| Product Type | 2-Port DisplayPort KVM Switch |
| Model | B140-202 |
| Number of Computers Supported | 2 |
| Video Interface | DisplayPort 1.2 |
| Maximum Video Resolution | 3840 x 2160 @ 60 Hz |
| Audio Support | Yes, via DisplayPort |
| USB Ports | 2 x USB 2.0 Type A |
| Power Source | USB bus-powered |
| Dimensions (W x D x H) | 4.5 x 2.5 x 0.9 in |
| Weight | 0.4 lbs |
| Enclosure Material | Plastic |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity Range | 0% to 80% RH (non-condensing) |
| LED Indicators | Port selection |
| Switch Control | Push button on unit |
| Included Cables | 2 x 6 ft DisplayPort cables |
| Compliance | RoHS |
| Warranty | 3 years limited |
| Maintenance | Wipe with dry cloth; no liquids |
| Repair / Spare Parts | Contact Tripp Lite support; no user-serviceable parts |
Frequently Asked Questions - B140-202 Tripp Lite
What is the maximum resolution supported by the B140-202?
The B140-202 supports resolutions up to 3840 x 2160 @ 60 Hz (4K) per DisplayPort 1.2.
Does the switch require external power?
No, the switch is USB bus-powered using the included USB cable connected to one of the computers.
Can I use a mouse and keyboard with this KVM?
Yes, the switch has 2 USB 2.0 ports for sharing peripherals like mouse, keyboard, or flash drives.
How do I switch between computers?
Press the front panel push button to toggle between the two connected computers. The LED indicates the active port.
Does it support audio?
Yes, audio is transmitted through the DisplayPort connection to the monitor with speakers or audio output.
What cables are included?
The package includes two 6 ft DisplayPort cables and one USB cable for power.
Is it compatible with both Windows and Mac?
Yes, it works with Windows, Mac, and Linux operating systems without driver installation.
Can I connect a third computer?
No, the B140-202 is designed for only 2 computers. For more, consider a switch with more ports.
How to clean and maintain the switch?
Use a soft, dry cloth to wipe the exterior. Do not use liquids or sprays.
What does the warranty cover?
Tripp Lite offers a 3-year limited warranty covering defects in materials and workmanship.
