SK14610 - Kettle SWAN - Free user manual and instructions

Product Type	Electric Kettle
Brand	Swan
Model	SK14610
Capacity	1.7 liters
Power Rating	2200-2400 W
Voltage	220-240 V, 50/60 Hz
Body Material	Stainless Steel
Lid Material	Plastic
Dimensions (H x W x D)	25 x 22 x 18 cm
Weight	1.2 kg
Cord Length	75 cm
Auto Shut-Off	Yes
Boil-Dry Protection	Yes
Concealed Heating Element	Yes
360° Swivel Base	Yes
Water Level Indicator	Yes
Removable Scale Filter	Yes
Lid Type	One-Touch Opening
Control Type	Switch with Indicator Light
Warranty	2 Years
Country of Origin	China

Frequently Asked Questions - SK14610 SWAN

How do I descale the kettle?

Mix equal parts white vinegar and water. Fill the kettle to half, boil, let sit for an hour, empty, rinse thoroughly with fresh water. Use a descaling solution for convenience.

How do I clean the kettle exterior?

Wipe with a damp cloth. Do not immerse in water. For stainless steel, use a mild cleaner. Avoid abrasive pads.

What is the water capacity?

The kettle holds up to 1.7 liters.

Does it automatically shut off when boiling?

Yes, the kettle has an auto shut-off feature for safeness.

Can I boil water for tea or coffee?

Yes, the kettle is designed to boil water for hot beverages.

Is the base detachable?

Yes, the kettle sits on a 360° swivel base that can be detached from the kettle.

How do I replace the filter?

The removable scale filter is located at the spout. Pull it out to clean or replace. Insert a new one until it clicks.

Why won't the kettle turn on?

Check the power connection and ensure the base is properly connected. The kettle won't operate if there is insufficient water (safety feature).

Is the kettle BPA-free?

Yes, all parts that come into contact with water are BPA-free.

What is the warranty period?

The Swan SK14610 comes with a 2-year warranty from the date of purchase.

USER MANUAL SK14610 SWAN

Model: SK14610 (all colours)

Help line

0333 220 6050

v1.0

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

When using any electrical appliance, basic safety precautions should always be followed including the following:

• The appliance is only to be used with the stand provided;
• Avoid spillage on the connector;
• The heating element surface is subject to residual heat after use.
  • Always ensure that the voltage on the rating label corresponds to the mains voltage in your home
• Incorrect operation and improper use can damage the appliance and cause injury to the user.
• This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years. Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer or qualified person in order to avoid an electrical hazard.
• Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for examination and/or repair by an authorised service agent.
• Never immerse the unit in water or any other liquid for cleaning purposes.
• Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance from the mains. Always unplug the unit when not in use, before cleaning or when adding or removing parts.

2

Swan

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

• The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries, fire or electric shock.
• Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be pulled on inadvertently.
• Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated oven.
• Do not use the appliance on a gas or electric cooking top or over or near an open flame.
• Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of extension cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled on by children or animals or tripped over.
• This appliance is not suitable for outdoor use. Do not use the appliance for anything other than its intended use.
• Do not carry the appliance by the power cord.
• Do not leave the appliance unattended during use. Always unplug the unit when not in use or before cleaning.
• Always operate the appliance on a smooth, even, stable surface. Do not place the unit on a hot surface.
• Ensure that the unit is switched off after use.
• The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

• for repairs carried out by unauthorised personnel.
- In case of technical problems, switch off the product and do not attempt to repair it yourself. Return the appliance to an authorised service facility for examination, adjustment or repair. Always insist on the use of original spare parts. Failure to comply with the above mentions precautions and instructions, could affect the safe operation of this product.
- Your appliance must never be switched on through an external timer or any kind of separate remote control system
- DO NOT OVER FILL PAST THE MAX LEVEL. If the kettle is overfilled, boiling water may be ejected.
- This appliance is intended to be used in household and similar applications such as: staff kitchen areas, in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments.

TECHNICAL DATA

Description: Kettle

Model: SK14610 (all colours)

Input Voltage: 220-240V

Frequency: 50Hz

Power consumption: 2500-3000 Watts

HOW TO USE

Before first use, remove all packaging.

It is important to ensure the correct plug adaptor is used when operating in a country not using the UK 13 Amp socket system. If in doubt, consult a qualified electrician.

• Fill the kettle with water via the spout or you can also fill the kettle by opening the lid. Ensure the lid is firmly closed after filling.
• Check that the water level is between the MIN and MAX lines on the water gauge.
• PLEASE DO NOT OVERFILL THE KETTLE PAST THE MAX LEVEL. DOING SO POSES A SCALDING RISK.
• Place the kettle on its base, Connect the plug to the mains supply and press the power switch down
• The kettle will switch itself off once the water has boiled
• If this is the first time you have used the kettle, discard the water from the first boiling.

CLEANING & MAINTENANCE

DAMAGE TO THIS PRODUCT CAUSED BY EXCESSIVE LIME SCALE BUILD UP IS NOT COVERED BY YOUR WARRANTY

• If you live in a hard water area, it will be necessary to de-scale the kettle from time to time. Most supermarkets sell de-scaling tablets, powders or liquids.
• These are inexpensive, easy to use and perfect for ensuring your kettle provides many years of faithful service.
• An excessive build up of lime scale will damage your kettle and increase the boiling time/electricity consumption!
• For cleaning external surfaces, a soft cloth moistened with a mild detergent solution is all that is required.
• DO NOT USE ABRASIVE OR STRONG CHEMICAL CLEANERS DO NOT IMMERSE ANY PART OF THE PRODUCT IN WATER
• ALWAYS ENSURE THE PRODUCT IS UNPLUGGED FROM THE MAINS SUPPLY AND COMPLETELY COOL BEFORE CLEANING.

WARRANTY

This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty materials of workmanship the faulty products must be returned to the place of purchase. Refunds or replacement is at the discretion of the store.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.

BS PLUG

The wires in the mains lead are coloured in accordance with the following code:

BLUE NEUTRAL

BROWN LIVE

GREEN/YELLOW EARTH

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or (earth symbol) and is coloured GREEN or GREEN/YELLOW.

WARNING: THIS APPLIANCE MUST BE EARTHED

Swan

DISPOSAL OF UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the recycling of electrical items. Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in

August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.

SWAN BRAND HERITAGE

Did you know...

In 1933 Swan were the first to develop an electric heating element that could be immersed in water. This led to the Swan kettle range that could boil up to six pints of water in just over nine minutes - pretty hot for the time! These days it takes about two minutes for a Swan kettle to boil.
