SK34020CN - Kettle SWAN - Free user manual and instructions

Product Type	Cordless Electric Kettle
Brand	Swan
Model	SK34020CN
Capacity	1.7 Liters
Power Rating	2200-2400 Watts
Voltage	220-240 V ~ 50/60 Hz
Material	Stainless Steel Body with A Lid
Color	Silver / Black
Dimensions (W x D x H)	Approx. 22 x 16 x 24 cm
Weight	Approx. 1.0 kg (kettle only)
Cordless Base	360° Rotational Base with Cord Storage
Boil-dry Protection	Automatic Shut-off When Empty
Auto Shut-off	After Boiling
Water Level Indicator	Visible Window with Marks
Lid Opening	One-Button Push-Open
Filter	Removable Limescale Filter
Spout	Precision Pour Spout
Handle	Cool-Touch Ergonomic Handle
Power Cord Base	Approx. 70 cm
Cleaning	Wipe exterior with damp cloth; descale regularly

Frequently Asked Questions - SK34020CN SWAN

How do I descale my Swan SK34020CN kettle?

To descale, fill the kettle with equal parts water and white vinegar or use a commercial descaling solution. Boil, let sit for 20 minutes, then rinse thoroughly. Repeat if necessary.

Why does my kettle shut off before boiling?

This may be due to excess limescale on the heating element. Descale the kettle. Also ensure the lid is closed properly and the water level is not below the minimum mark.

What is the maximum capacity of the kettle?

The maximum capacity is 1.7 liters. Do not fill beyond the MAX mark to avoid spillage during boiling.

Can I boil water directly from the base?

No, the kettle must be placed on the base for power connection. The base is cordless and rotates 360° for convenient placement.

Is the kettle BPA-free?

Yes, the Swan SK34020CN is made with BPA-free materials. All parts that come into contact with water are safe.

How do I clean the filter?

The removable filter can be taken out and rinsed under running water. Use a soft brush if needed. Replace it before use.

What should I do if the kettle doesn't turn on?

Check that the base is plugged in and the kettle is properly seated. Inspect the auto shut-off mechanism and ensure the kettle is not dry. If still not working, contact customer support.

Can I leave water in the kettle overnight?

It is best to empty the kettle after each use to prevent mineral buildup. If left, descale more frequently.

What is the power consumption?

The kettle operates at 2200-2400 watts and 220-240 volts. It is efficient and boils water quickly.

How do I store the cord?

The base has a cord storage compartment under it. Wrap the excess cord around the clips to keep it tidy.

USER MANUAL SK34020CN SWAN

Swan Retro designed for life Dome Kettle Models: SK34020 [all colours] v1.0 Helpline: 01733 404703

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

When using any electrical appliance, basic safety precautions should always be followed including the following:

• Always ensure that the voltage on the rating label corresponds to the mains voltage in your home
- Incorrect operation and improper use can damage the appliance and cause injury to the user.
- This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years. Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer or qualified person in order to avoid an electrical hazard.
- Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for examination and/or repair by an authorised service agent.
- Never immerse the unit in water or any other liquid for cleaning purposes.
- Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance from the mains. Always unplug the unit when not in use, before cleaning or when adding or removing parts.
- The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries, fire or electric shock.
- Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be pulled on inadvertently.
- Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated oven.
- Do not use the appliance on a gas or electric cooking top or over or near an open flame.
- Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of extension

Swan

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled on by children or animals or tripped over.

• This appliance is not suitable for outdoor use. Do not use the appliance for anything other than its intended use.
- Do not carry the appliance by the power cord.
- Do not leave the appliance unattended during use. Always unplug the unit when not in use or before cleaning.
• Always operate the appliance on a smooth, even, stable surface. Do not place the unit on a hot surface.
- Ensure that the unit is switched off after use.
- The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or for repairs carried out by unauthorised personnel.
- In case of technical problems, switch off the product and do not attempt to repair it yourself. Return the appliance to an authorised service facility for examination, adjustment or repair. Always insist on the use of original spare parts. Failure to comply with the above mentions precautions and instructions, could affect the safe operation of this product.
- Your appliance must never be switched on through an external timer or any kind of separate remote control system

TECHNICAL DATA

Description: Dome Kettle

Model: SK34020 (all colours)

Input Voltage: 220-240V. Frequency: 50/60Hz. Power consumption: 2520-3000 Watts

HOW TO USE

Before first use

Remove all packaging

It is important to ensure the correct plug adaptor is used when operating in a country not using the UK 13 Amp socket system. If in doubt, consult a qualified electrician.

Fill the kettle with water via the spout. You can also fill the kettle by opening the lid. Ensure the lid is firmly closed after filling.

Check that the water level is between the MIN and MAX lines on the water gauge.

PLEASE DO NOT OVERFILL THE KETTLE PAST THE MAX LEVEL. DOING SO POSES A SCALDING RISK.

Place the kettle on its base, Connect the plug to the mains supply and press the power switch down

The kettle will switch itself off once the water has boiled

If this is the first time you have used the kettle, discard the water from the first boiling.

Swan

CLEANING & MAINTENANCE

This product requires very little maintenance. However, if you live in a hard water area, it will be necessary to de-scale the kettle from time to time.

Most supermarkets sell de-scaling tablets, powders or liquids.

These are inexpensive, easy to use and perfect for ensuring your kettle provides many years of faithful service.

An excessive build up of limescale will damage your kettle and increase the boiling time/electricity consumption. It can also compromise the seals inside the kettle and cause it to leak. This is not covered by the warranty.

For cleaning external surfaces, a soft cloth moistened with a mild detergent solution is all that is required.

DO NOT USE ABRASIVE OR STRONG CHEMICAL CLEANERS DO NOT IMMERSE ANY PART OF THE PRODUCT IN WATER

ALWAYS ENSURE THE PRODUCT IS UNPLUGGED FROM THE MAINS SUPPLY AND COMPLETELY COOL BEFORE CLEANING.

Swan 5

DOCUMENTATION

We Swan Products Ltd declare that this product conforms to the following product legislation in accordance with the following directive[s]:

2004/108/EEC The EMC Directive (the Electromagnetic Compatibility Directive).

2006/95EC. The LVD Directive (Low Voltage Directive).

2011-65-EU. The RoHS directive (Restriction of Hazardous Substances Directive)

EC 1935/2004 Food Contact

2009/125/EC Eco Design Directive

WARRANTY

This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty materials of workmanship the faulty products must be returned to the place of purchase. Refunds or replacement is at the discretion of the store.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.

BS PLUG

The wires in the mains lead are coloured in accordance with the following code:

BLUE NEUTRAL

BROWN LIVE

GREEN/YELLOW EARTH

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows: The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or [earth symbol] and is coloured GREEN or GREEN/YELLOW.

Swan

WARNING: THIS APPLIANCE MUST BE EARTHED

SWAN BRAND HERITAGE

Illustration of a metallic kettle with a coiled cable and handle, no text or symbols present.

DISPOSAL OF UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.

co.uk for access to information about the recycling of electrical items. Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.

Did you know...

In 1933 Swan were the first to develop an electric heating element that could be immersed in water. This led to the Swan kettle range that could boil up to six pints of water in just over nine minutes - pretty hot for the time! These days it takes about two minutes for a Swan kettle to boil.

Swan 7

Stylized white and gray swan logo on black background (no text or symbols)

www.swan-brand.co.uk

Scan this QR code to hear about our story

We love what we do

we're proud of our quality

Find us on Facebook

* on selected products

Copyright © Swan Products Ltd. PO Box 3117, Stoke-on-Trent ST4 9GD
