Product Type	Li-ion Camera Battery
Brand	Watson
Model	BP-2L14
Battery Type	Lithium-ion (Li-ion)
Voltage	7.2V
Capacity	1000mAh
Dimensions	Approx. 1.5 x 2.0 x 0.5 in (38 x 51 x 13 mm)
Weight	Approx. 1.8 oz (51 g)
Operating Temperature	15°F to 105°F (-10°C to 40°C)
Storage Temperature	59°F (15°C) recommended
Warranty	1 Year Limited
Self-resetting Fuse	Yes (internal)
Overcharge Protection	Yes (built-in safety circuit)
Charging Method	In-camera or external charger compatible
Recommended Charge Level for Storage	40% capacity
Maintenance	Clean terminals with dry cloth; avoid full discharge for storage
Safety Features	Do not short circuit, incinerate, or expose to moisture
Compatible Devices	Camcorders and cameras using Canon BP-2L14 series

Frequently Asked Questions - BP-2L14 Watson

How should I charge the Watson BP-2L14 battery for the first time?

Charge the battery fully before first use. Use your camcorder or camera charger as instructed in the device manual. The battery does not require a special first-time conditioning.

Can I use the battery while it is charging?

No, it is not recommended to use the battery while charging. Always charge the battery in a compatible charger or camera with the power off.

What is the best way to store the battery when not in use?

Remove the battery from the device and store it in a cool, dry place at about 59°F (15°C). The ideal charge level for storage is approximately 40%. Do not store fully charged or completely discharged.

How long does the battery last on a full charge?

Run time depends on power demand. In lab tests with non-stop recording, it may last up to several hours. Real-world use (zoom, autofocus, playback) will reduce run time. Actual duration varies by device and usage.

What should I do if the battery gets hot during charging or use?

It is normal for the battery to become warm during charging or heavy use. If it becomes excessively hot, stop using and allow it to cool. If overheating persists, discontinue use and contact support.

Does this battery have overcharge protection?

Yes, the Watson BP-2L14 includes a built-in safety circuit that prevents overcharging and over-discharging. However, always use a compatible charger.

Can I leave the battery in the camera when not in use?

It is best to remove the battery if the camera will not be used for an extended period, as some devices draw power even when switched off. Remove to prevent deep discharge.

How do I clean the battery terminals?

Use a clean, soft, dry cloth to wipe the terminals. Do not use liquids or abrasive materials that may damage the contacts.

What is covered under the one-year warranty?

The warranty covers defects in materials and workmanship under normal consumer use for one year from purchase. It does not cover misuse, abuse, or unauthorized modifications.

How do I dispose of this lithium-ion battery?

Do not incinerate or discard in household waste. Follow local regulations for recycling lithium-ion batteries. Many electronics stores offer battery recycling programs.

USER MANUAL BP-2L14 Watson

Please read before using this equipment.

Blue 3D-rendered object resembling a folded or layered object with smooth edges (no text or symbols)

Abstract geometric pattern with yellow and white shapes (no text or symbols)

Thank you for purchasing the Watson Li-ion Battery Pack.

Browse through this manual for information and useful tips on how to use your new equipment.

SAFETY INSTRUCTIONS:

- Charge the battery pack before use. Read your camcorder or digital camera manual for charging instructions.

- When not in use, remove the battery pack from its device and store in a cool, dry place.

- Do not short circuit the terminals. This battery is protected with an internal self-resetting fuse, but short circuits may still cause severe damage to the battery. Be careful where you set the battery down.

• Under no circumstance attempt to open the battery case.
- Do not expose the battery to rain or moisture.

- Keep away from fire. Do not incinerate. Battery may explode in the presence of fire.

- Do not drop battery or expose it to strong shocks.

- Do not use at temperatures below 15°F (-10°C) or above 105°F (40°C). Use of the battery at very high temperatures will activate a safety circuit, disallowing use.

- Running time depends on the power demanded. Stated manufacturer run times are developed in simple laboratory tests of non-stop recording. Real-life use of zoom, automatic focus, tape review, etc., all demand extra power and shorten run time.

TO MAXIMIZE BATTERY PERFORMANCE

• Make sure the battery is fully charged before use.
- Clean the battery and terminals with a clean, soft, dry cloth.
• The battery may be warm during use on recharging. This is normal.
- When storing the battery for an extended period, be sure that it is not completely charged, nor completely discharged.

The ideal level is a 40% charge. This is approximate; the closer the battery is to this level, the better it will hold its charge during storage. The battery should be stored in a cool, dry place. The recommended temperature for storage is 59°F (15°C). You may store a battery in a refrigerator. Do not store batteries in a freezer.

- Remove the battery from your equipment when not in use. Some electronic equipment will draw current even when the switch is off.

- When operation time has noticeably shortened, the battery may need to be replaced.

ONE-YEAR LIMITED WARRANTY

This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function. This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state. To obtain warranty coverage, contact the Watson Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Watson along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.poweredbywatson.com or call Customer Service at 212-594-2353.

WATSON™ A Gradus Group Brand

Product warranty provided by the Gradus Group. Watson is a registered trademark of the Gradus Group. © 2016 Gradus Group LLC. All Rights Reserved.
