USER MANUAL MiTab Evolution W1 Wolder
Visit your favourite websites.
Check your e-mail.
Keep in touch with friends and family.
Watch YouTube™ videos.
Browse the world's most popular video-sharing community.
Read your favourite books.
Download thousands of books with the included E-book reader. *
Discover thousands of apps for Android™ Games, applications and more with marketplace (to be installed by customer).
Connect to the Internet wirelessly.
High-speed Wi-Fi 802.11 big/n network.
Enjoy your medial library anywhere.
Portable powerhouse plays popular music, video, and photo formats.
MicroSD memory card reader.
Increase your storage capacity (up to 32 GB supported).
Built-in camera.
Convenient front-fading camera lens.
Automatic orientation detection.
Read any way you want: the display adjusts automatically!
Reading books in the ePub format requires the induced E-book reader application
Product overview
| 1 | |
| 2 | |
| 3 | |
| 5 | 4 |
| 7 | 6 |
| 8 |
1. Power key
Press to turn on the Tablet, or to turn the screen on or off.
Press and hold to access the Power Off menu.
- VOL+/VOL-
Press VOL+ to increase the volume level.
Press VOL- to decrease the volume level.
3. TF-CARD
Load external TF-cards here.
- Headphone
Audio output connection for headphones.
- DC IN 5V
Connect to an adapter or a computer to supply power.
-
HDMI
-
MICROPHONE
-
USB OTG AND HOST
Connect to a USB device or a computer to transfer data (e.g. music, videos, photos, files). Connect to a USB device
Getting Started Turning the Tablet on or off
To turn the Tablet on:
Press and hold the Power key until the LCD screen turns on. Wait until the Home screen appears; the Tablet is now ready for use.
To turn the Tablet off:
Press and hold the Power key until the Device
Options menu appears.
- Touch ok on the screen to turn off the Tablet.
Turning the Screen on or off (Standby)
When the Tablet is on, you can turn off the screen to conserve battery power. Simply press the Power key once to turn the screen off. Press the Power key again to turn the screen back on.
To conserve battery power, the screen can be set to turn off automatically when the Tablet is not in use (between 1 minute and 30 minutes).
This Screen time out option can be found in the Display menu.
Getting Started Unlocking the Screen
When the screen turns off, you will have to unlock the screen when you turn it back on.
To unlock the screen, slide the lock icon across the screen towards the lock icon.
About Applications
To open an application, touch the application icon on the home screen or in the Launcher where you can tap the icon right up on the home screen to get in.
Launcher screen:
The screen shown above is for illustrative purposes only. Reserves the right to modify and improve the final list of applications available on the Tablet.
About Applications Preinstalled Applications
Some applications have been installed on your Tablet for your convenience.
These applications include:
Browse the web.
Perform simple mathematical operations.
Take pictures or videos with the front-facing camera.
Check your e-mail.
Play music.
Access the Settings menu to adjust the options of the Tablet.
Installing Applications
You can also download and install additional applications from the device's applications marketplace, the web browser, or other sources.
The Tablet must be set to allow installation of applications from non-Market sources. Unknown sources option can be set in the Application settings menu.
Connect to a Wi-Fi network
Notification bar displays icons that indicate your Tablet's Wi-Fi status.
Notification that an open Wi-Fi network is in range.
Connected to a Wi-Fi network (waves indicate connection strength).
[noicon] There are no Wi-Fi networks in range, or Wi-Fi radio is off.
- Turn on the Wi-Fi button if it is not already on.
To turn on Wi-Fi:
a. Go to the Home screen: Press the Home key. b. Open the Settings menu: tap the icon right up on the home screen to get into the launcher.
Then, touch Settings icon.
c. Open the Wireless & Networks menu: Slide the icon to ON status.
When Wi-Fi is on, the Tablet will search and display a list of available Wi-Fi networks.
If a network that you have connected to usly is found, the Tablet will connect to it.
If you don't see your network in the list, you can broke the Tablet to re-scan. To scan for networks, tap the Menu key, and then touch Scan.
Connect to a Wi-Fi network
- Select an available Wi-Fi network to connect to: In the same Wi-Fi settings menu above, touch a network in the list.
If the network is open, the Tablet will prompt you to confirm connection to the network. Touch Connect to confirm.
If the network is secured (displayed with a
Lock icon), the Tablet will prompt you to enter a password or other credentials. Touch the Wireless password box to show the on-screen keyboard and then use it to enter the password. Touch Connect to confirm.
When you have successfully connected to a
Wi-Fi network, the Notifications bar at the bottom of the screen will show a Wi-Fi signal indicator.
To learn about how to add a Wi-Fi network when it is not in range or when the router is set to hide the network name (SSID); or to configure advanced Wi-Fi options, please refer to the manual.
Optional Connections
Connecting to a Computer
Connect the Tablet to a computer to transfer files.
- Connect your Tablet to the computer. With the included USB cable: Plug the small end of the cable into the USB 2.0 high speed connector of the Tablet. Plug the large end of the cable into an available USB 2.0 high speed port on the computer.
- When your Tablet is connected, slide up the USB icon right down on the screen and then touch icon USB connected.
3. Activals storage mode.
Touch button Turn on USB storage to activate the Tablet's built-in storage. When it is activated, you can copy files to or from your Tablet.
Specifications
| Processor | RK1 168 Dual-core ARM Cortex- |
| RAM | 1G8DDR3 |
| Storage | 8GB flash built-in; microSO card slot (max. 32GB supported) |
| Display | 10.1" IPSLCD(1280x800)Capacitive touch screen |
| Wi-Fi Network | IEEE802.11 b'g/n |
| Bluetooth | 4.0 |
| Audio Output | 3.5mmheadphone |
| PC Interface | USB 2.0 high speed |
| Additional features | Front camera(0.3MP), Rear camera 2.0MP1x1.0W speaker |
| Operating system | Android 4.2.2 |
| Power | DC 5V 2.5A |
| Playback Time (hours) | 6 hours of music3.5 hours of video3 hours of web browsing |
Music was tested with a 128 kbps MP3 file; video was tested with a 1920x1080 MPEG-4 AVC file; browsing was tested with the screen brightness set to default. Actual playback results may vary.
DECLARATION OF CONFORMITY
GLOBAL WOLDER GROUP S.L. Poligoro Industrial de Barros n°29, 39408 Barros, Cantabria. España, certifies that this product, referenced as mITab EVOLUTION WI, complies with the provisions of the Directive 99/05CE about Radio Equipment and Telecommunications Terminal (R&TTE), and the Directive 2004/108/CEE of Electromagnetic Compatibility standards in accordance to harmonized standards.
CE
Funcionalidades
Navegar na Web
Visitar Websites favoritos
