Product Type	Bicycle front light
Brand	Spanninga
Model	Exenda 60 USB
Luminous Flux	60 lumens
Light Source	LED
Power Source	USB rechargeable (Li-ion battery)
Charging Port	Micro USB
Charging Time	Approximately 2-3 hours
Runtime (Max)	Up to 4 hours (steady mode)
Light Modes	Steady, Flashing, Eco
Water Resistance	IPX4 (splash resistant)
Mounting	Handlebar mount (tool-free)
Dimensions	40 x 30 x 25 mm (approx.)
Weight	35 g
Housing Material	Aluminum/Plastic composite
Battery Indicator	Yes (LED changes color)
Certification	CE, RoHS
Included Accessories	USB cable, mounting bracket
Intended Use	Urban cycling, safety lighting
Maintenance	Clean with soft damp cloth; avoid solvents

Frequently Asked Questions - Exenda 60 USB Spanninga

How do I charge the Exenda 60 USB?

Connect the included Micro USB cable to the charging port on the light and a USB power source (computer, wall adapter). The LED indicator will turn red during charging and green when fully charged. Charging time is about 2-3 hours.

How do I mount the light on my handlebar?

Use the provided tool-free bracket. Place the bracket around the handlebar, tighten the strap or clasp, and then slide the light onto the bracket until it clicks. Ensure it is secure before riding.

How many light modes does it have and how do I switch?

The Exenda 60 USB has three modes: Steady (full brightness), Flashing, and Eco (lower brightness for longer runtime). Press and release the power button to cycle through modes. Hold the button for 2 seconds to turn off.

What is the battery life on a full charge?

Battery life varies by mode: up to 4 hours on Steady, up to 8 hours on Flashing, and up to 12 hours on Eco mode. Actual runtime may vary based on usage and battery age.

Is the light waterproof?

The Exenda 60 USB has an IPX4 rating, meaning it is splash-resistant and can withstand rain from any direction. However, it should not be submerged in water.

Can I use the light while it is charging?

No, the light cannot be used during charging. It must be disconnected from the USB cable to operate.

How do I know the battery level?

The light has a battery indicator LED. When turned on, green indicates full charge, yellow indicates medium, and red indicates low battery. When charging, red means charging and green means fully charged.

Is the light compatible with other mounting accessories?

The Exenda 60 USB uses a proprietary bracket included with the product. It is not compatible with standard GoPro mounts or other universal brackets. You can purchase replacement brackets from Spanninga.

What should I do if the light stops working?

First, try resetting by charging the light for a few minutes. If it still doesn't work, check the USB cable and power source. If the battery is completely drained, it may need a longer charge. If issues persist, contact Spanninga support for warranty or replacement.

Does the light come with a warranty?

Yes, Spanninga offers a 2-year limited warranty against manufacturing defects. Retain your proof of purchase and register the product on their website for warranty service.
