NP-FP90 - Camera Battery Watson - Free user manual and instructions

Product Type	Li-ion Battery Pack
Brand	Watson
Model	NP-FP90
Battery Chemistry	Lithium-ion
Voltage	7.2V
Capacity	3000mAh
Dimensions	1.38 x 0.69 x 1.97 in (35 x 17.5 x 50 mm)
Weight	2.1 oz (60 g)
Operating Temperature	15°F to 105°F (-10°C to 40°C)
Storage Temperature	59°F (15°C) recommended
Recommended Storage Charge	40%
Protection Features	Self-resetting fuse, short circuit protection
Compatibility	Camcorders and digital cameras using NP-FP series (e.g., Sony)
Charging Method	Use compatible charger or camera
Warranty	1 Year Limited Warranty
Maintenance	Clean terminals with dry cloth
Replaceable Parts	None (sealed unit, not user-serviceable)
Safety Precautions	Do not short circuit, disassemble, incinerate, expose to moisture or high temperatures
Disposal	Recycle according to local regulations for Li-ion batteries

Frequently Asked Questions - NP-FP90 Watson

How do I charge the Watson NP-FP90 battery?

Charge the battery using a compatible charger or by connecting it to your camcorder or camera. Refer to your device manual for specific charging instructions.

Can I use this battery with any camera?

No, the NP-FP90 is designed for cameras and camcorders that accept NP-FP series batteries, particularly Sony models. Check compatibility before use.

How long does the battery last on a full charge?

Runtime depends on usage. With a 3000mAh capacity, typical recording time is about 2-4 hours, but use of zoom, autofocus, and other features will reduce it.

How should I store the battery when not in use?

Store at 40% charge in a cool, dry place. Recommended temperature is 59°F (15°C). Avoid full charge or complete discharge for long-term storage.

Is it safe to leave the battery in the camera?

It is recommended to remove the battery when not in use to prevent parasitic drain on the battery.

What should I do if the battery gets wet?

Do not use. Dry it with a soft cloth and let it air dry completely before using. If damaged, replace the battery.

How do I dispose of the battery?

Dispose of in accordance with local regulations for lithium-ion batteries. Do not incinerate.

Does the battery have a warranty?

Yes, Watson offers a 1-year limited warranty against defects in materials and workmanship.

Can I use the battery in extreme temperatures?

Operating temperature is 15°F to 105°F (-10°C to 40°C). Avoid use outside this range.

How do I clean the battery terminals?

Clean terminals with a clean, soft, dry cloth. Do not use liquids.

USER MANUAL NP-FP90 Watson

Please read before using this equipment.

Blue 3D illustration of a folded or layered object with smooth edges and no visible text or symbols

Abstract geometric pattern with yellow and white shapes (no text or symbols)

Thank you for purchasing the Watson Li-ion Battery Pack.

Browse through this manual for information and useful tips on how to use your new equipment.

SAFETY INSTRUCTIONS:

- Charge the battery pack before use. Read your camcorder or digital camera manual for charging instructions.

- When not in use, remove the battery pack from its device and store in a cool, dry place.

- Do not short circuit the terminals. This battery is protected with an internal self-resetting fuse, but short circuits may still cause severe damage to the battery. Be careful where you set the battery down.

• Under no circumstance attempt to open the battery case.
- Do not expose the battery to rain or moisture.

- Keep away from fire. Do not incinerate. Battery may explode in the presence of fire.

- Do not drop battery or expose it to strong shocks.

- Do not use at temperatures below 15°F (-10°C) or above 105°F (40°C). Use of the battery at very high temperatures will activate a safety circuit, disallowing use.

- Running time depends on the power demanded. Stated manufacturer run times are developed in simple laboratory tests of non-stop recording. Real-life use of zoom, automatic focus, tape review, etc., all demand extra power and shorten run time.

TO MAXIMIZE BATTERY PERFORMANCE

• Make sure the battery is fully charged before use.
- Clean the battery and terminals with a clean, soft, dry cloth.
• The battery may be warm during use on recharging. This is normal.
- When storing the battery for an extended period, be sure that it is not completely charged, nor completely discharged.

The ideal level is a 40% charge. This is approximate; the closer the battery is to this level, the better it will hold its charge during storage. The battery should be stored in a cool, dry place. The recommended temperature for storage is 59°F (15°C). You may store a battery in a refrigerator. Do not store batteries in a freezer.

- Remove the battery from your equipment when not in use. Some electronic equipment will draw current even when the switch is off.

- When operation time has noticeably shortened, the battery may need to be replaced.

ONE-YEAR LIMITED WARRANTY

This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function. This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state. To obtain warranty coverage, contact the Watson Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Watson along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.poweredbywatson.com or call Customer Service at 212-594-2353.

WATSON™ A Gradus Group Brand

Product warranty provided by the Gradus Group. Watson is a registered trademark of the Gradus Group. © 2016 Gradus Group LLC. All Rights Reserved.
