Comfort 7400 EL - Keyboard Sven - Free user manual and instructions

Product Type	Wired Multimedia Keyboard
Model	Comfort 7400 EL
Brand	Sven
Number of Keys	104
Shortcut Keys	12 Fn shortcut keys (media, volume, web, etc.)
Backlight	Individual key backlighting, two colors (blue/green), On/Off button
Interface	USB
Operating System Compatibility	Windows XP/Vista/7/8
Keyboard Layout	English/Russian/Ukrainian
Membrane Type	High-quality membrane
Estimated Key Life	More than 20,000,000 keystrokes
Dimensions (W × H × L)	455 × 20 × 155 mm
Weight	727 g
Power Source	USB port (5V DC)
Surface Finish	Glossy
Package Contents	Keyboard, User's Manual, Warranty Card
Country of Origin	China
Manufacturer	SVEN PTE. LTD, Singapore / Oy Sven Scandinavia Ltd, Finland
Recommended Cleaning	Use a soft, dry cloth; avoid liquids and abrasives
Safety	Keep away from moisture and heat; do not disassemble
Repair	No user-serviceable parts; contact authorized service center

Frequently Asked Questions - Comfort 7400 EL Sven

How do I install the Sven Comfort 7400 EL keyboard?

Simply connect the keyboard to an available USB port on your PC. The installation is automatic. No additional drivers are required for Windows XP/Vista/7/8.

How do I change the backlight color or turn it off?

Press the LED ILLUMINATION button to toggle between blue and green backlight. Press and hold the button for about 3 seconds to turn off the backlight.

What are the shortcut keys on this keyboard?

There are 12 Fn shortcut keys. To use them, press and hold the Fn key and then press the corresponding shortcut key. Functions include media control (play/pause, next/previous track, volume), opening My Computer, home page, email, and more.

Is the Sven Comfort 7400 EL compatible with Windows 10?

The manual states compatibility with Windows XP/Vista/7/8. It may work with Windows 10, but it is not officially listed. Basic keyboard functions should work, but shortcut keys may require driver updates.

What should I do if the keyboard is not working?

First, ensure your PC's BIOS has USB keyboard support enabled. Disconnect and reconnect the keyboard. Check the USB connector for damage. If the issue persists, contact your nearest authorized service center.

How many keys does the keyboard have?

It has 104 standard keys plus 12 Fn shortcut keys, totaling 116 keys.

Can I use this keyboard with a Mac?

The keyboard is designed for Windows (XP/Vista/7/8). It may work with Mac via USB, but some shortcut keys may not function correctly, and the layout is optimized for Windows.

How do I clean the keyboard?

Use a soft, dry cloth to wipe the surface. Do not use liquids, solvents, or abrasive cleaners. Avoid getting moisture inside the keys.

What is the keyboard's dimensions and weight?

Dimensions are 455 mm wide, 20 mm high, and 155 mm deep. Weight is approximately 727 grams.

Does the keyboard have a warranty?

Yes, it comes with a warranty card. For warranty service, contact the dealer or an authorized service center. Do not attempt to repair the keyboard yourself.

USER MANUAL Comfort 7400 EL Sven

Congratulations on your purchase of the Sven Multimedia Keyboard!

Please read this User's Manual before using the unit and retain this User's Manual in a safe place for future reference.

COPYRIGHT

© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).

This Manual and information contained in it are copyrighted. All rights reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The information in this Manual is given on «as is» terms. The author and the publisher do not bear any liability to a person or an organization for loss or damage which has arisen from the information contained in this Manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device for damage; if the product was damaged during transportation, address the firm which carried out the delivery; if the product functions incorrectly, address the dealer at once.

CONTENTS

1. SPECIAL FEATURES ...... 2
2. PACKAGE CONTENTS ...... 2
3. SYSTEM REQUIREMENTS ...... 2
4. INSTALLATION 2
5. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS 2
6. TROUBLESHOOTING .... 3
7. TECHNICAL SPECIFICATIONS .... 3

1. SPECIAL FEATURES

• Keyboard with individual character backlighting of each every key
• Two backlighting colors: blue or green
• On/Off backlighting button
  • High-quality membrane
• Windows XP/Vista/7/8 compatible
• Convenient and precise keystroke
• 12 Fn shortcut keys
• Glossy surface

2. PACKAGE CONTENTS

- Keyboard — 1 pc

- User's Manual — 1 pc

- Warranty card — 1 pc

3. SYSTEM REQUIREMENTS

- Windows XP/Vista/7/8.

- Free USB port.

4. INSTALLATION

• Connect the keyboard to an available USB port of your PC.
• Installation of the keyboard is automatic after its connection to the USB port.
• Press the LED ILLUMINATION button to change backlight color. Press and hold down the LED ILLUMINATION button within 3 seconds to turn off the backlight.

5. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS

Start media player

Volume down

Volume up

Mute/turn on sound volume

Go to previous media track

▶ Go to next media track

Play / Pause

■ Turn off media player

Open home web page

Start default e-mail program

Open My Computer

☆ Open My Favorites

Note. Press the shortcut keys while holding the Fn key.

6. TROUBLESHOOTING

Problem	Solution
The keyboard is not working.	1. Make sure that BIOS of your PC has USB controller settings for default operation.2. Disconnect the keyboard from the PC and check connector pins for possible damage. If there is no external damage found and connector pins are OK, reconnect the keyboard to the PC.3. Address your nearest authorized service center.
Problems using the additional shortcut keys.	We recommend that you address your nearest authorized service center.

If none of the above methods can solve the problem, please seek professional advice at your nearest service center. Never attempt to repair the product yourself.

7. TECHNICAL SPECIFICATIONS

Parameter, measurement unit	Value
Q-ty of keyboard keys	104
Q-ty of shortcut keys	12 Fn
Backlight on/off switch button	yes
Keyboard layout	Eng/Rus/Ukr
OS compatibility	Windows XP/Vista/7/8
Interface	USB
Extrapolated mean life	more than 20,000,000
Dimensions (W × H × L), mm	455 × 20 × 155
Weight, g	727

Notes:

• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to improvement of SVEN production.

Front view of a black Siemens computer keyboard with standard keys and buttons (no visible text or symbols on the keys themselves)

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, N° 02-02, Singapore, 427447. Produced under the control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN Scandinavia Ltd. Finland.

COMFORT

7400 EL
