Product Type	Matrix Transmitter for HDMI over Cat5/6
Brand	Tripp Lite
Model	BHDBT-T-SI-4X4
Power Supply	External power supply (included)
HDMI Inputs	4
HDMI Outputs	4
RS-232 Control	Full-duplex, up to 3 Mbps
IR Control	39 kHz frequency; IR extension cable included
Audio Support	7.1-channel surround, DTS-HD, Dolby TrueHD
EDID / HDCP	EDID and HDCP compatible
Maximum Resolution	Up to 4K (distance depends on receiver and cabling; e.g., 130 ft over Cat6a with compatible receiver)
Supported Cabling	Cat5e, Cat6, Cat6a (24 AWG solid wire recommended)
Mounting	Wall, rack, or pole; hardware included
Warranty	1-year limited
Plug and Play	Yes, no additional software required

Frequently Asked Questions - BHDBT-T-SI-4X4 Tripp Lite

How do I connect multiple receivers to the BHDBT-T-SI-4X4?

Each of the four RJ45 outputs can be connected to a compatible receiver (e.g., BHDBT-R-SI) using Cat5e/6/6a cable. The matrix transmitter supports up to four separate HDMI sources distributed to four displays.

What is the maximum distance for 4K video?

The maximum distance depends on the receiver and cabling. For example, with a BHDBT-R-SI-LR and Cat6a cable, 4K distance is up to 328 ft (100 m). For 1080p, the distance can be longer.

Can I use this transmitter with a BHDBT-R-SI receiver?

Yes, the BHDBT-T-SI-4X4 is compatible with all BHDBT series receivers, including BHDBT-R-SI, BHDBT-R-SI-ER, and BHDBT-R-SI-LR. The maximum distance achieved will be determined by the receiver used.

How do I control the matrix via RS-232?

Connect a 3.5mm to DB9 adapter to the RS-232 port, then connect to a computer. Use terminal emulation software with settings: Baud Rate 57600, Data 8 bit, Parity none, Stop 1 bit, Flow Control none. Commands like sw1 A switch source A to output 1.

What IR frequency does the system use?

The system uses a 39 kHz IR frequency. It includes IR-IN and IR-OUT cables for extending remote control signals from the source location to the display location.

Does the BHDBT-T-SI-4X4 support 3D video?

Yes, it is 3D compatible, along with EDID and HDCP support.

Can I daisy-chain multiple transceivers in the installation?

Yes, up to five transceivers (e.g., BHDBT-TR-SI) can be connected in a chain between the transmitter and receiver. Each transceiver can have a monitor connected, and the last unit must be a receiver.

What type of cable is recommended for best performance?

For maximum distance and performance, use 24 AWG solid wire Cat5e/6 or 23 AWG solid wire Cat6a cable. Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire. Avoid higher gauge cables like 26 AWG.

How do I switch between sources on a specific output?

Use the included remote control or the physical switches on the unit. Press the button corresponding to the output (e.g., button 1 for output 1) to cycle through sources A, B, C, D. Alternatively, use RS-232 commands.

What should I do if there is no video output?

Ensure all power supplies are connected and devices are powered on. Check that the correct input source is selected. Verify cables are properly seated and undamaged. Test with a different source or display. If using HDMI cables longer than 6 ft (for 28 AWG) or 16 ft (for 24 AWG) with 4K, try shorter cables.

USER MANUAL BHDBT-T-SI-4X4 Tripp Lite

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a \$50 value!

www.tripplite.com/warranty

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Copyright © 2015 Tripp Lite. All rights reserved.

All trademarks are the sole property of their respective owners.

Table of Contents

Package Contents 2

Product Features 3

Optional Accessories 5

Mounting Instructions 5

Installation

6

Standard Extender Kit Installation 6

Extender Kit with Transceiver Installation 8

Matrix Transmitter Installation 10

RS-232 Serial Control (Matrix Transmitter Units Only) 13

Troubleshooting

14

Warranty and Product Registration 15

Regulatory Compliance 16

Package Contents

	BHDBT-K-SI	BHDBT-K-SI-ER	BHDBT-K-SI-LR	BHDBT-T-SI-4X4	BHDBT-T-SI-4X2	BHDBT-TR-SI	BHDBT-TR-SI-ER	BHDBT-TR-SI-LR	BHDBT-R-SI	BHDBT-R-SI-ER	BHDBT-R-SI-LR
Transmitter (T), Transceiver (TR), Receiver (R), Kit (K)	K	K	K	T	T	TR	TR	TR	R	R	R
External Power Supply (1, 2)	2	2	2	1	1	1	1	1	1	1	1
IR-In Cables (0, 1, 2)	1	1	1	0	0	0	0	0	1	1	1
IR-Out Cables (0, 1, 2)	1	1	1	0	0	0	0	0	1	1	1
Remote Control	N	N	N	Y	Y	N	N	N	N	N	N
IR Extension Cable	0	0	0	1	1	0	0	0	0	0	0
3.5 mm to DB9 M/F Adapter Cable	1	1	1	1	1	0	0	0	1	1	1
3.5 mm to DB9 M/M Adapter Cable	1	1	1	0	0	0	0	0	1	1	1
Mounting Hardware	YY	YYY	YYY	YYY	Y
Owner's Manual	YY	YYY	YYY	YYY	Y

Product Features

• Extends HDMI audio/video, RS-232 Serial and IR Control Signals over Cat5/6 cabling.
  • Supports 7.1-channel surround sound, DTS-HD and Dolby True HD audio.
  • Uses a 39 KHz IR frequency.
  • Supports RS-232 Serial full-duplex baud rates up to 3 Mbps.
  • EDID, HDCP and 3D compatible.
• Includes mounting hardware that allows unit to be wall-mounted, rack mounted or pole mounted.
• Matrix transmitter units allow multiple HDMI inputs to be connected and distributed among multiple outputs.
• Transceiver units extend and expand your installation, allowing for multiple monitor connections at different points in a chain. Up to five (5) transceivers and one (1) receiver can be connected in a chain, with each unit being able to extend its maximum distance from the previous unit (see the table below for details on maximum distances supported).
• Plug and play; no software or drivers required.

Product Features

Model	Unit Type	4K Max Distance - Cat6a	4K Max Distance - Cat5e / Cat6	1080p Max Distance - Cat6a	1080p Max Distance - Cat5e / Cat6	Compatible Models
A. BHDBT-K-SI	Kit 130 ft.	(40 m)	115 ft.(35 m)	230 ft.(70 m)	200 ft.(60 m)	F
B. BHDBT-K-SI-ER	Kit N/A N/A			500 ft.(150 m)	500 ft.(150 m)	G
C. BHDBT-K-SI-LR	Kit	328 ft.(100 m)	230 ft.(70 m)	328 ft.(100 m)	328 ft.(100 m)	H
D. BHDBT-T-SI-4X4	Matrix Transmitter	Install Based*	Install Based*	Install Based*	Install Based*	F, G, H, I,J, K
E. BHDBT-T-SI-4X2	Matrix Transmitter	Install Based*	Install Based*	Install Based*	Install Based*	F, G, H, I,J, K
F. BHDBT-TR-SI	Transceiver 1	30 ft.(40 m)	115 ft.(35 m)	230 ft.(70 m)	200 ft.(60 m)	A, D, E, I
G. BHDBT-TR-SI-ER	Transceiver N	N/A N/A		500 ft.(150 m)	500 ft.(150 m)	B, D, E, J
H. BHDBT-TR-SI-LR	Transceiver	328 ft.(100 m)	230 ft.(70 m)	328 ft.(100 m)	328 ft.(100 m)	C, D, E, K
I. BHDBT-R-SI	Receiver 130	ft.(40 m)	115 ft.(35 m)	230 ft.(70 m)	200 ft.(60 m)	D, E, F
J. BHDBT-R-SI-ER	Receiver N/A	N/A		500 ft.(150 m)	500 ft.(150 m)	D, E, G
K. BHDBT-R-SI-LR	Receiver	328 ft.(100 m)	230 ft.(70 m)	328 ft.(100 m)	328 ft.(100 m)	D, E, H

* The BHDBT-T-SI-4X4 and BHDBT-T-SI-4X2 are compatible with all transceiver and receiver units. The max distance that can be achieved will be determined by the transceiver and/or receiver being used.

Optional Accessories

• N001-Series Cat5 Patch Cables
- N022-01K-GY Cat5 24 AWG Solid Wire Bulk Cable – 1,000 ft.
• N202-Series Cat6 24 AWG Solid Wire Patch Cables
• N222-01K-BL Cat6 24 AWG Solid Wire Bulk Cable – 1,000 ft.
- P520-006 RS232 Serial Extension Cable – 6 ft.
• P568-Series High Speed HDMI Cables

Mounting Instructions

The HDBaseT HDMI Over Cat5 / Cat6 Extender products come with mounting hardware that allows them to be mounted in a variety of ways. The following images show the different ways the included mounting brackets can be attached for different mounting methods.

Note: The images below show a B126-1A1 unit, but mounting is the same for the HDBaseT extender products.

Wallmount

19" rackmount Pole Mount

Pole Mount

Black electronic device with a gray circular strap and two ports, no visible text or symbols

Close-up of a black mechanical device with a base and mounting base (no visible text or symbols)

Installation

Standard Extender Kit Installation

Notes:

1. See the Product Features section of this manual for information on your model's maximum supported distances and resolutions.
2. Test to make sure the entire installation works properly before pulling cables through ceilings/walls.
3. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 or 23 AWG solid wire Cat6a cable. Using stranded wire cable or cable with a gauge (AWG) size higher than that recommended will result in a shorter extension distance. Higher gauge cabling such as 26 AWG has a more limited transmission capability than lower-gauge cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling. Extended lengths of 23 AWG solid wire Cat6a cable are available from Tripp Lite as a custom order.
4. When using a 28 AWG HDMI cable and displaying video resolutions higher than 1080p, the HDMI cables connecting the source and the monitor must not exceed 6 feet. When using a 24 AWG HDMI cable, you must not exceed a 16-foot length.
5. The transmitter and receiver included in each kit are compatible with each other only. You cannot mix and match transmitters and receivers from different kits. For example, a BHDBT-K-SI transmitter will not work with a BHDBT-K-SI-ER receiver.
6. Each kit includes one set of IR-IN and IR-OUT cables. It is up to the user to determine whether the cables will be used to extend an IR signal from the transmitter side to the receiver side, or the receiver side to the transmitter side. In most installations, the cables will be used to control the HDMI source (e.g., Blu-ray player) from the same location as the monitor connected to the receiver.

Installation

1. Make sure that the HDMI and RS-232 serial source is powered off.
2. Connect the HDMI source to the HDMI Input port on the local transmitter unit.
3. Connect the included 3.5 mm Male-to-DB9 female adapter cable to the RS-232 port on the local transmitter unit, then connect the computer to the adapter.
4. Connect the IR-IN cable to the IR-IN port on the local transmitter unit.

Note: The IR-IN unit accepts a signal from a remote control and sends it to a device that is controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.

1. Connect the IR-OUT cable to the IR-OUT port on the local transmitter unit.

Note: The IR-OUT unit receives the signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-Ray player, TV).

1. Connect the external power supply to the local transmitter unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).

2. Connect the RJ45 Output port on the local transmitter unit to the RJ45 Input port on the remote receiver unit using Cat5e/6/6a cable.

3. Connect the HDMI monitor to the HDMI Output port on the remote receiver unit.

4. Connect the included 3.5 mm male-to-DB9 male adapter cable to the RS-232 port on the remote receiver unit, then connect the RS-232 device to the adapter.

5. Connect the IR-IN cable to the IR-IN port on the remote receiver unit.

Note: The IR-IN unit accepts a signal from a remote control and sends it to a device controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.

1. Connect the IR-OUT cable to the IR-OUT port on the remote receiver unit.

Note: The IR-OUT unit receives the signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-ray player, TV).

1. Connect the external power supply to the remote receiver unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).

2. Turn on the power to the HDMI source and RS-232 serial source.

Installation

Extender Kit with Transceiver Installation

Notes:

1. The below installation diagram and instructions are for an HDBaseT HDMI over Cat5 Extender Kit installation, though installation will be similar if you purchase the transmitter and receiver units separately.
2. See the Product Features section of this manual for models compatible with your transceiver and for information on the maximum supported distances and resolutions for your model.

3. Although transceiver units transmit RS-232 serial and IR Control signals from the transmitter to the receiver, they do not feature their own RS-232 and IR Control ports.

4. Test to make sure the entire installation works properly before pulling cables through ceilings/walls.

5. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 or 23 AWG solid wire Cat6a cable. Using stranded wire cable or cable with a gauge (AWG) size higher than that recommended will result in a shorter extension distance. Higher gauge cabling such as 26 AWG has a more limited transmission capability than lower gauge cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling. Extended lengths of 23 AWG solid wire Cat6a cable is available from Tripp Lite as a custom order.

6. When using a 28 AWG HDMI cable and displaying video resolutions higher than 1080p, the HDMI cables connecting the source and the monitor must not exceed 6 feet. When using a 24 AWG HDMI cable, you must not exceed a 16-foot length.

7. Each kit includes one set of IR-IN and IR-OUT cables. It is up to the user to determine whether the cables will be used to extend an IR signal from the transmitter side to the receiver side, or the receiver side to the transmitter side. In most installations, the cables will be used to control the HDMI source (e.g., Blu-ray player) from the same location as the monitor connected to the receiver.

1. Make sure that the HDMI source and RS-232 serial source is powered off.
2. Connect the HDMI source to the HDMI Input port on the local transmitter unit.
3. Connect the included 3.5 mm male-to-DB9 female adapter cable to the RS-232 port on the local transmitter unit, then connect the computer to the adapter.

Installation

1. Connect the IR-IN cable to the IR-IN port on the local transmitter unit.
   Note: The IR-IN unit accepts a signal from a remote control and sends it to a device controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.
2. Connect the IR-OUT cable to the IR-OUT port on the local transmitter unit.
   Note: The IR-OUT unit receives a signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-ray player, TV).
3. Connect the external power supply to the local transmitter unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).
4. Connect the RJ45 Output port on the local transmitter unit to the RJ45 Input port on the transceiver unit using Cat5e/6/6a cable.
5. (Optional) Connect the HDMI monitor to the HDMI Output port on the transceiver unit.
6. Connect the external power supply to the transceiver unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).

Up to five transceiver units can be inserted in-between the transmitter and receiver units of your HDBaseT HDMI over Cat5 Extender Kit. To connect additional transceiver units, repeat steps 7 through 9. To complete your installation with a receiver unit, proceed to step 10.

1. Connect the RJ45 Output port on the last transceiver unit in the chain to the RJ45 Input port on the receiver unit using Cat5e/6/6a cable.
2. Connect the HDMI monitor to the HDMI Output port on the remote receiver unit.
3. Connect the included 3.5 mm male-to-DB9 male adapter cable to the RS-232 port on the remote receiver unit, then connect the RS-232 device to the adapter.
4. Connect the IR-IN cable to the IR-IN port on the remote receiver unit.

Note: The IR-IN unit accepts a signal from a remote control and sends it to a device controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.

1. Connect the IR-OUT cable to the IR-OUT port on the remote receiver unit.

Note: The IR-OUT unit receives the signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-ray player, TV).

1. Connect the external power supply to the remote receiver unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).
2. Turn on the power to the HDMI source and RS-232 serial source.

Installation

Matrix Transmitter Installation

Notes:

1. The below installation diagram and instructions are for a standard HDBaseT HDMI over Cat5 Matrix Transmitter installation. For instructions on adding transceivers to your installation, refer to the Extender Kit with Transceiver Installation section.
2. The installation diagram below shows a BHDBT-T-SI-4X2. Installation will be the same for the BHDBT-T-SI-4X4, except for the number of HDMI Output ports.
3. See the Product Features section of this manual for models compatible with your Matrix Transmitter and for information on your model's maximum supported distances and resolutions.
4. Test to make sure the entire installation works properly before pulling cables through ceilings/walls.
5. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 or 23 AWG solid wire Cat6a cable. Using stranded wire cable or cable with a gauge (AWG) size higher than that recommended will result in shorter extension distance. Higher gauge cabling such as 26 AWG has a more limited transmission capability than lower gauge cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling. Extended lengths of 23 AWG solid wire Cat6a cable is available from Tripp Lite as a custom order.
6. When using a 28 AWG HDMI cable and displaying video resolutions higher than 1080p, the HDMI cables connecting the source and the monitor must not exceed 6 feet. When using a 24 AWG HDMI cable, you must not exceed a 16-foot length.
7. Each receiver unit includes one set of IR-IN and IR-OUT cables. It is up to the user to determine whether the cables will be used to extend an IR signal from the transmitter side to the receiver side, or the receiver side to the transmitter side. In most installations, the cables will be used to control the HDMI source (e.g., Blu-ray player) from the same location as the monitor connected to the receiver.

Installation

1. Make sure that the HDMI source and RS-232 serial source is powered off.
2. (Optional) Connect the 3.5 mm male-to-DB9 female adapter cable included with the transmitter unit to the RS-232 port on the left rear of the unit, then connect the cable to the computer that will be serially controlling the unit.
3. (Optional) Connect the IR extension cable included with the transmitter unit to the 3.5 mm jack to the right of the RS-232 serial port mentioned in step 2. Position the cable's infrared sensor in an area that allows a direct line of sight between it and the remote control that came with the unit.
4. Connect the first HDMI source to the port on the switch marked Source A.
5. Repeat step 4 for each additional source you are connecting.
6. Connect the IR-IN cable included with the receiver unit to the IR-IN port on the local transmitter unit, starting with IR-IN Port A.

Note: The IR-IN unit accepts a signal from a remote control and sends it to a device controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.

1. Connect the IR-OUT cable included with the receiver unit to the IR-OUT port on the local transmitter unit, starting with IR-OUT Port A.

Note: The IR-OUT unit receives the signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-Ray player, TV).

1. There are four sets of IR-IN and IR-OUT ports which gives you the ability to remotely control each source and the monitor connected to the transmitter. Repeat steps 6 and 7 for each additional set of IR-IN and IR-OUT units you will be using.
2. Connect the 3.5 mm male-to-DB9 female adapter cable included with the receiver unit to RS-232 Port A, then connect the computer to the adapter.
3. There are four RS-232 ports that allow connection of an RS-232 device for each receiver unit connected to the transmitter. Repeat step 9 for each of the remaining RS-232 ports you will be using.
4. Connect the external power supply to the transmitter unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).
5. Connect the RJ45 port marked Output 1 on the transmitter unit to the RJ45 Input port on a receiver unit using Cat5e/6/6a cable.
6. Connect the HDMI monitor to the HDMI Output port on the receiver unit.

Installation

1. Connect the 3.5 mm male-to-DB9 female adapter cable included with the receiver unit to the RS-232 port on the receiver unit, then connect the RS-232 device to the adapter.
2. Connect the IR-IN cable included with the receiver unit to the IR-IN port on the remote receiver unit.
   Note: The IR-IN unit accepts a signal from a remote control and sends it to a device to be controlled on the other end of the installation. Position the IR-IN unit in an unobstructed area that can easily accept a remote control signal.
3. Connect the IR-OUT cable included with the receiver unit to the IR-OUT port on the remote receiver unit.
   Note: The IR-OUT unit receives the signal from the remote control on the other end of the installation and sends it to the device being controlled. Locate the IR-OUT unit in an area close to the remote-controlled device (e.g., Blu-Ray player, TV).
4. Connect the external power supply to the remote receiver unit and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU).
5. Repeat steps 12 through 17 for each additional RJ45 Output port on the transmitter that you will be connecting to a receiver unit.
6. Turn on the power to all HDMI and RS-232 serial devices in the installation.
7. Press the switch next to each set of Output LEDs to change the source being displayed on the corresponding Output monitor. You can also use the included remote control to switch between sources. To switch the source being displayed, press the button on the remote control of the desired Output port.
   Note: The same four-button remote control is included with both the BHDBT-T-SI-4X2 and BHDBT-T-SI-4X4. Buttons 3 and 4 will not be used for the BHDBT-T-SI-4X2.
   For details on using Terminal Emulation Software to control the switch, refer to the RS-232 Serial Control section of this manual.

RS-232 Serial Control (Matrix Transmitter Units Only)

Before using RS-232 serial control, you must first access Terminal Emulation Software and update the COM port settings.

1. Go to the Setup drop-down menu and select the Serial Port option.

1. Select the COM port that is being used and update the remaining settings: Baud Rate (57600), Data (8 bit), Parity (none), Stop (1 bit), Flow Control (none).

1. Next, you will need to configure your software to allow input control. Go to the Setup drop-down menu and select the Terminal option.

1. Update the following settings: Receive (LF), Local Echo (enable). The other settings can remain unchanged.

1. Once these settings are updated, the Terminal Emulation Software will recognize the switch. Upon recognition, you will be able to enter commands to control the unit. The available commands are listed as follows:

Command Action

sw[x] [n] Switches the source being displayed on the selected output. [x] is the output (1, 2, 3, or 4) and [n] is the desired source (A, B, C, or D). For example, a command of sw1 A would display source A on output 1.

PWD Turns power to the switch on/off.

STE Displays the current output state, showing which source is being displayed on each output.

Troubleshooting

If you are unable to obtain an acceptable image after following these installation instructions, try the following troubleshooting tips:

1. Are the external power supplies that came with the product connected and plugged into a working power source? For the product to function properly, it must be connected to and receiving power from the external power supply.
2. Was the power to the connected devices turned off prior to installation? If not, restart them.
3. What resolution are you trying to reach? Make sure that the desired resolution is supported by your model's maximum distance and resolution specifications as listed in the Product Features section of this manual. The shorter the extension distance, the higher the resolution you will be able to obtain. If you are not able to get an acceptable image, try lowering your computer's video resolution or adjusting the refresh rate.
4. What type of cabling are you using? Inferior cabling can result in poor performance, so it is important to use cables that support the video resolution you are trying to obtain. To achieve maximum distance and resolution, 24 AWG solid wire Cat5e/6 cable or 23 AWG solid wire Cat6a cable must be used. Tripp Lite's N202-Series Cat6 cables are made with 24 AWG solid wire, as are the N022-01K-GY (Cat5) and N222-01K-GY bulk cables. Extended lengths of 23 AWG solid wire Cat6a cable is available from Tripp Lite as a custom order. The HDMI cables you are using must also support the video resolution you are trying to obtain. Inexpensive, low quality HDMI cables may not support the maximum resolution. When using a 28 AWG HDMI cable and displaying video resolutions higher than 1080p, the HDMI cables connecting the source and the monitor must not exceed 6 feet. When using a 24 AWG HDMI cable, you must not exceed a 16-foot length.
5. Test your cables to ensure they are working properly. For example, connect your HDMI cables between a source and a monitor that you know works to see if the cable is functioning. For Cat5e/6 cable, connect it between a computer and a network to verify that it establishes a network connection.
6. Do you have any patch panels or other devices in-between the transmitter, repeater, and receiver units? Tripp Lite's HDBaseT HDMI over Cat5 extender products are designed to be connected directly from the transmitter to the transceiver and/or receiver with UTP cable. The more connection points that are between the source and the remote monitor, the more likely it will be that signal degradation will occur, causing poor performance. If you have a patch panel or other device in-between, it should be removed from the installation.

Troubleshooting

1. Check your cabling for any damages that may have occurred during installation. If a cable connector is loosened from being pulled through ceilings/walls or the cable jacket is damaged causing the wiring to be exposed, you will not be able to achieve maximum performance.
2. Are the transmitter, transceiver, and/or receiver located in an area that exposes them to higher temperatures? If the product is overheated, it will not function properly.
3. If you are having trouble getting your Terminal Emulation Software to recognize the switch, you may need to shut down your installation and start from the beginning. The 3.5 mm to DB9 adapter cable must be connected first. Otherwise, the switch will not be recognized.
4. If your are still having trouble getting your Terminal Emulation Software to recognize the switch, check that your serial settings are set according to the instructions in the RS-232 Serial Control section of this manual.

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from

TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE

is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Regulatory Compliance

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

WARNING

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Tripp Lite follows a policy of continuous improvement. Product specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

15-01-181 93-3418_RevA
