USER MANUAL R-550ET3X HITACHI

Interior view of a refrigerator with watermelon slices and food, alongside a digital kitchen control panel (no visible text or symbols)

HITACHI

Inspire the Next

Home and life solutions

People have always thought of consumer products as being for a single purpose. Hitachi Home and Life Solutions are engineering a new phase of product development – one where consumer products are interactive and serve multiple purposes.

As the evolution unfolds consumer products will begin to incorporate digital, network and sensor technologies. These products will become more and more incorporated into every day life, creating an entirely new level of relationship between people and their products.

We are changing the shape and quality of people's lifestyles while positioning Hitachi as a cutting edge brand that leads future development and is the global brand of choice.

Modern stainless steel refrigerator with open lid, displayed in wooden cabinets against a blue background (no visible text or symbols)

In today's modern kitchen, where good taste is the order of the day, you need a refrigerator that delivers on both superior styling and function. Through years of technological development and sophisticated design, Hitachi introduces you to one of the most advanced refrigerator ranges on the market.

A refrigerator range that not only symbolises your appreciation of good taste from the outside but retains the good taste of the food on the inside.

REFRIGERATION RANGE

Features

SILVER ION DEODORISER

The special deodoriser built into the air duct uses Silver Ion to help neutralise bacteria and odours throughout the refrigerator. Your food will last much longer than in conventional refrigerators while by spoilt food will be greatly reduced

TWIST ICE TRAYS

The convenient twist ice trays and large storage bank ensure you will always have ice on hand whenever you need it.

WARRANTY

2 year in-home parts and labour warranty. Additional 3 year parts warranty on compressor.*

ADVANCED MULTI-FLOW SYSTEM

The advanced multi-flow air distribution system chills or freezes your food quickly and efficiently. The freezer evenly distributes air from both the front and the back while the refrigerator compartment delivers super cold air to multiple sides of the food at once. This system allows cold air to circulate evenly around the refrigerator to keep all areas at a consistent temperature.

Abstract 3D graphic with blue curved shapes inside a transparent cube (no text or symbols)

3D diagram of a mechanical or electronic component with internal flow arrows, no visible text or symbols

The special Humidity Control System gives you the added flexibility of altering the

climate to suit a variety of different fruits and vegetables, keeping your food fresher for longer.

GLIDE OUT CRISPER

Storing vegetables should be effortless. That's why Hitachi has introduced the glide-out crisper. The four rollers allow you to access your vegetables quickly and easily.

The door gasket, which is prone to getting dirty and can be hard to get at, has undergone mould-proofing treatment for easier cleaning.

*See warranty card for further details.

Two people enjoying a meal at a wooden table with various fresh vegetables and fruit (no visible text or symbols)

QUICK FREEZING

Simply pressing the 'Freezing' button sets the freezer into "Quick Freeze" mode. This allows food and water to be frozen in a third less time than conventional freezers. As well as creating ice quickly, "Quick Freeze" also helps maintain the original taste of frozen foods and ensures they can be stored for longer.

POWER SAVING

When away on holidays or, if only storing a small amount of food, it seems unnecessary to have the refrigerator running at full power all the time and w

To prevent this Hitachi has introduced a clever 'Power Save' function that, when pressed, runs your refrigerator at 20% less power while still keeping your food in perfect condition.

ANTI-BACTERIAL DOOR COATING

The stainless steel surface has been covered with a transparent coating that has an anti-bacterial agent in it. The special coating makes it resistant to dirt and fingerprints, so it can be e

EASY, CHANGEABLE SHELF SUPPORT

The unique shelving support system gives you the flexibility of changing the height while unobtrusively hiding away the supports when not in use.

Features vary depending on model, please see specifications for details.

REFRIGERATION RANGE

Specifications

Exterior view of a modern stainless steel refrigerator (no visible text or symbols)

Interior view of a fully stocked refrigerator with open doors and various food items (no visible text or labels)

600L
R-600ET3X

Exterior view of a modern stainless steel refrigerator (no visible text or symbols)

Interior view of a modern refrigerator with open doors showing shelves, bottles, and food items (no visible text or labels)

550L
R-550ET3X

Exterior view of a modern stainless steel refrigerator (no visible text or symbols)

350L
R-360AT3 SLS

Front view of a white refrigerator with two doors, no visible text or symbols

Interior view of a refrigerator with open door and shelves filled with food items (no visible text or labels)

600L
R-600ET3

Front view of a white refrigerator with two doors, no visible text or symbols

Interior view of a white refrigerator with open doors showing various food items (no visible text or labels)

550L
R-550ET3

White refrigerator with front panel and side door (no visible text or symbols)

350L
R-360AT3 PWH

230L
R-240AT3 PWH

REFRIGERATION MODELS
R-600ET3X R-600ET3 R-550ET3X R-550ET3 R-360AT3 R-240AT3

Colour		Stainless Steel Pure White Stainless Steel Pure White				Pure White / Stainless Steel Look	Pure White
Capacity Total (F/R) (Litres) 600 (193/407) 600 (193/407) 550 (193/357) 550 (193/357) 350L (110/240) 230L (81/151)
Dimensions W x H x D (mm)		835 x 1810 x 715	835 x 1810 x 715	835 x 1710 x 715	835 x 1710 x 715	590 x 1710 x 640	590 x 1330 x 605
Cooling System		No Frost Type	No Frost Type	No Frost Type	No Frost Type	No Frost Type	No Frost Type
Door Handle		Vertical (Stainless Steel)	Vertical (Stainless Steel)	Vertical (Stainless Steel)	Vertical (Stainless Steel)	Vertical Handle	Vertical Handle
Storage Shelf of Fridge Compartment		Two (Glass)	Two (Glass)	Two (Glass)	Two (Glass)	Three (Wire)	Two (Wire)
Crisper Shelf		One (Glass)	One (Glass)	One (Glass)	One (Glass)	One (Plastic)	One (Plastic)
Glide Out Crisper & Humidity Control System		●	●	●	●	—	—
Slideout Crisper		—	—	—	—	●	●
Door Storage of Fridge Compartment	Top Shelf	Multi-use Egg Case (28 Egg pcs)	Multi-use Egg Case (Egg 28 pcs)	Multi-use Egg Case (28 Egg pcs)	Multi-use Egg Case (28 Egg pcs)	Multi-use Egg Case (Egg 18 pcs)	Multi-use Egg Case (Egg 18 pcs)
	Second Shelf	Utility	Utility	Utility	Utility	Two Utilities	Basket
	Third Shelf	Basket with 2L Bottle Storage	Basket with 2L Bottle Storage	Basket with 2L Bottle Storage	Basket with 2L Bottle Storage	Basket	Basket with 2L Bottle Storage
	Fourth Shelf	Basket	Basket	Basket	Basket	Basket with 2L Bottle Storage	—
Freezer Shelf		One (Glass)	One (Wire)	One (Glass)	One (Wire)	Two (Plastic)	Two (Plastic)
Ice Cube Tray		Twist Ice Maker (2pcs)	Twist Ice Maker (2pcs)	Twist Ice Maker (2pcs)	Twist Ice Maker (2pcs)	Twist Ice Maker (2pcs)	Twist Ice Maker (2pcs)
Ice Bank		●	●	●	●	●	●
Quick Freezing		●	●	●	●	—	—
Power Saving		●	●	●	●	—	—
Deodoriser		Silver Ion	Silver Ion	Silver Ion	Silver Ion	Silver Ion	Silver Ion
Advanced Multi-flow System		●	●	●	●	—	—
Multi-flow System		—	—	—	—	●	●
Anti-bacterial Door Coating		●	—	●	—	—	—
Easy Changeable Shelf Support		●	●	●	●	—	—
Energy Rating (Stars)		2.5	2.5	2.5	2.5	2.5	2.5
Energy Consumption (kW.n)		875	875	865	865	700	572
Refrigerant R134-a (gr)		185	185	185	185	160	140
Required Clearance	Top (mm)	300	300	300	300	300	300
	Side (mm)	50	50	50	50	50	50
	Rear (mm)	50	50	50	50	50	50

Design and specifications subject to change with product improvement.
