SB-720 - Kitchen scale Pyrex - Free user manual and instructions

USER MANUAL SB-720 Pyrex

Thank you for choosing a product of the new PYREX® electrical appliances range.

We hope that you will be satisfied by the use of this product.

The well-known heat-resistant glass cookware PYREX ^® has been a part of the Greek house holds for over 60 years. The range is now further supplemented with non-stick cookware and electrical appliances.

Περιεχόμενα

σελ\_1

- PARTS OF THE APPLIANCE - BATTERIES INSTALLATION & REPLACEMENT

page\_10

• USING YOUR KITCHEN SCALE

page\_11

- CARE AND CLEANING - TECHNICAL CHARACTERISTICS

9ελ 6

- IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC - SERVICE AND CUSTOMER CARE

Οδηγίες | Χρήσης

Zuyóç Kouzívaç SB-720

Instructions | Manual

Kitchen Scale SB-720

Please unfold the front page in order to check on the detailed view of the product.

• Read these instructions carefully and keep for future reference.
• Please keep the sales receipt for guarantee purposes.
• Remove all packaging.

IMPORTANT SAFEGUARDS

• The scale is intended for indoor use. Do not use it outdoors.
• The scale is intended only for domestic use. Any other use will cancel the warranty.
• Never use the scale for any other use than indicated.
• Your scale is electronic and thus its function may be influenced by temperature variations or by its movement.
• The scale must be placed on a flat, stable, smooth, and sheltered area. Always place the scale on a sheltered area when in use as air movement and may affect its accuracy.
• Always ensure the weighing platform is thoroughly clean before placing items directly on its surface.
• When weighing, do not place items on the edge of the weighing platform, always place them in the centre.

6-7_GR

• Do not overload the scale by exceeding the maximum weighing capacity of 15kg as this may damage the weighing sensor.
• Do not allow the scale to come into contact with strongly flavoured/coloured food or acids such as the zest from citrus fruits which could damage the surface of the scale.
• Do not expose the scale to any high electro-magnetic fields such as a cordless portable phone, computer, microwave oven etc. as this will interfere with the functioning and accuracy of the scale.
• Do not use excessive force when pressing the touch pads and never use a sharp object to operate them.
• Do not subject the scale to excessive force.
• Do not place hot food or hot containers such as saucepans onto the weighing platform.
• Never cut food on the weighing platform as sharp implements such as knives will damage the surface.
• Do not stand the scale near an oven or other direct source of heat.
• Do not operate or stand the scale in places with high humidity, where it may get wet.
• Never use highly corrosive or abstractive cleaning agents. Never use metal scouring pads for cleaning.
• Do not move the kitchen scale when in operation.
• Do not touch the kitchen scale with wet or damp hands.
• In case of a possible damage, do not attempt to repair the scale by yourself. Please contact one of the authorized PYREX-BENRUBI service centers.

• Any repair made by an unauthorized PYREX-BENRUBI Service Center CANCELS THE GUARANTEE.
• Any misuse of the device cancels the warranty.
• The appliance conforms EC regulation no. 1935/2004 of 27/10/2004 on materials intended to contact with food.

SAVE THESE INSTRUCTIONS

PARTS OF THE APPLIANCE

1. Weighing platform
2. LCD screen
3. ON/OFF / TARE button
4. Unit/Mode switch button
5. Battery cover

BATTERIES INSTALLATION & REPLACEMENT

• Make sure you connect the batteries with the correct polarity.
• If the scale is not going to be used for a long time, remove the batteries

batteries installation:

1. Unclip the battery cover (5) on the underside of the scale by pushing the clip inwards and then lifting off. Place the batteries inside the battery compartment, connecting them to the appropriate polarity.
2. Clip the battery cover back into place.

8-9_GB

Note: During use, if the battery symbol "LO" appears on the screen, it means that battery power is low and the batteries should be replaced.

batteries replacement:

1. Unclip the battery cover (5) on the underside of the scale by pushing the clip inwards and then lifting off. Remove the old batteries and fit the replacement (2xAAA),
2. Clip the battery cover back into place

disposal of the old batteries:

Please refer to section for the correct disposal of the product.

USING YOUR KITCHEN SCALE

Always place the scale on a dry and flat surface prior to weighing.

1. Press the "ON/OFF/Tare button" (3) to switch on.
2. LCD screen (2) will turn on and the display will show "0" after 2 seconds.
3. Place the item to be weighed onto the platform (1). The weight will appear on the display.
4. Press the "ON/OFF/Tare button" (3) to switch off.

Note: The maximum capacity is 15kg. This is the total weight of all ingredients plus the weight of the bowl.

Note: "O-LD" will be shown on the screen (2) in case of overload.

select weighing units:

After switching on the scale, press the «Unit/Mode switch button» (4). Each time the button is pressed, the weighing unit displayed will alternate among g / ml / oz.

auto switch off:

Automatic switch off will occur if the scale shows the same weight reading for 2 minutes.

manual switch off:

To conserve the battery power, switch off the scale when not in use. To do this, press and hold the "ON/OFF/Tare button" (3) until the LCD screen (2) switches off.

CARE AND CLEANING

• Do not immerse the scale in water. Wipe over the scale with a damp cloth, then dry thoroughly.
• Do not use abrasive or chemical agents to clean.

TECHNICAL CHARACTERISTICS

Model: Kitchen Scale SB-720

Batteries: 2xAAA (1.5V each)

10-11_GB

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC

At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources.

As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.

SERVICE AND CUSTOMER CARE

• All our products are subjected to rigorous quality control. Moreover, your appliance is guaranteed for a period of two (2) years from the date of purchase. If your product malfunctions or you find any defects, please address to the shop that you have bought it or send it or bring it to an authorized PYREX-BENRUBI Service Centre. To find the nearest authorized PYREX-BENRUBI Service Centre, visit www.benrubi.gr.
• No guarantee is provided, nor liability in case of any defect arising from willful or accidental damage, faulty installation, wrong handling or maintenance of the product, connection to an unsuitable electric supply, negligence, abnormal conditions, failure to follow our instructions, misuse or alteration or repair of the product without the approval of an authorized BENRUBI service center.

H. BENRUBI & FILS SA

27 Aghiou Thoma str, GR15124, Maroussi - Athens

Tel. / Customer Support: 210 6156400, e-mail: [e-mail]

PYREX®

www.pyrex.com.gr

H. BENRUBI & FILS SA

27 Aghiou Thoma str, GR15124, Maroussi - Athens

Tel. / Customer Support: 210 6156400, e-mail: [e-mail]

Pyrex® is a trademark of Coming Incorporated used under license by International Cookware
