WEE.PINK - Docking Station Promate - Free user manual and instructions

Brand	Promate
Model	WEE.PINK
Product Type	Universal Docking Station
Color	Pink
Dimensions (L x W x H)	Approx. 20 x 10 x 5 cm
Weight	Approx. 500 g
Power Input	USB-C PD 3.0 (5V/3A, 9V/2A, 15V/2A)
USB Ports	2x USB-A 3.0, 1x USB-C Data
Video Output	1x HDMI 2.0 (4K@30Hz)
Ethernet	1x RJ45 Gigabit Ethernet
SD Card Slot	SD / microSD card reader
Audio Jack	3.5 mm headphone/microphone combo
Compatible Devices	Laptops, tablets, smartphones with USB-C
Operating Systems Supported	Windows, macOS, Chrome OS, Linux
Maintenance & Cleaning	Wipe with dry cloth; avoid liquids
Safety Instructions	Do not expose to water or extreme temperatures
Spare Parts Availability	Contact Promate support
Warranty	1 year limited warranty

Frequently Asked Questions - WEE.PINK Promate

What devices are compatible with the Promate WEE.PINK docking station?

The docking station is compatible with laptops, tablets, and smartphones that have a USB-C port supporting DisplayPort Alt Mode and Power Delivery. It works with Windows, macOS, Chrome OS, and Linux.

Does it support 4K video output?

Yes, the HDMI port supports 4K resolution at 30Hz. For best performance, use a high-speed HDMI cable.

Can I charge my laptop through the docking station?

Yes, the USB-C port supports Power Delivery 3.0 up to 60W, allowing you to charge your laptop while using other ports. Ensure the power adapter is connected to the docking station.

How do I connect an external monitor?

Connect the HDMI cable from the docking station to your monitor. The display will be detected automatically. You can adjust settings in your operating system's display settings.

Is the docking station compatible with Apple MacBook?

Yes, it works with MacBook Air and MacBook Pro (USB-C models). Some older MacBooks may require a Thunderbolt 3 to USB-C adapter.

What is the maximum data transfer speed?

The USB-A and USB-C data ports support USB 3.0 with speeds up to 5 Gbps. The Ethernet port provides up to 1 Gbps network speed.

Can I use it with a smartphone?

Yes, if your smartphone supports USB-C with DisplayPort Alt Mode (e.g., Samsung DeX, Huawei EMUI Desktop). You can connect external displays and peripherals.

How do I clean the docking station?

Unplug the device and wipe the surface with a soft, dry cloth. Avoid using water or cleaning solvents to prevent damage.

Does it have an SD card slot?

Yes, it has a combined SD/microSD card slot that can read both types of memory cards simultaneously.

What should I do if the docking station is not working?

First, check all cable connections and ensure the power adapter is connected. Try a different USB-C port on your device. If the issue persists, contact Promate customer support for assistance.

USER MANUAL WEE.PINK Promate

Red and silver portable electronic device with a handle, no visible text or symbols on the body.

Built-in Mic

Handsfree

Multi-Color

Introduction

We believe that you should never have to compromise sound quality for portability. Introducing Wee, a wireless ultra-portable speaker. Even with its compact and portable size the speaker delivers a supreme base sound output and yet can easily clip onto your backpack. You can wirelessly stream audio from any Bluetooth® equipped mobile device or even play your favorite MP3/WAV tracks using the on board TF card reader. Wee can be used as a hands free device for answering calls too. All this encompassed in an abrasion resistant high quality aluminium housing. Wee, an ideal audio solution for indoor or outdoor music playback.

Packaging Contents:

• Wee
• USB charging cable
• AUX cable
• User Guide

Specification:

• Bluetooth® Version: 2.1+EDR
• Bluetooth® Profile: HFP, HSP, A2DP
• Input Power: 5V/500mA
• Output Power: 3W
• Impedance: 4 Ohms
• Speaker Frequency: 50Hz\~18000Hz
  • Signal-to-noise ratio: 65dB
• Charging time: 5 hours
  • Maximum playing hours: 5-6 hours
• Battery Capacity: 800 mAh
• Operating Distance: 10 meters

Features:

• Lightweight high quality aluminium housing
- Slim speaker
- Abrasion resistant surface
• Durable and portable
- Answer phone calls wirelessly from any Bluetooth® smartphone
- Easy-to-use controls for music playback and answering phone calls
- Streams music wirelessly from any Bluetooth® enabled device
- Micro-SD / TF card play back support
• Available in a variety of colours

Precautions:

Please read all safety instructions and warnings thoroughly before using this product. Improper use of this product may result in damage to this or attached products.

• Do not disassemble the device or attempt to fix it.
• Kindly use the included USB Cable to charge the product.
• Do not attempt to replace any part of this case or battery inside.
• Do not crush, puncture or dispose of in fire.

- Do not store or use the battery in a high temperature environment, including intense sunlight or heat.

- Avoid excessive drops, bumps, abrasions and impacts.

- If there is any reason to believe that there is internal damage to the device, discontinue use immediately.

- If you find that the device is too hot, is emitting and odor is deformed, punctured or exhibits any suspicious or abnormal behavior, discontinue use immediately and contact our customer service.

- Always charge this product before extended storage.

Appearance & Interface Description:

Diagram of a device with labeled parts, showing internal grid layout and control buttons

45 O1 O2

Technical diagram of a device with labeled ports and connectors, showing internal components and part numbers 8 and 9.

1. Volume + / Toggle Forward Button
2. LED Indicator
3. Volume - / Toggle Backward Button
4. Power Button
5. Mode Button
6. Play / Pause button
7. Reset Button
8. Micro-SD Card Slot
9. USB Charging Port

Operation Instructions:

Charging Wee

Line drawing showing a computer tower connected to a laptop via USB cable (no text or symbols)

1. Connect Wee to a PC/Laptop/Mac or 5V USB adaptor (not included) with the USB cable included
2. Red LED turns ON during charging, turns OFF after the device is fully charged.
3. Red LED twinkles when the device has low power.

Paring Wee with mobiles (Bluetooth enabled) and Tablets

Diagram showing a device emitting sound waves to a smartphone displaying a wireless signal icon.

1. Press and hold the power button on Wee
2. A voice prompt "Bluetooth Enabled" indicates that Wee is now in Bluetooth® pairing mode.
3. Turn on the Bluetooth function on your phone and search for "Wee" in the available device list.
4. Pair the device to your phone using the passkey (0000).

Playing Music via Micro-SD card

Technical line drawing of a cylindrical device with internal components and a black arrow pointing to the top part (no text or symbols)

1. Turn on Wee and insert your Micro-SD card into the Micro-SD card slot as indicated above.
2. You will hear a voice prompt "SD Card Enabled" and the first track on the Micro-SD card begins playing automatically.

Controlling Music Playback

Line drawing of a hand pointing at a device with buttons and a pen (no text or symbols)

1. Use the Play/ Pause button to control music playback.
2. Skip to the previous track by short pressing the Toggle Backward button.
3. Skip to the next track by short pressing the Toggle Forward button.

Volume control

Control volume via the paired devices or by long pressing the Volume + / Volume - buttons on the device.

Answering Calls

1. Short press the "Play / Pause" button to answer the phone call.
2. Short press again to end a call.

Refusing Calls

1. During an incoming call press the Power button once to refuse the call.
