to +85
162 to 3.6	-40 to +85

Atmel AVR

AVR UC3 32-bit Microcontrollers

Product	Flash (KBytes)	SRAM (Bytes)	USART	SPI (4 Slave CS)	TWI (I2C)	CAN	Ethernet MAC	SD/MMC	USB Hi-Speed	USB Full Speed	USB Host/OTG	HW capacitive touch	QTouch channels	IPS	ABDAC (Audio Bitstream DAC)	10-bit A/D (Channels)	12-bit A/D (Channels)	DAC	Analog Comparator
AT32UC3A0128 128 32K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A0256 256 64K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A0512 512 64K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A1128 128 32K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A1256 256 64K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A1512 512 64K 4 2 1 -- 1 --- Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A364 64 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A3128 128 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A3256 256 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A364S 64 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --
AT32UC3A3128S 128 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --								Yes	Yes	Yes	Yes	--	32	1	Yes	8	--	--	--
AT32UC3A3256S 256 128K 4 2 2 --- Yes Yes Yes Yes -- 32 1 Yes 8 --- --								Yes	Yes	Yes	Yes	--	32	1	Yes	8	--	--	--
AT32UC3A464 64 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --
AT32UC3A4128 128 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --
AT32UC3A4256 256 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --
AT32UC3A464S 64 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --
AT32UC3A4128S 128 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --								Yes	Yes	Yes	Yes	--	35	1	Yes	8	--	--	--
AT32UC3A4256S 256 128K 4 2 2 --- Yes Yes Yes Yes -- 35 1 Yes 8 --- --								Yes	Yes	Yes	Yes	--	35	1	Yes	8	--	--	--
AT32UC3B064 64 16K 3 1 1 --- --- Yes Yes -- 32 1															-- 8 --- ---
AT32UC3B0128 128 32K 3 1 1 --- --- Yes Yes Yes -- 32 1								--	--	Yes	Yes	--	32	1	--	8	--	--	--
AT32UC3B0256 256 32K 3 1 1 --- --- Yes Yes Yes -- 32 1								--	--	Yes	Yes	--	32	1	--	8	--	--	--
AT32UC3B0512 512 96K 3 1 1 --- --- Yes Yes Yes -- 32 1 --- --								--	--	Yes	Yes	--	32	1	--	8	--	--	--
AT32UC3B164 64 16K 2 1 1 --- --- Yes Yes --- 32 --- 6 --- --
AT32UC3B1128 128 32K 2 1 1 --- --- Yes Yes --- 32 --- --								--	--	Yes	--	--	32	--	--	6	--	--	--
AT32UC3B1256 256 32K 2 1 1 --- --- Yes Yes --- 32 --- --								--	--	Yes	--	--	32	--	--	6	--	--	--
AT32UC3B1512 512 96K 2 1 1 --- --- Yes Yes --- 32 --- --								--	--	Yes	--	--	32	--	--	6	--	--	--
AT32UC3C064C 64 16K 5 2 3 2 1 --- --- Yes Yes Yes --- -- 1 --- -- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C0128C 128 32K 5 2 3 2 1 --- --- Yes Yes Yes --- -- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C0256C 256 64K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C0512C 512 64K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C164C 64 16K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C1128C 128 32K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C1256C 256 64K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C1512C 512 64K 5 2 3 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	16	2	4
AT32UC3C264C 64 16K 4 1 2 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
AT32UC3C2128C 128 32K 4 1 2 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
AT32UC3C2256C 256 64K 4 1 2 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
AT32UC3C2512C 512 64K 4 1 2 2 1 --- --- Yes Yes Yes --- 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
ATUC64D3 64 16K 3 1 1 --- --- Yes Yes Yes Yes 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
ATUC128D3 128 16K 3 1 1 --- --- Yes Yes Yes Yes 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
ATUC64D4 64 16K 3 1 1 --- --- Yes Yes Yes Yes 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2
ATUC128D4 128 16K 3 1 1 --- --- Yes Yes Yes Yes 32 1 --- 16 2 4								--	--	Yes	Yes	--	--	1	--	--	11	1	2

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.
(b) Voltage supply: 3.0 - 3.6V or 4.5 - 5.5V.

Atmel Flash Microcontrollers

Product Portfolio

16-bit Timer/Counters	PWM (Channels)	RTC/ 32 KHz oscillator	Crystal oscillator	PLL	DFLL	Memory Protection Unit	Secure Access Unit	FlashVault*	Crypto (256-bit AES)	picoPower	I/O	Vcc Range (V)	Clock Speed (MHz)	Green Packages (a)	Temp. Range
6 13 Yes 2 2 -- Yes -- --- 109 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
6 13 Yes 2 2 -- Yes -- --- 109 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
6 13 Yes 2 2 -- Yes -- --- 109 3.0 - 3.6 56 LQFP144, TFBGA144 -40°C to +85°C
6 13 Yes 2 2 -- Yes -- --- 69 3.0 - 3.6 66 TQFP100 -40°C to +85°C
6 13 Yes 2 2 -- Yes -- --- 69 3.0 - 3.6 66 TQFP100 -40°C to +85°C
6 13 Yes 2 2 -- Yes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
6 12 Yes 2 2 -- Yes -- --- 110 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
6 12 Yes 2 2 -- Yes -- --- 110 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
3 12 Yes 2 2 -- Yes -- --- 110 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
3 12 Yes 2 2 -- Yes -- --- Yes -- 110 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
3 12 Yes 2 2 -- Yes -- --- Yes -- 110 3.0 - 3.6 66 LQFP144, TFBGA143 -40°C to +85°C
3 12 Yes 2 2 -- Yes -- --- Yes -- 110 3.0 - 3.6 66 LQFP144, TFBGA144 -40°C to +85°C
313 Yes 2 2 -- Yes -- --- 83 3.0 - 3.6 66 VFBGA100 -40°C to +85°C
3 13 Yes 2 2 -- Yes -- --- 83 3.0 - 3.6 66 VFBGA100 -40°C to +85°C
3 13 Yes 2 2 -- Yes -- --- 83 3.0 - 3.6 66 VFBGA100 -40°C to ++85°C
3 13 Yes 2 2 -- Yes -- --- Yes -- 83 3.0 - 3.6 66 VFBGA100 -40°C to +85°C
7 13 Yes 2 2 -- Yes -- --- Yes -- 83 3.0 - 3.6 66 VFBGA100 -40°C to +85°C
7 13 Yes 2 2 -- Yes -- --- Yes -- 83 3.0 - 3.6 66 VFBGA100 --40°C to +85°C
7 13 Yes 2 2 -- Yes -- --- 44 3.0 - 3.6 60 TQFP64, QFN64 -40°C to +85°C
7 13 Yes 2 2 -- Yes -- --- 44 3.0 - 3.6 60 TQFP64, QFN64 -40°C to +85°C
7 13 Yes 2 1 -- Yes -- --- 44 3.0 - 3.6 60 TQFP64, QFN64 -40°C to +85°C
7 13 Yes 1 2 -- Yes -- --- 28 3.0 - 3.6 60 TQFP48, QFN48 -40°C to +85°C
7 13 Yes 1 2 -- Yes -- --- 28 3.0 - 3.6 60 TQFP48, QFN48														-40°C to +85°C
7 13 Yes 1 2 -- Yes -- --- 28 3.0 - 3.6 60 TQFP48, QFN48 -40°C to +85°C
7 13 Yes 1 2 -- Yes -- --- 28 3.0 - 3.6 60 TQFPP48, QFN48 -40°C to +85°C
7	20	Yes	2	2	--	Yes	Yes	Yes	--	--	123	3.0 - 5.5(b)	66	LQFP144	-40°C to +85°C
7	20	Yes	2	2	--	Yes	Yes	Yes	--	--	123	3.0 - 5.5(b)	66	LQFP144	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	123	3.0 - 5.5(b)	66	LQFP144	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	123	3.0 - 5.5(b)	66LQFP144	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	81	3.0 - 5.5(b)	66	TQFP100	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	81	3.0 - 5.5(b)	66	TQFP100	-40°C to +85°C
6	20	Yes	2	2	--	Yes	Yes	Yes	--	--	81	3.0 - 5.5(b)	66	TQFP100	-40°C to +85°C
6	20	Yes	2	2	--	Yes	Yes	Yes	--	--	81	3.0 - 5.5(b)	66	TqFP100	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	45	3.0 - 5.5(b)	66	TQFP64	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	45	3.0 - 5.5(b)	66	TQFP64	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	45	3. 0 - 5.5(b)	66	TQFP64	-40°C to +85°C
3	20	Yes	2	2	--	Yes	Yes	Yes	--	--	45	3.0 - 5.5(b)	66	TQFP64	-40°C to +85°C
3	7	Yes	1	2	--	--	--	--	--	--	51	3.0 - 3.6	48	TQFP64, VQFN64	-40°C to +85°C
3	7	Yes	1	2	--	--	--	--	--	--	51	3.0 - 3.6	48	TQFP64, VQFN64	-40°C to +85°C
3	7	Yes	1	2	--	--	--	--	--	--	35	3.0 - 3.6	48	TQFP48, VQFN48	-40°C to +85°C
3	7	Yes	1	2	--	--	--	--	--	--	35	3.0 - 3.6	48	TQFP48, VQFN48	-40°C to +85°C

Atmel AVR

AVR UC3 32-bit Microcontrollers - Continued

Product

Flash (KBytes)

SRAM (Bytes)

USART

SPI (4 Slave CS)

TWI ( ^12C )

CAN

Ethernet MAC

SD/MMC

USB Hi-Speed

USB Full Speed

USB Host/OTG

HW capacitive touch

QTouch channels

iPS

ABDAC (Audio Bitstream DAC)

10-bit A/D (Channels)

12-bit A/D (Channels)

DAC

Analog Comparator

AT32UC3L016 16 8K

4 1 2 --

-- -- --

Yes --

-- -- 8 -- 8

AT32UC3L032 32 16K

4 1 2 --

-- -- --

Yes --

-- -- 8 -- 8

AT32UC3L064 64 16K

4 1 2 --

-- -- --

Yes --

-- -- 8 -- 8

AT32UC3L0128 128 32K

4 1 2 --

-- -- --

Yes --

-- -- 8 -- 8

AT32UC3L0256 256 32K

4 1 2 --

-- -- --

Yes --

-- -- 8 -- 8

ATUC64L3U 64 16K

4 1 2 --

-- -- --

Yes --

Yes 25

1 Yes -- 8 -- 8

ATUC128L3U

128 32K

4 1 2 --

-- -- --

Yes --

Yes 25

1 Yes -- 8 -- 8

ATUC256L3U

256 32K

4 1 2 --

-- -- --

Yes --

Yes 25

1 Yes -- 8 -- 8

ATUC64L4U 64 16K

4 1 2 --

-- -- --

Yes --

Yes 17 --

-- -- 8 -- 8

ATUC128L4U

128 32K

4 1 2 --

-- -- --

Yes --

Yes 17 --

-- -- 8 -- 8

ATUC256L4U

256 32K

4 1 2 --

-- -- --

Yes --

Yes 17 --

-- -- 8 -- 8

(a) Pb-free packaging complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also halide free and fully green.

(b) Voltage supply: 3.0 - 3.6V or 4.5 - 5.5V.

Atmel Flash Microcontrollers

Product Portfolio

16-bit Timer/Counters

PWM (Channels)

RTC/ 32 KHz oscillator

Crystal oscillator

PLL

DFLL

Memory Protection Unit

Secure Access Unit

FlashVault"

Crypto (256-bit AES)

picoPower

I/O

Vcc Range (V)

Clock Speed (MHz)

Green Packages (a)

Temp. Range

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.62 - 3.6 50 TQFP48, QFN48, TLLGA48 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.62 - 3.6 50 TQFP48, QFN48, TLLGA48 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.63 - 3.6 50 TQFP48, QFN48, TLLGA48 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.62 - 3.6 50 TQFP48, QFN48, TLLGA48 -30°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.62 - 3.6 50 TQFP48, QFN48, TLLGA48 -40°C to +85°C

36 Yes 1 -- 2 Yes Yes Yes -- Yes 51 1.62 - 3.6 50 TQFP64, QFN64 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 51 1.62 - 3.6 50 TQFP64, QFN64 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 51 1.62 - 3.6 50 TQF64, QFN64 -40°C to +85°C

6 36 Yes 1 -- 2 Yes Yes Yes -- Yes 36 1.62 - 3.6 50 TQFP48, QFN48, TLLGA48 -40°C to +85°C

Atmel®

Atmel | SMART and AVR Wireless Solutions

Product

Flash (KBytes)

EEPROM (KBytes)

SRAM (KBytes)

ISM Band

Sensitivity (dBm)

Output Power (dBm)

Vcc (V) Range

Clock Speed (MHz)

Green Package

Temp. Range(°C)

Data Rate (kbps)

AES

Antenna Diversity

Application Areas

Low Level/ Peer-Peer

ZigBee RF4CE

ZigBee PRO

ATmega128RFA1 128

4 16

2.4 GHz

-100

-17 to +3.5

1.8-3.6

16 QFN64

-40 to +85-40 to +125

2 Mb x x x x x

ATmega64RFR2 64 2

8

2.4 GHz

-100

17 to +3.5

1.8-3.6

16 QFN64

-40 to +85-40 to +125

2 Mb x x x x -

ATmega644RFR2 64 2

8

2.4 GHz

-100

17 to +3.5

1.8-3.6

16 QFN48

-40 to +85-40 to +125

2 Mb x x x x

ATmega128RFR2 128

4

16

2.4 GHz

-100

17 to +3.5

1.8-3.6

16 QFN64

-40 to +85-40 to +125

2 Mb x x -- x

ATmega1284RFR2 128

4

16

2.4 GHz

-100

17 to +3.5

1.8-3.6

16 QFN48

-40 to +85-40 to +125

2 Mb x x -- x

ATmega256RFR2 256

8

32

2.4 GHz

-100

-17 to +3.5

1.8-3.6

16 QFN64

-40 to +85-40 to +125

2 Mb x x -- x

ATmega2564RFR2 256

8

32

2.4 GHz

-100

-17 to +3.5

1.8-3.6

16 QFN48

-40 to +85-40 to +125

2 Mb x x -- x

AT86RF212B

-

-

-

700/800/900 MHz

-110

-10 to +10

1.8-3.6

-

QFN32

-40 to +85

1 Mb

x

x

x

-

x

AT86RF230

-

-

-

2.4 GHz

-101

-17 to +3

1.8-3.6

-

QFN32

-40 to +85

250

-

-

x

-

-

AT86RF231

-

-

-

2.4 GHz

-101

-17 to +3

1.8-3.6

-

QFN32

-40 to +85-40 to +125

2 Mb x x - x x

AT86RF232

-

-

-

2.4 GHz

-100

-17 to +3

1.8-3.6

-

QFN32

0 to +70

250

x

x

x

x

-

AT86RF233

-

-

-

2.4 GHz

-101

-17 to +4

1.8-3.6

-

QFN32

-40 to +85

2 Mb

x

x

-

-

x

Atmel Flash Microcontrollers

Product Portfolio

Atmel Tools

Design Software
Product Description

Atmel Studio Integrated development platform (IDP) for developing and debugging embedded Atmel AVR and Cortex-M based applications

Debuggers
Product Description

SAM-ICETM JTAG emulator for Atmel ARM processor-based microcontrollers

Atmel-ICE Mid-range in-system debugger for Atmel AVR 8- and 32-bit microcontrollers. 3 feature options available

AVR ONE! High-end in-system debugger for Atmel AVR 8- and 32-bit microcontrollers

Atmel®

Atmel Tools - Continued

Evaluation Kits
Product Description
SAM C21 Xplained Pro For evaluation and prototyping with Atmel SAM C20 and C21 Cortex-M0+ microcontrollers. Ordering code: ATSAMC21-XPRO
SAM D20 Xplained Pro	For evaluation and prototyping with Atmel SAM D20 Cortex-M0+ microcontrollers. Ordering code: ATSAMD20-XPRO
SAM D21 Xplained Pro	For evaluation and prototyping with Atmel SAM D21 Cortex-M0+ microcontrollers. Ordering code: ATSAMD21-XPRO
ATSAM3N-EK Evaluation kit for Atmel SAM3N Cortex-M3 microcontrollers
ATSAM3S-EK2 Evaluation kit for Atmel SAM3S and ATSAM3SD Cortex-M3 microcontrollers
ATSAM3U-EK Evaluation kit for Atmel SAM3U Cortex-M3 microcontrollers
ATSAM3X-EK Evaluation kit for Atmel SAM3X and SAM3A Cortex-M3 microcontrollers
ATSAM4L-EK Evaluation kit for Atmel SAM4L Cortex-M4 microcontrollers
SAM4L Xplained Pro For evaluation and prototyping with Atmel SAM4L Cortex-M4 microcontrollers. Available as evaluation kit or starter kit.
SAM L21 Xplained Pro For evaluation and prototyping with Atmel SAM L21 Cortex-M0+ microcontrollers. Ordering code: ATSAML21-XPRO-B

Atmel Flash Microcontrollers

Product Portfolio

Atmel Tools - Continued

Evaluation Kits
Product Description
SAM L22 Xplained Pro For evaluation and prototyping with Atmel SAM L22 Cortex-M0+ microcontrollers. Ordering code: ATSAML22-XPRO
SAM G55 Xplained Pro For evaluation and prototyping with Atmel SAM G55 Cortex-M4F microcontrollers. Ordering code: ATSAMG55-XPRO
ATSAM4E-EK Evaluation kit for Atmel SAM4E Cortex-M4 microcontrollers
SAM V71 Xplained Ultra Evaluation Kit	For evaluation and prototyping with Atmel SAM V71, SAM V70, SAM S70 and SAM E70 ARM Cortex-M7 microcontrollers.Ordering code: ATSAMV71-XULT.
ATSAM4S-EK2 Evaluation kit for Atmel SAM4S Cortex-M4 microcontrollers
SAM4S Wireless PIR Camera Reference Design Kit	Reference design kit for a low-cost, powerful passive infrared motion detector camera solution based on Atmel SAM4S Cortex-M4 microcontrollers
SAM4S Xplained Evaluation platform for Atmel SAM4S Cortex-M4 microcontrollers featuring a SAM4S16C and additional components demonstrating the features of the device
SAM4S Xplained Pro For evaluation and prototyping with Atmel SAM4S Cortex-M4 microcontrollers.Available as evaluation kit or starter kit.
SAM4N Xplained Pro For evaluation and prototyping with Atmel SAM4N Cortex-M4 microcontrollers.Available as evaluation kit or starter kit.
ATMEGA-1284P Xplained	MCU board for Atmel megaAVR featuring an ATmega1284P and additional components demonstrating the features of the device

Atmel®

Atmel Tools - Continued

Evaluation Kits
Product Description
XMEGA-A1 Xplained MCU board for Atmel AVR XMEGA featuring an ATxmega128A1 and additional components demonstrating the features of the device
XMEGA-A3BU Xplained MCU board for Atmel AVR XMEGA featuring an ATxmega256A3BU and additional components demonstrating the features of the device
XMEGA-B1 Xplained MCU board for Atmel AVR XMEGA featuring an ATxmega128B1 and additional components demonstrating the features of the device
UC3-L0 Xplained MCU board for AVR UC3L featuring an AT32UC3L064 and additional components demonstrating the features of the device
UC3-A3 Xplained MCU board for Atmel AVR UC3A3 featuring an AT32UC3A3256 and additional components demonstrating the features of the device
AVRSBIN1 Inertial One sensor board. Add-on board for Atmel AVR Xplained Kits
AVRSBIN2 Inertial Two sensor board. Add-on board for Atmel AVR Xplained Kits
AVRSBPR1 Pressure One sensor board. Add-on board for Atmel AVR Xplained Kits
AVRSBLP1 Light and proximity sensor board. Add-on board for Atmel AVR Xplained Kits

Atmel Flash Microcontrollers

Product Portfolio

Atmel Tools - Continued

Evaluation Kits
Product Description
EVK1101 Evaluation kit for Atmel AVR UC3B 32-bit microcontrollers
EVK1104 The evaluation kit combines an Atmel 32-bit AVR UC3 microcontroller with a wide selection of communication interfaces, including On-The-Go, SD card and MMC, NAND flash with ECC, and stereo 16-bit DAC.
EVK1105 The evaluation kit combines an Atmel 32-bit AVR UC3 microcontroller with a wide selection of communication interfaces, including On-The-Go, SD card and MMC, QVGA full color LCD display, light sensor and microphone.
UC3C-EK Evaluation kit for the Atmel AVR UC3C 32-bit microcontrollers
UC3L-EK Evaluation kit for Atmel AVR UC3L 32-bit microcontrollers
ATAVRSB200 Battery management development kit for Atmel AVR HVA and HVB devices
ATAVRSB201 Battery management add-on board for SB200, supporting one or two cell designs based on ATmega16HVA
ATAVRSB202 Battery management add-on board for SB200, supporting two, three or four cell designs based on ATmega32HVB
ATBM302-EK Evaluation kit demonstrating the functionality and performance of the ATBM302 battery management device.

Atmel®

Atmel Tools - Continued

Evaluation Kits
Product Description
RF4CE-EK Demonstrates Atmel RF4Control - ZigBee RF4CE compliant software stack-in combination with the 2.4GHz single-chip solution ATmega128RFA1
REB231ED-EK Evaluation kit and reference design for the Atmel AT86RF231 2.4GHzradio transceiver
REB231FE2-EK Evaluation kit and reference design for Atmel AT86RF231 2.4GHz radiotransceiver with front end module
RF231USB-RD Reference design for the Atmel AT86RF231 and ATSAM3S4BA USBdemonstrating RF and USB capabilities
REB232ED-EK Evaluation kit and reference design for the Atmel AT86RF232 2.4GHzradio transceiver
REB233SMAD-EK Evaluation kit and reference design for the Atmel AT86RF233 2.4GHzradio transceiver
ATmega128RFA1-EK Evaluation kit for the Atmel ATmega128RFA1 2.4GHz single-chip solution
AT256RFR2-EK Evaluation kit for the ATmega256RFR2 2.4GHz single-ship solution
RZ600 Evaluation kit for development, debugging, and demonstration of IEEE802.15.4-compliant wireless applications

Atmel Flash Microcontrollers

Product Portfolio

Atmel Tools - Continued

Starter Kits
Product Description
STK600 Starter kit for Atmel AVR 8- and 32-bit microcontrollers
AT89STK-05 Starter Kit for the AT89C5130A/AT89C5131A USB microcontrollers
AT89STK-06 Starter Kit for the AT89C51CC01/AT89C51CC03 CAN microcontrollers
AT89STK-11 Starter Kit for ISP-standard Flash C51 MCUs:• AT89C51RB2/RC2/IC2 • AT89C51RD2/ED2/ID2 • AT89C51RE2• AT89LP51RB2/RC2/IC2 • AT89LP51RD2/ED2/ID2

Atmel

Enabling Unlimited Possibilities®

Atmel Corporation

1600 Technology Drive, San Jose, CA 95110 USA

T: (+1)[phone]

F: (+1)[phone]

www.atmel.com

© 2015 Atmel Corporation. / Rev: Atmel-4099U-832bit-MCU-ProductGuide_E_US_092015

Atmel, ^8 Atmel logo and combinations thereof, Enabling Unlimited Possibilities, ^9 and others are registered trademarks or trademarks of Atmel Corporation in U.S. and other countries. ARM, ^10 ARM Connected ^11 logo and others are the registered trademarks or trademarks of ARM Ltd. Other terms and product names may be trademarks of others.

Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND CONDITIONS OF SALES LOCATED ON THE ATMEL WEBSITE. ATMEL ASSUMES NO LIABILITY WHAT SOVER AND DISCLAIMS ANY EXPRESS IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTY OF MERCHANTABILITY. FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY DIRECT INDIRECT. CONSEQUENTIAL PUNITIES, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS AND PROFITS, BUSINESS IN HRUPTION, CH LOSSES OF INFORMATION), ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IT AIMIL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and products descriptions as any time without notice. Atmel does not make any commitment to update the information contained herein. Unless specifically provided otherwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel products are not intended, authorized, or warranted for use as components in applications intended to support or sustain life.
